The QSW-M408-2C is equipped with four 10 Gb E SFP+ ports (with two 10 Gb E SFP+/RJ45 combo ports) & eight Gigabit ports. Compatible with 10 Gb E & NBASE-T technologies to support five speeds (10G / 5G / 2.5G / 1G / 100M), the QSW-M408-2C offers higher transmission speeds when used with existing cables. Featuring a user-friendly web UI, the QNAP Switch System (QSS) provides an overview dashboard, port management & setting guide, making central network management intuitive & easy. The QSW-M408-2C provides Layer 2 management features, such as LACP, VLAN, ACL & LLDP for IT administrators to efficiently control the network bandwidth & enhance security. The QSW-M408-2C is one the few web-managed switches that supports Rapid Spanning Tree Protocol (RSTP). You can easily & efficiently deploy small/medium-scale networks that support expansion, redundancy & loop prevention. Compliant with IEEE 802.3az Energy Efficient Ethernet & IEEE802.3x Flow Control in full-duplex mode, the QSW-M408-2C avoids packet loss from unparalleled bandwidth, & reduces power consumption for low-speed & inactive connections. QSS (QNAP Switch System) helps administrators update firmware with just one click, ensuring network security. The QSW-M408-2C is a Layer 2 Web Managed Switch equipped with four 10 Gb E SFP+ ports (with two 10 Gb E SFP+/RJ45 combo ports) & eight Gigabit ports. Supporting Layer 2 switching & network management via user-friendly web user interface, the QSW-M408-2C offers flexible deployment in a hybrid high-speed network infrastructure & an entry-level network management solution for even non-IT professionals. The QSW-M408-2C is compatible with 10 Gb E & NBASE-T technologies that supports up to five speeds (10G / 5G / 2.5G / 1G / 100M) to provide higher transmission speeds with your existing Cat 5e & 6a cables. With its high performance, user-friendly management features & desktop size, the QSW-M408-2C means that you can instantly upgrade to a hybrid high-speed network environment at a cost-effective price, while optimizing network bandwidth & ensuring network maintenance security ...

The QSW-M408-4C is equipped with four 10 Gb E SFP+/ RJ45 combo ports & eight Gigabit ports. Compatible with 10 Gb E & NBASE-T technologies to support five speeds (10G / 5G / 2.5G / 1G / 100M), the QSW-M408-4C offers higher transmission speeds when used with existing cables. Featuring a user-friendly web UI, the QNAP Switch System (QSS) provides an overview dashboard, port management & setting guide, making central network management intuitive & easy. The QSW-M408-4C provides Layer 2 management features, such as LACP, VLAN, ACL & LLDP for IT administrators to efficiently control the network bandwidth & enhance security. The QSW-M408-4C is one the few web-managed switches that supports Rapid Spanning Tree Protocol (RSTP). You can easily & efficiently deploy small/medium-scale networks that support expansion, redundancy & loop prevention. Compliant with IEEE 802.3az Energy Efficient Ethernet & IEEE802.3x Flow Control in full-duplex mode, the QSW-M408-4C avoids packet loss from unparalleled bandwidth, & reduces power consumption for low-speed & inactive connections. QSS (QNAP Switch System) helps administrators update firmware with just one click, ensuring network security. The QSW-M408-4C is a Layer 2 Web Managed Switch equipped with four 10 Gb E SFP+/RJ45 combo ports & eight Gigabit ports. Supporting Layer 2 switching & network management via a user-friendly web user interface, the QSW-M408-4C offers flexible deployment in hybrid high-speed network environments & provides an entry-level network management solution that is usable even by non-IT professionals. The QSW-M408-4C is compatible with 10 Gb E & NBASE-T technologies that supports up to five speeds (10G / 5G / 2.5G / 1G / 100M) to provide higher transmission speeds with existing Cat 5e & 6a cables. With its high performance, user-friendly management features & desktop size, the QSW-M408-4C means that you can instantly upgrade to a hybrid high-speed network environment at a cost-effective price, while optimizing network bandwidth & ensuring network maintenance security. ...

Includes: four 10 Gb E SFP+/ RJ45 combo ports. Compatible with 10 Gb E & NBASE-T technologies to support five speeds (10G
...

The QWA-AC2600 utilizes the 802.11n & 802.11ac standards & offers speeds up to 2533 Mbps to deliver a low-latency, high-speed wireless experience. The QWA-AC2600 supports Dual Band Dual Concurrent (DBDC) for acting as an access point or a base station, adding more possibilities to your investment. The QWA-AC2600 supports 4 x 4 MU-MIMO technology for communicating with multiple clients with multiple signal lanes (spatial streams). The QWA-AC2600 comes with four 5 d Bi detachable omni-directional high-gain antennas. The universal RP-SMA connectors enable antenna replacements for boosting signals & coverage. The QWA-AC2600 features an 80 cm high-frequency coaxial cable for extending the antennas magnetic stand base for flexible deployment & coverage. The QWA-AC2600 has an active cooling module to ensure optimal heat dissipation. The fan will adjust its speed to match the temperature of the module. The QWA-AC2600 is a 2.4/5 GHz Dual Band Dual Concurrent (DBDC), 4 x 4 Multi-user MIMO (MU-MIMO), low-profile PCI Express (PCIe) 2.0 x 1 wireless adapter with two Qualcomm QCA9984 NICs that supports up to 2533 Mbps (800 Mbps for IEEE 802.11n (2.4 GHz) & 1733 Mbps for IEEE 802.11ac (5 GHz)). The QWA-AC2600 can be used as an access point or a base station with Ubuntu/ Linux PCs or QNAP NAS. Combining the higher compatibility of 802.11n & faster connection of 802.11ac, the QWA-AC2600 enables versatile applications including wireless LANs in the workplace & Internet of Things (Io T) deployment in the field. ...

