https://youtu.be/fm 5 Ip Y Qx ZTA\n\n\n\n\n\n\n\n Product Model: ROG Strix Arion\n\n\n ...

ROG Strix B450-F Gaming II delivers all the essentials needed for a well-balanced build. Designed to handle the latest 3rd Gen AMD Ryzen processors, ROG Strix B450-F Gaming II features amped-up power delivery, optimized thermal design & more stable DDR4 memory. BIOS Flash Back makes upgrading easy to give any dream build a head start, & intuitive ROG software ensures a superior gaming experience. AMPED PERFORMANCE With a robust power design to drive multi-core Ryzen processors, plus cooling, storage, connectivity & audio options for a wide range of hardware, ROG Strix B450-F Gaming II offers gamers everything they need for a budget or high-performance build. Power Design Digital power control & an array of discrete MOS ensure ROG Strix B450-F Gaming II has the muscle to control the latest AMD CPUs. VRM Thermal Design The ROG Strix B450-F Gaming II uses new alloy chokes that deliver better efficiency, & high-quality thermal pads to help transfer heat from the VRM array to a sink that has ample surface area for the latest processors. & to ensure critical components always make optimal contact, there's a backplate on the rear of the board that helps balance MOSFET temperatures while providing structural reinforcement. M.2 Heatsink An integrated heatsink keeps the M.2 SSD at optimum operating temperature for consistent performance & reliability. BUILD SMART Packed with intuitive software & DIY-friendly options for convenient setup & use, cyberpunk inspired aesthetics, plus a diverse ecosystem of components, ROG Strix B450-F Gaming II is the key to any outstanding gaming build. Dual PCIe 3.0 x 4 M.2 Dual PCIe 3.0x 4 M.2 slots provide NVM Express SSD RAID support for an incredible performance boost. Create a RAID configuration with up to three PCI Express 3.0 storage devices via two M.2 slots & a PCIe x 16 slot to enjoy incredible data-transfer speeds. DDR4 OC 4400 M Hz Tuned to take full advantage of Ryzen's capabilities, & ready for the latest memory kits, ROG Strix B450 Gaming Series motherboards are built specifically for high-performance gaming rigs. Maximize frame rates with a high-bandwidth memory kit or leverage a host of tuning options to extract peak performance potential from a modest setup. Intel Gigabit Ethernet Intel Ethernet Controller I211-AT ensures fast & smooth data exchanges. It reduces CPU overhead & increases TCP & UDP throughput, leaving more processing power for gaming. M.2 Socket with E Key Integrated with Intel Wireless AC/AX technology, the M.2 socket offers PCIe support for a faster & more cost-effective Wi Fi & Bluetooth 5.1 solution*. * Bluetooth 5.1 will be ready in Windows 10 build 19041 or later. LANGuard Featuring advanced signal-coupling technology & high-tolerance components, LANGuard provides consistent Ethernet performance & greater protection against static electricity & power surges. Supreme FX Built-in ROG Supreme FX audio technology ensures pristine audio for ROG Strix B450-F Gaming II. Along with ensuring a flat frequency response for a neutral, detailed sound signature, it offers two front-panel outputs driven by op amps that deliver high-quality audio to gaming headsets. BUILD SMART Packed with intuitive software & DIY-friendly options for convenient setup & use, cyberpunk inspired aesthetics, plus a diverse ecosystem of components, ROG Strix B450-F Gaming II is the key to any outstanding gaming build. 5-Way Optimization Take care of complex tuning with just one click. ASUS 5-Way Optimization is a system-wide tuning utility that overclocks the processor & tunes fan speeds to ensure the best balance between cooling & acoustics. Pre-mounted I/O Shield Patented I/O shield is finished in sleek matte black & comes pre-mounted to make it easy to install the motherboard. BIOS Flash Back Users can place a BIOS file onto a FAT32-formatted USB (Universal Serial Bus) drive & simply plug it into the USB (Universal Serial Bus) BIOS Flash Back port & press a button to update the (UEFI) BIOS. Updates can be made even if memory or CPU aren't present. Pre-mounted I/O Shield Patented I/O shield is finished in sleek matte black & comes pre-mounted to make it easy to install the motherboard. BIOS Flash Back Users can place a BIOS file onto a FAT32-formatted USB (Universal Serial Bus) drive & simply plug it into the USB (Universal Serial Bus) BIOS Flash Back port & press a button to update the (UEFI) BIOS. Updates can be made even if memory or CPU aren't present. BIOS Flash Back Four onboard LEDs indicate power status, & any problem with the CPU, memory, graphics card or boot device for quick diagnosis. Safe Slot The reinforced ASUS Safe Slot provides stronger PCIe device retention & greater shearing resistance. Cyber-inspired Looks ROG Strix B450-F Gaming II embodies the unique Strix gaming spirit with its stylish cut across the I/O shroud, its cyberpunk-inspired ROG eye logo across the PCB plate, & futuristic cybertext highlights. Outshine the Competition ASUS AURA SYNC ROG Strix motherboards deliver sterling performance & superior aesthetics to outshine the competition. They also feature built-in ASUS Aura technology that enables full RGB lighting control & a variety of presets for embedded RGB LEDs as well as lighting strips connected to onboard RGB headers. In addition, all lighting can be easily synced with an ever-growing portfolio of Aura-capable ASUS hardware. Certified Compatibility ROG Strix motherboards undergo an extensive certification program to ensure the very best compatibility with the widest range of components & devices. For a smooth build process, refer to our list of guaranteed-compatible components. To help with memory upgrades, the list also

Includes:: a dedicated Qualified Vendor list (QVL). The ROG Strix Ecosystem Awaits Up your game with ROG Strix. Enjoy complementary aesthetics, control & compatibility across AIO coolers, cases, peripherals, & much more! ROG offers more choices than any other br&. ROG GIVES YOU MORE ROG-exclusive software utilities deliver intuitive audio tuning & gaming enhancements that allow you to configure your gaming build the way you want. Sonic Studio III Sonic Studio supports HRTF-based (head-related transfer function) virtual surround for VR headsets, casting an immersive aural landscape that draws you deeper into the action. The intuitive Sonic Studio interface also offers a range of EQ options & one-click presets, allowing you to tailor acoustics to suit personal preferences or the characteristics of your headset. AI Networking The proprietary ROG Game First VI utility is designed to help all users " beginners, experts, & everyone in between " optimize network settings to ensure smooth online gameplay. New to this generation, Game First VI features AI-enhanced identification & boost technology to ensure faster & smarter network optimization. Identification Game First VI analyzes your usage patterns & the digital signatures of your applications & compares them to a database of over 200, 000 apps. The database is regularly updated to ensure that apps are recognized. Boost Game First VI intelligently switches application priority & adjusts bandwidth accordingly, depending on the situation. When gaming, it accelerates & prioritizes game packets to give you supersmooth online gameplay " even when you're streaming high-quality video to your audience or transferring large files. Visualization An intuitive graph gives you an overview of the network in real time. Simply click on the tab to view current bandwidth usage of each application, geolocation status of each network connection, & an analysis of each Wi Fi channel. Armoury Crate Armoury Crate is a software utility designed to give you centralized control of supported gaming products, making it easy to tune the look & feel of your system. From a single intuitive interface, Armoury Crate lets you easily customize RGB lighting & effects for compatible devices & synchronize them with Aura Sync to create a unified lighting scheme across your system. You can also use Armoury Crate to download the user manual, drivers & software. In addition, Armoury Crate features a dedicated product registration page as well as a news feed to help you stay in touch with the gaming community. RAMCache III RAMCache lll software turns milliseconds into microseconds to boost game-load times. Fully compatible with the latest NVM Express storage options, its uniquely intelligent technology effectively caches an entire storage device so that favorite games & apps launch at breakneck speeds.\n\n\n\n Internal I/ONumber of M.2 (M) slots 2 Front panel connector Yes 12V power connector Yes Supported storage drive interfaces SATA IIIUSB 2.0 connectors 1USB 3.2 Gen 1 (3.1 Gen 1) connectors 1TPM connector Yes Number of SATA III connectors 6 Number of COM connectors 1 Number of chassis fan connectors 3 Front panel audio connector Yes CPU fan connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Technical details Motherboard chipset family AMDMotherboard chipset AMD B450HDMI version 2.0b Motherboard form factor ATXComponent for PCAudio Audio output channels 7.1 channels Performance Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64 Motherboard chipset family AMDMotherboard chipset AMD B450RAID levels 0, 1, 10 Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCProcessor Processor manufacturer AMDCompatible processor series AMD Ryzen 3, AMD Ryzen 5, AMD Ryzen 7, 3rd Generation AMD Ryzen 9 Maximum number of SMP processors 1 Processor socket Socket AM4 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMMemory channels Dual-channel Supported memory clock speeds 2133, 2400, 2666, 2800, 3000, 3200, 3466, 3600, 3866, 4000, 4400 MHz Maximum internal memory 128 GBUnbuffered memory Yes Storage controllers Supported storage drive types HDD & SSDSupported storage drive interfaces SATA IIIRAID levels 0, 1, 10 Rear panel I/O ports USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2 Display Port version 1.2USB 2.0 ports quantity 2S/PDIF out port Yes PS/2 ports quantity 1HDMI version 2.0b HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1 Digital audio optical out 1 Network Ethernet LANYes Wi-Fi No Wake-on-LAN ready Yes LAN controller Intel&174; I211-ATEthernet interface type Gigabit Ethernet Features Windows operating systems supported Windows 10 x 64 Motherboard chipset family AMDMotherboard chipset AMD B450 Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCAudio chip Supreme FX S1220 A Expansion slots Number of M.2 (M) slots 2PCI Express x 1 (Gen 2.x) slots 3PCI Express x 16 (Gen 3.x) slots 3BIOSBIOS type UEFI AMIClear CMOS jumper Yes BIOS memory size 256 Mbit Software Windows operating systems supported Windows 10 x 64 Drivers included Yes Weight & dimensions Width 305 mm Depth 244 mm Packaging content Drivers included Yes Cables included SATA\n\n\n\n

...

