Pro Lite LH5563S Pro Lite LH5563S is a 55 Full HD professional, feature-rich & robust LED-backlit display. Incorporating the latest Commercial Grade 120 Hz IPS panel technology, the display guarantees great viewing from all angles, high brightness & exceptional colour clarity. It also features an ambient light sensor delivering optimal picture quality with the added benefit of saving on power. The display supports PIP & video-wall function. A wide range of video & audio inputs ensures compatibility with multiple platforms. Pro Lite LH5563S is prepared for easy installation using the VESA wall mount. This display will suit a massive range of applications including public signage, retail, exhibitions & conference centres, POS/POI, control rooms, & production facilities. Display &
- ; 55”screen &
- ; Resolution 1920 x 1080p &
- ; Full HD &
- ; Contrast ration 300:1 (typical) &
- ; Response Time 10ms &
- ; Brightness 450cd/m-square &
- ; Viewing Angle
- horizontal/vertical: 178°/ 178°; right/left: 89°/ 89°; up/down: 89°/ 89° &
- ; Aspect Ratio 16:9 &
- ; Display Colours 1.073 Billion &
- ; Pixel Pitch 0.63 x 0.63mm Power &
- ; Power Supply AC 100
- 240 V, 50 / 60 Hz &
- ; Internal Power Supply &
- ; Power Usage
- 190 W typical; max. 0.5 W in Power management mode Connectivity&
- ; VGA (D-Sub) &
- ; RCA (Video) &
- ; DVI-D &
- ; HDMI &
- ; HDCP &
- ; Audio signal input – PC-Audio, RCA L/R (2x) &
- ; Output connector – RCA (L/R), RS232C, VGA, RCA &
- ; Input connector – RS232C, D-Sub, DVI-D, HDMI Special Features &
- ; Plug & Play &
- ; On-Screen-Display in 7 languages (EN, FR, ES, NL, DE, PL, RU) controlled by back controls or a remote control &
- ; 2 x 12 W (Stereo) speakers &
- ; VESA 200 x 400 mm &
- ; Black

Dimensions &
- ; 1260 x 732 x 59 mm (wxhxd) &
- ; 27.2kg What the box

Includes:: &
- ; Power cable &
- ; VGA (D-Sub) signal cable &
- ; Remote control &
- ; Iiyama logo sticker &
- ; Quick start guide &
- ; Safety guide








































...

55” Professional Digital Signage display with 24/7, 4K UHD & 700cd/m-square high brightness performance This high brightness display will deliver dynamic & sharp content, designed to entice & captivate your audience. The slim bezel & true commercial display with a 4K UHD resolution (3840x 2160), 700cd/m 2 & a contrast ratio of 4000:1 provides vibrant, detailed & sublime images. Thanks to on-board Android 9.0 you can easily customize the display by installing applications directly to it. Embedded NSign optional cloud based signage makes it the perfect choice for Digital Signage, In-store communication & messaging. Designed to perform in continual, around the clock environments, the LH5570UHB can be installed & utilised in landscape & portrait orientation. The jaw dropping & best-in-class 34.5mm total depth (when used with the included proprietary brackets) will mean this display can be installed discreetly & elegantly in all areas. ANDROID OS Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it. SLIM LINE Ultra Slim Line monitors feature a sleek bezel & are therefore particularly suitable for video wall or a multi-monitor set-up. 24/7 24/7 displays are designed for a continuous operation. 4K UHD resolution (3840x 2160), better known as 4K, offers a gigantic viewable area with 4 times more information & work space than a Full HD screen. Due to the high DPI (dots per inch), it displays an incredibly sharp & crisp image. MEDIA PLAYER LFD Play your favourite music & show your most beautiful videos, photos & images directly on screen from a flash drive or internal memory with the built-in media player. ...

Incorporating AMVA3 panel technology the LH5580S guarantees great viewing from all angles & perfect colour clarity. Features include PIP & PBP perfect for Video Conferencing or handling multi-input content. Build in expansion slot supports the Open Pluggable

