7NM-TECHNOLOGY-POWERED PERFORMANCE Experience accelerated gameplay with the most advanced Ryzen processor & 7nm technology Radeon RX graphics. BUILT FOR 1080P HIGH REFRESH GAMING Intelligently allocates power & cooling between the processor & graphics, allowing higher performance & battery life efficiencies. SMOOTHEST GAMING EXPERIENCE WITH FREESYNC 120HZ DISPLAY Enjoy optimized frame rates with tearing-free, stutter-free visuals. MATRIX DISPLAY MULTI-TASK WITH UP TO 3 MONITORS Expand the vision across multiple display with HDMI & mini Display Port, & enjoy up to 4K (3840x 2160) resolution output at 60 Hz for some extra productivity & fun. 5 TIMES BIGGER THAN OTHERS LOUDER SOUND, MORE RESONANCE, & HIGHER QUALITY Gamers can feel every engine sound roaring past with the upgraded giant speakers. Exclusive audio module design & independent sound chamber for top-notch auditory sensation. ...

MSI AM1I Socket AM1 VGA DVI HDMI 8-channel (7.1) HD Audio Mini-ITX Motherboard Socket
- AM1 CPU (Max Support)
- AMD Socket AM1

...

Specifications CPU AMD Socket AM1 Athlon™ / Sempron™ Processors Please refer to CPU Support on MSI for compatible CPU; the above description is for reference only Main Memory 2 x DDR3 memory slots support up to 32GB Supports DDR3 1333/ 1600 MHz Single channel memory architecture Supports non-ECC, un-buffered memory * For the support status of AMP/XMP memory modules, please take MSI’s Memory Support list as reference * The Max. 32GB memory capacity can be supported with DIMMs of 16GB (or above). MSI will update Memory support list once the DIMMs are available on the market Remark: Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed Slots 1 x PCIe 2.0 x 16 slot, supports x 4 speed 2 x PCIe 2.0 x 1 slots Graphics 1 x VGA port, supporting a maximum resolution of 2048x 1280 1 x DVI-D port, supporting a maximum resolution of 1920x 1200 1 x HDMI port, supporting a maximum resolution of 4096x 2160 * Only supports dual-display function * HDMI port does not guarantee support to play for 4K video On-Board SATA 2 x SATA 6 Gb/s ports
- Supports storage & data transfers at up to 6 Gb/s Audio Chipset integrated by Realtek ALC887
- 7.1-Channel High Definition Audio LAN Supports Gigabit LAN by Realtek RTL8111G
- Supports 10 Mb/s, 100 Mb/s & 1000 Mb/s Back Panel I/O Ports 1 x PS/2 keyboard/mouse combo port 1 x VGA port 1 x DVI-D port 1 x HDMI port 2 x USB (Universal Serial Bus) 3.0 ports 4 x USB (Universal Serial Bus) 2.0 ports 1 x LAN (RJ45) port 3 x audio jacks Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 2 x SATA 6 Gb/s connectors 1 x USB (Universal Serial Bus) 3.0 connector (supports additional 2 USB (Universal Serial Bus) 3.0 ports) 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports) 1 x 3-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 1 x Serial port connector 1 x TPM connector 1 x System panel connector 1 x Chassis Intrusion connector 1 x Clear CMOS jumper * This platform supports dual-display function (HDMI+VGA, HDMI+DVI, VGA+DVI)

Dimensions Micro-ATX 22.6cm x 17.3cm 6 mounting holes




...

Features Supports AMD RYZEN Series processors & 7th Gen A-series / Athlon TM Processors for socket AM4 Support DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) Mhz DDR4 Boost: Give your DDR4 memory a performance boost VR Ready: Best virtual reality game experience without latency GAMING LEDs: Ambient LED lights for an awesome look & feel Lightning Fast Game experience: Turbo M.2 Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience GAMING LAN with LAN Protect: The best online gaming experience with lowest latency & bandwidth management Military Class 4, Guard-Pro: Latest evolution in high quality components for best protection & efficiency Mystic Light Sync: Synchronize other RGB solutions with your gaming rig & control all LEDs in one click In-Game Weapons: Game Boost, GAMING Hotkey, X-Boost EZ Debug LED: Easiest way to troubleshoot Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites & search function GAMING CERTIFIED: 24-hour on- & offline game & motherboard testing by e Sports players WHQL certified for Windows 10 Product Overview A320M BAZOOKA: Geared Up for Battle Mystic Light: Personalize Your Gaming Rig Customize & set up your own colour scheme with RGB Mystic Light sync. Select any of the colours from the palette using your smartphone or the MSI Gaming App to match your system style. Bored of the same colours? Simply change the complete look of your system in 1 second! Glowing with Pride This GAMING motherboard features LEDs on the back which provide a cool GAMING glow inside your case. Like war paint, turn them on for a more immersive gaming experience & amp yourself up, ready to dominate the battlefield. Extend Your RGB Experience with Ease MSIs Mystic Light Extension pin header provides an intuitive way to control additional RGB strips & other RGB peripherals added to a system, without needing a separate RGB controller. By simply connecting any 12V RGB LED strip to the 4-pin Mystic Light Extension RGB-strip header gamers can sync colours to any style they choose. Mystic Light Sync: Synchronize Your LED Experience With the convenience of Mystic Light Sync, you can control RGB LED solutions from other brands, such as CPU coolers, keyboards & mice or RGB system fans. Get Started with Mystic Light To use Mystic Light, download the latest version of the MSI Gaming App below. For remote control of Mystic Light, simply download the latest version of the Mystic Light App for your smartphone from the Google Play Store or the App Store. Smartphone & PC Control Create your own colourful masterpiece with ease. The easy to use Gaming APP is available on PC, phone & tablet. It offers remote control, simply using your smartphone or tablet. Make your PC look & feel brand new with any colour you want with just a few clicks! Cooling: Stay Cool While Gaming Cooling your PC is essential for reliable performance. Weve made sure to include enough fan headers with full control to allow you to cool your system any way you want. Fully Controllable Fan Headers MSI motherboards let you manage speeds & temperatures for all your system & CPU fans, giving you full control to set up a cool & silent system. The fan headers are conveniently placed with the most popular CPU coolers in mind. DC or PWM Mode with Hysteresis MSI fan headers running in DC or PWM mode for optimal tuning of fan speeds & silence. Hysteresis also makes your fans spin up fluently to make sure your system stays silent, no matter what. Total Control in BIOS & Software Total Fan Control means that you can take control of your fans & check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU & motherboard, which will adjust the fan speeds automatically. Gaming