Designed for those seeking to get the most out of their build, ROG Strix B550 Gaming series motherboards offer a feature-set usually found in the higher-end ROG Strix X570 Gaming series, including the latest PCIe&174; 4.0 connectivity. Offering robust power delivery & effective cooling, ROG Strix B550-A Gaming is well-equipped to handle 3rd Gen AMD Ryzen&132;&162; CPUs. As an added bonus, outstanding performance is complemented by a stunning silver-&-white finish & cyberpunk-inspired aesthetics that present a standout look.\n\n Advance Your Gaming Immersion\n ROG Strix B550-A Gaming is PCIe&174; 4.0-ready & provides the latest connectivity options for supersmooth networking & blisteringly fast file transfers. Audio enhancements give you a massive advantage, allowing you to pick up on the subtlest of cues for a completely immersive gaming experience.\n\n All-round Performance\n ROG Strix B550-A Gaming provides robust power delivery to fuel Ryzen's cores, comprehensive cooling, & support for faster memory " so it has everything you need to load up your build with high-performance components for playing in the big leagues.\n\n Cooler by Design\n ROG Strix B550 series features the most comprehensive cooling options ever, configurable via Fan Xpert 4 or the UEFI BIOS.\n\n ASUS Opti Mem II\n To provide AMD's latest CPUs unfettered access to memory bandwidth, motherboard trace routing has been reimagined with the ROG Strix B550-A Gaming. Integrated Opti Mem II technology carefully maps memory signal pathways across PCB layers to reduce vias, & it also adds shielding zones that significantly reduce crosstalk. To further enhance overclocking headroom for fully stacked memory configurations, a highly customized Daisy Chain layout delivers time-aligned signaling.\n\n Play Your Own Style\n The cyberpunk-inspired aesthetics of ROG Strix B550-A Gaming are accentuated by the bold slashes & cybertext. By pairing your rig with other products from the diverse ROG ecosystem, you can create a fully customized gaming setup that reflects your personal style.\n\n Pre-mounted I/O shield\n Patented I/O shield is finished in sleek matte black & comes pre-mounted to make it easy to install on the motherboard.\n\n CERTIFIED COMPATIBILITY\n ROG Strix motherboards undergo an extensive certification program to ensure the very best compatibility with the widest range of components & devices. For a smooth build process, refer to our list of guaranteed-compatible components. To help with memory upgrades, the list also

Includes:: a dedicated Qualified Vendor list (QVL).\n\n The ROG Strix Ecosystem Awaits\n Up your game with ROG Strix. Enjoy complementary aesthetics, control & compatibility across AIO coolers, cases, peripherals, & much more! ROG offers more choices than any other br&.\n\n ROG Gives You More\n ROG-exclusive software utilities deliver intuitive audio tuning & gaming enhancements that allow you to configure your gaming build the way you want.\n\n UEFI BIOS\n The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, & tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as comprehensive features for seasoned veterans.\n\n AI Networking\n The proprietary ROG Game First VI utility is designed to help all users " beginners, experts, & everyone in between " optimize network settings to ensure smooth online gameplay. New to this generation, Game First VI features AI-enhanced identification & boost technology to ensure faster & smarter network optimization.\n\n Armoury Crate\n Armoury Crate is a new software utility designed to give you centralized control of supported gaming products, making it easy to tune the look & feel of your system. From a single intuitive interface, Armoury Crate lets you easily customize RGB lighting & effects for compatible devices & synchronize them with Aura Sync to create a unified lighting scheme across your system. You can also use Armoury Crate to download the user manual, drivers & software. In addition, Armoury Crate features a dedicated product registration page as well as a news feed to help you stay in touch with the gaming community.\n\n RAMCache III\n RAMCache lll software turns milliseconds into microseconds to boost game-load times. Fully compatible with the latest NVM Express&174; storage options, its uniquely intelligent technology effectively caches an entire storage device so that favorite games & apps launch at breakneck speeds.\n\n\n\n\n\n\n\n Model: ROG STRIX B550-A GAMING\n\n\n\n Manual: https://d 5bm 31en 4blvo.cloudfront.net/uploads/pdf/mmo_85936613_1600938883_6282_7738.pdf\n\n\n\n

...

Advance Your Gaming Immersionn ROG Strix B550-F Gaming is PCIe&174; 4.0-ready & provides the latest connectivity options for supersmooth networking & blisteringly fast file transfers. Audio enhancements give you a massive advantage, allowing you to pick up on the subtlest of cues for a completely immersive gaming experience.nn PCIe 4.0-Readyn ROG Strix B550-F Gaming features two M.2 slots, one of which supports the latest PCIe 4.0 standard to provide maximum storage flexibility & the fastest data speeds available via the 3rd Gen AMD Ryzen platform. Both M.2 slots support up to the type 22110 socket & NVM Express&174; RAID for a performance boost.nn All-round Performancen ROG Strix B550-F Gaming provides robust power delivery to fuel Ryzen's cores, comprehensive cooling, & support for faster memory " so it has everything you need to load up your build with high-performance components for playing in the big leagues.nn Play Your Own Stylen The cyberpunk-inspired aesthetics of ROG Strix B550-F Gaming are accentuated by the bold slashes & cybertext. By pairing your rig with other products from the diverse ROG ecosystem, you can create a fully customized gaming setup that reflects your personal style.nn UNDENIABLY ROG STRIXn ROG Strix B550-F Gaming embodies the ROG spirit with eye-catching aesthetics, including the next-generation distorted ROG eye logo & recessed cybertext patterning etched on the I/O shroud. These new designs move ROG Strix boldly into the future, while clearly reflecting the series' gaming roots.nn ROG Gives You Moren ROG-exclusive software utilities deliver intuitive audio tuning & gaming enhancements that allow you to configure your gaming build the way you want.nn UEFI BIOSn The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, & tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as comprehensive features for seasoned veterans.\n\n\n\n\n\n\n\n\n\n Model: ROG STRIX B550-F GAMING\n\n\n\n\n\n Manual: http://objects.icecat.biz/objects/mmo_79582270_1594017917_3125_32389.pdf\n\n\n\n\n\n\n\n ...

