Intel H61 Chipset All new design of Ultra Durable 4 classic Supports for Intel LGA1155 2nd Generation Intel Core™ Processors Unique On/ Off Charge delivers the best recharging capability to iPad, iPhone & iPod Touch Supports 3rd generation PCI-Express interface DVI interface for smoother HD video playback Industrys Leading All Solid Capacitor Design Enhanced Intel HD Graphics 2000/3000 integrated with the processor Dual UEFI BIOS™ protection with 3TB+ HDD boot up capability

Specification
- CPU Support for Intel Core™ i 7 processors/ Intel Core™ i 5 processors/ Intel Core™ i 3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1155 package L3 cache varies with CPU (Some Intel Core™ processors require a graphic card, please refer "CPU support List" for more information.) Chipset Intel H61 Express Chipset Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory * Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB. Dual channel memory architecture Support for DDR3 1333/1066/800 MHz memory modules Support for non-ECC memory modules (Please refer " Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor: 1 x D-Sub port 1 x DVI-D port, supporting a maximum resolution of 1920x 1200 * The DVI-D port does not support D-Sub connection by adapter. Audio Realtek ALC887 audio codec High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module & enable the multi-channel audio feature through the audio driver. LAN 1 x Atheros 8151 LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x 16 slot, running at x 16 (The PCI Express x 16 slot conforms to PCI Express 3.0 standard.) * PCIE Gen.3 is dependent on CPU & expansion card compatibility. 1 x PCI Express x 1 slot (The PCI Express x 1 slot conforms to PCI Express 2.0 standard.) 2 x PCI slots Storage Interface Chipset: 4 x SATA 3 Gb/s connectors supporting up to 4 SATA 3 Gb/s devices USB Chipset: Up to 8 USB (Universal Serial Bus) 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB (Universal Serial Bus) headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 4 x SATA 3 Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 2 x USB (Universal Serial Bus) 2.0/1.1 headers 1 x serial port header 1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x parallel port 1 x D-Sub port 1 x DVI-D port 4 x USB (Universal Serial Bus) 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In/ Line Out/ Microphone) I/O Controller i TE IT8728 chip H/W Monitoring System voltage detection CPU/ System temperature detection CPU/ System fan speed detection CPU overheating warning CPU/ System fan fail warning CPU/ System fan speed control * Whether the CPU/ System fan speed control function is supported will depend on the CPU/ System cooler you install. BIOS 2 x 32 Mbit flash Use of licensed AMI EFI BIOS Support for Dual BIOS™ Pn P 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a Unique Features Support for @BIOS Support for Q-Flash Support for Xpress Recovery 2 Support for Easy Tune * Available functions in Easy Tune may differ by motherboard model. Support for ON/OFF Charge Bundle Software Norton Internet Security (OEM version) Operating System Support for Microsoft Windows 8/7/ Vista/XP Form Factor Micro ATX Form Factor; 24.4cm x 20cm


...

GIGABYTE HD Experience Series Powered by AMD Radeon HD 5450 GPU Integrated with the first 1GB DDR3 memory & 64-bit memory interface Features Dual-link DVI-I / D-sub / HDMI Support Cross Fire X™ & Avivo™HD System power supply requirement: 400W

Specification
- Chipset
- Radeon HD 5450 Direct X
- 11 Open GL
- 4.1 Core Clock
- 650 MHz Shader Clock
- N/A Memory Clock
- 1100 MHz Process Technology
- 40 nm Memory Size
- 1 GB Memory Bus
- 64 bit Card Bus
- PCI-E 2.1 Memory Type
- DDR3 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 I/O
- HDMIx 1, DVI-Ix 1, D-subx 1 Card size
- H=22 mm, L=183 mm, W=122 mm Power requirement
- 400 W



















...

