The World First PCIe 4.0x 4 Controller, Phison PS5016-E16 controller, made by 28nm manufacturing technology. The advanced fabrication process ensures PS5016-E16 has enough compute power for ECC processing when adopting the latest 3D TLC NAND flash. PS5016-E16 also features eight NAND channels with 32 CE targets, DDR4 DRAM caching, & a PCIe 4.0x 4 interface. As for features, the chip supports the NVMe 1.3 protocol, LDPC error correction, & Wear Leveling, Over-Provision technologies to improve reliability & durability of SSDs. PCIe 4.0x 4, NVMe 1.3 Interface DDR4 DRAM cache 8 CH with 32 CEs Phison 4th Gen LDPC & RAID ECC Support Pyrite Heat spreader for controller Selected High Speed 3D TLC NAND Flash (800MT/s) The selected & high quality NAND Flash optimizes circuitry & architecture by increasing to 96 layers for higher storage space per unit area. 800MT/s throughput on the AORUS Gen 4 SSD far exceeds that of PCIe 3.0x 4 devices for superior storage performance. Xtreme Storage Performance With the new PCIe 4.0 controller, AORUS Gen 4 SSD delivers blazing speeds: up to 5, 000 MB/s for sequential read, & up to 4, 400MB/s sequential write. Sequential Read performance of PCIe 4.0 SSDs is up to 40% faster than PCIe 3.0 SSDs. Get ready to enter the next generation of computing with faster & smoother, gaming, streaming, & graphics intensive rendering. SSD Tool Box The newly updated SSD Tool Box is a software that gives users an overview of the SSD Status & various aspects such as model name, FW version, health condition & sensor temperature. Moreover, users can clear all the data with the Secure Erase function. You can download the SSD Tool Box from the link. ...

Features Fully Modular Design High quality 100% Japanese Capacitors 135mm 2 ball bearing smart fan with fan stop function 80 PLUS Gold certified: above 90% efficiency at 50% load Single +12V rail OCP/OTP/OVP/OPP/UVP/SCP protection 10 years warranty (Adjusted according to different regions) FULLY MODULAR DESIGN All the black flat cables are modular design. Installing only the cables you need to reduce clutter, to increase airflow & to improve the chassis thermal performance. HIGH QUALITY 100% JAPANESE CAPACITORS All capacitors are high quality Japanese capacitors, to produce the efficient performance & to ensure the longer reliability. 135MM SMART FAN Fan speed will be adjusted according to the system load. & the fan will stop when the system is idle or under low load (less than 20% load). The 2 ball bearing structure provides longer life time. 80 PLUS GOLD CERTIFIED 80 Plus Gold certified ensures to deliver 90% efficiency at 50% load. The better power efficiency leads to less power waste, less heat & less fan noise. & with the support of Intel processors, it will save more energy & more money. SINGLE +12V RAIL Single +12V rail provides the best power output, stability & compatibility for the hardware. It provides the easiest way to install the power cable. & it is the best design for overclocking. PROTECTION In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP & SCP, but also ensured the stable operation of your system through the safety certification of various countries. ...

Features Fully Modular Design High quality 100% Japanese Capacitors 135mm 2 ball bearing smart fan with fan stop function 80 PLUS Gold certified: above 90% efficiency at 50% load Single +12V rail OCP/OTP/OVP/OPP/UVP/SCP protection 10 years warranty (Adjusted according to different regions) FULLY MODULAR DESIGN All the black flat cables are modular design. Installing only the cables you need to reduce clutter, to increase airflow & to improve the chassis thermal performance. HIGH QUALITY 100% JAPANESE CAPACITORS All capacitors are high quality Japanese capacitors, to produce the efficient performance & to ensure the longer reliability. 135MM SMART FAN Fan speed will be adjusted according to the system load. & the fan will stop when the system is idle or under low load (less than 20% load). The 2 ball bearing structure provides longer life time. 80 PLUS GOLD CERTIFIED 80 Plus Gold certified ensures to deliver 90% efficiency at 50% load. The better power efficiency leads to less power waste, less heat & less fan noise. & with the support of Intel processors, it will save more energy & more money. SINGLE +12V RAIL Single +12V rail provides the best power output, stability & compatibility for the hardware. It provides the easiest way to install the power cable. & it is the best design for overclocking. PROTECTION In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP & SCP, but also ensured the stable operation of your system through the safety certification of various countries. ...

