Akasa AK-CC029-5 is a thermally advanced active cooling solution for Intel LGA 775 processors in 1U server chassis. The heatsink is made from pure copper with skived fins technology ensuring rapid heat transfer & efficient dissipation. The long life two-ball bearing fan draws the cool air though the fins & extracts hot air to one side to support chassis airflow. Pre-applied spring-loaded screws & motherboard backplate guarantee safe retention. Socket type
- Intel LGA 775 Heatsink dimension
- 83 x 87 x 14mm Heatsink material
- Pure copper Fan dimensionv
- 75 x 75 x 15mm Fan speed
- 5000 R.P.M. Fan air pressure
- 17.07mm H2O Fan airflow
- 10.75CFM Fan life expectancy
- 50000/hrs Bearing type
- Dual ball bearing Voltage rating
- 12V Fan connector
- 3-pin (with RPM reading) Noise level
- 41.65 d B (A) Product code
- AK-CC029-5












...

Features
- Eight high capacity heatpipes for rapid heat transfer Dual Viper fans Award winning S-FLOW fans provides 30% more airflow
...

Features
- High performance low profile four direct contact heatpipes cooler with only 59mm tall Suitable for HTPC or slim system
...

AK-CC7108EP01 is a new design OEM CPU cooler combining low noise, efficient cooling with great value. High engineered omni ...

Features
- Ultra compact & low noise cooler for Intel Core 2 Duo & Core i 3 CPU’s. The low profile design with embedded fan
...

The Ultra Quiet AK-CCE-7101CP uses a high engineering omni directional heat sink providing efficient CPU & motherboard zone cooling. The fan uses Intel approved power management (PWM) where speed is regulated automatically by CPU usage. Under normal conditions the CPU fan speed is low ensuring low noise computing. Intel approved pushpins ensure easy installation reliable retention & maximum compatibility on both LGA775 & LGA1156 platforms without any mounting adjustment pushpins will automatically slide into correct position. AK-CCE-7101CP is designed to work with CPUs up to 95 W. but greater cooling efficiency can be attained with efficient case airflow. Pre-applied high performance thermal compound ensures clean & easy installation. Specification: Type: Heat sink & Fan Interface: 4 Pin with PWM Control Socket (s): Intel LGA775 LGA1156. Warranty: 1 Year. ...

High engineered aluminium heatsink for cost effective performance Bi-ped fins maximise heat dissipation Ultra Quiet Enter bearing PWM fan Push-pin mounting provide easy & reliable retention Intel LGA775 & LGA1156 compatible Performance thermal interface pre-applied The Ultra Quiet AK-CCE-7104EP uses a high engineering omni directional heatsink providing efficient CPU & motherboard zone cooling. The Enter bearing fan uses Intel approved power management (PWM) where speed is regulated automatically by CPU usage. Under normal conditions the CPU fan speed is low ensuring low noise computing. Intel approved push pins provide reliable retention on LGA775 & LGA1156 platforms. High performance thermal interface is pre-applied.

Specification Socket type Intel LGA775 & LGA1156 Cooler

Dimensions 95 x 95 x 63 mm Heatsink material Aluminium fins & core Weight 362g Installation Push-pins Fan dimension ˆ…92 x 25 mm Fan speed 600
- 3000 RPM (PWM controlled) Max airflow 55.4 CFM (93.9 m&sup 3;/h) Max air pressure 4.30 mm H2O Noise level 11.7
- 28.8 d B (A) Current rating 0.26A Voltage rating 12V DC Bearing type Enter Bearing Fan life expectancy 40, 000 hours Fan connector 4pin PWM





...

Conveniently positioned at the front of your PC; this six slot media card reader accepts most available cards including SDXC.



...

TIM Clean fluid removes all thermal interface residues including silver based & prepares the chipset surface for new thermal compound. A safe citrus base solvent which leaves no residue. Ideal for cleaning CPU, GPU, Northbridge, RAM etc). High performance AK-455 thermal compound has an advanced formula designed to maximise heat transfer from chipset/CPU to the heatsink enabling you to get more from your existing cooler. The high viscosity formula efficiently fills invisible surface imperfections to improve contact & thermal conductivity. 5g thermal compound syringe enough for 10-15 CPU cooler installations & 125ml bottle of TIM Clean will last for even more CPU surface preparations. TIM kit is a must have for every PC enthusiasts. ...

Akasa All IN ONE fan controller, memory card reader, I/O port provider The All In One 2 is a development of the popular akasa control panel. The multi functional panel sits in a 5.25 PC bay & offers three major function types including: Five slot internal memory card reader Conveniently positioned at the front of your PC makes using flash cards easy. Compatible with all popular memory cards, accepts high capacity cards & absolutely no card adapters are required. Easy access multi connections Featuring e SATA, IEEE1394, HD Audio & 3x USB2.0 ports neatly covered behind a push open mesh cover ready to use when needed. Smart fan & temperature control Constantly monitors temperature in three system zones & enables automatic (temperature driven) or manual control of three fans. The colour LCD screen displays selected fan speed & thermal probe temperature. The built in adjustable alarm function warns you if any components exceed pre-set temperatures or if a fan is faulty. The multi featured All In One 2 panel makes the perfect solution for taking control of your PC system & expanding its multimedia functions. It is easy to use & adds class to any system case. The All In One 2 is available in silver or black. ¢ Colour LCD display ¢ Monitoring of three system zones temperature with alarm ¢ Controls three fans automatically or manually with alarm function ¢ SDXC supported ¢ Five port memory card reader for all popular flash cards ¢ Front mounted I/O ports provide convenient access ¢ Neat mesh hinged front cover gives attractive finish Application
- Multi function panel for 5.25 PC bay Number of channels: 3 fans 3 temperatures Fan voltage control: 6V
- 12V (manual) 7V
- 12V (automatic) Max load
- 0.5A (per channel) Screen size
- 31 x 17mm Fan speed display
- 0-9990 RPM Temperature display
- 0-90.0°C I/O ports
- 7 USB (Universal Serial Bus) ports
- 3 IEEE1394 port
- 1 e SATA ports
- 1 HD Audio
- 1x in/out (AC97 compatible) Memory card slots
- 5 Supported memory cards (CF) Compact Flash & (MD) Micro Drive (MS) Memory Stick / Pro / Duo (SD) Secure Digital / SDHC / SDXC & MMC (e X) Extreme Digital (micro SD) micro SDHC, micro SD Card reader interface
- USB (Universal Serial Bus) 2.0 Supported OS
- Windows 2000 / XP / Vista / 7 Input power
- 5V / 12V DC Product code: AK-ALL02-SL (silver)















...
