Packed with the latest GPU technologies, the Radeon™ HD 6450 graphics processor is a next-generation visual upgrade that delivers Eyefinity multi-display technology, HDMI 1.4a for stereoscopic (3D) displays as well as 2nd generation support for Direct X 11 for the most versatile solution for everyday computing. Specification: Output: 1 D-Sub (VGA) 1 x Dual-Link DVI 1 x HDMI (with 3D) GPU: 625 MHz Core Clock 40 nm Chip 160 x Stream Processors Video Memory: 2048 MB Size 64 -bit DDR3 1334 MHz Effective Dimension
- 190 (L)x 22 (W)x 94 (H) mm Size. Software
- Driver CD System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. For an AMD Cross Fire X system, a second same AMD Radeon graphics card, an AMD Cross Fire X™ Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable per graphics card (optional) are required. 400 Watt Power Supply is required.

...

Sapphire R5 230 1GB DDR3 VGA DUAL DVI HDMI PCI-E Graphics Card The new SAPPHIRE R5 230 1GB is a low profile PCI-Express graphics cards that require no additional power connector, making it ideal for entry level systems or for upgrading existing PC systems & providing additional monitor support. It has 160 Stream processors & core clocks of 625 M Hz, & offer 1GB DDR3 memory to deliver excellent performance & great value. Outputs are Dual-link DVI, VGA & HDMI, supporting a choice of monitor types & the cards ship with optional backplates for use in standard or low-profile chassis.

Specification Display Support 2 x Maximum Display Monitor (s) support Output 1 x D-Sub (VGA) 1 x HDMI (with 3D) 1 x Dual-Link DVI-D GPU 625 MHz Core Clock 160 x Stream Processors Video Memory 1024 MB Size 64 -bit DDR3 1334 MHz Effective Dimension 146 (L)X94 (W)X22 (H) mm Size. 1 x slot Software Driver CD SAPPHIRE Tri XX Utility System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 400 Watt Power Supply is required.

...

Sapphire R5 230 2GB DDR3 VGA DUAL DVI HDMI PCI-E Graphics Card The new SAPPHIRE R5 230 2GB is a low profile PCI-Express graphics cards that require no additional power connector, making it ideal for entry level systems or for upgrading existing PC systems & providing additional monitor support. It has 160 Stream processors & core clocks of 625 M Hz, & offer 2GB DDR3 memory to deliver excellent performance & great value. Outputs are Dual-link DVI, VGA & HDMI, supporting a choice of monitor types & the cards ship with optional backplates for use in standard or low-profile chassis.

Specification Display Support 2 x Maximum Display Monitor (s) support Output 1 x D-Sub (VGA) 1 x HDMI (with 3D) 1 x Dual-Link DVI-D GPU 625 MHz Core Clock 160 x Stream Processors Video Memory 2048 MB Size 64 -bit DDR3 1334 MHz Effective Dimension 190 (L)X94 (W)X22 (H) mm Size. 1 x slot Software Driver CD SAPPHIRE Tri XX Utility

...

“ Free AMD Radeon Rewards download coupon Bronze from 30th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” Please email gamescoupon@ebuyer.com when you order has been invoiced to claim your download code. Please allow upto 48 hours for a response. Sapphire R7 240 2GB DDR3 Dual DVI HDMI PCI-E Graphics Card The SAPPHIRE R7 240 2GB with Boost now has the latest DDR3 memory clocked at 1800 M Hz effective, & runs with a core clock speed of 730 MHz which with Power Tune Dynamic Boost rises to 780 MHz on the engine. Specification: Display Support 2 x Maximum Display Monitor (s) support Output: D-Sub (VGA) 1 x HDMI (with 3D) 1 x Dual-Link DVI-D GPU: 730 MHz Core Clock 28 nm Chip 320 x Stream Processors Video Memory: 2048 MB Size 128 -bit DDR3 1800 MHz Effective Dimension: 145 (L)X95 (W)X15 (H) mm Size. 2 x slot Software: Driver CD SAPPHIRE Tri XX Utility System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 400 Watt Power Supply is required. ...

The SAPPHIRE R7 240 4GB with Boost now has the latest DDR3 memory clocked at 1800 M Hz effective, & runs with a core clock speed of 730 MHz which with Power Tune Dynamic Boost rises to 780 MHz on the engine. Specifications Display Support 2 x Maximum Display Monitor (s) support Output D-Sub (VGA) 1 x HDMI (with 3D) 1 x Dual-Link DVI-D GPU 730 MHz Core Clock 320 x Stream Processors 28nm Chip Video Memory 4096 MB Size 128 -bit DDR3 1800 MHz Effective

Dimensions 145 (L)X95 (W)X15 (H) mm Size 1 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 1024MBMinimum of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive 400 Watt Power Supply is required

...