ROG Strix B550 Gaming series motherboards offer a feature-set usually found in the higher-end ROG Strix X570 Gaming series, including the latest PCIe&174; 4.0. With robust power delivery & effective cooling, ROG Strix B550 Gaming is well-equipped to handle Zen 3 architecture AMD Ryzen&132;&162; CPUs. Boasting futuristic aesthetics & intuitive ROG software, ROG Strix B550-F Gaming Wi Fi II gives you a head start on your dream build. ADVANCE YOUR GAMING IMMERSION ROG Strix B550-F Gaming Wi Fi II is PCIe&174; 4.0-ready & provides the latest connectivity options for supersmooth networking & blisteringly fast file transfers. Audio enhancements give you a massive advantage, allowing you to pick up on the subtlest of cues for a completely immersive gaming experience. PCIE 4.0-READY ROG Strix B550-F Gaming Wi Fi II features two M.2 slots, one of which supports the PCIe 4.0 standard to provide maximum storage flexibility & the lightning-fast data speeds. Both M.2 slots support up to the type 22110 socket & NVM Express&174; RAID for a performance boost. Wi Fi 6E Onboard Wi Fi 6E technology takes advantage of the newly available radio spectrum in the 6 GHz b&. It delivers ultrafast wireless networking speeds & enhanced capacity as well as better performance in dense wireless environments. * Wi Fi 6E availability & features are dependent on regulatory limitations & co-existence with 5 GHz Wi Fi. Intel 2.5 Gb Ethernet Onboard 2.5 Gb Ethernet gives your wired connection a boost, with speeds that are 2.5 times faster than standard Ethernet connections for speedy file transfers, lag-free gaming, & high-res video streaming. SUPREMEFX Built-in ROG Supreme FX audio technology ensures pristine audio for ROG Strix B550-F Gaming Wi Fi II. Along with ensuring a flat frequency response for a neutral, detailed sound signature, it offers two front-panel outputs driven by op amps that deliver high-quality audio to gaming headsets. ALL-ROUND PERFORMANCE ROG Strix B550-F Gaming Wi Fi II provides robust power delivery to fuel Ryzen&153;s cores, comprehensive cooling, & support for faster memory " so it has everything you need to load up your build with high-performance components for playing in the big leagues. COOLER BY DESIGN ROG Strix B550 series features the most comprehensive cooling options ever, configurable via Fan Xpert 4 or the UEFI BIOS. ASUS Opti Mem II To provide AMD's latest CPUs unfettered access to memory bandwidth, motherboard trace routing has been reimagined with the ROG Strix B550-F Gaming Wi Fi II. Integrated Opti Mem II technology carefully maps memory signal pathways across PCB layers to reduce vias, & it also adds shielding zones that significantly reduce crosstalk. To further enhance overclocking headroom for fully stacked memory configurations, a highly customized Daisy Chain layout delivers time-aligned signaling. PLAY YOUR OWN STYLE The cyberpunk-inspired aesthetics of ROG Strix B550-F Gaming Wi Fi II are accentuated by the bold slashes & cybertext. By pairing your rig with other products from the diverse ROG ecosystem, you can create a fully customized gaming setup that reflects your personal style. UNDENIABLY ROG STRIX ROG Strix B550-F Gaming Wi Fi II embodies the ROG spirit with eye-catching aesthetics, including the next-generation distorted ROG eye logo & recessed cybertext patterning etched on the I/O shroud. These new designs move ROG Strix boldly into the future, while clearly reflecting the series' gaming roots. OUTSHINE THE COMPETITION ROG Strix motherboards deliver sterling performance & superior aesthetics to outshine the competition. They also feature built-in ASUS Aura technology that enables full RGB lighting control & a variety of presets for embedded RGB LEDs as well as lighting strips connected to onboard RGB headers. In addition, all lighting can be easily synced with an ever-growing portfolio of Aura-capable ASUS hardware. PRE-MOUNTED I/O SHIELD Patented I/O shield is finished in sleek matte black & comes pre-mounted to make it easy to install on the motherboard. Four onboard LEDs indicate power status, & any problem with the CPU, memory, graphics card or boot device for quick diagnosis. CERTIFIED COMPATIBILITY ROG Strix motherboards undergo an extensive certification program to ensure the very best compatibility with the widest range of components & devices. For a smooth build process, refer to our list of guaranteed-compatible components. To help with memory upgrades, the list also

Includes:: a dedicated Qualified Vendor List (QVL). THE ROG STRIX ECOSYSTEM AWAITS Level up your game with ROG Strix. Enjoy complementary aesthetics, control & compatibility across AIO coolers, cases, peripherals, & much more. ROG offers more choices than any other br&. ROG GIVES YOU MORE ROG-exclusive software utilities deliver intuitive audio tuning & gaming enhancements that allow you to configure your gaming build the way you want. UEFI BIOS The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, & tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as comprehensive features for seasoned veterans. AI NETWORKING The proprietary ROG Game First VI utility is designed to help all users " beginners, experts, & everyone in between " optimize network settings to ensure smooth online gameplay. New to this generation, Game First VI features AI-enhanced identification & boost technology to ensure faster & smarter network optimization. AIDA64 EXTREME ROG Strix B550-F Gaming Wi Fi II

Includes:: a 60-day AIDA64 Extreme subscription. This industry-leading system information tool provides detailed information about installed hardware & software, & it also provides benchmarks for measuring performance of the entire system or individual components. AIDA64 Extreme

Includes:: a monitoring & diagnostics feature to detect & prevent hardware issues. All vital system sensors can be tracked in real time, allowing voltage readings, fan speeds, & temperature information to be displayed on the desktop or sent to dedicated displays or to the OLED panels of ROG AIO liquid coolers*. * Support available for ROG Ryujin II & later models. ARMOURY CRATE Armoury Crate is a new software utility designed to give you centralized control of supported gaming products, making it easy to tune the look & feel of your system. From a single intuitive interface, Armoury Crate lets you easily customize RGB lighting & effects for compatible devices & synchronize them with Aura Sync to create a unified lighting scheme across your system. You can also use Armoury Crate to download the user manual, drivers & software. In addition, Armoury Crate features a dedicated product registration page as well as a news feed to help you stay in touch with the gaming community. * Windows 10 required for full Aura Sync functionality within Armoury Crate. For Windows 8 & earlier versions, standalone Aura Sync software is available for free download from the product support site. RAMCACHE III RAMCache III software turns milliseconds into microseconds to boost game-load times. Fully compatible with the latest NVM Express&174; storage options, its uniquely intelligent technology effectively caches an entire storage device so that favorite games & apps launch at breakneck speeds.\n\n\n\n Internal I/ONumber of M.2 (M) slots 2 Thunderbolt headers 1USB 3.2 Gen 2 (3.1 Gen 2) connectors 112V power connector Yes Supported storage drive interfaces M.2, SATA IIIUSB 2.0 connectors 2USB 3.2 Gen 1 (3.1 Gen 1) connectors 1 Peripheral (Molex) power connectors (4-pin)1 Number of SATA III connectors 6 Number of EATX power connectors 1 Number of chassis fan connectors 3EPS power connector (8-pin) Yes CPU fan connector Yes RGB LED pin header Yes Technical details Motherboard chipset family AMDMotherboard chipset AMD B550 Parallel processing technology support Not supported HDMI version 2.1 Cooling type Active Motherboard form factor ATXComponent for PCAudio Audio output channels 7.1 channels Performance Number of HDDs supported 6 Supported storage drive types HDD & SSDWindows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x 64, Windows 10 Enterprise, Windows 10 Enterprise x 64, Windows 10 Home, Windows 10 Home x 64, Windows 10 IOT Core, Windows 10 Io T Enterprise, Windows 10 Pro, Windows 10 Pro x 64, Windows 10 x 64 Motherboard chipset family AMDMotherboard chipset AMD B550RAID levels 0, 1, 10 Cooling type Active Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCProcessor Processor manufacturer AMDCompatible processor series AMD Ryzen 3 3rd Gen, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen 7, 3rd Generation AMD Ryzen 9 Maximum number of SMP processors 1 Processor socket Socket AM4 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMSupported memory clock speeds 2133, 2400, 2666, 2800, 3000, 3200, 3466, 3600, 3866, 4000, 4133, 4400, 4600 MHz Maximum internal memory 128 GBStorage controllers Number of HDDs supported 6 Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, SATA IIIRAID levels 0, 1, 10 Graphics Parallel processing technology support Not supported Rear panel I/O ports USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1 Display Port version 1.2USB 2.0 ports quantity 2S/PDIF out port Yes Microphone in Yes Headphone outputs 1HDMI version 2.1HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1 Network Ethernet LANYes Wi-Fi Yes Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Wake-on-LAN ready Yes LAN controller Intel I225-VEthernet interface type 2.5 Gigabit Ethernet Bluetooth Yes Bluetooth version 5.2 Top Wi-Fi standard Wi-Fi 6 (802.11ax) Features Power source type ATXWindows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x 64, Windows 10 Enterprise, Windows 10 Enterprise x 64, Windows 10 Home, Windows 10 Home x 64, Windows 10 IOT Core, Windows 10 Io T Enterprise, Windows 10 Pro, Windows 10 Pro x 64, Windows 10 x 64 Motherboard chipset family AMDMotherboard chipset AMD B550 Cooling type Active Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCExpansion slots Number of M.2 (M) slots 2PCI Express x 1 (Gen 3.x) slots 3PCI Express x 16 (Gen 3.x) slots 1PCI Express x 16 (Gen 4.x) slots 1BIOSBIOS type UEFI AMIBIOS memory size 256 Mbit Power Power source type ATXSoftware Windows operating systems supported Windows 10, Windows 10 Education, Windows 10 Education x 64, Windows 10 Enterprise, Windows 10 Enterprise x 64, Windows 10 Home, Windows 10 Home x 64, Windows 10 IOT Core, Windows 10 Io T Enterprise, Windows 10 Pro, Windows 10 Pro x 64, Windows 10 x 64 Drivers included Yes Weight & dimensions Width 305 mm Depth 244 mm Packaging content Drivers included Yes Cables included SATA\n\n\n\n





...

Intel&174; B560 LGA 1200 ATX motherboard with PCIe 4.0, 8+2 teamed power stages, Two-Way AI Noise Cancelation, Wi Fi 6 (802.11ax), Realtek 2.5 Gb Ethernet, two M.2 slots with heatsinks, USB (Universal Serial Bus) 3.2 Gen 2x 2 USB (Universal Serial Bus) Type-C&174;, SATA & Aura Sync RGB lighting\n\n\n\n\n\n Product Model: ROG STRIX B560-A GAMING WIFI\n\n\n ...

Intel&174; B560 LGA 1200 ATX motherboard with PCIe 4.0, 8+2 teamed power stages, Two-Way AI Noise Cancelation, Wi Fi 6 (802.11ax), Realtek 2.5 Gb Ethernet, two M.2 slots with heatsinks, USB (Universal Serial Bus) 3.2 Gen 2x 2 USB (Universal Serial Bus) Type-C&174;, SATA & Aura Sync RGB lighting\n\n\n\n\n\n Product Model: ROG STRIX B560-A GAMING WIFI\n\n\n ...

