Features Supports 8th Gen Intel Core™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Intel Optane™ Memory Ready 2-Way Cross Fire™ Multi-Graphics Intel Gigabit LAN with c Fos Speed Internet Accelerator Software Ultra Durable™ 25KV ESD & 15KV Surge LAN Protection High Quality Audio Capacitors & Audio Noise Guard with LED Trace Path Lighting Ultra-Fast M.2 with PCIe Gen 3 x 4 & SATA interface RGB FUSION supports RGB LED strips in 7 colors Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers with FAN STOP Anti-Sulfur Resistors Design APP Center Including Easy Tune™ & Cloud Station™ Utilities Overview Smart Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM & Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. Fan pin header Temperature Sensors &9632; 6 Temperature Sensors &9632; 4 Fan/ Water Pump Connectors &9632; All Fan Pin Headers Upgraded to Hybrid Fan Headers &9632; Interoperable Fans & Sensors &9632; Intuitive UI for Fan Control Achieve fan silence. With Fan Stop map any fan to stop completely when temperatures drop below a specified threshold. Which fan stops, based on readings from which sensor, & at what temperature—all of it can be customized to your liking. Intel Optane Memory The GIGABYTE Z370 Platform is the first enthusiast platform that supports Intel’s latest Optane technology. Optane fuels storage performance by acting as a cache drive giving users a significant boost compared to traditional mechanical drives. Connecting the Future
- USB (Universal Serial Bus) Type-C™: The Worlds Next Universal Connector The USB (Universal Serial Bus) Type-C™ is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.1 Gen 1 support & faster charging capabilities. Powered by the Intel controller, this little port is the better USB (Universal Serial Bus) Type-C™. Intel Gb E LAN with c Fos Speed Internet Accelerator Networking Intel Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments. Supports RGB Light Strips in 7 Colors Personalize your next PC rig to your liking by selecting the color of your choice to illuminate the external RGB light strip. A total of 7 colors are available to make your system appearance unique! High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high-quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE Z370 motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level. LED trace path lighting Illuminates to show the separation of the PCB layers. The Industrys Leading Static-Electricity & Surge Protection Orange
- GIGABYTE LAN Protection Grey
- Traditional LAN Port Protection *ESD result is undertaken by individual LAN port

Specification CPU Support for 8th Generation Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors in the LGA1151 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel Z370 Express Chipset Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory Dual channel memory architecture Support for DDR4 4000 (O.C.) / 3866 (O.C.) / 3800 (O.C.) / 3733 (O.C.) / 3666 (O.C.) / 3600 (O.C.) / 3466 (O.C.) / 3400 (O.C.) / 3333 (O.C.) / 3300 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 / 2400 / 2133 MHz memory modules Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor-Intel HD Graphics support: 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x 2160@30 Hz * Support for HDMI 1.4 version & HDCP 2.2. Maximum shared memory of 1 GB Audio Realtek ALC892 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Intel Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 2 x PCI Express x 16 slots, running at x 4 (PCIEX4_1, PCIEX4_2) 3 x PCI Express x 1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.) Storage Interface Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe x 4/x 2 SSD support) 6 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Refer to "1-7 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. Intel Optane™ Memory Ready Multi-Graphics Technology Support for AMD Quad-GPU Cross Fire™ & 2-Way AMD Cross Fire™ technologies USB Chipset: 8 x USB (Universal Serial Bus) 3.1 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) 6 x USB (Universal Serial Bus) 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 1 x RGB LED strip header 6 x SATA 6 Gb/s connectors 1 x M.2 Socket 3 connector 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB (Universal Serial Bus) 3.1 Gen 1 headers 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x 6 pin, for the GC-TPM2.0_S module only) 1 x parallel port header 1 x serial port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x DVI-D port 1 x HDMI port 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports 2 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 6 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS Auto Green BIOS Setup Color Temperature Cloud Station Easy Tune Easy RAID Fast Boot Game Boost ON/OFF Charge Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart Time Lock Smart HUD System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) c Fos Speed Operating System Support for Windows 10 64-bit Form Factor ATX Form Factor; 30.5cm x 22.5cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.




...

