Every PC deserves great graphics. The PNY Ge Force GT 620 graphics card gives you a superior multimedia experience, every time. Count on NVIDIA dedicated graphics for faster, more immersive experience in your favorite applications every time. SPECIFICATIONS Bus Connector
- PCI-Express 2.0 Outputs
- VGA, DVI-I, HDMI Core Clock
- 700 MHz Memory Clock
- 1400 Mhz Memory Capacity
- 1 GB DDR3 Memory Interface
- 64-bit Memory Bandwidth
- 11, 2 GB/s Microsoft Direct X
- 11.1 API (feature level 11_0) MINIMUM SYSTEM REQUIREMENTS PCI Express or PCI Express 2.0-compliant motherboard with one dual-width x 16 graphics slot Minimum 350W or greater system power supply







...

Every PC deserves dedicated graphics. The PNY Ge Force GT 630 graphics card is designed to deliver a premium multimedia experience & reliable entry-level PC gaming, every time. Insist on NVIDIA dedicated graphics for faster, more immersive experience in your favorite applications every time. SPECIFICATIONS Bus Connector: PCI-Express 2.0 Outputs: VGA, DVI-I, HDMI Core Clock: 780 MHz Memory Clock: 1600 Mhz Memory Capacity: 1 GB DDR3 Memory Interface: 128-bit Memory Band
Width: 25, 6 GB/s Microsoft Direct X 11.1 API (feature level 11_0) MINIMUM SYSTEM REQUIREMENTS PCI Express or PCI Express 2.0-compliant motherboard with one dual-width x 16 graphics slot Minimum 350W or greater system power supply
...

Features Kepler GPU Architecture NVIDIA's Kepler GPU architecture has been designed from the ground up not just for maximum performance, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. Blu-ray 3D Support Connect your PC to any 3D enabled TV over HDMI & enjoy a cinematic 3D experience in your home with seamless support for 1080p Blu-ray 3D discs. NVIDIA Adaptive Vertical Sync Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, it's disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. New Anti-aliasing Mode: FXAA Anti-aliasing smoothes out jagged edges but can be demanding on framerates. FXAA is a new antialiasing technology that produces beautiful smooth lines with minimal performance impact. & with Kepler based GPUs, you'll be able to enable FXAA in hundreds of game titles through the NVIDIA Control Panel. Technical

Specification Manufacturer
- PNY Chipset
- GT 640 Chipset Features Direct Compute Support HDMI Output Support Microsoft Direct X 11 Microsoft Windows 7 support NVIDIA 3D-Vision Ready NVIDIA Adaptive Vertical Sync NVIDIA CUDA Technology NVIDIA Phys X Ready Open CL Support Open GL 4.2 Pure Video HD Shader Model 5.0 Manufacturing process
- 28 nm Cores
- 384 Core Clock
- 900 MHz Shader Clock
- 1800 MHz Memory
- 2GB Memory Bit Rate
- 128 Bit Memory Type
- GDDR3 Memory Clock
- 1782 MHz Cooling
- Fan Interface
- PCIe 3.0 (x 16) Connectivity 1 x D-Sub 1 x Dual Link DVI-D 1 x HDMI Maximum GPU Power
- 65W Maximum GPU Temperature
- 98 °C















...

NVIDIA Ge Force GTX 580 features with screaming performance & a vapor chamber thermal design. The GTX 580 rips through the games while running quieter than the previous generation. As youve come to expect from a Ge Force GTX GPU, GTX 580 packs support for all the premium GTX gaming technologies such as NVIDIA Surround, 3D Vision, Phys X, & SLI. Ge Force GTX 580
- dont play DX11 without it.
...

