The VE803 HDMI USB (Universal Serial Bus) Extender extends an HDMI signal up to 60 meters from the HDMI source using two Cat 5e cables. It is capable of sending 1080i signals up to 60 meters & 1080p signals up to 40 meters. The VE803 is equipped with USB (Universal Serial Bus) connectors which allow you to extend any USB (Universal Serial Bus) device between the units. The USB (Universal Serial Bus) feature also provides support for touch panel control, allowing you to control the local HDMI source device from the remote display, or control the remote display through the local unit.\n\n\n\n Features Type AV transmitter & receiver Cable types supported Cat 5e Maximum transfer distance 60 m Supported video modes 1080i, 1080p LED indicators Yes Product colour Black, Grey Technical details Type AV transmitter & receiver Cable types supported Cat 5e Maximum transfer distance 60 m Supported video modes 1080i, 1080p Product colour Black, Grey Connector (s)HDMI Type A, USB (Universal Serial Bus) Type B, USB (Universal Serial Bus) Type A, RJ-45 Sustainability certificates Ro HSPorts & interfaces USB ports quantity 2RJ-45 input ports 2RJ-45 output ports 2HDMI in 1 Number of HDMI outputs 1DC-in jack Yes Power Operating voltage 5 VIndication LED indicators Yes Operational conditions Operating relative humidity (H-H)0
- 80% Storage temperature (T-T)-20
- 60 &176;COperating temperature (T-T)0
- 50 &176;CWeight & dimensions Weight 160 g Dimensions (Wx Dx H)31.6 x 71.6 x 23 mm\n\n\n\n


...

The VE803 HDMI USB (Universal Serial Bus) Extender extends an HDMI signal up to 60 meters from the HDMI source using two Cat 5e cables. It is capable of sending 1080i signals up to 60 meters & 1080p signals up to 40 meters. The VE803 is equipped with USB (Universal Serial Bus) connectors which allow you to extend any USB (Universal Serial Bus) device between the units. The USB (Universal Serial Bus) feature also provides support for touch panel control, allowing you to control the local HDMI source device from the remote display, or control the remote display through the local unit.\n\n\n\n Features Type AV transmitter & receiver Cable types supported Cat 5e Maximum transfer distance 60 m Supported video modes 1080i, 1080p LED indicators Yes Product colour Black, Grey Technical details Type AV transmitter & receiver Cable types supported Cat 5e Maximum transfer distance 60 m Supported video modes 1080i, 1080p Product colour Black, Grey Connector (s)HDMI Type A, USB (Universal Serial Bus) Type B, USB (Universal Serial Bus) Type A, RJ-45 Sustainability certificates Ro HSPorts & interfaces USB ports quantity 2RJ-45 input ports 2RJ-45 output ports 2HDMI in 1 Number of HDMI outputs 1DC-in jack Yes Power Operating voltage 5 VIndication LED indicators Yes Operational conditions Operating relative humidity (H-H)0
- 80% Storage temperature (T-T)-20
- 60 &176;COperating temperature (T-T)0
- 50 &176;CWeight & dimensions Weight 160 g Dimensions (Wx Dx H)31.6 x 71.6 x 23 mm\n\n\n\n


...

ATEN VE814A is an HDBase T Video Extender that is capable of sending HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. Featuring dual synchronous outputs, the VE814A can transmit video signal to two remote displays & one at the local side. This HDCP 2.2-compliant extender meets the HDMI

Specification, including 3D, Deep Color, the maximum data rate of (10.2 Gbps), & 4K video quality up to 100 m.\n\n The VE814A supports RS-232 & IR signaling pass-through, allowing you to control the HDMI source device from the remote unit (VE814AR) while granting access to the HDMI display device from the local unit (VE8014AT). In addition, it supports Long Reach Mode that extends HDMI signals up to 150 m, 1080p, via a single Cat 5e/6 cable.\n\n The VE814A is a powerful solution for where digital signage is required, such as bars, educational spaces, & public transportation stations, allowing display of identical contents at different spots.\n\n\n\n\n\n Product Model: VE814A\n Datasheet: https://d 5bm 31en 4blvo.cloudfront.net/pdf/mmo_71524378_1589813967_8352_30482.pdf\n\n

...

