MSI B150A GAMING PRO Socket 1151 DVI HDMI 8-channel HD Audio Motherboard GAME IN STYLE MSI Performance GAMING motherboards deliver a polished gaming experience, whether you are racking up frags on the battlefield, questing for the latest unlocks or trying to level up your favorite gaming character. The Performance GAMING series motherboards offer a unique, customizable, design & distinguished look & feel with the best options tailored to gamers. SPECIFICATIONS CPU support Supports 6th Gen Intel Core / Pentium / Celeron Processors CPU socket LGA 1151 Chipset Intel B150 chipset Graphics interface 2 * PCI-E 3.0 x 16 slots, AMD Cross Fire„¢ support Display interface HDMI, DVI (Requires CPU Graphics) 4 DIMMs, Dual Channel DDR4-2133 Memory support Supports ECC memory, un-buffered memory Expansion slots 2 * PCI-E x 1 slots, 3 * PCI slots SATA 6 * SATA 6 Gb/s (2 ports reserved for SATA Express) USB (Universal Serial Bus) / IEEE 1394 2 * USB (Universal Serial Bus) 3.1 Gen 2, 6 * USB (Universal Serial Bus) 3.1 Gen 1, 4 * USB (Universal Serial Bus) 2.0 LAN Intel I219-V Gigabit LAN Audio 8-channel (7.1) HD Audio with Audio Boost 3 I/O OVERVIEW Gaming Device Port USB (Universal Serial Bus) 3.1 Gen 1 MSI GAMING LAN Audio connectors USB (Universal Serial Bus) 2.0 DVI Port USB (Universal Serial Bus) 3.1 Gen 2 HDMI Port USB (Universal Serial Bus) 3.1 Gen 1 Optical S/PDIF Out ...

MSI B150M BAZOOKA Socket 1151 HDMI DVI-D 8-channel Audio Motherboard Equip yourself with the MSI Arsenal GAMING series motherboards, packed with an arsenal of gaming features, to improve your game. Stable, high quality Military Class components, enhanced audio & LAN will make your gaming experience truly amazing. Arsenal GAMING motherboards ensure non-stop online gaming whether at home or at a LAN party. DDR4 BOOST By fully isolating the memory circuitry from other components, DDR4 Boost ensures the memory signal to stay pure for maximum performance & stability. AMBIENT LIGHT Arsenal GAMING motherboards come with a subtle ambient LED light on the back of the motherboard adding to the GAMING look & feel. AUDIO BOOST Audio Boost ensures you can enjoy true high quality sound when playing games, watching movies & listening to music. SPECIFICATIONS CPU support Supports 6th Gen Intel Core / Pentium / Celeron Processors CPU socket LGA 1151 Chipset Intel B150 Chipset Graphics interface 1* PCI-E 3.0 x 16 slot Display Interface HDMI, DVI “ Requires Processor Graphics Memory support 4 DIMMs, Dual Channel DDR4-2133 Expansion slots 2 * PCI-E x 1 slots M.2 / SATA 6 * SATA 6 Gb/s (2 ports reserved for SATA Express) USB (Universal Serial Bus) 6* USB (Universal Serial Bus) 3.1 Gen 1, 6 * USB (Universal Serial Bus) 2.0 LAN 10/100/1000 Mbps LAN Audio 8-channel (7.1) HD Audio I/O OVERVIEW Mouse port HDMI port DVI-D port LAN port Audio Connectors Keyboard port USB (Universal Serial Bus) 2.0 ports USB (Universal Serial Bus) 3.1 Gen 1 ports USB (Universal Serial Bus) 3.1 Gen 1 ports ...