<iframe width="510" height="300" src="https://www.youtube.com/embed/7w-Quiyx GVQ" frameborder="0" allow="autoplay; encrypted-media" allowfullscreen></iframe> Explore the full spectrum of glorious RGB Lighting with AORUS RGB Memory & Exclusive RGB Infused Demo Modules with seamless RGB synchronization between the motherboard & other peripherals. Bring new concept to memory with stylish & luxurious design. AORUS design principles are inspired by the brand icon, the Eagle. The pattern on the front side of AORUS RGB Memory sticks resembles an eagle diving through the sky. The dynamic features of the AORUS RGB Memory modules represent the eagle’s speed, agility, & the eagle’s prowess in flight. Moreover, the asymmetric design of the heatsink & placement of the AORUS logo makes it easier & more intuitive for users to slide the sticks correctly into place. Engineered to make a difference The all new AORUS RGB Memory kit is engineered to be the best & to deliver absolute performance. The stylish, luxurious design & the glossy finish make it stand out against the competition. The diffused RGB LEDs paired with aluminum heatsinks provide both effective heat dissipation & impressive style at the same time. If you want a memory kit that will take your PC to the next level the AORUS RGB Memory kit is what will make your system shine! Memory Composition The AORUS RGB Memory kit is built on a ten-layer, sophisticatedly engineered PCB that ensures the stability & the high performance of the Samsung B-die ICs. The heatsink of AORUS RGB Memory kit is designed to offer the best performance. The high quality materials offer better heat dissipation, guaranteeing the stability of the memory kit. The light diffuser adds balance & polish to the RGB LED lighting. Industry First RGB Infused Demo Modules
- Exclusive. Aesthetic. Populate all your DRAM slots without breaking the bank for a much better looking system. Industry-first AORUS RGB Infused Demo Modules keep the same design as the original memory sticks & are 100% compatible with the RGB Fusion software. Now you can customize the lighting on your memories any possible way you want! RGB Fusion 5 DDR Exclusive Lighting Effects, AORUS RGB Memory supports 11 lighting modes. 5 are new lighting modes only for the AORUS RGB Memory. Color strobe, Cascade, Color Cascade, Droplet & Color Droplet are the new modes that adds unique style to your system. Specifications Memory Type DDR4 Capacity 16GB kit (2x 8GB) Multi-Channel Kit Dual Channel Kit SPD Latency 16-15-15-36 SPD Speed 2133 M Hz SPD Voltage 1.2V Speed Rating PC4-25600 (3200 M Hz) Tested Latency 16-18-18-38 Tested Speed 3200 M Hz Tested Voltage 1.35v Heatspreader Color Silver LED lighting Yes RGB Fusion/ RGB Fusion Link Yes Package Memory Pin 288 Performance Profile XMP 2.0 Warranty Limited Lifetime Compatibility Intel Platform: X299, 300, 200 series motherboards AMD Platform: X399, AM4 series motherboards
...

YOUR GAME. YOUR WAY. Explore the full spectrum of glorious RGB Lighting with AORUS RGB Memory & Exclusive RGB Infused Demo Modules. Seamless RGB synchronization between the motherboard & other peripherals. Bring new concept to memory with stylish & luxurious design. DDR4 3200 M Hz 16GB (2x 8GB) Memory Kit Exclusive 2XRGB Infused Demo Module Timing: 16-18-18-38 (XMP 3200 M Hz) Design concept AORUS design principles are inspired by the brand icon, the Eagle. The pattern on the front side of AORUS RGB Memory sticks resembles an eagle diving through the sky. The dynamic features of the AORUS RGB Memory modules represent the eagle’s speed, agility, & the eagle’s prowess in flight. Moreover, the asymmetric design of the heatsink & placement of the AORUS logo makes it easier & more intuitive for users to slide the sticks correctly into place. Engineered to make a difference The all new AORUS RGB Memory kit is engineered to be the best & to deliver absolute performance. The stylish, luxurious design & the glossy finish make it stand out against the competition. The diffused RGB LEDs paired with aluminum heatsinks provide both effective heat dissipation & impressive style at the same time. If you want a memory kit that will take your PC to the next level the AORUS RGB Memory kit is what will make your system shine! Industry First RGB Infused Demo Modules
- Exclusive. Aesthetic Populate all your DRAM slots without breaking the bank for a much better looking system. Industry-first AORUS RGB Infused Demo Modules keep the same design as the original memory sticks & are 100% compatible with the RGB Fusion 2.0 software. Now you can customize the lighting on your memories any possible way you want!
...

