Features Supports 9th & 8th Gen Intel Core™ Processors (Socket 1151) Supports DDR4 2666 1 PCIe 3.0 x 16, 1 PCIe 2.0 x 1 Graphics Output Options: DVI-D, D-Sub, HDMI 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Supports Full Spike Protection, ASRock Live Update & APP Shop Overview HEVC 10-bit Decoding/ Encoding Supports HEVC 10-bit Decoding/ Encoding to provide substantially enhanced video quality & higher bit depth video experience. 4K x 2K Composed by a minimum of 3840 x 2160 pixels, which is twice the horizontal & vertical resolution of the 1080p format. 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution. Water Pump Header This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 1.5A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. Solid Capacitor Design ASRock applied solid capacitors on this motherboard. With these solid caps, this motherboard is allowed to perform more stably & ensure longer lifetime. A-Tuning A-Tuning is ASRocks multi purpose software suite with a new interface, more new features & enhanced utilities. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps & support software for users to download. You can also easily optimize your system & keep your motherboard up to date with ASRock Live Update & APP Shop.

Specification Unique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 9th & 8th Gen Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 4 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H310 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 64GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- DRAM, PCH 1.05V Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWA Encode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1
- Three graphics output options: D-Sub, DVI-D & HDMI**
- Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
- Supports HDCP 2.2 with DVI-D & HDMI 1.4 Ports
- Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Supports up to 2 displays simultaneously Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- 1 x Realtek RTL8111H
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE2: x 16 mode)*
- 1 x PCI Express 2.0 x 1 Slot * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug Connector
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 1 x Chassis/ Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x USB (Universal Serial Bus) 2.0 Header (Supports 2 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor
- Micro ATX Form Factor: 7.5-in x 7.4-in, 19.1 cm x 18.8 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE















































































...

Features Supports 9th & 8th Gen Intel Core™ Processors (Socket 1151) Supports DDR4 2666 1 PCIe 3.0 x 16, 2 PCIe 2.0 x 1 AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3, 1 M.2 (PCIe Gen 2 x 4 & SATA3) 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Intel Gigabit LAN PCIe Gen 2 x 4 M.2 The PCIe Gen 2 x 4 interface pushes data transfer speeds up to 20 Gb/s. In addition, it also supports SATA 3 6 Gb/s M.2 modules, & is compatible with ASRock’s U.2 Kit for installing some U.2 SSDs. Intel LAN Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability & is able to deliver ultimate network experience to users! 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution. 4K x 2K Composed by a minimum of 3840 x 2160 pixels, which is twice the horizontal & vertical resolution of the 1080p format. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. A-Tuning A-Tuning is ASRocks multi purpose software suite with a new interface, more new features & enhanced utilities. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps & support software for users to download. You can also easily optimize your system & keep your motherboard up to date with ASRock Live Update & APP Shop. Specifications Unique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 9th & 8th Gen Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 4 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H310 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, GT_CPU, DRAM, PCH 1.05V Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWA Encode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1
- Three graphics output options: D-Sub, DVI-D & HDMI**
- Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required)
- Supports HDCP 2.2 with DVI-D & HDMI 1.4 Ports
- Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Supports up to 2 displays simultaneously Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE1: x 16 mode)*
- 2 x PCI Express 2.0 x 1 Slots * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug*
- 1 x M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 2 x 4 (20 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled. ** Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector
- 1 x Print Port Header
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 2 x Chassis/ Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection)*** * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP & CHA_FAN2/WP can auto detect if 3-pin or 4-pin fan is in use. ***USB_11_12 is shared with USB_9_10. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 1 x Screw for M.2 Socket Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.0V Form Factor
- Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)


















































































...