MSI B150M ECO Socket LGA1151 VGA DVI-D HDMI 7.1-Channel HD Audio m-ATX Motherboard Specifications CPU Supports 6th Gen Intel Core i 3/i 5/i 7 processors, & Intel Pentium & Celeron processors for Socket LGA1151 Chipset: Intel B150 Chipset Main Memory 2 x DDR4 memory slots, support up to 32GB Supports DDR4 2133 MHz Dual channel memory architecture * Please refer www.msi.com for more information on compatible memory. Slots 1 x PCIe 3.0 x 16 slot 2 x PCIe 3.0 x 1 slots Onboard Graphics 1 x HDMI ports, support a maximum resolution of 4096x 2160@24 Hz, 2560x 1600@60 Hz Support for HDMI™ 1.4 version. 1 x DVI-D port, support a maximum resolution of 1920x 1200@60 Hz 1 x VGA port, supports a maximum resolution of 2048x 1536@50 Hz, 2048x 1280@60 Hz, 1920x 1200@60 Hz On-Board SATA Intel B150 Chipset 6 x SATA 6 Gb/s ports USB (Universal Serial Bus) Intel B150 Chipset 6 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connector) 4 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (available through the internal USB (Universal Serial Bus) connectors) Audio Realtek ALC887 Codec 7.1-Channel High Definition Audio LAN: 1 x Intel I219V Gigabit LAN controller Back Panel I/O Ports 1 x PS/2 keyboard port 1 x PS/2 mouse port 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports 1 x DVI-D port 1 x HDMI port 1 x VGA port 1 x LAN (RJ45) port 3 x audio jacks Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 6 x SATA 6 Gb/s connectors 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports) 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (supports additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) 1 x 4-pin CPU fan connector 2 x 4-pin system fan connectors 1 x Front panel audio connector 2 x Front panel connectors 1 x TPM module connector 1 x Serial port connector 1 x Parallel port connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper Dimension: 9.6 in. x 8.1 in. (24.3 cm x 20.6 cm) m-ATX Form Factor Mounting: 6 mounting holes ...

MSI B150M MORTAR Socket LGA 1151 VGA DVI HDMI 8-channel HD Audio Motherboard Get ready to crush your enemies on the battlefield with MSI GAMING LAN. Featuring carefully selected components & smart bandwidth management software that automatically prioritizes games above other applications, to ensure the best online gaming experience without lag. Equip yourself with the MSI Arsenal GAMING series motherboards, packed with an arsenal of gaming features, to improve your game. Stable, high quality Military Class components, enhanced audio & LAN will make your gaming experience truly amazing. Arsenal GAMING motherboards ensure non-stop online gaming whether at home or at a LAN party. DDR4 BOOST By fully isolating the memory circuitry from other components, DDR4 Boost ensures the memory signal to stay pure for maximum performance & stability. AMBIENT LIGHT Arsenal GAMING motherboards come with a subtle ambient LED light on the back of the motherboard adding to the GAMING look & feel. AUDIO BOOST Audio Boost ensures you can enjoy true high quality sound when playing games, watching movies & listening to music. SPECIFICATIONS CPU support: Supports 6th Gen Intel Core / Pentium / Celeron Processors CPU socket: LGA 1151 Chipset: Intel B150 Chipset Graphics interface: 2* PCI-E 3.0 x 16 slots Display Interface: HDMI, DVI, VGA“ Requires Processor Graphics Memory support: 4 DIMMs, Dual Channel DDR4-2133 Expansion slots: 1 * PCI-E x 16 slot, 2 * PCI-E x 1 slots M.2 / SATA: 6 * SATA 6 Gb/s (2 ports reserved for SATA Express) SATA RAID: RAID 0, 1, 5, 10 “ Available on SATA1 to SATA6 USB: 6* USB (Universal Serial Bus) 3.1 Gen 1, 6 * USB (Universal Serial Bus) 2.0 LAN: 10/100/1000 Mbps LAN Audio: 8-channel (7.1) HD Audio ...