GET READY FOR AMD RYZEN 3000-SERIES GIGABYTE X570 motherboards based on the AMD X570 Chipset provide full support for 3rd Gen AMD Ryzen Processors. The all-new design is a testament to GIGABYTEs dedication to design quality. GIGABYTE X570 motherboards offer a rich list of features such as support for PCIe 4.0 & USB (Universal Serial Bus) Type-C interfaces on select boards, refined audio, high speed of Ethernet & latest standard of WIFI design, to fulfill users performance, audio, & data transfer needs. The new, advanced power & thermal design enables users to unleash the performance on AMD Ryzen 3000-series Processors, making the GIGABYTE X570 motherboards perfect for users looking to build the best AMD platform gaming system. THERMAL REACTIVE ARMOR X570 AORUS XTREME uses some unprecedented & innovative thermal design to ensure CPU, Chipset, SSD stability & low temperature under full loading application & gaming. UNPARALLELED PERFORMANCE Hungry for better performance? X570 AORUS XTREME has full PCIe 4.0 design, supports high frequency memory, & full SSD thermal guard to make sure you get the maximum full system performance. Specifications: Chipset: X570 Socket: AM4 Form Factor: E-ATX PWM: Infineon XDPE132G5C Phase: 16, Powl Rstage 70A PCB Layers: 8 PCB Type: Low-Loss Memory Support 3rd Generation AMD Ryzen™ processors: Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules 2nd Generation AMD Ryzen processors/2nd Generation AMD Ryzen with Radeon Vega Graphics processors/AMD Ryzen with Radeon Vega Graphics processors: Support for DDR4 2933/2667/2400/2133 MHz memory modules 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules Memory Socket: DDR4 * 4 PCIe Slot: PCI Express Gen 4 x 16, x 8, x 4 PCIe Slot Details Integrated in the CPU (PCIEX16/PCIEX8): 3rd Generation AMD Ryzen™ processors: 1 x PCI Express x 16 slot, supporting PCIe 4.0 & running at x 16 (PCIEX16) 1 x PCI Express x 16 slot, supporting PCIe 4.0 & running at x 8 (PCIEX8) Multi-Graphics Support For 3rd Generation AMD Ryzen processors/2nd Generation AMD Ryzen processors only. Support for NVIDIA Quad-GPU SLI & 2-Way NVIDIA SLI technologies Support for AMD Quad-GPU Cross Fire & 2-Way AMD Cross Fire™ technologies Graphics out put: NONE Integrated in the CPU: 2 x USB (Universal Serial Bus) 3.2 Gen 2*/ Gen 1 Type-A ports (red) on the back panel * For 3rd Generation AMD Ryzen™ processors only. 2 x USB (Universal Serial Bus) 3.2 Gen 1 ports on the back panel Integrated in the Chipset: 1 x USB (Universal Serial Bus) Type-C™ port with USB (Universal Serial Bus) 3.2 Gen 2 support, available through the internal USB (Universal Serial Bus) header 1 x USB (Universal Serial Bus) Type-C™ port on the back panel, with USB (Universal Serial Bus) 3.2 Gen 2 support 3 x USB (Universal Serial Bus) 3.2 Gen 2 Type-A port (red) on the back panel 2 x USB (Universal Serial Bus) 3.2 Gen 1 ports available through the internal USB (Universal Serial Bus) header Chipset+USB 3.2 Gen 1 Hub: 2 x USB (Universal Serial Bus) 3.2 Gen 1 ports available through the internal USB (Universal Serial Bus) header 2 x USB (Universal Serial Bus) 2.0/1.1 ports available through the internal USB (Universal Serial Bus) header Chipset+USB 2.0 Hub: 4 x USB (Universal Serial Bus) 2.0/1.1 ports on the back panel SATA 6 Gbs: 6 M.2 Slot: 3 TPM: Header RAID: RAID 0/1/10 Audio Realtek ALC1220-VB codec* The front panel line out jack supports DSD audio. ESS SABRE9218 DAC chip High Definition Audio: 2/4/5.1/7.1-channel Support for S/PDIF Out LAN 1 x Aquantia Gb E LAN chip (10 Gbit/5 Gbit/2.5 Gbit/1000 Mbit/100 Mbit) (LAN1) 1 x Intel Gb E LAN phy (10/100/1000 Mbit) (LAN2) Wi Fi Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band BLUETOOTH 5.0 Support for 11ax 160 M Hz wireless standard & up to 2.4 Gbps data rate * Actual data rate may vary depending on environment & equipment. Light Effect: RGB Fusion RGB Header 2 x addressable LED strip headers 2 x RGB LED strip headers Fan Header 1 x OC PEG power connector 1 x CPU fan header 1 x water cooling CPU fan header 4 x system fan headers 2 x system fan/water cooling pump headers Debug LED: Yes Qflash Plus: Yes Dual BIOS: Yes Com Port: N/A Others 1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 2 x temperature sensor headers 1 x power button 1 x reset button 2 x BIOS switches Voltage Measurement Points ...