Features: Your In-Game Advantage Outsmart & outperform your opponents in-game using an array of unique MSI GAMING tools. Clever hardware & software tools, created to keep you one step ahead of the competition & boost your skills. Total Freedom, Maximum Ease Easily program your most-used commands & execute them with a single keystroke. You’re free to choose any key you want, so choose wisely. Gaming Hotkey Simply assign functions to any key whether to launch your favourite games, load profiles or do real-time overclocking with the push of a single button. The possibilities are endless! • User-friendly, easy-to-use application. • Launch your favourite game with a single button. Dedicated Port for Gaming Peripherals The GAMING Device Port is optimized to deliver the best connectivity for high-end gaming peripherals to fully utilize their features & responsiveness. Customize your mouse DPI to enhance accuracy or program macro combinations using the easy-to-use Mouse Master software to perform multiple commands with just one click. Gaming Benefits: • 3x more gold than regular connectors for the best signal. • 10x longer lifetime when plugging/un-plugging. • More responsive, more precise movements. • Customizable mouse settings. • No keypress left behind with n-key rollover. A Different View On Gaming MSI Dragon Eye means that you can watch a You Tube video or Twitch Stream while playing a game simultaneously. Simply add a link or stream to the Dragon Eye application & select the size, position, volume & transparency & start gaming. The hotkeys allow you to start/pause your video or set the volume. In-Game Feedback, On-Screen Display Keep track of your system performance with the OSD function in Gaming App. This feature means that you can fully customize which statistics are shown on-screen while you play your games. Keep an eye on your CPU speed, FPS counter, GPU temperature & much more while gaming without having to leave the game. Free Premium Software with MSI Motherboards? WTFast: Join The Gamers Private Network This unique & secure gamers solution uses its own optimized private network for gaming. Join the network to get an even lower ping! Storage: Be The First On The Battlefield This MSI GAMING motherboard supports all the latest storage standards. This means that you can connect any ultra-fast storage device, giving you in-game benefits. Start games faster, load levels faster & have a real advantage over your enemies. Turbo M.2 Enjoy a blazing fast system boot up & insanely quick loading of applications & games with MSI motherboards. Delivering speeds up to 32 Gb/s per device using Gen 3 x 4, Turbo M.2 is over 5 times faster than a regular SATA III connection! X-Boost Your Storage Performance This great little tool is very simple to use & automatically detects your storage devices connected to the system. When enabled, X-Boost optimizes your SSDs to keep your system fast & maximize storage performance, making sure you reach the battlefield even quicker or saving you a lot of time when transferring data. SATA Mass Storage We made sure each MSI motherboard comes with enough SATA ports to connect loads of HDDs for long term storage of large files & system backups. Ultra-Fast Performance, Great Gaming Experience All of the next gen storage connectors support NVMe, the fastest storage standard in the world. Simply put, MSI GAMING motherboards offer the best of the best in storage options & performance. Instantly load your favourite games & always be the first on the battlefield with MSI. VR: Immerse Yourself into Virtual Worlds Integrating the very best of cutting edge technologies on MSI hardware provides a smooth VR ride. Through joint efforts with major VR brands, combined with unique MSI features geared to VR, MSI brings gamers & VR professionals a vivid & realistic experience in which content truly comes alive. Get Ready to Be Overwhelmed by The Realms of VR From the start of Virtual Reality, MSI has been deeply involved in making VR Ready hardware in each of its product lines. Whether its a feature-rich motherboard, a framerate boosting graphics card or a blazing fast complete gaming system, a huge set of VR-supporting features awaits you. Optimized for The Best VR Brands Want the best of the best VR experience without any compromise? MSI motherboards offer everything you need when exploring the possibilities of VR. By closely working with the industries’ leading VR vendors, we make sure you get the best possible gaming experience when choosing Virtual Reality. Straight into The Action with One Click to VR Both hard- & software need to be in tune for a smooth VR experience. One Click to VR makes it very fast & easy to get primed for VR. A single click sets all your key components to their highest performance & makes sure other software applications won’t impact your virtual adventure. Audio: Sound That Pulls You into The Game Get the most immersive sound experience when gaming. MSI Audio Boost delivers the highest sound quality through the use of premium quality audio components. This lets you enjoy breath-taking, game-changing sound to create the most exciting gameplay. Isolated Audio Design with LED Border Audio Boost operates like a dedicated soundcard by being physically isolated from the rest of the motherboard circuitry to ensure the purest audio signal possible. A bright border illuminated by LEDs showcases & protects the Hi-Fi audio unit. Separated Audio Layers for Clean Left & Right Channels Using separated layers in the PCB ensures equally pristine sound quality for both left & right audio channels. De-Pop Protection Audio Boost protects your ears by eliminating those annoying loud popping sounds when you plug/unplug devices or turn your PC on/off. Dedicated High Definition Audio Processor Audio Boost is powered by an EMI-shielded high quality HD audio processor, making sure you enjoy the purest sound quality in both stereo & surround sound. Chemi-Con Audio Capacitors for A Warmer Sound By dedicating golden audio capacitors to the front output, a high fidelity sound experience with exceptional acoustics & realism for studio level headphones is ensured. The Chemi-Con audio capacitors are widely considered to be one of the great choices for the best sound output. 5.1 Audio for True Surround Sound With high quality audio connectors you get the best possible signal output with less chance of distortion. GAMING LAN: Dominate The Game With The Lowest Latency Get ready to crush your enemies on the battlefield with MSI GAMING LAN. Featuring the highest quality components tuned to deliver the best online gaming experience without lag. Optimize Online Gaming Traffic for Lower Latency! MSI GAMING LAN Manager automatically classifies & prioritizes the latency-sensitive applications for online games, giving you the best online gaming experience with low latency. MSI GAMING LAN Manager • Automatically prioritizes games above other applications. • means that you can change applications traffic priority. • means that you can customize bandwidth for each application. Memory: Unmatched Memory Performance MSI motherboards are crammed with features to fuel your gaming rigs memory with more speed, higher overclockability & increased stability. Enhanced Stability with Optimized Memory Layout Optimized traces & a fully isolated memory circuitry ensures perfect stability & performance, so you never have to worry about your system crashing during games. Memory Speed Impacts Performance The technical enhancements of DDR4 Boost allow for more stability at higher memory speeds compared to other brands. Enjoy the additional boost in gaming performance or when working with large video & photography files. Extreme Stability & Compatibility Testing MSI conducts thorough memory testing with the most popular memory brands under extreme conditions to ensure your system runs stable no matter what. Our memory partners include brands like Corsair, Crucial, Kingston, G. Skill & many more to optimize memory modules, configurations & even improve overclocking. Tuning: Designed for Limitless Tuning Founded on experience & with a long history of creating the best performing motherboards packed with smart features, you can count on this motherboard to deliver the best performance under the most extreme conditions. Countless system tuning & troubleshooting tools are at your disposal to push your system to new heights & satisfy even the most demanding tweaker. Overvoltage Protection Prevents potential short-circuit damage to the CPU & other critical components. EZ De Bug LED Run into trouble? On-board LEDs for key components will indicate the source of the problem so you know exactly where to look to get up & running again. USB: Maximize Your USB (Universal Serial Bus) Device Performance Transfer your favourite games, music & movies over USB (Universal Serial Bus) faster than ever. MSI offers a wide variety