Specification (OPS) standard; it simplifies the installation of a plug-in PC for digital signage applications. Landscape & Portrait friendly, Pro Lite LH5580S is designed for a continues operation. Perfect for true impact in Digital Signage. FULL HD With true 1920 x 1080p resolution this LFD is ready to display high definition images. This means it can accommodate more information on the screen; e.g. 60% more in comparison to a 1280 x 1024 monitor. MULTIPLE INPUTS A wide range of video inputs assures compatibility with multiple platforms. AMVA3 AMVA3 Panel technology offers 24 bit ‘ True Colour’ performance & amazing viewing angles LIGHT SENSOR The ambient light sensor detects changes in environmental lighting conditions & automatically adjusts the screens backlight brightness to compensate for & increase or decrease in light. PIP PIP (Picture in Picture) function means that you can watch images coming from two different sources at the same time. VESA VESA mount compliance means you can easily mount the LFD to any mounting that complies with the VESA standard. KEY LOCK You can easily lock & unlock the controls preventing unauthorised changes to settings you made. SPEAKERS Built-in stereo speakers deliver rich sound. REMOTE CONTROL For ease of control a remote control is supplied with the LFD. Technical

Specification Display 54.6” Screen Panel: AMVA3 LED Resolution: 1920 x 1080 Full HD 1080p Aspect Ratio: 16:9 Static Contrast ratio:4000:1 Response Time: 6.5ms Brightness: 450 cd/m 2 Viewing angle: 178° / 178° Pixel Pitch: 0.63 x 0.63mm Display Colours: 1.06B Analog Signal Frequency: 31.5~91.1 KHz (H)/ 50~85 Hz (V) Connectivity VGA DVI-D HDMI x 2 Display Port S-Video BNC jack Mini jack RS232C output connector Features Speakers: 2 x 10W (stereo) Plug & Play: VESA DDC2B VESA 400 x 400 Orientation: Portrait/landscape/face up Power Power Supply: AC 100
- 240 V, 50 / 60 Hz Power Consumption On: 133W Power Consumption (St&-By): 1W

Dimensions (Wx Hx D) 1247 x 718 x 66.5mm






...

This product may require special order or configuration. Please contact our Sales team for further information. Call us on: 01430 433780 Email us on: business@ebuyer.com Features Maximum impact with this 55” Digital signage LFD with 700cd/m 2 The Pro Lite LH5582SB-B1 professional large format display is the ideal digital signage solution for companies that want maximum impact & maximum flexibility. The slim design & ultra-thin metal bezel combined with the higher-brightness – 700cd/m 2 - IPS panel, 24/7 operating time & landscape/portrait orientation ensures optimal fit in almost any digital signage set-up, incl. video walls. The LED-backlit technology guarantees low power consumption & together with the active cooling ensures a reliable long-term operation. It can be operated via LAN network, RS232 or via an OPS plug-in PC. Also available in 42 inch: LH4282SB-B1 & 49 inch: LH4982SB-B1 Technical Specifications DISPLAY CHARACTERISTICS Diagonal :54.6", 138.8cm Panel :IPS LED, matte finish Native resolution :1920 x 1080 (2.1 megapixel Full HD) Aspect ratio :16:9 Brightness :700 cd/m-square typical Static contrast :1 300:1 typical Response time :8ms Viewing zone :horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° Colour support :1.07B (8 bit + A-FRC) Horizontal Sync :30
- 83 K Hz Vertical Sync :50
- 76 Hz Viewable area W x H :1209.6 x 680.4mm, 47.6 x 26.8" Pixel pitch :0.63mm Bezel colour & finish :black, matte INTERFACES / CONNECTORS / CONTROLS Analog signal input :VGA (x 1), RCA Composite (x 1) Digital signal input :DVI (x 1), HDMI (x 2), Display Port (x 1) Audio input: Mini jack (x 1) Digital signal output: Display Port (x 1) Audio output: Mini jack (x 1), RCA (L/R) (x 1), Speakers (2 x 10W) HDCP :yes USB (Universal Serial Bus) HUB :x 1 (v.2.0) FEATURES Max. non-stop operating time :24/7 Media playback :yes Housing (bezel) :metal GENERAL OSD languages :EN, DE, FR, ES, IT, PT, CN, RU, JP, CZ, NL, PL User controls :picture (picture style, restore style, backlight, colour, sharpness, noise reduction, MPEG artifact reduction, digital crystal clear, advanced, game or computer, format & edges) sound (sound style, restore style, bass, treble, balance, surround mode, audio out, advanced) tiling (enable, H. monitors, V. monitors, position, frame comp.) general settings (menu language, monitor ID, auto search, clock, scheduling, sleep timer, easylink, auto adjust, local KB lock, RC lock, pixel shift, smart power, wake on lan, switch on state, LED, switch delay, logo, APM, information OSD, displayport ver. network control port, factory settings) network settings (view network settings, network configuration, static IP configuration, digital media renderer-DMR, network name) Plug& Play :DDC2B, Mac OSX MECHANICAL Orientation :landscape, portrait VESA mounting :400 x 400mm ACCESSORIES INCLUDED Cables :power, DVI, HDMI, m DP
- DP, DP, RS232 Guides :quick start guide, safety guide Remote control :yes (batteries included) POWER MANAGEMENT Power supply unit :internal Power supply :AC 100
- 240V, 50/60 Hz Power usage :145W typical, 0.5W stand by SUSTAINABILITY Regulations :CB, CE, Tu V-Bauart, CU Energy efficiency class :B

