Features Supports 10th Gen Intel Core™ Series Processors Dual Channel Non-ECC Unbuffered DDR4, 2DIMMs Intel Optane™ Memory Ready Direct 8 Phase Digital VRM Solution with 90A Smart Power Stage Extended MOSFET Heatsink & Multi-Layered PCH M.2 Heatsink with Heatpipes Onboard Intel Wi Fi 6 802.11ax 2T2R & BT 5 with AORUS Antenna Blazing Fast Intel 2.5 Gb E LAN with c Fos Speed AMP-UP Audio with ALC1220-VB for Rear 120d B SNR HDMI 2.0 supports Premium 4K Best Choice for Small but Powerful PC Z490I AORUS ULTRA is a mini-ITX motherboard perfect for building a small form factor PC for people who demands higher performance but also cares about aesthetics. The compact yet powerful pc delivers amazing performance with the latest 10th gen CPU, dual slots graphic card & blazing fast connectivity. It also equips with comprehensive thermal solution to keep it cool under heavy workload. Performance is not compromised by its size. Z490I AORUS ULTRA motherboard uses an pure digital CPU power design which

Includes:: a digital PWM Controller with Smart Power Stages & is capable of providing 90A of power from each phase for a total of 720A. This 100% digital controller, new Tantalum Polymer Capacitors array, & Solid-pin CPU Power Connectors offer incredible precision & stability in delivering power to the motherboards most power-hungry & energy-sensitive components, allowing professional worker & gamer to get the incredible high performance from the latest 10th Gen. Intel Core™ processors. Unparalleled Performance GIGABYTE realize that our customer wont stop chasing a better computer performance. We take care of it & implement more on products. Optimized memory trace enhance the performance. Faster read & write are needed to save time & improve efficiency. We offer plenty of M.2 Storage with thermal guards to ensure unthrottled read & write. In advance, adopting PCIe 4.0 ready components get the Z490 easier to upgrade. Next Generation Connectivity Network connectivity is getting more important nowadays. Majority of Desktop PC are with both ethernet & WIFI for the stable connection to avoid interrupt or bad signal. The Z490I AORUS ULTRA features the fastest WIFI 6 that improves the reliability & performance in dense environment. Furthermore, As 4k Monitor become more popular, ultra high resolution display output is also required.

...

Supports 10th Gen Intel Core™ Series Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Ultra-Fast PCIe Gen 3 X4 M.2 Connectors Multi-Way Graphics Support with Dual Armor & Ultra Durable™ Design Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP Intel Optane™ Memory Ready 4+2 Hybrid Digital VRM Solution with Low RDS (on) MOSFET GIGABYTE motherboards use Low RDS (on) MOSFETs which reduce energy wastage through unnecessary residual heat dissipation. This all amounts to tangible energy saving which are beneficial for both end-users & the environment without impacting system performance. Benefits of Low RDS (on) MOSFETs Optimized gate charge to minimize switching losses. Lower temperature, smaller size, better thermal characteristics. NVMe PCIe Gen 3 x 4 M.2 Connectors GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. 2-Way Cross Fire™ Multi-Graphics Multi-graphics configuration offers better graphics performance for gaming enthusiasts who demand the highest frame rates without compromising on resolution. Intel Gb E LAN with c Fos Speed Internet Accelerator Networking Intel Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments. The Industrys Leading LAN Static-Electricity & Surge Protection GIGABYTE motherboards use ICs with up to 3 times the ESD resistance levels compared to traditional ICs. This helps to better protect the motherboard & its components against potential damage caused by static electricity. GIGABYTE motherboards also feature special anti-surge ICs that protect your motherboard, & your PC from any surge in power delivery that may occur, helping to ensure that your PC is equipped to deal with any potentially irregular & inconsistent power delivery. ...

