Board Form Factor UCFF (4" x 4") Socket Soldered-down BGA Internal Drive Form Factor 2.5" Drive of Internal Drives Supported 1 Lithography 14 nm TDP 10 W DC Input Voltage Supported 12-19 VDC Processor Included Intel Pentium Silver Processor J5005 (4M Cache, up to 2.80 GHz) Embedded Options Available No Description Other

Features:

Includes:: SDXC card slot, dual microphones Memory & Storage Max Memory Size (dependent on memory type) 8 GB Memory Types DDR4-2400 1.2V SO-DIMM Max of Memory Channels 2 Max Memory Bandwidth 38.4 GB/s Max of DIMMs 2 ECC Memory Supported & Dagger; No Processor Graphics Integrated Graphics & Dagger; Yes Graphics Output 2x HDMI 2.0a of Displays Supported & Dagger; 2 Expansion Options Removable Memory Card Slot SDXC with UHS-I support I/O Specifications of USB (Universal Serial Bus) Ports 6 USB (Universal Serial Bus) Configuration 2x front & 2x rear USB (Universal Serial Bus) 3.0; 2x USB (Universal Serial Bus) 2.0 via internal headers USB (Universal Serial Bus) Revision 2.0, 3.0 USB (Universal Serial Bus) 2.0 Configuration (External + Internal) 0 + 2 USB (Universal Serial Bus) 3.0 Configuration (External + Internal) 2B 2F + 0 Total of SATA Ports 1 Max of SATA 6.0 Gb/s Ports 1 RAID Configuration N/A Audio (back channel + front channel) 7.1 digital; L+R+mic (F); L+R+TOSLINK (R) Integrated LAN 10/100/1000 Integrated Wireless& Dagger; Intel Wireless-AC 9462 Integrated Bluetooth Yes Consumer Infrared Rx Sensor Yes S/PDIF Out Connector TOSLINK Additional Headers CEC, 2x USB2.0, AUX_PWR, FRONT_PANEL Package Specifications Low Halogen Options Available See MDDS Advanced Technologies Intel Virtualization Technology for Directed I/O (VT-d) & Dagger; Yes Intel v Pro™ Technology & Dagger; No TPM No Intel HD Audio Technology Yes Security & Reliability Intel AES New Instructions Yes



...

Inte Nuc Intel NUC Kit BOXNUC5i 3RYK Intel Core i 3-5010U Barebone Board Form Factor UCFF (4" x 4") Internal Drive Form Factor M.2 SSD of Internal Drives Supported 1 Embedded Options Available No Lithography 14 nm TDP 15 W DC Input Voltage Supported 12-19 VDC Board Chipset Intel Core i 3-5010U Processor (3M Cache, 2.10 GHz) Processor Included Intel Core i 3-5010U Processor (3M Cache, 2.10 GHz) Warranty Period 3 yrs -Memory Specifications Max Memory Size (dependent on memory type) 16 GB Memory Types DDR3L-1333/1600 1.35V 2x SO-DIMMs Max of Memory Channels 2 Max Memory Bandwidth 25.6 GB/s Max of DIMMs 2 ECC Memory Supported No Graphics Specifications Integrated Graphics Yes Graphics Output Mini-DP 1.2, Mini-HDMI 1.4a Intel Clear Video Technology Yes of Displays Supported 3 Expansion Options PCI Express Revision 2 PCI Express Configurations M.2 slot with PCIe X4 lanes Max of PCI Express Lanes 4 PCIe x 4 Gen 2.x 1 I/O Specifications USB (Universal Serial Bus) Revision 2.0, 3.0 of USB (Universal Serial Bus) Ports 6 USB (Universal Serial Bus) 2.0 Configuration (Back + Internal) 0 + 2 USB (Universal Serial Bus) 3.0 Configuration (Back + Internal) 2B, 2F + 0 Total of SATA Ports 2 Max of SATA 6.0 Gb/s Ports 2 RAID Configuration RAID-0, RAID-1 Audio (back channel + front channel) 7.1 digital + analog stereo headset Integrated LAN 10/100/1000 Integrated Wifi Intel Wireless-AC 7265 + BT 4.0 Integrated Bluetooth Yes ...

Board Form Factor
- UCFF (4" x 4") Internal Drive Form Factor
- M.2 & 2.5" Drive Number of Internal Drives Supported
- 2


...

