Specifications Cooler
- i Cooler GPU
- 7790 Core Clock
- 1075 MHz Memory Clock
- 6400 MHz Memory Size
- 1024 MB Memory




...

Specifications Chipset
- AMD Radeon HD 7850 PCI-e Series ASIC
- AMD Radeon HD 7850 GPU Manu. Process (Micron)
- 28nm Memory


...

The new architecture of the card gets more usable processing power for your money, enabling better frame rates in the latest games at high resolutions. In addition, with AMD Power Play and AMD Power Tune technologies, you can optimize the balance between performance & power consumption of your system by adjusting the engine clock during runtime of the card. Manage the power & keep your wallet loaded! Model Name
- HIS 7850 Fan 1GB GDDR5 PCI-E DVI/HDMI/2x Mini DP Chipset
- Radeon HD 7850 PCIe Series ASIC
- Radeon TM HD 7850 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 1024 Memory Type
- GDDR5 Engine CLK (MHz)
- 860 M Hz Memory CLK (Gbps)
- 4.8 Gbps Memory Interface (bit)
- 256bit Power Supply Requirement
- 500 Watt or greater power Max. Resolution
- 4096x 2160 per display (Display Port 1.2) 2560x 1600 per display (Dual-link DVI) 2048x 1536 per display (VGA) Bus Interface
- PCI Express 3.0 x 16 Mini Display Port
- Yes HDMI
- Yes DVI
- Dual-link DVI-I VGA
- No HD 7850 System Requirements
- PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 500W (or greater) power supply with one 75W 6-pin PCI Express power connectors recommended Certified power supplies are recommended. Refer to http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx for a list of Certified products Minimum 1GB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray™ playback requires Blu-ray drive The operation of AMD Cross Fire™ technology in dual mode requires a second AMD Radeon™ HD 7800 Series graphics card & an AMD Cross Fire™ Ready motherboard
















...

HIS 7850 Ice Q Turbo features i Power for more voltage, Faster Turbo Clock, Ice Q is Cooler & Quieter, i Turbo, Long Lasting Design Model Name
- HIS 7850 Ice Q Turbo 2GB GDDR5 PCI-E DVI/HDMI/2x Mini DP Chipset
- Radeon HD 7850 PCIe Series ASIC
- Radeon TM HD 7850 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 2048 Memory Type
- GDDR5 Engine CLK (MHz)
- 1000 M Hz Memory CLK (Gbps)
- 4.8 Gbps Memory Interface (bit)
- 256bit Power Supply Requirement
- 500 Watt or greater power Max. Resolution
- 4096x 2160 per display (Display Port 1.2) 2560x 1600 per display (Dual-link DVI) 2048x 1536 per display (VGA) Bus Interface
- PCI Express 3.0 x 16 Mini Display Port
- Yes HDMI
- Yes DVI
- Dual-link DVI-I VGA
- No HD 7850 System Requirements
- PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 500W (or greater) power supply with two 75W 6-pin PCI Express power connectors recommended Certified power supplies are recommended. Refer to http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx for a list of Certified products Minimum 1GB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray™ playback requires Blu-ray drive The operation of AMD Cross Fire™ technology in dual mode requires a second AMD Radeon™ HD 7800 Series graphics card & an AMD Cross Fire™ Ready motherboard
















...

Ice Q X Cooler, Quieter Cooler Ice Q X is cooler than the Reference Cooler. Thanks to the 9.2cm silent fan, massive amount of cool air is drawn from the central fan to cool down the GPU & graphics card directly. 4 heatpipes optimize cooling performance by removing heat from the core area, providing ultimate solution for professional gamers & HTCP users. Quieter Ice Q X is one of the quietest coolers. The card is below 28d B when watching movies, surfing Facebook, working. The card is quiet in 2D mode & remains quiet whether you are gaming, online socializing, entertaining or working. High Quality Components HIS uses only the finest materials & the most advanced techniques to build our cards, making them one of the most stable & durable product in the industry. Dynamic Phase Control PWM IC The advanced energy saving technique not only makes HIS cards environmental friendly but also saves money on your electric bills! Full Solid State Capacitors These capacitors of the excellent quality & durability extends the lifespan of the card. You can count on HIS cards to game hard for 24/7/365 for years! Solid State Choke Using these innovative material, HIS cards offer outstanding stability & power capacity -making the best out of power & unleashing clock speeds to the limit! New Design, New Experiences PCI-e 3.0 Support Armed with the latest PCI-e 3.0 bus design maximizes performance by delivering double bandwidth per lane of PCI-e 2.x. Paired the card with the latest platforms & get the ultimate performance! Specifications Chipset
- AMD Radeon HD 7850 PCIe Series ASIC
- AMD Radeon HD 7850 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 2048 Memory Type
- GDDR5 Engine CLK (MHz)
- 860 M Hz Memory CLK (Gbps)
- 4.8 Gbps Memory Interface (bit)
- 256bit Power Supply Requirement
- 500 Watt or greater power Max. Resolution
- 4096x 2160 per display (Display Port 1.2), 2560x 1600 per display (Dual-link DVI), 2048x 1536 per display (VGA) Bus Interface
- PCI Express 3.0 x 16 Mini Display Port
- Yes HDMI
- Yes DVI
- Dual-link DVI-I HD 7850 System Requirement PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 500W (or greater) power supply with one 75W 6-pin PCI Express power connectors recommended Certified power supplies are recommended. Minimum 1GB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray playback requires Blu-ray drive The operation of AMD Cross Fire technology in dual mode requires a second AMD Radeon HD 7800 Series graphics card & an AMD Cross Fire Ready motherboard













...