Dimensions / WEIGHT Product

Dimensions W x H x D :1228.5 x 699.5 x 71.0mm Weight (without box) :24.7kg EU ENERGY EFFICIENCY LABEL Energy efficiency class :B ON mode power consumption :146.1W Annual energy consumption :213k Wh/annum* Visible screen diagonal :139cm; 54.6"; (55" segment) RELATED INFORMATION Related products: OSTX40X81







...

This product may require special order or configuration. Please contact our Sales team for further information. Call us on: 01430 433780 Email us on: business@ebuyer.com 65" Professional Digital Signage display with a 24/7 operation, 4K UHD resolution & a portrait/landscape orientation See the difference with the Pro Lite LH6550UHS. A professional digital signage display with 4K graphics, continuous operating time (24/7) & landscape/portrait orientation. Featuring a slim bezel, ambient light sensor & an AMVA3 panel for exceptional color & image performance, the LH6550UHS offers businesses a versatile & effective solution to present their message in an innovative & engaging manner. Also available in 50 inch: LH5050UHS-B1 & 55 inch: LH5550UHS-B1 LAN Control LAN control enables making adjustments in the display OSD menu through your network (software not included). AMVA3 AMVA3 technology offers higher contrast, darker blacks & much better viewing angles than standard TN technology. The screen will look good no matter what angle you look at it. 4K UHD resolution (3840x 2160), better known as 4K, offers a gigantic viewable area with 4 times more information & work space than a Full HD screen. Due to the high DPI (dots per inch), it displays an incredibly sharp & crisp image. Display Port/HDMI Daisy Chain Support A daisy chain is a wiring scheme in which multiple devices are wired together in sequence or in a ring. It enables a connection of a series of devices using a single connection between each two devices, using Display Port/HDMI input & a Display Port/HDMI output. The output connects to the next downstream display. This cabling arrangement, with one Display Port/HDMI cable between each set of monitors, provides a simple, less cluttered system configuration. Light sensor The ambient light sensor detects changes in environmental lighting conditions & automatically adjusts the screens backlight brightness to compensate for an increase or decrease in light. ...

The Pro Lite P1905S meets the increasing demands for Protected LCD’s within Education, Retail & Industrial applications. In addition to having toughened safety glass fitted behind the bezel at 8H hardness rating capable of resisting above normal impacts to the display, iiyama have enhanced the range to include the latest high performance & energy saving technology. Features include 5msec response time, 1000:1 contrast ratio enhancing colour & Analogue & DVI inputs. The displays are Energy Star rated & have 19W typical power consumption in use & less than 1W in standby. PROTECTIVE GLASS The toughened safety glass fitted behind the bezel at 8H hardness rating is capable of resisting above normal impacts to the display making this LCD the ideal choice for Education, Retail & Industrial applications. LED-BACKLIT A typical CCFL LCD uses four backlight lamps. Using LED diodes considerably lowers the power consumption & reduces the CO2 emission into the environment making this LCD a true ECO-Friendly product. SPEAKERS This LED monitor is equipped with two high quality stereo speakers. KEY LOCK You can easily lock & unlock the front controls preventing unauthorised changes to settings you made. VESA VESA mount compliance means you can easily mount your monitor to a wall. Technical

Specification Display 19” Screen Panel: TN LED Resolution: 1280 x 1024 Aspect Ratio: 5:4 Brightness: 240 cd/m-square Static Contrast ratio: 1000:1 Response Time: 5ms Viewing angle: Horizontal/vertical: 170°/ 160°; right/left: 85°/ 85°; up/down: 80°/ 80° Display Colours: 16.7M Pixel Pitch: 0.294 x 0.294mm Horizontal Sync: 30
- 80 KHz Vertical Sync: 55
- 75 Hz Glass Thickness: 2mm Glass Transmission rate: 96% up typical Glass Hardness: 8H minimum Connectivity VGA DVI-D Features Speakers: 2 x 1W (Stereo) Tilt: 20° VESA 100 x 100 HDCP Supported Plug & Play: VESA DDC2B Power Power Supply: AC 100
- 240 V, 50 / 60 Hz (internal) Consumption On mode: 16W Consumption power management mode: 0.5W

Dimensions (Wx Hx D) 414.5 x 420.5 x 200.5mm






...