Requires users choice of SO-DIMM memory, 2.5inch storage (SSD or HDD) & choice of OS to complete the barebone system (not included). These systems are so easy to build just follow the included instructions, remove part of the case & insert the memory & storage close the unit up again & install users choice of Operating System (usually via an external DVD drive). Building an home theater PC (HTPC) or personal cloud? The Intel NUC with an Intel Celeron processor gives you control over your digital media. HDMI* video, an infrared sensor port, & internal 2.5-inch drive support will allow you to drive your home entertainment experience from the 4x 4 form factor, so you can create a digital media center or personal cloud for your media files that fits in the palm of your h&. In addition, this Intel NUC introduces the foundation for a new boot management capability that lets you choose the operating systems that work best for you via a user-friendly interface. Features & Configurations Processor Intel Celeron processor N2820 (up to 2.4 G Hz dual-core, 1MB cache, 7.5W TDP) Memory 1 DDR3L SODIMM 1.35V, 1333/1600 MHz (down clocked to 1066 MHz), 8GB maximum Graphics Intel HD Graphics (up to 756 M Hz) 1 x HDMI* 1.4a Audio Up to 7.1 surround audio via HDMI interface Back panel headphone/microphone jack Peripheral connectivity 1 x USB (Universal Serial Bus) 3.0 port on the front panel 2 x USB (Universal Serial Bus) 2.0 ports on the back panel Front panel consumer IR sensor Storage Internal support for 2.5¨ HDD or SSD Networking 10/100/1000 Mbps Ethernet port Intel Wireless-N 7260BN pre-installed, including wireless antennas (IEEE 802.11bgn, Bluetooth* 4.0, Intel Wireless Display built-in) Enclosure Silver aluminum ring with diamond cut around black top Dimensions: 116.6mm x 112mm x 51.5mm Power adapter 12V, 36W wall-mount AC adapter Multi-country plugs (IEC types A/C/G/I) Additional features Intel Visual BIOS Intel Visual Boot Manager Windows* 8.1 & 8 Logo Compatible with Linux* VESA mount bracket (75x 75mm & 100x 100mm compatible) Half-length PCIe* mini-card slot (used by pre-installed wireless card) Low-acoustics active cooling design Kensington lock support Included in the box Intel NUC board DN2820FYB integrated in enclosure VESA mount bracket, with screws 12V, 36W wall-mount AC adapter Intel Celeron brand sticker Integration guide ...

A revolution in ultra-compact device design, this new Intel NUC packs more features, including support for 2.5-inch drives, into an innovative small form factor. This fully scalable, computing solution comes complete with the latest 4th generation Intel Core i 5 processor. The Intel NUC provides a flexible, customizable engine to drive home theater PCs, media server PCs, & intelligent computing for small spaces, or anywhere else you can imagine. The Intel NUC D54250WYKH has many useful features, including four USB (Universal Serial Bus) 3.0 ports, an infrared sensor, a headphone/microphone jack, Mini HDMI*, & Mini Display Port* video interfaces, & extra space to accommodate 2.5-inch HDD or SSD drives to support a variety of home or small office usages. It also features Visibly Smart graphics using Intel HD Graphics 5000 to provide amazing performance & visually stunning graphics for immersive gaming, media editing with Intel Quick Sync Video, & HD playback with Intel Clear Video HD Technology (Intel CVT HD). Processor Intel Core i 5 4250U processor (1.3 GHz with turbo capability to achieve 2.6 GHz, dual-core processor with 3 MB smart cache) Memory Two SO-DIMM slots supporting up to 16 GB of 1600/1333 MHz 1.35V DDR3L memory (Note: 1.5V DDR3 memory is not supported) Graphics Intel HD 5000 graphics 1 x HDMI* 1.4a One Mini Display Port*1 1.2 supporting ultra-high definition 4K displays & multiple monitor functionality One Mini HDMI* 1.4a port Audio Intel HD Audio 2 via Mini HDMI 1.4a Mini Display Port 1.2 output supporting 8 channel (7.1) digital audio Intel HD Audio via stereo analog audio jack (microphone in/headphone out/speaker out) Peripheral connectivity Four super high-speed USB (Universal Serial Bus) 3.0 ports (two back panel ports & two front ports) Two additional high-speed USB (Universal Serial Bus) 2.0 ports via internal header Storage Internal support for 2.5-inch HDD or SSD (up to 9.5 mm thickness) Networking 10/100/1000 Mbps Ethernet port Wireless antennae (integrated into the chassis) Enclosure Silver aluminum ring with diamond cut around black top Dimensions: 116.6 mm x 112 mm x 51.5 mm Power adapter 19V, 65W DC-DC power adapter Power cord options (types B, E, G, & no cord options) Additional features Intel Visual BIOS Windows* 8.1 & 8 logo Compatible with Linux* VESA mount bracket (75 x 75 mm & 100 x 100 mm compatible) Half-length PCIe* mini-card slot Low-acoustics active cooling design Kensington lock* support 3-year advanced warranty replacement ...