of options to connect & boost your USB (Universal Serial Bus) 3.1 devices, delivering lightning-fast transfer speeds up to 5 Gb/s! X-Boost Your USB (Universal Serial Bus) Performance When enabled, X-Boost optimizes your devices for even better transfer speeds & can provide up to 20% increase in USB (Universal Serial Bus) performance, saving a lot of time when transferring data. This handy tool is very easy to use & automatically detects & optimizes the USB (Universal Serial Bus) devices connected to your system. Super Charge Your Phone & Gaming Gear MSI Super Charger USB (Universal Serial Bus) ports charge any connected device faster. It delivers more power than regular USB (Universal Serial Bus) ports to your smartphone, tablet, USB (Universal Serial Bus) game controller or portable console. Double ESD Protection Never worry about damage caused by defective USB (Universal Serial Bus) devices. The USB (Universal Serial Bus) ports on MSI motherboards are shielded by a set of protective ICs to prevent damage caused by Electrostatic Discharge (ESD) from plugging/unplugging USB (Universal Serial Bus) devices. Software: Apps To Greatly Improve Efficiency with many years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. Use these tools to get the most out of your motherboard & achieve victory when gaming. X-Boost Your Storage This unique & exclusive software means that you can boost the performance of any storage or USB (Universal Serial Bus) device connected to your system. Simply use X-BOOST’s Easy or Advanced mode to tune your system for up to 20% increased speeds, higher system responsiveness & faster loading of in-game levels. Take Command of Your System MSI’s Command Center software is the perfect tool to get the most out of your motherboard. With an intuitive interface, Command Center means that you can tune settings to increase system stability, maximize performance & optimize your system’s cooling features. Always Up-To-Date Never miss out on important updates. MSI Live Update automatically downloads & installs the latest drivers, BIOS & software so you can focus on your game. "...the best update package available on any motherboard." – Anandtech SSD Not Fast Enough? Try MSI RAMDisk MSI motherboards include RAMDisk, allowing you to create a virtual drive from your system RAM memory. Instantly load your favourite game, speed up your browser or your page file to significantly speed up your system! • Speed up system performance, over 25x faster than a SATA SSD. • Speed up games, apps & browser. • Increase SSD lifespan. CPU-Z MSI GAMING Edition MSI has worked closely with the CPUID team to develop a special edition of CPU-Z featuring the famous MSI GAMING dragon. Use CPU-Z to gather key information of your system’s key components, like CPU speed, Memory speed & timings, motherboard BIOS version & much more. Quality & Protection: Built On Everlasting Quality Using only the finest top quality components & integrating the latest technological innovations delivers the best possible gaming & professional experience. Rigorous quality testing under the most extreme conditions ensures a super reliable, high performance motherboard. Fortify Your System with PCI-E Steel Armor MSI PCI Express Steel Armor slots are armed with more solder points on the motherboard for a stronger hold, preventing any damage due to heavy-weight graphics cards. Steel Armor also protects PCI Express signals against electromagnetic interference for a pure gaming experience & even higher overclocking. Ultimate Motherboard Protection We’ve made sure you can enjoy your system endlessly. MSI motherboards feature Double ESD protection with double layer grounding around the motherboard mounting holes, preventing Electrostatic discharge (ESD) surges from damaging the motherboard. Super Stable with The Highest Quality Components MSI uses Military Class 4 components, which is the latest evolution of the industries’ highest quality standard. These high quality components are shielded by the best protection to make sure your system runs smoothly under the most extreme conditions. Military Class 4 • Dark Choke: A special core design allows the Dark Choke to run at a lower temperature offering better power efficiency & stability. • Humidity Protection. • Temperature Protection. • Circuit Protection. • ESD Protection. • EMI Protection. Certified for Gaming Each model is tweaked to deliver the best FPS for a stutter-free gaming experience. Tested in 24-hour on- & offline gaming sessions with the most popular gaming gear by the world’s best e Sports players, so you can enjoy top performance & reliability in the world’s most popular games. BIOS: A Gamers BIOS We made sure our BIOS contains all the latest options & is easy to use for everyone. The extensive features let you fine-tune your system to deliver reliable maximum performance when gaming. Easy to Read, Hi-Res Bios Font An award-winning, high-resolution, scalable font is used to make CLICK BIOS 5 easy to read, no matter what type of screen you use. The clean design layout, together with this great font makes CLICK BIOS 5 a true next gen UEFI BIOS. Easy Mode for Quick Gaming Tweaks When you just want to get back to your game, EZ-mode presents you with basic BIOS settings & functions for some quick adjustments. If you feel like spending more time fine-tuning options to boost your system’s performance, the Advanced mode is the way to go. Easy Search & Favourites Can’t find a specific BIOS setting? Don’t worry, a permanent search option in the top right corner can be used to find what you need. Want quick access to important settings? My Favourites gives easy access to selected Favourite settings, supporting up to 5 groups of Favourites. Hardware Monitor with Fan Control Hardware monitor lets you take control of your system & check your primary system vitals in a simplified graphical interface. You can also set up to 4 temperature targets for CPU & motherboard, which will adjust the fan speeds automatically. Make Your SSD as Fast as New with Secure Erase+ When using an SSD, its performance will slowly decrease over time as more & more data is written onto it. This will slow down Read/ Write speeds & increase access times of your SSD, making your system feel sluggish. Using an optimized formatting algorithm, Secure Erase+ lets you enjoy your SSD at maximum speed, making your system feel brand new! Specifications CPU • Supports AMD RYZEN series processors & 7th Gen A-series/ Athlon™ processors for Socket AM4 Chipset • AMDA320 Chipset Main Memory • 4 x DDR4 memory slots, support up to 64GB
- Support DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) Mhz* • Dual channel memory architecture • Support ECC UDIMM memory (non-ECC mode) • Support non-ECC UDIMM memory * 7th Gen A-series/ Athlon processors support a maximum of DDR4 2400 Mhz. Please refer www.msi.com for more information on compatible memory. Slots • 1x PCIe 3.0 x 16 slot
- RYZEN series processors support x 16 mode
- 7th Gen A-series/ Athlon™ processors support x 8 mode • 2 x PCIe 2.0 x 1 slots Onboard Graphics • 1 x VGA port, supports a maximum resolution of 2048x 1280@60 Hz, 1920x 1200@60 Hz • 1 x DVI-D port, supports a maximum resolution of 1920x 1200@60 Hz* • 1 x HDMI™ port, supports a maximum resolution of 4096x 2160@24 Hz* * Only support when using a 7th Gen A-series/ Athlon™ processor * Maximum shared memory of 2048 MB Storage • AMD A320 Chipset • 4 x SATA 6 Gb/s ports
- Support RAID 0, RAID 1 & RAID 10 • 1 x M.2 slot (Key M)
- Supports PCIe 3.0 x 4 (RYZEN Series Processors) or PCIe 3.0 x 2 (7th Gen A-series/ Athlon™ processors ) & SATA 6 Gb/s 2242/ 2260 /2280 storage devices USB (Universal Serial Bus) • AMD A320 Chipset
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports available through the internal USB (Universal Serial Bus) 3.1 Gen 1 connector
- 6 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) 2.0 connectors) • AMD processor
- 4x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) Type-A ports on the back panel Audio • Realtek ALC892 Codec
- 7.1-Channel High Definition Audio LAN • 1 x Realtek 8111H Gigabit LAN controller Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 4 x SATA 6 Gb/s connectors
- 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (supports additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports)
- 1 x 4-pin CPU fan connector
- 2 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Parallel port connector
- 1 x RGB LED strip connector
- 1 x Clear CMOS jumper Back Panel I/O Ports
- 1x PS/2 keyboard/ mouse combo port
- 2x USB (Universal Serial Bus) 2.0 Type-A ports
- 1x VGA port
- 1x DVI-D port
- 1x HDMI™ port
- 4x USB (Universal Serial Bus) 3.1 Gen 1 Type-A ports
- 1x LAN (RJ45) port
- 3x audio jacks Dimension • Micro-ATX Form Factor • 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm) Mounting • 8 mounting holes

































