Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra-compact PC with a stylish design based high polish surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience, sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC / multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. The BRIX is an ultra-compact, versatile DIY PC kit that redefines the desktop PC in terms of miniaturization with a form factor that is small enough (56mm x 107mm x 114mm) to sit in the palm of your h&. Intel Celeron J1900 Based on the Silvermot micro-architecture, utilizing the 22nm process technology. The So Cs feature significant improvements in computational power, energy efficiency, enhanced graphical & media performance making the BRIX ideal for thin clients, retail transactional clients, & digital signage. Advanced Features For Power Users The Brix is engineered to take full advantage of what the hardware & its UEFI BIOS are capable of. & therefore, it’s designed to deliver the most intuitive & integrated operating systems in the world. Trouble-Free Setup The BRIX is packed with wall mount adapter whether undergo rigorous testing for safety & reliability. The BRIX also bundled with a VESA bracket, it can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This offers a simple & elegant way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. Processor Intel Celeron J1900 up to 2.42 G Hz Memory 4GB DDR3L 1 x SO-DIMM Hard Drive 120GB SSD Optical Drive None Software No Operating System Display Not Included Graphics Intel HD Audio Realtek ALC283 Networking Gigabit LAN (Realtek RTL8111G) Power Supply Input: AC 100-240V Output: DC 12V 2.5A

Dimensions Width 56.1mm Depth 107.6mm Height 114.4mm Interfaces 1 x USB (Universal Serial Bus) 3.0 2 x USB (Universal Serial Bus) 2.0 1 x HDMI 1 x VGA D-Sub 1 x RJ45 1 x Audio-out / Mic-in 1 x DC-in 1 x Kensington lock slot Expansion slots 1 x Half-size mini-PCIe slot occupied by the Wi Fi+BT card Warranty/ Miscellaneous 1 Year Manufacturer Warranty VESA 75 x 75 & 100 x 100 mm

...

Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra-compact PC with a stylish design based high polish surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience, sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC / multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. The BRIX is an ultra-compact, versatile DIY PC kit that redefines the desktop PC in terms of miniaturization with a form factor that is small enough (56mm x 107mm x 114mm) to sit in the palm of your h&. Intel Celeron J1900 Based on the Silvermot micro-architecture, utilizing the 22nm process technology. The So Cs feature significant improvements in computational power, energy efficiency, enhanced graphical & media performance making the BRIX ideal for thin clients, retail transactional clients, & digital signage. Advanced Features For Power Users The Brix is engineered to take full advantage of what the hardware & its UEFI BIOS are capable of. & therefore, it’s designed to deliver the most intuitive & integrated operating systems in the world. Trouble-Free Setup The BRIX is packed with wall mount adapter whether undergo rigorous testing for safety & reliability. The BRIX also bundled with a VESA bracket, it can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This offers a simple & elegant way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. Processor Intel Celeron J1900 2.42 G Hz Memory 4GB DDR3L 1333 M Hz 1 x SO-DIMM Hard Drive 240GB SSD Optical Drive None Software No Operating System Display Not Included Graphics Intel HD Audio Realtek ALC283 Networking Gigabit LAN (Realtek RTL8111G) Power Supply Input: AC 100-240V Output: DC 12V 2.5A

Dimensions Width 56.1mm Depth 107.6mm Height 114.4mm Interfaces 1 x USB (Universal Serial Bus) 3.0 2 x USB (Universal Serial Bus) 2.0 1 x HDMI 1 x VGA D-Sub 1 x RJ45 1 x Audio-out / Mic-in 1 x DC-in 1 x Kensington lock slot Expansion slots 1 x Half-size mini-PCIe slot occupied by the Wi Fi+BT card Warranty/ Miscellaneous 1 Year Manufacturer Warranty VESA 75 x 75 & 100 x 100 mm

...

Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra-compact PC with a stylish design based high polish surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience, sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC / multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. The BRIX is an ultra-compact, versatile DIY PC kit that redefines the desktop PC in terms of miniaturization with a form factor that is small enough (56mm x 107mm x 114mm) to sit in the palm of your h&. Intel Celeron N2807 Based on the Silvermot micro-architecture, utilizing the 22nm process technology. The So Cs feature significant improvements in computational power, energy efficiency, enhanced graphical & media performance making the BRIX ideal for thin clients, retail transactional clients, & digital signage. Advanced Features For Power Users The Brix is engineered to take full advantage of what the hardware & its UEFI BIOS are capable of. & therefore, it’s designed to deliver the most intuitive & integrated operating systems in the world. Trouble-Free Setup The BRIX is packed with wall mount adapter whether undergo rigorous testing for safety & reliability. The BRIX also bundled with a VESA bracket, it can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This offers a simple & elegant way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. Processor Intel Celeron N2807 2.17 G Hz Memory 4GB DDR3L 1 x SO-DIMM Hard Drive 120GB SSD Optical Drive None Software No Operating System Display Not Included Graphics Intel HD Audio Realtek ALC283 Networking Gigabit LAN (Realtek RTL8111G) Power Supply Input: AC 100-240V Output: DC 12V 2.5A

Dimensions Width 56.1mm Depth 107.6mm Height 114.4mm Interfaces 1 x USB (Universal Serial Bus) 3.0 2 x USB (Universal Serial Bus) 2.0 1 x HDMI 1 x VGA D-Sub 1 x RJ45 1 x Audio-out / Mic-in 1 x DC-in 1 x Kensington lock slot Expansion slots 1 x Half-size mini-PCIe slot occupied by the Wi Fi+BT card Warranty/ Miscellaneous 1 Year Manufacturer Warranty VESA 75 x 75 & 100 x 100 mm

...

Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra-compact PC with a stylish design based high polish surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience, sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC / multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. The BRIX is an ultra-compact, versatile DIY PC kit that redefines the desktop PC in terms of miniaturization with a form factor that is small enough (56mm x 107mm x 114mm) to sit in the palm of your h&. Intel Celeron N2807 Based on the Silvermot micro-architecture, utilizing the 22nm process technology. The So Cs feature significant improvements in computational power, energy efficiency, enhanced graphical & media performance making the BRIX ideal for thin clients, retail transactional clients, & digital signage. Advanced Features For Power Users The Brix is engineered to take full advantage of what the hardware & its UEFI BIOS are capable of. & therefore, it’s designed to deliver the most intuitive & integrated operating systems in the world. Trouble-Free Setup The BRIX is packed with wall mount adapter whether undergo rigorous testing for safety & reliability. The BRIX also bundled with a VESA bracket, it can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This offers a simple & elegant way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit. Processor Intel Celeron N2807 2.17 G Hz Memory 4GB DDR3L 1333 M Hz 1 x SO-DIMM Hard Drive 250GB SSD Optical Drive None Software No Operating System Display Not Included Graphics Intel HD Audio Realtek ALC283 Networking Gigabit LAN (Realtek RTL8111G) Power Supply Input: AC 100-240V Output: DC 12V 2.5A

Dimensions Width 56.1mm Depth 107.6mm Height 114.4mm Interfaces 1 x USB (Universal Serial Bus) 3.0 2 x USB (Universal Serial Bus) 2.0 1 x HDMI 1 x VGA D-Sub 1 x RJ45 1 x Audio-out / Mic-in 1 x DC-in 1 x Kensington lock slot Expansion slots 1 x Half-size mini-PCIe slot occupied by the Wi Fi+BT card Warranty/ Miscellaneous 1 Year Manufacturer Warranty VESA 75 x 75 & 100 x 100 mm

...

