Cisco AIR-ANT5160V-R 6-d Bi omnidirectional antenna is a ruggedized high-performance colinear antenna that operates in the 5-GHz frequency range & is designed for use in large rooms or vaulted areas where extended coverage is needed. The antenna is designed to be used indoors or outdoors & can be mounted on a mast. Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

The AIR-ANT2460P-R is a wall mount, indoor/outdoor directional patch antenna. Designed for use with any radio that features an RP-TNC antenna connector. For use in the 2400-2500 MHz frequency b&. The pigtail cable is plenum rated, 36" long. Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

The AIR-ANT2485P-R is a wall mount indoor/outdoor antenna with a RP-TNC connector-Designed for use with any radio that features a RP-TNC connector. For use in the 2400-2500 MHz frequency b&. The plenum rated pigtail cable is 36" long. Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

Designed For Cisco Aironet 1810 Office Extend Access Point, 1810W ...

Cisco Aironet Power Injector products increase the deployment flexibility of Cisco Aironet wireless access points & bridges by providing an alternative powering option to local power, inline power-capable multiport switches, and multiport power patch panels. The Cisco Aironet Power Injector (AIR-PWRINJ5) increases wireless LAN deployment flexibility of Cisco Aironet Access Points by providing an alternative powering option to local power, inline power-capable multiport switches, & multiport power patch panels. The single-port Cisco Aironet Power Injector provides 802.3af power & data signal, sending both to the Cisco Aironet Access Point. The power injectors provide up to 15.4 W over the unused wire pairs of a Category 5 or better Ethernet cable, supplying enough power for a distance of 328 ft. (100 m) on the Cisco Aironet 1040, 1140, 1260, 2600, & 3500 Series Access Points. While it can also support the Cisco Aironet Series 3600 Access Points when modules are not being used, it is recommended to use the AIR-PWRINJ4= power injector instead for the 3600 series, as it has sufficient power to supply to the AP & any installed modules. Specifications Product Description Cisco Aironet Power Injector
- power injector
- 15.4 Watt Device Type Power injector
- external 802.3af compliant Input Voltage AC 100-240 V Power Capacity 15.4 Watt Output Connector (s) RJ-45

Dimensions (Wx Dx H) 16.5 cm x 6.5 cm x 3.6 cm Designed For Aironet 1602e Controller-based, 1602e Standalone, 1602i Controller-based, 1602i Standalone




...

This antenna was specifically designed for the Cisco Aironet 1250 Series. To support the 2.4-GHz IEEE 802.11n draft 2.0 radio modules with MIMO technology, the 2.4-GHz ceiling omnidirectional antenna was developed. It contains three antenna elements in a single white flush mount enclosure, providing an aesthetically pleasing option for installation in drop-ceiling office environments ...

The Cisco AIR-ANT5135SDW-R is specifically designed for indoor use & works in the 5-GHz frequency range. For use with your Cisco network this omnidirectional antenna provides a reliable & high performance solution.

Features: Omnidirectional Cisco quality & reliability 5 GHz operational frequency Indoor use only Technical Specifications Antenna type: Omnidirectional Operating frequency range: 5150–5850 MHz VSWR: 2:1 or less Peak gain: 3.5 d Bi Polarization: Linear Azimuth plane (3 d B beamwidth): Omnidirectional Elevation plane (3 d B beamwidth): 40° Length: 1.7 in. (4.3 cm) Diameter: 0.75 in. (1.9 cm) Connector: RP-TNC jack Environment: Indoor only Operating temperature: 32° F to 131° F (0° C to 55° C) Manufacturer’s Number: AIR ANT5135SDW-R

...

Every wireless Local Area Network (LAN) deployment is different. When engineering an in-building solution, varying facility sizes, construction materials, & interior divisions raise a host of transmission & multipath considerations. When implementing a building-to-building solution, distance, physical obstructions between facilities, & number of transmission points must be taken into account. Cisco is committed to providing not only the best access points, client adapters, & bridges in the industry-it is also committed to providing a complete solution for any wireless LAN deployment. That's why Cisco has the widest range of antennas, cable, & accessories available from any wireless manufacturer. Cisco offers a complete range of 2.4 GHz antennas for client adapter, access point, & bridge equipment that enable a customized wireless solution for almost any installation. This antenna is intended for use with access points or bridges. ...

100ft. cable with RP-TNC connectors 100ft. cable with RP-TNC connectors LL cable extends the length between any Aironet product & its antenna. With a loss of 6.7 decibels (d B) per 100 feet (30 meters [m]) for LL cable & 4.4 d B for the ULL cable, these cables provide installation flexibility without a significant sacrifice in range or performance. Cisco LL & ULL cables are not plenum rated 100ft. cable with RP-TNC connectors LL cable extends the length between any Aironet product & its antenna. With a loss of 6.7 decibels (d B) per 100 feet (30 meters [m]) for LL cable & 4.4 d B for the ULL cable, these cables provide installation flexibility without a significant sacrifice in range or performance. Cisco LL & ULL cables are not plenum rated 100ft. cable with RP-TNC connectors LL cable extends the length between any Aironet product & its antenna. With a loss of 6.7 decibels (d B) per 100 feet (30 meters [m]) for LL cable & 4.4 d B for the ULL cable, these cables provide installation flexibility without a significant sacrifice in range or performance. Cisco LL & ULL cables are not plenum rated Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

Cisco is the worldwide leader in networking for the Internet. Cisco provides the broadest line of solutions for transporting data, voice & video within buildings, across campuses, or around the world. Cisco solutions ensure that networks both public & private operate with maximum performance, security, & flexibility. A coaxial cable carries radio frequency (RF) energy between the antennas & the radio equipment. An antenna cable introduces signal loss in the antenna system for both the transmitter & receiver. In order to reduce signal loss, minimize the cable length & use only low-loss (LL) antenna cable in order to connect radio devices to antennas. RF coaxial cable = loss of signal strength Loss of signal strength is directly proportionate to the length of the cable segment. As the diameter of the cable increases, signal loss decreases, but at a much higher purchase cost. As signal frequency increases (a higher-numbered channel), loss increases. ...
