Biostar J3160MD Ver. 6.x VGA DVI 6-Channel HD Audio Micro ATX Motherboard Specifications: CPU Intel Celeron J3160 Quad-core 2.24G MEMORY Support Dual Channel DDR3L 1600/1066 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 8GB Memory for DDR3L-1600 OR 16GB Memory for DDR3L-1066 » The DIMM must be installed to DIMMA1 slot first. EXPANSION SLOT 1 x PCI-E x 16 2.0 Slot (x 1) 2 x PCI Slot STORAGE 2 x SATA3 Connector USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111H
- 10/100/1000 Controller INTEGRATED VIDEO Intel HD Graphics Supports DX11.1 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 2 x System Fan Header 1 x Serial Header H/W MONITORING CPU / System Temperature Monitoring System Fan Monitoring System Voltage Monitoring DIMENSION Micro ATX Form Factor Dimension: 22.6cm x 18.8cm (W x L ) OS SUPPORT Support Windows 7 (x 64) / 8.1 (x 64) / 10 BUNDLE SOFTWARE Bull Guard BIO-Remote 2 Smart Speed LAN FEATURES Supports 100% Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Features CPU Onboard On board Intel Celeron J3160 Quad-core 2.24G Supports 2 SO-DIMM of DDR3L 1600/1066 M Hz up to 16G maximum capacity Intel HD Graphics Mini ITX (17*17cm ) for flexible use Support HDMI multimedia port Supports BIO-Remote 2 Technology Supports Charger Booster Technology Overview HD Audio Provides high quality sound with minimal loss of audio fidelity. DX11.1 Direct 3D 11.1 enables Direct 3D 10 APIs & Direct 3D 11 APIs to use one underlying rendering device. & it allows developers to achieve a high speed, fully conformant software rasterizer. Smart Speed LAN Smart Speed LAN is a free software application which monitors & manages your PCs network behavior. With user-friendly GUI, it means that you can select & prioritize different types of network traffic, including gaming, media streaming, communications or web surfing. You can also set any specific applications, choosing to prioritize or block accordingly. Smart Speed LAN can feature automatic management options that use adaptive networking intelligence to ensure that you are getting the best online experience possible. Charger Booster Charger booster is the best & efficient charger solution for apple devices such as iPad, iPhone. Basically, Charger booster Technology is able to boost the charging time to be more efficiency & faster once any apple goods connecting to our Motherboard. With charger booster technology, you are able to charge your apple devices up to 42 % faster. USB (Universal Serial Bus) 3.0 Experience Fastest data transfers at 5 Gbps with USB (Universal Serial Bus) 3.0--the new latest connectivity standard. Built to connect easily with next-generation components & peripherals, USB (Universal Serial Bus) 3.0 transfers data 10X faster & backward compatible with previous USB (Universal Serial Bus) 2.0 components. ...

Biostar N3150NH Ver. 6.x Intel Celeron VGA HDMI 6-Channel HD Audio Mini ITX Motherboard Chipset NA CPU Intel Celeron N3150 1.6G Quad-core 1.6G turbo boost up to 2.08G MEMORY Support Dual Channel DDR3L 1600/1066 MHz 2 x DDR3 SO-DIMM Memory Slot Max. Supports up to 8GB Memory for DDR3L-1600 OR 16GB Memory for DDR3L-1066 » The DIMM must be installed to DIMMA1 slot first. EXPANSION SLOT 1 x PCI-E x 1 2.0 Slot STORAGE 2 x SATA3 Connector USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111H
- 10/100/1000 Controller INTEGRATED VIDEO Intel HD Graphics Supports DX11.1 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 2 x System Fan Header 1 x Serial Header H/W MONITORING CPU / System Temperature Monitoring System Fan Monitoring System Voltage Monitoring DIMENSION Mini ITX Form Factor Dimension: 17cm x 17cm (W x L ) OS SUPPORT Support Windows 7 (x 64) / 8.1 (x 64) / 10 BUNDLE SOFTWARE Bull Guard BIO-Remote 2 Smart Speed LAN FEATURES Supports Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Socket AM3 Supports AMD Phenom II/ Athlon II/ Sempron Processors Hyper Transport Technology up to 2G Supports AMD Cooln Quiet Technology Chipset NVIDIA n Force 520 CPU SUPPORT AMD Phenom™ II X4 Processor AMD Phenom™ II X3 Processor AMD Phenom™ II X2 Processor AMD Athlon™ II X4 Processor AMD Athlon™ II X3 Processor AMD Athlon™ II X2 Processor AMD Sempron™ Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR3 800/1066/1333 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 16GB Memory EXPANSION SLOT 3 x PCI Slots 1 x PCI-E x 1 Slot 1 x PCI-E x 16 Slot STORAGE 4 x SATA2 3 Gb/s Connector 1 x IDE Connector Support SATA RAID: 0, 1, 5, 10 USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header Gb E Realtek RTL8111DL
- 10/100/1000 Controller CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 2.0 Port 1 x COM Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA2 3 Gb/s Connector 1 x IDE Connector 1 x Floppy Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 1 x System FAN Header DIMENSION ATX Form Factor Dimension: 29.3cm X 20cm (W x L ) OS SUPPORT Support Windows XP / Vista / 7
...

