ASRock X99M Extreme 4 Socket LGA 2011-3 7.1 CH HD Audio Micro ATX Motherboard Product Specifications General Unique Feature ASRock Super Alloy XXL Aluminum Alloy Heatsink Premium 60A Power Choke Premium Memory Alloy Choke (Reduces 70% core loss compared to iron powder choke) Ultra Dual-N MOSFET (UDM) Nex FET MOSFET Nichicon 12K Platinum Caps (100% Japan made high quality conductive polymer capacitors) Sapphire Black PCB ASRock Ultra M.2 (PCIe Gen 3 x 4 & SATA3) ASRock HDD Saver Technology ASRock Full Spike Protection ASRock Cloud ASRock APP Shop CPU Supports Intel Core i 7 & Xeon 18-Core Processors Family for the LGA 2011-3 Socket Digi Power design 12 Power Phase design Supports Intel Turbo Boost 2.0 Technology Supports Untied Overclocking Technology Chipset
- Intel X99 Memory Quad Channel DDR4 Memory Technology 4 x DDR4 DIMM Slots Supports DDR4 3000+ (OC)*/2933+ (OC)/2800 (OC)/2400 (OC)/2133/1866/1600/1333/1066 non-ECC, un-buffered memory Supports non-ECC RDIMM (Registered DIMM) Supports DDR4 ECC, un-buffered memory/RDIMM with Intel Xeon processors E5 series in the LGA 2011-3 Socket Max. capacity of system memory: 64GB* Supports Intel Extreme Memory Profile (XMP) 2.0 15& Icirc;14; Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. ** Please refer to Memory Support List on ASRock's website for more information. BIOS 2 x 128 Mb AMI UEFI Legal BIOS with multilingual GUI support (1 x Main BIOS & 1 x Backup BIOS) Supports Secure Backup UEFI Technology ACPI 1.1 Compliant wake up events SMBIOS 2.3.1 Support CPU, DRAM, PCH 1.05V, PCH 1.5V, VPPM Voltage Multi-adjustment Audio, Video & Networking Graphics
- n/a Audio 7.1 CH HD Audio with Content Protection (Realtek ALC1150 Audio Codec) Premium Blu-ray Audio support Supports Surge Protection (ASRock Full Spike Protection) Supports Purity Sound„¢ 2 Nichicon Fine Gold Series Audio Caps 115d B SNR DAC with differential amplifier TI NE5532 Premium Headset Amplifier (Supports up to 600 ohm headsets) Direct Drive Technology EMI shielding cover PCB isolate shielding Supports DTS Connect LAN 1 x Intel I218V (Gigabit LAN PHY 10/100/1000 Mb/s) 1 x Qualcomm Atheros AR8171 (PCIE x 1 Gigabit LAN 10/100/1000 Mb/s) Supports Qualcomm Atheros Security Wake On Internet Technology (on Qualcomm Atheros AR8171) Supports Wake-On-LAN Supports Lightning/ESD Protection (ASRock Full Spike Protection) Supports Energy Efficient Ethernet 802.3az Supports PXE Expansion / Connectivity Slots 2 x PCI Express 3.0 x 16 Slots (PCIE1 @ x 16 mode; PCIE2 @ x 16 mode) 1 x PCI Express 2.0 x 16 Slot (PCIE3 @ x 4 mode) Supports AMD Quad Cross Fire X & Cross Fire X Supports NVIDIA Quad SLI & SLI 15& Icirc;14; Gold Contact in VGA PCIe Slot (PCIE1 & PCIE2) * If you install CPU with 28 lanes, PCIE1/PCIE2 will run at x 16/x 8. Storage
- 10 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10 & Intel Rapid Storage 13), NCQ, AHCI, Hot Plug & ASRock HDD Saver Technology 1 x e SATA Connector, supports NCQ, AHCI & Hot Plug 1 x Ultra M.2 Socket, supports M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s) *S_SATA3_3 connector is shared with the e SATA port, S_SATA3_2 connector is shared with Ultra M.2 Socket **RAID is supported on SATA3_0 ~ SATA3_5 ports only. Connector 1 x COM Port Header 1 x TPM Header 1 x Power LED Header 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin) 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin) (Smart Fan Speed Control) 1 x Power Fan Connector (3-pin) 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) 1 x HDD Saver Connector 1 x PCIe Power Connector 1 x Front Panel Audio Connector 1 x Thunderbolt„¢ AIC Connector 2 x USB (Universal Serial Bus) 2.0 Headers (support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x USB (Universal Serial Bus) 3.0 Header (Supports 2 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x Dr. Debug with LED 1 x BIOS Selection Switch Rear Panel I/O 1 x PS/2 Mouse/ Keyboard Port 1 x Optical SPDIF Out Port 1 x e SATA Connector 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) 4 x USB (Universal Serial Bus) 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) 2 x RJ-45 LAN Ports with LED (ACT/LINK LED & SPEED LED) 1 x Clear CMOS Switch HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone Other Features / Miscellaneous Software & UEFI Software ASRock A-Tuning ASRock Disk Health Report ASRock USB (Universal Serial Bus) Key ASRock APP Charger ASRock XFast LAN ASRock XFast RAM ASRock Restart to UEFI UEFI ASRock Full HD UEFI ASRock Instant Flash ASRock Internet Flash ASRock Crashless BIOS ASRock OMG (Online Management Guard) ASRock UEFI System Browser ASRock UEFI Tech Service ASRock Dehumidifier ASRock Easy RAID Installer ASRock Easy Driver Installer Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar, Start 8 (30 days trial), Orbweb.ME Professional (Win 8.1 / 7) Form Factor Micro ATX Form Factor High Density Glass Fabric PCB OS
- Microsoft Windows 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit Certifications FCC, CE, WHQL Er P/ Eu P ready (Er P/ Eu P ready power supply is required)




...