Features Features 14nm Intel N3350 to deliver to the most intuitive & integrated operating systems in the world Supports 2.5” thickness 7.0/ 9.5mm Hard Drives (1 x 6 Gbps SATA3) Ultra compact PC design – 0.69L (56.1 x 107.6 x 114.4mm) 1 x SO-DIMM DDR3L 1.35V Slots (1333/ 1600/ 1866 MHz) Intel IEEE 802.11 ac, Dual Band Wi-Fi & Bluetooth 4.0 NGFF M.2 card Supports dual displays via a VGA & a HDMI port Gigabit LAN Audio jack (Headphone & Microphone) VESA mounting bracket (75 x 75mm + 100 x 100mm) Support Fanless Design Additional Items Required with this product (not included): * Storage (Example: Hard Drive) * Memory * Operating System Overview Redefining the Desktop PC Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a stylish design based on a brushed aluminum surface chassis. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience, sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC / multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. The BRIX is an ultra compact, versatile DIY PC kit that redefines the desktop PC in terms of miniaturization with a form factor that is small enough (56mm x 107mm x 114mm) to sit in the palm of your h&. Intel Celeron Processor The new generation of Intel Celeron Processors leverage the 14nm process technology. The new processors improve upon power consumption along with enhancements in performance for graphics & computations. For the BRIX the new Celeron processors deliver a 30% increase in performance & at least 35% better 3D graphics performance gen-over-gen. The system-on-chip (So C) design provides an even smaller footprint than its desktop counterparts, making BRIX the ideal solution for thin clients, POS solutions, & digital signage. Dual Display With HDMI & VGA output, the BRIX can power two displays simultaneously, making it a perfect choice as a high productivity PC in both working environment & home entertainment. VESA Support The BRIX is packed with wall mount adapter whether undergo rigorous testing for safety & reliability. The BRIX also bundled with a VESA bracket, it can easily be mounted behind a monitor or HDTV making it discreetly hidden from view. This offers a simple & elegant way to turn any VESA-compliant display or TV into a full-featured PC or digital signage unit.

Specification Dimension 56.1 mm x 107.6 mm x 114.4 mm (2.21" x 4.24" x 4.5") Motherboard Size 100 x 105 mm CPU Intel Celeron Processor N3350, 2.4 G Hz, 2 core (TDP 6W) Memory 1 x SO-DIMM DDR3L slots (DDR3 1.35V) 1333/ 1600/ 1866 MHz Max. 8GB LAN Gigabit LAN (Realtek RTL8111HS) Wifi Card Intel Dual Band Wireless-AC 3168 Graphics Intel HD Graphics 500 Audio Realtek ALC891 VGA Resolution (Max.) 1920 x 1200 @60 Hz HDMI Resolution (Max.) 3840 x 2160 @30 Hz Expansion Slots 1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the Wi Fi+BT card Rear I/O 1 x HDMI (1.4) 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Side I/O 1 x VGA 1 x Headphone & Microphone jack 2 x USB (Universal Serial Bus) 3.0 Storage Supports 2.5” thickness 7.0/9.5mm Hard Drives (1 x 6 Gbps SATA3) Power Supply Input: AC 100-240V Output: DC 19V 2.1A VESA Bracket included Supports 75 x 75 & 100 x 100 mm Support OS WIN10 64bit Environment System Environment Operating Temperature: 0°C to +35°C System Storage Temperature: -20°C to +60°C

...

Features Additional Items Required with this product (not included): * Storage (Example: SSD) * Memory * Operating System Features Intel Core™ Quad core i 5-8250U Processor Ultra compact PC design at only 0.46L (34.4 x 112.6 x 119.4mm) 1 x M.2 SSD (2280) slot 2 x SO-DIMM DDR4 slots Intel IEEE 802.11ac, Dual Band Wi-Fi & Bluetooth 4.2 NGFF M.2 card HDMI plus Mini Display Port Outputs (Supports dual displays) 2 x USB (Universal Serial Bus) 3.1 (1 x USB (Universal Serial Bus) Type-C™) 2 x USB (Universal Serial Bus) 3.0 Intel Gigabit LAN Dual Array Microphone Headphone Jack VESA Mounting Bracket (75 x 75mm + 100 x 100mm) Overview The Perfect Fit for Any Space Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a brushed aluminum surface chassis design. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Intel 8th Generation Core™ Processors GIGABYTE BRIX supports 8th Generation Intel Quad-core processors which feature power-efficient 15W Intel Core i 5 & i 7 models. From a simple internet access point to a high end multimedia station, the GIGABYTE BRIX provides a broad range of usage scenarios & the ultimate space flexibility. Energy efficient Quad-core delivers up to 40% faster performance compared to 7th gen processors! Intel Turbo Boost Technology GIGABYTE BRIX offers more computing power than ever with Intels new 14nm processors, which comes with Intel Turbo Boost Technology 2.0. It accelerates processor & graphics performance for peak loads, automatically allowing processor cores to run faster than the rated operating frequency if theyre operating below power, current, & temperature

