A cloud-based, vendor agnostic, secure solution that enables wherever-you-go monitoring & visibility into your IT physical infrastructure\n\n\n Extendable architecture\n Available node & application license keys extend the capabilities of the platform allowing it to grow to meet changing business needs.\n\n Remote monitoring support\n Web-based service that serves as a second set of eyes into the health of a company's physical infrastructure. Experienced professionals work non-stop to provide 24-hour monitoring & to help diagnose problems before they become critical.\n\n Encrypted communications\n 2048 bit RSA certificate & data is encrypted in transit using 256 bit AES encryption. Eco Struxure IT Gateway uses an outbound connection through Port 443, & only communicates to Eco Struxure IT cloud using 40.84.62.190 & 23.99.90.28.\n\n Event Notifications\n Receive real-time event notifications that minimize response times to critical physical infrastructure situations, reduce mean time to repair, improve efficiency, & maximize uptime.\n\n Unified console\n Customizable Windows & Linux client application enables instant access from any browser or mobile device\n\n Alarm Consolidation\n Reduces erroneous alarms & decreases MTTR by detecting the root cause in minutes.\n\n Cloud-based monitoring\n Maintain uptime for local edge & distributed environments & check the status of your physical infrastructure equipment from a centralized view, ensuring peace of mind whether onsite or remote.\n\n Centralized Inventory Management\n Obtain Immediate & detailed visibility of all physical infrastructure devices by geography or customizable location.\n\n Multi-vendor device support\n Extensive multi-vendor support for monitoring networked SNMP, MODBUS & Redfish devices. Enables visibility of devices through threshold alert notifications, data trending & reporting.\n\n Assessment\n Determine patterns of healthy behavior & provide a scorecard using analytics & machine learning to identify which devices require attention.\n\n Benchmarking\n Compare your devices performance against the total population of similar devices in the industry.\n\n Auto-discovery\n Reduces the time needed to install & deploy physical infrastructure devices by automatically detecting manageable devices on your network.\n\n Automatic updates & backups\n Updates & backups are automatically applied to always provide the most current solution.\n\n Private networking\n Reduce IP addresses needed on the public network to manage devices, by placing them on an isolated secure network.\n\n Graphical trending analysis\n Access current & historic data for any device or group of devices. Plot & graph multiple data points in a logical correlation to visualize potential hazardous trends.\n\n Custom reporting\n Create, save & schedule user-defined reports for ease of data collection, distribution & analysis.\n\n Centralized Alert Repository\n Access historical alerts from several appliances through one central database. Sort alerts by type, date, appliance, and/or device group.\n\n\n\n\n\n Product Model: SFTWES75-DIGI\n\n\n ...

Boost & Trim Automatic Voltage Regulation (AVR)\n Gives higher application availability by correcting low & high voltage conditions without using the battery.\n\n Intelligent Battery Management\n Maximizes battery performance, life, & reliability through intelligent, precision charging.\n\n Power conditioning\n Protects connected loads from surges, spikes, lightning, & other power disturbances.\n\n Temperature-compensated battery charging\n Prolongs battery life by regulating the charge voltage according to \nbattery temperature.\n\n Automatic restart of loads after UPS shutdown\n Automatically starts up the connected equipment upon the return of utility power.\n\n Automatic self-test\n Periodic battery self-test ensures early detection of a battery that needs to be replaced.\n\n Cold-start capable\n Provides temporary battery power when the utility power is out.\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n Generator Compatible\n Ensures clean, uninterrupted power to protected equipment when generator power is used.\n\n Network manageable\n Provides remote management of the UPS over the network.\n\n Smart Slot\n Customize UPS capabilities with management cards.\n\n Audible Alarms\n Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.\n\n LED status indicators\n Quickly understand unit & power status with visual indicators.\n\n Serial Connectivity\n Provides management of the UPS via a serial port.\n\n USB Connectivity\n Provides management of the UPS via a USB (Universal Serial Bus) port (not available on all models).\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n Infra Stru Xure Manager Compatible\n Enables centralized management via the APC Infra Stru Xure Manager.\n\n User-replaceable batteries\n Increases availability by allowing a trained user to perform upgrades & replacements of the batteries reducing Mean Time to Repair (MTTR)\n\n Hot-swappable batteries\n Ensures clean, uninterrupted power to protected equipment while batteries are being replaced\n\n Predictive failure notification\n Provides early-warning fault analysis ensuring proactive component replacement.\n\n Resettable circuit breakers\n Enables a quick recovery from overload events.\n\n Adjustable voltage-transfer points\n Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.\n\n Adjustable voltage sensitivity\n Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.\n\n Field-replaceable power distribution panel\n Ensures compatibility with equipment that has different plug types.\n\n\n\n\n\n Product Model: Smart UPS\n\n\n ...