Gigabyte AX370-Gaming 5 + AMD Ryzen 7 1700X + AMD 120GB SSD See Motherboard details- Gigabyte AMD AX370-Gaming 5 AM4 Socket ATX Motherboard See Processor detials- AMD Ryzen 7 1700X 8 Core AM4 CPU/ Processor AMD 120GB SSD value Looking for the best way to boost your PC or laptop’s performance? Look no further than Radeon R3 SSD drives. Performance With speeds greater than 10x that of a traditional hard drive, you can now access programs & boot up operating systems unbelievably fast. Design The slim 2.5” form factor is compatible with desktop PCs as well as most notebooks. Warranty 3 year limited warranty Compatibility Intel or AMD-based systems, laptops & desktops. Specifications CAPACITY 120 GB NAND COMPONENTS TLC CONTROLLER Silicon Motion SM2256KX FORM FACTOR 2.5" 7mm INTERFACE SATA III, 6 Gbps HEIGHT 7mm WIDTH 69.75mm DEPTH 99.70mm WEIGHT 115g MAX READ 520 MB/s MAX WRITE 360 MB/s 4KB RANDOM READ 57, 400 IOPS 4KB STEADY STATE RANDOM WRITE 18, 400 IOPS ...

Features Supports New Generation AMD Ryzen™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Turbo B-Clock, Built-in Advanced Performance Tuning IC Fast 4 USB (Universal Serial Bus) 3.1 Gen 2 with USB (Universal Serial Bus) Type-C™ & Type-A 2-Way Graphics Support with Dual Armor & Ultra Durable™ Design NVMe PCIe Gen 3 x 4 U.2 Connector Ultra-Fast M.2 with PCIe Gen 3 x 4 & SATA interface Creative Sound Blaster X-Fi MB5 support Dual ALC 1220 with Front & Rear 120d B SNR HD Audio with Dual Smart Headphone Amps Killer™ E2500 Gaming Network + Intel Gigabit LAN USB (Universal Serial Bus) DAC-UP 2 & 4 Front USB (Universal Serial Bus) 3.0 Ports with Adjustable Voltage RGB FUSION with Multi-Zone LED Light Show design Swappable Overlay for Accent LED Smart Fan 5 features 9 Temperature Sensors & 8 Hybrid Fan Headers 2 External Thermistors Headers with 2 Included Thermistors GIGABYTE UEFI Dual BIOS™ APP Center Including Easy Tune™ & Cloud Station™ Utilities Specifications Form Factor- ATX CPU- Socket AM4 Chipset- AMD X370 Memory Type- DDR4 Memory Channel- Dual (2) Memory Type- (ECC) Non-ECC Memory Type- (R/U) UDIMM (Unbuffered) Memory Speed (Mhz) DDR4
- 2133 DDR4
- 2400 DDR4
- 2666 Maximum Memory- Capacity 64GB (4x 16GB) Graphics Connectors- HDMI Graphics Interface- PCIe 3.0 (x 16) SLI Support- 2-Way SLi Crossfire Support- 2-Way Cross Fire Audio- Dual Realtek ALC1220 Codec 7.1 HD Audio Network Interface Type- Dual Wired Gigabit LAN (10/100/1000) Network Interface Chip/ Modules 1 x Intel I211AT (Gigabit LAN) 1 x Killer E2500 (Gigabit LAN) SATA- SATAe / SATA3 / M.2 RAID- Support via SATA Storage Mode Support AHCI Hot Plug JBOD NCQ NVMe Boot (via M.2 PCIe Slot) NVMe Boot (via PCIe 3.0 Slot) NVMe Boot (via U.2 Connector) RAID 0 RAID 1 RAID 10 Expansion Slots 1 x M.2, 2242/2260/2280/22110, PCIe/SATA 3 x PCIe 2.0 x 1 1 x PCIe 2.0 x 16 (x 4 Bandwidth) 1 x PCIe 3.0 x 16 1 x PCIe 3.0 x 16 (x 8 Bandwidth) Internal I/O 1 x 2-Digit debug code LED 1 x 24-pin (Power) 1 x 4-pin CPU Fan Connector 1 x 4-pin CPU OPT Fan Connector 4 x 4-pin System Fan Connector 2 x 4-pin Water Pump Connector 1 x 8-pin (Power) 1 x BIOS switches 1 x Clear CMOS Button 1 x Front Panel Audio Header 1 x Front Panel Connector 1 x OC button 1 x Power button 1 x Reset Button 1 x RGB (RGBW) LED Strip Header 2 x SATA Express (Compatible with 2x SATA III) 4 x SATA III
- 6 Gb/s 1 x TPM Header 1 x U.2 Connector 2 x USB (Universal Serial Bus) 2.0 Header 2 x USB (Universal Serial Bus) 3.0 Header Back Panel 2 x 10/100/1000 (LAN) 2 x Audio I/O 1 x HDMI 1 x Line In 1 x Line Out 1 x Mic-In 1 x PS/2 Keyboard/ Mouse Combo 1 x SPDIF Out (Optical) 6 x USB (Universal Serial Bus) 3.0 3 x USB (Universal Serial Bus) 3.1 Type-A 1 x USB (Universal Serial Bus) 3.1 Type-C



