Features Supports 7th/ 6th Generation Intel Core™ Processors. Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs. Supports PCIe x 16 slot bifurcation in 2x 8 mode by riser card. Intel USB (Universal Serial Bus) 3.1 Gen 1 with USB (Universal Serial Bus) Type-C™. Intel Optane™ Memory Ready. Ultra-Fast M.2 with PCIe Gen 3 x 4 & SATA interface. ALC1220 120d B SNR HD Audio with Smart Headphone Amp. 802.11ac Dual Band 867 Mbps wireless supports MU-MIMO & BT4.2. Dual Intel Gb E LAN with c Fos Speed Internet Accelerator Software. Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers. Ultra Durable™ Metal Shielding over PCIe Slots. GIGABYTE UEFI Dual BIOS™. APP Center Including Easy Tune™ & Cloud Station™ Utilities.

Specification CPU- Support for 7th & 6th generation Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1151 package Chipset- Intel Z270 Express Chipset Memory- 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR4 4000 (O.C.) / 3866 (O.C.) / 3800 (O.C.) / 3733 (O.C.) / 3666 (O.C.) / 3600 (O.C.) / 3466 (O.C.) / 3400 (O.C.) / 3333 (O.C.) / 3300 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 (O.C.) / 2400 (O.C.) / 2133 MHz memory modules Onboard Graphics Outputs- 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 2 x HDMI ports, supporting a maximum resolution of 4096x 2160@24 Hz * Support for HDMI 1.4 version. Support for up to 3 displays at the same time Maximum shared memory of 1 GB PCI Slots- 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) Storage- 1 x M.2 connector on the back of the motherboard (Socket 3, M key, type 2260/2280 SATA & PCIe x 4/x 2 SSD support) 6 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, RAID 5, & RAID 10 USB (Universal Serial Bus) Chipset:- 2 x USB (Universal Serial Bus) 2.0/1.1 ports available through the internal USB (Universal Serial Bus) header, 6 x USB (Universal Serial Bus) 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header), 1 x USB (Universal Serial Bus) Type-C™ port on the back panel, with USB (Universal Serial Bus) 3.1 Gen 1 support Audio- Realtek ALC1220 codec, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out LAN- 2 x Intel Gb E LAN chips (10/100/1000 Mbit) Wi Fi / Bluetooth- Wi-Fi 802.11 a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band BLUETOOTH 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR Support for 11ac wireless standard & up to 867 Mbps data rate * Actual data rate may vary depending on environment & equipment. Form Factor- Mini-ITX Form Factor; 17.0cm x 17.0cm Warranty- 3 Year Manufacturer Warranty

...

Ultra-Gaming ATX Motherboard. GIGABYTE Z270X Series The GA-Z270X Ultra Gaming motherboard from Gigabyte lives up to its label by providing gamers with the performance & control they need to win. M.2 connectors, c Fos Speed Intel Gb E LAN & its Thunderbolt port deliver the speed every gamer is looking for &, with support for 6th & 7th generation Intel processors, top of its class performance is assured. Advanced three-way graphics support provide a truly immersive gaming experience whilst RGB Fusion allows the gamer to customise multiple LED lighting zones with a dazzling array of colours. RGB Fusion Lighting AORUS 200 series motherboards boast the most advanced LED system in the market today. With more customizability than ever & a convenient & intuitive UI thanks to the RGB Fusion App, you’ll have a blast making your AORUS your own. LED enthusiasts now have even more options with the ability to customize multiple zones independently. For a more functional use, the bright & vibrant LEDs can be configured to display the PC’s temperature or load. For even more LED goodness RGBW strips are now supported for more true & vibrant whites. Z270X Lighting Overlay AORUS brings even more color & life to your system with an Accent LED Overlay. This overlay complements the RGB Fusion technology in AORUS Motherboards adding more flare & style to your gaming machine. With the swappable overlay users can utilize different patterns & designs to make their system their own. Design your very own Accent LED Overlay with a 3D printer. Advanced GIGABYTE Fusion Mode With the all new RGB Fusion software, users have access to different preset LED lighting configurations with choice of colors. You can even set the LEDs to synchronize with your favorite music or have them change colors to indicate the CPU temperature. For true lighting experts there is an Advanced Mode, which can be fully customized by individual area with its own effects & color transitions, along with specific duration & transition times. Once done, it’s simple to save & share your lighting profile with others. Smart Fan 5 Tech With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM & Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. All Hybrid Fan Headers can automatically detect the type of cooling device whether it be fan or pump with different PWM or Voltage mode. Plus, it supports up to 2 amps with built-in overcurrent protection—a must for high-end high current fans. GIGABYTE Smart Fan Software Choose from different modes, Quiet to Full Speed, to match your system usage scenario. For each fan or pump, you can use the intuitive fan curve to define trigger thresholds & corresponding fan speeds. Interoperable Sensors & Fans
- Each fan can be customized to operate at different speeds according to any defined temperature source input (except the CPU fan). Fan Curve
- Customize fan curves based on specific temperatures with the intuitive graphical UI. Z270X BIOS Interface The enhanced BIOS interface also has the advanced features seen in the Smart Fan 5 UI, such as: the ability to set triggers based on different temperature sensors on the board, fan curve definition & the temperature interval setting, which can prevent fan rotation noise caused by sudden temperature change—all without having to load Windows. Motherboard Audio Technology The ALC1220 is a high-performance multi-channel High Definition Audio Codec with up to 120d B SNR for crystal clear audio & features such as Smart Headphone Amp, 114d B SNR recording for precise voice chats & hardware decoding of DSD128, ensuring users get the best possible audio quality from their PC. GIGABYTE Gaming motherboards use high-end Chemicon audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Z270X USB (Universal Serial Bus) DAC-UP 2 Tech AORUS improves upon USB (Universal Serial Bus) DAC-UP technologies with USB (Universal Serial Bus) DAC-UP 2. USB (Universal Serial Bus) DAC-UP 2 continues to provide clean, isolated & low-noise power while adding the ability to compensate for voltage drop. Virtual reality pioneers & gamers alike can rest assured that their expensive accessories & peripherals will not encounter connectivity or power deficiency issues with the AORUS USB (Universal Serial Bus) DAC-UP 2. With Gaming Gear drawing large amounts of power & having firm