Protected LCD for public environment This high quality 21, 5” LCD monitor has a toughened safety glass fitted behind the bezel. It offers 8H hardness rating, capable of resisting above normal pressure & impacts to the display. The high end LCD panel with LED backlights not only reduces the power consumption it also offers a bright image with high contrast. The Pro Lite P2252HS meets the increasing demands for Protected Economical LCD’s within Education, Retail & Industrial applications & can also be used for CCTV through HDMI input. Technical

Specification Display 21.5” Screen TN Panel LED backlit Resolution: 1920 x 1080 Full HD Aspect ratio: 16:9 Brightness: 225 cd/m 2 Static Contrast ratio: 1000:1 ACR Contrast ratio: 5000000:1 Response Time: 5ms Viewing angle: Horizontal/vertical: 170°/ 160°; right/left: 85°/ 85°; up/down: 80°/ 80° Colour

Depth: 16.7M Pixel Pitch: 0.248 x 0.248mm Connectivity VGA DVI-D HDMI Features HDCP supported 2 x 1W Stereo Speakers Plug & Play: VESA DDC2B Kensington lock prepared Tilt angle: 20° up; 0° down VESA 100 x 100 Compatible with Apple-Mac Power Voltage: 100 ~ 240V AC Power consumption: 18W Power management mode: 0.5W

Dimensions 516.5 x 382.5 x 195mm (Wx Hx D)





...

Protected LCD for public environment This high quality 21, 5” LCD monitor has a toughened safety glass fitted behind the bezel. It offers 8H hardness rating, capable of resisting above normal pressure & impacts to the display. The high end LCD panel with LED backlights not only reduces the power consumption it also offers a bright image with high contrast. The Pro Lite P2252HS meets the increasing demands for Protected Economical LCD’s within Education, Retail & Industrial applications & can also be used for CCTV through HDMI input. Technical Specification Display 21.5” Screen Panel: TN Resolution: 1920 x 1080 Full HD 1080p Aspect ratio: 16:9 Response Time: 8ms Brightness: 225 cd/m 2 Static Contrast: 1000:1 Advanced Contrast ratio: 5, 000, 000:1 Viewing angle: horizontal/vertical: 170°/ 160°; right/left: 85°/ 85°; up/down: 80°/ 80° Display Colours: 16.7M Pixel Pitch: 0.248 x 0.248mm Horizontal sync: 24
- 80 KHz Vertical sync: 55
- 75 Hz Connectivity VGA DVI-D HDMI Features Plug & Play: VESA DDC2B VESA 100 x 100 HDCP Supported Kensington-lock™ prepared Tilt: 20° up; 0 ° down Power Power Supply: AC 100
- 240 V, 50 / 60 Hz Power consumption on: 18W Power consumption (Power management): 0.5W

Dimensions (Wx Hx D) 516.5 x 382.5 x 195mm




...

Give your sales promotions & your in-store displays maximum impact & visibility with the Pro Lite S3820HSB-B1. The S3820HSB is a 38" (1920x 540) digital signage display that is ideally suited for retail, transportation, business & health care environments where a regular 16:9 display will not fit. With a 24/7 operating time, landscape & portrait orientation & brightness of 1000cd/m 2, this display can be installed anyhow & anywhere you want, ensuring an optimal fit & maximum exposure. The S3820HSB is fanless, only weighs 8.8kg & comes with two handles for easy handling & installation. VESA VESA mount compliance means you can easily mount the display to any mounting that complies with the VESA standard. FULL HD With true 1920 x 1080p resolution your monitor is ready to display high definition images. This means you can accommodate more information on your screen; e.g. 60% more in comparison to a 1280 x 1024 monitor. 24/7 24/7 displays are designed for a continuous operation. AMVA3 AMVA3 technology offers higher contrast, darker blacks & much better viewing angles than standard TN technology. The screen will look good no matter what angle you look at it. ...

Touch technology – capacitive This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, & the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance & will work with human finger (gloved or not) & magnetic ball. IP54 The IP Code classifies how resistant a device is to foreign objects & moisture. IP54 means that the monitor will operate in dusty conditions & will resist splashing water. Scratch resistance Scratch resistance is essential for touch solutions used in public places & schools. This is achieved thanks to a glass overlay covering the screen. It guarantees high durability of the touch function & even more importantly the touch function remains unaffected even if the glass is scratched. VESA VESA mount compliance means you can easily mount the LFD to any mounting that complies with the VESA standard. ...