ASRock Z170 Extreme 4 Socket LGA 1151 DVI-D HDMI Display Port 7.1 CH HD Audio ATX Motherboard Specifications General: Unique Feature ASRock USB (Universal Serial Bus) 3.1 ASRock USB (Universal Serial Bus) 3.1 Type-A Port (10 Gb/s) ASRock USB (Universal Serial Bus) 3.1 Type-C Port (10 Gb/s) ASRock Super Alloy XXL Aluminum Alloy Heatsink Combo Caps (Nichicon 12K Platinum Caps) Nichicon 12K Platinum Caps (100% Japan made high quality conductive polymer capacitors) I/O Armor Matte Black PCB High Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen 3 x 4 & SATA3) ASRock Full Spike Protection ASRock Live Update & APP Shop CPU Supports 6th Generation Intel Core i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Digi Power design 10 Power Phase design Supports Intel Turbo Boost 2.0 Technology Supports Intel K-Series unlocked CPUs Supports ASRock BCLK Full-range Overclocking Supports ASRock Hyper BCLK Engine Chipset
- Intel Z170 Memory: Dual Channel DDR4 Memory Technology 4 x DDR4 DIMM Slots Supports DDR4 3866+ (OC)*/3600 (OC)/3200 (OC)/2933 (OC)/2800 (OC)/2400 (OC)/2133 non-ECC, un-buffered memory Max. capacity of system memory: 64GB** Supports Intel Extreme Memory Profile (XMP) 2.0 15μ Gold Contact in DIMM Slots 3866+ (OC) memory frequency can only be achieved when a single memory module is installed (Single channel memory). Please refer to Memory Support List on ASRock's website for more information. Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS: 2 x 128 Mb AMI UEFI Legal BIOS with multilingual GUI support (1 x Main BIOS & 1 x Backup BIOS) Supports Secure Backup UEFI Technology ACPI 5.0 Compliant wake up events SMBIOS 2.7 Support CPU, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCPLL, VCCSA Voltage Multi-adjustment Audio, Video & Networking: Graphics: Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 510/530 Pixel Shader 5.0, Direct X 12 Max. shared memory 1792MB Three graphics output options: DVI-D, HDMI & Display Port 1.2 Supports Triple Monitor Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz Supports Display Port 1.2 with max. resolution up to 4K x 2K (4096x 2304) @ 60 Hz Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) Supports Accelerated Media Codecs: HEVC, VP8, VP9 Supports HDCP with DVI-D, HDMI & Display Port 1.2 Ports Supports Full HD 1080p Blu-ray (BD) playback with DVI-D, HDMI & Display Port 1.2 Ports Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Intel In Tru 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio: 7.1 CH HD Audio with Content Protection (Realtek ALC1150 Audio Codec) Premium Blu-ray Audio support Supports Surge Protection (ASRock Full Spike Protection) Supports Purity Sound 3 Nichicon Fine Gold Series Audio Caps 115d B SNR DAC with differential amplifier TI NE5532 Premium Headset Amplifier (Supports up to 600 ohm headsets) Pure Power-In Direct Drive Technology PCB isolate shielding Supports DTS Connect LAN Gigabit LAN 10/100/1000 Mb/s Giga PHY Intel I219V Supports Wake-On-LAN Supports Lightning/ESD Protection (ASRock Full Spike Protection) Supports Energy Efficient Ethernet 802.3az Supports PXE Expansion / Connectivity: Slots 3 x PCI Express 3.0 x 16 Slots (PCIE2/PCIE4/PCIE6: single at x 16 (PCIE2); dual at x 8 (PCIE2) / x 8 (PCIE4); triple at x 8 (PCIE2) / x 8 (PCIE4) / x 4 (PCIE6))* 3 x PCI Express 3.0 x 1 Slots (Flexible PCIe) Supports AMD Quad Cross Fire X, 3-Way Cross Fire X & Cross Fire X Supports NVIDIA Quad SLI & SLI 15μ Gold Contact in VGA PCIe Slot (PCIE2) Supports NVMe SSD as boot disks Storage: 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 14 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug 3 x SATA Express 10 Gb/s Connectors* 1 x Ultra M.2 Socket, supports type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** Support to be announced M2_1, SATA3_0, SATA3_1 & SATA_EXP_0 share lanes. If either one of them is in use, the others will be disabled. Supports ASRock U.2 Kit Supports NVMe SSD as boot disks Connector: 1 x COM Port Header 1 x TPM Header 1 x Power LED & Speaker Header 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control) 3 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control) 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) 1 x Front Panel Audio Connector 1 x Thunderbolt AIC Connector 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x USB (Universal Serial Bus) 3.0 Header (Supports 2 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x Dr. Debug with LED 1 x Power Switch with LED 1 x Reset Switch with LED Rear Panel I/O: 1 x PS/2 Mouse/ Keyboard Port 1 x DVI-D Port 1 x HDMI Port 1 x Display Port 1.2 1 x Optical SPDIF Out Port 1 x USB (Universal Serial Bus) 3.1 Type-A Port (10 Gb/s) (ASMedia ASM1142) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x USB (Universal Serial Bus) 3.1 Type-C Port (10 Gb/s) (ASMedia ASM1142) (Supports ESD Protection (ASRock Full Spike Protection)) 6 x USB (Universal Serial Bus) 3.0 Ports (Intel Z170) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED) 1 x Clear CMOS Switch HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone Other Features / Miscellaneous: Software & BIOS Software ASRock A-Tuning ASRock Disk Health Report ASRock USB (Universal Serial Bus) Key ASRock APP Charger ASRock XFast LAN ASRock XFast RAM ASRock Fast Boot (Fast Boot, Restart to UEFI)* UEFI ASRock EZ Mode ASRock Full HD UEFI ASRock My Favorites in UEFI ASRock Instant Flash ASRock Internet Flash ASRock Crashless BIOS ASRock OMG (Online Management Guard) ASRock UEFI System Browser ASRock UEFI Tech Service ASRock Dehumidifier ASRock Easy RAID Installer ASRock Easy Driver Installer These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Hardware Monitor: CPU/ Chassis temperature sensing CPU/ Chassis Fan Tachometer CPU/ Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature) CPU/ Chassis Fan multi-speed control Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCSA Form Factor
- ATX Form Factor OS
- Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit* To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRock's website for details. Certifications: FCC, CE, WHQL Er P/ Eu P ready (Er P/ Eu P ready power supply is required)



