Audio power is an important factor in audio quality. Most AV equipment isolates the power supply for each analog & digital signal to gather high-quality sound reproduction. Equipped with BIOSTAR Hi-Fi Power technology, it will utilize audio components with independent power design for a significant reduction in electronic noise & superb sound quality. BIOSTAR Hi-Fi Ground presents noise-blocking multi-layer PCB design which isolates analog audio signals from digital sources. The unique PCB layout is ideal for exceptional clarity & high fidelity sound. Its focused on improving sound quality beyond the regular motherboard designs. THX Tru Studio Pro is specially designed to bring the same great audio experience found in live performances, films, & recording studios
- to the PC. THX Tru Studio Pro provides the latest groundbreaking technologies that are products of years of collective experience & research by Creative & THX. Together, these technologies deliver the fullest audio experience for music, movies & games, while remaining true to the source & intention of the artists who created it. Virtu Universal MVP, is an optimized Lucid Virtu GPU virtualization software that makes your PC look better, respond faster, process video & media smoother, all within a low power environment, Virtu Universal MVP has many of the same features as the popular Virtu software, but with a twist
- the addition of the optional Hyperformance feature for intelligent reduction of redundant rendering tasks in the flow between the CPU, GPU & display. BIOSTAR Hi-Fi series motherboards have a sampling rate of 192k Hz/24-bit which delivers a high quality audio through an analog connection to your home theater system, multi-channel speakers & high-end headphone. You can enjoy real Blu-ray grade high-definition sound that youve never experienced before. Multi Channels Calibration (MCC) can transform any room into the ideal listening environment. With Multi Channels Calibration (MCC), audio performance is automatically calibrated according to the

Dimensions of your room. Simply place the speaker & setup the microphone at your usual listening spot, position the speakers & connect them. The users can set up the speaker settings easily by using a free bundle MCC software. The built-in amplifier can drive major high-end headphones with over 100d B loads & offer wide b&-width, low noise, high slew rate & low distortion audio source from front panel I/O. Gaming enthusiasts can enjoy a fuller range of dynamic sound with crisper details & less distortion. Chipset Intel Z77 CPU SUPPORT Intel Core i 7 LGA 1155 Processor Intel Core i 5 LGA 1155 Processor Intel Core i 3 LGA 1155 Processor Intel Pentium LGA 1155 Processor Intel Celeron LGA 1155 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR3 2600 (OC)/2400 (OC)/2200 (OC)/2133 (OC)/1866 (OC)/1800 (OC)/1600/1333/1066 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT 2 x PCI-E x 16 3.0 Slot (SLi / CFX x 8) 1 x PCI-E x 16 2.0 Slot (x 4) 3 x PCI-E x 1 2.0 Slot STORAGE 2 x SATA3 Connector 4 x SATA2 Connector Support SATA RAID: 0, 1, 5, 10 Support Intel Smart Response Technology USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header Intel USB3.0 only support Win 7 or later version Gb E Realtek RTL8111F
- 10/100/1000 Controller MULTI GRAPHICS AMD Cross Fire X NVIDIA SLI INTEGRATED VIDEO By CPU model Supports DX11 Supports HDCP CODEC Realtek ALC898 8 Channel Blu-ray Audio REAR I/O 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 6 x Audio Connector INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA3 6 Gb/s Connector 4 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header DIMENSION ATX Form Factor Dimension: 30.5 cm x 24.4 cm (W x L ) OS SUPPORT Support Windows XP / Vista / 7 / 8 ACCESSORIES 4 x SATA Cable 1 x SLI Connector 1 x Cross Fire Connector 1 x I/O Shield 1 x DVD Driver 1 x User Manual FEATURES Windows 8 Compatible Supports u EFI GUI Interface BIOS Supports THX Tru Studio Pro Supports BIO-Remote 2 Supports BIO-Remote Supports 100% Solid capacitor Supports Rapid Switch 2 Supports Rapid Debug 3 Supports HDMI Audio Ready Supports Toverclcoker OC software Supports GPU Supports Charger Booster Supports BIOS Online Update




...

