Sapphire VAPOR-X R9 290 4G GDDR5 DUAL DVI HDMI Display Port PCI-E Graphics Card The SAPPHIRE R9 290 Vapor-X Edition features several of the company’s industry-leading technologies. Based on the award-winning Graphics Core Next (GCN) architecture from AMD with 2560 Stream Processors, the SAPPHIRE R9 290 Vapor-X Edition boasts 4GB of the latest GDDR5 memory running at 1400 M Hz (5.6GB/s effective) & high speed engine clocks of 1030 M Hz.

Specification Display Support supports up to 3 display monitor (s) without Display Port 4 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 2 x Dual-Link DVI-D GPU 1030 MHz Core Clock 28 nm Chip 2560 x Stream Processors Video Memory 4096 MB Size 512 -bit GDDR5 5600 MHz Effective Dimension 305 (L)X 114 (W)X 47 (H) mm Size. 2.5 x slot Software Driver CD SAPPHIRE Tri XX Utility System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray™ / HD DVD playback requires Blu-ray / HD DVD drive. 750 Watt Power Supply is required. 2X150 Watt 8-pin PCI Express power connector is required. 64-bit operating system highly recommended

...

SAPPHIRE Technology launches a new top of the range graphics card, the SAPPHIRE R9 290X. Based on the latest Graphics Core Next (GCN) architecture from AMD, the card is being heralded as the ultimate GPU for a new era in PC gaming. The new SAPPHIRE R9 290X delivers breathtaking performance while pushing the boundaries of audio & visual realism for gamers who demand the best. For gamers who demand the very best, AMD Radeon R9 290X graphics shatter ordinary GPU performance. Groundbreaking GCN Architecture pushes your performance to insane levels while AMD True Audio technology & ultra-resolution gaming take you even deeper into the action. Radeon is faster. Radeon is immersive. Radeon is gaming. With Ultra Resolution Gaming you can leave HD in the dust by gaming on displays much, much larger. Whether using a 4k monitor or combining multiple HD monitors, you’ll get an expansive experience that’s truly out of sight. With AMD True Audio technology, you get the most revolutionary, realistic & breathtaking sound we’ve ever put in a GPU10 Mantle gives game developers the power to speak directly to the GPU core. With such a direct connection to your hardware, game developers are discovering a whole new world of immersion & performance made possible by AMD graphics leadership. Specifications Display Support
- Supports up to 3 display monitor (s) without Display Port. 4 x Maximum Display Monitor (s) support Output
- 1 x HDMI (with 3D), 1 x Display Port 1.2, 2 x Dual-Link DVI-D GPU
- Up to 1000 MHz Core Clock, 28 nm Chip, 2816 x Stream Processors Video Memory
- 4096 MB Size, 512bit GDDR5, 5000 MHz Effective

Dimensions
- 277 (L)X104 (W)X35 (H) mm Size, 2 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 1X75 Watt 6-pin PCI Express power connector is required. Certified power supplies are recommended. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 750 Watt Power Supply is required. 1X150 Watt 8-pin PCI Express power connector is required. 64-bit operating system highly recommended Windows Vista, Windows 7 or Windows 8 operating system. 64-bit operating system highly recommended.






...

SAPPHIRE Technology launches a new top of the range graphics card, the SAPPHIRE R9 290X. Based on the latest Graphics Core Next (GCN) architecture from AMD, the card is being heralded as the ultimate GPU for a new era in PC gaming. The new SAPPHIRE R9 290X delivers breathtaking performance while pushing the boundaries of audio & visual realism for gamers who demand the best. For gamers who demand the very best, AMD Radeon R9 290X graphics shatter ordinary GPU performance. Groundbreaking GCN Architecture pushes your performance to insane levels while AMD True Audio technology & ultra-resolution gaming take you even deeper into the action. Radeon is faster. Radeon is immersive. Radeon is gaming. With Ultra Resolution Gaming you can leave HD in the dust by gaming on displays much, much larger. Whether using a 4k monitor or combining multiple HD monitors, you’ll get an expansive experience that’s truly out of sight. With AMD True Audio technology, you get the most revolutionary, realistic & breathtaking sound we’ve ever put in a GPU10 Mantle gives game developers the power to speak directly to the GPU core. With such a direct connection to your hardware, game developers are discovering a whole new world of immersion & performance made possible by AMD graphics leadership. Specifications Display Support
- Supports up to 3 display monitor (s) without Display Port. 4 x Maximum Display Monitor (s) support Output
- 1 x HDMI (with 3D), 1 x Display Port 1.2, 2 x Dual-Link DVI-D GPU
- Up to 1000 MHz Core Clock, 28 nm Chip, 2816 x Stream Processors Video Memory
- 4096 MB Size, 512bit GDDR5, 5000 MHz Effective