...

ASRock Z170 Pro 4 Socket LGA 1151 DVI-D HDMI 7.1 CH HD Audio ATX Motherboard Specifications General: Unique Feature ASRock Super Alloy Nichicon 12K Platinum Caps (100% Japan made high quality conductive polymer capacitors) I/O Armor High Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen 3 x 4 & SATA3) ASRock Full Spike Protection ASRock Live Update & APP Shop CPU: Supports 6th Generation Intel Core i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Digi Power design 10 Power Phase design Supports Intel Turbo Boost 2.0 Technology Supports Intel K-Series unlocked CPUs Supports ASRock BCLK Full-range Overclocking Chipset
- Intel Z170 Memory: Dual Channel DDR4 Memory Technology 4 x DDR4 DIMM Slots Supports DDR4 3866+ (OC)*/3600 (OC)/3200 (OC)/2933 (OC)/2800 (OC)/2400 (OC)/2133 non-ECC, un-buffered memory Max. capacity of system memory: 64GB** Supports Intel Extreme Memory Profile (XMP) 2.0 3866+ (OC) memory frequency can only be achieved when a single memory module is installed (Single channel memory). Please refer to Memory Support List on ASRock's website for more information. Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS: 128 Mb AMI UEFI Legal BIOS with multilingual GUI support ACPI 5.0 Compliant wake up events SMBIOS 2.7 Support CPU, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCPLL, VCCSA Voltage Multi-adjustment Audio, Video & Networking: Graphics Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 510/530 Pixel Shader 5.0, Direct X 12 Max. shared memory 1792MB Dual graphics output: Support DVI-D & HDMI ports by independent display controllers Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) Supports Accelerated Media Codecs: HEVC, VP8, VP9 Supports HDCP with DVI-D & HDMI Ports Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Intel In Tru 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio: 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec) Premium Blu-ray Audio support Supports Surge Protection (ASRock Full Spike Protection) ELNA Audio Caps LAN: Gigabit LAN 10/100/1000 Mb/s Giga PHY Intel I219V Supports Wake-On-LAN Supports Lightning/ESD Protection (ASRock Full Spike Protection) Supports Energy Efficient Ethernet 802.3az Supports PXE Expansion / Connectivity: Slots 2 x PCI Express 3.0 x 16 Slots (PCIE2: x 16 mode; PCIE4: x 4 mode)* 3 x PCI Express 3.0 x 1 Slots (Flexible PCIe) Supports AMD Quad Cross Fire X & Cross Fire X Supports NVMe SSD as boot disks Storage: 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 14 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug 2 x SATA Express 10 Gb/s Connectors* 1 x Ultra M.2 Socket, supports type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** Support to be announced If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 & SATA3_1 will be disabled. Supports ASRock U.2 Kit Supports NVMe SSD as boot disks Connector: 1 x COM Port Header 1 x Chassis Intrusion Header 1 x TPM Header 1 x Power LED & Speaker Header 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control) 3 x Chassis Fan Connectors (2 x 4-pin, 1 x 3-pin) (Smart Fan Speed Control) 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector 1 x PCIe Power Connector 1 x Front Panel Audio Connector 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x USB (Universal Serial Bus) 3.0 Header (Supports 2 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) Rear Panel I/O: 1 x PS/2 Mouse/ Keyboard Port 1 x DVI-D Port 1 x HDMI Port 6 x USB (Universal Serial Bus) 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED) HD Audio Jacks: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone Other Features / Miscellaneous Software & BIOS: Software ASRock A-Tuning ASRock Disk Health Report ASRock USB (Universal Serial Bus) Key ASRock APP Charger ASRock XFast LAN ASRock XFast RAM ASRock Fast Boot (Fast Boot, Restart to UEFI)* UEFI ASRock EZ Mode ASRock Full HD UEFI ASRock My Favorites in UEFI ASRock Instant Flash ASRock Internet Flash ASRock Crashless BIOS ASRock OMG (Online Management Guard) ASRock UEFI System Browser ASRock UEFI Tech Service ASRock Dehumidifier ASRock Easy RAID Installer ASRock Easy Driver Installer These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Hardware Monitor: CPU/ Chassis temperature sensing CPU/ Chassis Fan Tachometer CPU/ Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature) CPU/ Chassis Fan multi-speed control CASE OPEN detection Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCSA Form Factor - ATX Form Factor OS - Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit* To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRock's website for details. Certifications:
- FCC, CE, WHQL
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)