Step up to the PNY Ge Force GTX 650 Ti for turbocharged, next-gen PC gaming at a remarkable price. Based on the fast & efficient Nvidia Kepler architecture, PNY Ge Force GTX 650 delivers 40% boost over Ge Force GTX 650 GPU, provides stunning Direct X 11 performance, 1080p HD brillance in your favorite FPS, RTS & MMO games. SPECIFICATIONS Bus Connector: PCI-Express 3.0 Outputs: Dual DVI, Mini HDMI Core Clock: 1058 MHz Memory Capacity: 1 GB GDDR5 Memory Interface: 128-bit Memory Band
Width: 86, 4 GB/s Fill Rate (texels/sec.): 59, 4 Billion Microsoft Direct X 11.1 API (feature level 11_0) MINIMUM SYSTEM REQUIREMENTS PCI Express or PCI Express 2.0-compliant motherboard with one dual-width x 16 graphics slot. Minimum 400W or greater system power supply. One 6-pin PCI Express supplementary power connector.
...

SEE HOW PNY IS REDEFINING SMOOTH, SEAMLESS, LIFELIKE GAMING. The powerful new Ge Force GTX 600-series architecture delivers more than just state-of-the-art features & technology. It gives you truly game-changing performance that will transform the way you experience all your favorite titles—now & in the future. This innovative architecture was designed from the ground up to deliver power-efficient gaming performance thats faster, smoother, & richer than anything youve experienced before. The Ge Force GTX 660 Ti adds a new dimension to the game-changing NVIDIA Kepler-powered family of graphics cards by delivering the ideal combination of performance, power efficiency, & affordability. Its a must-have upgrade for todays hottest & most demanding games. Specifications Processor Cores
- 1344 Core Clock
- 915 MHz Boost Clock
- 980 MHz Memory Amount
- 2048MB GDDR5 Memory Data Rate, effective
- 6.0 Gbps Memory Interface
- 192-bit Power & Thermal
- 150W-Active On-board Outputs
- DVI, DVI, HDMI, Display Port Bus Type
- PCI Express 3.0 Minimum System Requirements PCI Express-compliant motherboard with one dual-width x 16 graphics slot Two 6-pin PCI Express supplementary power connectors Minimum 550W or greater system power supply (with a minimum 12V current rating of 38A)3 300 MB of available hard-disk space 2GB system memory (4GB or higher recommended) Microsoft Windows 7, Windows Vista, or Windows XP Operating System (32 or 64-bit) DVD-ROM drive or Internet connection for installation DVI or HDMI or Display Port or VGA compatible monitor








...

The Ge Force GTX 660 is built for fast & fluid 1080p gaming in the Direct X 11 & NVIDIA Phys X-enabled games. Packed with all the Kepler features found in the flagship GTX680, Ge Force GTX 660 delivers the ideal fusion of power, performance, & affordability. General
-
- Graphics Engine
- NVIDIA Ge Force GTX 660
- Max Monitors Supported
- 4
- API Supported
- Direct X 11, Open GL 4.2
- Boost Clock
- 1033 MHz
- Bus Type
- PCI Express 3.0 x 16
- CUDA Cores
- 960
- Core Clock
- 980 MHz
- Interfaces
- 2 x DVI ¦ HDMI ¦ Display Port Features
-
- Nvidia CUDA technology, Nvidia Phys X-Ready, Nvidia 3D Vision technology, Nvidia Surround technology, Nvidia SLI ready, TXAA,
- NVIDIA Adaptive Vertical Sync, NVIDIA GPU Boost, Nvidia Fast Approximate Antialiasing Technology (FXAA), Kepler GPU Architecture Memory
-
- Bandwidth
- 144.2 GBps
- Bus Width
- 192-bit
- Size
- 2GB
- Technology
- GDDR5 SDRAM System Requirements
-
- Min Hard Drive Space
- 300 MB
- Min RAM Size
- 2GB
- OS Required
- Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Microsoft Windows XP (32/64 bits)
- Peripheral / Interface Devices
- DVD-ROM, two 6-pin power connectors
- Required Power Supply
- 450W







































...