Biostar NM70I-1037U Socket Intel Dual-core Celeron VGA HDMI 6-Channel HD Audio Mini ITX Motherboard Chipset: Intel NM70 CPU: Intel Celeron 1037U Dual-Core 1.8 G Hz Processor MEMORY: Support Dual Channel DDR3 1600/1333 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 16GB Memory EXPANSION SLOT: 1 x PCI-E x 16 2.0 Slot (x 8) STORAGE 1 x SATA3 Connector 3 x SATA2 Connector USB: 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN: Realtek RTL8111F
- 10/100/1000 Controller INTEGRATED VIDEO Intel HD Graphics Max. shared memory 1759MB Supports DX11 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O: 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O: 1 x Printer Header 2 x USB (Universal Serial Bus) 2.0 Header 1 x SATA3 6 Gb/s Connector 3 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header DIMENSION: Mini ITX Form Factor Dimension: 17cm x 17cm (W x L ) OS SUPPORT: Support Windows XP / Vista / 7 / 8 FEATURES Windows 8 Ready Supports Smart Speed LAN Supports BIO-Remote 2 Supports Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Chipset Intel H77 CPU SUPPORT Intel Core i 7 LGA 1155 Processor Intel Core i 5 LGA 1155 Processor Intel Core i 3 LGA 1155 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR3 2400 (OC)/2200 (OC)/2000 (OC)/1800 (OC)/1600/1333/1066 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT 1 x PCI-E x 16 3.0 Slot (supported by Core i 5 -3xxx / Core i 7 3xxx CPU) 1 x PCI-E x 16 2.0 Slot (x 4) 2 x PCI-E x 1 2.0 Slot 2 x PCI Slots STORAGE 2 x SATA3 6 Gb/s Connector 4 x SATA2 3 Gb/s Connector Support SATA RAID: 0, 1, 5, 10 Support Intel Smart Response Technology USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header Intel USB3.0 only support Win 7 or later version Gb E Realtek RTL8111E
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model Supports DX11 Supports HDCP CODEC Realtek ALC892 8-Channel HD Audio REAR I/O 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 6 x Audio Connector INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA3 6 Gb/s Connector 4 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header DIMENSION ATX Form Factor Dimension: 29.5 cm x 22 cm (W x L ) OS SUPPORT Support Windows XP / Vista / 7 ACCESSORIES 4 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x User Manual FEATURES Supports u EFI GUI Interface BIOS Supports BIO-Remote 2 Supports BIO-Remote Windows 7 Compatible Supports 100% Solid capacitor Supports Rapid Switch 2 Supports Rapid Debug 3 Supports BIOS-Flasher Supports BIOS-Relife Supports Toverclcoker OC software Supports GPU Supports Charger Booster Supports BIOS Online Update
...