ATEN VE814A is an HDBase T Video Extender that is capable of sending HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. Featuring dual synchronous outputs, the VE814A can transmit video signal to two remote displays & one at the local side. This HDCP 2.2-compliant extender meets the HDMI

Specification, including 3D, Deep Color, the maximum data rate of (10.2 Gbps), & 4K video quality up to 100 m.\n\n The VE814A supports RS-232 & IR signaling pass-through, allowing you to control the HDMI source device from the remote unit (VE814AR) while granting access to the HDMI display device from the local unit (VE8014AT). In addition, it supports Long Reach Mode that extends HDMI signals up to 150 m, 1080p, via a single Cat 5e/6 cable.\n\n The VE814A is a powerful solution for where digital signage is required, such as bars, educational spaces, & public transportation stations, allowing display of identical contents at different spots.\n\n\n\n\n\n Product Model: VE814A\n Datasheet: https://d 5bm 31en 4blvo.cloudfront.net/pdf/mmo_71524378_1589813967_8352_30482.pdf\n\n

...

With the rapid development of HDBase T technology, ATEN has released the new VM3909H HDMI HDBase T-Lite Matrix Switch. The switch extends uncompressed 4K / Full HD digital video, audio, IR & power via HDBase T technology through a single Cat 6a cable up to 40/70 meters.\n\n When the VM3909H is combined with VE805R receivers, it supports both ATEN Seamless Switch&132;&162; technology & Video Wall functionality. ATEN&153;s exclusive Seamless Switch&132;&162; technology employs an FPGA graphics processor to ensure continuous video streaming, real-time control & stable signal transmission across all sources. The Video Wall functionality means that you can create 18 video wall profiles for custom screen layouts through an easy-to-use web interface. The Power over HDBase T (POH) feature provides an ingenious way to power the VE802R receivers through the Cat 5e cable without the need of using an additional power supply.\n\n The VM3909H offers flexibility with reliable signal distribution controlled via front-panel pushbuttons, IR, RS-232 & Ethernet (Telnet / Web GUI) connections. It&153;s designed as a functional & integrated control system built for residential, commercial & conference center settings\n\n
Features:\n-Supports 9 HDMI inputs & mirrored 9 HDMI & HDBase T outputs\n-The mirrored HDMI outputs can be used to verify the corresponding HDBase T output or as an additional video display*\n-HDBase T Connectivity " connects HDMI displays over a long distance via one Cat 5e/6/6a cable\n-HDBase T Anti-jamming " resists signal interference during high-quality video transmission\n-Power over HDBase T (POH) " supplies power over a long distance from the switch to a receiver over a single Cat 5e/6/6a cable ** / ***\n-Seamless Switch&132;&162; Technology " ATEN FPGA engine unifies video formats to provide continuous video streams, real-time switching & stable signal transmissions**\n-Video Wall
- means that you can create custom video wall layouts via intuitive web GUI**\n-EDID Expert&132;&162; " selects optimum EDID settings for smooth power-up, high-quality display & use of the best video resolution across different screens\n-Multiple Control Methods " system management via front-panel pushbuttons, IR, RS-232 & -Ethernet (Telnet / Web GUI) connections\n-Bi-directional IR channel ports support full frequency IR signals from 30 KHz to 60 KHz \n-Supports ATEN&153;s Lock Pro&132;&162; HDMI cable lock for securing HDMI cables to the device\n-Firmware Upgradeable\n-Rack Mountable (VM3909H: 2U Design)\n\n Note:\n* The HDMI outputs can't support the Video Wall & Seamless Switch&132;&162; functions.\n** The Seamless Switch&132;&162;, Video Wall & POH features are only available when used a compatible receiver. \n*** The VM3909H can provide up to 15.4 W @ 48 VDC of power per port & 75W of total power ; please ensure that the power consumption of the devices connected to the VM3909H does not exceed this limit.\n\n Package Contents\n 1x VM3909H HDMI HDBase T-Lite Matrix Switch\n 1x Power Cord\n 1x Mounting Kit\n 1x User Instructions\n\n\n\n\n\n\n\n Model: VM3909H-AT-E\n\n\n\n\n\n\n\n

...

The VS182B True 4K HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to two displays at the same time. It supports all HDMIenabled equipment, such as DVD players, satellite set- top boxes & all HDMI monitors, displays, projectors, or TVs.\n\n The VS182B True 4K HDMI Splitter is HDMI 2.0 compliant, 4K at 60 Hz (4:4:4), & supports multiple streaming audio, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational & commercial settings.\n\n- Connects one HDMI source to two HDMI displays at the same time\n- HDMI (3D, Deep Color, 4K); HDCP 2.2 Compatible\n- Supports HDR\n- Supports max resolutions of up to 4096 x 2160 / 3840 x 2160 @ 60 Hz (4:4:4)\n- Long distance transmission- up to 15 m (1920x 1200)/ 1.8m (True 4K)*\n- Max pixel clock rate up to 600 MHz\n- Max data rate up to 18 Gbps (6 Gbps per lane)\n- LED indication of power status & source devices\n- EDID Expert&132;&162; " Selects optimum EDID settings for smooth power-up, high-quality display & use of the best video resolution via EDID DIP Switch, allowing users to effortlessly switch among Port 1, Default, & Auto\n- Plug-&-play " No software installation required\n\n\n\n\n\n Product Model: VS182B\n\n\n ...