Specification requirements USB (Universal Serial Bus) DAC-UP 2 is up for the challenge. U.2 Onboard (NVMe PCIe Gen 3 x 4) The new Intel 750 series SSDs offer an incredible increase in performance over SATA drives. Using the NVMe protocol which takes advantage of the fast bandwidth of PCIe Gen 3 x 4 lanes (32 Gb/s), the drives are a clear advantage for users looking to boot their OS faster, load their games in a flash & access large files without waiting. By implementing the U.2 port onboard to support the 2.5” Intel 750 Series drive, GIGABYTE ensures that the users can benefit from the best performance. Rapid Onboard AORUS Storage GIGABYTEs M.2 solution offers considerably faster storage performance & support for both PCIe & SATA interfaces for M.2 SSD devices. Intel USB (Universal Serial Bus) 3.1 Controller The ASMEDIA 2142 USB (Universal Serial Bus) 3.1 controller utilizes 2 PCIe Gen 3 lanes, offering a total of up to 16 Gb/s, which means you have extra bandwidth to take full control of the 10 Gb/s USB (Universal Serial Bus) 3.1 ports. With twice the bandwidth compared to its previous generation, & backwards compatibility with USB (Universal Serial Bus) 2.0 & 3.0, the much enhanced USB (Universal Serial Bus) 3.1 protocol is available over the new reversible USB (Universal Serial Bus) Type-C™ & the traditional USB (Universal Serial Bus) Type-A connector for better compatibility over a wider range of devices. Z270X motherboard Diagnostic LEDs Onboard LEDs controlled by the system BIOS indicate if a malfunction is occurring, allowing users to quickly diagnose which major component (CPU/DDR/VGA/HDD) is malfunctioning so they may take action promptly. Intel Gb E LAN Intel Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments. Durable Motherboard PCIe Slots The innovative one piece stainless steel shielding design from AORUS reinforces the PCIe connectors to provide the extra strength required to support heavy graphics cards. Never worry about your heavy graphics card damaging your motherboard again. AORUS’ proprietary Ultra Durable PCIe Metal Shielding reinforces the PCIe connector to prevent slot damage due to heavy graphics card. The DIMM & PCIe metal shield also provides extra strength for when you forget to release the lock while replacing your component, adding a foolproof option which can save your PC’s life. Ultra Durable Memory Armour GIGABYTEs exclusive one piece stainless steel shielding design prevents against PCB distortion & twist, plate bending, in addition to preventing any possible ESD interference. Anti-Sulfur Resistor Design Sulfur compounds in the air can penetrate tiny onboard resistors creating chemical change & causing these resistors to open or short. If either of these occurs the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design AORUS gives Ultra Durable Motherboards a whole new meaning. GIGABYTE APP Center TThe GIGABYTE APP Center gives you easy access to a wealth of GIGABYTE apps that help you get the most from your GIGABYTE motherboard. Using a simple, unified user interface, GIGABYTE APP Center means that you can easily launch all GIGABYTE apps installed on your system, check related updates online, & download the latest apps, drivers, & BIOS. GIGABYTE Patented Dual BIOS GIGABYTE Ultra Durable motherboards feature GIGABYTE Dual BIOS, an exclusive technology from GIGABYTE that protects arguably one of your PCs most crucial components, the BIOS. GIGABYTE Dual BIOS means that your motherboard has both a Main BIOS & a Backup BIOS, protecting users from BIOS failure due to virus, hardware malfunction, improper OC settings or power failure during the update process. Capable GIGABYTE Capacitors GIGABYTE motherboards integrate the absolute best quality solid state capacitors that are rated to perform at maximum efficiency for extended periods, even in extreme performance configurations. With ultra-low ESR no matter how high the CPU load, this provides peace of mind for end users who want to push their system hard, yet demand absolute reliability & stability. These exclusive capacitors also come in customized jet black, exclusively on GIGABYTE motherboards. Z270X G-Connector The tiny cables of the front panel connectors can be hard to manipulate as space is restricted & indicators being tiny. With the G-Connector, you can connect all the FP cables at once, simplifying the process of building your next PC & saving you some frustrations. Tri Def Smart Cam Technology To facilitate being the full streaming solution each AORUS motherboard