Features Supports 8th Gen Intel Core™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Intel Optane™ Memory Ready ASMedia 3142 USB (Universal Serial Bus) 3.1 Gen 2 with USB (Universal Serial Bus) Type-C™ & Type-A Front USB (Universal Serial Bus) 3.1 Gen 1 Type-C™ Header 2-Way Cross Fire™ Multi-Graphics with PCIe Armor & Ultra Durable™ Design ALC1220 120d B SNR HD Audio with Smart Headphone Amp Intel Gigabit LAN with c Fos Speed Internet Accelerator Software Ultra Durable™ 25KV ESD & 15KV Surge LAN Protection Dual Ultra-Fast M.2 with PCIe Gen 3 x 4 & SATA interface RGB FUSION supports RGB LED strips in 7 colors Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers with FAN STOP Anti-Sulfur Resistors Design APP Center Including Easy Tune™ & Cloud Station™ Utilities Overview Smart Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM & Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. Fan pin header Temperature Sensors &9632; 6 Temperature Sensors &9632; 4 Fan/ Water Pump Connectors &9632; All Fan Pin Headers Upgraded to Hybrid Fan Headers &9632; Interoperable Fans & Sensors &9632; Intuitive UI for Fan Control Achieve fan silence. With Fan Stop map any fan to stop completely when temperatures drop below a specified threshold. Which fan stops, based on readings from which sensor, & at what temperature—all of it can be customized to your liking. Intel Optane Memory The GIGABYTE Z370 Platform is the first enthusiast platform that supports Intel’s latest Optane technology. Optane fuels storage performance by acting as a cache drive giving users a significant boost compared to traditional mechanical drives. USB (Universal Serial Bus) Type-C™ Front Panel Connector Equipped with next generation connectivity onboard GIGABYTE Motherboards already support the cases of the future. Onboard headers for USB (Universal Serial Bus) 3.1 Gen 1 makes access convenient when connecting a USB (Universal Serial Bus) 3.1 Gen 1 drive or charging your new mobile device. Intel Gb E LAN with c Fos Speed Internet Accelerator Networking Intel Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments. Supports RGB Light Strips in 7 Colors Personalize your next PC rig to your liking by selecting the color of your choice to illuminate the external RGB light strip. A total of 7 colors are available to make your system appearance unique! High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high-quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE Z370 motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level. LED trace path lighting Illuminates to show the separation of the PCB layers. The Industrys Leading Static-Electricity & Surge Protection Orange
- GIGABYTE LAN Protection Grey
- Traditional LAN Port Protection *ESD result is undertaken by individual LAN port

Specification CPU Support for 8th Generation Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors in the LGA1151 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel Z370 Express Chipset Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory Dual channel memory architecture Support for DDR4 4000 (O.C.) / 3866 (O.C.) / 3800 (O.C.) / 3733 (O.C.) / 3666 (O.C.) / 3600 (O.C.) / 3466 (O.C.) / 3400 (O.C.) / 3333 (O.C.) / 3300 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 / 2400 / 2133 MHz memory modules Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor-Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x 2160@30 Hz * Support for HDMI 1.4 version & HDCP 2.2. Support for up to 3 displays at the same time Maximum shared memory of 1 GB Audio Realtek ALC1220 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Intel Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) * The PCIEX4 slot shares bandwidth with the M2Q_32G connector. The PCIEX4 slot will become unavailable when an SSD is installed in the M2Q_32G connector. 4 x PCI Express x 1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.) 1 x PCI slot Storage Interface Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe x 4/x 2 SSD support) (M2A_32G) 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x 4/x 2 SSD support) (M2Q_32G) 6 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Refer to "1-7 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. Intel Optane™ Memory Ready Multi-Graphics Technology Support for AMD Quad-GPU Cross Fire X™ & 2-Way AMD Cross Fire™ technologies USB Chipset+ASMedia USB (Universal Serial Bus) 3.1 Gen 2 Controller: 1 x USB (Universal Serial Bus) Type-C™ port on the back panel, with USB (Universal Serial Bus) 3.1 Gen 2 support 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port (red) on the back panel Chipset: 1 x USB (Universal Serial Bus) Type-C™ port with USB (Universal Serial Bus) 3.1 Gen 1 support, available through the internal USB (Universal Serial Bus) header 6 x USB (Universal Serial Bus) 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) 6 x USB (Universal Serial Bus) 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 2 x M.2 Socket 3 connectors 6 x SATA 6 Gb/s connectors 1 x CPU fan header 3 x system fan headers 1 x RGB LED strip header 1 x front panel header 1 x front panel audio header 1 x USB (Universal Serial Bus) Type-C™ header, with USB (Universal Serial Bus) 3.1 Gen 1 support 1 x USB (Universal Serial Bus) 3.1 Gen 1 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x S/PDIF Out header 1 x Trusted Platform Module (TPM) header (2x 6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 1 x USB (Universal Serial Bus) Type-C™ port, with USB (Universal Serial Bus) 3.1 Gen 2 support 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port (red) 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports 2 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 6 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS Auto Green BIOS Setup Color Temperature Cloud Station Easy Tune Easy RAID Fast Boot Game Boost ON/OFF Charge Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart Time Lock Smart HUD System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) c Fos Speed Operating System Support for Windows 10 64-bit Form Factor ATX Form Factor; 30.5cm x 22.5cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.