...

Features Supports AMD RYZEN Series processors & 7th Gen A-series / Athlon TM Processors for socket AM4 Support DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) Mhz DDR4 Boost: Give your DDR4 memory a performance boost VR Ready: Best virtual reality game experience without latency Lightning Fast Game experience: Turbo M.2 Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience GAMING LAN with LAN Protect: The best online gaming experience with lowest latency & bandwidth management Military Class 4, Guard-Pro: Latest evolution in high quality components for best protection & efficiency Mystic Light Sync: Synchronize other RGB solutions with your gaming rig & control all LEDs in one click In-Game Weapons:GAMING Hotkey, X-Boost, Xsplit Gamecaster EZ Debug LED: Easiest way to troubleshoot Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites & search function GAMING CERTIFIED: 24-hour on- & offline game & motherboard testing by e Sports players WHQL certified for Windows 10 Product Overview A320M GAMING PRO: Serious Gaming Mystic Light: Personalize Your Gaming Rig Customize & set up your own colour scheme with RGB Mystic Light Sync. Select any of the colours from the palette using your smartphone or the MSI Gaming App to match your system style. Bored of the same colours? Simply change the complete look of your system in 1 second! Fierce Red Gaming Glow This GAMING motherboard features LEDs on the back which provide a cool GAMING glow inside your case. Like war paint, turn them on for a more immersive gaming experience & amp yourself up, ready to dominate the battlefield. Extend Your RGB Experience with Ease MSIs Mystic Light Extension pinheaded provides an intuitive way to control additional RGB strips & other RGB peripherals added to a system, without needing a separate RGB controller. By simply connecting any 12V RGB LED strip to the 4-pin Mystic Light Extension RGB-strip header gamers can sync colours to any style they choose. Mystic Light Sync: Synchronize Your LED Experience With the convenience of Mystic Light Sync, you can control RGB LED solutions from other brands, such as CPU coolers, keyboards & mice or RGB system fans. Get Started with Mystic Light To use Mystic Light, download the latest version of the MSI Gaming App below. For remote control of Mystic Light, simply download the latest version of the Mystic Light App for your smartphone from the Google Play Store or the App Store. Smartphone & PC Control Create your own colourful masterpiece with ease. The easy to use Gaming APP is available on PC, phone & tablet. It offers remote control, simply using your smartphone or tablet. Make your PC look & feel brand new with any colour you want with just a few clicks! Cooling: Stay Cool While Gaming Cooling your PC is essential for reliable performance. Weve made sure to include enough fan headers with full control to allow you to cool your system any way you want. Looking Cool While Keeping Cool High quality materials & smart fan optimizations contribute to cooling all essential components, which is key to making sure your system runs stable at the best performance during long gaming sessions. Fully Controllable Fan Headers MSI motherboards let you manage speeds & temperatures for all your system & CPU fans, giving you full control to set up a cool & silent system. The fan headers are conveniently placed with the most popular CPU coolers in mind. Total Control in BIOS & Software Total Fan Control means that you can take control of your fans & check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU & motherboard, which will adjust the fan speeds automatically. Gaming