Features Support 7th Generation Intel Core™ Processor Intel H110 single chip architecture Support 2-DIMM DDR4-2400/ 2133/ 1866 up to 32G maximum capacity Support USB (Universal Serial Bus) 3.0 Support HDMI multimedia port Support Gb E LAN Product Overview The Intel H110 chipset is a single-chipset design to support socket 1151 Intel 6th generation Intel Core™ processor-based platform. Provides excellent performance & increased bandwidth & stability. Intel H110 chipset can also enable i GPU function, letting users enjoy the latest Intel integrated graphic performance. The PC platform features enhanced adaptive performance that adds speed when you need it. When combined with advanced system responsiveness, the platform delivers the ultimate PC experience. Specifications Chipset Intel H110 CPU SUPPORT Intel Core™ i 7 LGA 1151 Processor Intel Core™ i 5 LGA 1151 Processor Intel Core™ i 3 LGA 1151 Processor Intel Pentium LGA 1151 Processor Intel Celeron LGA 1151 Processor Maximum CPU TDP (Thermal Design Power): 91 Watt MEMORY Support Dual Channel DDR4 2400/ 2133/ 1866 MHz 2 x DDR4 DIMM Memory Slot Max. Supports up to 32GB Memory * DDR4 2400 for 7th Generation Intel Core™ Processor Family EXPANSION SLOT 1 x PCI-E x 16 3.0 Slot 2 x PCI-E x 1 2.0 Slot STORAGE 4 x SATA3 Connector USB 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111H
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model Supports DX12 Supports HDCP CODEC Realtek ALC887 8-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector, resolution up to 3840 x 2160 @30 Hz 1 x VGA Port, resolution up to 1920 x 1200 @60 Hz 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Header 1 x System Fan Header 1 x Serial Header H/W MONITORING CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control System Voltage Monitoring DIMENSION Micro ATX Form Factor Dimension: 22.6cm x 17.1cm (W x L ) OS SUPPORT Support Windows 10 (x 64) for Intel 7th Generation Processor &8251; Support Windows 7 / 8.1 (x 64) / 10 (x 64) for Intel 6th Generation Processor BUNDLE SOFTWARE Bull Guard Smart Speed LAN (Windows 7/ 8.1 only) ACCESSORIES 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide FEATURES Supports 100% Solid capacitor Supports Charger Booster Supports BIOS Online Update
...

Audio+ HD Audio HD Audio Provides high quality sound with minimal loss of audio fidelity. Video+ DX12 DX12 Direct X 12 introduces the next version of Direct 3D, the graphics API at the heart of Direct X. Direct 3D is one of the most critical pieces of a game or game engine, & weve redesigned it to be faster & more efficient than ever before. Direct 3D 12 enables richer scenes, more objects, & full utilization of modern GPU hardware. Integrated HDMI with HDCP Integrated HDMI with HDCP Onboard HDMI connector allows full video & audio support. It has industry-leading high definition video quality. Speed+ USB (Universal Serial Bus) 3.1 Gen 1 Type-A USB (Universal Serial Bus) 3.1 Gen 1 Type-A Experience Fastest data transfers at 5 Gbps with USB (Universal Serial Bus) 3.1 Gen 1--the new latest connectivity standard. Built to connect easily with next-generation components & peripherals, USB (Universal Serial Bus) 3.1 Gen 1 transfers data 10X faster & backward compatible with previous USB (Universal Serial Bus) 2.0 components. SATAIII 6 Gbps SATAIII 6 Gbps SATAIII 6 Gbps provides a higher bandwidth to retrieve & transfer HD media. With this super speed data transfer, SATAIII allows an incredible data boost which is 2x faster than the SATA 3G. Protection+ Super LAN Surge Protection Super LAN Surge Protection Super LAN Surge Protection, providing LAN port with more advanced antistatic protection capabilities by adding an integrated chip to strengthen electrical stability & prevent damage from lightning strikes & electrical surges. SLSP (Super LAN Surge Protection) series motherboard upgrades the existing system protection standards with maximum 4X protection comparing to other board makers. DIY+ e Hot-Line Utiltiy e Hot-Line Utiltiy Integrated e-service automatically sends your technical support request to Biostar Globe tech support without any delay. CPU-Chipset Features Intel H310 chipset Intel H310 chipset The Intel H310 chipset is a single-chipset design to support socket 1151 Intel 8th generation Intel Core™ processor-based platform. Provides excellent performance & increased bandwidth & stability. The PC platform features enhanced adaptive performance that adds speed when you need it. When combined with advanced system responsiveness, the platform delivers the ultimate PC experience. Specifications Chipset Intel H310 CPU SUPPORT 9th Gen Intel Core™ i 9 LGA 1151 Processor 9th Gen Intel Core™ i 7 LGA 1151 Processor 9th Gen Intel Core™ i 5 LGA 1151 Processor 9th Gen Intel Core™ i 3 LGA 1151 Processor 8th Gen Intel Core™ i 7 LGA 1151 Processor 8th Gen Intel Core™ i 5 LGA 1151 Processor 8th Gen Intel Core™ i 3 LGA 1151 Processor 8th Gen Intel Pentium LGA 1151 Processor 8th Gen Intel Celeron LGA 1151 Processor MEMORY Support DDR3L 1333/1600/1866/2400 MHz 2x DDR3L DIMM Memory Slots Max. Supports up to 32 GB Memory Each DIMM supports non-ECC 4/8/16GB DDR3L module INTEGRATED VIDEO By CPU model Supports DX12 Supports HDCP STORAGE 4 x SATA3 Connectors LAN Realtek RTL8111H Gb E LAN
- 10/100/1000 Mb/s Controller Support Super LAN Surge Protection CODEC Realtek ALC887 8-Channel HD Audio USB 4 x USB (Universal Serial Bus) 3.1 Gen 1 Port (2 on rear I/ Os & 2 via internal header) 6 x USB (Universal Serial Bus) 2.0 Port (2 on rear I/ Os & 4 via internal header) EXPANSION SLOT 1 x PCI-E 3.0 x 16 Slot 2 x PCI-E 2.0 x 1 Slot REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.1 Gen 1 Ports 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector, resolution up to 4096 x 2160@24 Hz, compliant with HDMI 1.4 1 x VGA Port, resolution up to 1920 x 1200 @60 Hz 1 x LAN port 3 x Audio Jacks INTERNAL I/O 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header (each header supports 2 USB (Universal Serial Bus) 3.1 Gen 1 ports) 2 x USB (Universal Serial Bus) 2.0 Header (each header supports 2 USB (Universal Serial Bus) 2.0 ports) 4 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Connector 1 x System Fan Connector 1 x 4-Pin Power Connector 1 x 24-Pin Power Connector 1 x Clear CMOS Header 1 x COM Port Header DIMENSION Micro ATX Form Factor Dimension: 22.6 cm x 17.1 cm (W x L ) OS SUPPORT Support Windows 10 (64bit) &8251;BIOSTAR reserves the right to add or remove support for any OS with or without notice. BUNDLE SOFTWARE Bull Guard ACCESSORIES 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide Caution!! The