Specification limits, gives users an extra burst of performance when needed. In addition, the integrated memory controller provides a direct connection between the DDR4 2400 M Hz memory & the processor for fast data processing. Connecting the Future
- USB (Universal Serial Bus) Type-C™: The Worlds Next Universal Connector Reversible USB (Universal Serial Bus) Type-C™ with USB (Universal Serial Bus) 3.1 The USB (Universal Serial Bus) Type-C™ is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.1 support for 10 Gb/s transfer speed. Super Speed 4K HD Entertainment Supporting the Newest Standards in Multimedia GIGABYTE ensures users won’t be limited by the standards or connections on the BRIX, by including HDMI 2.0 & support for HDCP 2.2* users can rest assured that their device will be able to display content to its full potential. The BRIX supports native resolutions of 4K at 60 Hz, presenting unrivaled visual clarity & stunning realism to owners of UHD displays. * HDMI port support HDMI 2.0 & HDCP 2.2. Multi-display productivity with HDMI 2.0 & Display Port BRIX supports up to three independent displays through HDMI 2.0 & a Display Port ++ without the need for an additional graphics card. Support for three display is only possible with daisy-chain connections through Display Port.

Specification Dimension 34.4 mm x 112.6 mm x 119.4 mm (1.35" x 4.43" x 4.7") Motherboard Size 105 x 110 mm CPU Intel Core™ Quad Core i 5-8250U 3.4 G Hz Memory 2 x SO-DIMM DDR4 slots 2400 M Hz Max. 64GB LAN Gigabit LAN (Intel i 219V) Wifi Card Intel Dual Band Wireless-AC 3168 Graphics Intel UHD Graphics 620 Audio Realtek ALC255 HDMI Resolution (Max.) HDMI2.0a ws HDCP 2.2 4096 x 2304 @ 60 Hz Mini DP Resolution (Max.) DP1.2a ws HDCP 2.2 4096 x 2304 @ 60 Hz Expansion Slots 1 x M.2 slot (2280_storage) PCIe X4 /SATA 1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the Wi Fi+BT card Front I/O 1 x USB (Universal Serial Bus) 3.1 type C 1 x USB3.1 1 x head phone jack with MIC 1 x Dual array Microphone Rear I/O 1 x HDMI (2.0a) 1 x Mini Display Port (1.2) 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot USB3.1 Asmedia 3142 Power Supply Input: AC 100-240V Output: DC 19V 3.42A VESA Bracket included Supports 75 x 75 & 100 x 100 mm Support OS WIN10 64bit Environment System Environment Operating Temperature: 0°C to +35°C System Storage Temperature: -20°C to +60°C




...

Features Additional Items Required with this product (not included): * Storage (Example: Hard Drive) * Memory * Operating System Features Intel Core™ Quad core i 5-8250U Ultra compact PC design at only 0.63L (46.8 x 112.6 x 119.4mm) Supports 2.5" HDD/SSD, 7.0/9.5 mm thick (1 x 6 Gbps SATA 3) 1 x M.2 SSD (2280) slot 2 x SO-DIMM DDR4 slots Intel IEEE 802.11ac, Dual Band Wi-Fi & Bluetooth 4.2 NGFF M.2 card HDMI plus Mini Display Port Outputs (Supports dual displays) 2 x USB (Universal Serial Bus) 3.1 (1 x USB (Universal Serial Bus) Type-C™) 2 x USB (Universal Serial Bus) 3.0 Intel Gigabit LAN Dual Array Microphone Headphone Jack VESA Mounting Bracket (75 x 75mm + 100 x 100mm) Overview The Perfect Fit for Any Space Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a brushed aluminum surface chassis design. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Intel 8th Generation Core™ Processors GIGABYTE BRIX supports 8th Generation Intel Quad-core processors which feature power-efficient 15W Intel Core i 5 & i 7 models. From a simple internet access point to a high end multimedia station, the GIGABYTE BRIX provides a broad range of usage scenarios & the ultimate space flexibility. Energy efficient Quad-core delivers up to 40% faster performance compared to 7th gen processors! Intel Turbo Boost Technology GIGABYTE BRIX offers more computing power than ever with Intels new 14nm processors, which comes with Intel Turbo Boost Technology 2.0. It accelerates processor & graphics performance for peak loads, automatically allowing processor cores to run faster than the rated operating frequency if theyre operating below power, current, & temperature