Boost & Trim Automatic Voltage Regulation (AVR)\n Gives higher application availability by correcting low & high voltage conditions without using the battery.\n\n Intelligent Battery Management\n Maximizes battery performance, life, & reliability through intelligent, precision charging.\n\n Power conditioning\n Protects connected loads from surges, spikes, lightning, & other power disturbances.\n\n Temperature-compensated battery charging\n Prolongs battery life by regulating the charge voltage according to \nbattery temperature.\n\n Automatic restart of loads after UPS shutdown\n Automatically starts up the connected equipment upon the return of utility power.\n\n Automatic self-test\n Periodic battery self-test ensures early detection of a battery that needs to be replaced.\n\n Cold-start capable\n Provides temporary battery power when the utility power is out.\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n Generator Compatible\n Ensures clean, uninterrupted power to protected equipment when generator power is used.\n\n Network manageable\n Provides remote management of the UPS over the network.\n\n Smart Slot\n Customize UPS capabilities with management cards.\n\n Audible Alarms\n Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.\n\n LED status indicators\n Quickly understand unit & power status with visual indicators.\n\n Serial Connectivity\n Provides management of the UPS via a serial port.\n\n USB Connectivity\n Provides management of the UPS via a USB (Universal Serial Bus) port (not available on all models).\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n Infra Stru Xure Manager Compatible\n Enables centralized management via the APC Infra Stru Xure Manager.\n\n User-replaceable batteries\n Increases availability by allowing a trained user to perform upgrades & replacements of the batteries reducing Mean Time to Repair (MTTR)\n\n Hot-swappable batteries\n Ensures clean, uninterrupted power to protected equipment while batteries are being replaced\n\n Predictive failure notification\n Provides early-warning fault analysis ensuring proactive component replacement.\n\n Resettable circuit breakers\n Enables a quick recovery from overload events.\n\n Adjustable voltage-transfer points\n Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.\n\n Adjustable voltage sensitivity\n Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.\n\n Field-replaceable power distribution panel\n Ensures compatibility with equipment that has different plug types.\n\n\n\n\n\n Product Model: Smart UPS\n\n\n ...

