With the 6000 series, XFX is literally putting you in the game. The AMD Radeon HD 6850 is 3-D ready & one of the first HDMI 1.4a & Display Port 1.2 solutions for Stereoscopic 3-D on the market. The AMD Radeon HD 6850 ushers in a new era of gaming that takes users to an entirely new level. The AMD 3-D experience is truly immersive & seamless. AMD has also teamed up with other Open 3-D ecosystem partners to provide consumers with more choice, more innovation & lower cost. Microsoft Direct X 11 Support ATI Eyefinity Technology AMD HD3D Technology AMD Advanced Parallel Processing Technology Microsoft Windows 7 Support 40nm Process Technology 3rd Generation Tera Scale Engine

Specification Specifications Chipset HD6850 Bus Type PCI-E 2.1 GPU Clock 775 MHz Memory Bus 256 bit Memory Clock 4.0 GHz Memory Size 1 GB Memory Type DDR5 Stream Processors 960 Thermal Solution Fansink Minimum Power Supply Requirement 500 Watt XFX Recommended Power Supply XFX 650W XXX edt PSU Outputs: Max Supported Resolution (ANALOG) 2048 x 1536 Max Supported Resolution (DIGITAL) 2560 x 1600 Output
- Display Port 1 Output
- DVI 2 Output
- HDMI 1




...

With the 6000 series, XFX is literally putting you in the game. The AMD Radeon HD 6850 is 3-D ready & one of the first HDMI & Display Port 1.2 solutions for Stereoscopic 3-D on the market. The AMD Radeon HD 6850 ushers in a new era of gaming that takes users to an entirely new level. The AMD 3-D experience is truly immersive & seamless. AMD has also teamed up with other Open 3-D ecosystem partners to provide consumers with more choice, more innovation & lower cost. This high-speed graphics card outdoes the competition with 800 M Hz, a 4 G Hz memory clock, DP + HDMI + Dual DVI which allows for play across four screens & a shader speed of 800 to ensure that graphics are crisp & life-like. Along with this series XFX debuts the 3E Trilogy, incorporating AMD Eye-Definition (utilizing AMDs HD3D technology & Direct X 11 for explosive performance & stunning effects), AMD Eyefinity (which supports multi-display gaming) & AMD Eyespeed (improves video image quality & application performance for amazing visuals) technologies. The AMD Radeon HD 6850 offers no compromise performance with flawless image quality so users arent just playing the game
- theyre in it. Specifcations GPU
- AMD HD 6850 Memory
- 1GB GDDR5 Core
- 800 M Hz (standard 775 M Hz) Memory Clock
- 4.2 G Hz Outputs
- Dual DVI, HDMI, Display Port Bus
- PCI-Express






...

The AMD Radeon HD 6870 is 3-D ready & one of the first HDMI & Display Port 1.2 solutions for Stereoscopic 3-D on the market. The AMD Radeon HD 6870 ushers in a new era of gaming that takes users to an entirely new level. The AMD 3-D experience is truly immersive & seamless. AMD has also teamed up with other Open 3-D ecosystem partners to provide consumers with more choice, more innovation & lower cost. Along with the series XFX debuts the 3E Trilogy, incorporating AMD eye-definition, AMD Eyefinity & AMD Eyespeed technologies. Specifications GPU
- HD 6870 Memory Size
- 1GB Memory Type
- GDDR5 Core Clock
- 900 M Hz Memory Clock
- 4.2 G Hz Memory Bus
- 256bit Outputs
- DVI x 2, HDMI x 1, Mini Display Port x 2 External Power 6pin
- x 2 Minimum Power Supply Requirement 500 Watt AMD Crossfire Ready
- Yes AMD Eyefinity Technology
- Yes Card Profile
- Double Card

Dimensions (cm)
- 22 x 11.12 x 3.81













...

