Fanless Design Its innovative fanless heat dissipation design is both silent & energy efficient. A fan-less design also reduces malfunctions & increases the life-cycle of the Cubi N mini PC Happiness all around MSI Cubi N is equipped with a Intel Gemini Lake processor which improves the decoding technology to support HEVC (H.265) decoding to provide substantially enhanced video quality & brings whole new ultra-realistic visuals. With Cubi N, you can experience the high quality of 4K UHD. Do more work simultaneously Are you watching a lot of webpages & applications on a small monitor? With the HDMI port & VGA port MSI Cubi N can support dual monitors, you can do & view more Mountable to a Monitor Cubi N is designed with a mini size & supports standard VESA-mount. Mount the Cubi N to the back of a monitor & make the PC completely invisible. Palm-sized size PC Smaller than a lunchbox & less volume than a large soda can, MSI Cubi N is the smallest mini PC in its kind. With a 0.45 liter case that still provides all the elements of a desktop-worthy PC. With a wavy meshed design, Cubi N is not just a mini PC but a fashion house decoration. Processor Intel Pentium N5000 1.1 G Hz Up to 2.7 G Hz Quad Core Memory 4GB DDR4 2400 M Hz Storage 64GB SSD Optical Drive None Software Operating System: Windows 10 Pro Display Not Included Graphics Integrated Intel UHD Input Devices Not Included Networking Intel Dual Band Wireless-AC 3168 Realtek 8111H Gigabit LAN 10/100/1000 Bluetooth 4.2 Power Supply 40W

Dimensions Width 116 mm Depth 112 mm Height 44.47 mm (SSD) 55.5 mm (HDD) Weight 555-660kg Interfaces Front 2 x USB (Universal Serial Bus) 3.1 Gen 1 Type A (one is with Super charger) 1 x mic in/headphone out Rear 2 x USB3.1 Gen 1 Type A 1 x HDMI out (1.4) 1 x RJ45 1 x VGA out 1 x DC jack Warranty 2 Year Manufacturer Warranty

...

MSI Cubi-010BEU Intel Broadwell Ci 3- 5005U Non-OS Barebone Spec: • Intel I3 2.0 Ghz 5005U Broadwell Processor • Intel HD Graphics with HDMI & DP • Just add Memory / Storage • Built in Wireless • Cubi-0010BEU

Features: • Only 0.45L liters measuring 115 x 111 x 35mm easy to place & carry out • Equipped with 5th Gen Intel Broadwell-U processors, low power consumption high performance • Unique modular design satisfy you big data desire • True 4K UHD display @mini DP & dual display support • 802.11AC & Bluetooth inside, unlimited integration with the world • Low noise design, quiet as a forest • Support standard VESA-mount, efficiency space saving WHEN YOU’RE SMALL, YOU HAVE TO BE SMART. With the smallest mini-PC to date, the MSI Cubi suits the needs of both consumers & businesses, built on a concept of nifty technology & a brilliant design that fits into any room. Featuring a wide range of Intel processors, combined with a unique expandability option & plenty of ports to connect with external devices, Cubi is the essence of small, smart computing. IDEAL FOR COUNTLESS APPLICATIONS The MSI Cubi is one of the latest & smallest mini-desktops, suited to serve as HTPC at home, all-round media PC in the office or commercial project PC. SMART DESIGN & NEAT COLORS With curved edges, a smooth surface, a subtle ventilation frame & conveniently positioned I/O ports, the MSI Cubi is not only the smallest, but also the smartest in its kind. EXPANDABLE WITH EXTRA HDD Base on a modular design, the MSI Cubi offers the possibility to install an additional 2.5" HDD for a super high capacity data storage. SUPPORTS LATEST INTEL BROADWELL PROCESSOR Built-in with the Intel’s latest 14nm Intel Broadwell processor
- with an integrated GPU performance increase of 40% & total power consumption decrease of 30% compared to the previous generation – the Cubi is both powerful & energy efficient at the same. 4K UHD SUPPORT MSI Cubi supports HD & 4K (3840 x 2160 @ 60 Hz) ultra-high-definition content, to serve as an HTPC that helps to change your living room in a home theater where you can enjoy the best display quality. DUAL DISPLAY With dual display support (via HDMI & Mini Display Port) you can connect two monitors at the same time for an efficient day at the office. LOW POWER CONSUMPTION This mini-PC is a true energy vanguard; in full loading the total power consumption is less than 30 Watt, saving a lot of money on the energy bill. MOUNTABLE TO A MONITOR Cubi can be mounted to the back of a monitor which makes the PC completely invisible on a desk. With such a low-noise PC, you won’t even notice it’s there at all!