Features Supports 10th Gen Intel Core™ Series Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Intel Optane™ Memory Ready Direct 11+1 Phases Digital VRM Solution with Dr MOS Enlarged VRM Heatsink with 5W/m K Thermal Conductive Pad Intel Gb E LAN with c Fos Speed Internet Accelerator Software Multi-Way Graphics Support with Dual Armor & Ultra Durable™ Design ALC1200 Multi-Channel Audio with High Quality Audio Capacitors & Audio Noise Guard Dual Ultra-Fast M.2 with PCIe Gen 3 X4 (1 with Thermal Guard) & SATA Interface Intel Native USB (Universal Serial Bus) 3.2 Gen 2 Type-A with Speed Up To 10 Gbps RGB FUSION 2.0 Support Addressable LED & RGB LED Strips Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading. Optimized gate charge to minimize switching losses. Lower temperature, smaller size, better thermal characteristics Support for DDR4 XMP Up to 4600 M Hz & Beyond* GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 4600 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their AORUS motherboard. Shielded Memory Routing All memory routing is under the PCB inner layer shielded by a large ground layer to protect from external interference. 2-Way Cross Fire™ Multi-Graphics Multi-graphics configuration offers better graphics performance for gaming enthusiasts who demand the highest frame rates without compromising on resolution. Dual NVMe PCIe Gen 3 x 4 M.2 Connectors GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. GIGABYTE Ultra-Efficient M.2 Thermal Guard With durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling & bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue. ...

FEATURES Supports 11th & 10th Gen Intel Core™ Series Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Intel Optane™ Memory Ready 18+1 Phases Digital VRM Solution with 90A Smart Power Stage & Tantalum Polymer Capacitors Array Shielded Memory Routing to Avoid Interference Advanced Thermal Solution with Fins-Array II, Direct Touch Heatpipe II & Nano Carbon Baseplate Onboard Intel Wi Fi 6E 802.11ax 2T2R & BT 5 with AORUS Antenna 125d B SNR AMP-UP Audio with High-End ESS SABRE 9118 DAC, ALC1220 & WIMA Audio Capacitors AQUANTIA 10 Gb E BASE-T LAN with c Fos Speed Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x 4 M.2 with Thermal Guards II RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP & Noise Detection Q-Flash Plus Update BIOS without Installing the CPU, Memory & Graphics Card A Solid Foundation for Your System Here to herald the arrival of the latest generation of Intel CPUs is the AORUS Master Motherboard, this beast is filled with the top-shelf components required to deliver top-rate performance & high-end reliability for mainstream daily users & gaming enthusiasts. Boasting an upgraded digital VRM power solution, an advanced cooling solution with fins-array II technology & a nanocarbon base plate, Wi-Fi 6E support & incredible PCI-e Gen 4.0 interfaces for your GPU & M.2 Slot, combine that with another two additional ultra-fast M.2 slots running at PCIe 3.0 x 4, RGB Fusion 2.0 support, Aquantia 10 Gb E Base-T LAN, high quality audio & a comprehensive rear I/O & you have everything you need to ensure you remain at the top of your game. The Z590 AORUS MASTER, the best for the PRO. Pure Digital Power Design Z590 AORUS MASTER uses an pure digital CPU power design which

Includes:: a digital PWM Controller with Smart Power Stages & is capable of providing 90A of power from each phase for a total of 1620A. This 100% digital controller, new Tantalum Polymer Capacitors Array, & additional 8+8 Solid-pin CPU Power Connectors offer incredible precision & stability in delivering power to the motherboards most power-hungry & energy-sensitive components, allowing enthusiasts to get the absolute maximum overclocking performance from the new 8-core 11th Gen. Intel Core™ processors. SUPPORT FOR DDR4 XMP UP TO 5000MHZ & BEYOND AORUS is offering a tested & proven platform that ensures proper compatibility with profiles up to 5000 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their AORUS motherboard. Un-throttled performance is guaranteed by the enhanced thermal solution that incorporates Fins-Array II, Heatpipe II & Thermal Guards II. The comprehensive solution delivers excellent heat dissipation. The Z590 AORUS MASTER stays cool on VRMs & M.2 SSD even on full loading, making it most suitable for enthusiasts, overclockers & professional gamers & with Smart Fan 6 technology containing several unique cooling features that ensure gaming PCs maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fans & pumps, & users can easily define each fan curve based on different temperature sensors across the board via an intuitive user interface.