Dimensions
- 277 (L)X104 (W)X35 (H) mm Size, 2 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 1X75 Watt 6-pin PCI Express power connector is required. Certified power supplies are recommended. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 750 Watt Power Supply is required. 1X150 Watt 8-pin PCI Express power connector is required. 64-bit operating system highly recommended Windows Vista, Windows 7 or Windows 8 operating system. 64-bit operating system highly recommended.






...

SAPPHIRE R9 290X Tri-X features the latest GCN (graphics core next) architecture from AMD with 2816 stream processing units & an enhanced engine clock of up to 1040 Mhz. It is equipped with 4GB of the latest high performance GDDR5 memory on a 512-bit interface & now clocked at 1300 MHz (5.2 G Hz effective) delivering higher bandwidth than the reference design. Specifications Display Support Supports up to 3 display monitor (s) without Display Port 4 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 2 x Dual-Link DVI-D GPU 28 nm Chip 1040 MHz Core Clock 2816 x Stream Processors Video Memory 4096 MB Size 512 -bit GDDR5 5200 MHz Effective

Dimensions 305 (L)X113 (W)X38 (H) mm Size 2.2 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 1X75 Watt 6-pin PCI Express power connector is required 4096MB Minimum of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray™ / HD DVD playback requires Blu-ray / HD DVD drive 750 Watt Power Supply is required 1X150 Watt 8-pin PCI Express power connector is required 64-bit operating system highly recommended A display with digital input (HDMI, Display Port or DVI) is required

...

Based on the award-winning Graphics Core Next (GCN) architecture from AMD with 2816 Stream Processors, the SAPPHIRE R9 290X Vapor-X boasts 4GB of the latest GDDR5 memory running at 1325 MHz & high speed engine clocks of 1030 M Hz. Together these clocks deliver industry leading performance – but to achieve this performance with stability & reliability demands high quality components throughout the design (especially in the power control circuitry) together with a sophisticated cooling solution. Please be aware that Overclocking or Overvolting this product with procedures other than those embedded in the driver, including the use of SAPPHIRE Tri XX, are carried out at the users own risk & may cause permanent damage or critical component failure. Such damage will not be covered by the normal warranty terms.

Specification Display Support 4 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 2 x Dual-Link DVI-D GPU 1030 MHz Core Clock 2816 x Stream Processors 28 nm Chip Video Memory 4096 MB Size 512 -bit GDDR5 5300 MHz Effective Dimension 305 (L)X 114 (W)X 47 (H) mm Size 2.5 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 4096MB Minimum of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray™ / HD DVD playback requires Blu-ray / HD DVD drive 750 Watt Power Supply is required 2X150 Watt 8-pin PCI Express power connector is required 64-bit operating system highly recommended

...