...

Features Supports AMD Ryzen™ & 7th Generation A-series/ Athlon™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Ultra-Fast PCIe Gen 3 x 4 M.2 with PCIe NVMe & SATA mode support High Quality Audio Capacitors & Audio Noise Guard with LED Trace Path Lighting RGB FUSION supports RGB LED strips in 7 colors Realtek Gigabit LAN with c Fos Speed Internet Accelerator Software Smart Fan 5 features 5 Temperature Sensors & 2 Hybrid Fan Headers GIGABYTE UEFI BIOS APP Center Including Easy Tune™ & Cloud Station™ Utilities

Specification CPU AM4 Socket: AMD Ryzen™ processor AMD 7th Generation A-series/ Athlon™ processor (Please refer "CPU Support List" for more information.) Chipset AMD X370 Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory Dual channel memory architecture Support for DDR4 3200 (O.C.)/2933 (O.C.)/2667*/2400/2133 MHz memory modules * Actual support may vary by CPU. Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor: 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x 2160@24 Hz * Support for HDMI 1.4 version. Maximum shared memory of 2 GB * Actual support may vary by CPU. Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. * Actual support may vary by CPU. (The PCIEX16 slot conforms to PCI Express 3.0 standard.) 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) 1 x PCI Express x 1 slot (The PCIEX4 & PCI Express x 1 slots conform to PCI Express 2.0 standard.) Storage Interface 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe x 4/x 2* SSD support) * Supports only M.2 SATA SSDs when using an AMD 7th Generation A-series or Athlon™ processor. 4 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, & RAID 10 * Refer to "1-7 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. USB (Universal Serial Bus) Chipset: 2 x USB (Universal Serial Bus) 3.1 Gen 1 ports available through the internal USB (Universal Serial Bus) header 8 x USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) CPU: 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports on the back panel Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6 Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x RGB LED strip header 1 x USB (Universal Serial Bus) 3.1 Gen 1 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x 10 pin, for the GC-TPM2.0 module only) 1 x serial port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x DVI-D port 1 x HDMI port 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks I/O Controller i TE I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS 3D OSD Auto Green BIOS Setup Cloud Station Color Temperature Easy Tune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup Smart Keyboard Smart Time Lock System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) c Fos Speed

...