Includes:: Tri Def Smart Cam software, you are now able to remove backgrounds without the hassle of using a green screen. Through the Smart Cam application you can now apply live filters, & fully control your background, not only while streaming, but also through other video applications such as Skype. Specifications CPU Support for 7th & 6th generation Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors/ Intel Pentiumprocessors/ Intel Celeron processors in the LGA1151 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel Z270 Express Chipset Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR4 3866 (O.C.) / 3800 (O.C.) / 3733 (O.C.) / 3666 (O.C.) / 3600 (O.C.) / 3466 (O.C.) / 3400 (O.C.) / 3333 (O.C.) / 3300 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 (O.C.) / 2400 (O.C.) / 2133 MHz memory modules Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor-Intel HD Graphics support: 1 x HDMI port, supporting a maximum resolution of 4096x 2160@24 Hz * Support for HDMI 1.4 version. 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. Maximum shared memory of 1 GB Audio Realtek ALC1220 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Intel Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x 16 slot, running at x 8 (PCIEX8) * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x 8 mode. 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) * The PCIEX4 slot shares bandwidth with the PCIEX1_2 & PCIEX1_3 slots. When the PCIEX1_2 or PCIEX1_3 slot is populated, the PCIEX4 slot operates at up to x 1 mode. 3 x PCI Express x 1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.) Multi-Graphics Technology Support for NVIDIA Quad-GPU SLI™ & 2-Way NVIDIA SLI™ technologies Support for AMD Quad-GPU Cross Fire X™ & 3-Way/2-Way AMD Cross Fire™ technologies Storage Interface Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe x 4/x 2 SSD support) 1 x U.2 connector 2 x SATA Express connectors 6 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Refer to "1-8 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. USB Chipset+ASMedia USB (Universal Serial Bus) 3.1 Gen 2 Controller: 1 x USB (Universal Serial Bus) Type-C™ port on the back panel, with USB (Universal Serial Bus) 3.1 Gen 2 support 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port (red) on the back panel Chipset: 8 x USB (Universal Serial Bus) 3.1 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) 6 x USB (Universal Serial Bus) 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x U.2 connector 1 x M.2 Socket 3 connector 2 x SATA Express connectors 6 x SATA 6 Gb/s connectors 1 x CPU fan header 1 x water cooling CPU fan header 2 x system fan headers 1 x system fan/water cooling pump header 1 x front panel header 1 x front panel audio header 2 x USB (Universal Serial Bus) 3.1 Gen 1 headers 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x RGB (RGBW) LED strip extension cable header 1 x S/PDIF Out header 1 x Trusted Platform Module (TPM) header 1 x Thunderbolt™add-in card connector 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x USB (Universal Serial Bus) Type-C™ port, with USB (Universal Serial Bus) 3.1 Gen 2 support 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port (red) 1 x DVI-D port 1 x HDMI port 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports 2 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 1 x optical S/PDIF Out connector 5 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In) I/O Controller i TE Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. BIOS 2 x 64 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS Auto Green BIOS Setup Color Temperature Cloud Station Easy Tune Easy RAID Fast Boot Game Boost GIGABYTE HW OC APP ON/OFF Charge Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart Time Lock System Information Viewer USB (Universal Serial Bus) Blocker USB (Universal Serial Bus) DAC-UP 2 V-Tuner Support for 3TB+ Unlock Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) Intel Optane™ Memory Ready c Fos Speed Operating System Support for Windows 10/8.1 64-bit Support for Windows 7 32-bit/64-bit * Operating systems supported may vary depending on your processor model. * Please download the " Windows USB (Universal Serial Bus) Installation Tool" from GIGABYTEs website & install it before installing Windows 7. Form Factor ATX Form Factor; 30.5cm x 24.4cm Box Contents GA-Z270X-Ultra Gaming motherboard Four SATA cables Motherboard driver disk I/O Shield Users Manual One G Connector Quick Installation Guide Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.. rm-cont h 2, . rm-row h 2{margin:0 0 10px}.u 1, . u 1-2{float:left}.rm-row{
Width:725px;overflow:hidden;padding:30px 0;border-bottom:1px solid eee;clear:both;font-family:" Helvetica Neue", Helvetica, Arial, sans-serif;font-
Size:12px}.rm-row h 2{font-
Size:22px!important}.rm-cont{padding:15px}.rm-cont img{max-
Width:100%!important;}. rm-align-center{max-
Width:100%;text-align:center!important}.rm-align-left{text-align:left!important}.rm-align-right{text-align:right!important}.u 1-2{
Width:50%}.u 1{
Width:100%; text-align:center;}.down-5{margin-top:5px}.down-10{margin-top:10px}.down-15{margin-top:15px}.down-20{margin-top:20px}.down-25{margin-top:25px}.down-30{margin-top:30px}. down-35{margin-top:35px}.down-40{margin-top:40px}.down-45{margin-top:45px}.down-50{margin-top:50px}.down-55{margin-top:55px}.down-60{margin-top:60px}.down-65{margin-top:65px}.down-70{margin-top:70px}.down-75{margin-top:75px}.down-80{margin-top:80px}.down-85{margin-top:85px}.down-90{margin-top:90px}. scale-img-50{
Width:50%!important}.scale-img-75{
Width:75%!important}














...