...

Features Supports 8th Gen Intel Core™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Intel Optane™ Memory Ready Intel USB (Universal Serial Bus) 3.1 Gen 1 with USB (Universal Serial Bus) Type-C™ 2-Way Cross Fire™ Multi-Graphics Support Intel Gigabit LAN with c Fos Speed Internet Accelerator Software Ultra Durable™ 25KV ESD & 15KV Surge LAN Protection High Quality Audio Capacitors & Audio Noise Guard with LED Trace Path Lighting Dual Ultra-Fast M.2 with PCIe Gen 3 x 4 & SATA interface RGB FUSION supports RGB LED strips in 7 colors Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers with FAN STOP Anti-Sulfur Resistors Design APP Center Including Easy Tune™ & Cloud Station™ Utilities Overview Smart Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM & Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. Fan pin header Temperature Sensors &9632; 6 Temperature Sensors &9632; 4 Fan/ Water Pump Connectors &9632; All Fan Pin Headers Upgraded to Hybrid Fan Headers &9632; Interoperable Fans & Sensors &9632; Intuitive UI for Fan Control Achieve fan silence. With Fan Stop map any fan to stop completely when temperatures drop below a specified threshold. Which fan stops, based on readings from which sensor, & at what temperature—all of it can be customized to your liking. Intel Optane Memory The GIGABYTE Z370 Platform is the first enthusiast platform that supports Intel’s latest Optane technology. Optane fuels storage performance by acting as a cache drive giving users a significant boost compared to traditional mechanical drives. Connecting the Future
- USB (Universal Serial Bus) Type-C™: The Worlds Next Universal Connector The USB (Universal Serial Bus) Type-C™ is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.1 Gen 1 support & faster charging capabilities. Powered by the Intel controller, this little port is the better USB (Universal Serial Bus) Type-C™. Intel Gb E LAN with c Fos Speed Internet Accelerator Networking Intel Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments. Supports RGB Light Strips in 7 Colors Personalize your next PC rig to your liking by selecting the color of your choice to illuminate the external RGB light strip. A total of 7 colors are available to make your system appearance unique! High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high-quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE Z370 motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level. LED trace path lighting Illuminates to show the separation of the PCB layers.