ROG STRIX B560-F GAMING WIFI ROG Strix B560-F Gaming Wi Fi delivers everything you need to create a well-balanced gaming PC utilizing 11th Generation Intel&174; Core&132;&162; processors. It's primed for the latest graphics cards, high-speed storage setups, & networking standards, & then further boosted with AI-infused utilities that have trickled down from top-tier ROG motherboards to take performance well beyond mainstream. As a finishing touch, futuristic aesthetics accented by customizable RGB lighting allow you to make the build uniquely yours. POTENTIAL, REALIZED Robust power delivery & comprehensive cooling features ensure exceptional performance, while AI-powered enhancements optimize network settings & improve in-game communication " all to help you maximize the full potential of your rig. TEAMED POWER STAGES 8+2 power stages combine high-side & low-side MOSFETS & drivers into a single package, delivering the power & efficiency that the latest Intel processors dem&. ALLOY CHOKES & CAPACITORS Superior chokes & durable capacitors are engineered to resist extreme temperatures, enabling performance that exceeds industry standards. PROCOOL POWER CONNECTOR The ASUS Pro Cool socket is built to exacting specifications to ensure flush contact with the PSU power lines, enabling lower impedance & better heat dissipation. DIGI+ POWER CONTROL The built-in Digi+ voltage-regulator module (VRM) is one of the finest in the industry, ensuring ultra-smooth & clean power delivery to the CPU. SIX-LAYER PCB The PCB design quickly dissipates heat around the VRM to improve overall system stability & provide the CPU with more overclocking headroom. COOLER BY DESIGN ROG Strix B560 motherboards feature comprehensive cooling options that are configurable via Fan Xpert 4 or the UEFI BIOS. CPU Fan Header A dedicated pair of PWM/DC fan headers for CPU coolers AIO Pump Fan Header A dedicated PWM/DC header for self-contained water-cooling setups M.2 Heatsink Keeps the M.2 SSD at the optimum operating temperature for consistent performance & reliability 4-pin PWM/DC Fan Header Each header supports auto-detection of PWM or DC fans TWO-WAY AI NOISE CANCELATION This utility leverages a massive deep-learning database to reduce background noise from the microphone & incoming audio, while preserving vocals at the same time. Distracting keyboard clatter, mouse clicks & other ambient noises are intelligently neutralized so you can hear & be heard with crystal clarity while gaming or in calls. AI NETWORKING The proprietary ROG Game First VI utility is designed to help all users " beginners, experts, & everyone in between " optimize network settings to ensure smooth online gameplay. New to this generation, Game First VI features AI-enhanced identification & boost technology to ensure faster & smarter network optimization. Identification Game First VI analyzes usage patterns & the digital signatures of your applications & compares them to a database of over 200, 000 apps. Boost Game First VI intelligently switches application priority & adjusts bandwidth, depending on the situation. When gaming, it accelerates & prioritizes game packets to give you supersmooth online gameplay &149; even when you're streaming high-quality video or transferring large files. Visualization An intuitive graph provides an overview of real-time network status. Simply click on the tab to view the current bandwidth usage of each application, geolocation status of each network connection, or an analysis of the Wi Fi channels. NETWORK INSIGHT WIFI Quick Assist analyzes network information & generates a graph to give you a clear picture of current network status. In addition, when paired with an ROG router, you can scan your Wi Fi network to find the best channel & use Game Boost to prioritize gaming devices & packets. ADAPTIVE INTELLIGENCE Game First VI notes what you're currently doing & adjusts bandwidth accordingly to ensure smooth online experiences, even when multitasking. GAMING FIRST MODE Gaming First mode leverages a massive application database & an analysis of your frequently used apps to prioritize gaming network traffic. This reduces jitter & decreases ping to give you lag-free online gaming. ADVANCED GAMING IMMERSION The latest connectivity features & audio enhancements propel ROG Strix B560-F Gaming Wi Fi performance to the next level. OPTIMEM II ROG Strix B560-F Gaming Wi Fi supports up to 128 GB DDR4 memory across four slots. Opti Mem II technology improves trace layout to significantly reduce vias & crosstalk, enhancing memory stability & compatibility while giving memory kits higher frequency margins. PCIE 4.0-READY ROG Strix B560-F Gaming Wi Fi features three onboard M.2 slots, one of which supports the latest PCIe 4.0 standard to provide maximum storage flexibility & the fastest data speeds available with the latest Intel processors. WIFI 6 (802.11 AX) Onboard Wi Fi 6 (802.11ax) supports ultrafast wireless-networking speeds, enhanced capacity & better performance in dense wireless environments, providing exceptional online gaming experiences. Pair your motherboard with ASUS Wi Fi 6 routers to fully experience the networking potential of Wi Fi 6. INTEL 2.5 GB ETHERNET Onboard 2.5 Gb Ethernet gives your wired connection a boost, with up to a 2.5X improvement over standard Ethernet connections for faster file transfers, smoother lag-free gaming & high-res video streaming. ROG SUPREMEFX Leveraging premium components together with advanced circuit layout optimizations & shielding techniques, ROG Supreme FX technology ensures pristine audio for all inputs & outputs. Front panel audio output quality is further preserved by a Savitech amplifier that's capable of driving a diverse range of gaming headsets & high-fidelity headphones. Audio Cover Effective shielding against electromagnetic interference preserves the integrity of audio signals to ensure the best sound quality. Audio-Line Shielding Specially designed shielding blocks electromagnetic interference from the motherboard or add-ons. Savitech SV3H712 Amplifier The integrated Savitech amplifier greatly improves THD+N performance from 72 to 83 d B, resulting in cleaner, more pristine sound. Premium Nichicon&132;&162; Audio Capacitors High-quality Japanese-made components produce a warmer, more natural sound with exceptional clarity & fidelity. AUDIO USB (Universal Serial Bus) TYPE-C&174; Dedicated onboard hardware & power filtering allow the Audio Type-C&174; port to pipe crystal clear sonics to 3.5mm analogue headphones or the ROG Delta headset. S210 INTEGRATED CHIP The S210 control chip automatically switches the port to USB (Universal Serial Bus) 2.0 protocol or stereo audio output for your preferred Type-C to 3.5mm converter cable. POWER NOISE-FILTER CIRCUIT Specially-designed circuity helps reduce power-input noise to ensure consistently quiet performance from any audio source. ROG AUDIO USB (Universal Serial Bus) TYPE-C&174; CABLE The bundled extension cable can be used to conveniently tether a USB (Universal Serial Bus) DAC or the ROG Delta headset to the Audio Type-C&174; port. Alternatively, the cable can be plugged into the rear USB (Universal Serial Bus) 3.2 Type-C port to quickly connect a high-speed drive or device. PLAY YOUR OWN STYLE Pair ROG Strix B560-F Gaming Wi Fi with other products from the diverse ROG ecosystem to create a fully customized gaming setup that reflects your personal style. UNDENIABLY ROG STRIX With its cyberpunk inspired aesthetic, ROG Strix B560-F Gaming Wi Fi boldly embodies the ROG spirit. The motherboard proudly displays the next-generation Aura RGB-illuminated glitch-effect ROG logo & a Strix nameplate etched in a series of straight lines & dots. OUTSHINE THE COMPETITION ROG Strix motherboards deliver sterling performance & superior aesthetics to outshine the competition. They also feature built-in ASUS Aura technology that enables full RGB lighting control & a variety of presets for embedded RGB LEDs, as well as lighting strips connected to onboard RGB headers. In addition, all lighting can be easily synced with an ever-growing portfolio of Aura-capable ASUS hardware. ADDRESSABLE GEN 2 RGB HEADER ROG Strix B560-F Gaming Wi Fi's Addressable Gen 2 RGB headers are now capable of detecting the number of LEDs on second-gen addressable RGB devices, allowing the software to automatically tailor lighting effects to specific devices. The new headers also offer backward-compatibility with existing Aura RGB gear. M.2 Q-LATCH The innovative Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools. The design employs a simple locking mechanism to secure the drive & neatly eliminate traditional screws. BIOS FLASHBACK&132;&162; BIOS Flash Back&132;&162; is the simplest & safest way to update BIOS. Simply drop the (UEFI) BIOS file onto a FAT32-formatted USB (Universal Serial Bus) stick, & plug it into the USB (Universal Serial Bus) BIOS Flash Back port & press the button. Updates can even be performed without having memory or a CPU installed. Q-LEDS Four onboard LEDs indicate power status, & any problem with the CPU, memory, graphics card or boot device for quick diagnosis. PRE-MOUNTED I/O SHIELD The patented ROG I/O shield is finished in sleek matte black & comes pre-mounted, which further simplifies the process of installing the motherboard. ROG GIVES YOU MORE ROG-exclusive software utilities deliver intuitive audio tuning & gaming enhancements so you can configure your gaming build the way you want. To further aid system setup & performance tuning, the highly acclaimed AIDA64 utility has also been added to the mix. UEFI BIOS The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, & tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans. When you're ready for a deeper dive into the configuration of your system, delve into the UEFI's Advanced mode & take complete control. Each section is intuitively organized, & a built-in search feature makes it easy to find the options you need. Advanced functions are coded with the intelligence to adapt to your settings, & when you're ready to take charge, parameters have the granularity to dial in performance just the way you want. Designed to simplify setup, EZ mode presents vital settings & stats on a single page. With guided wizards, drag-&-drop functionality, & one-click application of important settings, your rig will be up & running in no time. SONIC STUDIO III ROG Sonic Studio supports HRTF-based (head-related transfer function) virtual surround for VR headsets, casting an immersive aural landscape that draws you deeper into the action. The intuitive Sonic Studio interface also offers a range of EQ options & one-click presets, allowing you to tailor acoustics to suit personal preferences or the characteristics of your headset. SONIC STUDIO LINK The new Sonic Studio Link means that you can apply effects on all playback devices. Simply press the Sonic Studio Link button to enjoy the effect on any connected device. APP-SPECIFIC PROFILES Apply customized audio settings to various applications, so that each is perfectly tuned to the way you want to listen. SONIC STUDIO VIRTUAL MIXER Combine audio output from selected apps with audio from the microphone input & stream the compiled mix. DTS: SOUND UNBOUND ROG Strix B560 motherboards are pre-loaded with the DTS&174; Sound Unbound&132;&162; app that envelops you in audio as never before, conjuring whole new levels of immersion for extraordinary gaming & entertainment experiences. By leveraging Windows Sonic spatial technology, DTS Sound Unbound delivers audio in a virtual 3D space " putting you right in the middle of the soundscape, where you can sense the location & direction of every gunshot, footstep or other sound in your virtual environment. STEREO SOUND Discrete left & right audio channels enable headphone or two-speaker setup. SURROUND SOUND Audio is split & served over multiple speaker channels " e.g., 5.1 or 7.1 " to create an enveloping experience on a single, logical plane. SPATIAL SOUND A virtual audio-sphere effect creates astonishing 360&176; immersion " with you at the center, where sounds seem to arrive from all directions. AIDA64 EXTREME ROG Strix B560 motherboards include a 60-day AIDA64 Extreme subscription. This industry-leading system information tool provides detailed information about installed hardware & software, & it also provides benchmarks for measuring performance of the entire system or individual components. AIDA64 Extreme