Features 6 PCIe Slots Perfect for Mining Supports 7th / 6th Generation Intel Core™ Processors Dual Channel DDR4, 2 DIMMs On board M.2 Connector for Fast Data Transfer 8-channel HD Audio with High Quality Audio Capacitors Audio Noise Guard with LED Trace Path Lighting Realtek Gb E LAN with c Fos Speed Internet Accelerator Software APP Center Including Easy Tune™ & Cloud Station™ Utilities GIGABYTE UEFI Dual BIOS™ Technology Product Overview GIGABYTE Ultra Durable ™ Motherboards GIGABYTE 100 series motherboards support the latest 6th Generation Intel Core™ processors, a 14nm desktop CPU which features enhanced performance, power efficiency & support for DDR4 memory, bringing cutting edge features & ultimate performance to your next PC build. Onboard M.2 Storage GIGABYTE M.2 solution offers considerably faster storage performance & support for SATA interface for M.2 SSD devices. Fast USB (Universal Serial Bus) 3.1 Solution The latest USB (Universal Serial Bus) 3.1 offers a staggering 10 Gb/s transfer speed, 2x faster than USB (Universal Serial Bus) 3.0 & backward compatibility with existing USB (Universal Serial Bus) devices. High Quality Onboard Audio Design Delivers high quality sound resolution & sound expansion to create the most realistic sound effects for professional gamers. Realtek Gb E LAN with c Fos Speed Internet Accelerator Software Realtek Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to delivery better responsiveness in a crowded LAN environments. Realtek Gb E consumes significant less power when it’s in idle state in comparison with others. Humidity Protection Glass Fabric PCB There is nothing more harmful to the longevity of your PC than moisture, & most parts of the world experience moisture in the air as humidity at some point during the year. GIGABYTE motherboards have been designed to make sure that humidity is never an issue, incorporating a new Glass Fabric PCB technology that repels moisture caused by humid & damp conditions. Glass Fabric PCB technology uses a new PCB material which reduces the amount of space between the fiber weave, making it much more difficult for moisture to penetrate compared to traditional motherboard PCBs. This offers much better protection from short circuit & system malfunction caused by humid & damp conditions. High ESD Ethernet & USB (Universal Serial Bus) Port Protection GIGABYTE motherboards raise the bar in terms of protecting your system, providing advanced electrostatic discharge (ESD) protection for both your Ethernet LAN & USB (Universal Serial Bus) ports, both common sources of ESD-related failures. With pairing the dedicated protection filters, the Ethernet LAN & USB (Universal Serial Bus) ports can withstand high electrostatic discharges, protecting your system from common electrical surges & even direct lighting strikes. High Temperature Protection Lower RDS (on) MOSFETs Design GIGABYTE motherboards use Low RDS (on) MOSFETs which reduce energy wastage through unnecessary residual heat dissipation. This all amounts to tangible energy savings which are beneficial for both end-users & the environment without impacting system performance. GIGABYTE Patented Dual BIOS™ (UEFI) Design GIGABYTE Ultra Durable™ motherboards feature GIGABYTE Dual BIOS™, an exclusive technology from GIGABYTE that protects arguably one of your PCs most crucial components, the BIOS. GIGABYTE Dual BIOS™ means that your motherboard has both a Main BIOS & a Backup BIOS, protecting users from BIOS failure due to virus, hardware malfunction, improper OC settings or power failure during the update process. APP Center GIGABYTE APP Center gives you easy access to a wealth of GIGABYTE APPs that help you get the most from your GIGABYTE motherboard. Using a simple, unified user interface, GIGABYTE APP Center means that you can launch all GIGABYTE APPs installed on your system. Easy Tune™ Get the highest levels of performance from your PC with easy to use GIGABYTE overclocking features. Cloud Station™ GIGABYTE Cloud Station™ is composed of several GIGABYTE unique apps that allow your smart phones/tablet devices to communicate, share resources, & control your desktop PC via a wireless connection. Specifications CPU Support for 7th/6th Generation Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1151 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel H110 Express Chipset Memory 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR4 2400/2133 MHz memory modules Support for ECC UDIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) Support for non-ECC UDIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules * To support 2400 MHz or XMP memory, you must install a 7th generation processor. (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor
- Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200@60 Hz Maximum shared memory of 1 GB Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (The PCI Express x 16 slot conforms to PCI Express 3.0 standard.) 5 x PCI Express x 1 slots (All of the PCI Express x 1 slots conform to PCI Express 2.0 standard.) Storage Interface Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA SSD support) 4 x SATA 6 Gb/s connectors * Refer to "1-7 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. USB Chipset: 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB (Universal Serial Bus) header) 6 x USB (Universal Serial Bus) 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 2 x PCIe power connectors 1 x CPU fan header 3 x system fan headers 4 x SATA 6 Gb/s connectors 1 x M.2 Socket 3 connector 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB (Universal Serial Bus) 3.1 Gen 1 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 mouse port 1 x PS/2 Keyboard port 1 x parallel port 1 x serial port 1 x D-Sub port 2 x USB (Universal Serial Bus) 3.1 Gen 1 ports 2 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 2 x 64 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS Ambient LED Auto Green Cloud Station Easy Tune Fast Boot ON/OFF Charge Smart Time Lock Smart Keyboard Smart Backup System Information Viewer USB (Universal Serial Bus) Blocker Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) c Fos Speed Operating System Windows 10 64-bit (for 7th Generation Intel Processors) Windows 10 64-bit / Windows 8.1 64-bit / Windows 7 32-bit / 64-bits (for 6th Generation Intel Processors) * Please download the " Windows USB (Universal Serial Bus) Installation Tool" from GIGABYTEs website & install it before installing Windows 7. Form Factor ATX Form Factor; 30.5cm x 19.0cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
...

Supports 10th Gen Intel Core™ Processors. Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs. 8-Channel HD Audio with High Quality Audio Capacitors. GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management. Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers with FAN STOP. GIGABYTE APP Center, Simple & Easy Use. Anti-Sulfur Resistors Design. Humidity Protection Glass Fabric PCB There is nothing more harmful to the longevity of your PC than moisture, & most parts of the world experience moisture in the air as humidity at some point during the year. GIGABYTE motherboards have been designed to make sure that humidity is never an issue, incorporating a new Glass Fabric PCB technology that repels moisture caused by humid & damp conditions. Glass Fabric PCB technology uses a new PCB material which reduces the amount of space between the fibre weave, making it much more difficult for moisture to penetrate compared to traditional motherboard PCBs. This offers much better protection from short circuit & system malfunction caused by humid & damp conditions. High Temperature Protection Lower RDS (on) MOSFETs Design GIGABYTE motherboards use Low RDS (on) MOSFETs which reduce energy wastage through unnecessary residual heat dissipation. This all amounts to tangible energy savings which are beneficial for both end-users & the environment without impacting system performance. Refreshed BIOS The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system. APP CENTER GIGABYTE APP CENTER is an useful portal of all GIGABYTE MB utilities & drivers, you can choose any utility you want to install from APP CENTER & keep you updated with latest utilities & drivers version. Easy Tune GIGABYTEs Easy Tune™ is a simple & easy-to-use interface that allows users to fine-tune their system settings or adjust system & memory clocks & voltages in a Windows environment. With Smart Quick Boost, one click is all it takes to automatically overclock your system, giving an added performance boost when you need it the most. @BIOS The GIGABYTE @BIOS app means that you can update your system’s BIOS from within Windows using a simple & slick graphical user interface. @BIOS can automatically download the latest version from the GIGABYTE servers or you can update your BIOS from a file on your computer. @BIOS also means that you can save your current BIOS to a file, recover your previous BIOS from an image & backup your BIOS to an image. System Information Viewer GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your systems behaviour; these are the possibilities of the System Information Viewer. ...