MSI B150M MORTAR Socket LGA1151 VGA DVI-D HDMI 7.1-Channel HD Audio M-ATX Motherboard Specifications CPU Supports 6th Gen Intel Core i 3/i 5/i 7 processors, & Intel Pentium & Celeron processors for Socket LGA1151 * Please refer to CPU Support for compatible CPU; the above description is for reference only. Chipset: Intel B150 Chipset Main Memory 4 x DDR4 memory slots, support up to 64GB Supports DDR4 2133 MHz Dual channel memory architecture Supports ECC, un-buffered memory ECC UDIMM memory (non-ECC mode) Supports Intel Extreme Memory Profile (XMP) * Please refer to Compatibility reports for more information of compatible memory. * Hyper DIMM support is subject to the physical characteristics of individual CPUs * DDR4 2133 MHz & higher memory modules will only run at maximum of DDR4 2133 MHz on XMP mode due to Intel chipset limitation Slots 2 x PCIe 3.0 x 16 slots (support x 16/x 4)* 2 x PCIe 3.0 x 1 slots 1 x M.2 Key E Socket supports type 2242 Wi-Fi devices * The PCI_E4 slot will only run PCIe 3.0 x 2 speed when the PCI_E3 slot is installed a device. Onboard Graphics 1 x HDMI™ ports, support a maximum resolution of 4096x 2160@24 Hz, 2560x 1600@60 Hz Support for HDMI™ 1.4 version. 1 x VGA port, supports a maximum resolution of 2048x 1536@50 Hz, 2048x 1280@60 Hz, 1920x 1200@60 Hz 1 x DVI-D port, supports a maximum resolution of 1920x 1200 @60 Hz Multi-GPU: Supports 2-Way AMD Cross Fire™ Technology On-Board SATA Intel B150 Chipset 6 x SATA 6 Gb/s ports 1 x SATAe port* * SATAe port is backward compatible with SATA. USB (Universal Serial Bus) Intel B150 Chipset 6 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connectors) 4 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connectors) Audio Realtek ALC892 Codec 7.1-Channel High Definition Audio Supports S/PDIF output LAN 1 x Realtek RTL8111H Gigabit LAN controller 1 x M.2 Key E Socket supports type 2230 Wi-Fi devices Back Panel I/O Ports 1 x PS/2 keyboard/ mouse combo port 2 x USB (Universal Serial Bus) 2.0 ports 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports 1 x VGA port 1 x HDMI port 1 x DVI-D port 1 x LAN (RJ45) port 1 x Clear CMOS button 1 x Optical S/PDIF OUT connector 5 x OFC audio jacks Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 6 x SATA 6 Gb/s connectors 1 x USB (Universal Serial Bus) 3.1 Gen 1 connectors (support additional 2 USB3.1 Gen 1 ports) 1x USB (Universal Serial Bus) 2.0 connector (supports additional 2 USB (Universal Serial Bus) 2.0 ports) 1 x 4-pin CPU fan connector 2 x 4-pin system fan connectors 1 x Clear CMOS jumper 1 x Front panel audio connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Serial port connector Dimension: 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm) M-ATX Form Factor Mounting: 8 mounting holes ...

MSI B150M PRO-VDH Socket LGA 1151 VGA DVI HDMI 8-channel HD Audio Motherboard Making your life easier is our business The PRO Series motherboards fit in any PC. Quality you can trust with top performance & clever business solutions are key aspects of these motherboards. Make your life easier & boost your business with the super stable, reliable & long-lasting PRO Series motherboards. SPECIFICATIONS CPU support: 6th Gen Intel Core / Pentium / Celeron processors CPU socket: LGA 1151 Chipset: Intel B150 Chipset Graphics interface: 1 * PCI-E 3.0 x 16 Display interface: HDMI, DVI-D, VGA “ Requires Processor Graphics Memory support: 4 DIMMs, Dual Channel DDR4-2133 MHz Expansion slots: 2 * PCI-E x 1 SATA: 6 * SATA 6 Gb/s (2 x ports from SATA Express port) USB: 6 * USB (Universal Serial Bus) 3.1 Gen 1, 6 * USB (Universal Serial Bus) 2.0 LAN: Realtek Gigabit Ethernet Audio: 8-channel (7.1) HD Audio with Audio Boost Others: COM / LPT pin header ...

Features Supports 7th / 6th Gen Intel Core™ / Pentium / Celeron processors for LGA 1151 socket Supports DDR4-2400 Memory (Max.) DDR4 Boost: Give your DDR4 memory a performance boost VR Ready: Best virtual reality game experience without latency Mystic Light Sync: Synchronize other RGB solutions with your gaming rig & control all LEDs in one click Twin Turbo M.2 with Steel Armor. Intel Optane Memory Ready, Lightning USB (Universal Serial Bus) 3.1 Gen 2 Audio Boost 4 with Nahimic 2: Reward your ears with studio grade sound quality for the most immersive gaming experience GAMING LAN with LAN Protect, powered by Killer™: The best online gaming experience with lowest latency & bandwidth management Military Class 5, Guard-Pro: Latest evolution in high quality components for best protection & efficiency MULTI-GPU: With Steel Armor PCI-E slot. Supports AMD Crossfire™ In-Game Weapons: GAMING Hotkey, X-Boost, Xsplit Gamecaster EZ Debug LED: Easiest way to troubleshoot Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites & search function GAMING CERTIFIED: 24-hour on- & offline game & motherboard testing by e Sports players

