Designed to fuel "instant-on" access & a cutting-edge computing experience Combining fast data transfer rates with instantaneous access times, OCZ Octane S2 SSDs are designed to provide enhanced application performance for SATA 3 Gbps systems. Octane S2 leverages the cutting-edge Indilinx Everest platform & is optimized for the complete spectrum of file types & sizes, with proprietary page mapping algorithms mirroring real world conditions across a wide range of applications. The Octane S2 also

Includes:: advanced features unique to Indilinx, including latency reduction technology to enhance system responsiveness & enable instant-on boot-ups. Octane S2 SSDs also deliver superior energy efficiency, durability, & reliability compared to traditional hard drives. Density = 128GB Max Read = 275 MB/s Max Write = 135 MB/s Random Read (4KB) = 29, 000 IOPS Random Write (4KB) = 9, 000 IOPS SATA-II 3 Gb/s interface compatible with mainstream platforms Indilinx Infused Boot time reduction optimizations for instant-on experience Superior performance across all file sizes & mixed workloads Faster performance with compressed data (MP3, JPG, RAW, PSD, OS X software, etc.) Sustained performance; remains close to "fresh-out-of-the-box" performance Advanced flash management technology to maximize endurance AES & automatic encryption to secure data TRIM support Additional Technical

Features: Strong performance at low queue depths (QD 1
- 3) Innovative latency reduction technology (read as low as 0.06ms & write as low as 0.09ms) Indilinx n Durance increases NAND life up to 2X of the rated P/E cycles Proprietary page mapping algorithms Usable Capacities (IDEMA) = 64GB NAND Components = 2 Xnm Asynchronous Mode Multi-Level Cell (MLC) Interface = Serial ATA (SATA) 3 Gb/s Form Factor = 2.5" NAND Controller = Indilinx Everest

Dimensions (L x W x H) = 99.8mm x 69.63mm x 9.3mm MTBF = 1.25 million hours Certifications = Ro HS, CE, FCC, C-Tick, VCCI, BSMI, CCC, KCC, WEEE






...

STOP PRESS _ THE OCTANE JUST GOT FASTER!!!!23/01/2012 OCZ Technology Group today announced the release of new enhanced IOPS firmware (v 1.13) for the Octane SATA 3.0 Series SSDs. The random write performance has been significantly enhanced, in some capacities over double that of the previous specifications, for users looking to push their SSD performance to new heights. For all Octane SATA-III models, the enhanced IOPS made possible by this new firmware allow for greater transactional performance, especially during small file & random access speeds in everyday computing applications. When compared to the previous revision, random write IOPS performance doubles across nearly all capacities when tested in Iometer 2008: Old Random Write 4K IOPS (FW v 1.12) 128GB = 7, 700 New Random Write 4K IOPS (FW v 1.13) 128GB = 18, 000 OCZ strives to offer the fastest, highest performing solutions on the market & continues to support customers by offering firmware innovations to their storage investments. The new enhanced IOPS firmware will begin shipping in the next batch of drives to resellers, & the upgrade file will be made available to existing customers via the companys website OCZ Octane 128GB 2.5" SATA III Solid State Drive Designed to fuel "instant-on" access & a cutting-edge computing experience Combining high-speed data transfer rates with record-breaking access times, OCZ Octane SSDs are designed to provide a superior user experience & enhanced application performance. Octane leverages the cutting-edge Indilinx Everest platform & is optimized for the complete spectrum of file types & sizes, with proprietary page mapping algorithms mirroring real world conditions across a wide range of applications. The Octane series also