Overview Direct X 12 Direct X 12 is a new, “console-like” graphics API from Microsoft that empowers game developers with more direct & obvious control of PC hardware. This direct or “explicit” control better exposes the hardware resources of AMD Radeon™ GPUs to yield higher hardware throughput &, ultimately, more performance for users. To put it simply: much more efficient hardware through smarter software! At the discretion of a game developer, this superior efficiency can be spent on higher framerates, lower latency (VR), lower power consumption, better image quality, or some calculated balance of all four. In any scenario, gamers stand to benefit greatly from choosing AMD hardware to run their favorite Direct X 12 game. AMD Crossfire™ Harness the power of multiple GPUs AMD Cross Fire™ technology is the ultimate multi-GPU performance gaming platform. Unlocking game-dominating power, AMD Cross Fire™ harnesses the power of two or more discrete graphics cards working in parallel to dramatically improve gaming performance.1 AMD Cross Fire™ technology ready graphics cards fit practically every budget. With the flexibility to combine two, three or four GPUs, AMD Cross Fire™ technology is the perfect solution for those who demand extreme performance.

Specification GPU 512 Stream Processors 28 nm Graphics Core Next (GCN) 925 MHz Engine Clock Interface PCI-Express 3.0 Memory 128 bit Memory Bus GDDR3 Memory Type 800 MHz, 1600 MHz Effective 4 GB Size BIOS Support UEFI BIOS Displays Maximum 2 Outputs Output 1 x Dsub 1 x DVI-D 1 x HDMI Resolution 1920x 1200 Pixel Dual Link DVI Resolution 2048x 1536 Pixel D-sub Resolution 4096x 2160 HDMI Resolution API Direct X 12 Feature AMD Cross Fire AMD Power Tune AMD Zero Core Power Technology Cooling Single fan Form Factor 2 Part Slot Occupied 163 (L)X112 (W)X35 (H) Dimension /mm Power Consumption 70W OS Windows 10&12288; Windows 8/8.1&12288; Windows 7&12288; System Requirement CD-ROM or DVD-ROM drive for installing software PCI Express 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with.

...

Eliminate battlefield problems with the help of this Sapphire Radeon RX 460 graphics card. Its ideal for playing some of the most popular titles in glorious 1080p resolutions so that you get all the detail you need with efficient power. The factory-overclocked core produces outstanding performance consistently across the card that you can just get on with enjoying your games, while the 2GB of GDDR5 memory produces solid results even during intense gaming sessions. Power is boosted by the effective cooling, which ensures the card remains at optimal temperatures even under heavy loads. A pair of 95mm fans with precision-engineered blades ensure plenty of air flows through the card, dissipating heat, while the fin & heat pipe designs reduce the thermal stress on the system. Pair this Sapphire Radeon RX 460 graphics card with an identical one to take advantage of AMDs Crossfire technology to sync multiple GPUs for performance.

