Unlocked Digital Power
- Unlocked BIOS: One click to unlock all protections for extreme overclocking.
- Digital PWM Controller:

...

Afterburner Overclocking Utility Support in-game video recording Support wireless control by android/i OS hand held devices Support built-in DX11 effect test Support multi-card control GPU Boost 2.0 Technology Ensure the GPU runs at its peak & the game is at its highest frame rate possible Offer new levels of customisation including GPU temperate target, overclocking & unlocked voltage 3D Vision Surround Support 3 displays in full stereoscopic 3D with a single card Support up to 4 displays with a single card for multifunction All Solid Capacitors Lower temperature & higher efficiency Aluminium core without explosion NVIDIA Ge Force Experience one-click drivers & settings (tm) Get the best gaming, with NVIDIA Ge Force Experience (tm) one-click drivers & settings.

Specification
- Model NAme
- N780-3GD5
- GPU
- Nvidia Gefore GTX 780
- CUDA Core
- 2304 Units
- Core Base CLock
- 863 M Hz
- Core Boost Clock
- 902 M Hz
- Memory Clock
- 6008 M Hz
- Memory Size
- 3072MB GDDR5
- Memory Bus
- 384 bits
- Output
- Display Port; HDMI; DL-DVIx 2
-

Dimensions
- 267x 98x 39mm
- Form Factor
- ATX Technology Support
- Direct X
- 11.1API
- Open GL – 4.3
- PCI Express – 3.0
- CUDA – Yes
- SLI – Yes, 3-way SLI
- Phys X – Yes
- Pure Video HD – Yes
- HDCP – Yes


































...

MSI GTX 780 3GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". Thats why we bring you the best of the best. We dont want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Graphics Engine
- NVIDIA Ge Force GTX 780 Bus Standard
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 3072 Memory Interface
- 384 bits Core Clock Speed (MHz)
- 954 (Boost Clock: 1006) (OC mode) Memory Clock Speed (MHz)
- 6008 DVI Output
- 2 (Dual-link DVI-I x 1, Dual-link DVI-D x 1) HDMI-Output
- 1 (version 1.4a) Display Port
- 1 (version 1.2) HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output (Max Resolution)
- 2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11.1 API (feature level 11_0) Open GL Version Support
- 4.3 SLI Support
- Y 3-way SLI
- Y Card Dimension (mm)
- 266x 129x 38 mm The new Ge Force GTX 780 marks an evolution in gaming performance—an insanely fast, smooth, & whisper-quiet experience. It’s perfectly tuned to today’s most advanced gaming technologies with Ge Force Experience for one-click driver & setting optimisation, plus NVIDIA Phys X & TXAA for smooth, sharp graphics. With GTX 780, experience pure performance. MSI Exclusive Features Twin Frozr IV Thermal Design MSIs Twin Frozr is the industry defining graphics card cooler. The first Twin Frozr kicked off the dual-fan trend & today MSI stays true to its dual-fan dual-slot design where others have to resort to less effective methods. The Twin Frozr cooler uses a large Aluminium fin grid array that provides a huge amount of surface area for cooling. Heat from the GPU is transferred to the fin grid array by virtue of heat pipes with MSIs special Super Pipe technology. Super Pipes transfer heat twice as fast as regular heat pipes enabling an MSI GAMING graphics card to stay cooler than the competition. Furthermore, MSI provide all new Airflow Control technology on Twin Frozr IV. This new thermal technology leads the airflow to the heat pipes via a special deflector on the heatsink, so it can deflect more airflow to heat pipes directly. In addition, This exclusive heatsink design increases the area of the heatsink enhancing the heat dissipation. Military Class 4 Components One of the deciding factors in performance is the quality of the components used. That is why MSI only uses MIL-STD-810G certified components for its Gaming cards because only these components have proven to be able to withstand the torturous circumstances of extreme gaming & overclocking. Gaming App Tune up core clock speed & fan speed with Gaming Mode for the ultimate gaming performance. Switch to Eco Mode to reduce core clock speed & fan speed for a discrete setting that reduces noise & power consumption. Switch to Default Mode for factory settings & performance. Predator App Predator is a built-in screen & video capturing tool which captures your screen as still images or videos with the push of a button & means that you can capture & record your coolest, goofiest & most awesome gaming moments on your PC! MSI Afterburner Utility MSI Afterburner has quickly become the favourite overclocking software for media, overclockers & end-users. Because of its simple interface, its easy to learn, but it packs a lot of powerful features like an integrated benchmark utility called Kombustor that can check your system performance in benchmarking mode, or run as a stability test. NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA G-SYNC Technology NVIDIA G-SYNC is a groundbreaking new innovation that casts aside decades-old thinking to create the smoothest, most responsive computer displays ever seen. A monitor module you can install yourself, or buy pre-installed in gamer-focused monitors, NVIDIA G-SYNC waves goodbye to the days of screen tearing, input lag, & eyestrain-inducing stuttering caused by decades-old tech lazily carried over from analog TVs to modern-day monitors. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 760s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.



