Microsoft Direct X 11 AMD Cross Fire ready AMD Advanced Parallel Processing Technology (APP) AMD Avivo HD AMD Eyefinity Technology AMD HD3D Technology AMD Hybrid Graphics Technology AMD Power Play Technology AMD Stream Technology Specifications Chipset
- HD6950 Bus Type
- PCI-E 2.1 GPU Clock
- 880 MHz External Power
- 6-Pins 1 External Power
- 8-Pins 1 Memory Bus
- 256 bit Memory Clock
- 5.5 GHz Memory Size
- 2 GB Memory Type
- DDR5 Thermal Solution
- Blower Fansink Minimum Power Supply Requirement
- 550 Watt XFX Recommended Power Supply
- XFX 650W XXX edt PSU Outputs Max Supported Resolution (ANALOG)
- 2048 x 1536 Max Supported Resolution (DIGITAL)
- 2560 x 1600 Output
- HDMI 1 Output
- mini DP 2 Dual link Support
- Yes Output
- DL-DVI 1 Output
- SL-DVI 1


















...

XFX HD 7750 2GB DDR3 Dual DVI HDMI Display Port PCI-E Graphics Card Based on the award-winning GCN Architecture, AMD Radeon HD 7700 Series GPUs are built to destroy with the industry’s very first 28nm GPU design. Packed with incredible features, such as PCI Express 3.0, the ultra-efficient AMD Zero Core Power technology or gaming at resolutions beyond 5760x 1080 with AMD Eyefinity technology, these are the world’s most advanced graphics. For everyone. Processor & Bus: Chipset version: ATI Radeon HD 7750 GPU Clock: 800 MHz Memory: Memory Bus: 128 bit Memory Clock: 1.3 GHz Memory Size: 2 GB Memory Type: DDR3 Feature Technologies: AMD Eyefinity Technology: Y AMD HD3D Technology: Y Display Output: Display Port ready: 1.2 Dual link Support: Y HDMI Ready: 1.4a Max Supported Resolution (ANALOG): 2048 x 1536 Max Supported Resolution (DIGITAL): 2560 x 1600 Output
- Display Port: 1 Output
- DL-DVI-I: 1 Output
- HDMI: 1 Output
- SL-DVI-D: 1 Physical: Card Profile: Dual Thermal Solution: Fansink Thermal Type: Dual slot Card Dimension (cm): 16.8 x 11.12 x 3.81 Card Dimension (inch): 6.6 x 4.4 x 1.5 Requirements: Minimum Power Supply Requirement: 450 watt XFX Recommended Power Supply: XFX 550W PSU



...

Based on the award-winning GCN Architecture, AMD Radeon HD 7700 Series GPUs are built to destroy with the industrys very first 28nm GPU design. Packed with incredible features, such as PCI Express 3.0, the ultra-efficient AMD Zero Core Power technology or gaming at resolutions beyond 5760x 1080 with AMD Eyefinity technology, these are the worlds most advanced graphics. For everyone. Processor & Bus GPU Clock
- 800 MHz Chipset version
- AMD Radeon HD 7750 Memory Memory Bus
- 128 bit Memory Clock
- 1.3 GHz Memory Size
- 2 GB Memory Type
- DDR3 Feature Technologies AMD Eyefinity Technology
- Y AMD HD3D Technology
- Y Display Output Display Port ready
- 1.2 Dual link Support
- Y HDMI Ready
- 1.4a Max Supported Resolution (ANALOG)
- 2048 x 1536 Max Supported Resolution (DIGITAL)
- 2560 x 1600 Output
- Display Port x 1 Output
- SL-DVI-D x 1 Output
- DL-DVI-I x 1 Output
- HDMI x 1
















...

Based on the award-winning GCN Architecture, AMD Radeon HD 7700 Series GPUs are built to destroy with the industry’s very first 28nm GPU design. Packed with incredible features, such as PCI Express 3.0, the ultra-efficient AMD Zero Core Power technology or gaming at resolutions beyond 5760x 1080 with AMD Eyefinity technology, these are the world’s most advanced graphics. For everyone. * Product appearance &

Specification may vary* Processor & Bus: Chipset version: ATI Radeon HD 7770 GPU Clock: 1000 MHz Memory: Memory Bus: 128 bit Memory Clock: 4.5 GHz Memory Size: 1 GB Memory Type: DDR5 Feature Technologies: AMD Eyefinity Technology: Y AMD HD3D Technology: Y Other

Features: AMD
- Cross Fire ready: Y Display Output: Display Port ready: 1.2 Dual link Support: Y HDMI Ready: 1.4a Max Supported Resolution (ANALOG): 2048 x 1536 Max Supported Resolution (DIGITAL): 2560 x 1600 Output
- Display Port: 1 Output
- DL-DVI-I: 1 Output
- HDMI: 1 Output
- SL-DVI-D: 1 Physical: Card Profile: Dual Thermal Solution: Axial fansink Thermal Type: Dual slot Card Dimension (cm): 167. x 11.12 x 3.81 Card Dimension (inch): 6.6 x 4.4 x 1.5








...

