Features The SAPPHIRE Pulse Radeon RX560 plays your favorites at a smooth 1080p, from the latest e Sports games & MOBAs to the most popular, graphically-intensive AAA titles. Built on the future-ready Polaris architecture & the card is ready for the latest technologies like Display Port 1.4 HBR3/HDR, HDMI 4K60, & Freesync 2 technology delivering a high level of graphical fidelity in your favorite games & multimedia experience.

Specification GPU 896 Stream Processors 14 CU 14 nm Fin FET 4th Graphics Core Next (GCN) 1226 MHz Engine Clock Memory 128 bit Memory Bus GDDR5 Memory Type 1500 MHz, 6000 MHz Effective 2 GB Size BIOS Support UEFI BIOS Displays Maximum 3 Outputs Output 1 x DVI-D 1 x HDMI 1 x Display Port 1.4 Resolution 5120x 2880 (60 Hz) Pixel Display Port Resolution 2560x 1600 (60 Hz) Pixel Dual Link DVI Resolution 4096x 2160 (60 Hz) HDMI Resolution API Open GL 4.5 Open CL 2.0 Direct X 12 Shader Model 5 Feature AMD Cross Fire Free Sync Technology AMD Eyefinity Direct X™ 12 Optimized HDR Ready Frame Rate Target Control Precision fan control Radeon Relive Cooling Single fan Form Factor 2 Part Slot Occupied 210 (L)X 112 (W)X 36 (H) Dimension /mm Power Consumption 45W OS Windows 10&12288; Windows 7&12288; System Requirement 400 Watt Power Supply (Suggestion) CD-ROM or DVD-ROM drive for installing software

...

Game codes will be emailed out within 5 working days of invoice date Redemption/ Terms & conditions available here One application per customer Features For gamers on a slightly smaller budget, the SAPPHIRE Pulse Radeon RX 570 is the card to pick for smooth 1080p gaming in high details @ 60 FPS. This model is powered by 2048 GCN stream processors that run at a 1284 MHz boost clock. The card is cooled using the quiet Dual-X two-fan solution, with an easy fan swap Quick Connect system in place as well. Overview NITRO Quick Connect SAPPHIRE’s Quick Connect System provides a quick & easy solution. If there’s a fan issue detected, the user doesn’t need to return the entire card – SAPPHIRE’s partners will send out a replacement fan directly to the customer or the retailer. Please contact your place of purchase to request a fan replacement. SAPPHIRE’s channel partner will arrange the ideal solution for you to receive your replacement fan. VR Friendly The SAPPHIRE NITRO Gaming Series cards come with Dual HDMI ports, specifically designed to work with VR. By having two HDMI ports, you can have both an HD monitor & cutting-edge VR headset running at the same time. The ports are HDMI 2.0b, the latest update, with an 18 Gbps bandwidth, up to 32 audio channels, & is able to support 4K 50/60 resolutions like 2160P, whilst remaining entirely backwards compatible with older HDMI specifications. Frame Rate Target Control Frame Rate Target Control (FRTC) enables users to set a target maximum frame rate when playing an application in full screen mode; the benefit being that FRTC can reduce GPU power consumption (great for games running at frame rates much higher than the display refresh rate) & therefore reduce heat generation & fan speeds/noise on the graphics card. Frame Rate Target Control caps performance not only in 3D rendered in-game scenes, but also in splash screens, loading screens & menus, where frame rates can often run needlessly into the hundreds of FPS. Users might wish to set a very high cap just to limit wasteful FPS like that seen in menus & such, while still taking advantage of the responsiveness given by FPS well beyond 60. Direct X 12 Direct X 12 is a new, “console-like” graphics API from Microsoft that empowers game developers with more direct & obvious control of PC hardware. This direct or “explicit” control better exposes the hardware resources of AMD Radeon™ GPUs to yield higher hardware throughput &, ultimately, more performance for users. To put it simply: much more efficient hardware through smarter software! At the discretion of a game developer, this superior efficiency can be spent on higher framerates, lower latency (VR), lower power consumption, better image quality, or some calculated balance of all four. In any scenario, gamers stand to benefit greatly from choosing AMD hardware to run their favorite Direct X 12 game. ...

The SAPPHIRE HD 7750 ULTIMATE is the first card in this generation to use a passive heatpipe & heatsink cooler to deliver totally silent cooling, & increased reliability as it has no mechanical moving parts. It shares all the features of the HD 7700 series & the highly acclaimed GCN graphics processing architecture making it ideal for HTPCs & any general purpose PC where operational noise needs to be kept to a minimum. ...