Faster clocks, double the transistor density of earlier 40 nm technology. 40 nm technology helped make HD5450 series product advanced GPU high clocks speeds, incredible feature integration, full performance & precision all the time, & ability to take advantage of future, higher-speed memories. Chipset
- Radeon HD 5450 Core Clock
- 650 MHz Memory Clock
- 800 MHz Process Technology
- 40 nm Memory Size
- 512 MB Memory Bus
- 64 bit Card Bus
- PCI-E 2.1 Memory Type
- DDR2 Direct X
- 11 Open GL
- 3.1 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 I/O
- HDMI * 2, Display Port * 1, D-sub * 1 Card size
- H=21 mm, L=179 mm, W=120 mm Power requirement
- 400 W














...

This stylish heatsink uses the natural air flow in the case to cool down & provides great gaming experience under silent 0 d B environment. Avivo could provide vibrant high fidelity, flawlessly smooth next-generation video playback. Avivo technology easily allows your PCs to become digital home media center by its compelling video pipeline design that comprises the high definition video hardware acceleration. Using high quality components on graphics cards is the key factor for having a long lasting, stable & reliable product. Gigabyte is again setting a standard by using ferrite core chokes, low RDS (on) MOSFET & lower ESR solid capacitors, providing the stability & reliability from their high-end graphics solution. In addition, Gigabyte ultra durable 2 edition graphics cards now feature a sophisticated layout topology. This state-of-the-art power design from Gigabyte delivers the ideal integration of thermal, electric characteristics, digital signals, power circuitry & optimum placement of components for enhanced graphics performance. Multiply & conquer with multi-GPU performance: Cross Fires "supertiling" GPU sharing speeds rendering by evenly dividing the graphics processing, intelligently alternating the rendering workload to each Radeon GPU for efficient load balancing, & optimized performance. Cross Fire boosts image quality along with rendering speed, eliminating the need to crank down screen resolutions to get the high image quality you want. Cross Fire supports a wide range of ATI-based graphics cards & motherboards, & offers compatibility with a broad array of third party components for a flexible & robust solution. Specifications Chipset
- Radeon HD 5450 Direct X
- 11 Open GL
- 3.2 Core Clock
- 650 MHz Memory Clock
- 1333 MHz Process Technology
- 40 nm Memory Size
- 1 GB Memory Bus
- 64 bit Card Bus
- PCI-E 2.1 Memory Type
- DDR3 PCB Form
- Low Profile Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 I/O
- HDMI * 1 DVI-I * 1 D-sub * 1 Card size
- H=21 mm, L=179 mm, W=126 mm Power requirement
- 400 W
















...

Gigabyte HD 5570 2GB DDR3 DVI HDMI PCI-E Graphics Card Chipset
- Radeon HD 5570 Core Clock
- 650 MHz Memory Clock
- 1600


...

This stylish heatsink uses the natural air flow in the case to cool down & provides great gaming experience under silent 0 d B environment. Avivo could provide vibrant high fidelity, flawlessly smooth next-generation video playback. Avivo technology easily allows your PCs to become digital home media center by its compelling video pipeline design that comprises the high definition video hardware acceleration. Using high quality components on graphics cards is the key factor for having a long lasting, stable & reliable product. Gigabyte is again setting a standard by using ferrite core chokes, low RDS (on) MOSFET & lower ESR solid capacitors, providing the stability & reliability from their high-end graphics solution. In addition, Gigabyte ultra durable 2 edition graphics cards now feature a sophisticated layout topology. This state-of-the-art power design from Gigabyte delivers the ideal integration of thermal, electric characteristics, digital signals, power circuitry & optimum placement of components for enhanced graphics performance. Specifications Chipset
- Radeon HD 6450 PCB Form
- Low Profile Core Clock
- 625 MHz Memory Clock
- 1333 MHz Process Technology
- 40 nm Memory Size
- 1 GB Memory Bus
- 64 bit Card Bus
- PCI-E 2.1 Memory Type
- DDR3 Direct X
- 11 Open GL
- 4.1 I/O
- HDMI * 1 DVI-D * 1 D-sub * 1 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 Card size
- H=21 mm, L=179 mm, W=126 mm Power requirement
- 400 W
















...