Additional hardware (e.g. Blu-ray drive, 4K monitor, TV tuner, wirelessly enabled HDTV) and/or software (e.g. multimedia applications) are required for the full enablement of some features. HD Video display requires an HD video source. Not all features maybe supported on all components or systems -check with your component or system manufacturer for specific model capabilities & supported technologies. Testing conducted by AMD Engineering on optimized AMD reference systems. PC manufacturers may vary configurations yielding different results. Far Cry 4 at 3840x 2180, Ultra High preset, SMAA, 0XAF is used to simulate GPU performance; the Radeon™ R9 Nano on the system using the Intel Core™ i 7-5960X 3.0 G Hz processor, 16GB (4x 4GB) DDR4 2666 MHz memory, Windows 10 64-bit, & AMD Catalyst Driver 15.201 scored 37.966 fps while the Radeon™ R9 290X on the same system & AMD Catalyst Driver 15.20 scored 27.207 fps GRDT-69 Based on the product design, the Radeon™ R9 Nano is defined with an operating temperature target of 75°C while the Radeon™ R9 290X is defined with an operating temperature target of 95°C GRDT-75 Based on the product design, the Radeon™ R9 Nano is defined with a typical board power of 175W while the Radeon™ R9 290X is defined with a typical board power of 250W GRDT-76 Based on the product design, the Radeon™ R9 Nano is defined with a fan acoustic target of 42d BA while the Radeon™ R9 290X is defined with a fan acoustic target of 58d BA GRDT-77 Testing conducted by AMD Engineering on optimized AMD reference systems. PC manufacturers may vary configurations yielding different results. Far Cry 4 at 3840x 2180, Ultra High preset, SMAA, 0XAF is used to simulate GPU performance; the Radeon™ R9 Nano on the system using the Intel Core™ i 7-5960X 3.0 G Hz processor, 16GB (4x 4GB) DDR4 2666 MHz memory, Windows 10 64-bit, & AMD Catalyst Driver 15.201 scored 0.2169 fps/watt while the Radeon™ R9 290X on the same system & AMD Catalyst Driver 15.20 scored 0.1088 fps/watt GRDT-72 Testing conducted by AMD Engineering on optimized AMD reference systems. PC manufacturers may vary configurations yielding different results. Far Cry 4 at 3840x 2180, Ultra High preset, SMAA, 0XAF is used to simulate GPU performance; the Radeon™ R9 Nano on the system using the Intel Core™ i 7-5960X 3.0 G Hz processor, 16GB (4x 4GB) DDR4 2666 MHz memory, Windows 10 64-bit, & AMD Catalyst Driver 15.201 scored 0.2498 fps/mm while the Radeon™ R9 290X on the same system & AMD Catalyst Driver 15.20 scored 0.0989 fps/mm GRDT-71 Testing conducted by AMD Engineering on optimized AMD reference systems. PC manufacturers may vary configurations yielding different results. 3 D Mark Fire Strike at 3840x 2180, Ultra preset, 0x MSAA, 0XAF is used to simulate GPU performance; the Radeon™ R9 Nano on the system using the Intel Core™ i 7-5960X 3.0 G Hz processor, 16GB (4x 4GB) DDR4 2666 MHz memory, Windows 10 64-bit, & AMD Catalyst Driver 15.201 scored 3411 while the Sapphire Radeon™ R9 380 Mini ITX on the same system & AMD Catalyst Driver 15.20 scored 1551, the GTX 970 Mini ITX on the same system & Ge Force Driver 355.60 WHQL scored 2593, the GTX 960 Mini ITX on the same system & Ge Force Driver scored 1297 GRDT-73. Testing conducted by AMD Engineering on optimized AMD reference systems. PC manufacturers may vary configurations yielding different results. Far Cry 4 at 3840x 2180, Ultra High preset, SMAA, 0XAF is used to simulate GPU performance; the Radeon™ R9 Nano on the system using the Intel Core™ i 7-5960X 3.0 G Hz processor, 16GB (4x 4GB) DDR4 2666 MHz memory, Windows 10 64-bit, & AMD Catalyst Driver 15.201 scored 37.966 fps while the GTX 970 Mini ITX on the same system & Ge Force Driver 355.60 WHQL scored 27.345 fps GRDT-70 Testing conducted by AMD as of 17 August, 2015 in AMD Performance Labs on the AMD Radeon™ R9 Nano vs. NVIDIA Ge Force GTX 970 Mini ITX at 4K resolution. The games were tested using the following settings: Battlefield 4, 3840x 2160, High, FXAA, 0XAF; Crysis 3, 3840x 2160, High, 0XAA, 0XAF; Far Cry 4, 3840x 2160, High, SMAA, 0XAF; GTA V, 3840x 2160, High, 0XAA, 4XAF; Shadow of Mordor, 3840x 2160, High, 0XAA, 0XAF; Witcher 3, 3840x 2160, High, 0XAA, 0XAF;. System Configuration: test system comprised an Intel Core™i 7-5960X 3.0 G Hz processor, 16GB (4x 4GB) DDR4 2666 MHz memory, Windows 10 64-bit. AMD Catalyst Driver 15.201 & NVIDIA 355.60 WHQL Driver. GRDT-78 Testing conducted by AMD Engineering on optimized AMD reference systems. PC manufacturers may vary configurations yielding different results. Far Cry 4 at 3840x 2180, Ultra High preset, SMAA, 0XAF is used to simulate GPU performance; the Radeon™ R9 Nano on the system using the Intel Core™ i 7-5960X 3.0 G Hz processor, 16GB (4x 4GB) DDR4 2666 MHz memory, Windows 10 64-bit, & AMD Catalyst Driver 15.201 scored 0.22 fps/watt while the Sapphire Radeon™ R9 380 Mini ITX on the same system & AMD Catalyst Driver 15.20 scored 0.08 fps/watt, the GTX 970 Mini ITX on the same system & Ge Force Driver 355.60 WHQL scored 0.12 fps/watt, the GTX 960 Mini ITX on the same system & Ge Force Driver scored 0.13 fps/watt GRDT-74 Discrete AMD Radeon™ GPUs & AMD Fire Pro™ GPUs based on the Graphics Core Next architecture consist of multiple discrete execution engines known as a Compute Unit (“CU”). Each CU contains 64 shaders (“ Stream Processors”) working in unison. GRT-5 Direct X 12 enablement requires an x 86 processor & an AMD Radeon™ graphics chip based on the Graphics Core Next architecture. Windows 10 Technical Preview 2 (or later) & AMD Catalyst™ driver 15.20 (or later) from Windows Update required. GRT-9 AMD Free Sync™ technology is designed to eliminate stuttering and/or tearing in games & videos by locking a displays refresh rate to the framerate of the graphics card. Check with your component or system manufacturer for specific capabilities. AMD Free Sync™ technology compatible monitor, AMD Radeon™ Graphics and/or AMD A-Series APU compliant with Display Port™ Adaptive-Sync required. AMD Catalyst™ 15.2 Beta (or newer) required. Adaptive refresh rates vary by display; check with your monitor manufacturer forspecific capabilities. A list of supported hardware & compatible monitors is available at www.amd.com/freesync. GRT-2 AMDs Virtual Super Resolution (VSR) feature is offered by the AMD Radeon™ R9 Fury X, R9 390 Series, R9 380, R7 370, R7 360, AMD Radeon™ R9 290 Series & R9 285 graphics cards & is designed to automatically re-render games at higher resolutions & dynamically rescale them for HD displays at higher quality & visual details. Check with your system manufacturer for specific capabilities. GRT-8 15. Frame rate targeting is offered by select AMD Radeon™ R9 & R7 300 Series graphics & is designed to reduce heat, noise & powerconsumption by letting users set a target frame rate for their games & applications. Not currently compatible with AMD Cross Fire™ multi-GPU configurations. Confirm supported technologies with your component or system manufacturer for specific capabilities before purchase. GRT-1 ...

