USB Logic-analyser attachment & GLA-1016. Highlights &
Details: 16 input ports. Time analysis with 200 MHz internal Sampling Rate. Signal analysis & signal statistic. Description: The GLA-1016 is extremely small, but offers all the measurement capabilities of large appliances. The USB (Universal Serial Bus) version execution a convenient handling is ensured. The comprehensive measurement functions make the attachment, in conjunction with a computer, an ideal measuring system for all Digital systems analysis. Features. Memory
Depth: 128 Kbit/channel. Status analysis up to 100 MHz. Data export for measuring signal & settings. Signal analysis for I2C, RS232 & signal statistic. Included in delivery. Bag. Software CD. 16-channel holding wire. 20 wedge hook. Operating instructions. USB (Universal Serial Bus) cable. System requirements. PC with USB (Universal Serial Bus) 2.0 (1.1 compatible) & CD-ROM. Windows 98/98SE/ Me/2000/XP. Technical data: Weight 340 g. Interfaces 1x USB (Universal Serial Bus) 2.0. Inputs 16. Bandwidth (RBW) 200 MHz.
Dimensions (L x W x H) 102 x 137 x 39 mm. Type GLA-1016. Input impedance 500 k/10 p F. Bandwidth 200 MHz.