...

Supports 6th Generation Intel Core™ Processors (Socket 1151) Digi Power, 10 Power Phase Design Supports DDR4 3866+ (OC) memory modules 2 PCIe 3.0 x 16, 3 PCIe 3.0 x 1 AMD Quad Cross Fire X™, Cross Fire X™ Graphics Output Options: DVI-D, HDMI 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps 2 SATA Express, 6 SATA3, 1 Ultra M.2 (PCIe Gen 3 x 4 & SATA3) 8 USB (Universal Serial Bus) 3.0 (2 Front, 6 Rear) Supports Full Spike Protection, ASRock Live Update & APP Shop Unique Feature ASRock Super Alloy High Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen 3 x 4 & SATA3) ASRock Full Spike Protection ASRock Live Update & APP Shop CPU Supports 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Digi Power design 10 Power Phase design Supports Intel Turbo Boost 2.0 Technology Supports Intel K-Series unlocked CPUs Supports ASRock BCLK Full-range Overclocking Chipset Intel Z170 Memory Dual Channel DDR4 Memory Technology 4 x DDR4 DIMM Slots Supports DDR4 3866+ (OC)*/3600 (OC)/3200 (OC)/2933 (OC)/2800 (OC)/2400 (OC)/2133 non-ECC, un-buffered memory Max. capacity of system memory: 64GB** Supports Intel Extreme Memory Profile (XMP) 2.0 *3866+ (OC) memory frequency can only be achieved when a single memory module is installed (Single channel memory). Please refer to Memory Support List on ASRock's website for more information. ** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS 128 Mb AMI UEFI Legal BIOS with multilingual GUI support ACPI 5.0 Compliant wake up events SMBIOS 2.7 Support CPU, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCPLL, VCCSA Voltage Multi-adjustment Graphics Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel HD Graphics 510/530 Pixel Shader 5.0, Direct X 12 Max. shared memory 1792MB Dual graphics output: Support DVI-D & HDMI ports by independent display controllers Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) Supports Accelerated Media Codecs: HEVC, VP8, VP9 Supports HDCP with DVI-D & HDMI Ports Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports * Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. *** Intel In Tru™ 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)* Premium Blu-ray Audio support Supports Surge Protection (ASRock Full Spike Protection) ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN Gigabit LAN 10/100/1000 Mb/s Giga PHY Intel I219V Supports Wake-On-LAN Supports Lightning/ESD Protection (ASRock Full Spike Protection) Supports Energy Efficient Ethernet 802.3az Supports PXE Slots 2 x PCI Express 3.0 x 16 Slots (PCIE2: x 16 mode; PCIE4: x 4 mode)* 3 x PCI Express 3.0 x 1 Slots (Flexible PCIe) Supports AMD Quad Cross Fire X™ & Cross Fire X™ * Supports NVMe SSD as boot disks Storage 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 14 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug 2 x SATA Express 10 Gb/s Connectors* 1 x Ultra M.2 Socket, supports type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** * Support to be announced If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 & SATA3_1 will be disabled. ** Supports ASRock U.2 Kit Supports NVMe SSD as boot disks Connector 1 x COM Port Header 1 x Chassis Intrusion Header 1 x TPM Header 1 x Power LED & Speaker Header 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control) 3 x Chassis Fan Connectors (2 x 4-pin, 1 x 3-pin) (Smart Fan Speed Control) 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector 1 x PCIe Power Connector 1 x Front Panel Audio Connector 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x USB (Universal Serial Bus) 3.0 Header (Supports 2 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) Rear Panel I/O 1 x PS/2 Mouse/ Keyboard Port 1 x DVI-D Port 1 x HDMI Port 6 x USB (Universal Serial Bus) 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED) HD Audio Jacks: Line in / Front Speaker / Microphone Software ASRock A-Tuning ASRock Disk Health Report ASRock USB (Universal Serial Bus) Key ASRock APP Charger ASRock XFast LAN ASRock XFast RAM ASRock Fast Boot (Fast Boot, Restart to UEFI)* UEFI ASRock EZ Mode ASRock Full HD UEFI ASRock My Favorites in UEFI ASRock Instant Flash ASRock Internet Flash ASRock Crashless BIOS ASRock OMG (Online Management Guard) ASRock UEFI System Browser ASRock UEFI Tech Service ASRock Easy RAID Installer ASRock Easy Driver Installer * These utilities can be downloaded from ASRock Live Update & APP Shop. Hardware Monitor CPU/ Chassis temperature sensing CPU/ Chassis Fan Tachometer CPU/ Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature) CPU/ Chassis Fan multi-speed control CASE OPEN detection Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCSA Form Factor ATX Form Factor Solid Capacitor design OS Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit* * To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRock's website for details. ...

