GPU BOOST
- Go to the Limit with i GPU Level UP Protect 3.0
- Protects the Earth, Systems & You EFI BIOS (EZ Mode)
- Flexible & Easy BIOS Interface AI Suite II
- One-stop Access to Innovative ASUS Features Ture USB (Universal Serial Bus) 3.0 & SATA 6 Gb/s Support
- Fully Unleash Performance Mem OK!
- Any Memory is A-OK! CPU Intel Socket 1155 for Intel 2nd Generation Core™ i 7 Processor/ Core™ i 5 Processor/ Core™ i 3 Processor/ Support Intel 32nm CPU Supports Intel Turbo Boost Technology 2.0 * The Intel Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to www.asus.com for Intel CPU support list. Chipset Intel H67 (B3) Chipset Memory 4 x DIMM, Max. 32 GB, DDR3 1333/1066 Non-ECC, Un-buffered Memory Dual Channel memory architecture Supports Intel Extreme Memory Profile (XMP) * According to Intel SPEC, the Max. 32GB memory capacity can be supported with DIMMs of 8GB (or above). ASUS will update QVL once the DIMMs are available on the market. * Please refer to www.asus.com or user manual for Memory QVL. * When installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended. Expansion Slots 1 x PCIe 2.0 x 16 [blue] (single at x 16 mode) 1 x PCIe 2.0 x 16 *[black] (at x 4 mode, compatible with PCIe x 1 & x 4 devices) 2 x PCIe 2.0 x 1 3 x PCI * PCIe x 1 slot shares the bandwidth with PCIe x 16_2 slot. ** Due to Cross Fire X™ limitation, DO NOT use the PCIe x 1 slot when you install two Cross Fire X™ graphics cards on both the PCIe x 16 slots to set up a Cross Fire X™ cofiguration. *** To disable the PCIe X1 slot, refer to the Onboard Devices Configuration section in the BIOS for details. VGA Multi-VGA output support: HDMI, DVI-D, RGB
- Supports RGB with max. resolution 2048 x 1536@75 Hz
- Supports DVI with max. resolution up to 1920 X1200 @ 60 HZ
- Supports HDMI with max. resolution up to 1920 X1200 @ 60 HZ Maximum shared memory of 1748 MB Multi-GPU Support Supports ATI Quad-GPU Cross Fire X™ Technology Storage Intel H67 (B3) Express Chipset 4 x SATA 3.0 Gb/s ports (blue) 2 x SATA 6.0 Gb/s ports (gray) Intel Rapid Storage Technology Support RAID 0, 1, 5, 10 VIA VT6415 PATA controller 1 x Ultra DMA 133/100 for up to 2 PATA devices LAN PCIE Gigabit LAN Audio ALC887 8-Channel High Definition Audio CODEC USB (Universal Serial Bus) ASMedia USB (Universal Serial Bus) 3.0 controller
- 2 x USB (Universal Serial Bus) 3.0/2.0 ports (blue) at back panel Intel H67 (B3) Express Chipset
- 12 x USB (Universal Serial Bus) 2.0/1.1 ports (8 ports at mid-board, 4 ports at back panel) ASUS Unique Features
- Turbo V
- Auto Tuning
- Anti-Surge Protction
- GPU Boost
- Mem OK!
- ASUS Fan Xpert
- AI Suite II
- EPU
- Crash Free BIOS 3
- EZ Flash 2
- My Logo 2 Back Panel I/O Ports 1 x PS/2 Keyboard/ Mouse Combo port 1 x DVI 1 x VGA 1 x HDMI 1 x LAN (RJ45) port (s) 2 x USB (Universal Serial Bus) 3.0/2.0 4 x USB (Universal Serial Bus) 2.0/1.1 1 x S/PDIF Out (Optical) 8 -Channel Audio I/O Internal I/O Connectors 4 x USB (Universal Serial Bus) connectors support additional 8 USB (Universal Serial Bus) ports 1 x Mem OK! switch 1 x GPU Boost switch 1 x IDE connector 2 x SATA 6.0 Gb/s connectors 4 x SATA 3.0 Gb/s connectors 1 x CPU Fan connector (s) 2 x Chassis Fan connector (s) 1 x Power Fan connector (s) 1 x S/PDIF Out connector 1 x 24-pin ATX Power Power connector 1 x 8-pin EATX 12V Power connector 1 x Front panel audio connector 1 x COM connector 1 x System Panel connector BIOS 32 Mb Flash ROM, EFI BIOS, Pn P, DMI v 2.0, Wf M2.0, SMBIOS v 2.6, ACPI v 2 0a, Multi-language BIOS Accessories Users manual 1 x Ultra DMA 133/100/66 cable 2 x SATA 6.0 Gb/s cables I/O Shield Support Disc Drivers Anti-virus software (OEM version) ASUS Update ASUS Utilities Form Factor ATX Form Factor 12 inch x 9 inch (30.5 cm x 22.9 cm )