Single-port (10 Gbase-T) 10 Gb E network expansion card, PCIe Gen 3 x 4, Low-profile bracket pre-loaded, Low-profile flat & Full-height are bundled ...

QNAP offers affordable 10 Gb E network expansion cards to assist organizations & individuals in enhancing the bandwidth of their PCs & workstations to accommodate intensive data transfer & virtualization applications. Empowering desktop PCs with lightning-fast 10 Gbps network access is now within reach for all users to effortlessly handle data-intensive tasks & speed up workflows in offices & homes. The 10 Gb E network expansion card delivers speeds of up to 10 Gbps
- 10x faster than standard Gigabit Ethernet
- to greatly boost data transfer performance. Specifications Dual-port, 5-speed 10 Gb E network expansion card Controller: Aquantia AQtion AQC107S; Driver download: From Aquantia (not required for QTS) Connector: NBASE-T (RJ45) PCIe interface: PCIe Gen 2.0 x 4 Transmission rates: 10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps Supported operating systems: QTS; Windows (Driver required); Linux (Driver required) Supported QNAP NAS: Models with PCIe slot (s) (1 free slot required) Bracket: Low-profile bracket pre-installed; full-height & specialized (for selected QNAP NAS) brackets are bundled Port & cable: RJ-45; over CAT-6 class cable Package Content: 1 x Network card; 1 x QIG; 3 x Brackets

...

The dual port QXG-10G2T-X710 is a PCIe Gen 3 (compatible with PCIe Gen 2)10 Gb E network expansion card with an Intel Ethernet Controller X710 & supports up to five speeds (10G / 5G / 2.5G / 1G / 100M). By using Port Trunking, both ports can be combined to achieve up to 20 Gbps transfer speeds for accelerating file sharing & intensive data transfer. With SR-IOV & i SCSI support, the QXG-10G2T-X710 greatly boosts network efficiency & is ideal for I/O-intensive & latency-sensitive virtualization applications & data centers. Build a 10 Gb E network environment The QXG-10G2T-X710 can be used with QNAP's 10 Gb E switches, such as the QSW-M2108-2C or QSW-1208-8C, for you to build a budget-friendly high-speed network environment. Supports SR-IOV & i SCSI, achieve the best virtualization environment The QXG-10G2T-X710 supports SR-IOV, which can allocate bandwidth resources from a physical network card directly to VMs. It ensures reliable VM applications & reduced CPU overheads. The QXG-10G2T-X710 also supports i SCSI, which enables computers, servers, or virtual machines to use storage from your QNAP NAS as virtual disks. You can partition, format, and use these virtual disks exactly like local disks, or even use them for storage expansion or as backup destinations. Supports Windows & Linux servers/workstations Besides QNAP devices, the QXG-10G2T-X710 supports Windows 10, Windows Server, and Linux (driver required), allowing you to attain optimal business performance for a wider range of system applications & services. ...

The QNAP QXG-10G2TB is a PCIe Gen 3 (compatible with PCIe Gen 2) 10 Gb E network expansion card with a Marvell AQtion Controller AQC113C that supports up to five speeds (10 Gb E / 5 Gb E / 2.5 Gb E / 1 Gb E / 100 Mb E). The QXG-10G2TB achieves up to 10 Gbps transfer speeds, accelerating file sharing & intensive data transfer. Highly energy efficient & cost-effective, the QXG-10G2TB provides a high-performance entry-level 10 Gb E solution. ...

QNAP offers various cost-effective network expansion cards for businesses & organizations to upgrade the bandwidth of their QNAP NAS to accommodate intensive data transfer & virtualization applications. 25 Gb E network expansion card Using a Mellanox Connect X-4 Lx Smart NIC controller, the 25 Gb E network expansion card provides significant performance improvements for large file sharing, intensive data transfer, & optimizes VMware virtualization applications with i SER support. Controller: Mellanox Connect X-4 Lx Connector: SFP28 PCIe interface: PCIe Gen 3 x 8 Transmission rates: 25 Gbps/10 Gbps Supported operating systems: QTS; Windows (Driver required); Linux (Driver required) Supported QNAP NAS: Models with PCIe slot (s) (1 free slot required) Bracket: Low-profile bracket pre-installed; full-height & specialized (for selected QNAP NAS) brackets are bundled Port & cable: SFP28 DAC cable (3M) or SFP28 OPTIC transceiver ...

Controller: Intel Ethernet Controller I225-LM Connector: RJ45 PCIe interface: PCIe Gen 2 x 1 Transmission rates: 2.5 Gbps/1 Gbps/100 Mbps/10 Mbps Supported operating systems: QTS 4.4.2 or later (recommend an upgrade to the latest version); Windows 10 (1809 or later); Linux Stable Kernel 4.20/5.x; Windows Server 2019 (Driver required) Supported QNAP NAS: Models with PCIe slot (s) (1 free slot required) Port & cable: RJ-45; over CAT-5 class cable Supported functions: PXE, Wake-On-LAN (Wo L), 9k jumbo frame, 802.1AS-rev/1588, 802.1 Qav/802.1 Qbv, Time Sensitive Networking (TSN), RSS+MSI-X, Teaming & VLAN support, Intel AMT** Package Content: 1 x Network card (Low-profile bracket pre-installed); 1 x QIG; 2 x Brackets (full-height & specialized for QNAP NAS) ...
