Specifications Family
- AMD A4 Series Model Number
- A4-6300 Core Frequency
- 3700 M Hz Turbo Frequency
- 3900 M Hz Socket
-




...

&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203; Get more of what you want with an AMD A-Series APU Changing the game for PCs by revolutionizing the accelerated desktop processor that combines the power of a multicore CPU with AMD Radeon™ graphics all in one energy-efficient chip. Unlock your system’s full potential with HSA-enabled APUs Experience a new level of immersion with AMD True Audio technology Blaze through apps with AMD Turbo Core technology Specifications Model
- AMD A4-7300 Core Frequency
- 3.8 G Hz Turbo Core Frequency
- 4 G Hz Number of Cores
- 2 L2 shared Cache
- 1MB AMD Radeon Graphics Brand
- HD 8470D AMD Radeon Cores
- 192 GPU Clock Speed
- 800 M Hz Max DDR3
- 1600 M Hz TDP
- 65 Watts









...

Now you can create exactly what you want using a top-of-the-line AMD processor or the innovative AMD Accelerated Processor Unit (APU). Processor
- AMD A6-3670K Socket
- FM1 Cores
- 4 Clock
- 2.7 G Hz Cache
- 4MB L2 Cache (4 x 1MB) Graphics
- HD 6530D Graphics Cores on Die
- 320 GPU Clock speed
- 444 M Hz Direct X Version
- DX11








...

Choose the AMD CPU or APU that’s right for you. Build your own system with an AMD processor-in-a-box (PIB) & get exactly what you want from an innovative AMD A-Series Accelerated Processor Unit (APU). Specifications Model
- A6-7400K Radeon Brand
- Radeon R5 Graphics Compute Cores
- 6 (2 CPU + 4 GPU) CPU Clock Speed
- 3.5 G Hz / 3.9 G Hz Turbo Totel L2 Cache
- 1MB DDR3 Speed
- 1866 M Hz GPU Clock Speed
- 756 Mhz TDP
- 65 Watt







...

AMD A6-7470K 4.0 GHz Socket FM2+ 1MB Cache Retail Boxed Processor AMD A6-7470K specifications General information Type CPU / Microprocessor Market segment Desktop Family AMD A6-Series Model number A6-7470K Frequency 3700 MHz Turbo frequency 4000 MHz Boosted P states [1] 1: 4000 MHz, 1.425V 2: 3800 MHz, 1.375V Package 906-pin lidded micro-PGA package Socket Socket FM2+ Size 1.57" x 1.57" / 4cm x 4cm Architecture / Microarchitecture Microarchitecture Steamroller Processor core Godavari CPUID 630F81 Manufacturing process 0.028 micron Data width 64 bit The number of CPU cores 2 The number of threads 2 Floating Point Unit Integrated Level 1 cache size 96 KB 3-way set associative shared instruction cache 2 x 16 KB 4-way set associative data caches Level 2 cache size 1 MB 16-way set associative shared cache Level 3 cache size None Multiprocessing Uniprocessor Features MMX instructions Extensions to MMX SSE / Streaming SIMD Extensions SSE2 / Streaming SIMD Extensions 2 SSE3 / Streaming SIMD Extensions 3 SSSE3 / Supplemental Streaming SIMD Extensions 3 SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 SSE4a AES / Advanced Encryption Standard instructions AVX / Advanced Vector Extensions BMI1 / Bit Manipulation instructions 1 F16C / 16-bit Floating-Point conversion instructions FMA3 / 3-operand Fused Multiply-Add instructions FMA4 / 4-operand Fused Multiply-Add instructions TBM / Trailing Bit Manipulation instructions XOP / e Xtended Operations instructions AMD64 / AMD 64-bit technology AMD-V / AMD Virtualization technology EVP / Enhanced Virus Protection Turbo Core 3.0 technology Low power features Power Now! Low power P states [1] 1: 3500 MHz, 1.225V 2: 3000 MHz, 0.875V 3: 2600 MHz, 0.75V 4: 1900 MHz, 0.65V 5: 1400 MHz, 0.525V Integrated peripherals / components Integrated graphics GPU Type: Radeon R5 series Shader cores: 256 Base frequency (MHz): 800 Memory controller The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-2133 Maximum memory bandwidth (GB/s): 34.1 ...

&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203;&8203; Get more of what you want with an AMD A-Series APU Changing the game for PCs by revolutionizing the accelerated desktop processor that combines the power of a multicore CPU with AMD Radeon™ graphics all in one energy-efficient chip. Unlock your system's full potential with HSA-enabled APUs Experience a new level of immersion with AMD True Audio technology Blaze through apps with AMD Turbo Core technology Specifications Model
- AMD A8-6500T Core Frequency
- 2.1 G Hz Turbo Core Frequency
- 3.1 G Hz Number of Cores
- 4 L2 shared Cache
- 4MB AMD Radeon Graphics Brand
- HD 8570D AMD Radeon Cores
- 256 GPU Clock Speed
- 720 M Hz Max DDR3
- 1600 M Hz TDP
- 45 Watts









...

Specifications Family
- AMD A8 Series Model Number
- A8 7650K Socket
- AMD FM2+ Frequency
- 3.3 G Hz Turbo Frequency
-




...