ASRock Z170M Pro 4S Socket 1151 DVI-D HDMI 7.1 Channel HD Audio Micro ATX Motherboard Specifications General Unique Feature ASRock Super Alloy High Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen 3 x 4 & SATA3) ASRock Full Spike Protection ASRock Live Update & APP Shop CPU Supports 6th Generation Intel Core i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Digi Power design 6 Power Phase design Supports Intel Turbo Boost 2.0 Technology Supports Intel K-Series unlocked CPUs Supports ASRock BCLK Full-range Overclocking Chipset Intel Z170 Memory Dual Channel DDR4 Memory Technology 4 x DDR4 DIMM Slots Supports DDR4 3466+ (OC)*/3200 (OC)/2933 (OC)/2800 (OC)/2400 (OC)/2133 non-ECC, un-buffered memory Supports ECC UDIMM memory modules (operate in non-ECC mode) Max. capacity of system memory: 64GB** Supports Intel Extreme Memory Profile (XMP) 2.0 *3466+ (OC) memory frequency can only be achieved when a single memory module is installed (Single channel memory). Please refer to Memory Support List on ASRock's website for more information. ** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS 128 Mb AMI UEFI Legal BIOS with multilingual GUI support ACPI 5.0 Compliant wake up events SMBIOS 2.7 Support DRAM, VCCIO, VCCSA Voltage Multi-adjustment Audio, Video & Networking Graphics Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 510/530 Pixel Shader 5.0, Direct X 12 Max. shared memory 1024MB* Dual graphics output: Support DVI-D & HDMI ports by independent display controllers Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) Supports Accelerated Media Codecs: HEVC, VP8, VP9 Supports HDCP with DVI-D & HDMI Ports Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports * The size of maximum shared memory may vary from different operating systems. ** Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. *** Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. **** Intel In Tru 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)* Premium Blu-ray Audio support Supports Surge Protection (ASRock Full Spike Protection) ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN Gigabit LAN 10/100/1000 Mb/s Giga PHY Intel I219V Supports Wake-On-LAN Supports Lightning/ESD Protection (ASRock Full Spike Protection) Supports Energy Efficient Ethernet 802.3az Supports PXE Expansion / Connectivity Slots 2 x PCI Express 3.0 x 16 Slots (PCIE1: x 16 mode; PCIE4: x 4 mode)* 2 x PCI Express 3.0 x 1 Slots (Flexible PCIe) Supports AMD Quad Cross Fire X & Cross Fire X™ * Supports NVMe SSD as boot disks Storage 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 14 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug* 1 x Ultra M.2 Socket, supports type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 & SATA3_1 will be disabled. ** Supports ASRock U.2 Kit Supports NVMe SSD as boot disks Connector 1 x COM Port Header 1 x TPM Header 1 x Chassis Intrusion & Speaker Header 1 x CPU Fan Connector (4-pin) (Smart Fan Speed Control) 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)* 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector 1 x Front Panel Audio Connector 1 x USB (Universal Serial Bus) 2.0 Header (Supports 2 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) 1 x USB (Universal Serial Bus) 3.0 Header (Supports 2 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) * All CPU/ Chassis Fan Connectors can auto detect if 3-pin or 4-pin fan is in use. The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. Rear Panel I/O 1 x PS/2 Mouse/ Keyboard Port 1 x DVI-D Port 1 x HDMI Port 6 x USB (Universal Serial Bus) 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED) HD Audio Jacks: Line in / Front Speaker / Microphone Other Features / Miscellaneous Software & BIOS Software ASRock A-Tuning ASRock Disk Health Report ASRock USB (Universal Serial Bus) Key ASRock APP Charger ASRock XFast LAN ASRock XFast RAM ASRock Fast Boot (Fast Boot, Restart to UEFI)* UEFI ASRock EZ Mode ASRock Full HD UEFI ASRock My Favorites in UEFI ASRock Instant Flash ASRock Internet Flash ASRock Crashless BIOS ASRock OMG (Online Management Guard) ASRock UEFI System Browser ASRock UEFI Tech Service ASRock Easy RAID Installer ASRock Easy Driver Installer * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD - Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Hardware Monitor CPU/ Chassis temperature sensing CPU/ Chassis Fan Tachometer CPU/ Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature) CPU/ Chassis Fan multi-speed control CASE OPEN detection Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCSA Form Factor Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm Solid Capacitor design OS Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit* * To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please see our online tutorial or check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRock's website for details. Certifications FCC, CE, WHQL Er P/ Eu P ready (Er P/ Eu P ready power supply is required) ...