Specification CPU Support for 8th Generation Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors in the LGA1151 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel Z370 Express Chipset Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory Dual channel memory architecture Support for DDR4 4000 (O.C.) / 3866 (O.C.) / 3800 (O.C.) / 3733 (O.C.) / 3666 (O.C.) / 3600 (O.C.) / 3466 (O.C.) / 3400 (O.C.) / 3333 (O.C.) / 3300 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 / 2400 / 2133 MHz memory modules Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor-Intel HD Graphics support: 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x 2160@30 Hz * Support for HDMI 1.4 version & HDCP 2.2. Maximum shared memory of 1 GB Audio Realtek ALC892 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Intel Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) 2 x PCI Express x 1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.) Storage Interface Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe x 4/x 2 SSD support) (M2A_32G) 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x 4/x 2 SSD support) (M2Q_32G) 6 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Refer to "1-7 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. Intel Optane™ Memory Ready Multi-Graphics Technology Support for AMD Quad-GPU Cross Fire X™ & 2-Way AMD Cross Fire™ technologies USB Chipset: 1 x USB (Universal Serial Bus) Type-C™ port on the back panel, with USB (Universal Serial Bus) 3.1 Gen 1 support 8 x USB (Universal Serial Bus) 3.1 Gen 1 ports (6 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) headers) 4 x USB (Universal Serial Bus) 2.0/1.1 ports available through the internal USB (Universal Serial Bus) headers Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 3 x system fan headers 1 x RGB LED strip header 6 x SATA 6 Gb/s connectors 2 x M.2 Socket 3 connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB (Universal Serial Bus) 3.1 Gen 1 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x 6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x DVI-D port 1 x HDMI port 1 x USB (Universal Serial Bus) Type-C™ port, with USB (Universal Serial Bus) 3.1 Gen 1 support 6 x USB (Universal Serial Bus) 3.1 Gen 1 ports 1 x RJ-45 port 6 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS Auto Green BIOS Setup Color Temperature Cloud Station Easy Tune Easy RAID Fast Boot Game Boost ON/OFF Charge Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart Time Lock Smart HUD System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) c Fos Speed Operating System Support for Windows 10 64-bit Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.


...

Features Supports 8th Gen Intel Core™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Ultra-Fast M.2 with PCIe Gen 3 x 4 & SATA interface Intel Optane™ Memory Ready Dual display interfaces including High Definition Multimedia Interface High Quality Audio Capacitors & Audio Noise Guard with LED Trace Path Lighting Gb E LAN with c Fos Speed Internet Accelerator Software Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers GIGABYTE UEFI Dual BIOS™ APP Center Including Cloud Station™ Utility Overview Smart Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM & Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. NVMe PCIe Gen 3 x 4 2280 M.2 Connector GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. Realtek Gb E LAN with c Fos Speed Internet Accelerator Networking Realtek Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments.

Specification CPU Support for 8th Generation Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors in the LGA1151 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel Z370 Express Chipset Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory Dual channel memory architecture Support for DDR4 3866 (O.C.) / 3800 (O.C.) / 3733 (O.C.) / 3666 (O.C.) / 3600 (O.C.) / 3466 (O.C.) / 3400 (O.C.) / 3333 (O.C.) / 3300 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 / 2400 / 2133 MHz memory modules Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor-Intel HD Graphics support: 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x 2160@30 Hz * Support for HDMI 1.4 version & HDCP 2.2. Maximum shared memory of 1 GB Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 2 x PCI Express x 1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.) Storage Interface Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe x 4/x 2 SSD support) 6 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Refer to "1-7 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. Intel Optane™ Memory Ready USB Chipset: 6 x USB (Universal Serial Bus) 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) 6 x USB (Universal Serial Bus) 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 6 x SATA 6 Gb/s connectors 1 x M.2 Socket 3 connector 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB (Universal Serial Bus) 3.1 Gen 1 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x 6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x DVI-D port 1 x HDMI port 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports 2 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS Auto Green BIOS Setup Color Temperature Cloud Station Easy Tune Easy RAID Fast Boot Game Boost ON/OFF Charge Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart Time Lock Smart HUD System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) c Fos Speed Operating System Support for Windows 10 64-bit Form Factor Micro ATX Form Factor; 22.6cm x 19.3cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.

...

Model Z370N-WIFI CPU 1151 v 2 Chip Z370 Form Factor ITX DMI PCI Express Gen 3 VGA On CPU Graphics 1 x PCI Express x 16 slots, running at x 16 SLI Cross Fire N/A PCI N/A PCI-Ex 1 N/A Memory Type 2 ch, 2 DIMM DDR4 Memory Socket DDR 4 *2 USB (Universal Serial Bus) Rear Ports 1 USB (Universal Serial Bus) 3.0 Type C, 6 USB (Universal Serial Bus) 3.0 Rear Ports USB (Universal Serial Bus) (Ports from Header) 2 USB (Universal Serial Bus) 3.0 (Headers), 2 USB (Universal Serial Bus) 2.0 (Headers) SATA3 4 M.2 Slot 1 TPM N/A RAID RAID 0, 1, 5, 10 Audio ALC1220 Video Out 1 x Display port, 2 x HDMI LAN 1 x Gb E Intel 219V Wi Fi Intel Windstorm Peak 8265NGW 2x 2 11ac & BT4.2 Light Effect N/A RGB Header RGBW 1 (5 pin), Digital header 1 (3 pin) Fan Header 4 Slot Armour PCIe, Memory Debug LED N/A Dual BIOS Yes Com Port N/A ...