Includes:: advanced features unique to Indilinx, including latency reduction technology to enhance system responsiveness & enable instant-on boot-ups. Octane SSDs also deliver the energy efficiency, durability, & reliability that traditional hard drives cannot provide. Density 128GB Max Read 535 MB/s Max Write 170 MB/s Random Read (4KB) 37, 000 IOPS Random Write (4KB) 18, 000 IOPS updated firmware Product Features SATA 6 Gb/s interface, unleashes the full potential of todays leading platforms Indilinx Infused Boot time reduction optimizations for instant-on experience Superior performance across all file sizes & mixed workloads Faster performance with compressed data (MP3, JPG, RAW, PSD, OS X software, etc.) Sustained performance; remains close to "fresh-out-of-the-box" performance Advanced flash management technology to maximize endurance AES & automatic encryption to secure data TRIM support Advanced Features Strong performance at low queue depths (QD 1
- 3) Innovative latency reduction technology (read as low as 0.06ms & write as low as 0.09ms) Indilinx n Durance increases NAND life up to 2X of the rated P/E cycles Proprietary page mapping algorithms Specifications Usable Capacities (IDEMA) = 128GB NAND Components = 2 Xnm Synchronous Mode Multi-Level Cell (MLC) Interface = Serial ATA (SATA) 6 Gb/s Form Factor = 2.5" NAND Controller = Indilinx Everest

Dimensions (L x W x H) = 99.8mm x 69.63mm x 9.3mm MTBF = 1.25 million hours Certifications = Ro HS, CE, FCC, C-Tick, VCCI, BSMI




...

OCZ Petrol 2.5" 128GB SATA III Solid State Drive At the most affordable price per gigabyte yet, OCZ Petrol SSDs leverage the SATA 6 Gbps Indilinx Everest platform to deliver superior performance & latency over hard drives, & are optimized for the complete spectrum of file types & sizes. The Petrol series

Includes:: advanced features unique to Indilinx, including latency reduction technology to enhance system responsiveness & enable instant-on boot-ups, & proprietary NDurance technology to increase the lifespan of the NAND flash memory & minimize performance degradation. Putting the benefits of SSDs within the reach of all, Petrol delivers a faster, more responsive computing experience over traditional hard disc storage. High Performance SSD Architecture The Petrol series leverages the cutting-edge Indilinx Everest platform to deliver up to 360 MB/s (max read) & 30, 000 IOPS (max 4KB random read) at an ultra-competitive price point. It delivers faster performance with compressed data such as MP3, JPG, RAW, PSD & OS X software, & strong performance at low queue depths (QD 1 &8211; 3). Petrols proprietary page mapping algorithms ensure superior performance across all file sizes & mixed workloads. The Petrol series also

Includes:: a number of advanced features unique to Indilinx, including innovative latency reduction technology, enabling both read & write access times as low as 0.06ms & 0.09ms respectively. This enhances application responsiveness & enables features such as "fast boot" in consumer applications. Enhanced Performance & Endurance Over The Long Term Petrol SSDs come equipped with Indilinxs proprietary NDurance technology, increasing the lifespan of the NAND flash memory, ensuring the most consistent & reliable performance as well as minimizing performance degradation even after the drives storage capacity is highly utilized. Efficient NAND Flash management including dynamic & static wear-leveling, & background garbage collection ensures close to &8216;fresh-out-of-the-box&8217; performance even after continual use. Trim Support The Petrol SSDs feature support for the Windows 7 TRIM comm&. This allows them to store only the data they need & perform memory optimization to ensure the fastest possible write speeds. Density = 128GB Max Read = 360 MB/s Max Write = 180 MB/s Random Read (4KB) = 32, 000 IOPS Random Write (4KB) = 6, 000 IOPS Cutting-edge SATA-III 6 Gb/s interface design Indilinx Infused Boot time reduction optimizations for instant-on experience Superior performance across all file sizes & mixed workloads Faster performance with compressed data (MP3, JPG, RAW, PSD, OS X software, etc.) Sustained performance; remains close to "& Aring;&8220;fresh-out-of-the-box" performance Advanced flash management technology to maximize endurance AES & automatic encryption to secure data TRIM support Additional Technical

Features: Strong performance at low queue depths (QD 1
- 3) Innovative latency reduction technology (read as low as 0.06ms & write as low as 0.09ms) Indilinx n Durance increases NAND life up to 2X of the rated P/E cycles Proprietary page mapping algorithms Usable Capacities (IDEMA) = 128GB NAND Components = 2 Xnm Asynchronous Mode Multi-Level Cell (MLC) Interface = Serial ATA (SATA) 6 Gb/s Form Factor = 2.5" NAND Controller = Indilinx Everest Dimensions (L x W x H) = 99.8mm x 69.63mm x 9.3mm MTBF = 1.25 million hours Certifications = Ro HS, CE, FCC, C-Tick, VCCI, BSMI, CCC, KCC, WEEE Warranty = 3 Years






...