SAPPHIRE HD 7950 3GB OC with Boost Vapor-X Edition has the latest GDDR5 memory clocked at 5000 M Hz effective, & runs with a core clock speed of 850 MHz which with Power Tune Dynamic Boost rises to 950 MHz on the engine. It has a slightly less sophisticated 8-phase power design & the versatile output configuration of Dual-link DVI-I, DVI-D, HDMI & Display Port. The Vapor-X cooler is based on a new vapor chamber designed especially for this series. Heat is carried away by four heatpipes (2 x 8mm plus 2 x 6mm), & finally dispersed by two 90mm fan with aerofoil blades & dust repelling bearings. The Vapor-X cooler easily handles the heat generated from the HD 7950 even under extreme load conditions. ...

Packed with the latest GPU technologies, the Radeon HD 6450 graphics processor is a next-generation visual upgrade, HDMI 1. 4a for stereoscopic (3D) displays. Displayport 1. 2 as well as 2nd generation support for Direct X 11 for the most versatile solution for everyday computing. ...

SAPPHIRE Technology is now shipping the very first CPU cooler. Designed for the enthusiast & based on the companys award winning Vapor-X technology, the extremely efficient low-noise cooler features dual fans, a rating of 200 watts & a universal mounting for AMD or Intel CPU types. In a similar configuration to its graphics cards, the vapour chamber is in direct contact with the CPU surface to accelerate the flow of heat away. The heat is then carried away by a multi-heatpipe array & cooling fins. Final heat dispersion is achieved by two fans, each with aerofoil section blades designed for efficient airflow with low noise, similar to those used on the highly acclaimed SAPPHIRE Dual-X series of graphics cards. The Vapor-X solution results in a high cooling efficiency designed to cater for 200 Watts, more than enough even for enthusiasts overclocking the latest CPU types. When operating with lower power requirements, fan speeds can be very low, keeping noise levels to a minimum. Vapor-X cooling Technology SAPPHIREs innovative Vapor-X cooling technology allows greater performance for CPU cooler. A Vapor-X product means a virtually silent functioning experience & more headroom to explore performance tweaking! The vapour chamber is in direct contact with the CPU surface to accelerate the flow of heat away, the heat would then carried away by a multi-heatpipe array & cooling fins. Dual- X Technology A highly efficient multi-heatpipe cooler with dual fans that provides quiet & very cool operation during normal operating conditions. With SAPPHIRE Dual-X Technology, final heat dispersion is achieved by two fans, each with aerofoil section blades designed for efficient airflow with low noise. Specifications Intel CPU Support Core i 7 Extreme Core i 7 Core i 5 Core i 3 Core 2 Extreme Core 2 Quad Core 2 Duo Pentium Celeron LGA 2011 LGA 1366 LGA 1155 LGA 1156 LGA 775 AMD CPU Support FX-Series A-Series Phenom II X4 Phenom II X3 Phenom II X2 Phenom X4 Phenom X3 Athlon II X4 Athlon II X3 Athlon II X2 Athlon X2 Athlon Sempron AMD FM1 AMD FM2 AMD AM3 AMD AM3+ AMD AM2 AMD AM2+

Dimensions 135 x 110.4 x 163.5mm (5.3 x 4.3 x 6.4 in) Heat Sink Material Vapor Chamber / 4x 7mm Heatpipes / Aluminum Fins Weight 924.85g (net weight); 1524.8g (gross weight) Heat Pipes

Dimensions ¸7mm, 362mmx 4 Fan Dimension 120 x 120 x 25mm (4.7 x 4.7 x 1 in) Number of Fans 2 per unit Fan Speed 495- 2200 RPM (PWM) Fan Noise Level (d B-A)
- 40 d BA Maximum Maximum Air Flow
- 2 x 77 CFM Maximum Air Pressure
- 2.6 mm H2O ± 10% Bearing Type Sleeve Bearing Connector 4-Pin Fan Rated Voltage 12 VDC Fan Rated Current 0.37A Power Consumption 2 x 4.44 W






...

Now, more people than ever can experience real innovation in Direct X 11 gaming with AMD Radeon™ HD 6750 Graphics. Expand your visual real estate across up to five displays & get lost in the action with AMD Eyefinity multi-display technology. Using AMD App Acceleration, speed up everyday applications & do more than ever with your PC. Loaded with advanced technologies, these GPUs have the power & premium features needed for fully immersive gameplay. Output 1 x Dual-Link DVI 1 x HDMI 1.4a 1 x Display Port GPU 700 MHz Core Clock 40 nm Chip 720 x Stream Processors Memory 1024 MB Size 128 -bit GDDR5 4000 MHz Effective Software Driver CD Accessory DVI to VGA Adapter 6 PIN to 4 PIN Power Cable ...