...

GPU Boost 2.0 Technology Ensures the GPU runs at its peak performance & games at their highest frame rate possible. Offer new levels of customization including GPU temperature target, overclocking, & unlocked voltage Product

Specification Product Name
- GTX 780 Ti 3GD5 GPU
- NVIDIA Ge Force GTX 780 Ti Codename
- GK 110 Processors
- 2880 Units Core Clock
- Base: 876 MHz Boost: 928 MHz Memory Clock
- 7000 MHz Memory Size
- 3G GDDR5 Memory Bus
- 384 bits Outputs
- Display Port / HDMI / DL-DVI-D / DL-DVI-I Power Consumption
- 250 W Card Dimension
- 263 x 111 x 41 mm Form Factor
- ATX













...

NOW YOURE GAMING WITH MSI. A graphics card is the single most important element for more FPS. As gamers, we understand that not just any graphics card "will do". Thats why we bring you the best of the best. We dont want to bug you with noise & heat, but we DO want to give you more performance. With MSI GAMING series graphics cards you get just that. Specifications Graphics Engine
- NVIDIA Geforce GTX 780 Ti Bus Standard
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size (MB)
- 3072 Memory Interface
- 384 bits 1020 M Hz Core (Boost Clock:1085 M Hz) (OC mode) 980 M Hz Core (Boost Clock:1046 M Hz) (Gaming mode) 876 M Hz Core (Boost Clock:928 M Hz) (Silent mode) Memory Clock Speed (MHz)
- 7000 DVI Output
- 2 (Dual-link DVI-I, Dual-link DVI-D) HDMI-Output
- 1 (version 1.4a) Display Port
- 1 HDCP Support
- Y HDMI Support
- Y Dual-link DVI
- Y Display Output (Max Resolution)
- 2560x 1600 RAMDACs
- 400 Direct X Version Support
- 11.2 API (feature level 11_0) Open GL Version Support
- 4.3 SLI Support
- Y 3-way SLI
- Y Card