...

. rm__row { display: flex; justify-content: center; align-items: center; flex-direction: row; background-
Colour: black;
...

. rm__row { display: flex; justify-content: center; align-items: center; flex-direction: row; background-
Colour: black;
...

MSI Dragon Liquid CPU Cooler Compatible CPU Types: Intel LGA 2011, LGA 1366, LGA 1155/1156 • AMD AMD AM2, AM2+, AM3, FM1 Depth: 12.0 cm Form Factor: CPU Cooler Height: 2.7 cm Marketing: The low profile liquid cooler delivers superior cooling capability to manufacturers of workstations & high performance gaming systems. Operating Humidity: 5 to 95 % Operating Temperature: 5 to 35 °C Product Type: CPU Cooler Socket: Intel LGA 2011 • Intel LGA 1156 • Intel LGA 1366 • AMD AM2, AM2+, AM3, FM1 Weight: 0.225kg Width: 15.1 cm ...

CPU Integrated AMD Zacate-FT1 APU
- Zacate E350, dual core Chipset AMD Hudson M1 Chipset Main Memory Supports two unbuffered DIMM
...

This MSI Star Type ES500 98-Key USB (Universal Serial Bus) Multimedia Keyboard delivers the performance you need to make day to day computing tasks easier! It features a USB (Universal Serial Bus) interface, isolated keycap structure design & a 98-Key layout. This keyboard comes with Multimedia keys, Num lock, Caps lock & Scroll lock LEDs & is rated for up to 12 million keystrokes to ensure trouble-free typing. ...

Processor Support Supports AMD Fusion FM2 series Chipset AMD A55 chipset Memory Support DDR3 1066/1333/1600/1866 SDRAM (16GB Max) Supports dual channel mode LAN Supports LAN 10/100/1000 Fast Ethernet by Realtek RTL8111E Audio Chip integrated by Realtek ALC887 Flexible 8-channel audio with jack sensing Compliant with Azalia 1.0 Spec SATA 4 SATA 3 Gb/s ports by AMD A55 Back panel 1 PS/2 mouse port 1 PS/2 keyboard port 1 VGA port 1 HDMI port 4 USB (Universal Serial Bus) 2.0 ports 1 LAN jack 3 flexible audio jacks On-Board Connectors 2 USB (Universal Serial Bus) 2.0 connectors 1 Front Panel Audio connector 1 Serial connector 1 TPM Module connector 1 Chassis Intrusion connector Slots 1 PCI Express x 16 slot 1 PCI Express x 1 slot 1 PCI slot Form Factor Micro-ATX (22.6cm X 17.3cm) Feature on Focus All Solid Cap design M-Flash included Directx 11 Dual Graphic Mounting 6 mounting holes ...

