Decoder scale NTT with NEM651 6pin plug DCC Multiprotocol decoder with load regulation for DC & Faulhaber motors With higher current capacity for small locos with High current demands N TT OOHO Features Regulated Multiprotocol decoder for DCC Motorola with automatic system recognition for analog DC Suitable for DC & Bell armature motors up to 07A 15A peak current Quiet motor running with 1875 K Hz control frequency 14 27 28 31 & 128 speed steps depending on the data format Short 1127 & long 1289999 addresses NMRA compatible Minimum maximum & middle speeds adjustable Speed step table for 14 28 & 31 speed steps Main line programming DCC Shunting speed half speed switched with F3 Direction dependent dimmable lighting switched via F0 With solder pads for connecting Uhlenbrock Intelli Sound modules or LISSY Mini transmitter Reacts to DCC brake signal eg from Power 3 Brake diode or braking section in DC operation All outputs have short circuit protection Conventional DC operation with automatic switching between DC & digital mode All CVs programmable by digital devices with DCC & Motorola formats Programmable via register direct CV or page mode in DCC operation Updatable using Flash memory NEM651 6 pin plug
Dimensions 145 x 83 x 24mm