Features: Your In-Game Advantage Outsmart & outperform your opponents in-game using an array of unique MSI GAMING tools. Clever hardware & software tools, created to keep you one step ahead of the competition & boost your skills. Total Freedom, Maximum Ease Easily program your most-used commands & execute them with a single keystroke. You’re free to choose any key you want, so choose wisely. Gaming Hotkey Simply assign functions to any key whether to launch your favourite games, load profiles or do real-time overclocking with the push of a single button. The possibilities are endless! • User-friendly, easy-to-use application. • Launch your favourite game with a single button. Dedicated Port for Gaming Peripherals The GAMING Device Port is optimized to deliver the best connectivity for high-end gaming peripherals to fully utilize their features & responsiveness. Customize your mouse DPI to enhance accuracy or program macro combinations using the easy-to-use Mouse Master software to perform multiple commands with just one click. Gaming Benefits: • 3x more gold than regular connectors for the best signal. • 10x longer lifetime when plugging/un-plugging. • More responsive, more precise movements. • Customizable mouse settings. • No keypress left behind with n-key rollover. In-Game Feedback, On-Screen Display Keep track of your system performance with the OSD function in Gaming App. This feature means that you can fully customize which statistics are shown on-screen while you play your games. Keep an eye on your CPU speed, FPS counter, GPU temperature & much more while gaming without having to leave the game. Free Premium Software with MSI Motherboards? WTFast: Join The Gamers Private Network This unique & secure gamers solution uses its own optimized private network for gaming. Join the network to get an even lower ping! Your Game, Your Stream, Your Fame XSplit lets you easily record your gaming moments & broadcast your live gameplay sessions to Twitch, You Tube, UStream & more. Its simple, easy to use & ideal for capturing those perfect gaming moments & sharing it live with friends & the rest of the world. Storage: Be The First On The Battlefield This MSI GAMING motherboard supports all the latest storage standards. This means that you can connect any ultra-fast storage device, giving you in-game benefits. Start games faster, load levels faster & have a real advantage over your enemies. Turbo M.2 Enjoy a blazing fast system boot up & insanely quick loading of applications & games with MSI motherboards. Delivering speeds up to 32 Gb/s per device using Gen 3 x 4, Turbo M.2 is over 5 times faster than a regular SATA III connection! X-Boost Your Storage Performance This great little tool is very simple to use & automatically detects your storage devices connected to the system. When enabled, X-Boost optimizes your SSDs to keep your system fast & maximize storage performance, making sure you reach the battlefield even quicker or saving you a lot of time when transferring data. SATA Mass Storage We made sure each MSI motherboard comes with enough SATA ports to connect loads of HDDs for long term storage of large files & system backups. Ultra-Fast Performance, Great Gaming Experience All of the next gen storage connectors support NVMe, the fastest storage standard in the world. Simply put, MSI GAMING motherboards offer the best of the best in storage options & performance. Instantly load your favourite games & always be the first on the battlefield with MSI. VR: Immerse Yourself into Virtual Worlds Integrating the very best of cutting edge technologies on MSI hardware provides a smooth VR ride. Through joint efforts with major VR brands, combined with unique MSI features geared to VR, MSI brings gamers & VR professionals a vivid & realistic experience in which content truly comes alive. Get Ready to Be Overwhelmed by The Realms of VR From the start of Virtual Reality, MSI has been deeply involved in making VR Ready hardware in each of its product lines. Whether its a feature-rich motherboard, a framerate boosting graphics card or a blazing fast complete gaming system, a huge set of VR-supporting features awaits you. Optimized for The Best VR Brands Want the best of the best VR experience without any compromise? MSI motherboards offer everything you need when exploring the possibilities of VR. By closely working with the industries’ leading VR vendors, we make sure you get the best possible gaming experience when choosing Virtual Reality. Straight into The Action with One Click to VR Both hard- & software need to be in tune for a smooth VR experience. One Click to VR makes it very fast & easy to get primed for VR. A single click sets all your key components to their highest performance & makes sure other software applications won’t impact your virtual adventure. Audio: Sound That Pulls You into The Game Get the most immersive sound experience when gaming. MSI Audio Boost delivers the highest sound quality through the use of premium quality audio components. This lets you enjoy breath-taking, game-changing sound to create the most exciting gameplay. Amplify Your Game with Audio Boost Built on years of experience in building motherboards dedicated to giving gamers true Hi-Fi sound. Audio Boost has developed into a high quality audio unit, offering a clear advantage over your opponents when gaming. Locate your enemies with your eyes closed using Audio Boost. Isolated Audio Design with LED Border Audio Boost operates like a dedicated soundcard by being physically isolated from the rest of the motherboard circuitry to ensure the purest audio signal possible. A bright border illuminated by LEDs showcases & protects the Hi-Fi audio unit. Separated Audio Layers for Clean Left & Right Channels Using separated layers in the PCB ensures equally pristine sound quality for both left & right audio channels. De-Pop Protection Audio Boost protects your ears by eliminating those annoying loud popping sounds when you plug/unplug devices or turn your PC on/off. Dedicated High Definition Audio Processor Audio Boost is powered by an EMI-shielded high quality HD audio processor, making sure you enjoy the purest sound quality in both stereo & surround sound. Chemi-Con Audio Capacitors for A Warmer Sound By dedicating golden audio capacitors to the front output, a high fidelity sound experience with exceptional acoustics & realism for studio level headphones is ensured. The Chemi-Con audio capacitors are widely considered to be one of the great choices for the best sound output. 5.1 Audio for True Surround Sound With high quality audio connectors you get the best possible signal output with less chance of distortion. GAMING LAN: Dominate The Game with The Lowest Latency Get ready to crush your enemies on the battlefield with MSI GAMING LAN. Featuring the highest quality components tuned to deliver the best online gaming experience without lag. Optimize Online Gaming Traffic for Lower Latency! MSI GAMING LAN Manager automatically classifies & prioritizes the latency-sensitive applications for online games, giving you the best online gaming experience with low latency. MSI GAMING LAN Manager • Automatically prioritizes games above other applications. • means that you can change applications traffic priority. • means that you can customize bandwidth for each application. LAN Protect to Shield Your System Against Power Surges Featuring 15KV anti-surge protection to shield your network from lightning strikes & static electricity, the LAN Protect connector is designed to give you a reliable networking experience. Memory: Unmatched Memory Performance MSI motherboards are crammed with features to fuel your gaming rigs memory with more speed, higher overclockability & increased stability. Enhanced Stability with Optimized Memory Layout Optimized traces & a fully isolated memory circuitry ensures perfect stability & performance, so you never have to worry about your system crashing during games. Memory Speed Impacts Performance The technical enhancements of DDR4 Boost allow for more stability at higher memory speeds compared to other brands. Enjoy the additional boost in gaming performance or when working with large video & photography files. Extreme Stability & Compatibility Testing MSI conducts thorough memory testing with the most popular memory brands under extreme conditions to ensure your system runs stable no matter what. Our memory partners include brands like Corsair, Crucial, Kingston, G. Skill & many more to optimize memory modules, configurations & even improve overclocking. Tuning: Designed for Limitless Tuning Founded on experience & with a long history of creating the best performing motherboards packed with smart features, you can count on this motherboard to deliver the best performance under the most extreme conditions. Countless system tuning & troubleshooting tools are at your disposal to push your system to new heights & satisfy even the most demanding tweaker. For Power Users Load-Line Calibration What you set, is what you get. LLC makes sure your CPU voltage remains 100% stable under any load. This greatly improves stability when demanding more CPU performance. EZ De Bug LED Run into trouble? On-board LEDs for key components will indicate the source of the problem so you know exactly where to look to get up & running again. Overvoltage Protection Prevents potential short-circuit damage to the CPU & other critical components. USB: Maximize Your USB (Universal Serial Bus) Device Performance