Supports 10th Gen Intel Core™ Processors Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs 8-Channel HD Audio with High Quality Audio Capacitors Ultra-Fast M.2 with PCIe Gen 3 X2 & SATA Interface GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management HDMI /DVI-D/D-Sub Ports for Multiple Display Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers with FAN STOP GIGABYTE APP Center, Simple & Easy Use Anti-Sulfur Resistors Design Exclusive Realtek 8118 Gaming LAN High Speed Gigabit LAN with Automatic Bandwidth Allocation Realtek 8118 LAN is a high performance & friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features & the fastest & smoothest Internet experience. NVMe PCIe Gen 3 x 2 2280 M.2 Connector GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. High Definition Digital Outputs Enjoy true HD display capability using the most commonly integrated digital output technologies on today’s HD displays & TVs. Smart Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM & Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution & high fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level. The Industrys Leading Surge Protection GIGABYTE motherboards also feature special anti-surge IC that protect your motherboard, helping to ensure that your PC is equipped to deal with any potentially irregular electrical spikes. Humidity Protection Glass Fabric PCB There is nothing more harmful to the longevity of your PC than moisture, & most parts of the world experience moisture in the air as humidity at some point during the year. GIGABYTE motherboards have been designed to make sure that humidity is never an issue, incorporating a new Glass Fabric PCB technology that repels moisture caused by humid & damp conditions. Glass Fabric PCB technology uses a new PCB material which reduces the amount of space between the fiber weave, making it much more difficult for moisture to penetrate compared to traditional motherboard PCBs. This offers much better protection from short circuit & system malfunction caused by humid & damp conditions. High Temperature Protection Lower RDS (on) MOSFETs Design GIGABYTE motherboards use Low RDS (on) MOSFETs which reduce energy wastage through unnecessary residual heat dissipation. This all amounts to tangible energy savings which are beneficial for both end-users & the environment without impacting system performance. ...

Features Supports 11th & 10th Gen Intel Core™ Series Processors Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs Ultra-Fast M.2 with PCIe Gen 3 X4 & SATA Interface GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management High Quality Audio Capacitors & Audio Noise Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP GIGABYTE APP Center, Simple & Easy Use Anti-Sulfur Resistors Design 6+2 Phases Hybrid Power Design Cleaner & more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies & heavy loading. 6+2 Phases Low RDS (on) MOSFETs Solid capacitors to improve transient response & minimize oscillation. 8-pin Solid Pin CPU Power Connector. Exclusive Realtek 8118 Gaming LAN High Speed Gigabit LAN with Automatic Bandwidth Allocation Realtek 8118 LAN is a high performance & friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features & the fastest & smoothest Internet experience. Solid Pin Power Connectors H510 motherboards feature solid plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading. Solid Pin Power connector advantages Larger contact area for electricity More metal quantity to sustain higher power & generated heat Ultra durable & longer lifespan BIOS The BIOS is essential for users during initial setup to allow for the most optimal settings. With a new GUI & easier to use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system. * Photos are for reference only. Product features may vary by model. ...

Product Overview The Perfect Fit for Any Space Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a brushed aluminum surface chassis design. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. The Power of Intel Core™ / Intel 6th Gen Core™ Processors The 6th Generation of Intel Core i 7 processors are high-end desktop processors intended for those that need uncompromised performance. They have faster clock speeds than a Core i 3 or i 5, in addition to more powerful integrated GPU. Intel CPUs have a number of built-in features to ensure top of the line performance. When using processor-intensive applications, Turbo Boost 2.0 increases the clock speed while Hyper-Treading lets each core run two threads for even more efficient multitasking. in addition, the integrated memory controller provides a direct connection between the memory & the processor for fast data processing. Intel HD 520 Graphics Intel HD 520 Graphics deliver up to 1.34x more pixel-pushing performance than the previous generation. This directly results in smoother & more responsive video playback & game play. With the Intel HD 520 Graphics, you now have the power needed to edit HD videos & play games at ultra-high resolutions & silky-smooth frame rates. Fast USB (Universal Serial Bus) 3.1 Solution The latest USB (Universal Serial Bus) 3.1 offers a staggering 10 Gb/s transfer speed, 2x faster than USB (Universal Serial Bus) 3.0 & backward compatibility with existing USB (Universal Serial Bus) devices. Connecting the Future
- USB (Universal Serial Bus) Type-C™: The World's Next Universal Connector with Reversible Design The USB (Universal Serial Bus) Type-C™ is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.1 support for 10 Gb/s transfer speed. USB (Universal Serial Bus) 3.0 & Network Connectivity GIGABYTE BRIX™ also