Specification GPU: AMD Radeon RX 460 Graphics Stream Processors: Up to 896 unit Compute Units: 14 Boost Clock: Up to 1210 MHz Base Clock: 1090 MHz Memory Clock: Up to 1750 MHz, Effective 7000 Mbps Memory Type: 2048MB Bus Interface: PCI-E 3.0 x 8 HDCP support: Yes Firmware: UEFI BIOS External Power: NA Cooling System: Dual slot, Dual Fan Bracket: Full Height DIMENSION: 216 (L)X 111.5 (W)X 38 (H)mm 3 x Maximum Display Monitors support 1 x DP / 1 x HDMI / 1 x DVI-D PRODUCT FEATURES Sapphire Dual-X Cooling Technology Fin FET 14 Technology Microsoft Direct X 12 Support (Direct X12 OPTIMIZED) 4th GCN Architecture (Powered by Polaris Architecture) Vulkan API support Virtual Super Resolution (VSR) AMD Free Sync Technology AMD Eyefinity Open GL 4.5 support Open CL Support XConnect Support HDMI 2.0b / Display Port 1.4 (Display Port 1.2 Certified, Display Port 1.3/1.4 Ready) Dolby True HD & DTS-HD Master Audio TM Support SYSTEM REQUIREMENTS PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. NOTE: Minimum recommended system power supply wattage is based on the specific graphics card & the typical power requirements of other system components. Your system may require more or less power. 400W (or greater) power supply is required. OEM & other pre-assembled PCs may have different power requirements. Minimum 4GB of system memory. Recommended 8GB. Installation software requires a keyboard, a mouse, & a display. DVD playback requires DVD drive & a DVD. A display with digital input (HDMI™ or Display Port) is required. Blu-ray playback requires Blu-ray drive a Supported operating systems include Windows 10, & Windows 7. 64-bit operating system required. Cooling System (Dual-X Cooling) Cooling Fan 90mm x 2 Dual Ball Bearing Cooling Module Aluminum Extrusion Module Board Design Power Design 3 VDDC + 1 VDDCI + 1 MVDD -Rick Teck RT8880 Controller IC -Magna Chip MDU1514 (high side) -MDU1517 (low side) x 2 PCB Layer 4 Layers Product Positioning Faster than GTX 950 in less than 75W Sapphire Boost settings (Default) Engine Clock Boost Clock 1210 MHz / Base Clock 1090 MHz Memory Clock 1750 MHz, 7.0 Gbps Target GPU Temperature 70&8451; Fan Speed Nominal 0~1900 RPM / Maximum 3700 RPM

...

Crush your opponents with the help of this Sapphire NITRO Radeon RX 460 graphics card. As you break bunker after bunker or explore strange worlds, youll see everything in glorious detail whether its in 1080p or 1440p or through a virtual reality headset. A massive 4GB of GDDR5 memory produces outstanding results even when the game has complicated textures & large maps, & the overclocked core processor ensures you can easily brute force your way through graphical complexity. HDR-ready technology delivers lifelike images & graphics with outstanding contrast. In addition, the Virtual Super Resolution feature enables effective 4K & 1440p upscaling so that you can enjoy higher resolutions across your favourite games. Powerful fan technologies & designs deliver effective cooling across the card. In addition, you can seamlessly connect an external GPU to your computer thanks to the AMD XConnect technology on this Sapphire NITRO Radeon RX 460 graphics card.

Specification GPU: AMD Radeon RX 470 Graphics Stream Processors: Up to 896 unit Compute Units: 14 Boost Clock: Up to 1250 MHz Base Clock: 1175 MHz Memory Clock: Up to 1750 MHz, Effective 7000 Mbps Memory Type: 4096MB Bus Interface: PCI-E 3.0 x 8 HDCP support: Yes Firmware: UEFI BIOS External Power: PCIe Graphic External 1 x 6 pin Cooling System: Dual slot, Dual Fan Bracket: Full Height Software: Driver DVD DIMENSION: 221 (L)X 123 (W)X 38 (H)mm 3 x Maximum Display Monitors support DP / HDMI / DVI-D PRODUCT FEATURES Sapphire Dual-X Cooling Technology Fin FET 14 Technology Microsoft Direct X 12 Support (Direct X12 OPTIMIZED) 4th GCN Architecture (Powered by Polaris Architecture) Vulkan™ API support Virtual Super Resolution (VSR) AMD Free Sync Technology AMD Eyefinity Open GL 4.5 support Open CL Support XConnect Support HDMI 2.0b / Display Port 1.4 (Display Port 1.2 Certified, Display Port 1.3/1.4 Ready) Dolby True HD & DTS-HD Master Audio TM Support AMD True Audio Next Technology SYSTEM REQUIREMENTS PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. NOTE: Minimum recommended system power supply wattage is based on the specific graphics card & the typical power requirements of other system components. Your system may require more or less power. 450W (or greater) power supply with minimum one PCIE 6 pin power connector is required. OEM & other pre-assembled PCs may have different power requirements. Minimum 4GB of system memory. Recommended 8GB. Installation software requires a keyboard, a mouse, & a display. DVD playback requires DVD drive & a DVD. A display with digital input (HDMI or Display Port) is required. Blu-ray playback requires Blu-ray drive a Supported operating systems include Windows 10, & Windows 7. 64-bit operating system required. Cooling System (Dual-X Cooling) Cooling Fan 90mm x 2 Dual Ball Bearing Quick Connect Support Cooling Module 6mm Heat-Pipe x 2 Board Design Power Design
- 4 VDDC + 1VDDCI + 1MVDD Onsemi 81022 Controller IC Fairchild D.R integrated Mosfet PCB Layer
- 6 Layers RGB LED Self-color LED External Power Connector
- PCI-Express x 6 pin power connector NITRO Boost settings (Default) Engine Clock
- Boost Clock 1250 MHz / Base Clock 1175 MHz Memory Clock
- 1750 MHz, 7.0 Gbps Target GPU Temperature 75&8451; Fan Speed
- Nominal 0~1900 RPM / Maximum 3500 RPM







...

