Intel Core I7-7800X 3.50GHz LGA 2066 Retail Boxed Processor

Features Intel Turbo Boost Technology 2.0 Dynamically increases the processor’s frequency, as needed, by taking advantage of thermal and power headroom when operating below specified limits. Intel Hyper-Threading Technology Delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner. Integrated Memory Controller Supports up to 4 channels of DDR4-2400 memory with 1 DIMM per channel. Support for the Intel Extreme Memory Profile (Intel XMP) specification, revision 2.0, for DDR4. Intel Optane Memory Provides performance improvements as well as fast app response times for system acceleration and responsiveness. Intel Smart Cache 8.25MB of shared cache allows faster access to your data by enabling dynamic
and efficient allocation of the cache to match the needs of each core significantly reducing latency to frequently used data and improving performance. Overclocking Enabled Fully unlocked core multipliers, power, base clock and DDR4 memory ratios for amazing flexibility with overclocking. Chipset/Motherboard Compatibility Supported by the Intel X299 Chipset. Intel Advanced Encryption Standard New Instructions (Intel AES-NI) A fast, secure AES engine for a variety of encryption apps, including whole disk encryption, file storage encryption, conditional access of HD content, internet security, and VOIP. Consumers benefit from protected internet and email content, plus fast, responsive disk encryption. Intel Virtualisation Technology Allows one hardware platform to function as
multiple “virtual” platforms. Offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions. PCI Express 3.0 Interface Offers up to 8GT/S for fast access to peripheral devices and networking up to 28 lanes. Green Technology Manufactured with lead-free and halogen-free component packages. Product Overview Intel Core X-Series Processor Family Something for every Enthusiast! The new X-series processor family is designed to scale to your performance needs by delivering options between 4 to 18 cores for extreme performance, the latest technological advancements and headroom for the future. This platform comes ready to install Intel Optane memory and Intel Optane SSDs for amazing system responsiveness.
Support for immersive 4K visuals, four channel DDR4 2666 memory*, Thunderbolt 3 delivering a 40Gb/s bi-directional port for almost any peripheral you want to connect and up to 8 SATA ports for a RAID storage array makes this the ultimate desktop platform. *Please note: This i7-7800X CPU only supports DDR4 2400 memory when modules are not overclocked. Game, Record, Stream Enter the realm of extreme performance where same play is so life-like it is difficult to tell where reality ends and the game begins. Surrounded by multiple high-res displays and premium audio sound, you are totally immersed in the action of your AAA game title or the latest virtual reality thriller. Play extreme, live extreme, game extreme on a computer with an unlocked Intel Core X-series processor. And because
modern gaming extends beyond just gameplay, you want to simultaneously share your gameplay with the community and the world. Record all the action capturing that once in a life-time manoeuvre that brought you to victory, and convert your game play into sharable format to immediately post on your social media page. That is extreme mega tasking and the power of the Intel Core X-series processor. Unleash Your Ultimate Creative Genius Now with an Intel Core X-Series Processor Your creativity is limitless and once you are in the flow of ideas, you need a system that will keep up. You need the uncompromising performance in a PC powered by the Intel Core X-series processor. The Intel Core X-series processor family with 6, 8, 10, 12 or even 18 cores delivers amazing performance when multiple
real-time workloads are stacked. Spend more time creating while your Intel Core X-series processor powered system simultaneously handles uploading massive 4K files, rendering effects and other compute intensive workloads in the background. And with the updated Intel Turbo Boost Max Technology 3.0*, you have the control to give priority to the apps that need the power of the two best performing cores. Quad channel memory also delivers improved responsiveness and decreases start up time when you are working with large files and content creation applications. With an Intel Core X-series processor you can focus on creating with the confidence that your results will be as remarkable as you imagined. *Please note: Intel Turbo Boost Max Technology 3.0 is not supported by this i7-7800X CPU.
Intel X299 Chipset and Intel Core X-Series Processors for The Ultimate Platform The Intel X299 chipset paired with the Intel Core X-series processors provide a world class platform for gaming, content creation and overclocking. Whether it is responsiveness, expandability or performance you crave, this platform has you covered. Integrated USB 3.0 makes moving files to your tablet and smartphone blazing fast. The platform also provides RAID support on PCI Express and Serial ATA storage devices, fast data transfers with support for PCIe 3.0 storage devices and finally, Intel Optane Memory support. Want to push the envelope with overclocking? The Intel X299 chipset and Intel Core X-series processor family bring new unlocked base clock capabilities. Unlock your individual cores and memory
frequencies to amazing levels while having the flexibility to keep other areas within specification. With support for Intel Extreme Memory Profiles (XMP), Intel Extreme Tuning Utility (X TUI, and the Intel Performance Tuning Protection Package Plan the capabilities of the Intel X299 chipset and new Intel Core X-series processors are a threat to every overclocking world record. Specifications CPU Type Intel Core i7 CPU Model 7800X Socket 2066 Core Name Skylake-X Manufacturing Process 14 nm Core 6 Core No. of Threads 12 Core Ratio 35 x Clock Speed 3.5 GHz Turbo Speed 4.0 GHz Intel Turbo Boost Max Technology 3.0 Speed FSB Speed N/A QPI Speed N/A DMI Speed 8 GT/s Unlocked Core Multiplier Yes Unlocked Full Range Base Clock (B-Clock) Yes Max. Memory Size 128 GB Max. Memory Speed DDR4 - 2400
Max. Memory Channels 4 (Quad Channel) ECC Memory Support Not Supported Max. PCIe Lanes Supported 28 Intel Smart Cache 8.25MB Max. TDP 140W Heatsink Not Included, Sold Separately Package Type Retail