Specification limits, gives users an extra burst of performance when needed. In addition, the integrated memory controller provides a direct connection between the DDR4 2400 M Hz memory & the processor for fast data processing. Connecting the Future
- USB (Universal Serial Bus) Type-C™: The Worlds Next Universal Connector Reversible USB (Universal Serial Bus) Type-C™ with USB (Universal Serial Bus) 3.1 The USB (Universal Serial Bus) Type-C™ is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.1 support for 10 Gb/s transfer speed. Super Speed 4K HD Entertainment Supporting the Newest Standards in Multimedia GIGABYTE ensures users won’t be limited by the standards or connections on the BRIX, by including HDMI 2.0 & support for HDCP 2.2* users can rest assured that their device will be able to display content to its full potential. The BRIX supports native resolutions of 4K at 60 Hz, presenting unrivaled visual clarity & stunning realism to owners of UHD displays. * HDMI port support HDMI 2.0 & HDCP 2.2. Multi-display productivity with HDMI 2.0 & Display Port BRIX supports up to three independent displays through HDMI 2.0 & a Display Port ++ without the need for an additional graphics card. Support for three display is only possible with daisy-chain connections through Display Port.

Specification Dimension 46.8 mm x 112.6 mm x 119.4 mm (1.84" x 4.43" x 4.7") Motherboard Size 105 x 110 mm CPU Intel Core™ Quad Core i 5-8250U 3.4 G Hz Memory 2 x SO-DIMM DDR4 slots 2400 M Hz Max. 64GB LAN Gigabit LAN (Intel i 219V) Wifi Card Intel Dual Band Wireless-AC 3168 Graphics Intel UHD Graphics 620 Audio Realtek ALC255 HDMI Resolution (Max.) HDMI2.0a ws HDCP 2.2 4096 x 2304 @ 60 Hz Mini DP Resolution (Max.) DP1.2a ws HDCP 2.2 4096 x 2304 @ 60 Hz Expansion Slots 1 x M.2 slot (2280_storage) PCIe X4 /SATA Support Optane memory 1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the Wi Fi+BT card Front I/O 1 x USB (Universal Serial Bus) 3.1 type C 1 x USB3.1 1 x head phone jack with MIC 1 x Dual array Microphone Rear I/O 1 x HDMI (2.0a) 1 x Mini Display Port (1.2) 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Storage Supports 2.5" HDD/SSD, 7.0/9.5 mm thick (1 x 6 Gbps SATA 3) USB3.1 Asmedia 3142 Power Supply Input: AC 100-240V Output: DC 19V 3.42A VESA Bracket included Supports 75 x 75 & 100 x 100 mm Support OS WIN10 64bit Environment System Environment Operating Temperature: 0°C to +35°C System Storage Temperature: -20°C to +60°C




...

Features Additional Items Required with this product (not included): * Storage (Example: SSD) * Memory * Operating System Features Intel Core™ i 7-8550U Processor Ultra compact PC design at only 0.46L (34.4 x 112.6 x 119.4mm) 1 x M.2 SSD (2280) slot 2 x SO-DIMM DDR4 slots Intel IEEE 802.11ac, Dual Band Wi-Fi & Bluetooth 4.2 NGFF M.2 card HDMI plus Mini Display Port Outputs (Supports dual displays) 2 x USB (Universal Serial Bus) 3.1 (1 x USB (Universal Serial Bus) Type-C™) 2 x USB (Universal Serial Bus) 3.0 Intel Gigabit LAN Dual Array Microphone Headphone Jack VESA Mounting Bracket (75 x 75mm + 100 x 100mm) Overview The Perfect Fit for Any Space Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a brushed aluminum surface chassis design. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Intel 8th Generation Core™ Processors GIGABYTE BRIX supports 8th Generation Intel Quad-core processors which feature power-efficient 15W Intel Core i 5 & i 7 models. From a simple internet access point to a high end multimedia station, the GIGABYTE BRIX provides a broad range of usage scenarios & the ultimate space flexibility. Energy efficient Quad-core delivers up to 40% faster performance compared to 7th gen processors! Intel Turbo Boost Technology GIGABYTE BRIX offers more computing power than ever with Intels new 14nm processors, which comes with Intel Turbo Boost Technology 2.0. It accelerates processor & graphics performance for peak loads, automatically allowing processor cores to run faster than the rated operating frequency if theyre operating below power, current, & temperature

Specification limits, gives users an extra burst of performance when needed. In addition, the integrated memory controller provides a direct connection between the DDR4 2400 M Hz memory & the processor for fast data processing. Connecting the Future
- USB (Universal Serial Bus) Type-C™: The Worlds Next Universal Connector Reversible USB (Universal Serial Bus) Type-C™ with USB (Universal Serial Bus) 3.1 The USB (Universal Serial Bus) Type-C™ is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.1 support for 10 Gb/s transfer speed.