Features Supports 8th Gen Intel Core™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Intel Optane™ Memory Ready ASMedia 3142 USB (Universal Serial Bus) 3.1 Gen 2 with USB (Universal Serial Bus) Type-C™ & Type-A Multi-Way Graphics Support with PCIe Armor & Ultra Durable™ Design ALC1220 120d B SNR HD Audio with Smart Headphone Amp Intel Gigabit LAN with c Fos Speed Internet Accelerator Software Ultra Durable™ 25KV ESD & 15KV Surge LAN Protection Dual Ultra-Fast M.2 with PCIe Gen 3 x 4 & SATA interface RGB FUSION supports RGB LED strips in 7 colors Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers with FAN STOP Anti-Sulfur Resistors Design Lightning-Fast Intel Thunderbolt™ 3 AIC Support APP Center Including Easy Tune™ & Cloud Station™ Utilities Overview Smart Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM & Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. Fan pin header Temperature Sensors Fan/ Water Pump pin header &9632; 6 Temperature Sensors &9632; 5 Fan/ Water Pump Connectors &9632; All Fan Pin Headers Upgraded to Hybrid Fan Headers &9632; Interoperable Fans & Sensors &9632; Intuitive UI for Fan Control Achieve fan silence. With Fan Stop map any fan to stop completely when temperatures drop below a specified threshold. Which fan stops, based on readings from which sensor, & at what temperature—all of it can be customized to your liking. Intel Optane Memory The GIGABYTE Z370 Platform is the first enthusiast platform that supports Intel’s latest Optane technology. Optane fuels storage performance by acting as a cache drive giving users a significant boost compared to traditional mechanical drives. Connecting the Future
- USB (Universal Serial Bus) Type-C™: The Worlds Next Universal Connector The USB (Universal Serial Bus) Type-C™ is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.1 Gen 1 support & faster charging capabilities. Powered by the Intel controller, this little port is the better USB (Universal Serial Bus) Type-C™. Intel Gb E LAN with c Fos Speed Internet Accelerator Networking Intel Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments. Supports RGB Light Strips in 7 Colors Personalize your next PC rig to your liking by selecting the color of your choice to illuminate the external RGB light strip. A total of 7 colors are available to make your system appearance unique! High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high-quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE Z370 motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level. LED trace path lighting Illuminates to show the separation of the PCB layers. The Industrys Leading Static-Electricity & Surge Protection Orange
- GIGABYTE LAN Protection Grey
- Traditional LAN Port Protection *ESD result is undertaken by individual LAN port

