Intel Hyper-Threading technology Deliver two processing threads per physical core for a total of four threads for massive computational throughput. This 4-way multi-task processing allows each core of your processor to work on two tasks at the same time. Intel smart cache Intel smart cache is shared cache dynamically allocated to each processor core, based on workload. This efficient, dual-core-optimized implementation increases the probability that each core can access data from the fast cache, significantly reducing latency to frequently used data & improving performance. Intel HD graphics Provide superb visual performance for sharper images, richer color, & life-like video & audio. Specifications
- Processor
-
- Type / Form Factor
- Intel Core i 3 3210 (3rd Gen)
- Number of Cores
- Dual-Core
- Number of Threads
- 4 threads
- Cache
- 3 MB
- Cache Memory Details
- L3
- 3 MB
- Processor Qty
- 1
- Clock Speed
- 3.2 GHz
- Compatible Processor Socket
- LGA1155 Socket
- Manufacturing Process
- 22 nm
- Thermal Design Power
- 55 W Architecture Features
-
- Enhanced Speed Step technology
- Hyper-Threading Technology
- Integrated memory controller
- Execute Disable Bit capability
- Intel Virtualization Technology
- Intel 64 Technology
- Intel My Wi Fi Technology
- Intel Anti-Theft Technology
- Intel Advanced Vector Extensions (AVX)
- Thermal Monitoring Technologies
- Idle States
- Intel VT-x with Extended Page Tables (EPT) Cache Memory
- Installed Size
- 3 MB Integrated Graphics
-
- Type
- Intel HD Graphics 2500
- Base Frequency
- 650 MHz
- Max Dynamic Frequency
- 1.05 GHz
- Features
- Intel FDI, Intel Clear Video HD Technology, In TRU 3D
-
- - Technology, Intel Quick Sync Video, Intel Wireless Display (Wi Di), Intel Insider
















































...

Processor integration & manufacturing take huge leaps forward in the latest Intel micro architecture (codename Haswell). As the first new micro architecture on the 22nm manufacturing process, it marks the arrival of a new 4th gen Intel Core platform, which comprises 4th gen Intel Core processors & the Intel 8 Series chipset family (codename Lynx Point). This new platform delivers significant performance advancements—including vastly enhanced graphics, battery life, & security—for a zero-compromise computing experience. Specifications Family
- Intel Core i 3 Model Number
- i 3 4130 Socket
- Intel LGA 1150 Core Frequency
- 3.4 G Hz Number of Cores
- 2 Number of Threads
- 4 L3 Cache
- 3MB Shared Integrated graphics
- Intel HD 4400 Thermal Power Design
- 54W Lithography Process
- 22nm









...

Intel Core i 3-4130T 2.90 G Hz Soct 1150 3MB Cache Retail Boxed Status Launched Launch Date Q3'13 Processor Number i 3-4130T of Cores 2 of Threads 4 Clock Speed 2.9 GHz Intel Smart Cache 3 MB DMI2 5 GT/s of QPI Links 0 Instruction Set 64-bit Instruction Set Extensions SSE4.1/4.2 AVX2.0 Embedded Options Available No Lithography 22 nm Scalability 1S Only Max TDP 35 W Thermal Solution

Specification PCG 2013A Memory Specifications Max Memory Size (dependent on memory type) 32 GB Memory Types DDR3-1333/1600 of Memory Channels 2 Max Memory Bandwidth 25.6 GB/s ECC Memory Supported Yes Graphics Specifications Processor Graphics Intel HD graphics 4400 Graphics Base Frequency 200 MHz Graphics Max Dynamic Frequency 1.15 GHz Graphics Video Max Memory 1 GB Intel Quick Sync Video Yes Intel In Tru™ 3D Technology Yes Intel Wireless Display Yes Intel Clear Video HD Technology Yes of Displays Supported 3 Expansion Options PCI Express Revision 3.0 PCI Express Configurations Up to 1x 16, 2x 8, 1x 8/2x 4 Max of PCI Express Lanes 16 age Specifications Max CPU Configuration 1 TCASE 66.4 C Package Size 37.5mm x 37.5mm Graphics & IMC Lithography 22nm Sockets Supported FCLGA1150 Low Halogen Options Available See MDDS Advanced Technologies Intel Turbo Boost Technology No Intel v Pro Technology No Intel Hyper-Threading Technology Yes Intel Virtualization Technology (VT-x) Yes Intel Virtualization Technology for Directed I/O (VT-d) No Intel VT-x with Extended Page Tables (EPT) Yes Intel TSX-NI No Intel 64 Yes Idle States Yes Enhanced Intel Speed Step Technology Yes Thermal Monitoring Technologies Yes Intel Virtualization Technology for Itanium (VT-i) No Intel Stable Image Platform Program (SIPP) No

...

Specifications Model
- Intel i 3 4150 Family
- Intel Core i 3 Core Frequency
- 3.5 G Hz Bus Speed
- 5 GT/s DMI clock Multiplier
-




...

Specifications Socket
- Intel 1150 Family
- Intel Core i 3 Model Number
- i 3 4160 Frequency
- 3600 M Hz Bus Speed
-




...

Specifications Family
- Intel Core i 3 Model Number
- Intel i 3 4340 Core Frequency
- 3.6 G Hz Socket
- Intel LGA 1150



...

Specifications Model
- Intel i 3 4350 Family
- Intel Core i 3 Core Frequency
- 3.6 G Hz Bus Speed
- 5 GT/s DMI clock Multiplier
-




...

Specifications Model
- Intel i 3 4360 Family
- Intel Core i 3 Core Frequency
- 3.7 G Hz Bus Speed
- 5 GT/s DMI clock Multiplier
-




...