Specification CPU Supports 6th/7th Gen Intel Core™ i 3/i 5/i 7 processors, & Intel Pentium & Celeron processors for Socket LGA1151 * This function will be supported depend on the CPU. Chipset Intel B250 Chipset Main Memory 4 x DDR4 memory slots, support up to 64GB
- 7th Gen processors support DDR4 2400/ 2133 MHz*
- 6th Gen processors support DDR4 2133 MHz* Dual channel memory architecture Supports Intel Extreme Memory Profile (XMP) * Please refer www.msi.com for more information on compatible memory. Slots 2 x PCIe 3.0 x 16 slots (supports x 16/x 4 mode)* 4 x PCIe 3.0 x 1 slots * The PCI_E4 slot will be unavailable when an M.2 SSD module has been installed in the M.2_2 slot. * The PCI_E2 slot will be unavailable when an expansion card has been installed in the PCI_E5 slot. * The PCI_E3 slot will be unavailable when an expansion card has been installed in the PCI_E6 slot. Multi-GPU Supports 2-Way AMD Cross Fire™ Technology Onboard Graphics 1 x HDMI™ port, supports a maximum resolution of 4096x 2160@30 Hz (7th CPU), 4096x 2160@24 Hz (6th CPU), 2560x 1600@60 Hz 1 x DVI-D port, supports a maximum resolution of 1920x 1200@60 Hz Storage Intel B250 Chipset 6 x SATA 6 Gb/s ports* 2x M.2 slots (Key M)
- Support up to PCIe 3.0 x 4 & SATA 6 Gb/s
- Support PCIe 3.0 x 4 NVMe U.2 SSD with Turbo U.2 Host Card**
- M2_1 slot supports 2242/ 2260 /2280/ 22110 storage devices
- M2_2 slot supports 2242/ 2260 /2280 storage devices
- Intel Optane™ Memory Ready for all M.2 slots Supports Intel Smart Response Technology for Intel Core™ processors (optional) * M.2 & SATA ports maximum support 2x M.2 PCIe SSDs + 6x SATA HDDs. ** The Turbo U.2 Host Card is not included, please purchase separately. USB (Universal Serial Bus) ASMedia ASM1142 Chipset
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 (Super Speed USB (Universal Serial Bus) 10 Gbps) Type-C port on the back panel
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 (Super Speed USB (Universal Serial Bus) 10 Gbps) Type-A port on the back panel Intel B250 Chipset
- 6 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connector)
- 6 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connector) Audio Realtek ALC1220 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output LAN 1 x Killer™ E2500 Gigabit LAN controller Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6 Gb/s connectors
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 connectors (supports additional 4 USB (Universal Serial Bus) 3.1 Gen 1 ports)
- 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin water pump fan connector
- 4 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x LED connector
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial connector
- 1 x Clear CMOS jumper Back Panel I/O Ports
- 1 x PS/2 keyboard/ mouse combo port
- 2 x USB (Universal Serial Bus) 2.0 Type-A ports
- 1 x DVI-D port
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-C port
- 2x USB (Universal Serial Bus) 3.1 Gen 1 Type-A ports
- 1 x HDMI™ port
- 1 x LAN (RJ45) port
- 5 x OFC audio jacks
- 1 x Optical S/PDIF OUT connector Dimension 12 in. x 9.6 in. (30.4 cm x 24.3 cm) ATX Form Factor Mounting 9 mounting holes







































...