Chipset AMD A75 CPU SUPPORT AMD A8 Processor AMD A6 Processor AMD A4 Processor AMD E2 Processor Maximum CPU TDP (Thermal Design Power): 100 Watt MEMORY Support Dual Channel DDR3 2000 (OC)/1866/1600/1333/1066/800 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT 2 x PCI-E x 16 2.0 Slot (x 16 + x 4) 2 x PCI-E x 1 2.0 Slot 2 x PCI Slots STORAGE 6 x SATA3 6 Gb/s Connector Support SATA RAID: 0, 1, 10 USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 4 x USB (Universal Serial Bus) 2.0 Port 3 x USB (Universal Serial Bus) 2.0 Header Gb E Realtek RTL8111E
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model Maximum resolution: VGA:1920x 1600, DVI-D:1920x 1200, HDMI:1920x 1200 CODEC Realtek ALC892 8-Channel HD Audio REAR I/O 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 6 x Audio Connector INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 3 x USB (Universal Serial Bus) 2.0 Header 6 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header DIMENSION ATX Form Factor Dimension: 30.5cm x 24.4cm (W x L ) OS SUPPORT Support Windows XP / Vista / 7 FEATURES Supports u EFI GUI Interface BIOS Supports BIO-Remote 2 Supports BIO-Remote Windows 7 Compatible Supports 100% Solid capacitor Supports Rapid Switch Supports Rapid Debug 3 Supports BIOS-Flasher Supports BIOS-Relife Supports Toverclcoker OC software Supports GPU
...

Chipset AMD A75 CPU Support AMD A8 Processor AMD A6 Processor AMD A4 Processor AMD E2 Processor Maximum CPU TDP (Thermal Design Power): 100 Watt Memory Support Dual Channel DDR3 2000 (OC)/1866/1600/1333/1066/800 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory Expansion Slots 1 x PCI Slots 1 x PCI-E x 1 2.0 Slot 2 x PCI-E x 16 2.0 Slot (x 16 + x 4) Storage 6 x SATA3 6 Gb/s Connector Support SATA RAID: 0, 1, 10 USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header Gb E Realtek RTL8111E
- 10/100/1000 Controller Integrated Video By CPU model Maximum resolution: VGA:1920x 1600, DVI-D:1920x 1200, HDMI:1920x 1200 Codec Realtek ALC892 6-Channel Blu-ray Audio REAR I/O 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector Internal I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 6 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header

Dimensions Micro ATX Form Factor Dimension: 24.4cm x 22.5cm (W x L ) OS Support Support Windows XP / Vista / 7


...

Chipset AMD A75 CPU Support AMD A8 Processor AMD A6 Processor AMD A4 Processor AMD E2 Processor Maximum CPU TDP (Thermal Design Power): 100 Watt Check Biostar website for list of compatible processors, the above is for reference only Memory Support Dual Channel DDR3 2000 (OC)/1866/1600/1333/1066/800 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory Expansion Slots 1 x PCI Slots 1 x PCI-E x 1 2.0 Slot 2 x PCI-E x 16 2.0 Slot (x 16 + x 4) Storage 6 x SATA3 6 Gb/s Connector Support SATA RAID: 0, 1, 10 USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 4 x USB (Universal Serial Bus) 2.0 Port 3 x USB (Universal Serial Bus) 2.0 Header Gb E Realtek RTL8111E
- 10/100/1000 Controller Integrated Video By CPU model Maximum resolution: VGA:1920x 1600, DVI-D:1920x 1200, HDMI:1920x 1200 Audio Realtek ALC892 8-Channel HD Audio Rear I/O 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 6 x Audio Connector Internal I/O 1 x USB (Universal Serial Bus) 3.0 Header 3 x USB (Universal Serial Bus) 2.0 Header 6 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header

Dimensions Micro ATX Form Factor Dimension: 24.4cm x 22.5cm (W x L ) OS Support Support Windows XP / Vista / 7


...

Specifications Chipset AMD A75 CPU SUPPORT AMD A10 Processor AMD A8 Processor AMD A6 Processor AMD A4 Processor AMD E2 Processor AMD Athlon II X4 Processor Maximum CPU TDP (Thermal Design Power): 100 Watt MEMORY Support Dual Channel DDR3 1866/1600/1333/1066/800 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT 1 x PCI-E x 16 2.0 Slot 2 x PCI-E x 1 2.0 Slot 1 x PCI Slots STORAGE 6 x SATA3 Connector Support SATA RAID: 0, 1, 10 USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111F
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model AMD Dual Graphics Technology Supports DX11 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 6 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header 1 x CIR Header DIMENSION Micro ATX Form Factor Dimension: 24.4cm x 20cm (W x L ) OS SUPPORT Support Windows XP / Vista / 7 / 8 FEATURES Windows 8 Compatible Supports BIO-Remote 2 Supports BIO-Remote Supports 100% Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...