...

FEATURES Supports 11th & 10th Gen Intel Core™ Series Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Intel Optane™ Memory Ready Direct 12+1 Phases Digital VRM Solution with 90A Smart Power Stage Shielded Memory Routing to avoid Interference Advanced Thermal Solution with Fins-Array II Heatsink, Direct Touch Heatpipe II & Thermal Guard II Intel Wi Fi 6 802.11ax 2T2R & BT5 with AORUS Antenna AMP-UP Audio with ALC4080 & WIMA for Rear 120d B SNR Blazing Fast Intel 2.5 Gb E LAN with c Fos Speed Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x 4 M.2 with Thermal Guards II for extreme RAID Performance RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP & Noise Detection Q-Flash Plus Update BIOS without Installing the CPU, Memory & Graphics Card * Actual support may vary by CPU. EXTREME POWER DESIGN To unleash the full potential of the latest Intel 11th Gen CPU, the motherboard requires the best CPU power design. With the best quality components & GIGABYTE R&D design capability, Z590 AORUS PRO AX is a true beast among motherboards UNPARALLELED PERFORMANCE GIGABYTE understands that our customer wont stop chasing better computer performance, & strive to deliver that in our products. For the Z590 series, protective & optimized memory trace enhance the performance; faster read & write speed save time & improve efficiency; & generous M.2 Storage with thermal guards ensure unthrottled read & write performance. Future upgrades to the Z590 are made possible by the use of PCIe 4.0-ready components. ADVANCED THERMAL SOLUTION Unthrottled performance is guaranteed by the enhanced thermal solution that incorporates Fins-Array II, Direct-Touch Heatpipe II & Thermal Guards II. The comprehensive solution delivers excellent heat dissipation. The Z590 AORUS PRO AX stays cool on VRMs & M.2 SSD even on full loading, making it most suitable for enthusiasts, overclockers & professional gamers. NEXT GENERATION CONNECTIVITY A high-end product needs to be future-proof so your system stays up-to-date with the latest technology. Z590 AORUS PRO AX provides all next generation network, storage, & WIFI connectivity to keep you up to speed. DEFINITIVE AESTHETICS Z590 AORUS PRO AX features RGB FUSION 2.0 & offers users the option to control onboard, external light strips, and/or AORUS devices with RGB/ Addressable RGB LEDs to make their PC more unique & stylish. ULTRA DURABLE GIGABYTE is reputable for its product durability & high quality manufacturing process. Needless to say, we use the best components we can find for the GIGABYTE motherboard & reinforce every slot to make each of them solid & durable. ...