Includes:: a M.2 module offering IEEE 802.11ac Wi-Fi & the latest Bluetooth 4.2, providing connectivity for low power Bluetooth devices & peripherals, as well as allowing users to easily connect mobile devices. Super Speed 4K HD Entertainment Native 4K HD Decode Support The GIGABYTE BRIX™ now support a native resolution of 4K, bringing unrivalled visual clarity & stunning realism to owners of 4K HDTV or PC monitors. This also opens up new possibilities for those in the digital signage interested in the small footprint of the GIGABYTE BRIX™, & those in need of a 4K display solution capable of delivering an ultra-realistic, high definition visual experience. Multi-display productivity with HDMI & Display Port++ BRIX supports up to three independent displays through HDMI & a Display Port ++ without the need for an additional graphics card. Support for three display is only possible with daisy-chain connections through Display Port++. VESA Support Bundled with a VESA bracket, the GIGABYTE BRIX™ can easily be mounted behind a monitor or HDTV, offering a simple & effective way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. 2.5" Hard Drive Support Utilizing SATA III 6 Gb/s high speed data transfer technology, the GIGABYTE BRIXs supports the installation of one 2.5” SATA 6 Gbps HDD or Solid State Drive (SSD) & one M.2 2280 SSD module. This allows for optimized storage configurations which combine fast M.2 performance with larger capacity 2.5” hard drive. Ideal for: The Perfect Compact Home PC: Living room, Bedroom, Kitchen, Study. Vertical Markets: School, University computer labs, Libraries, Hospital / Medical equipment, Governmental. An Ultimate Graphics Powerhouse: Play the latest 3D games, Multimedia production, Video editing, 3D design. Powerful Commercial Applications: Factory testing machine, Bank ATM system, Gaming equipment, Vending machine, Security system. At the Office: Meeting room device, Workstation, Studio, Freelance office space. Simpler & Smarter Digital Life: Shopping mall signboard, Split-flap display, Scoreboard system, Indoor / Outdoor LED Display. Features Features Latest Intel 6th generation Core Processors. Ultra compact PC design at only 0.6L (46.8 x 112.6 x 119.4mm). Supports 2.5” HDD/SSD, 7.0/9.5 mm thick (1x 6 Gbps SATA 3). 1x M.2 SSD (2280) slot. 2x SO-DIMM DDR4 slot (2133 MHz). Intel IEEE 802.11 ac, Dual Band Wi-Fi & Bluetooth 4.2 NGFF M.2 card. Intel HD Graphics 520. 2x USB3.1 (1* USB (Universal Serial Bus) Type-C™). 2x USB (Universal Serial Bus) 3.0. HDMI plus Mini Display Port Outputs (Supports dual displays). Intel Gigabit LAN. Headphone/ Microphone Jack. VESA mounting Bracket (75 x 75mm + 100 x 100mm). Dimension 46.8 mm x 112.6 mm x 119.4 mm (1.84" x 4.43" x 4.7") Motherboard Size 105 x 110 mm CPU Intel Core™ i 7-6500U 2.5 G Hz / 3.1 G Hz Memory 2 x SO-DIMM DDR4 slots 2133 M Hz Max. 32GB LAN Gigabit LAN (Intel i 219LM) Audio Realtek ALC255 Graphics Intel HD Graphics 520 HDMI Resolution (Max.) 4096 x 2160 @ 24 Hz Mini DP Resolution (Max.) 3840 x 2160 @ 60 Hz Expansion Slots 1 x M.2 slot (2280_storage) PCIe /SATA 1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the Wi Fi+BT card Front I/O 1 x USB (Universal Serial Bus) 3.1 type C 1 x USB3.1 1 x head phone jack with MIC Rear I/O 1 x HDMI (1.4a) 1 x Mini Display Port (1.2) 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Power Supply Input: AC 100-240V Output: DC 19V 3.42A VESA Bracket included Supports 75 x 75 & 100 x 100 mm Wifi Card Intel Dual Band Wireless-AC 3165 USB3.1 Asmedia Storage Supports 2.5” HDD/SSD, 7.0/9.5 mm thick (1 x 6 Gbps SATA 3) Support OS WIN7 32/64bit WIN8.1 64bit WIN10 64bit Environment System Environment Operating Temperature: 0°C to +35°C System Storage Temperature: -20°C to +60°C


...

Contents 1x Gigabyte GA-Z87-HD3 1x Intel Core i 5 4670K (1150/ Quad Core/3.4 Ghz/6 Mb/ Haswell/84W/ Graphics) 8 Gb DDR3 (2x 4 Gb) Corsair Vengeance Pro Description Feel the Force of the Gigabyte Performance Bundle ideal of Gamers, Power Users & Overclockers. Built on the latest Intel Haswell platform it offers the perfect balance of power, performance & style. Complimented by the blisteringly fast Corsair Vengeance Pro Low Latency Memory. Why you Should Buy this bundle - Tested Prior to shipping & Pre Built to work straight out of the box
- Quad Core Computing for the most demanding of applications & games
- Killer good looks on a stylish black Motherboard/ Memory Combo
- Industry leading heat management Motherboard GIGABYTE 8 Series Motherboards support the latest 4th Generation Intel Core processors, bringing together a unique blend of features & technologies that offer the absolute ultimate platform for your next PC build. From high current capable digital power delivery, performance-enhancing caching technologies, exclusive high-end audio features, advanced networking & device charging, gold plated hardware connectors & of course, killer good looks, GIGABYTE 8 series motherboards are in a class of their own. Next Gen Intel 8 Series Platform The latest Intel 8 Series platform offers significant improvements in performance & power consumption with the latest 4th generation Intel Core processors & Intel Z87 chipsets. As well as a boost in overall productivity, the latest HD4600 Intel processor graphics provide native 4K resolution playback over standard HDMI connectivity, with significantly higher frame rates in the latest DX11 3D game titles. * Supports 4th Generation Intel Core processors * GIGABYTE Ultra Durable 4 Plus Technology * GIGABYTE UEFI Dual BIOS * 15µ gold plated CPU socket * Multi-GPU Support * All solid capacitors * GIGABYTE On/ Off Charge for USB (Universal Serial Bus) devices * LAN with high ESD Protection CPU Want a system that can not only rock the latest game but also rip through your media? Then combining a 4th gen Intel Core processor in the LGA1150 socket with the latest Intel 8 Series Z chipset will get you the results you want. The built-in visuals of the 4th gen Intel Core processors deliver everything you need to enjoy a stunning & seamless graphic experience when viewing & interacting with pictures and media on your PC without the need for a discrete graphics card, thanks to Intel HD Graphics 4600—the new baseline for all 4th gen Intel Core i 5 & Intel Core i 7 processors. Unlocked Intel Core processors enable system tuning for the processor cores, memory, & power. Adjusting these settings provides extra performance & fexibility for more complex multimedia applications & immersive gaming. Whether you are a novice overclocker or a seasoned veteran, these processors will have you singing their praises in no time. The Intel Core processor family delivers a great PC experience. Whether you are looking for enhanced performance, greater adaptability, or differentiated visual features, Intel has the processor to ft your needs. If you are using your PC for creativity, playing games, or everyday tasks such as homework & e-mail, these new processors make it easier to design, render, edit, play, & share. Processor Number – i 5-4670K Nm Technology – 22 Core Frequency – 3.4 G Hz Turbo Frequency – 3.8 G Hz HT- No Cores – 4 Threads – 4 Corsair Vengeance Pro Series memory modules are designed for overclocking on the latest 3rd & 4th generation Intel Core platforms, with eight-layer PCBs & ICs specially selected for performance potential. The aluminum heat spreaders provide superior temperature management & have the aggressive look you want in your gaming rig. XMP 1.3 profiles allow for automatic, reliable overclocking. They’re available in multiple colors to let you match your Vengeance Pro memory to your system’s color scheme. As a bonus, they’re priced to deliver class-leading value, so you’ll have more room left in your system build budget. Built for overclocking Each Vengeance Pro Series module is built from an eight-layer PCB & highly-screened memory ICs. The efficient heat spreader provides effective cooling to improve overclocking potential. Designed for great looks The heat spreader doesn’t just allow Vengeance Pro Series to run better –the aggressive yet refined form factor looks great in showcase systems. The color accent clip lets you match your Vengeance Pro Series memory to your system’s color scheme. Performance & Compatibility Vengeance Pro Series memory is optimized for performance on the latest 3rd & 4th generation Intel Core platforms. XMP 1.3 profile support makes stable overclocking easy & automatic. Perfect size The Vengeance Pro Series module height is carefully designed to fit easily in most system while still providing ample cooling performance & that edgy look.