The OCZ Synapse Series is optimized for caching applications to dynamically manage the Synapse SSD in conjunction with standard hard disk drives (HDDs), to provide users with SSD-level performance across the entire capacity of the HDD. The OCZ Synapse Series leverages the latest & most advanced hardware & software technology to deliver superior storage performance without sacrificing HDD capacity. For users craving the performance advantages of SSDs combined with the high capacities associated with HDDs, OCZ offers the first no-compromise approach to enabling high-performance & high-capacity storage for virtually any PC platform. The OCZ Synapse Series integrates Dataplex™ caching software to dynamically manage the use of both SSD & HDD for superior overall storage performance. This combination creates an environment where the most frequently used "hot" data stays on the ultra-fast SSD, while the "cold" data remains on the larger capacity HDD (sold separately). Advanced caching algorithms learn user behavior & adapt storage policies to ensure optimal performance for each individual user, maximizing productivity for the most demanded programs & applications Synapse Series integrates seamlessly within any modern PC platform, ensuring optimal compatibility along with performance gains & comes backed by a 3-year warranty. 128GB Max Performance Max Read: up to 550 MB/s Max Write: up to 510 MB/s Random Write 4k: 80, 000 IOPS

Specification Interface: SATA-III 6 Gbps / Backwards Compatible SATA-II 3 Gbps MLC NAND Flash Native TRIM support Integrated Dataplex™ caching software ECC Recovery, Data Encryption Slim 2.5" Design: 98 x 69.9 x 9.1 mm Lightweight: 79g Operating Temp: 0°C ~ 70°C Ambient Temp: 0°C ~ 55°C Storage Temp: -45°C ~ 85°C Low Power Consumption: 2.7W Active, 1.5W Idle Shock Resistant up to 1500G Included 3.5" Desktop adapter bracket Compatible with Windows 7 32-bit & 64-bit MTBF: 2 million hours 3-Year Warranty *NOTE: Synapse Series features 50% NAND flash overprovisiong to accommodate performance & software features FAQ What makes Synapse unique to other SSDs? The OCZ Synapse Series is optimized for caching applications to dynamically manage the Synapse SSD in conjunction with standard hard disk drives (HDDs), to provide users with SSD-level performance across the entire capacity of the HDD with Dataplex caching software. What are the benefits of Synapse when used with the Dataplex Software? Dataplex™ caching software dynamically manages the use of both SSD & HDD, & creates an environment where the most frequently used "hot" data stays on the SSD, while the "cold" data remains on your existing HDD. Advanced caching algorithms learn user behavior & adapt storage policies to ensure optimal performance for each individual user, resulting in higher performance after just a few runs of your frequently used applications & programs. Click here for performance charts How do I access the Dataplex Software file after purchasing my Synapse? Your Synapse packaging will include a product key for your Dataplex Software License. After locating the product key, visit the Synapse product page where you will see a tab for “ Downloads”. Click the tab & enter your information, then click the “ Submit & Download” button at the bottom of the page. The software file will save & you can install as usual. How is Synapse different from chipset-based caching? Synapse Cache SSDs are compatible with virtually any PC platform you already own, with no need for expensive upgrades to the latest motherboard to get the benefits of caching. The Synapse SSD has the additional benefit of speeding up your entire system since it accelerates the full capacity of your HDD as well. Whereas built-in chipset caching features mainly target enthusiasts, Synapse is also ideal even for the home or office user on a budget wanting to make the most of their existing system. Who are the target users that will benefit from Synapse? Synapse SSDs will provide the most benefit to desktop & even notebook users with multiple drive bays, who already have one or more high-capacity HDDs as their primary drive but want the speed benefits of an SSD without sacrificing their terabytes of storage. The advantage of Synapse is that you can purchase a relatively small capacity SSD to accelerate your entire storage subsystem, vs. purchasing a similar capacity SSD as a boot drive & only put a limited amount of files/programs on it. Is my data secure with Synapse? When used in conjunction with the Dataplex software, your frequently/recently used data is secure on the Synapse in the event of power loss or hardware failure. Since the “hot” data is a direct copy from your main storage on the HDD, you will not lose any data that has been recently accessed by Synapse. Does Synapse work in a RAID configuration? Synapse SSD can be installed as a cache for RAID configurations. Fault tolerance for the RAID array will be the same as before the use of the caching software. If the RAID array is configured as RAID1 or better, then you should not encounter any data loss if one or more HDDs fail. Can Synapse be used as a “regular” SSD? It is recommended to use the Synapse in conjunction with the Dataplex software for the full performance benefits of the product, but if the software is not installed then Synapse will act as a typical storage drive for files, OS, & applications within the set storage space. Even without the software installed, the Synapse will maintain 50% NAND flash overprovisioning built-in for performance optimization. Can the Synapse become “full” of data after prolonged used? 50% NAND overprovisioning ensures that the Synapse SSD will never be completely filled. Using the intelligent caching software, the Synapse SSD is self-maintaining & initiates a background cleaning process to remove infrequently used or older data from its cache. Synapse also features traditional TRIM support to work in conjunction with Windows 7. Why is only half the Synapse capacity accessible? The 50% NAND overprovisioning used on all Synapse models (translating into 32GB & 64GB cache capacities) is maintained as a performance feature to increase the lifespan of the drive, & accommodate the writing of “hot” user data. Since the Synapse acts as a cache for file/program copies vs. typical data storage, the “free” capacity will be sufficient to deliver the full benefits of Synapse for any personal usage pattern.

