Video/ Audio Input IP video input: 16-ch Two-way audio input: 1-ch, RCA (2.0 Vp-p, 1k& Omega;) Network Incoming band
Width: 160 Mbps Outgoing band
Width: 80 Mbps Remote connection: 128 Video/ Audio Output HDMI/VGA output: 1-ch, resolution: 1920 x 1080P /60 Hz, 1600 x 1200 /60 Hz, 1280 x 1024 /60 Hz, 1280 x 720 /60 Hz, 1024 x 768 /60 Hz Recording Resolution: 6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF Frame Rate: Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) Audio Output: 1-ch, RCA (Linear, 1k& Omega;) Synchronous Playback: 16-ch Decoding Live view / Playback: 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF Capability: 16-ch@4CIF, 12-ch@720P, 6-ch@1080P Hard Disk SATA: 4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs Capacity: Up to 6TB capacity for each HDD External Interface Network Interface: 1RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface USB (Universal Serial Bus) Interface: Front panel: 2 x USB 2.0 Rear panel: 1 x USB 3.0 Alarm In: 16-ch Alarm Out: 4-ch POE Interface: 16 independent 100 Mbps Po E network interfaces Max. Power: 200W Supported Standard: AF and AT General Power Supply: 100~240VAC Consumption (without hard disk & POE): ≤ 20W Working Temperature: -10 degrees C ~ +55 degrees C (+14 degrees F~ + 131 degrees F) Working Humidity: 10 % ~ 90 % Chassis: 19-inch rack-mounted 1.5U chassis Dimensions: 445 x 390 x 70mm (17.5 x 15.3 x 2.8 inch) Weight (without HDD): ≤ 4kg (8.82 lb)