Cold-start capable\n Provides temporary battery power when the utility power is out.\n\n Energy meter\n Provides actual kilowatt hours of usage for energy conscious users.\n\n Green mode\n Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.\n\n High online efficiency\n Reduces utlility costs, generates less heat.\n\n Intuitive LCD interface\n Provides clear & accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.\n\n Predictive replace battery date\n Dynamically provides the month & year when battery replacement is recommended to aide in long term maintenance planning.\n\n Preinstalled network management card\n Provides for remote management & control of the UPS over a network out of the box.\n\n Single switched outlet group\n Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off & non-critical load shedding.\n\n Smart Slot\n Customize UPS capabilities with management cards.\n\n Temperature-compensated battery charging\n Prolongs battery life by regulating the charge voltage according to battery temperature.\n\n Availability\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n Automatic restart of loads after UPS shutdown\n Automatically starts up the connected equipment upon the return of utility power.\n\n Automatic self-test\n Periodic battery self-test ensures early detection of a battery that needs to be replaced.\n\n Intelligent battery management\n Maximizes battery performance, life, & reliability through intelligent, precision charging.\n\n Temperature-compensated battery charging\n Prolongs battery life by regulating the charge voltage according to battery temperature.\n\n Boost & Trim Automatic Voltage Regulation (AVR)\n Gives higher application availability by correcting low & high voltage conditions without using the battery (not available on all models).\n\n Power conditioning\n Protects connected loads from surges, spikes, lightning, & other power disturbances.\n\n Manageability\n\n Network manageable\n Provides remote power management of the UPS over the network.\n\n Serial connectivity\n Provides management of the UPS via a serial port.\n\n Audible alarms\n Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n LED status indicators\n Quickly understand unit & power status with visual indicators.\n\n USB connectivity\n Provides management of the UPS via a USB (Universal Serial Bus) port (not available on all models).\n\n Safety\n\n Safety-agency approved\n Ensures the product has been tested & approved to work safely with the connected service provider equipment & within the specified environment.\n\n Marketing Features\n\n Low operating & maintenance costs with high efficiency, proven reliability & intelligent battery management\n Patented green operating mode achieves efficiencies over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance & life through intelligent, precision temperature compensated charging.\n Dynamic battery replacement date indicator & automatic self tests insure battery reliability & warn in advance of needing replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down. Designed & manufactured by APC for over 23 years, Smart-UPS is the world&153;s most trusted network UPS with over 25 million units sold.\n\n Save time with easy & convenient remote accessibility\n Network manageable via serial, USB (Universal Serial Bus) or optional ethernet.

Includes:: Powerchute&174; Business Edition Software for convenient monitoring & control, safe operating system shutdown & innovative energy management capabilities.\n\n Smarter productivity with ability to tailor to your specific application needs\n Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application specific settings, thresholds & notifications.\n\n Peace of mind that comes with full equipment compatibility & reliability of a leader\n Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested & approved means that you can deploy Smart-UPS with complete confidence that they meet or exceed the industry&153;s most rigorous standards.\n\n Avoids costly power problems by keeping your IT equipment & data safe & available\n Network grade power conditioning protects from damaging surges & disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% & trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systems\n\n Serviceability\n\n Resettable circuit breakers\n Enables a quick recovery from overload events.\n\n Hot-swappable batteries\n Ensures clean, uninterrupted power to protected equipment while batteries are being replaced\n\n Predictive failure notification\n Provides early-warning fault analysis ensuring proactive component replacement.\n\n User-replaceable batteries\n Increases availability by allowing a trained user to perform upgrades & replacements of the batteries reducing Mean Time to Repair (MTTR)\n\n Battery failure notification\n Provides early-warning fault analysis on batteries enabling timely preventive maintenance\n\n Adaptability\n\n Adjustable voltage-transfer points\n Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.\n\n Adjustable voltage sensitivity\n Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.\n\nclass="generic">\n\n Power Output voltage regulation 5% Output power 1000 WInput operation voltage (min)151 VInput operation voltage (max)302 VOutput operation voltage (min)220 VOutput operation voltage (max)240 VSurge energy rating 459 JEmergency Power Off (EPO)OOutput power capacity 1500 VAPerformance Audible alarm modes Battery replacement UPS topology Line-Interactive Waveform Sine Auto-restart Yes Response time 2 ms LED indicators Yes Noise level 46 d B Audible alarm (s) Yes Features Output frequency 50/60 Hz Web-based management Yes Audible alarm modes Battery replacement UPS topology Line-Interactive Waveform Sine Output voltage regulation 5% Auto-restart Yes Response time 2 ms Output power 1000 WInput operation voltage (min)151 VInput operation voltage (max)302 VOutput operation voltage (min)220 VOutput operation voltage (max)240 VSurge energy rating 459 JEmergency Power Off (EPO)ONoise level 46 d B Audible alarm (s) Yes Output power capacity 1500 VAInput frequency 50/60 Hz Ports & interfaces AC outlets quantity 4 AC outlet (s)AC outlet types C13 coupler, C14 coupler Power plug C14 coupler USB 2.0 ports quantity 1 Ethernet LAN (RJ-45) ports 1 Battery Battery capacity 432 Ah Battery technology Sealed Lead Acid (VRLA) Battery recharge time 3 h Hot-swap battery Yes Cold start Yes Automatic battery test Yes Design Rack capacity 2UForm factor Rackmount LED indicators Yes Product colour Black Display LCDCertification CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEERo HS compliance Yes Operational conditions Operating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-15
- 45 &176;COperating relative humidity (H-H)0
- 95% Storage relative humidity (H-H)0
- 95% Operating altitude 0
- 3000 m Non-operating altitude 0
- 15000 m Technical details Output voltage 230 VOutput frequency 50/60 Hz Management features Web-based management Yes Weight & dimensions Weight 28.6kg Width 432 mm Height 89 mm Depth 457 mm Package width 594 mm Package depth 603 mm Package height 251 mm Package weight 31.8kg Packaging data Quick installation guide Yes Cables included Input power cable, USB cable Resource CDYes Rack mount kit Yes Package width 594 mm Package depth 603 mm Package height 251 mm Package weight 31.8kg Logistics data Quantity per pallet 8 pc (s) Certificates Certification CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEERo HS compliance Yes Other features Output voltage 230 VPackaging content Quick installation guide Yes Cables included Input power cable, USB cable Resource CDYes Rack mount kit Yes\n\n