Dimensions (mm)
- 266 x 129 x 38 mm Weight
- 782g NVIDIA Features NVIDIA Ge Force Experience Want to know the best settings to play your games? Ge Force Experience will figure it out for you. Ge Force Experience connects you to NVIDIA’s cloud datacenter to download optimal game settings tailored to your PC based on your CPU, GPU & monitor. Optimal settings maximize image quality while maintaining great performance so you get the best experience. A built-in interactive screenshot viewer helps you learn more about each setting & their benefits. The Ge Force Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you’ll be able to update the driver directly, without leaving your desktop. NVIDIA Kepler GPU Architecture NVIDIAs Kepler GPU architecture has been designed from the ground up not just for maximum performance in the latest Direct X 11 games, but optimal performance per watt. The new SMX streaming multiprocessor is twice as efficient as the prior generation & the new geometry engine draws triangles twice as fast. The result is world class performance & the highest image quality in an elegant & power efficient graphics card. NVIDIA TXAA Technology Film studios invest enormous resources in developing advanced technologies & post-production effects to deliver visually spectacular experiences for movie-goers. For games to achieve this level of fidelity, developers need new anti–aliasing technologies that deliver a viewing experience that eliminates the distraction of unrealistic, jagged lines (”jaggies”) & aliased shimmering–without compromising performance. NVIDIA is making this happen today, bringing cinema-quality graphics to life in blockbuster gaming titles with an innovative new temporal antialiasing technology called TXAA. Available exclusively on Ge Force GTX Kepler-powered GPUs, TXAA is designed to be directly integrated into game engines. Plus, it combines the raw power of MSAA (multi–sample anti–aliasing) with a temporal filter & sophisticated resolve filters similar to those used in CG films. The end result is a smoother, more lifelike image than any other comparable technique. NVIDIA FXAA Technology FXAA is a NVIDIA-developed post-processing technique that selectively blurs a game’s graphics to tackle unsightly jagged edges & high-contrast pixel deviation. Gaining popularity amongst developers due to its low performance impact & its ability to anti-alias transparent textures & details, FXAA is highly recommended for low-end & mid-range systems. NVIDIA G-SYNC Technology NVIDIA G-SYNC is a groundbreaking new innovation that casts aside decades-old thinking to create the smoothest, most responsive computer displays ever seen. A monitor module you can install yourself, or buy pre-installed in gamer-focused monitors, NVIDIA G-SYNC waves goodbye to the days of screen tearing, input lag, & eyestrain-inducing stuttering caused by decades-old tech lazily carried over from analog TVs to modern-day monitors. NVIDIA GPU Boost 2.0 Technology Up until now, GPUs have operated at a fixed clock speed when playing 3D games, even if they have the potential to run faster. GPU Boost intelligently monitors graphics work load & increases the clock speed whenever possible. The result is that the GPU always performs at its peak & you get the highest framerate possible. With NVIDIA GPU Boost 2.0 Enjoy new levels of customization with advanced controls like GPU temperature target, overclocking, & overvoltage. NVIDIA Adaptive V-Sync Technology Nothing is more distracting than framerate stuttering & screen tearing. The first tends to occur when framerates are low, the second when framerates are high. Adaptive V-Sync is a smarter way to render frames. At high framerates, V-sync is enabled to eliminate tearing, at low frame rates, its disabled to minimize stuttering. It gets rid of distractions so you can get on with gaming. NVIDIA Phys X Technology Phys X is designed specifically for hardware acceleration by powerful processors with hundreds of cores. Combined with the tremendous parallel processing capability of the GPU, Phys X will provide an exponential increase in physics processing power & will take gaming to a new level delivering rich, immersive physical gaming environments. NVIDIA CUDA Technology NVIDIA CUDA technology is the world’s only C language environment that enables programmers & developers to write software to solve complex computational problems in a fraction of the time by tapping into the many-core parallel processing power of GPUs. With millions of CUDA-capable GPUs already deployed, thousands of software programmers are already using the free CUDA software tools to accelerate applications—from video & audio encoding to oil & gas exploration, product design, medical imaging, & scientific research. NVIDIA Surround with up to 4 Monitors Nothing is as breathtaking as playing your favorite games across three monitors. At 5760 x 1080, the expanded field of view fully engages human peripheral vision & provides for the most immersive experience in racing & flight simulators. Add in a fourth display to keep tabs on chat, email or web while you are gaming. NVIDIA 3D Vision NVIDIA 3D Vision brings a fully immersive, stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. Get up to 2x monitor & keyboard brightness with NVIDIA 3D Light Boost technology. In addition, you can enjoy 3D movies & 3D digital photographs from 3 D Vision Live.com in eye popping, crystal-clear quality. NVIDIA SLI Technology Used by the most demanding gamers worldwide, SLI lets you link up to three Ge Force GTX 760s together for astounding performance. & with NVIDIA’s track record for fast & frequent software updates, you’ll not only get the best performance in existing games, but future games too.





















...

Specifications Graphics Engine
- NVIDIA Ge Force GTX 970 Bus Standard
- PCI Express x 16 3.0 Memory Type
- GDDR5 Memory Size


...

MSI GAMING Graphics Cards give you more performance out of the box. Whether it’s a pre-overclocked model or you use the Gaming App, you can just get right in the game & enjoy more performance. Overclocking through the MSI Gaming App is covered by warranty to take away your worries. Get in there & start winning! Twin Frozr V
- Cooler, Quieter, Better GAMING With every new generation of GPUs comes more performance. With every new generation of MSI Twin Frozr we give you less noise & heat!. We’ve listened to all your requests & the new Twin Frozr V is smaller, features stronger fans, generates less noise, keeps your graphics card & its components cooler & matches perfectly with your MSI GAMING motherboard including some funky LED lightning. Product