Transfer your favourite games, music & movies over USB (Universal Serial Bus) faster than ever. MSI offers a wide variety of options to connect & boost your USB (Universal Serial Bus) 3.1 devices, delivering lightning-fast transfer speeds up to 5 Gb/s! X-Boost Your USB (Universal Serial Bus) Performance When enabled, X-Boost optimizes your devices for even better transfer speeds & can provide up to 20% increase in USB (Universal Serial Bus) performance, saving a lot of time when transferring data. This handy tool is very easy to use & automatically detects & optimizes the USB (Universal Serial Bus) devices connected to your system. Super Charge Your Phone & Gaming Gear MSI Super Charger USB (Universal Serial Bus) ports charge any connected device faster. It delivers more power than regular USB (Universal Serial Bus) ports to your smartphone, tablet, USB (Universal Serial Bus) game controller or portable console. Front Side USB (Universal Serial Bus) Faster Than Ever with USB (Universal Serial Bus) 3.1 Ready for next generation cases & perfect to use with the latest smartphones, the on-board front side USB (Universal Serial Bus) connector now offers ultra-high speed through USB (Universal Serial Bus) 3.1 with Type-A. Double ESD Protection Never worry about damage caused by defective USB (Universal Serial Bus) devices. The USB (Universal Serial Bus) ports on MSI motherboards are shielded by a set of protective ICs to prevent damage caused by Electrostatic Discharge (ESD) from plugging/unplugging USB (Universal Serial Bus) devices. Software: Apps to Help You Win with many years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. Use these tools to get the most out of your motherboard & achieve victory when gaming. X-Boost Your Storage This unique & exclusive software means that you can boost the performance of any storage or USB (Universal Serial Bus) device connected to your system. Simply use X-BOOST’s Easy or Advanced mode to tune your system for up to 20% increased speeds, higher system responsiveness & faster loading of in-game levels. Take Command of Your System MSI’s Command Center software is the perfect tool to get the most out of your motherboard. With an intuitive interface, Command Center means that you can tune settings to increase system stability, maximize performance & optimize your system’s cooling features. Always Up-To-Date Never miss out on important updates. MSI Live Update automatically downloads & installs the latest drivers, BIOS & software so you can focus on your game. "...the best update package available on any motherboard." – Anandtech SSD Not Fast Enough? Try MSI RAMDisk MSI motherboards include RAMDisk, allowing you to create a virtual drive from your system RAM memory. Instantly load your favourite game, speed up your browser or your page file to significantly speed up your system! • Speed up system performance, over 25x faster than a SATA SSD. • Speed up games, apps & browser. • Increase SSD lifespan. CPU-Z MSI GAMING Edition MSI has worked closely with the CPUID team to develop a special edition of CPU-Z featuring the famous MSI GAMING dragon. Use CPU-Z to gather key information of your system’s key components, like CPU speed, Memory speed & timings, motherboard BIOS version & much more. Quality & Protection: Built On Everlasting Quality Using only the finest top quality components & integrating the latest technological innovations delivers the best possible gaming & professional experience. Rigorous quality testing under the most extreme conditions ensures a super reliable, high performance motherboard. Fortify Your System with PCI-E Steel Armor MSI PCI Express Steel Armor slots are armed with more solder points on the motherboard for a stronger hold, preventing any damage due to heavy-weight graphics cards. Steel Armor also protects PCI Express signals against electromagnetic interference for a pure gaming experience & even higher overclocking. Ultimate Motherboard Protection We’ve made sure you can enjoy your system endlessly. MSI motherboards feature Double ESD protection with double layer grounding around the motherboard mounting holes, preventing Electrostatic discharge (ESD) surges from damaging the motherboard. Super Stable with The Highest Quality Components MSI uses Military Class 4 components, which is the latest evolution of the industries’ highest quality standard. These high quality components are shielded by the best protection to make sure your system runs smoothly under the most extreme conditions. Military Class 4 • Solid CAP: A key ingredient in high-end motherboard designs, Dark Caps have lower Equivalent Series Resistance (ESR) & an increased lifespan of over 10 years. • Dark Choke: A special core design allows the Dark Choke to run at a lower temperature offering better power efficiency & stability. • Humidity Protection. • Temperature Protection. • Circuit Protection. • ESD Protection. • EMI Protection. Certified for Gaming Each model is tweaked to deliver the best FPS for a stutter-free gaming experience. Tested in 24-hour on- & offline gaming sessions with the most popular gaming gear by the world’s best e Sports players, so you can enjoy top performance & reliability in the world’s most popular games. BIOS: A Gamers BIOS We made sure our BIOS contains all the latest options & is easy to use for everyone. The extensive features let you fine-tune your system to deliver reliable maximum performance when gaming. Easy to Read, Hi-Res Bios Font An award-winning, high-resolution, scalable font is used to make CLICK BIOS 5 easy to read, no matter what type of screen you use. The clean design layout, together with this great font makes CLICK BIOS 5 a true next gen UEFI BIOS. Easy Mode for Quick Gaming Tweaks When you just want to get back to your game, EZ-mode presents you with basic BIOS settings & functions for some quick adjustments. If you feel like spending more time fine-tuning options to boost your system’s performance, the Advanced mode is the way to go. Easy Search & Favourites Can’t find a specific BIOS setting? Don’t worry, a permanent search option in the top right corner can be used to find what you need. Want quick access to important settings? My favourites gives easy access to selected Favourite settings, supporting up to 5 groups of favourites. Hardware Monitor with Fan Control Hardware monitor lets you take control of your system & check your primary system vitals in a simplified graphical interface. You can also set up to 4 temperature targets for CPU & motherboard, which will adjust the fan speeds automatically. Make Your SSD as Fast as New with Secure Erase+ When using an SSD, its performance will slowly decrease over time as more & more data is written onto it. This will slow down Read/ Write speeds & increase access times of your SSD, making your system feel sluggish. Using an optimized formatting algorithm, Secure Erase+ lets you enjoy your SSD at maximum speed, making your system feel brand new! Specifications CPU • Supports AMD RYZEN series processors & 7th Gen A-series/ Athlon™ processors for Socket AM4 * This function will be supported depend on the CPU. Chipset • AMDA320 Chipset Main Memory • 2 x DDR4 memory slots, support up to 32GB
- Support DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) Mhz* • Dual channel memory architecture • Supports non-ECC UDIMM memory • Supports ECC UDIMM memory (non-ECC mode) * 7th Gen A-series/ Athlon ™ processors support up to DDR 2400 MHz only. Please refer www.msi.com for more information on compatible memory. Slots • 1 x PCIe 3.0 x 16 slots
- RYZEN series processors support x 16 mode
- 7th Gen A-series/ Athlon™ processors support x 8 mode • 2 x PCIe 2.0 x 1 slots Onboard Graphics • 1 x VGA port, supports a maximum resolution of 2048x 1280@60 Hz, 1920x 1200@60 Hz* • 1 x DVI-D port, supports a maximum resolution of 1920x 1200@60 Hz* • 1 x HDMI™ port, supports a maximum resolution of 4096x 2160@24 Hz* * Only support when using a 7th Gen A-series/ Athlon™ processor. * Maximum shared memory of 2048 MB Storage • AMDA320 Chipset • 4 x SATA 6 Gb/s ports
- Supports RAID 0, RAID1 & RAID 10 • 1 x M.2 slots (Key M)
- Supports PCIe 3.0 x 4 (RYZEN series processors) or PCIe 3.0 x 2 (7th Gen A-series/ Athlon™ processors) & SATA 6 Gb/s 2242/ 2260 /2280 storage devices USB (Universal Serial Bus) • AMDA320 Chipset
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports through the internal USB (Universal Serial Bus) 3.1 Gen 1 connector
- 6 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) connectors) • AMD CPU Chipset
- 4 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) Type-A ports on the back panel Audio • Realtek ALC887 Codec
- 7.1-Channel High Definition Audio LAN • 1 x Realtek 8111H Gigabit LAN controller Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 4 x SATA 6 Gb/s connectors
- 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (supports additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports)
- 1 x 4-pin CPU fan connector
- 2 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Parallel port connector
- 1 x Extended LED strip connector
- 1 x Clear CMOS jumper Back Panel I/O Ports
- 1 x PS/2 keyboard/ mouse combo port
- 2 x USB (Universal Serial Bus) 2.0 Type-A ports
- 1 x VGA port
- 1 x DVI-D port
- 1 x HDMI™ port
- 4 x USB (Universal Serial Bus) 3.1 Gen 1 Type-A ports
- 1 x LAN (RJ45) port
- 3 x audio jacks Dimension • 9.6 in. x 8.7 in. (24.4 cm x 21.0 cm) • m-ATX Form Factor Mounting • 9 mounting holes

