Includes:: a monitoring & diagnostics feature to detect & prevent hardware issues. All vital system sensors can be tracked in real time, allowing voltage readings, fan speeds, & temperature information to be displayed on the desktop or sent to dedicated displays or to the LCD panels of ROG AIO liquid coolers. ARMOURY CRATE Armoury Crate is a software utility designed to give you centralized control of supported gaming products, making it easy to tune the look & feel of your system. From a single intuitive interface, Armoury Crate lets you easily customize RGB lighting & effects for compatible devices & synchronize them with Aura Sync to create a unified lighting scheme across your system. You can also use Armoury Crate to download drivers, software & the user manual. In addition, Armoury Crate features a dedicated product registration page as well as a news feed to help you stay in touch with the gaming community. RAMCACHE III RAMCache III software turns milliseconds into microseconds to boost game-load times. Fully compatible with the latest NVM Express&174; storage options, its uniquely intelligent technology effectively caches an entire storage device so that favorite games & apps launch at breakneck speeds.\n\n\n\n Internal I/ONumber of M.2 (M) slots 3 Thunderbolt headers 1 Total number of SATA connectors 612V power connector Yes Supported storage drive interfaces M.2, PCI Express 3.0, PCI Express 4.0, SATA IIIUSB 2.0 connectors 2USB 3.2 Gen 1 (3.1 Gen 1) connectors 2TPM connector Yes S/PDIF out connector Yes Number of SATA III connectors 6 Number of chassis fan connectors 3 Front panel audio connector Yes EPS power connector (8-pin) Yes CPU fan connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Technical details Motherboard chipset family Intel Motherboard chipset Intel B560 Supported processor sockets LGA 1200 (Socket H5) Parallel processing technology support Not supported HDMI version 2.0 Motherboard form factor ATXComponent for PCTotal number of SATA connectors 6 Audio Audio output channels 7.1 channels Performance Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64 Motherboard chipset family Intel Motherboard chipset Intel B560 Supported processor sockets LGA 1200 (Socket H5) Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCProcessor Processor manufacturer Intel Compatible processor series Intel&174; Celeron&174;, Intel&174; Core&132;&162; i 3, Intel Core i 5, Intel Core i 7, Intel Core i 9, Intel Pentium GSupported processor sockets LGA 1200 (Socket H5) Processor socket LGA 1200 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMMemory channels Dual-channel Non-ECCYes Supported memory clock speeds 2133, 2400, 2666, 2800, 2933, 3200, 3333, 3466, 3600, 3733, 4000, 4266, 4400, 4600, 4800, 5000 MHz Maximum internal memory 128 GBUnbuffered memory Yes Storage controllers Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, PCI Express 3.0, PCI Express 4.0, SATA IIINumber of storage drives supported 9 Graphics Parallel processing technology support Not supported Maximum resolution 5120 x 2880 pixels Rear panel I/O ports USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1 Display Port version 1.4USB connector type USB Type-A, USB (Universal Serial Bus) Type-CUSB 2.0 ports quantity 4 Wi Fi-AP antenna jack 1 Microphone in Yes Headphone outputs 5HDMI version 2.0HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1 Network Ethernet LANYes Wi-Fi Yes Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Wake-on-LAN ready Yes LAN controller Intel I225-VEthernet interface type 2.5 Gigabit Ethernet Bluetooth Yes Bluetooth version 5.0 Top Wi-Fi standard Wi-Fi 6 (802.11ax) Features Windows operating systems supported Windows 10 x 64 Motherboard chipset family Intel Motherboard chipset Intel B560 Supported processor sockets LGA 1200 (Socket H5) Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCAudio chip Realtek ALC S1220 A Expansion slots Number of M.2 (M) slots 3PCI Express x 1 (Gen 3.x) slots 2PCI Express x 16 (Gen 3.x) slots 1PCI Express x 16 (Gen 4.x) slots 1BIOSBIOS type UEFI AMIClear CMOS jumper Yes BIOS memory size 128 Mbit Video Maximum resolution 5120 x 2880 pixels Software Windows operating systems supported Windows 10 x 64 Drivers included Yes Weight & dimensions Width 305 mm Depth 244 mm Packaging content Drivers included Yes Cables included USB Type-C, SATA\n\n\n\n

...