ASRock Super Alloy Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Supports DDR4 3733+ (OC) 2 PCIe 3.0 x 16, 3 PCIe 3.0 x 1, 1 PCI, 1 M.2 Socket (Key E) AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub Supports Triple Monitor 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps 6 SATA3, 2 Ultra M.2 (PCIe Gen 3 x 4 & SATA3) 8 USB (Universal Serial Bus) 3.0 (1 Type-C, 2 Front, 5 Rear) Specifications Unique Feature ASRock Super Alloy
- XXL Aluminum Alloy Heatsink
- Premium 40A Power Choke
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology ASRock Ultra M.2 (PCIe Gen 3 x 4 & SATA3) ASRock Full Spike Protection ASRock Live Update & APP Shop CPU
- Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151)
- Digi Power design
- 8 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology
- Supports Intel K-Series unlocked CPUs
- Supports ASRock BCLK Full-range Overclocking Chipset
- Intel Z270 Memory
- Dual Channel DDR4 Memory Technology
- 4 x DDR4 DIMM Slots
- Supports DDR4 3733+ (OC)*/3600 (OC)/3200 (OC)/2933 (OC)/2800 (OC)/2400**/2133 non-ECC, un-buffered memory
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Max. capacity of system memory: 64GB***
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Please refer to Memory Support List on ASRock's website for more information. **7th Gen Intel CPU supports DDR4 up to 2400; 6th Gen Intel CPU supports DDR4 up to 2133. *** Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, GT_CPU, DRAM, VPP, PCH 1.0V, VCCIO, VCCST, VCCSA, VCCPLL Voltage Multi-adjustment Graphics
- Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel HD Graphics
- Gen 9 LP, DX11.3, DX12
- HWAEncode/ Decode: VP8, HEVC 8b, VP9, HEVC 10b (For 7th Gen Intel CPU)
- HWA Encode/ Decode: VP8, HEVC 8b; GPU/SWEncode/ Decode: VP9, HEVC 10b (For 6th Gen Intel CPU)
- Max. shared memory 1024MB**
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports Full HD 1080p Blu-ray (BD) playback with DVI-D & HDMI Ports * Intel HD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** The size of maximum shared memory may vary from different operating systems. *** Due to chipset limitation, the Blu-ray playback of Intel HD Graphics is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. **** Intel In Tru™ 3D is only supported under Windows 8 / 8 64-bit / 7 / 7 64-bit. Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)*
- Premium Blu-ray Audio support
- Supports Surge Protection (ASRock Full Spike Protection)
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection (ASRock Full Spike Protection)
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 2 x PCI Express 3.0 x 16 Slots (PCIE2: x 16 mode; PCIE4: x 4 mode)*
- 3 x PCI Express 3.0 x 1 Slots (Flexible PCIe)
- 1 x PCI Slot
- Supports AMD Quad Cross Fire X™ & Cross Fire X™
- 1 x M.2 Socket (Key E), supports type 2230 Wi Fi/BT module * Supports NVMe SSD as boot disks If PCIE5 slot or PCI slot is occupied, PCIE4 slot will run at x 2 mode. Storage
- 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug*
- 1 x Ultra M.2 Socket (M2_1), supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)**
- 1 x Ultra M.2 Socket (M2_2), supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)* * If M2_1 is occupied by a SATA-type M.2 device, SATA3_5 will be disabled. If M2_2 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled. ** Supports Intel Optane™ Technology Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Chassis Intrusion Header
- 1 x Power LED & Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)
- 1 x Chassis Optional/ Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x Thunderbolt™ AIC Connector (5-pin)
- 1 x Thunderbolt™ AIC Connector (10-pin)**
- 3 x USB (Universal Serial Bus) 2.0 Headers (Support 5 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.0 Header (Supports 2 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis Optional/ Water Pump Fan supports the water cooler fan of maximum 1.5A (18W) fan power. CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use. *** Only one Thunderbolt™ AIC Card is supported. Rear Panel I/O
- 2 x Antenna Ports
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 5 x USB (Universal Serial Bus) 3.0 Type-A Ports (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.0 Type-C Port (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock APP Charger
- ASRock XFast LAN* UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash
- ASRock Crashless BIOS
- ASRock UEFI System Browser
- ASRock UEFI Tech Service
- ASRock Easy RAID Installer * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 3 x Screws for M.2 Sockets Hardware Monitor
- Temperature Sensing: CPU, Chassis, Chassis Optional/ Water Pump Fans
- Fan Tachometer: CPU, Chassis, Chassis Optional/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis, Chassis Optional/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis, Chassis Optional/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPP, PCH 1.0V, VCCIO, VCCSA, VCCST Form Factor
- ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit (For 7th Gen Intel CPU)
- Microsoft Windows 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit (For 6th Gen Intel CPU)* * To install Windows 7 OS, a modified installation disk with x HCI drivers packed into the ISO file is required. Please check our User Manual for more detailed instructions. For the updated Windows 10 driver, please visit ASRock's website for details. Certifications
- FCC, CE, WHQL
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)







































































































...

