Every single pieces of Gainward crowned " Golden Sample" has to survive from the most critical burn-in tests by operating in the most aggressive clock rate in extreme temperature, to ensure best stability under aggressive over-clocking. Gainward GTX 560 " Golden Sample" is manufactured with pre-over-clocked 8% from 822 MHz to 900 MHz for all 384 CUDA cores & from 2, 004 MHz to whopping 2, 100 MHz for GDDR5 256-bit memory bank, equivalent bandwidth is up to 134.4 GB/sec. With brand new translucent cover design, Gainward GTX 560 " Golden Sample" is proud to illustrate its thermal solution cooled by 4 pcs of Gainward Grand Prix (GP) heat-pipes cooler in 6 mm heat-pipes, forced ventilated by dual GR8 silent PWM fans, which has excellent OC capability & over-clocking behavior which is rather linear & predictable. ...

Superior hardware design Gainwards high-performance/ Wide-Bandwidth hardware design 822 MHz core clock, 2004 MHz memory clock High performance 2-slot cooler Dual DVI (resolution support up to 2560 x 1600), VGA & HDMI support Full integrated support for HDMI Designed to meet the output protection management & security specifications of the Blu-ray Disc formats Supports two monitors simultaneously Enabled by the NVIDIA n View Multi-Display technology for office applications, 3D gaming & professional applications Full support for NVIDIA Phys X technology enables a class of physical gaming interaction for a more dynamic & realistic experience with Ge Force Ge Force GPU support for NVIDIA 3D Vision, bringing a fully immersive stereoscopic 3D experience to the PC CUDA technology unlocks the power of the GPUs processor cores to accelerate the most demanding system tasks Easy Plug-&-Play autorun installation from CD-ROM NVIDIA SLI technology offers amazing performance scaling by implementing AFR for the premier gaming solution with solid, state-of-the-art drivers Provide good out-of-box experience for every user & deliver continuous performance & feature updates over the life of NVIDIA Ge Force GPUs Designed for the PCI Express 2.0 bus architecture, offering the high data transfer speeds for the bandwidth-hungry games & 3D applications Full support for Open CL GPU computing API Ensures top-notch compatibility & performance for Open GL applications The combination of high-definition video decode acceleration & post-processing Hardware decode acceleration ...

It is designed to meet the output protection management (HDCP) & security specifications of the Blu-ray Disc formats, allowing the playback of encrypted movie content on PCs when connected to HDCP-compliant displays. Direct X 11 GPU with Shader Model 5.0 support designed for ultra high performance in the APIs key graphics feature, GPU accelerated tessellation. GTX 560 Ti Golden Sample full supports for NVIDIA Phys X technology, enabling a class of physical gaming interaction for a more dynamic & realistic experience with Ge Force. Ge Force GPU support for NVIDIA 3D Vision, bringing a fully immersive stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. In addition, you can watch 3D movies & 3D digital photographs in eye popping, crystal-clear quality. CUDA technology unlocks the power of the GPUs processor cores to accelerate the most demanding system tasks such as video transcoding, physics simulation, ray tracing & more, delivering incredible performance over traditional CPUs. It delivers a proven record of compatibility, reliability, & stability with the widest range of games & applications. NVIDIA Ge Force drivers provide the best out-of-box experience for every user & deliver continuous performance & feature updates over the life of NVIDIA Ge Force GPUs. Designed for the PCI Express 2.0 bus architecture, offering the highest data transfer speeds for the most bandwidth-hungry games & 3D applications, while maintaining backwards compatibility with existing PCI Express motherboards for the broadest support. The combination of high-definition video decode acceleration & post-processing that delivers unprecedented picture clarity, smooth video, accurate color, & precise image scaling for movies & video. ...

Gainward GR 8 design Great 8 cm Fan (GR8) achieves highest cooling performance at much lower temperatures under power saving mode. Rugged Cap, Full Solid-State OS-CON capacitors Gainward designs in only with the highest quality components to ensure excellent stability at extreme conditions. EXPERTool- Gainwards award winning! Gainward takes care of your power-hungry desires, gears you up with the best graphics tuning utility
- EXPERTool, customized performance enhancements & efficient desktop management, which enable clock rates & fans controls. Specifications GPU
- Nvidia GTX 560SE Process Technology
- 40nm Processor Cores
- 288 Cores Memory Amount
- 1024MB Memory Interface
- 192bit DRAM Type
- GDDR5 Core Clock
- 736 M Hz Shader Clock
- 1472 M Hz Memory Clock
- 1914 M Hz Memory Bandwidth
- 91.9 (GB/ Sec) Outputs
- Dual-link DVI-I, HDMI, VGA