ROG Strix B560-G Gaming Wi Fi delivers everything you need to create a well-balanced micro ATX-based gaming PC utilizing 11th Generation Intel&174; Core&132;&162; processors. It&153;s ready to take on heavyweight graphics cards, & neatly crams in options for the latest storage & networking standards. AI enhancements that have trickled down from higher-end counterparts add a further performance boost. As a finishing touch, futuristic aesthetics accented by customizable RGB lighting allow you to make the build uniquely yours. POTENTIAL, REALIZED Robust power delivery & comprehensive cooling features ensure exceptional performance, while AI-powered enhancements optimize network settings & improve in-game communication " all to help you maximize the full potential of your rig. TEAMED POWER STAGES 8+2 power stages combine high-side & low-side MOSFETS & drivers into a single package, delivering the power & efficiency that the latest Intel processors dem&. ALLOY CHOKES & CAPACITORS Superior chokes & durable capacitors are engineered to resist extreme temperatures, enabling performance that exceeds industry standards. PROCOOL POWER CONNECTOR The ASUS Pro Cool socket is built to exacting specifications to ensure flush contact with the PSU power lines, enabling lower impedance & better heat dissipation. DIGI+ POWER CONTROL The built-in Digi+ voltage-regulator module (VRM) is one of the finest in the industry, ensuring ultra-smooth & clean power delivery to the CPU. SIX-LAYER PCB The PCB design quickly dissipates heat around the VRM to improve overall system stability & provide the CPU with more overclocking headroom. COOLER BY DESIGN ROG Strix B560 motherboards feature comprehensive cooling options that are configurable via Fan Xpert 4 or the UEFI BIOS. CPU Fan Header A dedicated pair of PWM/DC fan headers for CPU coolers AIO Pump Fan Header A dedicated PWM/DC header for self-contained water-cooling setups M.2 Heatsink Keeps the M.2 SSD at the optimum operating temperature for consistent performance & reliability 4-pin PWM/DC Fan Header Each header supports auto-detection of PWM or DC fans TWO-WAY AI NOISE CANCELATION This utility leverages a massive deep-learning database to reduce background noise from the microphone & incoming audio, while preserving vocals at the same time. Distracting keyboard clatter, mouse clicks & other ambient noises are intelligently neutralized so you can hear & be heard with crystal clarity while gaming or in calls. AI NETWORKING The proprietary ROG Game First VI utility is designed to help all users " beginners, experts, & everyone in between " optimize network settings to ensure smooth online gameplay. New to this generation, Game First VI features AI-enhanced identification & boost technology to ensure faster & smarter network optimization. Identification Game First VI analyzes usage patterns & the digital signatures of your applications & compares them to a database of over 200, 000 apps. Boost Game First VI intelligently switches application priority & adjusts bandwidth, depending on the situation. When gaming, it accelerates & prioritizes game packets to give you supersmooth online gameplay &149; even when you're streaming high-quality video or transferring large files. Visualization An intuitive graph provides an overview of real-time network status. Simply click on the tab to view the current bandwidth usage of each application, geolocation status of each network connection, or an analysis of the Wi Fi channels. WHAT IT DOES NETWORK INSIGHT WIFI Quick Assist analyzes network information & generates a graph to give you a clear picture of current network status. In addition, when paired with an ROG router, you can scan your Wi Fi network to find the best channel & use Game Boost to prioritize gaming devices & packets. ADAPTIVE INTELLIGENCE Game First VI notes what you're currently doing & adjusts bandwidth accordingly to ensure smooth online experiences, even when multitasking. GAMING FIRST MODE Gaming First mode leverages a massive application database & an analysis of your frequently used apps to prioritize gaming network traffic. This reduces jitter & decreases ping to give you lag-free online gaming. ADVANCED GAMING IMMERSION The latest connectivity features & audio enhancements propel ROG Strix B560-G Gaming Wi Fi performance to the next level. OPTIMEM II ROG Strix B560-G Gaming Wi Fi supports up to 128 GB DDR4 memory across four slots. Opti Mem II technology improves trace layout to significantly reduce vias & crosstalk, enhancing memory stability & compatibility while giving memory kits higher frequency margins. PCIE 4.0-READY ROG Strix B560-G Gaming Wi Fi features two onboard M.2 slots, one of which supports the latest PCIe 4.0 standard to provide maximum storage flexibility & the fastest data speeds available with the latest Intel processors. WIFI 6 (802.11 AX) Onboard Wi Fi 6 (802.11ax) supports ultrafast wireless-networking speeds, enhanced capacity & better performance in dense wireless environments, providing exceptional online gaming experiences. Pair your motherboard with ASUS Wi Fi 6 routers to fully experience the networking potential of Wi Fi 6. INTEL 2.5 GB ETHERNET Onboard 2.5 Gb Ethernet gives your wired connection a boost, with up to a 2.5X improvement over standard Ethernet connections for faster file transfers, smoother lag-free gaming & high-res video streaming. ROG SUPREMEFX Leveraging premium components together with advanced circuit layout optimizations & shielding techniques, ROG Supreme FX technology ensures pristine audio for all inputs & outputs. Front panel audio output quality is further preserved by a Savitech amplifier that's capable of driving a diverse range of gaming headsets & high-fidelity headphones. Audio Cover Effective shielding against electromagnetic interference preserves the integrity of audio signals to ensure the best sound quality. Audio-Line Shielding Specially designed shielding blocks electromagnetic interference from the motherboard or add-ons. Savitech SV3H712 Amplifier The integrated Savitech amplifier greatly improves THD+N performance from 72 to 83 d B, resulting in cleaner, more pristine sound. Premium Nichicon&132;&162; Audio Capacitors High-quality Japanese-made components produce a warmer, more natural sound with exceptional clarity & fidelity. AUDIO USB (Universal Serial Bus) TYPE-C&174; Dedicated onboard hardware & power filtering allow the Audio Type-C&174; port to pipe crystal clear sonics to 3.5mm analogue headphones or the ROG Delta headset. S210 INTEGRATED CHIP The S210 control chip automatically switches the port to USB (Universal Serial Bus) 2.0 protocol or stereo audio output for your preferred Type-C to 3.5mm converter cable. POWER NOISE-FILTER CIRCUIT Specially-designed circuity helps reduce power-input noise to ensure consistently quiet performance from any audio source. ROG AUDIO USB (Universal Serial Bus) TYPE-C&174; CABLE The bundled extension cable can be used to conveniently tether a USB (Universal Serial Bus) DAC or the ROG Delta headset to the Audio Type-C&174; port. Alternatively, the cable can be plugged into the rear USB (Universal Serial Bus) 3.2 Type-C port to quickly connect a high-speed drive or device. PLAY YOUR OWN STYLE Pair ROG Strix B560-G Gaming Wi Fi with other products from the diverse ROG ecosystem to create a fully customized gaming setup that reflects your personal style. UNDENIABLY ROG STRIX With its cyberpunk-inspired aesthetic, ROG Strix B560-G Gaming Wi Fi boldly embodies the ROG spirit. The motherboard proudly displays the next-generation glitch-effect ROG logo & a Strix nameplate etched in a series of straight lines & dots. & to complement the motherboard&153;s classic black finish, a series of discrete customizable light effects allow you to put a personal touch to your build. OUTSHINE THE COMPETITION ROG Strix motherboards deliver sterling performance & superior aesthetics to outshine the competition. They also feature built-in ASUS Aura technology that enables full RGB lighting control & a variety of presets for embedded RGB LEDs, as well as lighting strips connected to onboard RGB headers. In addition, all lighting can be easily synced with an ever-growing portfolio of Aura-capable ASUS hardware. ADDRESSABLE GEN 2 RGB HEADER ROG Strix B560-G Gaming Wi Fi's Addressable Gen 2 RGB headers are now capable of detecting the number of LEDs on second-gen addressable RGB devices, allowing the software to automatically tailor lighting effects to specific devices. The new headers also offer backward-compatibility with existing Aura RGB gear. M.2 Q-LATCH The innovative Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools. The design employs a simple locking mechanism to secure the drive & neatly eliminate traditional screws. BIOS FLASHBACK&132;&162; BIOS Flash Back&132;&162; is the simplest & safest way to update BIOS. Simply drop the (UEFI) BIOS file onto a FAT32-formatted USB (Universal Serial Bus) stick, & plug it into the USB (Universal Serial Bus) BIOS Flash Back port & press the button. Updates can even be performed without having memory or a CPU installed. Q-LEDS Four onboard LEDs indicate power status, & any problem with the CPU, memory, graphics card or boot device for quick diagnosis. PRE-MOUNTED I/O SHIELD The patented ROG I/O shield is finished in sleek matte black & comes pre-mounted, which further simplifies the process of installing the motherboard. ROG GIVES YOU MORE ROG-exclusive software utilities deliver intuitive audio tuning & gaming enhancements so you can configure your gaming build the way you want. To further aid system setup & performance tuning, the highly acclaimed AIDA64 utility has also been added to the mix. UEFI BIOS The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, & tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as more comprehensive features for seasoned veterans. When you're ready for a deeper dive into the configuration of your system, delve into the UEFI's Advanced mode & take complete control. Each section is intuitively organized, & a built-in search feature makes it easy to find the options you need. Advanced functions are coded with the intelligence to adapt to your settings, & when you're ready to take charge, parameters have the granularity to dial in performance just the way you want. Designed to simplify setup, EZ mode presents vital settings & stats on a single page. With guided wizards, drag-&-drop functionality, & one-click application of important settings, your rig will be up & running in no time. SONIC STUDIO III ROG Sonic Studio supports HRTF-based (head-related transfer function) virtual surround for VR headsets, casting an immersive aural landscape that draws you deeper into the action. The intuitive Sonic Studio interface also offers a range of EQ options & one-click presets, allowing you to tailor acoustics to suit personal preferences or the characteristics of your headset. SONIC STUDIO LINK The new Sonic Studio Link means that you can apply effects on all playback devices. Simply press the Sonic Studio Link button to enjoy the effect on any connected device. APP-SPECIFIC PROFILES Apply customized audio settings to various applications, so that each is perfectly tuned to the way you want to listen. SONIC STUDIO VIRTUAL MIXER Combine audio output from selected apps with audio from the microphone input & stream the compiled mix. DTS: SOUND UNBOUND ROG Strix B560 motherboards are pre-loaded with the DTS&174; Sound Unbound&132;&162; app that envelops you in audio as never before, conjuring whole new levels of immersion for extraordinary gaming & entertainment experiences. By leveraging Windows Sonic spatial technology, DTS Sound Unbound delivers audio in a virtual 3D space " putting you right in the middle of the soundscape, where you can sense the location & direction of every gunshot, footstep or other sound in your virtual environment. STEREO SOUND Discrete left & right audio channels enable headphone or two-speaker setup. SURROUND SOUND Audio is split & served over multiple speaker channels " e.g., 5.1 or 7.1 " to create an enveloping experience on a single, logical plane. SPATIAL SOUND A virtual audio-sphere effect creates astonishing 360&176; immersion " with you at the center, where sounds seem to arrive from all directions. AIDA64 EXTREME ROG Strix B560 motherboards include a 60-day AIDA64 Extreme subscription. This industry-leading system information tool provides detailed information about installed hardware & software, & it also provides benchmarks for measuring performance of the entire system or individual components. AIDA64 Extreme