Key Features ASRock Super Alloy Supports 7th & 6th Generation Intel Core TM i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Supports DDR4 3733+ (OC) 4 PCIe 3.0 x 16, 1 PCIe 3.0 x 1 AMD Quad Cross Fire XTM Nvidia Quad SLI Support Graphics Output Options: HDMI, Display Port Supports Triple Monitor 7.1 CH HD Audio (Realtek ALC1220 Audio Codec) 10 SATA3, 3 x Ultra M.2 Sockets, support type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)*** 9 USB (Universal Serial Bus) 3.0 (4 Rear, 1 Type-C, 4 Front) Specification: CPU
- Supports 7th & 6th Generation Intel Core TM i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151)
- Digi Power design
- 12 Power Phase design Chipset Intel Z270 Chipset Memory
- Dual Channel DDR4 Memory Technology
- 4 x DDR4 DIMM Slots
- Supports DDR4 3733+ (OC)*/3600 (OC)/3200 (OC)/2933 (OC)/2800 (OC)/2400**/2133 non-ECC, un-buffered memory Onboard Graphics Outputs
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz
- Supports Display Port 1.2 with max. resolution up to 4K x 2K (4096x 2304) @ 60 Hz Maximum shared memory of 1024MB Multi-GPU Support Supports Nvidia SLI & AMD Cross Fire X™ Technology PCI Slots
- 4 x PCI Express 3.0 x 16 Slots (PCIE1: x 16 mode; PCIE4: x 4 mode)* * Supports NVMe SSD as boot disks
- 1 x PCI Express 3.0 x 1 Slots (Flexible PCIe) Storage
- 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug* * M2_1, SATA3_0 & SATA3_1 share lanes. If either one of them is in use, the others will be disabled. * M2_2, SATA3_4 & SATA3_5 share lanes. If either one of them is in use, the others will be disabled. * If M2_3 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled.
- 4 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, support NCQ, AHCI & Hot Plug
- 2 x SATA Express 10 Gb/s Connectors** ** Support to be announced
- 3 x Ultra M.2 Sockets, support type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)*** *** Supports Intel Optane TM Technology *** Supports NVMe SSD as boot disks *** Supports ASRock U.2 Kit USB (Universal Serial Bus) Rear Panel:
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x HDMI Port
- 1 x Display Port 1.2
- 1 x Optical SPDIF Out Port
- 1 x USB (Universal Serial Bus) 3.1 Type-A Port (10 Gb/s) (ASMedia ASM2142) (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.1 Type-C Port (10 Gb/s) (ASMedia ASM2142) (Supports ESD Protection (ASRock Full Spike Protection))
- 4 x USB (Universal Serial Bus) 3.0 Ports (Intel Z270) (Supports ESD Protection (ASRock Full Spike Protection))
- 2 x RJ-45 LAN Ports with LED (ACT/LINK LED & SPEED LED)
- 1 x Clear CMOS Switch
- HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks) Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
- Premium Blu-ray Audio support
- Supports Surge Protection (ASRock Full Spike Protection)
- Supports Purity Sound TM 4
- Nichicon Fine Gold Series Audio Caps
- 120d B SNR DAC with Differential Amplifier
- TI NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets)
- Pure Power-In
- Direct Drive Technology
- PCB Isolate Shielding
- Impedance Sensing on Front Out port
- Individual PCB Layers for R/L Audio Channel
- AURA RGB LED
- Gold Audio Jacks
- 15ì Gold Audio Connector
- Supports DTS Connect LAN Intel I219-V Gigabit LAN Form Factor ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm Warranty Three Year Manufacturer Warranty








































...

Features ASRock Super Alloy Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Supports DDR4 3600+ (OC) 3 PCIe 3.0 x 16, 1 PCIe 3.0 x 1, 1 M.2 (Key E) NVIDIA Quad SLI™, AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC1220 Audio Codec), Supports Purity Sound™ 4 & DTS Connect 6 SATA3, 2 Ultra M.2 (PCIe Gen 3 x 4 & SATA3) 2 USB (Universal Serial Bus) 3.1 10 Gb/s (1 Type-A + 1 Type-C), 9 x USB (Universal Serial Bus) 3.0 (4 Front, 4 Rear, 1 x Vertical Type-A) Intel Gigabit LAN ASRock AURA RGB LED

Specification CPU
- Supports 7th & 6th Generation Intel Core TM i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151)
- Digi Power design
- 6 Power Phase design Chipset Intel Z270 Chipset Memory
- Dual Channel DDR4 Memory Technology
- 4 x DDR4 DIMM Slots
- Supports DDR4 3600+ (OC)*/3200 (OC)/2933 (OC)/2800 (OC)/2400**/2133 non-ECC, un-buffered memory Onboard Graphics Outputs
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz Maximum shared memory of 1024MB Multi-GPU Support
- Supports AMD Quad Cross Fire X & Cross Fire X
- Supports NVIDIA Quad SLI & SLI PCI Slots
- 3 x PCI Express 3.0 x 16 Slots (PCIE1/PCIE3/PCIE4: single at x 16 (PCIE1); dual at x 8 (PCIE1) / x 8 (PCIE3); triple at x 8 (PCIE1) / x 8 (PCIE3) / x 4 (PCIE4))* * Supports NVMe SSD as boot disks
- 1 x PCI Express 3.0 x 1 Slot (Flexible PCIe) Storage
- 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug* * If M2_1 is occupied by a SATA-type M.2 device, SATA3_5 will be disabled. * If M2_2 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.
- 1 x Ultra M.2 Socket (M2_1), supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)**
- 1 x Ultra M.2 Socket (M2_2), supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** ** Supports Intel Optane TM Technology USB (Universal Serial Bus) Rear Panel:
- 4 x USB (Universal Serial Bus) 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.1 Type-A Port (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.1 Type-C Port (Supports ESD Protection (ASRock Full Spike Protection)) On Board:
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
- 2 x USB (Universal Serial Bus) 3.0 Headers (Support 4 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
- Premium Blu-ray Audio support
- Supports Surge Protection (ASRock Full Spike Protection)
- Supports Purity Sound TM 4
- Nichicon Fine Gold Series Audio Caps
- 120d B SNR DAC with Differential Amplifier
- TI NE5532 Premium Headset Amplifier for Front Panel Audio Connector (Supports up to 600 Ohm headsets) LAN Intel I219-V Gigabit LAN Form Factor Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm Warranty Three Year Manufacturer Warranty































...