PCI-e 3.0 Support Armed with the latest PCI-e 3.0 bus design maximizes performance by delivering double bandwidth per lane of PCI-e 2.x. Paired the card with the latest platforms & get the ultimate performance! More Graphics, Less Power The new architecture of the card gets more usable processing power for your money, enabling better frame rates in the latest games at high resolutions. In addition, with AMD Power Play„¢ & AMD Power Tune technologies, you can optimize the balance between performance & power consumption of your system by adjusting the engine clock during runtime of the card. Manage the power & keep your wallet loaded! See More, Win More! The card is capable to turn your computer into a super gaming machine. Enjoy the latest 3D games with stunning graphics & effects that your enemies cannot match! Get an immersive experience with AMD Eyefinity 2.0! Expand your game across up to 4 displays while your opponents have one monitor. Along with all-new support for stereo 3D, universal bezel compensation & brand new display configurations, take the unfair advantage over your opponent & win more with the surround sight! The HIS 7950 3GB supports 30 LCD monitor & any large size TV up to 80" feature with 16:9 ratio in amazing 4096 by 2160 resolution. Up-scaling your computer into a multimedia center with the biggest display! Specifications Chipset
- AMD Radeon HD 7950 PCIe Series ASIC
- Radeon HD 7950 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 3072 Memory Type
- GDDR5 Engine CLK (MHz)
- 800 M Hz Memory CLK (Gbps)
- 5 Gbps Memory Interface (bit)
- 384bit Power Supply Requirement
- 500 Watt or greater power Max. Resolution
- 4096x 2160 per display (Display Port 1.2), 2560x 1600 per display (Dual-link DVI), 2048x 1536 per display (VGA) Bus Interface
- PCI Express 3.0 x 16 Mini Display Port
- Yes HDMI
- Yes DVI
- Dual-link DVI-I HD 7950 System Requirement PCI Express based PC is required with one X16 lane graphics slot with 2 slots space available on the motherboard 500W (or greater) power supply with two 75W 6-pin PCI Express power connectors recommended Certified power supplies are recommended Minimum 1GB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray playback requires Blu-ray drive The operation of AMD Cross Fire technology in dual mode requires a second AMD Radeon HD 7950 graphics card & an AMD Cross Fire Ready motherboard













...

HIS 7950 Ice Q Boost Clock features Boost Clock is Faster, Ice Q, is Cooler & Quieter, i Turbo & Long Lasting Design! Model Name
- HIS 7950 Ice Q Boost Clock 3GB GDDR5 PCI-E DVI/HDMI/2x Mini DP Chipset
- Radeon HD 7950 PCIe Series ASIC
- Radeon TM HD 7950 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 3072 Memory Type
- GDDR5 Engine CLK (MHz)
- 850 M Hz (Boost Clock 925 M Hz) Memory CLK (Gbps)
- 5 Gbps Memory Interface (bit)
- 384bit Power Supply Requirement
- 500 Watt or greater power Max. Resolution
- 4096x 2160 per display (Display Port 1.2) 2560x 1600 per display (Dual-link DVI) 2048x 1536 per display (VGA) Bus Interface
- PCI Express 3.0 x 16 Mini Display Port
- Yes HDMI
- Yes DVI
- Dual-link DVI-I VGA
- No HD 7950 System Requirements
- PCI Express based PC is required with one X16 lane graphics slot with 2 slots space available on the motherboard 500W (or greater) power supply with two 75W 6-pin PCI Express power connectors recommended Certified power supplies are recommended. Refer to http://support.amd.com/us/certified/power-supplies/ Pages/listing.aspx for a list of Certified products Minimum 1GB of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray™ playback requires Blu-ray drive The operation of AMD Cross Fire™ technology in dual mode requires a second AMD Radeon™ HD 7950 graphics card & an AMD Cross Fire™ Ready motherboard.
















...