Processor Support Supports AMD Fusion CPU (FM2 Socket) Chipset AMD A85X chipset Memory Support DDR3 1066/1333/1600/1866 SDRAM (32GB Max) Supports dual channel mode LAN Supports LAN 10/100/1000 Fast Ethernet by Realtek RTL8111E Audio Chip integrated by Realtek ALC892 Flexible 8-channel audio with jack sensing Compliant with Azalia 1.0 Spec SATA 8 SATA 6 Gb/s ports by AMD A85X USB (Universal Serial Bus) 3.0 4 USB (Universal Serial Bus) 3.0 ports by AMD A85X (rear x 2, front x 2) Slots 2 PCI Express x 16 slots 3 PCI Express x 1 slots 2 PCI slots Back panel 1 PS/2 mouse or keyboard port 1 SPDIF port 4 USB (Universal Serial Bus) 2.0 ports 2 USB (Universal Serial Bus) 3.0 ports 1 HDMI port 1 Displayport 1 VGA port 1 DVI-I port 1 LAN port 6 flexible audio ports On-Board Connectors 3 USB (Universal Serial Bus) 2.0 connectors 1 USB (Universal Serial Bus) 3.0 connector 1 Front Panel Audio connector 1 Serial connector 1 TPM Module connector 1 Chassis Intrusion connector 8 SATA ports Form Factor ATX (30.5 cm X 24.5 cm) Feature on Focus OC GENIE II M-Flash Click BIOS II Dual Graphic SATA 6 Gb/s Super Charger THX USB (Universal Serial Bus) 3.0 USB (Universal Serial Bus) Safeguard V-Check points 2 way crossfire Support AMD Memory Profile Easy Button Mounting 9 mounting holes ...

AMD A85X chipset • OC Genie II: Auto OC to boost performance in 1 sec • Click BIOS II: Easy-to-use UEFI BIOS interface • Super Charger: fast charge iPad/iPhone/smartphone • Support USB (Universal Serial Bus) 3.0 & SATA 6 Gb/s Specifications CPU • AMD A10/A8/A6/A4-series processors for the FM2 package Please refer to CPU Support for compatible CPU; the above description is for reference only. Chipset • AMD A85X Chipset Main Memory • Supports two unbuffered DIMM of 1.5 Volt DDR3 1066/1333/1600/1866/2133* (OC) DRAM, 32GB Max • Supports Dual-Channel mode * The maximum 32 GB of system memory can be reached while using 16 GB (or above) memory modules. We will update the memory test report on the website when the new memory modules are available on the market. * Due to the limitation of 32-bit Windows operating system, when more than 4 GB memory installed, the actual size can be used will be less than that. Slots • 1 PCI Express gen 2 x 16 slot • 2 PCIE 2.0 x 1 slots • 1 PCI slot On-Board SATA • 6x SATA 6 Gb/s ports by AMD A85X
- Supports storage & data transfer at up to 6 Gb/s
- SATA1~6 ports support RAID 0/1/5/10/JBOD modes by AMD A85X Audio • Chipset integrated by Realtek ALC887
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec LAN • Realtek PCI-E Gb LAN controller RTL8111E
- Supports 10 Mb/s, 100 Mb/s & 1000 Mb/s
- Compliance with PCI-Express Bus

Specification v 1.0a USB (Universal Serial Bus) 3.0 • 2 USB (Universal Serial Bus) 3.0 rear ports by AMD A85X • 1 USB (Universal Serial Bus) 3.0 onboard connector by AMD A85X Internal I/O Connectors
- 1 x ATX 24-pin power connector
- 1 x ATX 4-pin 12V CPU power connector
- CPU x 1 / System x 2 FAN connectors
- 1 x Front panel audio connector
- 1 x Front panel connector
- 2 x USB (Universal Serial Bus) 2.0 connectors
- 1 x USB (Universal Serial Bus) 3.0 connector
- 1 x Serial port connector
- 1 x TPM Module connector
- 1 x Chassis Intrusion connector
- 1 x Parallel connector Back Panel I/O Ports
- 1x PS/2 keyboard/ mouse port
- 6x USB (Universal Serial Bus) 2.0 ports
- 2x USB (Universal Serial Bus) 3.0 ports
- 1x LAN port
- 1x Graphics card port*
- 1x DVI-D port* supporting Dual-link DVI
- 1x HDMI port*
- 6x audio ports * This platform supports dual-display function (HDMI+VGA, HDMI+DVI, VGA+DVI) & triple-display function (HDMI+VGA+DVI). • The graphic output can only work with CPUs with GPUs core inside. Dimension • Micro-ATX (24.4 cm x 22.8 cm) Mounting • 6 mounting holes


























...