Sapphire Radeon RX470 4GB GDDR5 HDMI 3x Display Port PCI-E Graphics Card

Specification GPU: AMD Radeon RX 470 Graphics

...

Exert complete control over the battlefield with the help of this Sapphire NITRO+ Radeon RX 470 graphics card. When you enjoy 1080p gaming, you don't want your experience to be anything less than 60 fps, & this card delivers just that. AMD Free sync technology reduces latency, improves flow & enhances the gaming experience & seamlessly eliminates stuttering & tearing. When working at high loads, it can be difficult for a fan to keep up, but NITRO Free Flow technology improves the air recirculation of this graphics card so that hot air is kept away & cool air is drawn into the card to reduce operating temperatures dramatically & efficiently. The two 95mm fans also suck in huge amounts of their thanks to the enhanced blade design, & dual ball bearings improve fan longevity. Effortlessly VR & 1440p gaming are assured with this Sapphire NITRO+ Radeon RX 470 graphics card.

Specification GPU: AMD Radeon RX 470 Graphics Stream Processors: Up to 2048 unit Compute Units: 32 Boost Clock: Up to 1260 MHz Base Clock: 1143 MHz Memory Clock: Up to 1750 MHz, Effective 7000 Mbps Memory Type: 4096MB Bus Interface: PCI-E 3.0 x 16 HDCP support Firmware: Dual UEFI BIOS External Power: PCIe Graphic External 1 x 8 pin Cooling System: Dual slot, Dual Fan Bracket: Full Height Software: Driver DVD 2 x DP / 2 x HDMI / 1 x DVI-D PRODUCT FEATURES Sapphire Dual-X Cooling Technology Fin FET 14 Technology Microsoft Direct X 12 Support (Direct X12 OPTIMIZED) 4th GCN Architecture (Powered by Polaris Architecture) Vulkan API support Virtual Super Resolution (VSR) AMD Free Sync Technology AMD Eyefinity Open GL 4.5 support Open CL Support XConnect Support HDMI 2.0b / Display Port 1.4 (Display Port 1.2 Certified, Display Port 1.3/1.4 Ready) Dolby True HD & DTS-HD Master Audio TM Support AMD True Audio Next Technology SYSTEM REQUIREMENTS PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. NOTE: Minimum recommended system power supply wattage is based on the specific graphics card & the typical power requirements of other system components. Your system may require more or less power. 500W (or greater) power supply with minimum one PCIE 8 pin power connector is required. OEM & other pre-assembled PCs may have different power requirements. Minimum 4GB of system memory. Recommended 8GB. Installation software requires a keyboard, a mouse, & a display. DVD playback requires DVD drive & a DVD. A display with digital input (HDMI or Display Port) is required. Blu-ray playback requires Blu-ray drive a Supported operating systems include Windows 10, & Windows 7 64-bit operating system required. Cooling System (Dual-X Cooling) Cooling Fan 95mm x 2 Dual Ball Bearing Quick Connect Support Cooling Module 8mm Heat-Pipe x 2 + 6mm Heat-Pipe x 1 NITRO Back-Plate
- Yes Board Design Power Design
- 4 VDDC + 1VDDCI + 1MVDD IR3567B Controller IC+ Power Stage integrated Mosfet PCB Layer
- 8 Layers RGB LED External Power Connector
- PCI-Express x 8 pin power connector Product Positioning
- Faster Than RX 480 MBA, 10% Faster than GTX 970 NITRO Boost settings (Default) Engine Clock
- Boost Clock 1260 MHz / Base Clock 1143 MHz Memory Clock
- 1750 MHz, 7.0 Gbps Target GPU Temperature
- 75&8451; Fan Speed
- Nominal 0~2200 RPM / Maximum 3200 RPM Silent Mode Settings Engine Clock
- Boost Clock 1206 MHz / Base Clock 926 MHz Memory Clock
- 1750 MHz, 7.0 Gbps Target GPU Temperature
- 75&8451; Fan Speed
- Nominal 0~1900 RPM / Maximum 3200 RPM














...