Features Supports 7th / 6th Gen Intel Core™ / Pentium / Celeron processors for LGA 1151 socket Supports DDR4-2400 Memory (Max.) DDR4 Boost: Give your DDR4 memory a performance boost VR Ready: Best virtual reality game experience without latency Lightning Fast Game experience: Twin Turbo M.2, Intel Optane Memory Ready, Lightning USB (Universal Serial Bus) 3.1 Gen 2 Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience GAMING LAN with LAN Protect, powered by Intel: The best online gaming experience with lowest latency & bandwidth management Military Class 5, Guard-Pro: Latest evolution in high quality components for best protection & efficiency MULTI-GPU: With Steel Armor PCI-E slot. Supports AMD Crossfire™ Mystic Light Sync: Synchronize other RGB solutions with your gaming rig & control all LEDs in one click In-Game Weapons: GAMING Hotkey, X-Boost, Xsplit Gamecaster EZ Debug LED: Easiest way to troubleshoot Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites & search function GAMING CERTIFIED: 24-hour on- & offline game & motherboard testing by e Sports players Specifications CPU Supports 7th/6th Gen Intel Core™ i 3/i 5/i 7 processors, & Intel Pentium & Celeron processors for Socket LGA1151 * This function will be supported depend on the CPU. Chipset Intel B250 Chipset Main Memory 4 x DDR4 memory slots, support up to 64GB
- 7th Gen processors support DDR4 2400/ 2133 MHz*
- 6th Gen processors support DDR4 2133 MHz* Dual channel memory architecture Supports Intel Extreme Memory Profile (XMP) * Please refer www.msi.com for more information on compatible memory. * DDR4 memory modules can only run at maximum of 2400 MHz for 7th Gen processors & 2133 MHz for 6th Gen processors on XMP mode. Slots 3 x PCIe 3.0 x 16 slots (support x 16/x 4/x 1 modes) 3 x PCIe 3.0 x 1 slots * The PCI_E4 slot will be unavailable when an M.2 PCIe SSD module has been installed in the M2_2 slot. ** The PCI_E2/ PCI_E5 slot will be unavailable when an expansion card has been installed in the PCI_E3/ PCI_E6 slot. Onboard Graphics 1 x HDMI™ port, supports a maximum resolution of 4096x 2160@30 Hz (7th Gen CPU), 4096x 2160@24 Hz (6th Gen CPU), 2560x 1600@60 Hz 1 x DVI-D port, supports a maximum resolution of 1920x 1200@60 Hz Multi-GPU Supports 2-Way AMD Cross Fire™ Technology Storage Intel B250 Chipset 6x SATA 6 Gb/s ports* 2x M.2 slots (Key M)
- Support up to PCIe 3.0 x 4 & SATA 6 Gb/s
- Support PCIe 3.0 x 4 NVMe U.2 SSD with Turbo U.2 Host Card**
- M2_1 slot supports 2242/ 2260 /2280/ 22110 storage devices
- M2_2 slot supports 2242/ 2260 /2280 storage devices
- Intel Optane™ Memory Ready for M2_2 slot*** Supports Intel Smart Response Technology for Intel Core™ processors * M.2 & SATA ports combination details please refer user manual. ** The Turbo U.2 Host Card is not included, please purchase separately. *** Intel Optane™ Technology is only supported when using 7th Gen processors. Before using Intel Optane™ memory modules, please ensure that you have updated the drivers & BIOS to the latest version from MSI website. USB ASMedia ASM2142 Chipset
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 (Super Speed USB (Universal Serial Bus) 10 Gbps) Type-C port on the back panel ƒ- 1 x USB (Universal Serial Bus) 3.1 Gen 2 (Super Speed USB (Universal Serial Bus) 10 Gbps) Type-A port on the back panel Intel B250 Chipset
- 6 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connectors)
- 6 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connectors) Audio Realtek ALC892 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output LAN 1 x Intel I219-V Gigabit LAN controller Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6 Gb/s connectors
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 connectors (supports additional 4 USB (Universal Serial Bus) 3.1 Gen 1 ports)
- 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin water pump fan connector
- 4 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x RGB LED connector
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Parallel port connector
- 1 x Clear CMOS jumper Back Panel I/O Ports
- 1 x PS/2 keyboard/ mouse combo port
- 2 x USB (Universal Serial Bus) 2.0 Type-A ports
- 1 x DVI-D port
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-C port
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 Type-A ports
- 1 x HDMI™ port
- 1 x LAN (RJ45) port
- 5 x OFC audio jacks
- 1 x Optical S/PDIF OUT connector Dimension 12 in. x 9.6 in. (30.4 cm x 24.3 cm) ATX Form Factor Mounting 9 mounting holes





































...

