The R9 270 supports Direct X 11.2 & all the latest game enhancements. It has 1280 stream processors & 2GB of GDDR5 memory delivering excellent performance in all but the most extreme settings, & is considerably faster than competing solutions in this price range. Specifications GPU 920/ Boost:945 MHz Core Clock 1280 x Stream Processors 28 nm Chip Video Memory 2048 MB Size 256 -bit GDDR5 5600 MHz Effective Display Support supports up to 2 display monitor (s) without Display Port 3 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I Dimension 228 (L)X109 (W)X35 (H) mm Size 2 x slot ...

The R9 270 supports Direct X 11.2 & all the latest game enhancements. It has 1280 stream processors & 2GB of GDDR5 memory delivering excellent performance in all but the most extreme settings, & is considerably faster than competing solutions in this price range. PCI Express based PC is required with one X16 lane graphics slot available on the motherboard 2X75 Watt 6-pin PCI Express power connector is required for Cross Fire X system 1X75 Watt 6-pin PCI Express power connector is required 4096MB Minimum of system memory Installation software requires CD-ROM drive DVD playback requires DVD drive Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive 500 Watt Power Supply is required 600 Watt Power Supply is recommended for Cross Fire X System Specifications Display Support
- supports up to 2 display monitor (s) without Display Port 3 x Maximum Display Monitor (s)
- support Output
- 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU
- 920/ Boost:945 MHz Core Clock 28 nm Chip 1280 x Stream Processors Video Memory
- 2048 MB Size 256 -bit GDDR5 5600 MHz Effective

Dimensions
- 228 (L)X109 (W)X35 (H) mm Size 2 x slot







...

The R9 270X supports Direct X 11.2 & all the latest game enhancements. It has 1280 stream processors & 2GB of GDDR5 memory delivering excellent performance in all but the most extreme settings, & is considerably faster than competing solutions in this price range. Specifications GPU 1020 MHz Core Clock 1280 x Stream Processors 28 nm Chip Video Memory 2048 MB Size 256 -bit GDDR5 5600 MHz Effective Output 1 x HDMI (with 3D) 1 x Display Port 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I Display Support 3 x Maximum Display Monitor (s) support

Dimensions 228 (L)X109 (W)X35 (H) mm Size. 2 x slot

...

Sapphire R9 270X 4GB GDDR5 WITH BOOST & OC Dual DVI HDMI Display Port Graphics Card The R9 270X supports Direct X 11.2 & all the latest game enhancements. It has 1280 stream processors & 4GB of GDDR5 memory delivering excellent performance in all but the most extreme settings, & is considerably faster than competing solutions in this price range. Specification: Display Support 3 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU Up to 1020/ Boost: Up to 1070 MHz Core Clock 28 nm Chip up to 1280 x Stream Processors Video Memory 4096 MB Size 256 -bit GDDR5 5600 MHz Effective Dimension 228 (L)X109 (W)X35 (H) mm Size. 2 x slot Software Driver CD SAPPHIRE Tri XX Utility Accessory Cross Fire Bridge Interconnect Cable DVI to VGA Adapter 6 PIN to 4 PIN Power Cable x 2 HDMI 1.4a high speed 1.8 meter cable (Full Retail SKU only) System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4X75 Watt 6-pin PCI Express power connector is required for Cross Fire X system. 2X75 Watt 6-pin PCI Express power connector is required. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 500 Watt Power Supply is required. 600 Watt Power Supply is recommended for Cross Fire X System. 64-bit operating system highly recommended ...

SAPPHIRE DUAL-X R9 270X 2GB GDDR5 OC Dual DVI HDMI Display Port PCI-E Graphics Card Aimed at the slightly more budget conscious gamer, the R9 270X series is the perfect match for gameplay at 1080p with maximum settings. The SAPPHIRE R9 270X Dual-X model again features the proven SAPPHIRE Dual-X technology & delivers the best cost:performance ratio in its class. Specification: Display Support 3 x Maximum Display Monitor (s) support Output: 1 x HDMI (with 3D) 1 x Display Port 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU: 1020 MHz Core Clock 28 nm Chip 1280 x Stream Processors Video Memory: 2048 MB Size 256 -bit GDDR5 5600 MHz Effective Dimension: 228 (L)X109 (W)X35 (H) mm Size. 2 x slot Software: Driver CD SAPPHIRE Tri XX Utility System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4X75 Watt 6-pin PCI Express power connector is required for Cross Fire X system. 2X75 Watt 6-pin PCI Express power connector is required. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 500 Watt Power Supply is required. 600 Watt Power Supply is recommended for Cross Fire X System. 64-bit operating system highly recommended ...