The VS182B True 4K HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to two displays at the same time. It supports all HDMIenabled equipment, such as DVD players, satellite set- top boxes & all HDMI monitors, displays, projectors, or TVs.\n\n The VS182B True 4K HDMI Splitter is HDMI 2.0 compliant, 4K at 60 Hz (4:4:4), & supports multiple streaming audio, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational & commercial settings.\n\n- Connects one HDMI source to two HDMI displays at the same time\n- HDMI (3D, Deep Color, 4K); HDCP 2.2 Compatible\n- Supports HDR\n- Supports max resolutions of up to 4096 x 2160 / 3840 x 2160 @ 60 Hz (4:4:4)\n- Long distance transmission- up to 15 m (1920x 1200)/ 1.8m (True 4K)*\n- Max pixel clock rate up to 600 MHz\n- Max data rate up to 18 Gbps (6 Gbps per lane)\n- LED indication of power status & source devices\n- EDID Expert&132;&162; " Selects optimum EDID settings for smooth power-up, high-quality display & use of the best video resolution via EDID DIP Switch, allowing users to effortlessly switch among Port 1, Default, & Auto\n- Plug-&-play " No software installation required\n\n\n\n\n\n Product Model: VS182B\n\n\n ...

The VS184 HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to four displays at the same time. It supports all HDMI-enabled equipment, such as DVD players, satellite set-top boxes & all HDMI displays.\n\n The VS184 HDMI Splitter is HDCP (High Bandwidth Digital Content Protection) compliant, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational & commercial settings.\n\n- Connects one HDMI A/V source to four HDMI displays at the same time\n- Superior video quality " HDTV resolution of 480p, 720p, 1080i & 1080p (1920x 1080); VGA, SVGA, SXGA, UXGA (1600x 1200), WUXGA (1920x 1200)\n- Cascade distance: Source to Device -1.8m, Device to Device-15m, Device to Display-20m\n- HDMI (Deep Color)\n- Supports Dolby True HD & DTS HD Master Audio\n- Cascadable to 3 levels
- provides up to 64 HDMI signals.\n- Long distance transmission
- 20 m (24 AWG)\n- DDC compatible\n- HDCP 1.1 compatible\n- Signaling rates up to 2.25 Gbits in support of 1080p display\n- All-metal casing\n- LED indication of display devices\n- Plug-&-play
- no software installation required\n- Easy & affordable way to take your home theater system to the next level, or upgrade presentations, training, & video broadcasts in a corporate, educational, or commercial setting\n\n\n\n\n\n Product Model: VS184B\n Datasheet: https://d 5bm 31en 4blvo.cloudfront.net/pdf/mmo_37237284_1498426814_3578_14309.pdf\n\n


...

The VS184 HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to four displays at the same time. It supports all HDMI-enabled equipment, such as DVD players, satellite set-top boxes & all HDMI displays.\n\n The VS184 HDMI Splitter is HDCP (High Bandwidth Digital Content Protection) compliant, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational & commercial settings.\n\n- Connects one HDMI A/V source to four HDMI displays at the same time\n- Superior video quality " HDTV resolution of 480p, 720p, 1080i & 1080p (1920x 1080); VGA, SVGA, SXGA, UXGA (1600x 1200), WUXGA (1920x 1200)\n- Cascade distance: Source to Device -1.8m, Device to Device-15m, Device to Display-20m\n- HDMI (Deep Color)\n- Supports Dolby True HD & DTS HD Master Audio\n- Cascadable to 3 levels
- provides up to 64 HDMI signals.\n- Long distance transmission
- 20 m (24 AWG)\n- DDC compatible\n- HDCP 1.1 compatible\n- Signaling rates up to 2.25 Gbits in support of 1080p display\n- All-metal casing\n- LED indication of display devices\n- Plug-&-play
- no software installation required\n- Easy & affordable way to take your home theater system to the next level, or upgrade presentations, training, & video broadcasts in a corporate, educational, or commercial setting\n\n\n\n\n\n Product Model: VS184B\n Datasheet: https://d 5bm 31en 4blvo.cloudfront.net/pdf/mmo_37237284_1498426814_3578_14309.pdf\n\n


...