Features Supports 7th / 6th Gen Intel Core™ / Pentium / Celeron processors for LGA 1151 socket Supports DDR4-2400 Memory DDR4 Boost: Give your DDR4 memory a performance boost Audio Boost: Reward your ears with studio grade sound quality for a HI-FI experience EZ Debug LED: Easiest way to troubleshoot Twin Turbo M.2: Delivering Speeds Up to 32 Gb/s, Intel Optane Memory Ready Lightning USB: Double bandwidth, supports USB (Universal Serial Bus) 3.1 Gen 2 Type A + Type C X-Boost: Great tool to boost your USB (Universal Serial Bus) & Storage performance Double ESD Protection: Double layer grounding motherboard mounting holes Military Class 5, Guard-Pro: Latest evolution in high quality components for best protection & efficiency Click BIOS: Secure & Reliable UEFI BIOS solution

Specification CPU Supports 6th/7th Gen Intel Core™ i 3/i 5/i 7 processors, & Intel Pentium & Celeron processors for Socket LGA1151 * This function will be supported depend on the CPU. Chipset Intel B250 Chipset Main Memory 4 x DDR4 memory slots, support up to 64GB
- 7th Gen processors support DDR4 2400/ 2133 MHz*
- 6th Gen processors support DDR4 2133 MHz* Dual channel memory architecture Supports Intel Extreme Memory Profile (XMP) * Please refer www.msi.com for more information on compatible memory. Slots 2 x PCIe 3.0 x 16 slots (supports x 16/x 4 mode)* 3 x PCIe 3.0 x 1 slots** 1 x PCI slot * The PCI_E4 slot will be unavailable when an M.2 PCIe SSD module has been installed in the M.2_2 slot. ** The PCI_E2/ PCI_E5 slot will be unavailable when an expansion card has been installed in the PCI_E3/ PCI1 slot. Onboard Graphics 1 x HDMI™ port, supports a maximum resolution of 4096x 2160@30 Hz (7th CPU), 4096x 2160@24 Hz (6th CPU), 2560x 1600@60 Hz 1 x DVI-D port, supports a maximum resolution of 1920x 1200@60 Hz 1 x VGA port, supports a maximum resolution of 2048x 1536@50 Hz, 2048x 1280@60 Hz, 1920x 1200@60 Hz Multi-GPU Supports 2-Way AMD Cross Fire™ Technology Storage Intel B250 Chipset 6 x SATA 6 Gb/s ports* 2 x M.2 slots (Key M)
- Support up to PCIe 3.0 x 4 & SATA 6 Gb/s
- Support PCIe 3.0 x 4 NVMe U.2 SSD with Turbo U.2 Host Card**
- M2_1 slot supports 2242/ 2260 /2280/ 22110 storage devices
- M2_2 slot supports 2242/ 2260 /2280 storage devices
- Intel Optane™ Memory Ready Supports Intel Smart Response Technology for Intel Core™ processors (optional) * M.2 & SATA ports maximum support 2x M.2 PCIe SSDs + 6x SATA HDDs. Please refer to the manual for M.2 slots with examples of various combination possibilities. ** The Turbo U.2 Host Card is not included, please purchase separately. USB (Universal Serial Bus) ASMedia ASM2142 Chipset
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 (Super Speed USB (Universal Serial Bus) 10 Gbps) Type-C port on the back panel ƒ- 1 x USB (Universal Serial Bus) 3.1 Gen 2 (Super Speed USB (Universal Serial Bus) 10 Gbps) Type-A port on the back panel Intel B250 Chipset
- 6 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connector) (optional)
- 6 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connector) Audio Realtek ALC887 Codec
- 7.1-Channel High Definition Audio LAN 1 x Intel I219-V Gigabit LAN controller Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6 Gb/s connectors
- 2 x USB (Universal Serial Bus) 2.0 connectors (support additional 4 USB (Universal Serial Bus) 2.0 ports)
- 1x USB (Universal Serial Bus) 3.1 Gen 1 connectors (support additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin water pump fan connector
- 4 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Parallel port connector
- 1 x TBT connector
- 1 x Clear CMOS jumper Back Panel I/O Ports
- 1 x PS/2 keyboard/ mouse combo port
- 2 x USB (Universal Serial Bus) 2.0 Type-A ports
- 1 x VGA port
- 1 x DVI-D port
- 1 x HDMI™ port
- 1 x LAN (RJ45) port
- 4 x USB (Universal Serial Bus) 3.1 Gen 1 Type-A ports
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-C port
- 3 x audio jacks Dimension 12 in. x 9.6 in. (30.4 cm x 24.3 cm) ATX Form Factor Mounting 9 mounting holes






































...