Sapphire Vapor-X R9 270X 2GB GDDR5 OC Dual DVI HDMI Displayort PCI-E Graphics Card Aimed at the slightly more budget conscious gamer, the R9 270X series is the perfect match for gameplay at 1080p with maximum settings. The SAPPHIRE R9 270X Vapor-X model features a second generation Vapor-X cooler design, lighter in weight but delivering the industry acclaimed quiet & efficient cooling associated with this br&. Specification: Display Support 4 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU: 1050/ Boost:1100 MHz Core Clock 28 nm Chip 1280 x Stream Processors Video Memory: 2048 MB Size 256 -bit GDDR5 5800 MHz Effective Dimension: 264 (L)X103 (W)X35 (H) mm Size. 2 x slot Software: Driver CD SAPPHIRE Tri XX Utility System Requirements: PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4X75 Watt 6-pin PCI Express power connector is required for Cross Fire X system. 2X75 Watt 6-pin PCI Express power connector is required. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray/HD DVD playback requires Blu-ray / HD DVD drive. 500 Watt Power Supply is required. 600 Watt Power Supply is recommended for Cross Fire X System. 64-bit operating system highly recommended ...

The SAPPHIRE R9 270X Vapor-X model features a second generation Vapor-X cooler design, lighter in weight but delivering the industry acclaimed quiet & efficient cooling associated with this br&.

Specification Display Support 4 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU 1050/ Boost:1100 MHz Core Clock 28 nm Chip 1280 x Stream Processors Video Memory 2048 MB Size 256 -bit GDDR5 5800 MHz Effective

Dimensions 264 (L)X103 (W)X35 (H) mm Size. 2 x slot



...

With 3GB of the latest GDDR5 memory & 1792 stream processors, & support for Direct X 11.2, the architecture is built to play the very latest games with perfectly smooth action even at higher resolutions such as 2560 x 1440. In fact its Ultra HD graphics processor can feed even the latest 4K displays with the HDMI 1.4a interface. The R9 280 family represents a breakthrough in cost:performance.

Specification Display Support supports up to 3 display monitor (s) without Display Port 4 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU 850 (Boost:940) MHz Core Clock 28 nm Chip 1792 x Stream Processors Video Memory 3072 MB Size 384 -bit GDDR5 5000 MHz Effective Dimension 262 (L)X112 (W)X34 (H) mm Size. 2 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4X75 Watt 6-pin PCI Express power connector is required for Cross Fire X™ system. 2X75 Watt 6-pin PCI Express power connector is required. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 500 Watt Power Supply is required. 850 Watt Power Supply is recommended for Cross Fire X System.

...

Always looking to deliver the best solutions to the user, even the base model in this family features SAPPHIRE’s highly acclaimed Dual-X cooler. Dual-X, with its two aerofoil fans, & graduated heatpipes, is a design which received industry acclaim in the previous generation of products. The SAPPHIRE R9 280X Dual-X model is the most cost effective member of the family & yet is still overclocked compared with the reference design to give users the best possible value for your money in this performance class. Specifications Display Support 3 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 1 x Display Port 1.2 1 x Dual-Link DVI-D 1 x Dual-Link DVI-I GPU 870/ Boost:1020 MHz Core Clock 28 nm Chip 2048 x Stream Processors Video Memory 3072 MB Size 384 -bit GDDR5 6000 MHz Effective Dimension 262 (L)X112 (W)X34 (H) mm Size 2 x slot Accessory Cross Fire Bridge Interconnect Cable 8 PIN to 4 PIN Power Cable 6 PIN to 4 PIN Power Cable ...

“ Free AMD Radeon Rewards download coupon GOLD from 30th April 2014 whilst stocks last with selected cards. Offer on selected cards only, not available on ex-display cards.” The SAPPHIRE R9 280X TOXIC Edition features the exciting new Tri-X cooler design which uses three sophisticated aerofoil section fans together with industry leading 10mm heatpipes to give unrivalled cooling efficiency. The stylish shroud is designed not only to look cool, but to manage the airflow over the card for maximum cooling effect. This new cooler, together with a high performance 10-phase power management system & high quality components such as the SAPPHIRE exclusive double sided Black Diamond chokes & long-life solid capacitors, has enabled SAPPHIRE to deliver stable higher power levels whilst keeping temperatures low. As a result the TOXIC edition features extreme factory programmed overclocks, delivering the best performance in the industry for this product family. & at the touch of a switch, the user can choose between UEFI & non-UEFI platforms. Display Support
- 5 x Maximum Display Monitor (s) support Output 1 x HDMI (with 3D) 2 x Mini-Display Port 1 x Single-Link DVI-D 1 x Dual-Link DVI-I GPU 1100/ Boost:1150 MHz Core Clock 28 nm Chip 2048 x Stream Processors Video Memory 3072 MB Size 384 -bit GDDR5 6400 MHz Effective Dimension 308 (L)X113 (W)X41 (H) mm Size. 2.2 x slot System Requirements PCI Express based PC is required with one X16 lane graphics slot available on the motherboard. 4096MBMinimum of system memory. Installation software requires CD-ROM drive. DVD playback requires DVD drive. Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive. 750 Watt Power Supply is required. 1000 Watt Power Supply is recommended for Cross Fire X System. 2X150 Watt 8-pin PCI Express power connector is required. 4X150 Watt 8-pin PCI Express power connector is required for Cross Fire X system.
...