AT-OME-MH21AT-OME-MH21\n\n&162; Two-input AV switcher\n&162; USB (Universal Serial Bus)-C input for AV & data\n&162; Integrated USB (Universal Serial Bus) 3.0 hub\n&162; 4K/UHD capability @ 60 Hz with 4:4:4 chroma sampling plus support for HDR formats\n&162; Selectable 4K to 1080p downscaling\n&162; Automatic input selection & automatic display control\n&162; Audio de-embedding\n\n Learn More\n\n The Atlona AT-OME-MH21 is a compact versatile switcher with HDMI & USB (Universal Serial Bus)-C inputs. It is equipped with features for complete AV integration in huddle rooms & small meeting spaces including automatic switching & display control audio de-embedding & a USB (Universal Serial Bus) 3.0 hub for video conferencing peripherals or touch displays. Part of the Omega&132;&162; Series of integration products for modern AV communications & collaboration the OME-MH21 is HDCP 2.2 compliant & supports 4K HDR & 4K/60 4:4:4 at HDMI data rates up to 18 Gbps. in addition 4K downscaling to 1080p @ 60 30 or 24 Hz is available when connected to an HD display. The OME-MH21

Includes:: USB (Universal Serial Bus) 3.0 & USB (Universal Serial Bus)-C interfaces for two host PCs plus two peripheral devices such as a camera microphone speakerphone touch-enabled display or keyboard & mouse.\n\n USB for Video Conferencing with Zoom Skype for Business Microsoft Teams & More\n\n The OME-MH21 features interfacing for host PCs & USB (Universal Serial Bus) peripherals making it ideal for video conferencing & UC (unified communications) platforms such as Zoom Skype? for Business Microsoft? Teams? Cisco? Webex? Blue Jeans & Go To Meeting?. Available from Atlona is the AT-HDVS-CAM PTZ camera with USB (Universal Serial Bus) interface.\n\n Compact Flexible Switcher with Integrated AV System Automation\n\n The OME-MH21 combines the benefits of auto-switching integrated display control USB (Universal Serial Bus) interfacing & more. It incorporates many popular integration convenience features while delivering excellent performance & value for 4K presentation & video conferencing applications. The USB (Universal Serial Bus)-C input is ideal for AV interfacing with newer laptops & mobile devices plus data connectivity to the USB (Universal Serial Bus) hub. For additional integration convenience the OME-MH21 features audio de-embedding & remote management with Atlona Management System (AMS).\n\n Automatic Display Control\n\n The OME-MH21 provides control to a display through IP RS-232 IR or CEC* without the need for a separate control system. This simplifies system design & integration while reducing costs. With automatic display control the OME-MH21 can trigger a display to power on automatically whenever a laptop or other device is connected. At the end of the presentation when the presenter disconnects the laptop the OME-MH21 forces the display to power off. Ease of presenter interaction with the system & the savings incurred by automatic display shutdown provide a significant return on investment. The OME-MH21 display control capability can also be triggered by an external control system.\n\n* Consumer Electronics Control (CEC): Atlona does not guarantee the function of CEC with all televisions. We can confirm proper operation with many current Samsung Panasonic Sony & LGTVs. Many manufacturers do not support the CEC &156;off&157; command when sent from a source & older TVs use proprietary commands. Atlona only supports those TVs that follow CEC command structure from HDMI 1.2a & support the &156;off&157; command when issued by a source. We encourage any dealer to get evaluation product from Atlona prior to designing a system around this control technology or be prepared to use other methods to control their displays if Atlona CEC is not compatible with the installed displays.\n\n Reliable Auto-Switching\n\n The OME-MH21 can automatically select an input source based on detection of the 5 volt hot plug detect (HPD) signal as well as active video. This ensures reliable auto-switching operation for all video sources including DVRs Display Port / Mini Display Port adapters & other devices that always maintain the HPD line at the 5 volt &156;high&157; state but may not be delivering active video.\n\n Applications\n\n Huddle rooms & small meeting spaces " The OME-MH21 provides a compact yet comprehensive & cost-effective integration solution. When installed below a meeting table the available Pocket&132;&162; 3H (AT-PKT-3H) provides convenient tabletop AV & USB (Universal Serial Bus) cable access for easy BYOD connectivity.\n Video conferencing " This switcher provides interfacing with USB (Universal Serial Bus) devices for soft codec conferencing with video & USB (Universal Serial Bus) switched together between two host PCs. The USB (Universal Serial Bus) interfacing is also ideal for a touch-enabled display enabling on-screen control of a PC.\n Product compatibility\n\n Please see below for a list of complementary integration products for the OME-MH21.\n\n\n\n\n\n\n\n\n\n

...
