RDNA Architecture Engineered from the ground up with superior performance & power efficiency, RDNA is the architecture powering AMD’s 7nm gaming GPU, delivering 1.25 performance per clock compared to previous 14nm processors. VR Ready Certified to provide the performance required for a smooth experience in your VR adventures. MSI Afterburner The ultimate overclocking software with advanced control options & real-time hardware monitor. Radeon Free Sync TM Puts an end to choppy gameplay & broken frames with fluid, artifact-free performance at virtually any framerate. Multi GPU Support MSI graphics cards fully support multi-GPU setups using AMD Cross Fire technology on eligible GPUs.

Specification Model Name RADEON RX 5700 XT 8G Graphics Processing Unit AMD RADEON RX 5700 XT Interface PCI Express 4.0 Cores 2560 Units (40 CU) Core Clock Boost: Up to 1905 MHz Game: 1755 MHz Base: 1605 MHz Memory Speed 14 Gbps Memory 8GB GDDR6 Memory Bus 256-bit Output Display Port x 3 (v 1.4) / HDMI 2.0b x 1 HDCP Support 2.2 Power consumption 225 W Power connectors 8-pin x 1 + 6-pin x 1 Recommended PSU 650 W Card Dimension (mm) 270x 110 x 40 mm Weight (Card / Package) 1110 g / 1549 g Direct X Version Support 12 API Open GL Version Support 4.5 Maximum Displays 4 VR Ready Y Free Sync TM technology Y Digital Maximum Resolution 7680 x 4320

...

MSI Radeon HD 7950 3GB GDDR5 DVI HDMI Display Port Graphics Card Key

Features: Twin Frozr III Thermal Design:

...

MSI Radeon R9 290X 4GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". Thats why we bring you the best of the best. We dont want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Graphics Engine
- AMD Radeon R9 290X Interface
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 4096 Memory Interface
- 512 bits Core Clock Speed (MHz) 1040 M Hz Core (OC mode) 1030 M Hz Core (Gaming mode) 1000 M Hz Core (Silent mode) Memory Clock Speed (MHz)
- 5000 DVI Output
- 2 (Dual-link DVI-D) HDMI-Output
- 1 (version 1.4a) Display Port
- 1 HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output (Max Resolution)
- 2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11.2 Open GL Version Support
- 4.3 Cross Fire Support
- Y, 4-ways (SW) Card Dimension (mm)
- 276x 127x 39mm

















...

MSI Radeon R9 390 Gaming 8GB GDDR5 Dual-Link DVI-D HDMI Display Port PCI-E Graphics card Next-Gen Thermal Design: Twin Frozr V Torx Fan Maximizes airflow & dispersion. Super Pipe Improves dissipation through efficient heatpipelayout. Zero Frozr Fans stop spinning in low load to keep the card quiet & increase lifetime. Airflow Control technology Deflects airflow towards heatpipesto improve thermal efficiency. Gaming App Easy Tuning–OC, Gaming & Silent modes adjust Graphics Card settings based on user requirements. Eye Rest: Dedicated color profiles for Gaming, movies & Eye Rest, allow to custom visual related setting what you like. LED control choose from 5 unique lighting modes to set the right ambience for their gaming moments with just one click Military Class 4 Components Certified to MIL-STD-810G standards for top stability & quality. Built with Hi-c CAP, Solid CAP, & New SFC components. Product

Specification Model Name
- R9 390 GAMING 8G GPU
- AMD Radeon™ R9 390 Codename
- Grenada PRO Processors
- 2560 Units Core Clock (OC)
- 1060 MHz Memory Clock (OC)
- 6100 MHz Memory Size
- 8GB GDDR5 Memory Bus
- 512 bits Output
- Display Port/HDMI DL-DVI-D x 2 Power Consumption/ Connector
- 275 W / 6-pin x 1, 8-pin x 1 Dimension / Weight
- 277x 129x 51 mm / 1312g Form Factor
- ATX Technology Support Afterburner OC
- GPU Direct X
- 12 Open GL
- 4.4 Multi-GPU
- Cross Fire TM Multi-Display
- Eyefinity 3D Technology
- HD3D Power Saving
- Power Tune HDCP Capable
- Yes





















...

. rm-cont h 2, . rm-row h 2{margin:0 0 10px}.u 1, . u 1-2{float:left}.rm-row{
Width:725px;overflow:hidden;padding:30px 0;border-bottom:1px
...

. rm-cont h 2, . rm-row h 2{margin:0 0 10px}.u 1, . u 1-2{float:left}.rm-row{
Width:725px;overflow:hidden;padding:30px 0;border-bottom:1px
...