...

Features Supports AMD RYZEN Series processors & 7th Gen A-series / Athlon TM Processors for socket AM4 Support DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) Mhz DDR4 Boost: Give your DDR4 memory a performance boost VR Ready: Best virtual reality game experience without latency GAMING LEDs: Ambient LED lights for an awesome look & feel Lightning Fast Game experience: Turbo M.2 Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience GAMING LAN with LAN Protect: The best online gaming experience with lowest latency & bandwidth management Military Class 4, Guard-Pro: Latest evolution in high quality components for best protection & efficiency Mystic Light Sync: Synchronize other RGB solutions with your gaming rig & control all LEDs in one click In-Game Weapons:GAMING Hotkey, X-Boost EZ Debug LED: Easiest way to troubleshoot Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites & search function GAMING CERTIFIED: 24-hour on- & offline game & motherboard testing by e Sports players WHQL certified for Windows 10 Product Overview MYSTIC LIGHT PERSONALIZE YOUR GAMING RIG Customize & set up your own color scheme with RGB Mystic Light sync. Select any of the colors from the palette using your smartphone or the MSI Gaming App to match your system style. Bored of the same colors? Simply change the complete look of your system in 1 second! COOLING STAY COOL WHILE GAMING Cooling your PC is essential for reliable performance. Weve made sure to include enough fan headers with full control to allow you to cool your system any way you want. • 3x fan headers • DC/PWM mode • Full fan control GAMING FEATURES YOUR IN-GAME ADVANTAGE Outsmart & outperform your opponents in-game using an array of unique MSI GAMING tools. Clever hardware & software tools, created to keep you one step ahead of the competition & boost your skills. Gaming Hotkey Gaming Device Port STORAGE BE THE FIRST ON THE BATTLEFIELD This MSI GAMING motherboard supports all the latest storage standards. This means that you can connect any ultra-fast storage device, giving you in-game benefits. Start games faster, load levels faster & have a real advantage over your enemies. 1x M.2 Boost your storage VR IMMERSE YOURSELF INTO VIRTUAL WORLDS Integrating the very best of cutting edge technologies on MSI hardware provides a smooth VR ride. Through joint efforts with major VR brands, combined with unique MSI features geared to VR, MSI brings gamers & VR professionals a vivid & realistic experience in which content truly comes alive. AUDIO SOUND THAT PULLS YOU INTO THE GAME Get the most immersive sound experience when gaming. MSI Audio Boost delivers the highest sound quality through the use of premium quality audio components. This lets you enjoy breathtaking, game-changing sound to create the most exciting gameplay. Audio Boost Audio capacitors GAMING LAN DOMINATE THE GAME WITH THE LOWEST LATENCY Get ready to crush your enemies on the battlefield with MSI GAMING LAN. Featuring the highest quality components tuned to deliver the best online gaming experience without lag. MEMORY UNMATCHED MEMORY PERFORMANCE MSI motherboards are crammed with features to fuel your gaming rigs memory with more speed, higher overclockability & increased stability. Optimal layout 100% compatibility TUNING DESIGNED FOR LIMITLESS TUNING Founded on experience & with a long history of creating the best performing motherboards packed with smart features, you can count on this motherboard to deliver the best performance under the most extreme conditions. Countless system tuning & troubleshooting tools are at your disposal to push your system to new heights & satisfy even the most demanding tweaker. USB (Universal Serial Bus) MAXIMIZE YOUR USB (Universal Serial Bus) DEVICE PERFORMANCE Transfer your favorite games, music & movies over USB (Universal Serial Bus) faster than ever. MSI offers a wide variety of options to connect & boost your USB (Universal Serial Bus) 3.1 devices, delivering lightning-fast transfer speeds up to 5 Gb/s! Front USB (Universal Serial Bus) 3.1 Boost your USB SOFTWARE APPS TO GREATLY IMPROVE EFFICIENCY with many years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. Use these tools to get the most out of your motherboard & achieve victory when gaming. X-Boost Command Center Live Update RAMDisk QUALITY & PROTECTION BUILT ON EVERLASTING QUALITY Using only the finest top quality components & integrating the latest technological innovations delivers the best possible gaming & professional experience. Rigorous quality testing under the most extreme conditions ensures a super reliable, high performance motherboard. BIOS
- A GAMERS BIOS We made sure our BIOS contains all the latest options & is easy to use for everyone. The extensive features let you fine-tune your system to deliver reliable maximum performance when gaming. Specifications CPU • Supports AMD RYZEN series processors & 7th Gen A-series/ Athlon™ processors for Socket AM4 * This function will be supported depend on the CPU. Chipset • AMD A320 Chipset Main Memory • 2 x DDR4 memory slots, support up to 32GB
- Support DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) Mhz* • Dual channel memory architecture • Support ECC UDIMM memory (non-ECC mode) • Support non-ECC UDIMM memory * 7th Gen A-series/ Athlon processors support a maximum of DDR4 2400 Mhz. Please refer www.msi.com for more information on compatible memory. Slots • 1 x PCIe 3.0 x 16 slot
- RYZEN series processors support x 16 mode
- 7th Gen A-series/ Athlon™ processors support x 8 mode • 2 x PCIe 2.0 x 1 slots Onboard Graphics • 1 x VGA port, supports a maximum resolution of 2048x 1280@60 Hz, 1920x 1200@60 Hz • 1 x DVI-D port, supports a maximum resolution of 1920x 1200@60 Hz* • 1 x HDMI™ port, supports a maximum resolution of 4096x 2160@24 Hz* * Only support when using a 7th Gen A-series/ Athlon™ processor * Maximum shared memory of 2048 MB Storage • AMD A320 Chipset • 4 x SATA 6 Gb/s ports
- Support RAID 0, RAID 1 & RAID 10 • 1 x M.2 slot (Key M)
- Supports PCIe 3.0 x 4 (RYZEN Series Processors) or PCIe 3.0 x 2 (7th Gen A-series/ Athlon™ processors ) & SATA 6 Gb/s 2242/ 2260 /2280 storage devices USB (Universal Serial Bus) • AMD A320 Chipset
- 2 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) ports available through the internal USB (Universal Serial Bus) 3.1 Gen 1 connector
- 6 x USB (Universal Serial Bus) 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) 2.0 connectors) • AMD processor
- 4 x USB (Universal Serial Bus) 3.1 Gen 1 (Super Speed USB) Type-A ports on the back panel Audio • Realtek ALC887 Codec
- 7.1-Channel High Definition Audio LAN • 1 x Realtek 8111H Gigabit LAN controller Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 4 x SATA 6 Gb/s connectors
- 2 x USB (Universal Serial Bus) 2.0 connectors (supports additional 4 USB (Universal Serial Bus) 2.0 ports)
- 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (supports additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports)
- 1 x 4-pin CPU fan connector
- 2 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Parallel port connector
- 1 x RGB LED strip connector
- 1 x Clear CMOS jumper Back Panel I/O Ports
- 1 x PS/2 keyboard/ mouse combo port
- 2 x USB (Universal Serial Bus) 2.0 Type-A ports
- 1 x VGA port
- 1 x DVI-D port
- 1 x HDMI™ port
- 4 x USB (Universal Serial Bus) 3.1 Gen 1 Type-A ports
- 1 x LAN (RJ45) port
- 3 x audio jacks Dimension • Micro-ATX Form Factor • 9.6 in. x 8.3 in. (24.4 cm x 21.0 cm) Mounting • 8 mounting holes
































