Datacenter, cloud & high-performance computing environments not only require large amounts of storage capacity, they also must provide the data protection & performance today's applications & end users dem&. The Mega RAID SAS 9361-8i 12 Gb/s SAS & SATA RAID controller card addresses these needs by delivering proven performance & RAID data protection for a range of server storage applications. Connect up to 128 SATA or SAS drives with eight internal 12 Gb/s SATA & SAS ports Fit into rack-mounted servers with low-profile form factor & side-mounted SAS connectors Support critical, high-bandwidth applications with PCIe 3.0 connectivity Balance protection & performance for critical applications with RAID levels 0, 1, 5, 6, 10, 50, & 60 Add more protection & peace of mind with optional Cache Vault flash cache protection. ...

The explosive growth of data in cloud & enterprise datacenters is driving the need for a higher performance storage interface to speed the ability of critical applications to access data. LSI first-to-market 12 Gb/s SAS solutions are designed to deliver the performance & data protection capabilities required for the most demanding next-generation server & storage platforms. High performance with 12 Gb/s data transfer rates Four internal 12 Gb/s SATA & SAS ports One mini SAS SFF8643 internal connector (horizontal mount) LSISA3108: 1.2 GHz Power PC 476 dual core 12 Gb/s ROC PCI Express 3.0 host interface 1 GB DDRIII cache memory Support for Cache Vault flash cache protection 12 Gb/s solutions accelerate performance for next-generation datacenters, web & cloud Delivers enterprise-class data protection & security Preserves investment in 6 Gb/s & 3 Gb/s drives Connect up to 128 3 Gb/s, 6 Gb/s, or 12 Gb/s SATA & SAS devices ...

Hyper-scale, datacenter, and high-performance computing environments not only require large amounts of storage capacity, they also must provide the data protection & performance today's applications & end users dem&. The Mega RAID SAS 9380-8e 12 Gbps SAS & SATA RAID controller card helps address these needs by delivering proven performance & RAID data protection for a range of server storage applications. Connects up to 240 SATA or SAS drives with eight external 12 Gbps SAS ports Provides external JBOD expansion & RAID data protection to address a wide range of storage performance & capacity requirements Supports critical, high-bandwidth applications with PCIe 3.0 connectivity Balances protection & performance for critical applications with RAID levels 0, 1, 5, 6, 10, 50, & 60 ...

Designed for large-scale, data-intensive applications, the SAS 9305-16i 12 Gb/s SAS HBA is ideal for increased connectivity & maximum performance for high-end servers & appliances with internal storage. With performance of over 1.5 million input-output operations per second (IOPS), this adapter delivers the performance & scalability needed by critical applications. Connects up to 1024 SAS & SATA devices with 16 internal 12 Gb/s SAS ports Provides maximum connectivity & performance for high-end servers & applications Support critical applications with the bandwidth of PCIe 3.0 connectivity Achieve more than 1.5 million IOPS for performance-sensitive applications ...

Datacenter, cloud & high-performance computing environments not only require large amounts of storage capacity, they also must provide the data protection & performance today's applications & end users dem&. The Mega RAID SAS 9361-16i 12 Gb/s SAS & SATA RAID controller card addresses these needs by delivering proven performance & RAID data protection for a range of server storage applications. Connect up to 16 SATA or SAS drives via direct connection inside the box or up to 240 drives leveraging SAS expander technology Fit into rack-mounted servers with low-profile form factor & side-mounted SAS connectors Support critical, high-bandwidth applications with PCIe 3.0 connectivity Balance protection & performance for critical applications with RAID levels 0, 1, 5, 6, 10, 50, & 60 ...

LSI Mega RAID SATA + SAS entry controller cards allow small to medium business (SMB) owners & gaming enthusiasts to enjoy the RAID technology at affordable prices with low power consumption. This product line delivers trusted Mega RAID reliability with minimal maintenance effort. Mega RAID entry controller cards offer users a straight-forward solution that

Includes:: essential RAID levels & uncomplicated configuration options. High performance with 12 Gb/s data transfer rates PCI Express 3.0 host interface drives superior system performance Delivers robust, yet simple RAID functionality Flexible SATA+SAS array architecture optimizes cost Complete kit package

Includes:: necessary cables & brackets

Includes:: JBOD mode support applications Internal storage configurations 1U/2U rack servers File, web, database & email servers High-performance workstations Eight internal 12 Gb/s SATA+SAS ports x 8 PCI Express 3.0 host interface Two x 4 SFF-8643 mini-SAS HD internal connectors LSISAS3008 Power PC 476 controller & 1.2 GHz RAID 0, 1, 5, 10, 50 & JBOD mode Low-profile form factor Supports up to 64 devices in JBOD mode Up to 32 physical devices in RAID mode Powerful device monitoring & maintenance capabilities





...

Designed for large-scale external storage enclosures, the 9400-8e Tri-Mode Storage Adapter is ideal for increased connectivity & maximum performance for data center flexibility. With increased bandwidth & IOPS performance compared to previous generations, the 9400-8e adapter delivers the performance & scalability needed by critical applications. Connects up to 1024 SAS/SATA devices Provides maximum connectivity & performance for high-end servers & applications Support critical applications with the bandwidth of PCIe 3.1 connectivity Ideal for connecting large-scale external storage enclosures ...

RAID controller cards temporarily cache data from the host system until it is successfully written to the storage media. While cached, data can be lost if system power fails, jeopardizing the data’s permanent integrity. RAID caching is a cost-effective way to improve I/O performance by writing data to a controller’s cache before it is written to disk. However, in the event of a power or server failure, the writes in cache may be lost. Cache Vault flash cache protection modules & battery backup units (BBUs) protect the integrity of cached data by storing cached data in non-volatile flash cache storage or by providing battery power to the controller. Cache Vault technology prevents data loss by powering critical components of the card long enough to automatically transfer the cached data to NAND flash. Once power returns, the data is restored to the cache & normal operation resumes. By using a super-capacitor instead of Lithium-ION batteries, Cache Vault technology virtually eliminates hardware maintenance costs associated with batteries, lowers total cost of ownership over the life of the controller card & provide more environmentally friendly cache protection, all while maintaining optimal RAID performance. ...

The Broadcom dual-port 10GBASE-T Ethernet network adapter for Dell Power Edge rack servers is based on the Net Xtreme E-series BCM57406 Controller ASIC. As application workloads & virtualization technologies drive increased demands on server performance, network performance requirements scale accordingly. This growth demands an advanced breed of Ethernet connectivity solutions. Broadcom Net Xtreme E-series adapters in Dells Power Edge servers deliver high throughput, low latency & key features to enable optimal performance for a variety of workloads. Whether in a native bare-metal platform or in a virtualized environment, Net Xtreme-E series solutions are designed to deliver the networking performance & flexibility needed to ensure optimal application performance. Features like SRIOV with 128 virtual functions (VFs) & VMQ hardware support give IT administrators the tools to address any networking challenge. ...

The Broadcom 57412 10 Gb Network Interface Card from Dell is ideal for connecting your server to your network. The Dual Port PCIe Adapter proven to be reliable & standards-based solutions. ...
