Product Collection 7th Generation Intel Core™ i 7 Processors Code Name Products formerly Kaby Lake Vertical Segment Desktop Processor Number i 7-7700K Lithography 14 nm Performance of Cores 4 of Threads 8 Processor Base Frequency 4.20 GHz Max Turbo Frequency 4.50 GHz Cache 8 MB Smart Cache Bus Speed 8 GT/s DMI3 of QPI Links 0 TDP 91 W Conflict Free Yes Datasheet View now Learn how Intel is pursuing conflict-free technology. Memory Specifications Max Memory Size (dependent on memory type) 64 GB Memory Types DDR4-2133/2400, DDR3L-1333/1600 @ 1.35V Max of Memory Channels 2 ECC Memory Supported & Dagger; No Graphics Specifications Processor Graphics & Dagger; Intel HD Graphics 630 Graphics Base Frequency 350 MHz Graphics Max Dynamic Frequency 1.15 GHz Graphics Video Max Memory 64 GB 4K Support Yes, at 60 Hz Max Resolution (HDMI 1.4)& Dagger; 4096x 2304@24 Hz Max Resolution (DP)& Dagger; 4096x 2304@60 Hz Max Resolution (e DP
- Integrated Flat Panel)& Dagger; 4096x 2304@60 Hz Direct X* Support 12 Open GL* Support 4.4 Intel Quick Sync Video Yes Intel In Tru™ 3D Technology Yes Intel Clear Video HD Technology Yes Intel Clear Video Technology Yes of Displays Supported & Dagger; 3 Device ID 0x 5912 Expansion Options Scalability 1S Only PCI Express Revision 3.0 PCI Express Configurations & Dagger; Up to 1x 16, 2x 8, 1x 8+2x 4 Max of PCI Express Lanes 16 Package Specifications Sockets Supported FCLGA1151 Max CPU Configuration 1 Thermal Solution
Specification PCG 2015D (130W) TJUNCTION 100°C Package Size 37.5mm x 37.5mm Low Halogen Options Available See MDDS Advanced Technologies Intel Optane™ Memory Supported & Dagger; Yes Intel Turbo Boost Technology & Dagger; 2.0 Intel v Pro™ Technology & Dagger; No Intel Hyper-Threading Technology & Dagger; Yes Intel Virtualization Technology (VT-x) & Dagger; Yes Intel Virtualization Technology for Directed I/O (VT-d) & Dagger; Yes Intel VT-x with Extended Page Tables (EPT) & Dagger; Yes Intel TSX-NI Yes Intel 64 & Dagger; Yes Instruction Set 64-bit Instruction Set Extensions SSE4.1/4.2, AVX 2.0 Idle States Yes Enhanced Intel Speed Step Technology Yes Thermal Monitoring Technologies Yes Intel Identity Protection Technology & Dagger; Yes Intel Stable Image Platform Program (SIPP) No Security & Reliability Intel AES New Instructions Yes Secure Key Yes Intel Software Guard Extensions (Intel SGX) Yes Intel Memory Protection Extensions (Intel MPX) Yes Intel OS Guard Yes Execute Disable Bit & Dagger; Yes Intel Boot Guard Yes
