RAC014 Powerlite Dynalite Designed & manufactured by highly experienced auto electricians in West Midlands, UK. The Dynalite aims to bring together modern alternator technology with the classic looks & appearance of a Dynamo. Ideal for both road & competition use the Dynalite provides up to 80% more power & weigh up to 40% less than original dynamo units. The Dynalite units are produced in a wide range of different models replicating original dynamo units, thus allowing the Dynalite to directly replace dynamo units with no modifications to the vehicle. In many cases the original dynamo pulleys can also be used on the new units, creating a simple & reversible alternator conversion. The self regulating Dynalite units offer increased reliability & performance charging efficiently across the full rev range. The wiring changes required for the units are very simple & reversible. All Dynalite units are supplied with comprehensive fitting instructions. Powerlite also offer a wide range of fitting accessories including pulleys & dummy control boxes. What changes need to be made to the wiring? The Dynalite unlike a dynamo is self regulating, therefore the control box is redundant. There are two ways to rewire the control box for the Dynalite unit. The first is to simply bypass or use the control box as a junction point with two small wiring changes. The second & preferred option is to fit a Powerlite dummy control box. Dummy Control Boxes: Identical in fitment & appearance to the original, the dummy unit is pre-wired to aid the necessary changes. Dummy boxes are fitted with an 40A fuse, protecting your electrical system. We recommend the use of dummy control boxes where applicable. NOW 60AMP!! LUCAS C45 TYPE (POSITIVE EARTH) SEE RAC008 FOR NEGATIVE EARTH. The RAC014 (C45 Dynamo replacement) now has a 60 Amp output as opposed to the original 40amp. This now means that it offers more than three times the power of the original dynamo together with increased reliability & full power available at engine tick-over speed. Amps
- 60 A Bracket Distance
- 165 mm OEM
- Lucas Polarity
- Positive Earth Shaft Diameter
- 17 mm




...

RAC016 Powerlite Dynalite Designed & manufactured by highly experienced auto electricians in West Midlands, UK. The Dynalite aims to bring together modern alternator technology with the classic looks & appearance of a Dynamo. Ideal for both road & competition use the Dynalite provides up to 80% more power & weigh up to 40% less than original dynamo units. The Dynalite units are produced in a wide range of different models replicating original dynamo units, thus allowing the Dynalite to directly replace dynamo units with no modifications to the vehicle. In many cases the original dynamo pulleys can also be used on the new units, creating a simple & reversible alternator conversion. The self regulating Dynalite units offer increased reliability & performance charging efficiently across the full rev range. The wiring changes required for the units are very simple & reversible. All Dynalite units are supplied with comprehensive fitting instructions. Powerlite also offer a wide range of fitting accessories including pulleys & dummy control boxes. What changes need to be made to the wiring? The Dynalite unlike a dynamo is self regulating, therefore the control box is redundant. There are two ways to rewire the control box for the Dynalite unit. The first is to simply bypass or use the control box as a junction point with two small wiring changes. The second & preferred option is to fit a Powerlite dummy control box. Dummy Control Boxes: Identical in fitment & appearance to the original, the dummy unit is pre-wired to aid the necessary changes. Dummy boxes are fitted with an 40A fuse, protecting your electrical system. We recommend the use of dummy control boxes where applicable. PORSCHE 356 (12 VOLT) REQUIRES MODIFIED UPSTAND (NEGATIVE EARTH) Amps
- 40 A OEM
- Bosch Polarity
- Negative Earth Shaft Diameter
- 15 mm



...

RAC023 Powerlite C42 PAS Type Dynalite
- Negative Earth Amps: 40 A Bracket distance: 173mm OEM: Lucas Polarity: Negative Earth
...

RAC024 Powerlite Dynalite Designed & manufactured by highly experienced auto electricians in West Midlands, UK. The Dynalite aims to bring together modern alternator technology with the classic looks & appearance of a Dynamo. Ideal for both road & competition use the Dynalite provides up to 80% more power & weigh up to 40% less than original dynamo units. The Dynalite units are produced in a wide range of different models replicating original dynamo units, thus allowing the Dynalite to directly replace dynamo units with no modifications to the vehicle. In many cases the original dynamo pulleys can also be used on the new units, creating a simple & reversible alternator conversion. The self regulating Dynalite units offer increased reliability & performance charging efficiently across the full rev range. The wiring changes required for the units are very simple & reversible. All Dynalite units are supplied with comprehensive fitting instructions. Powerlite also offer a wide range of fitting accessories including pulleys & dummy control boxes. What changes need to be made to the wiring? The Dynalite unlike a dynamo is self regulating, therefore the control box is redundant. There are two ways to rewire the control box for the Dynalite unit. The first is to simply bypass or use the control box as a junction point with two small wiring changes. The second & preferred option is to fit a Powerlite dummy control box. Dummy Control Boxes: Identical in fitment & appearance to the original, the dummy unit is pre-wired to aid the necessary changes. Dummy boxes are fitted with an 40A fuse, protecting your electrical system. We recommend the use of dummy control boxes where applicable. LUCAS C40 TYPE (POSITIVE EARTH) SEE RAC006 FOR NEGATIVE EARTH. Amps
- 40 A Bracket Distance
- 144 mm OEM
- Lucas Polarity
- Positive Earth Shaft Diameter
- 15 mm