...

121682 Feature Feature Value UPS topology Line-Interactive Output power capacity 2200 VAOutput power 1980 WWaveform Sine Input operation voltage (min)151 VInput operation voltage (max)302 VInput frequency 50/60 Hz Output operation voltage (min)220 VOutput operation voltage (max)240 VSurge energy rating 375 JResponse time 6 ms Output voltage Total Harmonic Distortion (THD)5% Noise level 55 d B Power protection features Over voltage Audible alarm (s)YAudible alarm modes Alarm when on battery, Low battery alarm AC outlets quantity 9 AC outlet (s)USB port YUSB 2.0 ports quantity 1USB port type USB Type-ASerial interface Y Serial interface type RJ-45 Ethernet LAN (RJ-45) ports 1 Smart Slot Y Battery technology Sealed Lead Acid (VRLA) Number of batteries supported 1 Battery life (max)5 year (s) Battery recharge time 3 h Replacement battery cartridge RBC43 Form factor Rackmount Product colour Black, Metallic Rack capacity 2UCable length 2 m Display LCDCertification CE, EAC, EN 60950, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEEOperating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-15
- 45 &176;COperating relative humidity (H-H)0
- 95% Storage relative humidity (H-H)0
- 95% Operating altitude 0
- 3000 m Non-operating altitude 0
- 15000 m Width 480 mm Depth 683 mm Height 86 mm Weight 42.3kg Rack mount kit Y Cables included RS-232, USB cable Software CDYPackage width 600 mm Package depth 980 mm Package height 254 mm Package weight 49.7kg Quantity per pallet 8 pc (s)





...

