Salicru SLC 4000 TWIN RT2 – 4000 VA On-line double-conversion tower/rack Uninterruptible Power Systems (UPS). UPS topology: Double-conversion (Online), Output power capacity: 4000 VA, Output power: 4000 W. AC outlet types: C13 coupler, C19 coupler, Terminal, Power plug: Terminal, AC outlets quantity: 6 AC outlet (s). Battery technology: Lead-Calcium (Pb-Ca), Battery recharge time (90%): 9 h, Charge type: Constant current/ Constant voltage. Form factor: Rackmount/ Tower, Product

Colour: Black, Rack capacity: 4U.

Width: 438 mm,

Depth: 600 mm,

Height: 88 mm Salicru’s SLC TWIN RT2 series models are uninterruptible power supplies with unrivalled electrical protection features for critical server environments. Their dual tower/rack format offers physical adaptability to any site &, together with the built-in PDU strip, provides maximum ease of connection of the loads to be protected. In addition, their unity output power factor (VA=W) increases the power density delivered & reduces the space required for the installation of the UPS. The LCD screen is swivel-mounted according to the mounting format chosen for ease of handling. In terms of serial communications, they feature USB (Universal Serial Bus), RS-232 & relay interfaces, as well as a smart slot to optionally accommodate an SNMP card, MODBUS or potential-free contacts; also available are software packages for local or virtual monitoring & management of the protected devices. For applications that require extended backup, additional battery modules and/or solutions with extra charger can be installed. & for applications that require redundant protection or increase the need for power, there is the option of connecting up to 3 devices in parallel.







...

SALICRU’s SLC TWIN PRO2 series UPS systems feature on-line double conversion technology, currently the most advanced for the protection of critical systems as it provides a fully stabilised & filtered sinusoidal supply voltage. The systems come in a tower format & are available in power ratings of 4, 5, 6, 8, 10, 15 & 20 k VA. The SALICRU SLC TWIN PRO2’s output voltage is always single-phase, featuring a single-phase input of 4 to 20 k VA & a three-phase input of 8 to 20 k VA. All devices with single-phase input provide a unitary output power factor (1), the most optimum for systems & environments with high energy needs. Adaptability is another important feature thanks to the numerous operating modes available: On-line, Batteries, Eco-mode, Bypass, Frequency converter & Parallel redundant. The possibilities of control & monitoring are varied: on the one h&, an LCD display + keypad for local operation of the device, &, on the other, various communication options (USB HID & RS-232 interfaces, & slot for SNMP, RS-485 & AS-400 cards) that enable the UPS to be integrated into standard or virtualised platforms for management, incident notification & remote maintenance. SALICRU’s SLC TWIN PRO2 series is the best option for providing a secure power supply to ERP systems, Business Intelligence, CRM solutions, intranets/extranets & corporate networks in the event of a wide range of possible disturbances (micro power outages, voltage fluctuations, frequency variations, harmonics, transients, etc.), which can cause irreparable damage or incur high costs in all of these critical systems.
- On-line double conversion & DSP control technology
- Output power factor PF=1. (1)
- Compact tower format for space saving
- Active power factor corrector for all input phases
- Multiple operating modes for better adaptability
- Equipped for parallel operation as standard, up to 3 devices
- USB (Universal Serial Bus) & RS-232 interface for all models as standard
- Monitoring software for Windows, Linux, Unix & Mac (downloadable)
- Intelligent slot for SNMP/RS-485/optocoupler cards
- Eco-mode operation for increased efficiency
- Backup extensions available for all power ratings
- Frequency conversion function
- EPO – emergency power off
- Manual and/or automatic programmable battery test
- SLC Greenergy solution














...

Salicru SLC 5000 TWIN RT2 – 5000 VA On-line double-conversion tower/rack Uninterruptible Power Systems (UPS). UPS topology: Double-conversion (Online), Output power capacity: 5000 VA, Output power: 5000 W. AC outlet types: C13 coupler, C19 coupler, Terminal, Power plug: Terminal, AC outlets quantity: 6 AC outlet (s). Battery technology: Lead-Calcium (Pb-Ca), Battery recharge time (90%): 9 h, Charge type: Constant current/ Constant voltage. Form factor: Rackmount/ Tower, Product

Colour: Black, Rack capacity: 4U.