Specification CPU Support for 8th Generation Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors in the LGA1151 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel Z370 Express Chipset Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory Dual channel memory architecture Support for DDR4 4000 (O.C.) / 3866 (O.C.) / 3800 (O.C.) / 3733 (O.C.) / 3666 (O.C.) / 3600 (O.C.) / 3466 (O.C.) / 3400 (O.C.) / 3333 (O.C.) / 3300 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 / 2400 / 2133 MHz memory modules Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x 2160@30 Hz * Support for HDMI 1.4 version & HDCP 2.2. Maximum shared memory of 1 GB Audio Realtek ALC1220 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Intel Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x 16 slot, running at x 8 (PCIEX8) * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x 8 mode. 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) * The PCIEX4 slot shares bandwidth with the M2Q_32G connector. The PCIEX4 slot will become unavailable when an SSD is installed in the M2Q_32G connector. 3 x PCI Express x 1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.) Storage Interface Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe x 4/x 2 SSD support) (M2P_32G) 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x 4/x 2 SSD support) (M2Q_32G) 6 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Refer to "1-8 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. Intel Optane™ Memory Ready Multi-Graphics Technology Support for NVIDIA Quad-GPU SLI™ & 2-Way NVIDIA SLI™ technologies Support for AMD Quad-GPU Cross Fire X™ & 3-Way/2-Way AMD Cross Fire™ technologies USB Chipset+ASMedia USB (Universal Serial Bus) 3.1 Gen 2 Controller: 1 x USB (Universal Serial Bus) Type-C™ port on the back panel, with USB (Universal Serial Bus) 3.1 Gen 2 support 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port (red) on the back panel Chipset: 10 x USB (Universal Serial Bus) 3.1 Gen 1 ports (6 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) 4 x USB (Universal Serial Bus) 2.0/1.1 ports available through the internal USB (Universal Serial Bus) headers Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x water cooling CPU fan header 2 x system fan headers 1 x system fan/water cooling pump header 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 6 x SATA 6 Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB (Universal Serial Bus) 3.1 Gen 1 headers 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x 6 pin, for the GC-TPM2.0_S module only) 1 x Thunderbolt™ add-in card connector 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x HDMI port 1 x USB (Universal Serial Bus) Type-C™ port, with USB (Universal Serial Bus) 3.1 Gen 2 support 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port (red) 6 x USB (Universal Serial Bus) 3.1 Gen 1 ports 1 x RJ-45 port 6 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Overheating warning Fan fail warning Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS Auto Green BIOS Setup Color Temperature Cloud Station Easy Tune Easy RAID Fast Boot Game Boost ON/OFF Charge Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart Time Lock Smart HUD System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) c Fos Speed Operating System Support for Windows 10 64-bit Form Factor ATX Form Factor; 30.5cm x 22.5cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.




...

. rm-bg {background: url (https://img.ebyrcdn.net/894584-861438-800.jpg) no-repeat left center;
Colour: black; background-


...

Features Supports 9th & 8th Gen Intel Core™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Intel Optane™ Memory Ready 12 Phases IR Digital VRM Solution with Pow I Rstage Advanced Thermal Design with Fins-Array Heatsink & Direct Touch Heatpipe Onboard Intel CNVi 802.11ac 2x 2 Wave 2 Wi-Fi 125d B SNR AMP-UP Audio with ALC1220 & High-End ESS SABRE 9118 DAC with WIMA audio capacitors USB (Universal Serial Bus) Turbo Charger for Mobile Device Fast Charge Support Intel Gigabit LAN with c Fos Speed RGB FUSION with Multi-Zone Addressable LED Light Show Design, Supports Addressable LED & RGB LED Strips Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers with FAN STOP Front USB (Universal Serial Bus) 3.1 Gen 2 Type-C™ Header Triple Ultra-Fast NVMe PCIe Gen 3 x 4 M.2 with Triple Thermal Guard USB (Universal Serial Bus) DAC-UP 2 with Adjustable Voltage CEC 2019 Ready, Save Power With a Simple Click Overview DESIGN CONCEPT DOMINANT IN DARKNESS In the dark, starless night, the falcon strikes fear into the heart of its prey. Even with minimal visibility, the falcon pinpoints its prey & patiently anticipates the perfect moment to swoop in for the kill. The falcon with its laser sharp gaze dominates the darkness of night in the same manner that AORUS Core Lighting illuminates the vast AORUS ecosystem. AORUS PERFORMANCE 12 Phase Digital Power Design 40A IR 3553 for each v Core Phase High current capacity MOSFET Lower temperature Server level reliability Z390 AORUS MASTER motherboard uses an all IR digital CPU power design which

Includes:: both digital PWM Controller & Powl Rstage MOSFET, & is capable of providing at least 40A of power from each phase, for a total of 480A. These 100% digital controller & additional 8+8 Solid-pin CPU Power Connectors offer incredible precision in delivering power to the motherboards most power-hungry & energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from the new 8-core 9th Gen Intel Core™ processors. Advanced Thermal Design Z390 AORUS MASTER reaches a perfect balance between style & performance by combining the media acclaimed Fins-Array heatsink, a heatpipe, & a thermal baseplate, to provide 30% lower MOSFET temperatures for enthusiasts, overclockers & professional gamers. Triple PCIe Gen 3 x 4 M.2 AORUS Gaming Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their systems potential.