...

* Saving based on buying these 2 items seperatley. MSI AMD A520M-A PRO MATX Motherboard Supports AMD Ryzen™ 5000 & 3000 Series desktop processors & AMD Ryzen™ 4000 G-Series desktop processors Supports DDR4 Memory, up to 4600 (OC) MHz Turbo M.2: Running at PCI-E Gen 3 x 4 maximizes performance for NVMe based SSDs Core Boost: With premium layout & digital power design to support more cores & provide better performance. DDR4 Boost: Advanced technology to deliver pure data signals for the best performance & stability. 2oz Thickened Copper PCB: An enhanced PCB design improves heat dissipation & performance reliability. Audio Boost: Reward your ears with studio grade sound quality Dragon Center: A brand new software which integrates all MSI exclusive tools with user friendly user interface. AMD Ryzen 5 5600X AM4 Processor Specifications of CPU Cores
- 6 of Threads
- 12 Base Clock
- 3.7 G Hz Max Boost Clock
- Up to 4.6 G Hz Total L2 Cache
- 3MB Total L3 Cache
- 32MB Unlocked
- Yes CMOS
- TSMC 7nm Fin FET Package
- AM4 PCI Express Version
- PCIe 4.0 Thermal Solution (PIB)
- Wraith Stealth Default TDP / TDP
- 65W Max Temps
- 95°C












...

Business Elegance The PRO Series is tailored to professionals from all walks of life. The lineup features impressive performance & high quality, while aiming to provide users incredible experience. Users who care about productivity & efficiency can definitely count on the MSI PRO Series to assist you with multitasking & increasing efficiency. Chipset Heatsink The chipset heatsink is designed to reduce dust & noise & also capable of maintaining high efficiency of PCH. Control in One Click MSI Motherboards let you manage speeds & temperatures for all your system & CPU fans in BIOS & software with a simplified graphical interface. You can also set up to 4 temperature targets, which will adjust the fan speeds automatically. FROZR AI Cooling Detecting CPU & GPU temperatures & automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE. Auto Detect Your Fan MSI fan headers automatically detect fans running in DC or PWM mode for optimal tuning of fan speeds & silence. Hysteresis also makes your fans spin up fluently to make sure your system stays silent, no matter what. Core Boost Core Boost technology combines MSIs premium layout & optimised power design which allows for faster & undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking. Performance Switch Performance Switch combines the benefits of AMD default PBO (Precision Boost Overdrive) & MSI’s own OC settings, provides higher CPU performance in both status of single-core & multi-core. This is for users who dare for the maximum performance. PBO Thermal Point MSI PBO Thermal profiles are setting maximum CPU temperature at 85°C, 75°C & 65°C levels. With the thermal profiles, the CPU operates at lower voltage & temperature but remaining the same performance. Config TDP Config TDP is designed to provide ECO Mode (65W) or different TDP (PPT/TDC/EDC) settings for advanced users. By offering several profiles for different TDP settings in Click BIOS 5, Config TDP makes setting TDP profiles easier & don’t need to modify settings manually for each TDP. Lightning Gen 4 PCI-E MSI lightning Gen 4 PCI-E represents the bandwidth of a x 16 interface to 64GB/s that has doubled compared to its previous generation. Reinforced, Heavy Soldered Connections MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points & support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor shields the point of contact from electromagnetic interference. Supports AMD Ryzen™ 7000 Series Desktop Processors. Supports DDR5 Memory, Dual Channel DDR5 6000+MHz (OC). Core Boost: With premium layout & digital power design to support more cores & provide better performance. Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability & compatibility. Lightning Fast Game Experience: PCIe 4.0 slot, Lightning Gen 4 x 4 M.2. Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience. Steel Armor: Protecting VGA cards against bending & EMI for better performance, stability & strength. ...