Processor 5th generation Intel Core i 3-5010U processor (2.1 G Hz Dual Core, 3MB Cache, 15W TDP) Memory Dual-channel DDR3L SODIMMs 1.35V, 1333/1600 MHz, 16GB maximum Graphics Intel HD 5500 Graphics 2x Mini Display Port 1.2 1x e DP connector (2-lane with backlight adjustable voltage/timings) Audio Up to 7.1 surround audio via Mini Display Port Headphone/microphone jack on the front panel Peripheral Connectivity 2x USB (Universal Serial Bus) 3.0 ports (front panel) 2x USB (Universal Serial Bus) 3.0 ports (back panel) 2x USB (Universal Serial Bus) 2.0 ports (internal header) Storage Internal support for M.2 Key Type B SSD card (22x 42 or 22x 80) Internal SATA3 support for 2.5" HDD/SSD (up to 9.5mm thickness Networking Integrated Intel 10/100/1000 Mbps Ethernet Network Connection M.2 22x 30 slot & wireless antennas pre-assembled (for wireless card support) Enclosure (kit only) Silver with Black Top & Diamond Cut around the Top Aluminum & Plastic Dimensions: 4.52" x 4.37" x 1.9" or 115 mm x 111 mm x 48.7 mm Power Adapter 19V, 65W wall-mount AC-DC power adapter Multi-country plugs (IEC types A/C/G/I) Additional Features Discrete trusted platform module (TPM v 2.0) Watchdog timer (hard-coded to board reset) Backpanel serial port expandability (via 3rd party cable) Support for user-replaceable third-party lids High-Speed Custom Solutions connector (PCIe x 4) Custom Solutions header (DMIC, App Launch GPIO, HDMI_CEC, SMBus, I2C[0:1], GPIO[0:1], 3.3/5 Vstby power), & NFC header 2x Serial ports via header (TXD/RXD/RTS/CTS, w/5V x-ceivers) Power connectors: 12-19V DC (back panel), 12-24V DC (internal) OS certs: Windows* 7 & 8.1 OS compatibility: Ubuntu*, Linux Mint, Fedora, Open SUSE, ¦ VESA mount bracket & mounting hole support Low-acoustics active cooling design Kensington lock support Integration guide 3-year product life cycle 3-year limited warranty Included in the box Intel NUC Kit NUC5i 3MYHE integrated in enclosure (kit only) VESA mount bracket, with screws 19V, 65W wall-mount AC-DC power adapter with multi-country AC plugs (IEC types A/C/G/I) Integration guide ...

Board Form Factor UCFF (4" x 4") Internal Drive Form Factor M.2 & 2.5" Drive of Internal Drives Supported 2 Embedded Options Available No Lithography 14 nm TDP 15 W DC Input Voltage Supported 12-19 VDC Board Chipset Intel Core i 3-5010U Processor (3M Cache, 2.10 GHz) Processor Included Intel Core i 3-5010U Processor (3M Cache, 2.10 GHz) Warranty Period 3 yrs Specifications Max Memory Size (dependent on memory type) 16 GB Memory Types DDR3L-1333/1600 1.35V 2x SO-DIMMs Max of Memory Channels 2 Max Memory Bandwidth 25.6 GB/s Max of DIMMs 2 ECC Memory Supported No Graphics Specifications Integrated Graphics Yes Graphics Output Mini-DP 1.2, Mini-HDMI 1.4a Intel Clear Video Technology Yes of Displays Supported 3 Expansion Options PCI Express Revision 2 PCI Express Configurations M.2 slot with PCIe X4 lanes Max of PCI Express Lanes 4 PCIe x 4 Gen 2.x 1 I/O Specifications USB (Universal Serial Bus) Revision 2.0, 3.0 of USB (Universal Serial Bus) Ports 6 USB (Universal Serial Bus) 2.0 Configuration (Back + Internal) 0 + 2 USB (Universal Serial Bus) 3.0 Configuration (Back + Internal) 2B, 2F + 0 Total of SATA Ports 2 Max of SATA 6.0 Gb/s Ports 2 RAID Configuration RAID-0, RAID-1 Audio (back channel + front channel) 7.1 digital + analog stereo headset Integrated LAN 10/100/1000 Integrated Wifi Intel Wireless-AC 7265 + BT 4.0 Integrated Bluetooth Yes ...