Features Supports 8th Generation Intel Core™ Processors (Socket 1151) Supports DDR4 2666 1 PCIe 3.0 x 16, 1 PCIe 2.0 x 1 Graphics Output Options: DVI-D, D-Sub, HDMI 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Supports Full Spike Protection, ASRock Live Update & APP Shop Overview 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. Solid Capacitor Design ASRock applied solid capacitors on this motherboard. With these solid caps, this motherboard is allowed to perform more stably & ensure longer lifetime. Water Pump Header This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 1.5A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes. A-Tuning A-Tuning is ASRocks multi purpose software suite with a new interface, more new features & enhanced utilities. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps & support software for users to download. You can also easily optimize your system & keep your motherboard up to date with ASRock Live Update & APP Shop.

Specification nique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 8th Generation Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 5 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H310 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- DRAM, PCH 1.05V Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWAEncode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)
- Three graphics output options: D-Sub, DVI-D & HDMI**
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports 4K Ultra HD (UHD) playback with HDMI Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Supports up to 2 displays simultaneously Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s
- 1 x Realtek RTL8111H
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE2: x 16 mode)*
- 1 x PCI Express 2.0 x 1 Slot * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug Connector
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (4-pin)
- 1 x Chassis/ Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x USB (Universal Serial Bus) 2.0 Header (Supports 2 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore Form Factor
- Micro ATX Form Factor: 7.5-in x 7.4-in, 19.1 cm x 18.8 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)
















































































...

Features Supports 8th Generation Intel Core™ Processors (Socket 1151) Supports DDR4 2666 1 PCIe 3.0 x 16, 2 PCIe 2.0 x 1 AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC887 Audio Codec), ELNA Audio Caps 4 SATA3, 1 M.2 (PCIe Gen 2 x 4 & SATA3) 4 USB (Universal Serial Bus) 3.1 Gen 1 (2 Front, 2 Rear) Intel Gigabit LAN Overview PCIe Gen 2 x 4 M.2 The PCIe Gen 2 x 4 interface pushes data transfer speeds up to 20 Gb/s. In addition, it also supports SATA 3 6 Gb/s M.2 modules, & is compatible with ASRock’s U.2 Kit for installing some U.2 SSDs. 4K x 2K Composed by a minimum of 3840 x 2160 pixels, which is twice the horizontal & vertical resolution of the 1080p format. 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. A-Tuning A-Tuning is ASRocks multi purpose software suite with a new interface, more new features & enhanced utilities. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps & support software for users to download. You can also easily optimize your system & keep your motherboard up to date with ASRock Live Update & APP Shop.

Specification Unique Feature ASRock Super Alloy
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 8th Generation Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- 5 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H310 Memory
- Dual Channel DDR4 Memory Technology
- 2 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Max. capacity of system memory: 32GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- CPU, GT_CPU, DRAM, PCH 1.05V Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWA Encode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)
- Three graphics output options: D-Sub, DVI-D & HDMI**
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports 4K Ultra HD (UHD) playback with HDMI Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. ** Supports up to 2 displays simultaneously Audio
- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 1 x PCI Express 3.0 x 16 Slot (PCIE1: x 16 mode)*
- 2 x PCI Express 2.0 x 1 Slots * Supports NVMe SSD as boot disks Storage
- 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI & Hot Plug*
- 1 x M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 2 x 4 (20 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA3_3 will be disabled. ** Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector
- 1 x Print Port Header
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Chassis Intrusion & Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 2 x Chassis/ Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 4 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (Supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection)*** * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP & CHA_FAN2/WP can auto detect if 3-pin or 4-pin fan is in use. ***USB_11_12 is shared with USB_9_10. Rear Panel I/O
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 4 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 1 x Screw for M.2 Socket Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- CASE OPEN detection
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, PCH 1.05V Form Factor
- Micro ATX Form Factor: 8.9-in x 7.4-in, 22.6 cm x 18.8 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)




















































































...