116393 Feature Feature Value UPS topology Line-Interactive Output power capacity 2200 VAOutput power 1980 WWaveform Sine Input operation voltage (min)151 VInput operation voltage (max)302 VInput frequency 50/60 Hz Output operation voltage (min)220 VOutput operation voltage (max)240 VSurge energy rating 365 JResponse time 6 ms Emergency Power Off (EPO)YOutput voltage Total Harmonic Distortion (THD)5% Noise level 45 d B Power protection features Over voltage, Overload Audible alarm (s)YAudible alarm modes Alarm when on battery, Low battery alarm, Battery replacement Auto-restart YAC outlets quantity 9 AC outlet (s)USB port YUSB 2.0 ports quantity 1USB port type USB Type-ASerial interface Y Serial ports quantity 1 Ethernet LAN (RJ-45) ports 1 Smart Slot Y Battery technology Sealed Lead Acid (VRLA) Typical backup time at full load 8.7 min Typical backup time at half load 25 min Battery life (max)5 year (s) Battery recharge time 3 h Product colour Black LED indicators Y Display LCDCertification CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDEOperating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-15
- 45 &176;COperating relative humidity (H-H)0
- 95% Storage relative humidity (H-H)0
- 95% Operating altitude 0
- 3000 m Non-operating altitude 0
- 15000 m Width 197 mm Depth 544 mm Height 435 mm Weight 48.8kg Cables included RS-232, USB cable Software CDYPackage width 381 mm Package depth 762 mm Package height 699 mm Package weight 61.9kg Quantity per pallet 9 pc (s)





...

116393 Feature Feature Value UPS topology Line-Interactive Output power capacity 2200 VAOutput power 1980 WWaveform Sine Input operation voltage (min)151 VInput operation voltage (max)302 VInput frequency 50/60 Hz Output operation voltage (min)220 VOutput operation voltage (max)240 VSurge energy rating 365 JResponse time 6 ms Emergency Power Off (EPO)YOutput voltage Total Harmonic Distortion (THD)5% Noise level 45 d B Power protection features Over voltage, Overload Audible alarm (s)YAudible alarm modes Alarm when on battery, Low battery alarm, Battery replacement Auto-restart YAC outlets quantity 9 AC outlet (s)USB port YUSB 2.0 ports quantity 1USB port type USB Type-ASerial interface Y Serial ports quantity 1 Ethernet LAN (RJ-45) ports 1 Smart Slot Y Battery technology Sealed Lead Acid (VRLA) Typical backup time at full load 8.7 min Typical backup time at half load 25 min Battery life (max)5 year (s) Battery recharge time 3 h Product colour Black LED indicators Y Display LCDCertification CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDEOperating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-15
- 45 &176;COperating relative humidity (H-H)0
- 95% Storage relative humidity (H-H)0
- 95% Operating altitude 0
- 3000 m Non-operating altitude 0
- 15000 m Width 197 mm Depth 544 mm Height 435 mm Weight 48.8kg Cables included RS-232, USB cable Software CDYPackage width 381 mm Package depth 762 mm Package height 699 mm Package weight 61.9kg Quantity per pallet 9 pc (s)





...

Cold-start capable\n Provides temporary battery power when the utility power is out.\n\n Energy meter\n Provides actual kilowatt hours of usage for energy conscious users.\n\n Green mode\n Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.\n\n High online efficiency\n Reduces utlility costs, generates less heat.\n\n Intuitive LCD interface\n Provides clear & accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.\n\n Predictive replace battery date\n Dynamically provides the month & year when battery replacement is recommended to aide in long term maintenance planning.\n\n Preinstalled network management card\n Provides for remote management & control of the UPS over a network out of the box.\n\n Single switched outlet group\n Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off & non-critical load shedding.\n\n Smart Slot\n Customize UPS capabilities with management cards.\n\n Temperature-compensated battery charging\n Prolongs battery life by regulating the charge voltage according to battery temperature.\n\n Availability\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n Automatic restart of loads after UPS shutdown\n Automatically starts up the connected equipment upon the return of utility power.\n\n Automatic self-test\n Periodic battery self-test ensures early detection of a battery that needs to be replaced.\n\n Intelligent battery management\n Maximizes battery performance, life, & reliability through intelligent, precision charging.\n\n Temperature-compensated battery charging\n Prolongs battery life by regulating the charge voltage according to battery temperature.\n\n Boost & Trim Automatic Voltage Regulation (AVR)\n Gives higher application availability by correcting low & high voltage conditions without using the battery (not available on all models).\n\n Power conditioning\n Protects connected loads from surges, spikes, lightning, & other power disturbances.\n\n Manageability\n\n Network manageable\n Provides remote power management of the UPS over the network.\n\n Serial connectivity\n Provides management of the UPS via a serial port.\n\n Audible alarms\n Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n LED status indicators\n Quickly understand unit & power status with visual indicators.\n\n USB connectivity\n Provides management of the UPS via a USB (Universal Serial Bus) port (not available on all models).\n\n Safety\n\n Safety-agency approved\n Ensures the product has been tested & approved to work safely with the connected service provider equipment & within the specified environment.\n\n Marketing Features\n\n Low operating & maintenance costs with high efficiency, proven reliability & intelligent battery management\n Patented green operating mode achieves efficiencies over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance & life through intelligent, precision temperature compensated charging.\n Dynamic battery replacement date indicator & automatic self tests insure battery reliability & warn in advance of needing replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down. Designed & manufactured by APC for over 23 years, Smart-UPS is the world&153;s most trusted network UPS with over 25 million units sold.\n\n Save time with easy & convenient remote accessibility\n Network manageable via serial, USB (Universal Serial Bus) or optional ethernet.