Includes:: a monitoring & diagnostics feature to detect & prevent hardware issues. All vital system sensors can be tracked in real time, allowing voltage readings, fan speeds, & temperature information to be displayed on the desktop or sent to dedicated displays or to the LCD panels of ROG AIO liquid coolers. ARMOURY CRATE Armoury Crate is a software utility designed to give you centralized control of supported gaming products, making it easy to tune the look & feel of your system. From a single intuitive interface, Armoury Crate lets you easily customize RGB lighting & effects for compatible devices & synchronize them with Aura Sync to create a unified lighting scheme across your system. You can also use Armoury Crate to download drivers, software & the user manual. In addition, Armoury Crate features a dedicated product registration page as well as a news feed to help you stay in touch with the gaming community. RAMCACHE III RAMCache III software turns milliseconds into microseconds to boost game-load times. Fully compatible with the latest NVM Express&174; storage options, its uniquely intelligent technology effectively caches an entire storage device so that favorite games & apps launch at breakneck speeds.\n\n\n\n Internal I/ONumber of M.2 (M) slots 2 Thunderbolt headers 1USB 3.2 Gen 2 (3.1 Gen 2) connectors 112V power connector Yes Supported storage drive interfaces M.2, PCI Express 3.0, PCI Express 4.0, SATA IIIUSB 2.0 connectors 2USB 3.2 Gen 1 (3.1 Gen 1) connectors 1TPM connector Yes S/PDIF out connector Yes Number of SATA III connectors 6 Number of COM connectors 1 Number of chassis fan connectors 2 Front panel audio connector Yes EPS power connector (8-pin) Yes CPU fan connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Technical details Motherboard chipset family Intel Motherboard chipset Intel B560 Supported processor sockets LGA 1200 (Socket H5) Parallel processing technology support Not supported HDMI version 2.0 Motherboard form factormicro ATXComponent for PCAudio Audio output channels 7.1 channels Performance Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64 Motherboard chipset family Intel Motherboard chipset Intel B560 Supported processor sockets LGA 1200 (Socket H5) Audio output channels 7.1 channels Motherboard form factormicro ATXComponent for PCProcessor Processor manufacturer Intel Compatible processor series Intel&174; Celeron&174;, Intel&174; Core&132;&162; i 3, Intel Core i 5, Intel Core i 7, Intel Core i 9, Intel Pentium GSupported processor sockets LGA 1200 (Socket H5) Processor socket LGA 1200 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMMemory channels Dual-channel Non-ECCYes Supported memory clock speeds 2133, 2400, 2666, 2800, 2933, 3300, 3333, 3466, 3600, 3733, 4000, 4266, 4400, 4600, 4800, 5000 MHz Maximum internal memory 128 GBUnbuffered memory Yes Storage controllers Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, PCI Express 3.0, PCI Express 4.0, SATA IIINumber of storage drives supported 8 Graphics Parallel processing technology support Not supported Maximum resolution 5120 x 2880 pixels Rear panel I/O ports USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1 Display Port version 1.4USB connector type USB Type-A, USB (Universal Serial Bus) Type-CUSB 2.0 ports quantity 7 Wi Fi-AP antenna jack 1 Microphone in Yes Headphone outputs 5HDMI version 2.0HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1USB 3.2 Gen 2x 2 Type-C ports quantity 1 Network Ethernet LANYes Wi-Fi Yes Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Wake-on-LAN ready Yes LAN controller Intel I225-VEthernet interface type 2.5 Gigabit Ethernet Bluetooth Yes Bluetooth version 5.0 Top Wi-Fi standard Wi-Fi 6 (802.11ax) Features Windows operating systems supported Windows 10 x 64 Motherboard chipset family Intel Motherboard chipset Intel B560 Supported processor sockets LGA 1200 (Socket H5) Audio output channels 7.1 channels Motherboard form factormicro ATXComponent for PCAudio chip Supreme FX S1220 A Expansion slots Number of M.2 (M) slots 2PCI Express x 1 (Gen 3.x) slots 2PCI Express x 16 (Gen 3.x) slots 1PCI Express x 16 (Gen 4.x) slots 1BIOSBIOS type UEFI AMIClear CMOS jumper Yes BIOS memory size 128 Mbit Video Maximum resolution 5120 x 2880 pixels Software Windows operating systems supported Windows 10 x 64 Drivers included Yes Weight & dimensions Width 244 mm Depth 244 mm Packaging content Drivers included Yes Cables included SATA, USB (Universal Serial Bus) Type-C\n\n\n\n

...

ROG STRIX B660-A GAMING WIFI D4 ROG Strix B660-A Gaming Wi Fi D4 offers premium power delivery & optimized cooling to unleash the full force of the latest 12th Gen Intel&174; Core&132;&162; processors. Onboard PCIe&174; 5.0, Wi Fi 6 & three PCIe 4.0 M.2 slots provide lightning-fast data transfers for an endless variety of scenarios, & ASUS-exclusive intelligent controls to help optimize PC settings. On top of all that, DIY-friendly innovations help simplify the PC building process to get to you up & running smoothly. TEAMED POWER STAGES 12+1 power stages combine high-side & low-side MOSFETS & drivers into a single package, delivering the power & efficiency that the latest Intel processors can take full advantage of. ALLOY CHOKES & CAPACITORS High-end chokes & durable capacitors are engineered to resist extreme temperatures, enabling performance that exceeds industry standards. PROCOOL POWER CONNECTOR The ASUS Pro Cool socket is built to exacting specifications to ensure flush contact with the PSU power lines, enabling lower impedance & better heat dissipation. DIGI+ POWER CONTROL The Digi+ voltage regulator module (VRM) is one of the finest in the industry, ensuring ultra-smooth & clean power delivery to the CPU. SIX-LAYER PCB A multi-layered printed circuit board design quickly dissipates heat around the voltage regulators to improve overall system stability & provide the CPU with more overclocking headroom. COOLER BY DESIGN ROG Strix B660 motherboards feature comprehensive cooling options that configurable via the Fan Xpert 4 tool in Armoury Crate or within the UEFI BIOS. CPU Fan Headers A dedicated pair of PWM/DC fan headers for CPU coolers. AIO Pump Fan Header A dedicated PWM/DC header for self-contained water-cooling setups. M.2 Heatsink Keeps a mounted M.2 SSD at the optimum operating temperature for consistent performance & reliability. 4-Pin PWM/DC Fan Header Each header supports auto-detection of PWM or DC fans. TWO-WAY AI NOISE CANCELATION This powerful ASUS-exclusive utility leverages a massive deep-learning database to reduce background noise from the microphone* & incoming audio while preserving voices. Distracting keyboard clatter, mouse clicks & other ambient noises are removed so you can hear & be heard with perfect clarity while gaming or during calls. *A splitter cable is necessary when using a 3.5 mm headset. AI COOLING ASUS AI Cooling technology automatically manages & controls motherboard-connected fans to ensure optimal settings based on current system load & temperature. SELF-ADAPTIVE FAN TUNING CPU temperature detection AI Cooling detects CPU temperatures & uses a proprietary algorithm to calculate the lowest fan speed required to effectively cool the system & keep fan noise down. Automated optimization Under stable system loads, the software then automatically lowers fan* speed to the optimal setting, decreasing fan noise without compromising performance. * Fans need to be connected to the following headers for AI Cooling control: CPU_FAN / CPU_OPT / CHA_FAN / M.2_FAN / H_AMP / RAD_FAN Ongoing monitoring AI Cooling continues to monitor the system & adjust fan speed based on current load. AI NETWORKING The proprietary ROG Game First VI utility is designed to help all users " beginners, experts, & everyone in between " optimize network settings to ensure smooth online gameplay. New to this generation, Game First VI features AI-enhanced identification & boost technologies to ensure faster & smarter network optimization. Identification Game First VI analyzes usage patterns & the digital signatures of your applications & compares them to a database of over 200, 000 apps. Boost Game First VI intelligently switches application priority & adjusts bandwidth, depending on the situation. When gaming, it accelerates & prioritizes game packets to give you supersmooth online gameplay &149; even when you're streaming high-quality video or transferring large files. Visualization An intuitive graph provides an overview of real-time network status. Simply click on the tab to view the current bandwidth usage of each application, geolocation status of each network connection, or an analysis of the Wi Fi channels. WHAT IT DOES ADAPTIVE INTELLIGENCE Game First VI notes what you're currently doing & adjusts bandwidth accordingly to ensure smooth online experiences, even when multitasking. GAMING FIRST MODE Gaming First mode leverages a massive application database & an analysis of your frequently used apps to prioritize gaming network traffic. This reduces jitter & decreases ping to give you lag-free online gaming. NETWORK INSIGHT WIFI Quick Assist analyzes network information & generates a graph to give you a clear picture of current network status. In addition, when paired with an ROG router, you can scan your Wi Fi network to find the best channel & use Game Boost to prioritize gaming devices & packets. Opti Mem II Opti Mem II technology offers higher clock speeds through trace layout optimizations that significantly reduce signal distance & crosstalk while enhancing memory stability & compatibility. ROG Strix B660-A Gaming Wi Fi D4 supports up to 128 GB of DDR4 memory across four slots. WIFI 6 (802.11 AX) Onboard Wi Fi 6 (802.11ax) supports ultrafast wireless-networking speeds, enhanced capacity & better performance in dense wireless environments, providing exceptional online gaming experiences. Pair your motherboard with ASUS Wi Fi 6 routers to fully experience the networking potential of Wi Fi 6. Intel 2.5 Gb Ethernet Onboard 2.5 Gb Ethernet gives your wired connection a boost, with up to a 2.5x improvement over standard Ethernet connections for faster file transfers, smoother lag-free gaming & high-res video streaming. SUPREMEFX ROG Supreme FX is a unique blend of hardware & software that provides superior audio. In ROG Strix B660-A Gaming Wi Fi D4, Supreme FX features the ALC4080 codec to increase playback resolution from 192 k Hz to 384 k Hz across all channels. The front-panel output is streamed through a highly integrated Savitech amplifier that&153;s capable of driving of a wide variety of gaming headsets & high-fidelity headphones. UNDENIABLY ROG STRIX The ROG Strix B660-A Gaming Wi Fi D4 will turn heads with a striking silver-white finish that contrasts with a bold Aura RGB-illuminated glitch-effect logo. Meanwhile, parallel strakes & dotted text on the aluminum I/O shroud, M.2 & PCH heatsinks tie the whole aesthetic together & underline the ROG Strix fundamentals of speed, diversity & attitude. OUTSHINE THE COMPETITION ROG Strix motherboards deliver sterling performance & superior aesthetics to outshine the competition. They also feature built-in ASUS Aura technology that enables full RGB lighting control, & a variety of presets for both embedded RGB LEDs & third-party lighting strips. In addition, all lighting can be easily synced with other Aura-capable ASUS hardware. M.2 Q-LATCH The innovative Q-Latch makes it easy to install or remove an M.2 SSD without the need for specific tools. The design employs a simple locking mechanism to secure the drive & neatly eliminate traditional screws. CERTIFIED COMPATIBILITY ROG Strix motherboards undergo an extensive certification program to ensure compatibility with the widest range of components & devices. Our Qualified Vendor List (QVL) provides a reference for identifying guaranteed-compatible components & memory. ASUS AIO coolers are also compatible with a wide variety of CPUs, up to & including 12th Gen Intel processors, giving you ultimate flexibility to cool the CPU that fits your needs. THE ROG STRIX ECOSYSTEM AWAITS Level up your game with ROG Strix. Enjoy complementary aesthetics, control & compatibility across AIO coolers, cases, peripherals, & much more. ROG offers more choices than any other br&. UEFI BIOS The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, & tune your rig. It offers intelligently simplified options for newcomers to PC DIY & more comprehensive features for seasoned veterans. MEMTEST86 For added convenience, Mem Test 86 has been pre-installed into the ROG UEFI (BIOS). Run the test to pinpoint memory issues with just one click, without needing to insert a USB (Universal Serial Bus) stick or load an operating system. The memory report will also be stored in the BIOS archives for reference. Designed to simplify setup, EZ mode presents vital settings & stats on a single page. With guided wizards, drag-&-drop functionality, & one-click application of important settings, your rig will be up & running in no time. SONIC STUDIO III ROG Sonic Studio supports HRTF-based (head-related transfer function*) virtual surround for VR headsets, casting an immersive aural landscape that draws you deeper into the action. The intuitive Sonic Studio interface also offers a range of EQ options & one-click presets, allowing you to tailor acoustics to suit personal preferences or the characteristics of your headset. SONIC STUDIO LINK The new Sonic Studio Link means that you can apply effects on all playback devices. Simply press the Sonic Studio Link button to enjoy the effect on any connected device. SONIC STUDIO VIRTUAL MIXER Combine audio output from selected apps with audio from the microphone input & stream the compiled mix. APP-SPECIFIC PROFILES Apply customized audio settings to various applications, so that each is perfectly tuned to the way you want to listen. DTS: SOUND UNBOUND ROG Strix B660 motherboards are pre-loaded with the DTS&174; Sound Unbound&132;&162; app that envelops you in audio as never before, conjuring whole new levels of immersion for extraordinary gaming & entertainment experiences. By leveraging Windows Sonic spatial technology, DTS Sound Unbound delivers audio in a virtual 3D space " putting you right in the middle of the soundscape, where you can sense the location & direction of every gunshot, footstep or other sound in your virtual environment. * DTS Sound Unbound requires in-game support. Check with game developers for supported titles. AIDA64 EXTREME ROG Strix B660 motherboards include an AIDA64 Extreme 60 days free trial. This industry-leading system information tool provides detailed information about installed hardware & software, & it also provides benchmarks for measuring performance of the entire system or individual components. AIDA64 Extreme