Features Supports 8th Generation Intel Core™ Processors (Socket 1151) 10 Power Phase Design Supports DDR4 2666 2 PCIe 3.0 x 16, 3 PCIe 3.0 x 1, 1 M.2 (Key E) AMD Quad Cross Fire X™ Graphics Output Options: HDMI, DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC892 Audio Codec), ELNA Audio Caps 6 SATA3, 2 Ultra M.2 (PCIe Gen 3 x 4 & SATA3) 2 USB (Universal Serial Bus) 3.1 Gen 2 (Rear Type-A+C), 6 USB (Universal Serial Bus) 3.1 Gen 1 (4 Front, 2 Rear) Intel Gigabit LAN Overview Dual M.2 For SSD Equipped with M.2 slot that supports both SATA3 6 Gb/s & PCIe Gen 3 x 4 Ultra M.2 interface that pushes data transfer speeds up to 32 Gb/s, & is compatible with ASRock’s U.2 Kit for installing some of the world’s fastest U.2 PCIe Gen 3 x 4 SSD. Intel LAN Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability & is able to deliver ultimate network experience to users! M.2 (KEY E) For Wi Fi Besides the onboard LAN port, users may also choose 802.11ac wireless connections by M.2 (Key E) slot. * Wi-Fi module is not included. ELNA Audio Caps Who says high quality audio is only available on high-end motherboards? ASRock applied ELNA audio capacitors on mainstream & entry-level motherboards! Compared with traditional solid caps, the leakage current of ELNA audio caps is merely 3u A. This is the key to reduce noise level significantly & satisfy even the pickiest audiophiles. A-Tuning A-Tuning is ASRocks multi purpose software suite with a new interface, more new features & enhanced utilities.