Using high quality components on graphics cards is the key factor for having a long lasting, stable & reliable product. GIGABYTE is again setting a new standard by Gigabyte HD 6570 2GB DDR3 DVI HDMI Display Port PCI-E Graphics Card using Ferrite Core Chokes, Low RDS (on) MOSFET & Lower ESR Solid Capacitors, providing the stability & reliability from their high-end graphics solution. In addition, GIGABYTE Ultra Durable 2 Edition graphics cards now feature a sophisticated layout topology. This state-of-the-art power design from GIGABYTE delivers the ideal integration of thermal, electric characteristics, digital signals, power circuitry & optimum placement of components for enhanced graphics performance. Chipset
- Radeon HD 6570 PCB Form
- ATX Core Clock
- 650 MHz Shader Clock
- N/A Memory Clock
- 1600 MHz Process Technology
- 40 nm Memory Size
- 2 GB Memory Bus
- 128 bit Card Bus
- PCI-E 2.1 Memory Type
- DDR3 Direct X
- 11 Open GL
- 4.1 I/O HDMI * 1 DVI-D * 1 D-sub * 1 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 Card size
- H=32.5 mm, L=211.8 mm, W=129.9 mm Power requirement
- 400 W
















...

Using high quality components on graphics cards is the key factor for having a long lasting, stable & reliable product. Gigabyte is again setting a new standard, providing the stability & reliability from their high-end graphics solution. In addition, Gigabyte Ultra Durable 2 edition graphics cards feature a sophisticated layout topology. This state-of-the-art power design from Gigabyte delivers the ideal integration of thermal, electric characteristics, digital signals, power circuitry & optimum placement of components for enhanced graphics performance. GIGABYTE HD Experience Series Powered by AMD Radeon HD 6570 GPU Integrated with the first 1GB DDR3 memory & 128-bit memory interface Features Dual-link DVI-D / D-sub / HDMI Overclock to 670 MHz Support Cross Fire X & Avivo HD System power supply requirement: 400W Chipset
- Radeon HD 6570 PCB Form
- ATX Core Clock
- 670 MHz Memory Clock
- 1600 MHz Process Technology
- 40 nm Memory Size
- 1 GB Memory Bus
- 128 bit Card Bus
- PCI-E 2.1 Memory Type
- DDR3 Direct X
- 11 Open GL
- 4.1 I/O
- HDMI * 1, DVI-D * 1, D-sub * 1 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 Card size
- H=32.5 mm, L=211.8 mm, W=129.9 mm Power requirement
- 400W
















...

GIGABYTE HD Experience Series Powered by AMD Radeon HD 6670 GPU Integrated with the first 2GB DDR3 memory & 128-bit memory interface Features Dual-link DVI-D / D-sub / HDMI Support Cross Fire X™ & Avivo™HD System power supply requirement: 400W

Specification
- Chipset
- Radeon HD 6670 Tools
- N/A Core Clock
- 800 MHz Shader Clock
- N/A Memory Clock
- 1600 MHz Process Technology
- 40 nm Memory Size
- 2 GB Memory Bus
- 128 bit Card Bus
- PCI-E 2.1 Memory Type
- DDR3 Direct X
- 11 Open GL
- 4.1 PCB Form
- ATX I/O
- HDMIx 1, DVI-Dx 1, D-subx 1 Digital max resolution
- 2560 x 1600 Analog max resolution
- 2048 x 1536 Multi-view
- 2 Card size
- H=37.7 mm, L=211.8 mm, W=136.8 mm Power requirement
- 400 W





















...

Specifications Chipset
- Radeon HD 6770 Core Clock
- 775 M Hz Memory Clock
- 4000 MHz Process Technology
- 800 Memory



...