Includes:: Powerchute&174; Business Edition Software for convenient monitoring & control, safe operating system shutdown & innovative energy management capabilities.\n\n Smarter productivity with ability to tailor to your specific application needs\n Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application specific settings, thresholds & notifications.\n\n Peace of mind that comes with full equipment compatibility & reliability of a leader\n Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested & approved means that you can deploy Smart-UPS with complete confidence that they meet or exceed the industry&153;s most rigorous standards.\n\n Avoids costly power problems by keeping your IT equipment & data safe & available\n Network grade power conditioning protects from damaging surges & disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% & trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systems\n\n Serviceability\n\n Resettable circuit breakers\n Enables a quick recovery from overload events.\n\n Hot-swappable batteries\n Ensures clean, uninterrupted power to protected equipment while batteries are being replaced\n\n Predictive failure notification\n Provides early-warning fault analysis ensuring proactive component replacement.\n\n User-replaceable batteries\n Increases availability by allowing a trained user to perform upgrades & replacements of the batteries reducing Mean Time to Repair (MTTR)\n\n Battery failure notification\n Provides early-warning fault analysis on batteries enabling timely preventive maintenance\n\n Adaptability\n\n Adjustable voltage-transfer points\n Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.\n\n Adjustable voltage sensitivity\n Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications. Feature Feature Value UPS topology Line-Interactive Output power capacity 2200 VAOutput power 1980 WWaveform Sine Input operation voltage (min)151 VInput operation voltage (max)302 VInput frequency 50/60 Hz Output operation voltage (min)220 VOutput operation voltage (max)240 VOutput frequency 50/60 Hz Surge energy rating 375 JResponse time 4 ms Emergency Power Off (EPO)ONoise level 55 d B Surge protection Y Audible alarm (s)YWeb-based management Y Audible alarm modes Battery replacement Auto-restart YAC outlet types C20 coupler Power plug C20 coupler AC outlets quantity 9 AC outlet (s)USB 2.0 ports quantity 1 Ethernet LAN (RJ-45) ports 1 Battery technology Sealed Lead Acid (VRLA) Battery capacity 509 Ah Battery recharge time 5 h Hot-swap battery Y Automatic battery test Y Cold start Y Form factor Rackmount Product colour Black Rack capacity 2ULED indicators Y Display LCDRo HS compliance Y Certification CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEEOperating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-15
- 45 &176;COperating relative humidity (H-H)0
- 95% Storage relative humidity (H-H)0
- 95% Operating altitude 0
- 3000 m Non-operating altitude 0
- 15000 m Width 480 mm Depth 683 mm Height 86 mm Weight 42.2kg Rack mount kit Y Cables included Input power cable, USB cable Quick installation guide Y Resource CDYPackage width 600 mm Package depth 980 mm Package height 254 mm Package weight 49.6kg Quantity per pallet 8 pc (s) Output voltage 230 V







...