New Design, New Experiences PCI-e 3.0 Support Armed with the latest PCI-e 3.0 bus design maximizes performance by delivering double bandwidth per lane of PCI-e 2.x. Paired the card with the latest platforms & get the ultimate performance! More Graphics, Less Power The new architecture of the card gets more usable processing power for your money, enabling better frame rates in the latest games at high resolutions. In addition, with AMD Power Play„¢ & AMD Power Tune technologies, you can optimize the balance between performance & power consumption of your system by adjusting the engine clock during runtime of the card. Manage the power & keep your wallet loaded! See More, Win More! The card is capable to turn your computer into a super gaming machine. Enjoy the latest 3D games with stunning graphics & effects that your enemies cannot match! Connect your screens with the specially bundled Active Mini Display Port to SL-DVI Dongle & you are ready to get an immersive experience with AMD Eyefinity 2.0! Expand your game across up to 4 displays while your opponents have one monitor. Along with all-new support for stereo 3D, universal bezel compensation & brand new display configurations, take the unfair advantage over your opponent & win more with the surround sight! Game Better & Faster With full Microsoft Direct X 11.1 support, the card is ready for next generation Direct X games. Equipped with AMD HD3D technology, you can enjoy a stereo 3D experience in the latest 3D games. The card also offers up to 2x faster tessellation & faster Direct Compute over earlier cards. Gamers will be pleased to enjoy the life-like graphics! See Better, Enjoy Better The HIS 7970 3GB supports 30 LCD monitor & any large size TV up to 80" feature with 16:9 ratio in amazing 4096 by 2160 resolution. Up-scaling your computer into a multimedia center with the biggest display! Specifications Chipset
- AMD Radeon HD 7970 PCIe Series ASIC
- AMD Radeon HD 7970 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 3072 Memory Type
- GDDR5 Engine CLK (MHz)
- 925 M Hz Memory CLK (Gbps)
- 5.5 Gbps Memory Interface (bit)
- 384 Power Supply Requirement
- 500 Watt or greater power Max. Resolution
- 4096x 2160 per display (Display Port 1.2), 2560x 1600 per display (Dual-link DVI), 2048x 1536 per display (VGA) Bus Interface
- PCI Express x 16 Mini Display Port
- Yes HDMI
- Yes DVI
- Dual-link DVI-I HD 7970 System Requirement PCI Express based PC is required with one X16 lane graphics slot with 2 slots space available on the motherboard 500W (or greater) power supply with one 150W 8-pin PCI Express power connector & one 75W 6-pin PCI Express power connector recommended Certified power supplies are recommended Minimum 1GB of system memory Installation software requires CD-ROM drive, a keyboard, a mouse, & a display DVD playback requires DVD drive Blu-ray playback requires Blu-ray drive













...

Hightech Information System (HIS) today announced the launch of HIS 7970 Ice Q X&sup 2; 3GB. This world’s fastest card with single GPU is cooler & quieter with the innovative & performance-leading Ice Q X&sup 2; solution. The card also has better OC capability & longer life span with HIS high quality component. Model Name
- HIS 7970 Ice Q X&sup 2; 3GB GDDR5 PCI-E DVI/HDMI/2x Mini DP Chipset
- Radeon HD 7970 PCIe Series ASIC
- Radeon TM HD 7970 GPU Manu. Process (Micron)
- 28nm Memory Size (MB)
- 3072 Memory Type
- GDDR5 Engine CLK (MHz)
- 925 M Hz Memory CLK (Gbps)
- 5.5 Gbps Memory Interface (bit)
- 384 Power Supply Requirement
- 500 Watt or greater power Max. Resolution
- 4096x 2160 per display (Display Port 1.2) 2560x 1600 per display (Dual-link DVI) 2048x 1536 per display (VGA) Bus Interface
- PCI Express x 16 Mini Display Port
- Yes HDMI
- Yes DVI
- Dual-link DVI-I VGA
- No HD 7970 System Requirements
- PCI Express based PC is required with one X16 lane graphics slot with 2 slots space available on the motherboard 500W (or greater) power supply with one 150W 8-pin PCI Express power connector & one 75W 6-pin PCI Express power connector recommended Certified power supplies are recommended. Refer to http://ati.amd.com/certified PSU for a list of Certified products Minimum 1GB of system memory Installation software requires CD-ROM drive, a keyboard, a mouse, & a display DVD playback requires DVD drive Blu-ray™ playback requires Blu-ray drive
















...

The Mini Display Port to HDMI Adapter enable you to connect any HDMI interface embedded device (Monitor, Projector...) with a Mini Display Port interface (Desktop, Laptop) & no need to purchase any Mini Display Port embedded terminal device. * Supports audio output for Macbook Pro / i Mac released on or after mid-2010 Features No extra drivers need when it plugs Support Plug & Play for easy use Mini DP to HDMI with resolution till 1920x 1200 2 channel Audio function Compliant with HDMI 1.3a Quick Installation Guide 1. Notice Please check following information before using this product. The prouduct DO NOT need any external drivers This product is the adapter for connecting Mini Display Port to HDMI port. Make sure that your source device (Desktop, Laptop..) has been Mini Display Port embedded or bundled any adapter / connector with Mini Display Port Make sure that your terminal device (Monitor, Projector...) has been HDMI port embedded or bundled any adapter / connector with HDMI port 2. Making the Connection Connect the Mini Display Port connector to the source device coordinative port. Then connect the HDMI connector to your terminal device coordinative port as well. If your terminal device (Monitor, Projector...) has not been connected to the adapter yet, make the connection & power on your terminal device again. System Requirements Windows XP, Windows Vista, Windows 7 & Mac OS X v 10.5 or later ...