Key Features • Supports 11th & 10th Gen Intel Core Series Processors • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs • 20+1 Phases Digital VRM Solution with 100A Smart Power Stage & Tantalum Polymer Capacitors Array • XTREME MEMORY with SMT DIMM & Shielded Memory Routing • Thermal Reactive Armor with Fins-Array II Heatsink, Direct Touch Heatpipe II & Nano Carbon Baseplate • Intel Thunderbolt 4 Onboard • Onboard Intel Wi Fi 6E 802.11ax 2T2R & BT 5 with 2X AORUS Antenna • Exclusively bundled ESSential USB (Universal Serial Bus) DAC • 127d B SNR AMP-UP Audio with High-End ESS SABRE 9018K2M DAC, LME 49720, OPA1622 & WIMA Audio Capacitors • AQUANTIA 10 Gb E BASE-T LAN & Intel 2.5 Gb E LAN with c Fos Speed • Exclusively bundled AORUS PRO Gen 4 AIC Adaptor • Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x 4 M.2 with Thermal Guards II UNPARALLELED PERFORMANCE To unleash the full potential of the new Intel 11th Gen CPU, the motherboard requires the best CPU power, memory & IO design. With the best quality components & GIGABYTE R&D design capability, Z590 AORUS XTREME is a true beast among motherboards. 20*+1 PHASES TRUE POWER DESIGN • Pure Digital PWM Architecture • 100A Dr MOS for Each Phase • High Current Capacity Driver-MOSFET • Tantalum Polymer Capacitors Array • 8+8 Solid Pin CPU Power Connector • Low Temperature • Improved Transient THERMAL REACTIVE ARMOR Z590 AORUS XTREME uses an unprecedented & innovative thermal design to ensure the best CPU, Chipset, SSD stability & low temperatures under full load application & gaming. AORUS M.2 Thermal Guard II With durability in mind, GIGABYTE provides a new thermal solution for large capacity M.2 SSD devices with double side flash. The M.2 Thermal Guard II uses a double-sided heatsink design & prevents throttling & bottlenecks on high speed M.2 SSDs by dissipating heat before it becomes an issue. Smart Fan 6 Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool & quiet. Multiple fan headers can support PWM/DC fan & pump, & users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface. ...

Features Supports 11th & 10th Gen Intel Core™ Series Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Direct 12+1 Phases Digital VRM Solution with Low RDS (on) MOSFETs Shielded Memory Routing for Better Memory Overclocking Enlarged VRM Heatsink with Multi-Cut to increased surface contact Dual Ultra-Fast NVMe PCIe 4.0*/3.0 x 4 M.2 GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP Q-Flash Plus Update BIOS without Installing the CPU, Memory & Graphics Card Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading. • Digital PWM Controller to deliver appropriate voltage to the CPU. • Direct 12+1 Phases Low RDS (on) MOSFETs without PWM Doublers, each power phase connects directly to the CPU. • All-solid capacitors to improve transient response & minimize oscillation. • 8+4 Solid Pin CPU Power Connectors. RGB FUSION 2.0 With Z590 D Motherboard, RGB Fusion 2.0 is even better with Addressable LEDs.* RGB Fusion 2.0 offers users the option to control onboard RGB & external RGB / Addressable LED light strips for their PC. Already feature filled with colors & patterns, RGB Fusion 2.0 on Z590 Series Motherboards are now upgraded with Addressable LED support. With external Addressable LED strips*, where each LED is digitally addressable, users can experience even more patterns, styles, & illuminations. With Z590 D Motherboard will support either 5v or 12v Addressable LED lighting strips & up to 300 LED lights. RGB Fusion 2.0 with Addressable LEDs comes with new patterns & various speed settings with more to come. Refreshed BIOS The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system. ...

Features • Supports 11th & 10th Gen Intel Core™ Series Processors • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs • Direct 12+1 Phases Digital VRM Solution with 60A Dr MOS • Shielded Memory Routing for Better Memory Overclocking • Fully Covered Thermal Design with High Coverage MOSFET Heatsinks • Fast 2.5 Gb E LAN with Bandwidth Management • Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x 4 M.2 with Thermal Guards • Rear USB (Universal Serial Bus) 3.2 Gen 2 Type-C & Front USB3.2 Gen 1 Type-C for Connecting Devices • Pre-installed IO Shield for Easy & Quick Installation • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips • Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP • Q-Flash Plus Update BIOS without Installing the CPU, Memory & Graphics Card DIRECT POWER DESIGN Z590 GAMING X motherboard uses an 12+1 phases digital CPU power design which

Includes:: both digital PWM Controller & Dr MOS. These 100% digital controller & additional 8+4 Solid-pin CPU Power Connectors offer incredible precision in delivering power to the motherboards most power-hungry & energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from the new Intel 11th Gen CPU. ADVANCED THERMAL SOLUTION Z590 GAMING X uses high performance Fully Covered thermal design with high coverage MOSFET Heatsinks & thick thermal pad, providing ultimate MOSFET cooling performance for enthusiasts, overclockers & gamers. NEXT GENERATION CONNECTIVITY A high-end product needs to be future-proof so your system stays up-to-date with the latest technology. Z590 GAMING X provides all next generation network, storage, connectivity to keep you up to speed. DEFINITIVE AESTHETICS Z590 GAMING X features RGB FUSION 2.0 & offers users the option to control onboard, external light strips, and/or GIGABYTE devices with RGB/ Addressable RGB LEDs to make their PC more unique & stylish.