Intel Nuc Kit NUC5i 5MYHE Core i 5 5300U Barebone From enterprise to small & medium business, university computing labs to call centers, the Intel NUC is driving the models of computing in small spaces. The Intel NUC kit NUC5i 5MYHE is powered by fast processor, providing an ideal combination of performance & reliability for usages where downtime isnt an option. Intel v Pro technology helps you manage repairs remotely, reducing the time it takes to resolve hardware problems by 66 percent & software problems by 88 percent giving your customers the reliability & availability they require. The advanced capabilities of the processor, gives your customers performance to run video analytics to target messages to the right audience. & the triple display capability means your customers can deliver their messages across multiple screens. With 4K display support its an ideal device for digital signage with video analytics, digital kiosk, intelligent vending, or PC replacement. A serial port option to connect legacy embedded devices means that you can customize the Intel NUC for a wide-range of usages, including POS systems. A replaceable lid further extends options for customization, enabling third-party innovation & usage models with NFC & USB (Universal Serial Bus) headers. Intel NUC NUC5i 5MYHE has the option to install a 2.5" HDD or an M.2 SSD. The choice gives your customers options to store all their files locally or take advantage of the fast, power-efficient M.2 form factor which minimizes load times & improves reliability. ...

A revolution in ultra-compact device design, the Intel NUC NUC5i 5RYK packs more features into 4 inches square. The NUC5i 5RYK is equipped with the 5th generation Intel Core i 5-5250U processor with Intel Turbo Boost Technology 2.01 which gives you extra GHz on demand to let you maximize performance on processor-intensive tasks like media editing. A replaceable lid gives you plenty of options to create the Intel NUC you want—with amazing style & features. It also features Intel HD Graphics 6000 with 4K display capabilities to provide visually stunning graphics. A high-speed USB (Universal Serial Bus) 3.0 charging port lets you easily charge your tablet or smartphone quickly. Complete with Wi Fi 802.11ac wireless, Bluetooth*, & 7.1 surround sound, the Intel NUC NUC5i 5RYK is ideal for home theater PCs, media server PCs, & home hubs. For peace of mind, you’ll get embedded security that helps keep threats out & user identities & credentials safe. With this kind of power, size, & versatility, you’ll rethink what’s possible. ...

Intel Nuc Kit NUC6i 5SYH Intel Core i 5-6260U Barebone Specifications: Board Form Factor UCFF (4" x 4") Socket Soldered-down BGA Internal Drive Form Factor M.2 & 2.5" Drive of Internal Drives Supported 2 Embedded Options Available No Lithography 14 nm TDP 15 W DC Input Voltage Supported 12-19 VDC Datasheet Link Description Other

Features:

Includes:: SDXC card slot Processor Included Intel Core i 5-6260U Processor (4M Cache, up to 2.90 GHz) Warranty Period 3 yrs Memory Specifications Max Memory Size (dependent on memory type) 32 GB Memory Types DDR4-2133 1.2V SO-DIMM Max of Memory Channels 2 Max Memory Bandwidth 34.1 GB/s Max of DIMMs 2 ECC Memory Supported No Graphics Specifications Integrated Graphics Yes Graphics Output Mini-DP 1.2 HDMI 1.4b Intel Clear Video Technology Yes of Displays Supported 3 Expansion Options PCI Express Revision Gen 3 PCI Express Configurations M.2 slot with PCIe x 4 lanes Removable Memory Card Slot SDXC with UHS-I support M.2 Card Slot (storage) 22x 60, 80 I/O Specifications USB (Universal Serial Bus) Revision 2.0 3.0 of USB (Universal Serial Bus) Ports 6 USB (Universal Serial Bus) 2.0 Configuration (External + Internal) 0 + 2 USB (Universal Serial Bus) 3.0 Configuration (External + Internal) 2B 2F + 0 Total of SATA Port 2 Max of SATA 6.0 Gb/s Ports 2 RAID Configuration 2.5" HDD/SSD + M.2 SATA/PCIe SSD (RAID-0 RAID-1) Audio (back channel + front channel) 7.1 digital (HDMI m DP); L+R+mic (F) Integrated LAN 10/100/1000 Integrated Wifi Intel Wireless-AC 8260 + BT 4.2 Integrated Bluetooth Yes Additional Headers CEC, NFC, 2x USB2.0, AUX_PWR



...