Cold-start capable\n Provides temporary battery power when the utility power is out.\n\n Energy meter\n Provides actual kilowatt hours of usage for energy conscious users.\n\n Green mode\n Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.\n\n High online efficiency\n Reduces utlility costs, generates less heat.\n\n Intuitive LCD interface\n Provides clear & accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.\n\n Predictive replace battery date\n Dynamically provides the month & year when battery replacement is recommended to aide in long term maintenance planning.\n\n Preinstalled network management card\n Provides for remote management & control of the UPS over a network out of the box.\n\n Single switched outlet group\n Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off & non-critical load shedding.\n\n Smart Slot\n Customize UPS capabilities with management cards.\n\n Temperature-compensated battery charging\n Prolongs battery life by regulating the charge voltage according to battery temperature.\n\n Availability\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n Automatic restart of loads after UPS shutdown\n Automatically starts up the connected equipment upon the return of utility power.\n\n Automatic self-test\n Periodic battery self-test ensures early detection of a battery that needs to be replaced.\n\n Intelligent battery management\n Maximizes battery performance, life, & reliability through intelligent, precision charging.\n\n Temperature-compensated battery charging\n Prolongs battery life by regulating the charge voltage according to battery temperature.\n\n Boost & Trim Automatic Voltage Regulation (AVR)\n Gives higher application availability by correcting low & high voltage conditions without using the battery (not available on all models).\n\n Power conditioning\n Protects connected loads from surges, spikes, lightning, & other power disturbances.\n\n Manageability\n\n Network manageable\n Provides remote power management of the UPS over the network.\n\n Serial connectivity\n Provides management of the UPS via a serial port.\n\n Audible alarms\n Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.\n\n Disconnected battery notification\n Warns when a battery is not available to provide backup power.\n\n LED status indicators\n Quickly understand unit & power status with visual indicators.\n\n USB connectivity\n Provides management of the UPS via a USB (Universal Serial Bus) port (not available on all models).\n\n Safety\n\n Safety-agency approved\n Ensures the product has been tested & approved to work safely with the connected service provider equipment & within the specified environment.\n\n Marketing Features\n\n Low operating & maintenance costs with high efficiency, proven reliability & intelligent battery management\n Patented green operating mode achieves efficiencies over 97%. Smart-ups was the first network UPS to be Energy Star certified. Intelligent battery management, pioneered by APC, maximizes battery performance & life through intelligent, precision temperature compensated charging.\n Dynamic battery replacement date indicator & automatic self tests insure battery reliability & warn in advance of needing replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down. Designed & manufactured by APC for over 23 years, Smart-UPS is the world&153;s most trusted network UPS with over 25 million units sold.\n\n Save time with easy & convenient remote accessibility\n Network manageable via serial, USB (Universal Serial Bus) or optional ethernet.