...

Features • Supports 11th & 10th Gen Intel Core™ Series Processors • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs • Direct 12+1 Phases Digital VRM Solution with 60A Dr MOS • Shielded Memory Routing for Better Memory Overclocking • Fully Covered Thermal Design with High Coverage MOSFET Heatsinks • Fast 2.5 Gb E LAN with Bandwidth Management • Dual Ultra-Fast NVMe PCIe 4.0/3.0 x 4 M.2 with Thermal Guard • Rear USB (Universal Serial Bus) 3.2 Gen 2 Type-C & Front USB3.2 Gen 1 Type-C for Connecting devices • Pre-installed IO Shield for easy & quick installation • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips • Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP • Q-Flash Plus Update BIOS without Installing the CPU, Memory & Graphics Card DIRECT POWER DESIGN Z590M GAMING X motherboard uses an 12+1 phases digital CPU power design which

Includes:: both digital PWM Controller & Dr MOS. These 100% digital controller & additional 8+4 Solid-pin CPU Power Connectors offer incredible precision in delivering power to the motherboards most power-hungry & energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from the new Intel 11th Gen CPU. ADVANCED THERMAL SOLUTION Z590M GAMING X uses high performance Fully Covered thermal design with high coverage MOSFET Heatsinks & thick thermal pad, providing ultimate MOSFET cooling performance for enthusiasts, overclockers & gamers. NEXT GENERATION CONNECTIVITY A high-end product needs to be future-proof so your system stays up-to-date with the latest technology. Z590M GAMING X provides all next generation network, storage, connectivity to keep you up to speed. High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers.

...

Features • Supports 11th & 10th Gen Intel Core™ Series Processors • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs • Direct 12+1 Phases Digital VRM Solution with 50A Dr MOS • Shielded Memory Routing for Better Memory Overclocking • Enlarged VRM Heatsink with Air-Flow Grooving to Increased Surface Contact • Fast 2.5 Gb E LAN with Bandwidth Management • Onboard Intel 802.11ac Wireless & BT with High-Gain Antenna • Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x 4 M.2 with Thermal Guard • USB (Universal Serial Bus) 3.2 Gen 2 & Front USB (Universal Serial Bus) Type-C for Fast & Versatile Connections • Pre-installed IO Shield for Easy & Quick Installation • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips • Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP • Q-Flash Plus Update BIOS without Installing the CPU, Memory & Graphics Card Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading. Digital PWM Controller to deliver appropriate voltage to the CPU. Direct 12+1 Phases Dr MOS without PWM Doublers, each power phase connects directly to the CPU, With capability to handle 600 Amps current in total. All-solid capacitors to improve Transient response & minimize oscillation. 8+4 Solid Pin CPU Power Connectors. Support for DDR4 XMP Up to 4800 M Hz & Beyond* GIGABYTE is offering a tested & proven platform that ensures proper compatibility with profiles up to 4800 M Hz & beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable & that the XMP function is activated & enabled on their GIGABYTE motherboard. RGB FUSION 2.0 With Z590 UD AC Motherboard, RGB Fusion 2.0 is even better with Addressable LEDs.* RGB Fusion 2.0 offers users the option to control onboard RGB & external RGB / Addressable LED light strips for their PC. Already feature filled with colors & patterns, RGB Fusion 2.0 on Z590 Series Motherboards are now upgraded with Addressable LED support. With external Addressable LED strips*, where each LED is digitally addressable, users can experience even more patterns, styles, & illuminations. ...