Width: 438 mm,

Depth: 600 mm,

Height: 88 mm Salicru’s SLC TWIN RT2 series models are uninterruptible power supplies with unrivalled electrical protection features for critical server environments. Their dual tower/rack format offers physical adaptability to any site &, together with the built-in PDU strip, provides maximum ease of connection of the loads to be protected. In addition, their unity output power factor (VA=W) increases the power density delivered & reduces the space required for the installation of the UPS. The LCD screen is swivel-mounted according to the mounting format chosen for ease of handling. In terms of serial communications, they feature USB (Universal Serial Bus), RS-232 & relay interfaces, as well as a smart slot to optionally accommodate an SNMP card, MODBUS or potential-free contacts; also available are software packages for local or virtual monitoring & management of the protected devices. For applications that require extended backup, additional battery modules and/or solutions with extra charger can be installed. & for applications that require redundant protection or increase the need for power, there is the option of connecting up to 3 devices in parallel.







...

SALICRUs SLC TWIN PRO series is a UPS range in a tower format equipped with on-line double-conversion technology & the advanced features to make it an excellent protection system for sensitive & critical loads. High output power factor to ensure availability to all types of loads. For facilities that require more back-up time, there is a possibility of backup extensions using UPSs with extra charger & additional battery modules. Also notable is the possibility of Eco-mode operation to improve the efficiency of the device, EPO (emergency power off) functions, operation as a frequency converter & built-in battery test. ...

SALICRUs SLC TWIN PRO2 series is a UPS range in a tower format equipped with on-line double-conversion technology & the latest features to make it an advanced protection system for sensitive & critical loads. High output power factor (PF=0.9) to ensure availability to all types of loads. Full control through status information via LCD display & keypad. & extensive monitoring & communication options via the built-in USB (Universal Serial Bus) HID interface, an intelligent slot for SNMP cards or relays & a wide range of software packages available
- free monitoring version downloadable for Windows, Linux, Unix or Mac & packages available for multi servers or virtualised systems. For facilities that require more back-up time, there is a possibility of backup extensions using UPSs with extra charger & additional battery modules. Also notable is the possibility of Eco-mode operation to improve the efficiency of the device, EPO (emergency power off) functions, operation as a frequency converter & built-in battery test.
...

Salicrus SLC TWIN RT2 UPS range is a continuity solution for the electrical protection of critical systems. It combines double-conversion technology (AC/DC-DC/AC) & boasts a unity output power factor (VA=W) to enable it to power systems with high energy requirements, while offering high operating efficiency. ...

Salicrus SLC TWIN RT2 UPS range is a highly advanced continuity solution for the electrical protection of critical systems. It combines the most reliable double-conversion technology (AC/DC-DC/AC) on the market & boasts a unity output power factor (VA=W) to enable it to power systems with high energy requirements, while offering high operating efficiency. With a range of power ratings from 700 VA (W) to 10, 000 VA (W), it comes in a 2U (up to 3 k VA) or 4U rack format, convertible to tower format, with a swivel mount LCD display, according to the needs of the facility. Also available are solutions with an extra charger & additional battery modules for applications that require greater backup. In terms of communications, it features an RS-232/USB interface (compatible with HID protocol for devices up to 3 k VA) & a smart slot that can optionally hold an SNMP card, MODBUS or potential free contacts; also available are software packages for local or virtual monitoring & management of protected devices. Other outstanding features include: 50/60 or 60/50 Hz frequency converter, emergency stop (EPO), programmable outputs for critical/non-critical loads (up to 3 k VA) & system operation in parallel (up to 3 units for devices from 4 k VA). Features On-line double-conversion technology. Output power factor PF=1. Convertible tower/rack format. Control panel with swivel mount LCD display & keypad.