Based on the award-winning GCN Architecture, AMD Radeon HD 7700 Series GPUs are built to destroy with the industrys very first 28nm GPU design. Packed with incredible features, such as PCI Express 3.0, the ultra-efficient AMD Zero Core Power technology or gaming at resolutions beyond 5760x 1080 with AMD Eyefinity technology, these are the worlds most advanced graphics. For everyone. Core Edition: Benchmark Core Clock This card features XFXs unique standard GPU core at 1000 MHz which is the benchmark core clock. Enjoy a great immersive gaming experience. GHz Edition The first generation of ground breaking GPUs with core clocks above 1 G Hz. The GHz Edition graphics cards from XFX & AMD are designed with massive headroom for overclocking beyond 1 G Hz. The XFactor
- See The XFX Difference Quality components, greater durability Solid Capacitors Dust-Free IP-5X Fan XFX Bracket Design Maximize Your Gaming Experience Multi-Monitor & Stereoscopic 3D Up to 3 Displays Independent resolutions & controls 16K x 16K Resolutions Combine multiple Active & Passive 3D Specifications Processor & Bus GPU Clock
- 1000 MHz Chipset version
- ATI Radeon HD 7770 Memory Memory Bus
- 128 bit Memory Clock
- 4.5 GHz Memory Size
- 1 GB Memory Type
- GDDR5 Feature Technologies AMD Eyefinity Technology
- Y AMD HD3D Technology
- Y Other Features AMD
- Cross Fire ready
- Y Display Output Display Port ready
- 1.2 Dual link Support
- Y HDMI Ready
- 1.4a Max Supported Resolution (ANALOG)
- 2048 x 1536 Max Supported Resolution (DIGITAL)
- 2560 x 1600 Output
- Display Port x 1 Output
- SL-DVI-D x 1 Output
- DL-DVI-I x 1 Output
- HDMI x 1 Physical Card Dimension (cm)
- 22.5 x 11.12 x 3.81 Card Dimension (inch)
- 8.8 x 4.4 x 1.5 Card Profile
- Dual Thermal Solution
- Ghost singal Axial fansink Thermal Type
- Dual slot
























...

Based on the award-winning GCN Architecture, AMD Radeon HD 7700 Series GPUs are built to destroy with the industrys very first 28nm GPU design. Packed with incredible features, such as PCI Express 3.0, the ultra-efficient AMD Zero Core Power technology or gaming at resolutions beyond 5760x 1080 with AMD Eyefinity technology, these are the worlds most advanced graphics. For everyone. Double Dissipation Edition XFXs unique dual fan design allows air to cool everything including the thermal, GPU, heatsinks, components & the PCB board. Processor & Bus GPU Clock
- 1000 MHz Chipset version
- ATI Radeon HD 7770 Memory Memory Bus
- 128 bit Memory Clock
- 4.5 GHz Memory Size
- 1 GB Memory Type
- DDR5 Feature Technologies AMD Eyefinity Technology
- Y AMD HD3D Technology
- Y Other Features AMD
- Cross Fire ready
- Y Display Output Display Port ready
- 1.2 Dual link Support
- Y HDMI Ready
- 1.4a Max Supported Resolution (ANALOG)
- 2048 x 1536 Max Supported Resolution (DIGITAL)
- 2560 x 1600 Output
- Display Port x 1 Output
- SL-DVI-D x 1 Output
- DL-DVI-I x 1 Output
- HDMI x 1


















...

Specification
- Chipset version
- ATI Radeon HD 7790 GPU Clock
- 1075 MHz Memory Bus
- 128 bit Memory Clock
- 6.4 GHz




...