Includes:: a monitoring & diagnostics feature to detect & prevent hardware issues. All vital system sensors can be tracked in real time, allowing voltage readings, fan speeds, & temperature information to be displayed on the desktop or sent to dedicated displays or to the OLED panels of ROG AIO liquid coolers*. * Support available for ROG Ryujin II & later models. ARMOURY CRATE Armoury Crate is a software utility designed to give you centralized control of supported gaming products, making it easy to tune the look & feel of your system. From a single intuitive interface, Armoury Crate helps you customize RGB lighting & effects for compatible devices & synchronize them with Aura Sync to create a unified lighting scheme across your system. In addition, Armoury Crate&153;s Fan Xpert 4 tool provides comprehensive control over fans, water pumps & all-in-one (AIO) coolers. You can also use Armoury Crate to download drivers, software & user manuals, register products, & tap into a special news feed that connects you to the global ASUS gaming community. * Windows 10 required for full Aura Sync functionality within Armoury Crate. For Windows 8 & earlier versions, standalone Aura Sync software is available for free download from the product support site.\n\n\n\n Internal I/ONumber of M.2 (M) slots 3 Thunderbolt headers 1USB 3.2 Gen 2 (3.1 Gen 2) connectors 1 Front panel connector Yes 12V power connector Yes Supported storage drive interfaces M.2, PCI Express 4.0, SATA IIIUSB 2.0 connectors 2USB 3.2 Gen 1 (3.1 Gen 1) connectors 1TPM connector Yes S/PDIF out connector Yes Number of SATA III connectors 4 Number of chassis fan connectors 3 Front panel audio connector Yes EPS power connector (8-pin) Yes CPU fan connector Yes Chassis intrusion connector Yes ATX Power connector (24-pin) Yes RGB LED pin header Yes Technical details Motherboard chipset family Intel Motherboard chipset Intel B660 Supported processor sockets LGA 1700HDMI version 2.1 Motherboard form factor ATXComponent for PCAudio Audio output channels 7.1 channels Performance Number of HDDs supported 4 Supported storage drive types HDD & SSDWindows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660RAID levels 0, 1, 5, 10 Supported processor sockets LGA 1700 Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCProcessor Processor manufacturer Intel Compatible processor series Intel&174; Celeron&174;, Intel&174; Core&132;&162; i 3, Intel Core i 5, Intel Core i 7, Intel Core i 9, Intel&174; Pentium&174; Gold Supported processor sockets LGA 1700 Processor socket LGA 1700 Memory Number of memory slots 4 Memory slots type DIMMSupported memory types DDR4-SDRAMMemory channels Dual-channel Non-ECCYes Supported memory clock speeds 2133, 2400, 2666, 2800, 2933, 3000, 3200, 3333, 3400, 3466, 3600, 3733, 4000, 4266, 4400, 4600, 4800, 5000, 5333 MHz Maximum internal memory 128 GBUnbuffered memory Yes Storage controllers Number of HDDs supported 4 Supported storage drive types HDD & SSDSupported storage drive interfaces M.2, PCI Express 4.0, SATA IIIRAID levels 0, 1, 5, 10 Number of storage drives supported 7RAID support Yes Rear panel I/O ports USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1 Display Port version 1.4USB 2.0 ports quantity 4 Wi Fi-AP antenna jack 2 Headphone outputs 5HDMI version 2.1HDMI ports quantity 1 Ethernet LAN (RJ-45) ports 1 Display Ports quantity 1 Network Ethernet LANYes Wi-Fi Yes Wi-Fi standards 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Ethernet interface type 2.5 Gigabit Ethernet Bluetooth Yes Bluetooth version 5.2 Top Wi-Fi standard Wi-Fi 6 (802.11ax) Features Power source type ATXWindows operating systems supported Windows 10 x 64, Windows 11 x 64 Motherboard chipset family Intel Motherboard chipset Intel B660 Supported processor sockets LGA 1700 Audio output channels 7.1 channels Motherboard form factor ATXComponent for PCAudio chip Realtek ALC4080 Expansion slots Number of M.2 (M) slots 3PCI Express x 1 (Gen 3.x) slots 2PCI Express x 16 (Gen 3.x) slots 1PCI Express x 16 (Gen 5.x) slots 1BIOSBIOS type UEFI AMIClear CMOS jumper Yes BIOS memory size 192 Mbit Power Power source type ATXSoftware Windows operating systems supported Windows 10 x 64, Windows 11 x 64 Weight & dimensions Width 305 mm Depth 244 mm Packaging content Cables included SATA\n\n\n\n

...