Specification CPU 1. Support for 9th & 8th Generation Intel Core™ i 9 processors/ Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1151 package 2. L3 cache varies with CPU (Please refer to "CPU Support List" for more information.) Chipset 1. Intel Z390 Express Chipset Memory 1. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory 2. Dual channel memory architecture 3. Support for DDR4 4266 (O.C.) / 4133 (O.C.) / 4000 (O.C.) / 3866 (O.C.) / 3800 (O.C.) / 3733 (O.C.) / 3666 (O.C.) / 3600 (O.C.) / 3466 (O.C.) / 3400 (O.C.) / 3333 (O.C.) / 3300 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 / 2400 / 2133 MHz memory modules 4. Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) 5. Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules 6. Support for Extreme Memory Profile (XMP) memory modules (Please refer to " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor-Intel HD Graphics support: 1. 1 x HDMI port, supporting a maximum resolution of 4096x 2160@30 Hz * Support for HDMI 1.4 version & HDCP 2.2. Maximum shared memory of 1 GB Audio 1. Realtek ALC1220-VB codec * The front panel line out jack supports DSD audio. 2. ESS SABRE 9118 DAC 3. High Definition Audio 4. 2/4/5.1/7.1-channel 5. Support for S/PDIF Out LAN 1. Intel Gb E LAN chip (10/100/1000 Mbit) Wireless Communication module 1. Intel CNVi interface 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band 2. BLUETOOTH 5 3. Support for 11ac 160 MHz wireless standard & up to 1.73 Gbps data rate * Actual data rate may vary depending on environment & equipment. Expansion Slots 1. 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 2. 1 x PCI Express x 16 slot, running at x 8 (PCIEX8) * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x 8 mode. 3. 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) * The PCIEX4 slot shares bandwidth with the M2P connector. The PCIEX4 slot operates at up to x 2 mode when a PCIe SSD is installed in the M2P connector. 4. 3 x PCI Express x 1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.) 5. 1 x M.2 Socket 1 connector for an Intel CNVi wireless module (CNVI) Storage Interface Chipset: 1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe x 4/x 2 SSD support, Intel Hybrid SSD support) (M2M) 2. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe x 4/x 2 SSD support) (M2A) 3. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 PCIe x 4/x 2 SSD support) (M2P) 4. 6 x SATA 6 Gb/s connectors 5. Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Refer to "1-9 Internal Connectors, " for the installation notices for the PCIEX4, M.2 & SATA connectors. Intel Optane™ Memory Ready Multi-Graphics Technology 1. Support for NVIDIA Quad-GPU SLI™ & 2-Way NVIDIA SLI™ technologies 2. Support for AMD Quad-GPU Cross Fire™ & 3-Way/2-Way AMD Cross Fire™ technologies USB (Universal Serial Bus) Chipset: 1. 1 x USB (Universal Serial Bus) Type-C™ port with USB (Universal Serial Bus) 3.1 Gen 2 support, available through the internal USB (Universal Serial Bus) header 2. 1 x USB (Universal Serial Bus) Type-C™ port on the back panel, with USB (Universal Serial Bus) 3.1 Gen 2 support 3. 3 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A ports (red) on the back panel 4. 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) Chipset+USB 2.0 Hub: 1. 8 x USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1. 1 x 24-pin ATX main power connector 2. 2 x 8-pin ATX 12V power connectors 3. 1 x CPU fan header 4. 1 x water cooling CPU fan header 5. 4 x system fan headers 6. 2 x system fan/water cooling pump headers 7. 2 x Addressable LED strip headers 8. 2 x Addressable LED strip power select jumpers 9. 2 x RGB LED strip headers 10. 3 x M.2 Socket 3 connectors 11. 6 x SATA 6 Gb/s connectors 12. 1 x front panel header 13. 1 x front panel audio header 14. 1 x S/PDIF Out header 15. 1 x USB (Universal Serial Bus) Type-C™ port, with USB (Universal Serial Bus) 3.1 Gen 2 support 16. 1 x USB (Universal Serial Bus) 3.1 Gen 1 header 17. 2 x USB (Universal Serial Bus) 2.0/1.1 headers 18. 1 x Thunderbolt™ add-in card connector 19. 1 x Trusted Platform Module (TPM) header (2x 6 pin, for the GC-TPM2.0_S module only) 20. 1 x OC button 21. 1 x reset button 22. 2 x temperature sensor headers 23. 2 x BIOS switches 24. 1 x Clear CMOS jumper 25. Voltage Measurement Points Back Panel Connectors 1. 1 x Power/ Reset button 2. 1 x Clear CMOS button 3. 2 x SMA antenna connectors (2T2R) 4. 1 x HDMI port 5. 1 x USB (Universal Serial Bus) Type-C™ port, with USB (Universal Serial Bus) 3.1 Gen 2 support 6. 3 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A ports (red) 7. 2 x USB (Universal Serial Bus) 3.1 Gen 1 ports 8. 4 x USB (Universal Serial Bus) 2.0/1.1 ports 9. 1 x RJ-45 port 10. 1 x optical S/PDIF Out connector 11. 5 x audio jacks I/O Controller 1. i TE I/O Controller Chip H/W Monitoring 1. Voltage detection 2. Temperature detection 3. Fan speed detection 4. Water cooling flow rate detection 5. Overheating warning 6. Fan fail warning 7. Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. BIOS 1. 2 x 128 Mbit flash 2. Use of licensed AMI UEFI BIOS 3. Support for Dual BIOS™ 4. Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features 1. Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS Auto Green Cloud Station Easy Tune Easy RAID Fast Boot Game Boost Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart Time Lock Smart HUD System Information Viewer Smart Survey USB (Universal Serial Bus) Blocker USB (Universal Serial Bus) DAC-UP 2 USB (Universal Serial Bus) Turbo Charger 2. Support for Q-Flash 3. Support for Xpress Install Bundle Software 1. Norton Internet Security (OEM version) 2. c Fos Speed 3. XSplit Gamecaster + Broadcaster (12 months license) Operating System 1. Support for Windows 10 64-bit Form Factor 1. ATX Form Factor; 30.5cm x 24.4cm Remark 1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. 2. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.