Includes:: pedestal (pedestal mount) & lugs (rack mount). Backup extensions available for all power ratings. UPS models with extra charger for backup extensions. RS-232 & USB (Universal Serial Bus)-HID communication interfaces. Downloadable monitoring software for Windows, Linux & Mac. Smart slot for SNMP/potential-free contacts/MODBUS. ADSL/fax/modem line protection. Eco-mode operation. Programmable outputs for critical/non-critical loads. Parallelable up to 3 units. PDU strip for distribution of output loads. Frequency conversion function. SLC Greenergy solution. Applications: Continuous protection for critical systems Salicrus SLC TWIN RT2 series offers, in a compact format, all of the necessary features for the protection of applications that require a high level of security in the event of any type of electrical disturbance, such as IT servers, voice & data networks, CAD/ CAM, document management, unified communications (UC) & video streaming.

...

SALICRU’s SLC TWIN RT series is a double conversion On-line UPS with an output power factor of 0.9, which can be turned into tower or rack format & can be set up in parallel. The powers range is from 700 VA to 10 k VA. The rack format is highly compact (with batteries included) & comprises 2U of up to 3 k VA, 3U of 4 to 6 k VA & just 5U for powers of 8 & 10 k VA. It comes with extensive communications options by graphic display, which can be positioned for the tower or rack formats, & incorporates USB (Universal Serial Bus) & RS-232 ports, as well as smart slot for SNMP/relays communication. For applications with broader back-up requirements, there is the option of additional battery modules. Above 4 k VA they include a rear plug-in module for electrical connections & a maintenance bypass to enable work to be done without having to disconnect the loads. Double conversion Online UPS. Output power factor = 0.9. Input current Total Harmonic Distortion (THDi) <5%. Directable LCD display. Convertible between tower & rack. Up to 2 units in parallel. (1)

Includes:: pedestal (tower) (2) & ears (rack). Selectable & priority loads control. (2) Ecomode operation. Serial communication interfaces (RS232) & USB (Universal Serial Bus). Monitoring software for Windows, Unix, Linux & Mac. Smart slot for SNMP/relays. Data/modem line protection. (3) Extended backup available. Automatic frequency detector. Frequency converter function. EPO – Emergency Power Off. Cold Start function for starting from batteries. Self test on every start up and/or manual. SLC Greenergy solution. (1) From 4 k VA (2) Except 10 k VA (3) Up to 3 k VA (included)

...

- On-line double-conversion technology. - Output power factor PF=0.9. - Control panel with LCD screen & keypad. - Backup extensions available for all power ratings. - USB (Universal Serial Bus) HID interface for all models as standard. Slot for SNMP ...

Salicru SLC-4000-TWIN PRO2 – 4000 VA Uninterruptible Power Systems (UPS) On-line double conversion & DSP control. UPS topology: Double-conversion (Online), Output power capacity: 4000 VA, Output power: 4000 W. AC outlet types: C13 coupler, AC outlets quantity: 2 AC outlet (s), Serial interface type: RS-232. Battery technology: Lead-Calcium (Pb-Ca), Battery recharge time: 7 h. Form factor: Tower, Product

Colour: Black, Cooling type: Active.

Width: 250 mm,

Depth: 592 mm,

Height: 576 mm Salicru's SLC TWIN PRO2 series UPS systems feature on-line double conversion technology, currently the most advanced for the protection of critical systems as it provides a fully stabilised & filtered sinusoidal supply voltage. The systems come in a tower format & are available in power ratings of 4, 5, 6, 8, 10, 15 & 20 k VA. The Salicru SLC TWIN PRO2's output voltage is always single-phase, featuring a single-phase input of 4 to 20 k VA & a three-phase input of 8 to 20 k VA. All devices with single-phase input provide a unitary output power factor (1), the most optimum for systems & environments with high energy needs. Adaptability is another important feature thanks to the numerous operating modes available: On-line, Batteries, Eco-mode, Bypass, Frequency converter & Parallel redundant. The possibilities of control & monitoring are varied: on the one h&, an LCD display + keypad for local operation of the device, &, on the other, various communication options (USB HID & RS-232 interfaces, & slot for SNMP, RS-485 & AS-400 cards) that enable the UPS to be integrated into standard or virtualised platforms for management, incident notification & remote maintenance. (1) Except 15 & 20 k VA I / I models







...