Features ASRock Super Alloy Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Supports DDR4 3600+ (OC) 2 PCIe 3.0 x 16, 2 PCIe 3.0 x 1 AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub Supports Triple Monitor 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps 6 SATA3, 2 Ultra M.2 (One supports PCIe Gen 3 x 4 & SATA3, the other one supports PCIe Gen 3 x 4 only) 9 USB (Universal Serial Bus) 3.0 (1 Type-C, 4 Front, 4 Rear)

Specification CPU
- Supports 7th & 6th Generation Intel Core TM i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151)
- Digi Power design
- 6 Power Phase design Chipset Intel Z270 Chipset Memory
- Dual Channel DDR4 Memory Technology
- 4 x DDR4 DIMM Slots
- Supports DDR4 3600+ (OC)*/3200 (OC)/2933 (OC)/2800 (OC)/2400**/2133 non-ECC, un-buffered memory Onboard Graphics Outputs
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz Maximum shared memory of 1024MB Multi-GPU Support Supports AMD Cross Fire X™ Technology PCI Slots
- 2 x PCI Express 3.0 x 16 Slots (PCIE1: x 16 mode; PCIE4: x 4 mode)* * Supports NVMe SSD as boot disks
- 2 x PCI Express 3.0 x 1 Slots (Flexible PCIe) Storage
- 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug* * If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.
- 1 x Ultra M.2 Socket (M2_1), supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)**
- 1 x Ultra M.2 Socket (M2_2), supports type 2230/2242/2260/2280 M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** ** Supports Intel Optane TM Technology ** Supports NVMe SSD as boot disks USB (Universal Serial Bus) Rear Panel:
- 1 x USB (Universal Serial Bus) 2.0 Port (Supports ESD Protection (ASRock Full Spike Protection))
- 4 x USB (Universal Serial Bus) 3.0 Type-A Ports (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.0 Type-C Port (Supports ESD Protection (ASRock Full Spike Protection)) On Board:
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
- 2 x USB (Universal Serial Bus) 3.0 Headers (Support 4 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec) * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver.
- Premium Blu-ray Audio support
- Supports Surge Protection (ASRock Full Spike Protection)
- ELNA Audio Caps LAN Intel I219-V Gigabit LAN Form Factor Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm Warranty Three Year Manufacturer Warranty


























...

Features ASRock Super Alloy Supports 7th & 6th Generation Intel Core™ i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151) Supports DDR4 3733+ (OC) 1 PCIe 3.0 x 16, 1 PCIe 2.0 x 1 Graphics Output Options: 2 x HDMI, DVI-D Supports Triple Monitor 7.1 CH HD Audio (Realtek ALC892 Audio Codec), Nichicon Fine Gold Series Audio Caps 6 SATA3, 1 Ultra M.2 8 USB (Universal Serial Bus) 3.0 (2 Front, 6 Rear) Dual Intel Gigabit LAN Intel 802.11ac Wi Fi

Specification CPU
- Supports 7th & 6th Generation Intel Core TM i 7/i 5/i 3/ Pentium/ Celeron Processors (Socket 1151)
- Digi Power design
- 6 Power Phase design Chipset Intel Z270 Chipset Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 3733+ (OC)*/3600 (OC)/3200 (OC)/2933 (OC)/2800 (OC)/2400**/2133 non-ECC, un-buffered memory Onboard Graphics Outputs
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 24 Hz / (3840x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz Maximum shared memory of 1024MB PCI Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE1: x 16 mode) Storage 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15 & Intel Smart Response Technology), NCQ, AHCI & Hot Plug* * If M2_1 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled.
- 1 x Ultra M.2 Socket, supports type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** ** Supports Intel Optane TM Technology ** Supports NVMe SSD as boot disks USB (Universal Serial Bus) Rear Panel:
- 2 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
- 6 x USB (Universal Serial Bus) 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) On Board:
- 1 x USB (Universal Serial Bus) 2.0 Headers (Support 2 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
- 1 x USB (Universal Serial Bus) 3.0 Headers (Support 2 USB (Universal Serial Bus) 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec) * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver.
- Premium Blu-ray Audio support
- Supports Surge Protection (ASRock Full Spike Protection)
- Nichicon Fine Gold Series Audio Caps LAN Intel I219-V Gigabit LAN Wi Fi / Bluetooth Intel 802.11ac Wi Fi Module
- Supports IEEE 802.11a/b/g/n/ac
- Supports Dual-Band (2.4/5 GHz)
- Supports high speed wireless connections up to 433 Mbps
- Supports Bluetooth 4.0 / 3.0 + High speed class II Form Factor Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm Warranty Three Year Manufacturer Warranty

























...