The SAPPHIRE Radeon™ Pro Duo. Packing two Fiji XT chips & 8 GB of next-generation HBM memory, it’s the fastest graphics card available on the market. Virtual Reality & 4K gaming are the benchmarks of Radeon™ Pro Duo, but the Pro also stands for superior performance in content creation. Gamers, artists & developers alike will all benefit from the extreme 16 teraflops of raw computational power offered by the very first member of the Radeon™ Pro product family. World’s Fastest Graphics Card FEATURING ASYNCHRONOUS SHADERS 16 TFLOPs of Compute Performance Power 1st Workstation Class Graphics Card WITH HIGH BANDWIDTH MEMORY (HBM) The Fastest Gaming Card Graphics in the World SAPPHIRE have done it again by creating the fastest gaming card in the World. Improving off of the SAPPHIRE Radeon R9 295 X2, the SAPPHIRE Radeon Pro Duo is faster & quieter. The 3rd generation GCN architecture featuring asynchronous shaders enables the latest Direct X™ 12 & Vulkan™ titles to deliver amazing 4K & VR gaming experiences. Powering VR & Game Development The SAPPHIRE Radeon Pro Duo is capable of developing & driving VR experiences at the maximum fidelity level. Create faster with Fire Pro optimizations to maximize productivity without sacrificing gaming performance. Enjoy the benefits of Liquid VR technology to enable rich & immersive VR experiences by simplifying & optimizing VR content creation that works seamlessly with leading headsets. Create & Perform Be more productive by completing tasks faster than ever. With dual GPUs enabled with HBM technology, the SAPPHIRE Radeon Pro Duo has the parallel computing power to speed through Open CL™ supported applications such as Adobe Premiere, Adobe Aftereffects, Da Vinci Resolve & FUSION. Premium Industrial Design Sleeved tubing, soft touch front & back plates, LED logo, matte black PCB & nickel-plated aluminium chassis on the Radeon Pro Duo has been crafted to turn heads. GPU 8192 Stream Processors 28 nm Graphics Core Next (GCN) 1000 MHz Engine Clock Interface PCI-Express 3.0 Memory 4096 bit Memory Bus HBM Memory Type 1000 MHz Effective Memory Clock 8192 MB Size BIOS Support Legacy BIOS UEFI BIOS Displays Maximum 4 Outputs Output 1 x HDMI 3 x Display Port Resolution 4096X2160 Pixel Display Port Resolution 4096x 2160 HDMI Resolution API Open GL 4.5 Open CL 2.0 Direct X 12 Shader Model 5.0 Feature AMD Cross Fire AMD Cross Fire XDMA Free Sync Technology AMD Eyefinity Quad HD Display (4K*2K Support) AMD HD3D Technology Dual BIOS AMD Liquid VR technology AMD Virtual Super Resolution (VSR) AMD True Audio technology Universal Video Decoder (UVD) Cooling Water cooling Form Factor 2 Part Slot Occupied 278 X 130 X 40 Dimension /mm Power Consumption 300W OS Windows 10&12288; Windows 8/8.1&12288; Windows 7&12288; System Requirement 800 Watt Power Supply (Suggestion) 3 x 8-pin AUX Power Connector CD-ROM or DVD-ROM drive for installing software PCI Express 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with. ...