Features Supports AMD Ryzen™ & 7th Generation A-series/ Athlon™ Processors Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs Fast 2 USB (Universal Serial Bus) 3.1 Gen 2 with USB (Universal Serial Bus) Type-A Ultra-Fast PCIe Gen 3 x 4 M.2 with PCIe NVMe & SATA mode support High Quality Audio Capacitors & Audio Noise Guard with LED Trace Path Lighting Realtek Gigabit LAN with c Fos Speed Internet Accelerator Software Smart Fan 5 features 5 Temperature Sensors & 3 Hybrid Fan Headers GIGABYTE UEFI Dual BIOS™ APP Center Including Easy Tune™ & Cloud Station™ Utilities Overview Smart Fan 5 With Smart Fan 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan 5 more hybrid fan headers that support both PWM & Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly. All Hybrid Fan Pin Headers • All Hybrid Fan Headers can automatically detect the type of cooling device whether it be fan or pump with different PWM or Voltage mode. • Supports up to 2 amps with built-in overcurrent protection—a must for high-end high current fans. Realtek Gb E LAN with c Fos Speed Internet Accelerator Networking Realtek Gb E LAN features c Fos Speed, a network traffic management application which helps to improve network latency & maintain low ping times to deliver better responsiveness in crowded LAN environments.

Specification CPU AM4 Socket: AMD Ryzen™ processor AMD 7th Generation A-series/ Athlon™ processor (Please refer "CPU Support List" for more information.) Chipset AMD X370 Memory 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory Dual channel memory architecture Support for DDR4 3200 (O.C.)/2933 (O.C.)/2667*/2400/2133 MHz memory modules * Support for higher than DDR4 2667 MHz may vary by CPU. Support for ECC Un-buffered DIMM 1 Rx 8/2 Rx 8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1 Rx 8/2 Rx 8/1 Rx 16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor: 1 x D-Sub port, supporting a maximum resolution of 1920x 1200@60 Hz 1 x DVI-D port, supporting a maximum resolution of 1920x 1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x 2160@24 Hz * Support for HDMI 1.4 version. Support for up to 3 displays at the same time Maximum shared memory of 2 GB * Actual support may vary by CPU. Audio Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out LAN Realtek Gb E LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. * Actual support may vary by CPU. (The PCIEX16 slot conforms to PCI Express 3.0 standard.) 1 x PCI Express x 16 slot, running at x 4 (PCIEX4) 1 x PCI Express x 1 slot (The PCIEX4 & PCIEX1 slots conform to PCI Express 2.0 standard.) Storage Interface 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe x 4*/x 2 SSD support) * Actual support may vary by CPU. 6 x SATA 6 Gb/s connectors Support for RAID 0, RAID 1, & RAID 10 * Refer to "1-7 Internal Connectors, " for the installation notices for the M.2 & SATA connectors. USB Chipset: 2 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A ports (red) on the back panel 2 x USB (Universal Serial Bus) 3.1 Gen 1 ports (available through the internal USB (Universal Serial Bus) header) 6 x USB (Universal Serial Bus) 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) CPU: 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports on the back panel Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x M.2 Socket 3 connector 6 x SATA 6 Gb/s connectors 1 x CPU fan header 2 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB (Universal Serial Bus) 3.1 Gen 1 header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x 10 pin, for the GC-TPM2.0 module only) 2 x serial port headers 1 x parallel port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports 2 x USB (Universal Serial Bus) 3.1 Gen 2 Type-A ports (red) 2 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In, Line Out, Mic In) I/O Controller i TE I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the fan you install. BIOS 2 x 128 Mbit flash Use of licensed AMI UEFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.7, Wf M 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS 3D OSD Auto Green Ambient LED BIOS Setup Cloud Station Color Temperature Easy Tune Fast Boot Game Boost ON/OFF Charge Smart Backup Smart Keyboard Smart Time Lock System Information Viewer USB (Universal Serial Bus) Blocker V-Tuner Support for Q-Flash Support for Xpress Install Bundle Software Norton Internet Security (OEM version) c Fos Speed Operating System Support for Windows 10 64-bit Support for Windows 7 64-bit * To support Windows 7 64-bit, you must install an AMD Summit Ridge & Bristol Ridge CPU. * Please download the " Windows USB (Universal Serial Bus) Installation Tool" from GIGABYTEs website & install it before installing Windows 7. Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm Remark Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win 9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.

...
