The FOX F12-942 Bench Top Pillar Drill has similar features to the smaller pillar drills in the Fox range. This model represents the best performance in a complete pillar drill that is suited to a small or medium sized workshop; alternatively, it would be ideal for a light tradesman. It has a 450W, 0.5hp motor that generates five separate speeds, ranging from 180 to 2740rpm. There is a B16 chuck with a capacity of 3 to 16mm & a tilting workbench with grooves that are perfect for vice fitments. This pillar drill operated using aluminium pulleys for almost silent operation & offers a chuck stroke of 80mm. The innovatively designed handles make it even easier to use. ...

The Fox F12-961 Floor Standing Pillar Drill is a professional quality unit with serious power, accuracy & reliability. It would be perfectly suited to a professional tradesman or craftsman. It has a powerful 1500W 2hp motor that generates 12 separate speeds ranging from 200-1990rpm. It has a 475x 425mm workbench that tilts & has grooves for fitting a vice. There is a B22 chuck with a min/max capacity of 5-20mm & the drill is operated by a system of aluminium pulleys for near silent operation. The innovatively designed handles make the machine easy to operate. ...

The Fox F14-650 1/2" Bench Top Mortiser is the perfect choice for a woodworking enthusiast, small workshop or joinery shop. It is compact & sturdy with a cast iron head & a cast steel base. It has a double bar rack for accurate & repeatable up & down movement while the gas strut makes for a smooth rise & fall mechanism. There is a user adjustable depth stop for accurate & repetitive strokes as well as a tool holder rack. The 370W induction motor develops 0.5hp. ...

The Fox F14-651 3/4" Bench Top Mortiser is one of Foxs most popular tools. It is a robust machine with a cast iron construction that provides brilliant stability. It has two steel columns & a unique 180 degree rotating base to allow the user to mortise off-bench. There is a 370W induction motor & a double bar rack for a precise up & down movement. There is a user adjustable depth stop for exact & repetitive strokes & a gas strut that provides a smooth rise & fall movement. It boasts 230mm of head travel & a 180 degree rotating head. Chisel Capacity: 6 to 12mm (1/4 to 1/2 inches) Maximum mortising

Depth: 76mm (3 inches) Drill chuck capacity: 1 to 13mm Table

Size: 340 x 150m Sm wood Table

Size: 180 x 150mm Base

Size: 320 x 200mm Spindle to fence (maximum): 65mm Chisel to table (maximum): 120mm Overall

Height: 780mm Turn headstock: 0 to 360 degrees Motor: 230V 50 Hz 370 W Spindle speed: 1, 400rpm Gross weight: 35kg Net weight: 31kg Packing

Size: 560 x 370 x 260mm











...

The Fox F14-656 1HP Ultimate Mortiser was designed with the serious user & demanding workshop in mind. The powerful 750W induction motor develops 1HP, easily powering mortisers of up to 1" or 25.4mm in softwood & 34;" (19mm) in hardwoods. There is a precision milled cast iron table that gives the user both lateral & longitudinal adjustment options via the well placed hand wheels. There is a hydraulic gas strut that provides counterbalance & ensures optimum control & high quality movement during operation. There is a double bar rack for accurate up & down movement & a user adjustable depth stop for precise & repeatable strokes. The head of this mortiser travels 200mm. ...

The Fox F22-564-250 10" x 5" Planer Thicknesser is an ideal planing/thicknessing solution for a busy workshop. It is a professional woodworking tool that is tough & sturdy enough to manage even the most difficult jobs. It has a maximum cutting width of 250mm & a maximum thicknesser cutting capacity height of 120mm. There is a large cast aluminium planer bench that measures in at an impressive 920 x 292mm as well as a strong aluminium tilting fence & a 100mm dust port. Motor: 1280W
- 240V (1.5HP) Blade

Size: 261x 16.5x 1.5mm Block Speed: 9000rpm Max Planing

Width: 250mm Max Cutting Depth per Pass: Thicknesser-3mm, Planer-2mm Feed Rate: 6m/min Range of Cutting

Depth: 5-120mm Table Size of Thicknesser: 270x 290mm Table Size of Planer: 920x 262mm Aluminium Parallel Fence Dimensions: 635mmx 124mm Dust Port Diameter: 100mm

Dimensions (h x l x d): 1100x 970x 520mm Weight: 36kg








...

The Fox F22-568 10" x 7" Planer Thicknesser is solid & sturdy. It has a large cast iron thicknessing bed that is securely mounted on a central ram with two columns that ensure accurate & stable work at all times. It has a 2200W induction motor & a maximum cutting width of 250mm. The table itself can be mounted on three separate guides to allow easy working & there is a large parallel guide that offers a large & stable surface. The blades have a long sharpening life thanks to the rotation speed & there is a large capacity dust port also. The engines efficiency is maintained by the motors pulley drive system. Motor: 2200W
- 240V Blade

Size: 250x 30x 3mm Block Speed: 4000rpm Max Planing

Width: 250mm Max Cutting Depth per Pass: Thicknesser-3mm, Planer-2.5mm Feed Rate: 8m/min Range of Cutting

Depth: 5-200mm Table Size of Thicknesser: 250x 600mm Table Size of Planer: 248x 600mm Aluminium Parallel Fence Dimensions: 720x 130mm Dust Port Diameter: 100mm

Dimensions (h x l x d): 720x 1130x 490mm Weight: 148kg








...

The Fox F28-182 FOX Bandsaw is the perfect machine for a workshop where space is at a premium. Its height cutting capacity is a unique 85mm, its width capacity is 200mm. The featured press steel work bench (300mm x 300mm) tilts to 45 degrees, & the 200W induction motor is quiet while still providing 0.5hp. There is an integral dust port with a diameter of 38mm. ...

The Fox F28-186 Bandsaw is a small & compact bandsaw with a large cutting capacity, allowing you to work on much larger workpieces than you would normally be able to with a bandsaw of this size. There is a cast iron table that tilts to 45 degrees & a 370W induction motor that provides 0.5hp while still remaining quiet. There are both upper & lower bearing blade guides & the upper guide is adjustable via the smooth rack. The upper & lower doors of this machine have micro switches in order to prevent accidental operation when they are open & there is a blade capacity of 3 to 12.7mm wide. Included are 2x 250mm cast aluminium flywheels. Table Dimensions: 340x 340mm Table

Height: 1060mm Max Cutting Capacity
- Throat: 245mm Max Cutting Capacity
-

Height: 150mm Blade Length: 1820mm Blade Speed: 730m/min Dust Port Diameter: 38mm

Dimensions Incl. Stand (h x l x d): 1600x 600x 470mm Weight: 36kg







...

The Fox F28-191 Bandsaw is ideal for cutting up to 160mm in height with a width of anything up to 305mm. Included are two rotation speed levels which can be material specifically adjusted to match the job at h&. There is a 521x 400mm aluminium table that tilts to 45&730; & the 750W induction motor develops 1hp while remaining quiet during operation. There are upper & lower bearing blade guides that are adjustable via the smooth rack. The machine is housed on a steel base & there are 2 x 315mm cast aluminium flywheels. Table

Height: 1060mm Max Cutting Capacity
- Throat: 305mm Max Cutting Capacity
-

Height: 160mm Blade Capacity: 3-20mm Blade Length: 2240mm Blade Speed: 370-800m/min Dust Port Diameter: 100mm

Dimensions Incl. Stand (h x l x d): 1680x 850x 600mm Weight: 49kg







...