...

Features Supports 9th & 8th Gen Intel Core™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Intel Optane™ Memory Ready 12+1 Phases Digital VRM Solution with Dr MOS Advanced Thermal Design with Multi-cuts Heatsinks & Heatpipe ALC1220-VB Enhance 114d B (Rear) / 110d B (Front) SNR in Microphone with WIMA Audio Capacitors Intel Gigabit LAN with c Fos Speed RGB FUSION with Multi-Zone LED Light Show Design, Supports Addressable LED & RGB LED Strips Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers with FAN STOP Front USB (Universal Serial Bus) 3.1 Gen 1 Type-C™ Header Dual Ultra-Fast NVMe PCIe Gen 3 x 4 M.2 with Thermal Guards Multi-Way Graphics Support with Dual Armor & Ultra Durable™ Design CEC 2019 Ready, Save Power With a Simple Click Overview The AORUS Core is inspired by the falcons aggressive nature & hunting prowess. The falcon uses its razor sharp talons to swiftly strike down its prey with exceptional efficiency & precision, qualities that are exemplified in the fine details of AORUS design. 12*+1 Phases Digital Power Design Z390 AORUS PRO motherboard uses an 12+1 phases digital CPU power design which

Includes:: both digital PWM Controller & Dr MOS. These 100% digital controller & additional 8+4 Solid-pin CPU Power Connectors offer incredible precision in delivering power to the motherboards most power-hungry & energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from the new 8-core 9th Gen Intel Core™ processors. Advanced Thermal Design Z390 AORUS PRO uses very high performance thermal design by combining 2 heatsinks with Heatpipe, thick thermal pad, providing ultimate MOSFET cooling performance for enthusiasts, overclockers & gamers. Pre-installed I/O Shield With an integrated I/O shield, building a GIGABYTE Ultra Durable PC is even easier. Dual PCIe Gen 3 x 4 M.2 AORUS Gaming Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their systems potential.. rm-bg {background: url (https://img.ebyrcdn.net/894584-861438-800.jpg) no-repeat left center;