...

RAC026 Powerlite Dynalite Designed & manufactured by highly experienced auto electricians in West Midlands, UK. The Dynalite aims to bring together modern alternator technology with the classic looks & appearance of a Dynamo. Ideal for both road & competition use the Dynalite provides up to 80% more power & weigh up to 40% less than original dynamo units. The Dynalite units are produced in a wide range of different models replicating original dynamo units, thus allowing the Dynalite to directly replace dynamo units with no modifications to the vehicle. In many cases the original dynamo pulleys can also be used on the new units, creating a simple & reversible alternator conversion. The self regulating Dynalite units offer increased reliability & performance charging efficiently across the full rev range. The wiring changes required for the units are very simple & reversible. All Dynalite units are supplied with comprehensive fitting instructions. Powerlite also offer a wide range of fitting accessories including pulleys & dummy control boxes. What changes need to be made to the wiring? The Dynalite unlike a dynamo is self regulating, therefore the control box is redundant. There are two ways to rewire the control box for the Dynalite unit. The first is to simply bypass or use the control box as a junction point with two small wiring changes. The second & preferred option is to fit a Powerlite dummy control box. Dummy Control Boxes: Identical in fitment & appearance to the original, the dummy unit is pre-wired to aid the necessary changes. Dummy boxes are fitted with an 40A fuse, protecting your electrical system. We recommend the use of dummy control boxes where applicable. LUCAS C42 TYPE (POSITIVE EARTH) SEE RAC007 FOR NEGATIVE EARTH. Amps
- 40 A Bracket Distance
- 173 mm OEM
- Lucas Polarity
- Positive Earth Shaft Diameter
- 15 mm




...

RAC045 Powerlite C45 PAS Type Dynalite
- Negative Earth Lucas C45PV5 type Dynalite with power steering connections in negative
...

RAC046 Powerlite C45 PAS Type Dynalite
- Positive Earth Lucas C45PV5 type dynalite with power steering connections in positive
...

RAC051 Powerlite Alternator Powerlite offer a range of Alternators including compact lightweight units, ideal for competition cars where weight & space are at a premium. Our alternators are available in a wide range of outputs & bracket configurations enabling a suitable unit to be identified to meet the specifications required. The range also

Includes:: adaptable multimount units & units configured to replace standard units without modification Simple wiring on the units affords easy fitment when replacing original equipment alternators or dynamos on a wide range of vehicles. Powerlite also offer a range of wiring connectors & adapters to aid installation.FORD DURATEC ENGINE 80 AMP ALTERNATOR. SUPPLIED WITH MOUNTING BRACKETS TO FIT ON THE INLET SIDE OF THE ENGINEWiring configuration
- RAC906 Amps
- 80 AShaft Diameter
- 17 mm




...

RAC056 Powerlite Alternator Powerlite offer a range of Alternators including compact lightweight units, ideal for competition cars where weight & space are at a premium. Our alternators are available in a wide range of outputs & bracket configurations enabling a suitable unit to be identified to meet the specifications required. The range also

Includes:: adaptable multimount units & units configured to replace standard units without modification Simple wiring on the units affords easy fitment when replacing original equipment alternators or dynamos on a wide range of vehicles. Powerlite also offer a range of wiring connectors & adapters to aid installation.A127 TYPE ALTERNATOR. 55 AMP R/H FIXING, SUPPLIED WITH FAN & PULLEY & SPACERS. Wiring configuration
- RAC916 Amps
- 55 AShaft Diameter
- 17 mm




...

RAC057 Powerlite Lucas style A127 55 Amp L/HA127 TYPE ALTERNATOR. 55 AMP L/H FIXING, SUPPLIED WITH FAN & PULLEY & SPACERS. Lucas A127 55 amp left hand fixing. Heavy duty alternator used in many applications. Versatile & easy to fit ...