Features Supports 7th / 6th Gen Intel Core™ / Pentium / Celeron processors for LGA 1151 socket Supports DDR4-2400 Memory (Max.) DDR4 Boost: Give your DDR4 memory a performance boost VR Ready: Best virtual reality game experience without latency Lightning Fast Game experience: Turbo M.2, Intel Optane Memory Ready Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience GAMING LAN: The best online gaming experience with lowest latency & bandwidth management Military Class 4, Guard-Pro: Latest evolution in high quality components for best protection & efficiency Mystic Light Sync: Synchronize other RGB solutions with your gaming rig & control all LEDs in one click In-Game Weapons: GAMING Hotkey, X-Boost, Xsplit Gamecaster EZ Debug LED: Easiest way to troubleshoot Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites & search function GAMING CERTIFIED: 24-hour on- & offline game & motherboard testing by e Sports players

Specification CPU Supports 7th/ 6th Gen Intel Core™ i 3/i 5/i 7 processors, & Intel Pentium & Celeron processors for Socket LGA1151 * This function will be supported depend on the CPU. Chipset Intel B250 Chipset Main Memory 2 x DDR4 memory slots, support up to 32GB
- 7th Gen processors support DDR4 2400/ 2133 MHz*
- 6th Gen processors support DDR4 2133 MHz* Dual channel memory architecture Supports Intel Extreme Memory Profile (XMP) * Please refer www.msi.com for more information on compatible memory.s * DDR4 memory modules can only run at maximum of 2400 MHz for 7th Gen processors & 2133 MHz for 6th Gen processors on XMP mode. Slots 1 x PCIe 3.0 x 16 slots 1 x M.2 Wi-Fi/ Bluetooth module vertical slot (Key E) Storage Intel B250 Chipset 4 x SATA 6 Gb/s ports* 1 x M.2 slot (Key M slot on the bottom of the motherboard)
- Supports up to PCIe 3.0 x 4 & SATA 6 Gb/s
- Supports 2242/ 2260 /2280 storage devices
- Intel Optane™ Memory Ready * The SATA1 connector will be unavailable when an M.2 SATA SSD module has been installed in the M.2_2 slot. USB (Universal Serial Bus) Intel B250 Chipset
- 6 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connector) ƒ- 4 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) connector) Audio Realtek ALC887 Codec
- 7.1-Channel High Definition Audio WLAN & Bluetooth Wi-Fi/ Bluetooth expansion module with Intel Dual Band Wireless-AC 8265 chip
- Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4 G Hz, 5 G Hz) up to 867 Mbps speed.
- Supports Dual Mode Bluetooth 2.1, 2.1+EDR, 3.0, 4.0, BLE, 4.2 LAN 1 x Realtek RTL8111H Gigabit LAN controller Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 4-pin ATX 12V power connector
- 4 x SATA 6 Gb/s connectors
- 1 x USB (Universal Serial Bus) 2.0 connector (supports additional 2 USB (Universal Serial Bus) 2.0 ports)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (supports additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin system fan connector
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x LED connecotr
- 1 x Clear CMOS jumper Back Panel I/O Ports
- 1 x PS/2 keyboard/ mouse combo port
- 2 x USB (Universal Serial Bus) 2.0 Type-A ports
- 2 x antenna connectors
- 1 x DVI-D port
- 4 x USB (Universal Serial Bus) 3.1 Gen 1 Type-A ports
- 1 x HDMI™ port
- 1 x LAN (RJ45) port
- 3 x audio jacks Dimension 6.7 in. x 6.7 in. (17 cm x 17 cm) Mini-ITX Factor Mounting 4 mounting holes
































...