Specification Model Name
- GTX 980 GAMING 4G Model
- V317 GPU
- NVIDIA Ge Force GTX 980 Codename
- GM 204 Processors
- 2048 Units Core Base Clock (OC)
- 1216 M Hz Core Boost Clock (OC)
- 1317 M Hz Memory Clock
- 7010 MHz Memory Size
- 4GB GDDR5 Memory Bus
- 256 bit Outputs DL-DVI-I HDMI Display Port x 3 Power Consumption
- 178W Card Dimension
- 279x 140x 36 mm Form Factor
- ATX Technology Support Afterburner
- Voltage OC GPU Direct X
- 12 Open GL
- 4.4 Multi-GPU SLI
- 3-way Multi-Display Surround 3D Technology 3 D Vision Power Saving GPU Boost 2f.0 HDCP Capable
- Y




















...

MSI GTX TITAN Black 6GB GDDR5 Dual DVI HDMI Display Port PCI-E Graphics Card All Solid Capacitors 10 years long lifetime under full load. Lower temperature & higher efficiency. Aluminum core for higher stability. Product Specification: MKT name
- NTITAN Black 6GD5 GPUNVIDIA Ge Force GTX TITAN Black Codename GK 110 Processors 2880 Units Core Clock Base: 889 MHz Boost: 980 MHz Memory Clock
- 7000 MHz Memory Size 6GB GDDR5 Memory Bus
- 384 bits Bus Support
- PCI-E 3.0 Outputs Display Port / HDMI / DL-DVI-D / DL-DVI-I Power Consumption
- 250 W Card Dimension
- 267 x 111 x 35mm Form Factor
- ATX Technology Support Afterburner OC
- GPU Direct X
- 11.2 API (feature level 11_0) Open GL
- 4.4 Multi-GPU Technology
- SLI, 3-way Multi-Display Technology
- Surround 3D Technology
- 3 D Vision Power Saving Tech.
- GPU Boost 2.0 HDCP Capable
- Y














...

MSI GTX TITAN Z Dual DVI HDMI Display Port PCI-E Graphics card MKT name NTITANZ 12GD5 GPU NVIDIA Ge Force GTX TITAN Z Codename
-
...

Multi-task with up to 3 Monitors Expand the vision for extreme gaming experience. MSI innovative Matrix Display supports up to 2 external displays simultaneously through 1x HDMI port* & 1x Mini Display Port 1.2. Multi-task is made possible even during competitive gameplays. Connect the laptop to HDTV display, Matrix Display supports 4K output with a resolution up to 3840 x 2160. MSI Matrix Display technology creates an ideal environment for extreme gaming experience & pleasant multimedia entertainment. Dynamic Temperature / Performance Balancing The exclusive MSI “SHIFT” technology pushes system to the extreme while minimizing noise & temperature. Switch between different profiles either push your system to the extreme or in the pursuit of longer battery life. Easily activate it by pressing the FN + F7 hotkey combo, or via the Dragon Centre Cooler Boost 4 Enhanced Cooling Design for Higher Power Gaming Heat is the most original element on earth. Its pure physics that more energy will generate more heat. Cooling is therefore a knotty task to tackle with. MSI exclusive Cooler Boost 4 technology creates dual thermal modules internally by allocating dedicated heat pipes for GPU & CPU. One click on the fan boost button, a total of 6 heat pipes & dual fans actively & effectively push heat out of the system, making the cooling design the highest level of its kind. Processor Intel Core i 7-8750H 2.2 G Hz Turbo boost up to 4.1 G Hz 6 Cores 9MB Cache Memory 8GB DDR4 Storage 1TB HDD Optical Drive None Software Operating System: Windows 10 Home Display 15.6” LED Backlit Resolution 1920 x 1080 Full HD Graphics NVIDIA Ge Force GTX 1050 Audio 4x 2W Speaker Input Devices Keyboard & Touchpad Networking Wired: Gb LAN Wireless: 802.11 ac Wi-Fi Bluetooth v 5 Power Supply 6-Cell, 41 Whr battery 135W adapter

Dimensions Width 383 mm Depth 260 mm Height 22~29 mm Weight 2.2kg Interfaces 1x Type-C USB3.1 Gen 1 2x Type-A USB3.1 Gen 1 1x Type-A USB2.0 1x RJ45 1x SD (XC/HC) 1x (4K @ 30 Hz) HDMI 1x Mini-Display Port 1x Mic-in 1x Headphone-out (SPDIF)

...