The SAPPHIRE HD 6770 Vapor-X is based on the latest graphics architecture from AMD, the second generation of GPU to be built in its 40nm process. It supports the advanced graphical features of Direct X 11, & delivers spectacular video clarity, speed & visual effects, including over multiple monitors using AMD Eyefinity. Output 2 x Dual-Link DVI 1 x HDMI 1.4a 1 x Display Port GPU 860 MHz Core Clock 40 nm Chip 800 x Stream Processors Memory 1024 MB Size 128 -bit GDDR5 4800 MHz Effective Software Driver CD Accessory DVI to VGA Adapter 6 PIN to 4 PIN Power Cable ...

The SAPPHIRE R7 250X Vapor-X OC Edition is the first card in this generation to use the SAPPHIRE exclusive implementation of Vapor chamber cooling technology. Previous products with Vapor-X have received world wide acclaim for delivering very efficient cooling that allows the card to run at higher speeds but with very low noise levels. Based on the latest GPU technology from AMD, the SAPPHIRE R7 250X Vapor-X OC Edition has 1GB of the latest DDR5 memory, & is factory overclocked with core clocks of 1100 M Hz & memory clocks of 1300 M Hz (5.2 GB/s effective) to deliver excellent performance.

Specification Display Support 3 x Maximum Display Monitor (s) support Outputs 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU 1100 MHz Core Clock 28 nm Chip 640 x Stream Processors Video Memory 1024 MB Size 128 -bit GDDR5 5200 MHz Effective Dimension 225 (L)x 110 (W)x 43 (H) mm Size 2 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 2X75 Watt 6-pin PCI Express power connector is required for Cross Fire X system 1X75 Watt 6-pin PCI Express power connector is required Certified power supplies are recommended 1024MB Minimum of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive For an AMD Cross Fire X™ system, a second same AMD Radeon™ graphics card, an AMD Cross Fire X™ Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable per graphics card (optional) are required. To support 3 displays, one of the monitors has to support Display Port 450 Watt Power Supply is required

...

Double the amount of displays No software, just plug in & enjoy Work, or game, smarter & faster Expand Your View Break though traditional desktop workspace limitations with the Vid-2X. Sapphire’s Vid-2X is a neat little device that allows two monitors to be connected to a single Display Port or Dual-Link DVI output. Several Vid-2X external graphics adapters can be used to create advanced multiple monitor configurations. Dual Monitors on Laptops & Desktops Multiple monitor capabilities are now standard on all modern desktop systems but what about hardware already deployed or mobile users with laptops & netbooks? In corporate environments desktops may be under lease preventing any internal modifications or upgrades. The Vid-2X is an ideal alternative to docking stations for adding an additional monitor to laptops. Leather Touch A distinguished touch… by Sapphire. The Vid-2X product line offers a unique paint finish with a leather touch. Impress friends & collegues with the contemporary design of Sapphire. Just plug it in! Easy to install, completely external. No need to mess with a system’s internals or even have to install a driver. Simply connect the device to the video graphics port on your existing adapter. Connect the unit to a USB (Universal Serial Bus) port on your system & that’s it! Your operating system will automatically adjust & expose the new multi monitor functionality.

Specification Input Format VESA Display Port v 1.1a 4-lanes with 24 bit Colour Depth Output Format 2 x Single Link (max 1920 x 1200) DVI 2 x HDMI also supported via adapters (not included) Power Requirements Mini USB (Universal Serial Bus) Power DC +5V Display Mode Table @ 50 Hz/60 Hz, 24 bpp Stretch-Mode: 3840x 1200 / 3840x 1080 Display Mode Table @ 60 Hz, 24 bpp Stretch-Mode: 3360x 1050 / 3200x 1200 / 3200x 900 / 2880x 1050 / 2880x 900 / 2732x 768 / 2560x 1024 / 1920x 1200 Stretch/ Clone-Mode:1920x 1080 / 1600x 1200 / 1600x 900 / 1440x 1050 / 1440x 900 / 1366x 768 / 1360x 768 / 1280x 1024 / 1280x 800 /1280x 768 / 1024x 768 / 800x 600 Dimenstions (Wx Hx D): 114 x 32 x 107 mm Weight Net Weight: 210 g Regulatory Approvals CE, FCC, IECS, MCC, WEEE, Ro HS Ambient Operating Tempurature 0 – 55°C (Min/ Max) Storage Temperature -40 to 75°C (Min/ Max) Operating Humidity 20 – 80% relative humidity (Non-Condensing) Storage Humidity 5 to 95% relative humidty (Non-Condensing)

...