The Ge Force GTX 680 gives you more than just state-of-the-art features & technology. It delivers truly game-changing performance that taps into the powerful new Ge Force architecture to redefine smooth, seamless, lifelike gaming. Key Features NVIDIA GPU Boost NVIDIA Adaptive Vertical Sync NVIDIA Surround™ Support for four concurrent displays including:
- Two dual-link DVI
- HDMI1
- Displayport 1.2 Microsoft Direct X 11 with Direct Compute 5.0 support NVIDIA Phys X technology NVIDIA 3D Vision-Ready 2 NVIDIA SLI-Ready NVIDIA CUDA technology PCI Express 3.0 support Open GL 4.2 support Open CL™ support Minimum System Requirements PCI Express-compliant motherboard with one dual-width x 16 graphics slot Two 6-pin PCI Express supplementary power connectors Minimum 550W or greater system power supply (with a minimum 12V current rating of 38A)3 300 MB of available hard-disk space 2GB system memory (4GB or higher recommended) Microsoft Windows 7, Windows Vista, or Windows XP Operating System (32 or 64-bit) DVD-ROM drive or Internet connection for installation DVI or HDMI or Displayport or VGA compatible monitor Package Contents Ge Force GTX 680 graphics card Quick Installation Guide Installation DVD, which
Includes:: – Detailed installation guide – NVIDIA Graphics Drivers – NVIDIA Ge Force Demos – Phys X™ System Software DVI-to-VGA adapter 6-pin PCIe to Molex Power Adapter Product Specifications Processor Cores 1536 Core Clock 1006 MHz Boost Clock 1058 MHz Texture Fill Rate 128.8 Gigatexels/sec Memory Amount 2048MB GDDR5 Memory Data Rate, effective 6.0 Gbps Memory Interface 256-bit Memory Bandwidth 192.0 GB/sec Power & Thermal 195W-Active On-board Outputs DVI, DVI, HDMI, Display Port Bus Type PCI Express 3.0



...

Step up to Ge Force GTX gaming with the new GTX 750 Ti. Its powerful, ultra-efficient next-gen architecture makes the GTX 750 Ti the weapon of choice for serious gaming at an incredible value. GTX 750 & GTX 750 Ti cards give you the gaming horsepower to take on today’s most demanding titles in full 1080p HD. They deliver 25% more performance than previous generation cards & up to twice the power efficiency thanks to the next-generation NVIDIA Maxwell architecture. Plus, they come loaded with Ge Force GTX gaming technologies like NVIDIA Game Stream & Ge Force Experience. If you’re looking for hyper-realistic gameplay, stunning visuals, & exceptional value, this is your graphics card. PRODUCT SPECIFICATIONS GPU
- Ge Force GTX 750 Ti CUDA Cores
- 640 Core Speed
- 1 020 MHz Boost Speed
- 1 085 MHz Memory Size
- 2GB GDDR5 Memory Interface
- 128-bit Memor Frequency
- 5, 4 GBps TDP
- 62 Watts Multi-Screen
- 3 Concurrent Screens * NVIDIA 3D Surround ** Resolution
- 4096x 2160 (Digital) Bus Type
- PCI Express 3.0 16x Card

Dimensions
- 160 x 128 x 36mm Box

Dimensions
- 297 x 224 x 64mm MINIMUM SYSTEM REQUIREMENTS PCI Express-compliant motherboard with one dual-width x 16 graphics slot Minimum 400 W or greater system power supply (with a minimum 12 V current rating of 20 A) * 4- & 3- Screen Support only in Windows 8, Windows 7 & Windows Vista. Windows XP or earlier version will only support dual monitors ** NVIDIA 3D SURROUND requires additional hardware, please see NVIDIA for detailed information
















...

Fast just got faster. The next-generation Ge Force GTX 770 is a high-performance graphics card designed from the ground up to deliver high-speed, super-smooth gaming. It’s stacked with unique gaming technologies that make it fast. Really fast. GTX 770 features a massively powerful NVIDIA Kepler GPU. Plus, it comes with 7 Gbps memory—the fastest ever on a GPU & NVIDIA GPU Boost 2.0 technology, giving you the performance capabilities you need to game at extreme settings. ...