...

The industrys best SSDs just got better. Meet the storage expectations you didnt know you had. Engineered by longtime SSD experts, the OCZ Vector Series delivers a new level of untouchable performance, endurance, & reliability designed to empower your laptop or desktop to be all it can be. There is a faster, more responsive computing experience inside this box. Imagine faster file transfers, quicker boot ups, & a computer that responds the way it was designed to (minus the hard drive) & youve got yourself a Vector SSD. Its a 2.5" solid state powerhouse. If you want lasting reliability, durability, & stealth operation, here it is. With groundbreaking SSD quality & technology in every drive, the Vector Series is built to provide years of hard drive-humiliating performance that is second to no other storage solution. Performance Sequential Read: 550MB/s Sequential Write: 400 MB/s 4k Random Write: 90, 000 IOPS 4k Random Read: 95, 000 IOPS Features Advanced suite of NAND flash management keeps your drive at higher sustained performance over long term for maximum endurance. Excels in both incompressible & compressible data types such as multimedia, encrypted data, ZIP files & software. Cutting-edge controller technology delivers maximum performance & delivers unmatched endurance without compression or loss of usable capacity, rated for 20GB/day of host writes for 5 years (typical client workloads). Bundled with a 3.5" desktop adapter bracket & Acronis True Image cloning software registration key (Windows compatible) to easily transfer data from your old hard drive. Sleek alloy housing offers slimmer 7mm z-height for compatibility with the latest thinner form factor notebooks.