Specification Dimension 34.4 mm x 112.6 mm x 119.4 mm (1.35" x 4.43" x 4.7") Motherboard Size 105 x 110 mm CPU Intel Core™ Quad Core i 7-8550U 4.0 G Hz / 3.7 G Hz Memory 2 x SO-DIMM DDR4 slots 2400 M Hz Max. 64GB LAN Gigabit LAN (Intel i 219V) Wifi Card Intel Dual Band Wireless-AC 3168 Graphics Intel UHD Graphics 620 Audio Realtek ALC255 HDMI Resolution (Max.) HDMI2.0a ws HDCP 2.2 4096 x 2304 @ 60 Hz Mini DP Resolution (Max.) DP1.2a ws HDCP 2.2 4096 x 2304 @ 60 Hz Expansion Slots 1 x M.2 slot (2280_storage) PCIe X4 /SATA 1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the Wi Fi+BT card Front I/O 1 x USB (Universal Serial Bus) 3.1 type C 1 x USB3.1 1 x head phone jack with MIC 1 x Dual array Microphone Rear I/O 1 x HDMI (2.0a) 1 x Mini Display Port (1.2) 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot USB3.1 Asmedia 3142 Power Supply Input: AC 100-240V Output: DC 19V 3.42A VESA Bracket included Supports 75 x 75 & 100 x 100 mm Support OS WIN10 64bit Environment System Environment Operating Temperature: 0°C to +35°C System Storage Temperature: -20°C to +60°C




...

Features Additional Items Required with this product (not included): * Storage (Example: Hard Drive) * Memory * Operating System Features Intel Core™ Quad Core i 7-8550U Ultra compact PC design at only 0.63L (46.8 x 112.6 x 119.4mm) Supports 2.5" HDD/SSD, 7.0/9.5 mm thick (1 x 6 Gbps SATA 3) 1 x M.2 SSD (2280) slot 2 x SO-DIMM DDR4 slots Intel IEEE 802.11ac, Dual Band Wi-Fi & Bluetooth 4.2 NGFF M.2 card HDMI plus Mini Display Port Outputs (Supports dual displays) 2 x USB (Universal Serial Bus) 3.1 (1 x USB (Universal Serial Bus) Type-C™) 2 x USB (Universal Serial Bus) 3.0 Intel Gigabit LAN Dual Array Microphone Headphone Jack VESA Mounting Bracket (75 x 75mm + 100 x 100mm) Overview The Perfect Fit for Any Space Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a brushed aluminum surface chassis design. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Intel 8th Generation Core™ Processors GIGABYTE BRIX supports 8th Generation Intel Quad-core processors which feature power-efficient 15W Intel Core i 5 & i 7 models. From a simple internet access point to a high end multimedia station, the GIGABYTE BRIX provides a broad range of usage scenarios & the ultimate space flexibility. Energy efficient Quad-core delivers up to 40% faster performance compared to 7th gen processors! Intel Turbo Boost Technology GIGABYTE BRIX offers more computing power than ever with Intels new 14nm processors, which comes with Intel Turbo Boost Technology 2.0. It accelerates processor & graphics performance for peak loads, automatically allowing processor cores to run faster than the rated operating frequency if theyre operating below power, current, & temperature

Specification limits, gives users an extra burst of performance when needed. In addition, the integrated memory controller provides a direct connection between the DDR4 2400 M Hz memory & the processor for fast data processing. Connecting the Future
- USB (Universal Serial Bus) Type-C™: The Worlds Next Universal Connector Reversible USB (Universal Serial Bus) Type-C™ with USB (Universal Serial Bus) 3.1 The USB (Universal Serial Bus) Type-C™ is a new reversible connector that is loaded with useful features such as USB (Universal Serial Bus) 3.1 support for 10 Gb/s transfer speed.