Specification Unique Feature ASRock USB (Universal Serial Bus) 3.1 Gen 2
- ASRock USB (Universal Serial Bus) 3.1 Gen 2 Type-A Port (10 Gb/s)
- ASRock USB (Universal Serial Bus) 3.1 Gen 2 Type-C Port (10 Gb/s) ASRock Super Alloy
- Premium 50A Power Choke
- I/O Armor
- Sapphire Black PCB
- High Density Glass Fabric PCB ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology ASRock Ultra M.2 (PCIe Gen 3 x 4 & SATA3) ASRock Full Spike Protection (for all USB (Universal Serial Bus), Audio, LAN Ports) ASRock Live Update & APP Shop CPU
- Supports 8th Generation Intel Core™ Processors (Socket 1151)
- Supports CPU up to 95W
- Digi Power design
- 10 Power Phase design
- Supports Intel Turbo Boost 2.0 Technology Chipset
- Intel H370 Memory
- Dual Channel DDR4 Memory Technology
- 4 x DDR4 DIMM Slots
- Supports DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory
- Supports ECC UDIMM memory modules (operate in non-ECC mode)
- Max. capacity of system memory: 64GB*
- Supports Intel Extreme Memory Profile (XMP) 2.0
- 15μ Gold Contact in DIMM Slots * Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation. BIOS
- 128 Mb AMI UEFI Legal BIOS with multilingual GUI support
- ACPI 6.0 Compliant wake up events
- SMBIOS 2.7 Support
- DRAM, PCH 1.0V, VCCIO, VCCST, VCCSA, VPPM Voltage Multi-adjustment Graphics
- Supports Intel UHD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) & MPEG-2 Full HW Encode 1, Intel In Tru™ 3D, Intel Clear Video HD Technology, Intel Insider™, Intel UHD Graphics
- Direct X 12
- HWAEncode/ Decode: AVC/H.264, HEVC/H.265 8-bit, HEVC/H.265 10-bit, VP8, VP9 8-bit, VP9 10-bit (Decode only), MPEG2, MJPEG, VC-1 (Decode only)
- Three graphics output options: D-Sub, DVI-D & HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K (4096x 2160) @ 30 Hz
- Supports DVI-D with max. resolution up to 1920x 1200 @ 60 Hz
- Supports D-Sub with max. resolution up to 1920x 1200 @ 60 Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xv YCC & HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports HDCP with DVI-D & HDMI Ports
- Supports 4K Ultra HD (UHD) playback with HDMI Port * Intel UHD Graphics Built-in Visuals & the VGA outputs can be supported only with processors which are GPU integrated. Audio
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)*
- Premium Blu-ray Audio support
- Supports Surge Protection
- ELNA Audio Caps * To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY Intel I219V
- Supports Wake-On-LAN
- Supports Lightning/ESD Protection
- Supports Energy Efficient Ethernet 802.3az
- Supports PXE Slots
- 2 x PCI Express 3.0 x 16 Slots (PCIE2/PCIE4: single at x 16 (PCIE2); dual at x 16 (PCIE2) / x 4 (PCIE4))*
- 3 x PCI Express 3.0 x 1 Slots (Flexible PCIe)
- Supports AMD Quad Cross Fire X™ & Cross Fire X™
- 1 x M.2 Socket (Key E), supports type 2230 Wi Fi/BT module & Intel CNVi (Integrated Wi Fi/BT) * If PCIE3 or PCIE5 is occupied, PCIE4 will downgrade to x 2 mode. Supports NVMe SSD as boot disks Storage
- 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 15), NCQ, AHCI & Hot Plug*
- 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)**
- 1 x Ultra M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s module & M.2 PCI Express module up to Gen 3 x 4 (32 Gb/s)** * If M2_1 is occupied by a SATA-type M.2 device, SATA3_5 will be disabled. If M2_2 is occupied by a SATA-type M.2 device, SATA3_0 will be disabled. ** Supports Intel Optane™ Technology Supports NVMe SSD as boot disks Supports ASRock U.2 Kit Connector
- 1 x COM Port Header
- 1 x TPM Header
- 1 x Power LED & Speaker Header
- 1 x CPU Fan Connector (4-pin)*
- 3 x Chassis/ Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x Front Panel Audio Connector
- 1 x Thunderbolt™ AIC Connector (5-pin)
- 2 x USB (Universal Serial Bus) 2.0 Headers (Support 3 USB (Universal Serial Bus) 2.0 ports) (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Headers (Support 4 USB (Universal Serial Bus) 3.1 Gen 1 ports) (Supports ESD Protection) * The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/ Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. CHA_FAN1/WP, CHA_FAN2/WP & CHA_FAN3/WP can auto detect if 3-pin or 4-pin fan is in use. Rear Panel I/O
- 2 x Antenna Ports
- 1 x PS/2 Mouse/ Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI Port
- 2 x USB (Universal Serial Bus) 2.0 Ports (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A Port (10 Gb/s) (Supports ESD Protection)
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-C Port (10 Gb/s) (Supports ESD Protection)
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports (Supports ESD Protection)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED & SPEED LED)
- HD Audio Jacks: Line in / Front Speaker / Microphone Software & UEFI Software
- ASRock A-Tuning
- ASRock XFast LAN UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash
- ASRock Easy RAID Installer * These utilities can be downloaded from ASRock Live Update & APP Shop. Support CD
- Drivers, Utilities, Anti Virus Software (Trial Version), Google Chrome Browser & Toolbar Accessories
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables
- 3 x Screws for M.2 Sockets Hardware Monitor
- Temperature Sensing: CPU, Chassis/ Water Pump Fans
- Fan Tachometer: CPU, Chassis/ Water Pump Fans
- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/ Water Pump Fans
- Fan Multi-Speed Control: CPU, Chassis/ Water Pump Fans
- Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, VPPM, PCH 1.0V, VCCSA, VCCST Form Factor
- ATX Form Factor: 12.0-in x 8.8-in, 30.5 cm x 22.4 cm
- Solid Capacitor design OS
- Microsoft Windows 10 64-bit Certifications
- FCC, CE
- Er P/ Eu P ready (Er P/ Eu P ready power supply is required)
































































































...