Choose the AMD CPU or APU that’s right for you. Build your own system with an AMD processor-in-a-box (PIB) & get exactly what you want from an innovative AMD A-Series Accelerated Processor Unit (APU). Specifications Model
- A8-7600 Radeon Brand
- Radeon R7 Graphics Compute Cores
- 10 (4 CPU + 6 GPU) CPU Clock Speed
- 3.1GHZ / 3.8 G Hz Turbo Totel L2 Cache
- 4MB DDR3 Speed
- 2133 M Hz GPU Clock Speed
- 720 Mhz TDP
- 65 Watt







...

AMD A8-7650K 3.8 GHz Socket FM2+ 4MB Cache Retail Boxed Processor AMD A8-7650K specifications General information Type CPU / Microprocessor Market segment Desktop Family AMD A8-Series Model number A8-7650K CPU part number: AD765KXBJASBX is a boxed microprocessor with low-noise fan & heatsink Frequency 3300 MHz Turbo frequency 3800 MHz Boosted P states [1] 1: 3800 MHz, 1.35V 2: 3600 MHz, 1.325V 3: 3500 MHz, 1.275V Package 906-pin lidded micro-PGA package Socket Socket FM2+ Size 1.57" x 1.57" / 4cm x 4cm Architecture / Microarchitecture Microarchitecture Steamroller Processor core Kaveri Core stepping KV-A1 CPUID 630F01 Manufacturing process 0.028 micron 2.41 billion transistors Die size 245mm 2 Data width 64 bit The number of CPU cores 4 The number of threads 4 Floating Point Unit Integrated Level 1 cache size 2 x 96 KB 3-way set associative shared instruction caches 4 x 16 KB 4-way set associative data caches Level 2 cache size 2 x 2 MB 16-way set associative shared caches Level 3 cache size None Multiprocessing Uniprocessor Features MMX instructions Extensions to MMX SSE / Streaming SIMD Extensions SSE2 / Streaming SIMD Extensions 2 SSE3 / Streaming SIMD Extensions 3 SSSE3 / Supplemental Streaming SIMD Extensions 3 SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 SSE4a AES / Advanced Encryption Standard instructions AVX / Advanced Vector Extensions BMI1 / Bit Manipulation instructions 1 F16C / 16-bit Floating-Point conversion instructions FMA3 / 3-operand Fused Multiply-Add instructions FMA4 / 4-operand Fused Multiply-Add instructions TBM / Trailing Bit Manipulation instructions XOP / e Xtended Operations instructions AMD64 / AMD 64-bit technology AMD-V / AMD Virtualization technology EVP / Enhanced Virus Protection Turbo Core 3.0 technology Low power features Power Now! C1, CC6 & PC6 states Package S3, S5 & S5 states Low power P states [1] 1: 3100 MHz, 0.95V 2: 2800 MHz, 0.8V 3: 2400 MHz, 0.5V 4: 1900 MHz, 0.325V Integrated peripherals / components Integrated graphics GPU Type: Radeon R7 series Shader cores: 384 Base frequency (MHz): 720 The number of supported displays: 4 Memory controller The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-2133 DIMMs per channel: 2 Maximum memory bandwidth (GB/s): 34.1 ...

AMD A8-7670K 3.9 GHz Socket FM2+ 4MB Cache Retail Boxed Processor AMD A8-7670K specifications General information Type CPU / Microprocessor Market segment Desktop Family AMD A8-Series Model number A8-7670K CPU part number: AD767KXBJCSBX is a boxed microprocessor with low-noise fan & heatsink Frequency 3600 MHz Turbo frequency 3900 MHz Boosted P states [1] 1: 3900 MHz, 1.375V 2: 3700 MHz, 1.25V Package 906-pin lidded micro-PGA package Socket Socket FM2+ Size 1.57" x 1.57" / 4cm x 4cm Architecture / Microarchitecture Microarchitecture Steamroller Processor core Godavari Core stepping A1 CPUID 630F81 Manufacturing process 0.028 micron Data width 64 bit The number of CPU cores 4 The number of threads 4 Floating Point Unit Integrated Level 1 cache size 2 x 96 KB 3-way set associative shared instruction caches 4 x 16 KB 4-way set associative data caches Level 2 cache size 2 x 2 MB 16-way set associative shared caches Level 3 cache size None Multiprocessing Uniprocessor Features MMX instructions Extensions to MMX SSE / Streaming SIMD Extensions SSE2 / Streaming SIMD Extensions 2 SSE3 / Streaming SIMD Extensions 3 SSSE3 / Supplemental Streaming SIMD Extensions 3 SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4 SSE4a AES / Advanced Encryption Standard instructions AVX / Advanced Vector Extensions BMI1 / Bit Manipulation instructions 1 F16C / 16-bit Floating-Point conversion instructions FMA3 / 3-operand Fused Multiply-Add instructions FMA4 / 4-operand Fused Multiply-Add instructions TBM / Trailing Bit Manipulation instructions XOP / e Xtended Operations instructions AMD64 / AMD 64-bit technology AMD-V / AMD Virtualization technology EVP / Enhanced Virus Protection Turbo Core 3.0 technology Low power features Power Now! Low power P states [1] 1: 3400 MHz, 1.025V 2: 3100 MHz, 0.85V 3: 2800 MHz, 0.75V 4: 2400 MHz, 0.55V 5: 1900 MHz, 0.45V Integrated peripherals / components Integrated graphics GPU Type: Radeon R7 series Shader cores: 384 Base frequency (MHz): 757 The number of supported displays: 4 Memory controller The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-2133 Maximum memory bandwidth (GB/s): 34.1 ...