Specification Dimension 46.8 mm x 112.6 mm x 119.4 mm (1.84" x 4.43" x 4.7") Motherboard Size 105 x 110 mm CPU Intel Core™ Quad Core i 7-8550U 4.0 G Hz / 3.7 G Hz Memory 2 x SO-DIMM DDR4 slots 2400 M Hz Max. 64GB LAN Gigabit LAN (Intel i 219V) Wifi Card Intel Dual Band Wireless-AC 3168 Graphics Intel UHD Graphics 620 Audio Realtek ALC255 HDMI Resolution (Max.) HDMI2.0a ws HDCP 2.2 4096 x 2304 @ 60 Hz Mini DP Resolution (Max.) DP1.2a ws HDCP 2.2 4096 x 2304 @ 60 Hz Expansion Slots 1 x M.2 slot (2280_storage) PCIe X4 /SATA Support Optane memory 1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the Wi Fi+BT card Front I/O 1 x USB (Universal Serial Bus) 3.1 type C 1 x USB3.1 1 x head phone jack with MIC 1 x Dual array Microphone Rear I/O 1 x HDMI (2.0a) 1 x Mini Display Port (1.2) 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Storage Supports 2.5" HDD/SSD, 7.0/9.5 mm thick (1 x 6 Gbps SATA 3) USB3.1 Asmedia 3142 Power Supply Input: AC 100-240V Output: DC 19V 3.42A VESA Bracket included Supports 75 x 75 & 100 x 100 mm Support OS WIN10 64bit Environment System Environment Operating Temperature: 0°C to +35°C System Storage Temperature: -20°C to +60°C




...

The Perfect Fit for Any Space Challenging the essence of how we define a desktop PC, GIGABYTE engineers have developed an ultra compact PC with a brushed aluminum surface chassis design. Ideal for a broad range of computing applications at home or in the office, the BRIX expounds sheer simplicity & convenience. With a broad choice of processors covering the entire performance spectrum, the BRIX sets a new standard for desktop miniaturization that makes it perfect as a discreet HTPC/multimedia hub, an ultra-low power PC for the family, an office PC or as a digital signage unit. Features Latest Intel 6th generation Core Processors Ultra compact PC design at only 0.6L (46.8 x 112.6 x 119.4mm) Supports 2.5” HDD/SSD, 7.0/9.5 mm thick (1 x 6 Gbps SATA 3) 1 x M.2 SSD (2280) slot 2 x SO-DIMM DDR4 slot (2133 MHz) Intel IEEE 802.11 ac, Dual Band Wi-Fi & Bluetooth 4.2 NGFF M.2 card Intel HD Graphics 510 2 x USB3.1 (1* USB (Universal Serial Bus) Type-C™) 2 x USB (Universal Serial Bus) 3.0 HDMI plus Mini Display Port Outputs (Supports dual displays) Intel Gigabit lan Headphone/ Microphone Jack VESA mounting Bracket (75 x 75mm + 100 x 100mm) Dimension 46.8 mm x 112.6 mm x 119.4 mm (1.84" x 4.43" x 4.7") Motherboard Size 105 x 110 mm CPU Intel Celeron 3955U 2.0 G Hz Memory 2 x SO-DIMM DDR4 slots 2133 M Hz Max. 32GB LAN Gigabit LAN (Intel i 219LM) Audio Realtek ALC255 Graphics Intel HD Graphics 510 HDMI Resolution (Max.) 3840 x 2160 @ 30 Hz Mini DP Resolution (Max.) 3840 x 2160 @ 60 Hz Expansion Slots 1 x M.2 slot (2280_storage) SATA 1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the Wi Fi+BT card Front I/O 1 x USB (Universal Serial Bus) 3.1 type C 1 x USB3.1 1 x head phone jack with MIC Rear I/O 1 x HDMI (1.4a) 1 x Mini Display Port (1.2) 2 x USB (Universal Serial Bus) 3.0 1 x RJ45 1 x DC-In 1 x Kensington lock slot Power Supply Input: AC 100-240V Output: DC 19V 3.42A VESA Bracket included Supports 75 x 75 & 100 x 100 mm Wifi Card Intel Dual Band Wireless-AC 3165 USB3.1 Asmedia Storage Supports 2.5” HDD/SSD, 7.0/9.5 mm thick (1 x 6 Gbps SATA 3) Support OS WIN7 32/64bit WIN8.1 64bit WIN10 64bit Environment System Environment Operating Temperature: 0°C to +35°C System Storage Temperature: -20°C to +60°C ...