Supports 10th Gen Intel Core Processors (Socket 1200) 7 Power Phase Design Supports DDR4 2933 MHz 1 PCIe 3.0 x 16, 1 PCIe 3.0 x 1, 1 M.2 Key E for Wi Fi Graphics Output Options: HDMI, DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC887 Audio Codec) 4 SATA3, 1 Ultra M.2 (PCIe Gen 3 x 4 & SATA3) 4 USB (Universal Serial Bus) 3.2 Gen 1 (2 Front, 2 Rear) Intel Gigabit LAN 7 Power Phase Design Featuring sturdy components & completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities & enhanced performance with the lowest temperature for advanced gamers as well. Premium 50A Power Choke Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced & enhanced Vcore voltage to the motherboard. Intel LAN Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability & is able to deliver ultimate network experience to users! Ultra M.2 32 Gb/s (PCIe Gen 3 x 4 & SATA3) The PCIe Gen 3 x 4 Ultra M.2 interface pushes data transfer speeds up to 32 Gb/s. In addition, it also supports SATA3 6 Gb/s M.2 modules, & is compatible with ASRock’s U.2 Kit for installing some of the world’s fastest U.2 PCIe Gen 3 x 4 SSDs. M.2 (KEY E) For Wi Fi Besides the onboard LAN port, users may also choose 802.11ac wireless connections by M.2 (Key E) slot. Super Alloy Motherboard Premium 50A Power Choke Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced & enhanced Vcore voltage to the motherboard. ...

Supports 10th Gen Intel Core Processors (Socket 1200) Supports DDR4 2933 M Hz 1 PCIe 3.0 x 16, 1 PCIe 3.0 x 1 Graphics Output Options: HDMI, D-Sub 7.1 CH HD Audio (Realtek ALC887 Audio Codec) 4 SATA3 4 USB (Universal Serial Bus) 3.2 Gen 1 (2 Front, 2 Rear) 5 Power Phase Design Featuring sturdy components & completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities & enhanced performance with the lowest temperature for advanced gamers as well. Premium 50A Power Choke Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced & enhanced Vcore voltage to the motherboard. Super Alloy Motherbard Premium 50A Power Choke Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced & enhanced Vcore voltage to the motherboard. Sapphire Black PCB Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality & gives the motherboard a more mysterious touch. High Density Glass Fabric PCB High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity. Dual Graphics Outputs Complete with two types of most used connectors! Packed with a HDMI + D-SUB combo, you have more graphics output options now. ...

Key Features • Supports 10th Gen Intel Core™ Processors & 11th Gen Intel Core™ Processors • Supports DDR4 3200 M Hz • Graphics Output: HDMI • 6 PCIe 3.0 x 16, 1 Mining Port (M_ Port 1 at x 1) • 1 SATA3, 1 M.2 (SATA3) • 2 Rear USB (Universal Serial Bus) 3.1 Gen 1 Type-A • 4 USB (Universal Serial Bus) 2.0 Type-A (2 Rear, 2 Front) • Intel Gigabit LAN • 2 Extra 24-pin ATX Power Connector • Onboard Power On / Reset Button • Fully Independent Power Rail LEGENDARY PERFORMANCE, EXTREME DURABILITY This motherboard is specifically designed for mining, the revolutionary digital crypto-currency that may be used anywhere in the world. The abundant onboard PCIe slots guarantee fast Crypto mining, while the additional power connectors provide advanced system stability while mining. This motherboard comes fully equipped with six PCI Express 3.0 x 16 slots & a USB (Universal Serial Bus) mining port for you to install up to Seven graphics cards. There is also an extra 24-pin ATX connector for easy multiple power supply setups. You also get a fully independant power rail which is ideal for more flexible power management to PCIe slots. Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability & is able to deliver ultimate network experience to users! USB (Universal Serial Bus) Type PCIe x 1 Mining Ports This motherboard has included a smart way to show the status of every graphics card. While the system is booting, the Power-On, Self-Test (POST) screen will show the status of the graphics cards that were installed on the motherboard. There is also an onboard USB (Universal Serial Bus) Type PCIe x 1 mining ports for setting up even more graphics cards. Riser Kit Free The advanced PCI-E Steel Slots packed with solid cover that prevent any signal interference with graphics cards. It also ensures the heavy graphics cards to be well-installed in the PCI-E slots safely. Install graphics cards directly on the motherboard without using riser kits to ensure ultimate stability. Live Update & APP Shop ASRock Live Update & APP Shop is designed for your convenience. We provide various apps & support software for users to download. You can also easily optimize your system & keep your motherboard up to date with ASRock Live Update & APP Shop. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.