Dimensions
- PCB: 168mm (L) x 112mm (W), 2 Slot Coolers, 2 Slot Bracket Key Features Fermi 2.0 Microsoft Windows 7 support Direct X 11 Done Right Shader Model 5.0 support Microsoft Direct Compute 5.0 support NVIDIA Unified Driver Architecture (UDA) NVIDIA CUDA Technology Better NVIDIA Phys X performance NVIDIA 3D Vision support NVIDIA 3D Surround ready in SLI configuration NVIDIA Pure Video HD technology NVIDIA SLI support Open GL 4.1 support & Open CL Support High Definition 1080p Display Support Dual-link HDCP Capable Native HDMI 1.4a connector Minimum System Requirements Graphics card requires: PCI Express or PCI Express 2.0-compliant motherboard with two & half width x 16 graphics slot Two 6-pin PCI Express supplementary power connectors Minimum 450W or greater system power supply (with a minimum 12V current rating of 24A) Microsoft Windows 7, Windows Vista, Windows XP














...

Gainward’s award winning High- Performance/ Wide-Bandwidth TM hardware design powered by NVIDIA’s Ge Force TM GTX 560 Ti GPU (40nm) integrating 1024MB/256bits high-speed GDDR5 memory which offers enhanced, leading-edge performance for the 3D enthusiasts. Dual-link HDCP Capable: Designed to meet the output protection management (HDCP) & security specifications of the Blu-ray Disc formats, allowing the playback of encrypted movie content on PCs when connected to HDCP-compliant displays. Microsoft Direct X 11 Support: Direct X 11 GPU with Shader Model 5.0 support designed for ultra high performance in the new API’s key graphics feature, GPUaccelerated tessellation. NVIDIA Phys XTM: Full support for NVIDIA Phys X technology, enabling a totally new class of physical gaming interaction for a more dynamic & realistic experience with Ge Force. NVIDIA 3D Vision TM Ready: Ge Force GPU support for NVIDIA 3D Vision, bringing a fully immersive stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. In addition, you can watch 3D movies & 3D digital photographs in eye popping, crystal-clear Quality. NVIDIA CUDA Technology: CUDA technology unlocks the power of the GPU’s processor cores to accelerate the most demanding system tasks such as video transcoding, physics simulation, ray tracing & more, delivering incredible performance over traditional CPUs. Microsoft Windows 7 Support: Windows 7 is the next generation operating system that will mark a dramatic improvement in the way the OS takes advantage of the GPU to provide a more compelling user experience. Core 835 MHz Memory 2050 MHz Capacity 1024 MB Type GDDR5/256 Bits Outputs 2 x DVI-I, VGA, HDMI ...

Gainward’s award winning High- Performance/ Wide-Bandwidth TM hardware design powered by NVIDIA’s Ge Force TM GTX 560 Ti GPU (40nm) integrating 2GB/256bits high-speed GDDR5 memory which offers enhanced, leading-edge performance for the 3D enthusiasts. Dual-link HDCP Capable: Designed to meet the output protection management (HDCP) & security specifications of the Blu-ray Disc formats, allowing the playback of encrypted movie content on PCs when connected to HDCP-compliant displays. Supports two monitors simultaneously, enabled by the NVIDIA n View™ Multi- Display Technology for office applications, 3D gaming & professional applications such as CAD, DTP, animation or video editing. NVIDIA n View™ allows end-users to select any combination of multiple displays. Microsoft Direct X 11 Support: Direct X 11 GPU with Shader Model 5.0 support designed for ultra high performance in the new API’s key graphics feature, GPUaccelerated tessellation. NVIDIA Phys XTM: Full support for NVIDIA Phys X technology, enabling a totally new class of physical gaming interaction for a more dynamic & realistic experience with Ge Force. NVIDIA 3D Vision TM Ready: Ge Force GPU support for NVIDIA 3D Vision, bringing a fully immersive stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. In addition, you can watch 3D movies & 3D digital photographs in eye popping, crystal-clear quality. NVIDIA CUDATM Technology: CUDA technology unlocks the power of the GPU’s processor cores to accelerate the most demanding system tasks such as video transcoding, physics simulation, ray tracing & more, delivering incredible performance over traditional CPUs. Microsoft Windows 7 Support: Windows 7 is the next generation operating system that will mark a dramatic improvement in the way the OS takes advantage of the GPU to provide a more compelling user experience. By taking advantage of the GPU for both graphics & computing, Windows 7 will not only make today’s PCs more visual & more interactive but also ensure that they have the speed & responsiveness customers want. Core 822 M Hz Memory 2004 M Hz Capacity 2048 MB Type GDDR5/256 bits Outputs 2 x DVI-I, VGA, HDMI ...