Includes:: Powerchute&174; Business Edition Software for convenient monitoring & control, safe operating system shutdown & innovative energy management capabilities.\n\n Smarter productivity with ability to tailor to your specific application needs\n Intuitive LCD interface provides clear information with the ability to configure the UPS locally with easy to use navigation keys. Over 15 different programmable settings including switched outlet group control allow for application specific settings, thresholds & notifications.\n\n Peace of mind that comes with full equipment compatibility & reliability of a leader\n Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested & approved means that you can deploy Smart-UPS with complete confidence that they meet or exceed the industry&153;s most rigorous standards.\n\n Avoids costly power problems by keeping your IT equipment & data safe & available\n Network grade power conditioning protects from damaging surges & disruptive noise. Solid state automatic voltage regulation boosts low input voltage up to 30% & trims high voltage up to 12% without battery operation. Reliable battery back-up capacity to power through outages or gracefully shutdown systems\n\n Serviceability\n\n Resettable circuit breakers\n Enables a quick recovery from overload events.\n\n Hot-swappable batteries\n Ensures clean, uninterrupted power to protected equipment while batteries are being replaced\n\n Predictive failure notification\n Provides early-warning fault analysis ensuring proactive component replacement.\n\n User-replaceable batteries\n Increases availability by allowing a trained user to perform upgrades & replacements of the batteries reducing Mean Time to Repair (MTTR)\n\n Battery failure notification\n Provides early-warning fault analysis on batteries enabling timely preventive maintenance\n\n Adaptability\n\n Adjustable voltage-transfer points\n Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.\n\n Adjustable voltage sensitivity\n Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications. Feature Feature Value UPS topology Line-Interactive Output power capacity 2200 VAOutput power 1980 WWaveform Sine Input operation voltage (min)151 VInput operation voltage (max)302 VInput frequency 50/60 Hz Output operation voltage (min)220 VOutput operation voltage (max)240 VOutput frequency 50/60 Hz Surge energy rating 375 JResponse time 4 ms Emergency Power Off (EPO)ONoise level 55 d B Surge protection Y Audible alarm (s)YWeb-based management Y Audible alarm modes Battery replacement Auto-restart YAC outlet types C20 coupler Power plug C20 coupler AC outlets quantity 9 AC outlet (s)USB 2.0 ports quantity 1 Ethernet LAN (RJ-45) ports 1 Battery technology Sealed Lead Acid (VRLA) Battery capacity 509 Ah Battery recharge time 5 h Hot-swap battery Y Automatic battery test Y Cold start Y Form factor Rackmount Product colour Black Rack capacity 2ULED indicators Y Display LCDRo HS compliance Y Certification CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEEOperating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-15
- 45 &176;COperating relative humidity (H-H)0
- 95% Storage relative humidity (H-H)0
- 95% Operating altitude 0
- 3000 m Non-operating altitude 0
- 15000 m Width 480 mm Depth 683 mm Height 86 mm Weight 42.2kg Rack mount kit Y Cables included Input power cable, USB cable Quick installation guide Y Resource CDYPackage width 600 mm Package depth 980 mm Package height 254 mm Package weight 49.6kg Quantity per pallet 8 pc (s) Output voltage 230 V







...

116386 Feature Feature Value UPS topology Line-Interactive Output power capacity 3000 VAOutput power 2700 WWaveform Sine Input operation voltage (min)151 VInput operation voltage (max)302 VInput frequency 50/60 Hz Automatic Voltage Regulation (AVR)YSurge energy rating 365 JHold time (max)2 ms Efficiency 98.4% Emergency Power Off (EPO)YNoise level 53 d B Surge protection Y Audible alarm (s)YAuto-restart YAC outlet types C13 coupler, C19 coupler Power plug C20 coupler AC outlets quantity 9 AC outlet (s) Number of output IEC jumpers 2USB port Y Smart Slot Y Battery technology Sealed Lead Acid (VRLA) Battery capacity 816 VAh Typical backup time at full load 5.1 min Typical backup time at half load 17.2 min Battery life (max)5 year (s) Battery recharge time 3 h Hot-swap battery Y Automatic battery test Y Cold start Y Form factor Tower Product colour Black Cable length 1.83 m LED indicators Status Display LCDRo HS compliance Y Certification CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH, PEP, EOLIOperating temperature (T-T)0
- 40 &176;CStorage temperature (T-T)-15
- 45 &176;COperating relative humidity (H-H)0
- 95% Storage relative humidity (H-H)0
- 95% Operating altitude 0
- 3000 m Non-operating altitude 0
- 15000 m Width 197 mm Depth 544 mm Height 435 mm Weight 52.5kg Cables included RS-232, USB cable Quick installation guide Y Package width 381 mm Package depth 762 mm Package height 699 mm Package weight 63.7kg Quantity per pallet 9 pc (s) Nominal output voltage 230 VNominal input voltage 230 V





...