...

Features Supports 10th Gen Intel Core Processors & 11th Gen Intel Core Processors. Supports DDR4 3200 M Hz (OC). 1x PCIe 4.0 x 16, 1x PCIe 3.0 x 1. Graphics Output Options: HDMI, DVI-D, D-Sub. 7.1 CH HD Audio (Realtek ALC897 Audio Codec). 4x SATA3 ports. 4x USB (Universal Serial Bus) 3.2 Gen 1 (2x Rear, 2x Front). Realtek Gigabit LAN. Premium 50A Power Choke ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced & enhanced Vcore voltage to the motherboard. HDMI 4k @60 Hz Supports the most recent HDMI 4K 60 Hz graphics output

Specification. With the larger bandwidth & increased frame rate, the motion on your screen becomes more fluid & less blurry. High Density Glass Fabric PCB High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity. Sapphire Black PCB Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality & gives the motherboard a more mysterious touch. 3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI port supports 4K resolution. Water Pump Header This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 2A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise. Full Spike Protection Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection

Includes:: various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.



...

Features Supports 10th Gen Intel Core™ Processors & 11th Gen Intel Core™ Processors 8 Phase Power Design Supports DDR4 4800 M Hz (OC) 1 x PCIe 4.0 x 16, 1 x PCIe 3.0 x 16, 3 x PCIe 3.0 x 1 1 x M.2 Key-E for Wi Fi Graphics Output Options: HDMI, Display Port 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Nahimic Audio 6 SATA3, 1 x Hyper M.2 (PCIe Gen 4 x 4) 2 x Ultra M.2 (PCIe Gen 3 x 4 & SATA3) 1 x USB (Universal Serial Bus) 3.2 Gen 2x 2 Front Type-C (20 Gb/s) Rear USB (Universal Serial Bus) 3.2 Gen 2 Type A+C (10 Gb/s) 6 x USB (Universal Serial Bus) 3.2 Gen 1 (2 x Rear, 4 x Front) 6 x USB (Universal Serial Bus) 2.0 (2 x Rear, 4 x Front) Dragon 2.5 Gigabit LAN ASRock Polychrome SYNC Steel Legend represents the philosophical state of rock-solid durability & irresistible aesthetics. Built around most demanding specs & features, the Steel Legend series aims at daily users & mainstream enthusiasts! Providing a strong array of materials/components to ensure a stable & reliable performance. 8 Power Phase Design Featuring sturdy components & completely smooth power delivery to the CPU. Plus, it offers enhanced performance with the lowest temperature for advanced gamers. Premium 50A Power Choke Compared to traditional chokes, ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced & enhanced Vcore voltage to the motherboard. Clever Access Memory Conventional PC systems processor can only access a fraction of graphics memory & limits system performance. With Clever Access Memory, the data channel gets expanded to harness the full potential of GPU memory, removes the bottleneck & increase performance. Base Frequency Boost (BFB) Technology Who ever said that only K series CPUs & the Z-family platform are capable of being performed with maximum power. Via ASRock BFB (Base Frequency Boost) Technology, users may install their non K series CPUs to ASRock’s selected 500 series motherboards & enjoy the base frequency boost with the hidden power of processors immediately. While ASRock BFB breathes life into non K series CPUs, the boost frequency currently still depends on the cooling system applied on your rig. ...