Packed with the latest GPU technologies, the Radeon HD 6450 graphics processor is a next-generation visual upgrade, HDMI 1.4a for stereoscopic (3D) displays, Displayport 1.2 as well as 2nd generation support for Direct X 11 for the most versatile solution for everyday computing. Output 1x D-Sub (VGA) 1 x Dual-Link DVI 1 x HDMI 1.4a GPU 625 MHz Core Clock 40 nm Chip 160 x Stream Processors Memory 1024 MB Size 64 -bit DDR3 1334 MHz Effective Dimension 146 (L)x 22 (W)x 94 (H) mm Size. Software Driver CD System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 400 Watt Power Supply is required. For best cooling performance, a chassis installed with at least one 120mm or 90mm fan is required. ...

Packed with the latest GPU technologies, the Radeon™ HD 6450 graphics processor is a next-generation visual upgrade that delivers Eyefinity multi-display technology, HDMI 1.4a for stereoscopic (3D) displays as well as 2nd generation support for Direct X 11 for the most versatile solution for everyday computing. Specification: Output: 1 D-Sub (VGA) 1 x Dual-Link DVI 1 x HDMI (with 3D) GPU: 625 MHz Core Clock 40 nm Chip 160 x Stream Processors Video Memory: 2048 MB Size 64 -bit DDR3 1334 MHz Effective Dimension
- 190 (L)x 22 (W)x 94 (H) mm Size. Software
- Driver CD System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. Certified power supplies are recommended. Please refer to: http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. For an AMD Cross Fire X system, a second same AMD Radeon graphics card, an AMD Cross Fire X™ Ready motherboard & one AMD Cross Fire X Bridge Interconnect cable per graphics card (optional) are required. 400 Watt Power Supply is required.

...

Sapphire R5 230 1GB DDR3 VGA DUAL DVI HDMI PCI-E Graphics Card The new SAPPHIRE R5 230 1GB is a low profile PCI-Express graphics cards that require no additional power connector, making it ideal for entry level systems or for upgrading existing PC systems & providing additional monitor support. It has 160 Stream processors & core clocks of 625 M Hz, & offer 1GB DDR3 memory to deliver excellent performance & great value. Outputs are Dual-link DVI, VGA & HDMI, supporting a choice of monitor types & the cards ship with optional backplates for use in standard or low-profile chassis.

Specification Display Support 2 x Maximum Display Monitor (s) support Output 1 x D-Sub (VGA) 1 x HDMI (with 3D) 1 x Dual-Link DVI-D GPU 625 MHz Core Clock 160 x Stream Processors Video Memory 1024 MB Size 64 -bit DDR3 1334 MHz Effective Dimension 146 (L)X94 (W)X22 (H) mm Size. 1 x slot Software Driver CD SAPPHIRE Tri XX Utility System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 1024MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 400 Watt Power Supply is required.

...