Features Core/ Memory Boost Clock / Memory Frequency 1203 MHz / 6000 MHz 2GB GDDR5 All Solid Capacitors 10 years long lifetime under full load. Lower temperature & higher efficiency. Aluminum core for higher stability. Afterburner Overclocking Utility Wireless control through Android/i OS devices. Predator: In-game video recording. Kombustor: built-in Direct X12 benchmark. AMD Eyefinity Makes games more immersive by enabling you to play across multiple screens for an eye-popping gaming experience. AMD Free Sync™ Synchronizes the display refresh to your Radeon RX Series GPU for the fast, smooth gaming. Overview DEMAND MORE, DEMAND RADEON Guiding the Future of Gaming The 4th generation GCN architecture is engineered for gamers who play anything from the latest MOBA’s to the most popular AAA titles. Asynchronous Shaders & an enhanced Geometry Engine power new levels of smooth gameplay performance. PERFECT IN ANY CASE The saying “ Good things come in small packages” is certainly true for AERO ITX cards. Thanks to its small form factor it will fit into virtually any case. Its compact size also means that its weight is dramatically less than that of a full-size graphics card. MILITARY CLASS 4 COMPONENTS One of the deciding factors in performance is the quality of the components used. That is why MSI only uses MIL-STD-810G certified components for AERO ITX cards. These components have proven durable enough to withstand the torturous circumstances of extreme gaming & overclocking for extended usage.

Specification Model Name Radeon™ RX 550 AERO ITX 2G OC Graphics Processing Unit Radeon™ RX 550 Interface PCI Express x 16 (uses x 8) Core Name Polaris 12 Cores 512 Units Core Clocks 1203 MHz Memory Clock Speed 6000 MHz Memory 2GB GDDR5 Memory Bus 128-bit Output Display Port (Version 1.4) / HDMI (Version 2.0) / DL-DVI-D HDCP Support 2.2 Recommended PSU 400 W Card Dimension (mm) 155 x 112 x 38 mm Weight (Card / Package) 285 g / 509 g Afterburner OC Y Direct X Version Support 12 Open GL Version Support 4.5 Maximum Displays 3

...

Features TORX FAN 3.0 Award-winning fan design combining two different fan designs for cool & quiet gaming. SOLID BACKPLATE Increases toughness of the card to prevent bending while complementing the design. ZERO FROZR Eliminates fan noise by stopping the fans in low-load situations so you can focus on your game. MASTERY OF AERODYNAMICS Using ground breaking aerodynamic techniques, the heatsink is optimized for efficient heat dissipation. CUSTOM PCB An optimized PCB design with enhanced power delivery provides a solid base for high performance gaming. DRAGON CENTER A consolidated platform that offers all software including MYSTIC LIGHT functionality for your MSI Gaming product. ...

Key Features EXPERIENCE POWERFUL, ACCELERATED GAMING Introducing the AMD Radeon RX 5500 XT Mech OC Graphics Card, powered by the all advanced 7nm RDNA Architecture taking 1080p gaming to all new heights giving you, ultra-responsive, high fidelity triple A gaming with up to 60 Frames/sec & e Sports gaming with up to 90 Frames/sec & with all new compute units you can expect even higher levels of performance & optimised visual effects such as volumetric lighting, blur effects & multi-level cache hierarchy for reduced latency & faster response times, sounds great right? This is accelerated gaming customised for you. Reduces latency & provides higher bandwidth Powered by the groundbreaking 7nm RDNA architecture with Radeon™ Image Sharpening & Radeon™ Anti-Lag technology, Radeon RX 5500 XT GPU delivers extremely efficient, ultra-responsive, high-fidelity gaming for immersive explosions, physics, & lighting effects, bringing realism to life. Take your gaming experience to the next level. You can experience stutter-free, tear-free gaming, reduced input latency & day-0 drivers optimized for new game releases. Super-fast performance for todays demanding titles Equipped with 8GB of advanced GDDR6 memory to provide high bandwidth of up to 224 GB/s, enabling 1080p performance for today’s most demanding games. Radeon RX 5500 XT features PCI Express 4.0 support, which enables two times the bandwidth compared to PCI Express 3.0. Get ready for the next generation of PC gaming. Award winning COOLING PERFORMANCE MSI are bringing the award-winning TORX Fans 3.0 to the RX 5500 XT Mech cards to provide the ultimate cooling performance as the dual fan blades work coherently to optimize efficient airflow which in return helps you obtain the best possible gaming experience. 6mm Copper Heat-pipes & Thermal Padding AMD Radeon RX 5500 XT Mech Graphics Card features fantastic cooling solutions with a large surface area & six direct touch copper heat-pipes that are positioned in an optimised layout to increase overall cooling efficiency this is then further reinforced via the use of large thermal pads to allow various components such as the VRAM to transfer heat to the heatsink for better cooling. ...

Features TORX FAN 3.0 Award-winning fan design combining two different fin designs for cool & quiet gaming. SOLID BACKPLATE Increases toughness of the card to prevent bending while complementing the design. OC PERFORMANCE MSI OC graphics cards are equipped with higher clock speeds out of the box for increased performance. CUSTOM PCB An optimized PCB design with enhanced power delivery provides a solid base for high performance gaming. MSI AFTERBURNER The ultimate overclocking software with advanced control options & real-time hardware monitor. VR READY Certified to provide the performance required for a smooth experience in your VR adventures. AMD Free Sync TM Puts an end to choppy gameplay & broken frames with fluid, artifact-free performance at virtually any framerate. ...