...

Gigabyte Pre Built Intel Premium Bundle (Intel Core i 3
- 3220/ Gigabyte GA-H61M-USB3V/ Corsair 8gb DDR3 XMS Memory) Contents 1x
...

Features Supports Intel Core™ X-series Processor Family Quad Channel Non-ECC Unbuffered DDR4, 8 DIMMs, DDR4333+ (OC) Intel Optane™ Memory Ready ASMedia 3142 USB (Universal Serial Bus) 3.1 Gen 2 with USB (Universal Serial Bus) Type-C™ & Type-A 3-Way Graphics Support with Dual Armor & Ultra Durable™ Design Server-Class Digital Power Design ALC1220 120d B SNR HD Audio with Smart Headphone AMP & WIMA audio capacitor RGB FUSION supports Digital LED & RGBW Light Strips Smart Fan 5 features Multiple Temperature Sensors & Hybrid Fan Headers with FAN STOP Dual Ultra-Fast M.2 with PCIe Gen 3 x 4 interface NVMe PCIe Gen 3 x 4 U.2 support by optional adaptor Intel Gb E LAN Gaming Network with c Fos Speed Internet Accelerator Software Anti-Sulfur Resistor Design Ultra Durable™ 25KV ESD & 15KV Surge LAN Protection Lightning-Fast Intel Thunderbolt™ 3 AIC Support GIGABYTE UEFI Dual BIOS™ APP Center Including Easy Tune™ & Cloud Station™ Utilities Product Overview The AORUS X299 enthusiast motherboards are faster & more powerful than any motherboard the world has ever seen. With an aggressively redesigned armor & thermal heatsinks its sure to turn heads & catch eyes. Performance is no stranger to AORUS, with exotic cooling & an ability to be tuned to peak performance AORUS motherboards will exceed expectations. RGB FUSION Set the Color that Matches Your Style AORUS X299 series motherboards boast the most advanced LED system in the market today. With more customizability than ever & a convenient & intuitive UI thanks to the RGB Fusion App, you’ll have a blast making your AORUS your own. LED enthusiasts now have even more options with the ability to customize multiple zones independently. For a more functional use, the bright & vibrant LEDs can be configured to display the PC’s temperature or load. For even more LED goodness RGBW strips are now supported for more true & vibrant whites. RGB Fusion with Digital LEDs With AORUS X299 Motherboards, RGB Fusion is even better with Digital LEDs.* RGB Fusion offers users the option to control onboard & external LED light strips for their PC. Already feature filled with colors & patterns, RGB Fusion on X299 Series AORUS Motherboards are now upgraded with Digital LED support. With onboard options & external digital LED strips*, where each LED is digitally addressable, users can experience even more patterns, styles, & illuminations. AORUS Gaming Motherboards will support either 5v or 12v digital LED strips. RGB Fusion with Digital LEDs comes with 9 new patterns & various speed settings with more to come. * Digital LEDs are available only on select Motherboards, external LED Strips, Digital LED Strips are not included with Motherboard purchase. Surround Lighting Multi-light zones are equipped with high brightness RGB LEDs, namely the CPU, Memory, Armor, Audio, PCI-Express & Accent LED PCH Overlay. When it’s all set & done, your system will shine like never before. RGB Fusion (Advanced mode) With the all new RGB Fusion software, users have access to different preset LED lighting configurations with choice of colors. You can even set the LEDs to synchronize with your favorite music or have them change colors to indicate the CPU temperature. For true lighting experts there is an Advanced Mode, which can be fully customized by individual area with its own effects & color transitions, along with specific duration & transition times. GIGABYTE RGB Fusion APP Dont just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try & adjust colors & speeds for different modes, all this can be achieved away from the keyboard & monitor of their PC. Swappable Overlay for Accent LED AORUS brings even more color & life to your system with an Accent LED PCH Overlay. This overlay complements the RGB Fusion technology in AORUS Motherboards adding more flare & style to your gaming machine. With the swappable overlay users can utilize different patterns & designs to make their system their own. * LED strips & customized overlays are not included. Photos are for reference only. Product features may vary by model. Armor AORUS X299 Gaming Motherboards are designed with an aggressive stance, but looks are just the beginning. The armor on the AORUS Gaming Series are created to offer best-in-class performance while still staying cool. Base Plate AORUS Motherboards are the perfect choice when starting your PC build. With an integrated base plate, AORUS Motherboards give users a strong foundation to build their Gaming PC. With larger & heavier coolers, graphics cards, & even memory modules the AORUS Base Plate is perfect to help support any enthusiast’s build while reducing cuts & stings from sharp areas of the motherboard. I/O Shield Armor With an integrated I/O shield building an AORUS Gaming PC is even easier.* Gone are the days of realizing that the rear I/O was forgotten or lost. * Integrated I/O Shields are only available on select AORUS Motherboards Smart Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM & Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. Achieve fan silence. With Fan Stop map any fan to stop completely when temperatures drop below a specified threshold. Which fan stops, based on readings from which sensor, & at what temperature—all of it can be customized to your liking. New Smart Fan 5 Software Interoperable Sensors & Fans Each fan can be customized to operate at different speeds according to any defined temperature source input (except the CPU fan). Fan Curve Customize fan curves based on specific temperatures with the intuitive graphical UI. Choose from different modes, Quiet to Full Speed, to match your system usage scenario. For each fan or pump, you can use the intuitive fan curve