Specification Usable capacity: 128GB NAND Components: Multi-Level Cell (MLC) NAND Flash Interface: Serial ATA (SATA) 6 Gb/s (SATA-III) Form Factor: 2.5", 7mm height Dimensions: 99.7 (L) x 69.75 (W) x 7mm (H) Operating & Storage Temperature: 0°C
- 55°C; 45°C
- 85°C Controller: Indilinx Barefoot 3 Performance Optimisations: TRIM, Idle Time Garbage Collection, SMART Monitoring, ECC Shock Resistance: Up to 1500G/0.5ms Operational Vibration: 2.17 Grms (7-800 Hz) Non-operational Vibration 16.3 Grms (20-2000 Hz) Certifications: Ro HS, CE, FCC, KCC, C-Tick, VCCI & BSMI Operating system compatibility: Windows, Linux, Mac OS X Warranty: 5 Year Manufacturer Warranty



...

Based on a cutting-edge architecture, Vertex 2 Solid State Drives raise the bar once again & deliver unprecedented performance for the complete gamut of gaming & professional multimedia applications. OCZ designed the Vertex 2 to surpass the competition where it counts most, pushing the limits in both sequential & random read/write rates. With spectacular performance in 4k file writes up to 50, 000 IOPS, these drives take productivity to the next level with over ten times the performance of the previous generation. Using the controller technology, Vertex 2 not only provides a faster, more responsive PC experience, but promotes cooler, quieter, & more energy efficient conditions compared to traditional mechanical hard drives. With sheer performance that outpaces the competition, the Vertex 2 doesnt lose sight of what makes an SSD the ideal storage alternative to hard drives & delivers the quality, reliability, & durability demanded by consumers that will not settle for anything but the best. Built with SATA 3 Gb/s, the Vertex 2 Series easily integrates into todays mobile & desktop platforms & features TRIM support to optimize performance over the drives lifespan as the ultimate Windows 7 notebook or desktop upgrade. ...

OCZ Agility 3 SATA III Solid State Drives are designed & built to provide an exceptional balance of performance & value. The ...

Based on a cutting-edge architecture, Vertex 2 solid state drives raise the bar once again & deliver unprecedented performance for the complete gamut of gaming & professional multimedia applications. OCZ designed the Vertex 2 to surpass the competition where it counts most, pushing the limits in both sequential & random read/write rates. Using the controller technology, Vertex 2 not only provides a faster, more responsive PC experience, but promotes cooler, quieter, & more energy efficient conditions compared to traditional mechanical hard drives. With sheer performance that outpaces the competition, the Vertex 2 doesnt lose sight of what makes an SSD the ideal storage alternative to hard drives & delivers the quality, reliability, & durability demanded by consumers that will not settle for anything but the best. ...

Octane SSDs are the worlds first SSD to achieve up to a 1TB capacity in a compact 2.5 inch format. Combining high-speed data transfer rates with record-breaking access times to provide a superior user experience & enhanced application performance, Octane leveraging the cutting-edge Indilinx Everest platform & optimized for the complete spectrum of file types & sizes, with proprietary page mapping algorithms mirroring real world conditions across a wide range of applications. The Octane series also

Includes:: advanced features unique to Indilinx, including latency reduction technology to enhance application responsiveness & enable features such as "fast boot" in consumer applications. First 1TB 2.5” solution on the market Delivers up to 32, 000 IOPS Bandwidth up to 460 MB/s Max Read: 460 MB/s Max Write: 330 MB/s 99.8mm x 69.63mm x 9.3mm Advanced technology to maximize endurance & lifespan Optimized for SATA 6 Gbps, unleashes the full potential of today’s leading platforms Proprietary page mapping algorithms for superior performance across all file sizes & mixed workloads TRIM support AES & Automatic Encryption to secure data Proprietary NDurance Technology to increase NAND lifespan Optimized for Write Latency Reduction

...

OCZ makes desktop upgrades easier than ever for cutting edge SSD users! The OCZ Solid State Drive 3.5" Adaptor Bracket 2 for 3.5" dock bays are the ideal solution to flawlessly integrate Solid State Drives into your desktop system. Brackets are optimized for OCZ's complete line of SSDs for maximum compatibility. If you have any queries or issues regarding setup or performance please contact OCZ HERE who will be willing to assist you. ...