Product Name: Gainward Ge Force GTX 570 1280MB GDDR5 GPU: Ge Force GTX 570 GPU Clockspeed: 732 Mhz Memory: 1280MB GDDR5 (320 bits) Memory Clockspeed: 1900 Mhz Pixels per clock (peak): N/A Bandwidth: 152 GB/s Ramdac: 400 MHz Bus: PCI-Express 2.0 Cooling: 2-Slot/dual Fan cooler Video-Features: HDMI Connectivity: Dual DVI-I, Display Port ...

Its GDDR5 memory is clocked at 1900 MHz, core clock is set at standard 732 MHz. Although clock rate is rather modest by default, the revolutionarily better cooling solution has left lots of headroom for over-clocking by Gainward award winning graphics tuning utility
- Expertool, which activates clock rate settings & fan control with user-friendly interface & fail-safe clock-down override. Owning Gainward GTX 570 series, you can enjoy the incredible 3D experience at extreme HD resolutions for todays hottest game titled World of War Craft or so with the epic performance & innovation thermal design. Along with all the benefits listed, Gainward GTX 570 series packs support all the premium GTX gaming technologies such as Direct X 11, NVIDIA Surround, 3D Vision, Phys X, & SLI. The new world has arrived! What are you waiting for? Gainward GTX 570 is your best Xmas gift & wish, play with it & immerse in amazing 3D experience without sacrificing any frame rig!
...

Gainward’s award winning High-Performance/ Wide-Bandwidth TM hardware design powered by NVIDIA’s Ge Force TM GTX 570 GPU (40nm) integrating 1280MB/320bits high-speed GDDR5 memory which offers enhanced, leading-edge performance for the 3D enthusiasts. Dual-link HDCP Capable: Designed to meet the output protection management (HDCP) & security specifications of the Blu-ray Disc formats, allowing the playback of encrypted movie content on PCs when connected to HDCP-compliant displays. NVIDIA Ge Force Unified Driver Architecture (UDA): Delivers a proven record of compatibility, reliability, & stability with the widest range of games & applications. NVIDIA Ge Force drivers provide the best out-of-box experience for every users & deliver continuous performance & feature updates over the life of NVIDIA Ge Force GPUs. Microsoft Direct X 11 Support: Direct X 11 GPU with Shader Model 5.0 support designed for ultra high performance in the new API’s key graphics feature, GPUaccelerated tessellation. NVIDIA Phys XTM: Full support for NVIDIA Phys X technology, enabling a totally new class of physical gaming interaction for a more dynamic & realistic experience with Ge Force. NVIDIA 3D Vision TM Ready: Ge Force GPU support for NVIDIA 3D Vision, bringing a fully immersive stereoscopic 3D experience to the PC. A combination of high-tech wireless glasses & advanced software, 3D Vision transforms hundreds of PC games into full stereoscopic 3D. In addition, you can watch 3D movies & 3D digital photographs in eye popping, crystal-clear quality. NVIDIA CUDATM Technology: CUDA technology unlocks the power of the GPU’s processor cores to accelerate the most demanding system tasks such as video transcoding, physics simulation, ray tracing & more, delivering incredible performance over traditional CPUs. Microsoft Windows 7 Support: Windows 7 is the next generation operating system that will mark a dramatic improvement in the way the OS takes advantage of the GPU to provide a more compelling user experience. By taking advantage of the GPU for both graphics & computing, Windows 7 will not only make today’s PCs more visual & more interactive but also ensure that they have the speed & responsiveness customers want. Core 750 M Hz Memory 1950 M Hz Capacity 1280 MB Type GDDR5/320 Bits Outputs Dual DVI-I, DP, HDMI ...

Gainward’s award winning High-Performance/ Wide-Bandwidth hardware design powered by NVIDIA’s Ge Force TM GTX 580 GPU (40nm) integrating 1536MB/384bits high-speed GDDR5 memory which offers enhanced, leading-edge performance for the 3D enthusiasts. 783 M Hz core clock, 2010 M Hz (DDR 4020) memory clock High performance 2.5-slot/three- fan cooler

Includes:: Gainward’s award winning EXPERTool tuning utility for customized performance enhancements & efficient desktop management. Product Name
- Gainward Ge Force GTX 580 1536MB " Phantom" GPU
- Ge Force GTX 580 GPU Clockspeed
- 783 Mhz Memory
- 1536MB GDDR5 (384 bits) Memory Clockspeed
- 2010 Mhz Bandwidth
- 193 GB/s Ramdac
- 400 MHz Bus
- PCI-Express 2.0 Cooling
- 2.5-Slot Video-Features
- HDMI Connectivity
- Dual DVI-I, Display Port












...