to define trigger thresholds & corresponding fan speeds. System Information Viewer GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks & processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system’s behavior; these are the possibilities of the System Information Viewer. U.2 Adaptor (NVMe PCIe Gen 3 x 4) NVMe Performance for PCIe SSDs The new Intel 750 series SSDs offer an incredible increase in performance over SATA drives. Using the NVMe protocol which takes advantage of the fast bandwidth of PCIe Gen 3 x 4 lanes (32 Gb/s), the drives are a clear advantage for users looking to boot their OS faster, load their games in a flash & access large files without waiting. By implementing the U.2 Adaptor to support the 2.5” Intel 750 Series drive, AORUS ensures that the users can benefit from the best performance. SSDs & cables not included. PURE SPEED AORUS Extreme USB (Universal Serial Bus) 3.1 Motherboards The ASMEDIA 3142 USB (Universal Serial Bus) 3.1 controller utilizes 2 PCIe Gen 3 lanes, offering a total of up to 16 Gb/s, which means you have extra bandwidth to take full control of the 10 Gb/s USB (Universal Serial Bus) 3.1 ports. With twice the bandwidth compared to its previous generation, & backwards compatibility with USB (Universal Serial Bus) 2.0 & 3.0, the much enhanced USB (Universal Serial Bus) 3.1 protocol is available over the new reversible USB (Universal Serial Bus) Type-C™ & the traditional USB (Universal Serial Bus) Type-A connector for better compatibility over a wider range of devices. Specifications CPU Support for Intel Core™ X series processors in the LGA2066 package L3 cache varies with CPU (Please refer "CPU Support List" for more information.) Chipset Intel X299 Express Chipset Memory 8 x DDR4 DIMM sockets supporting up to 128 GB of system memory. * Support for up to 512 GB of system memory when using Registered DIMMs. * Supported when using a 44-lane or 28-lane CPU. 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory. * Supported when using a 16-lane CPU. 4 channel memory architecture. * Supported when using a 44-lane or 28-lane CPU. Dual channel memory architecture. Supported when using a 16-lane CPU. Support for DDR4 4333 (O.C.) / 4266 (O.C.) / 4133 (O.C.) / 4000 (O.C.) / 3866 (O.C.) / 3800 (O.C.) / 3733 (O.C.) / 3666 (O.C.) / 3600 (O.C.) / 3466 (O.C.) / 3400 (O.C.) / 3333 (O.C.) / 3300 (O.C.) / 3200 (O.C.) / 3000 (O.C.) / 2800 (O.C.) / 2666 (O.C.) / 2400 / 2133 MHz memory modules Support for non-ECC Un-buffered DIMM memory modules Support for Registered DIMM 1 Rx 8/2 Rx 8/1 Rx 4/2 Rx 4 memory modules (operate in non-ECC mode) Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Audio Realtek ALC1220 codec High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN Intel Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 2 x PCI Express x 16 slots, running at x 16 (PCIEX16_1, PCIEX16_2) 1 x PCI Express x 16 slot, running at x 8 (PCIEX8) 2 x PCI Express x 16 slots, running at x 4 (PCIEX4_1, PCIEX4_2) (All of the PCI Express slots conform to PCI Express 3.0 standard.) * Refer to "1-6 Setting up AMD Cross Fire™/NVIDIA SLI™ Configuration, " for the installation notices for the PCI Express x 16 slots. Storage Interface Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe x 4/x 2 SSD support) (M2Q_32G) 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA & PCIe x 4/x 2 SSD support) (M2P_32G) 8 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, RAID 5, & RAID 10 * Refer to "1-9 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. Multi-Graphics Technology Support for NVIDIA Quad-GPU SLI™ & 3-Way* /2-Way* NVIDIA SLI™ technologies * Supported when using a 44-lane. Support for AMD Quad-GPU Cross Fire™ & 3-Way* /2-Way AMD Cross Fire™ technologies * Supported when using a 44-lane. USB Chipset+ASMedia USB (Universal Serial Bus) 3.1 Gen 2 Controller: 1 x USB (Universal Serial Bus) Type-C™ port on the back panel, with USB (Universal Serial Bus) 3.1 Gen 2 support 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port (red) on the back panel Chipset: 10 x USB (Universal Serial Bus) 3.1 Gen 1 ports (6 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) 4 x USB (Universal Serial Bus) 2.0/1.1 ports available through the internal USB (Universal Serial Bus) headers Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x water cooling CPU fan header 4 x system fan headers 1 x system fan/water cooling pump header 1 x 3 Amp fan/water cooling pump header 1 x digital LED strip extension cable header 2 x RGB (RGBW) LED strip extension cable headers 2 x M.2 Socket 3 connectors 8 x SATA 6 Gb/s connectors 1 x Intel VROC Upgrade Key header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB (Universal Serial Bus) 3.1 Gen 1 headers 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Thunderbolt™ add-in card connector 1 x Trusted Platform Module (TPM) header 1 x power button 1 x OC button 2 x temperature sensor headers 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x USB (Universal Serial Bus) Type-C™ port, with USB (Universal Serial Bus) 3.1 Gen 2 support 1 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A port (red) 6 x USB (Universal Serial Bus) 3.1 Gen 1 ports 1 x RJ-45 port 6 x audio jacks (Center/ Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Overheating warning Fan fail warning Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. 3D OSD @BIOS Auto Green BIOS Setup Color Temperature Cloud Station Easy Tune Easy RAID Fast Boot Game Boost ON/OFF Charge Platform Power Management RGB Fusion Smart Backup Smart Keyboard Smart Time Lock Smart HUD System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) Intel Optane™ Memory Ready c Fos Speed Operating System Support for Windows 10 64-bit Form Factor ATX Form Factor; 30.5cm x 24.4cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website. ...