Specification & pictures are subject to change without notice!


...

Features On board Intel Celeron J3060 Dual-core 2.48G Supports 2 SO-DIMM of DDR3L 1600/1066 M Hz up to 16G maximum capacity Intel HD Graphics Mini ITX (17*17cm ) for flexible use Support HDMI multimedia port Supports BIO-Remote 2 Technology Supports Charger Booster Technology Specifications CPU Intel Celeron J3060 Dual-core 2.48G MEMORY Support Dual Channel DDR3L 1600/1066 MHz 2 x DDR3 SO-DIMM Memory Slot Max. Supports up to 8GB Memory for DDR3L-1600 OR 16GB Memory for DDR3L-1066 &8251; The DIMM must be installed to DIMMA1 slot first. EXPANSION SLOT 1 x PCI-E x 1 2.0 Slot STORAGE 2 x SATA3 Connector USB 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111H
- 10/100/1000 Controller INTEGRATED VIDEO Intel HD Graphics Supports DX11.1 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 2 x System Fan Header 1 x Serial Header H/W MONITORING CPU / System Temperature Monitoring System Fan Monitoring System Voltage Monitoring DIMENSION Mini ITX Form Factor Dimension: 17cm x 17cm (W x L ) OS SUPPORT Support Windows 7 (x 64) / 8.1 (x 64) / 10 BUNDLE SOFTWARE Bull Guard BIO-Remote 2 Smart Speed LAN ACCESSORIES 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide FEATURES Supports Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Specifications Chipset Intel NM70 CPU Intel Celeron 1037U Dual-Core 1.8 G Hz Processor MEMORY Support Dual Channel DDR3 1600/1333 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 16GB Memory EXPANSION SLOT 1 x PCI-E x 16 2.0 Slot (x 8) STORAGE 1 x SATA3 Connector 3 x SATA2 Connector USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111F
- 10/100/1000 Controller INTEGRATED VIDEO: Intel HD Graphics Max. shared memory 1759MB (DVMT) Supports DX11 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 2 x USB (Universal Serial Bus) 2.0 Header 1 x SATA3 6 Gb/s Connector 3 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header DIMENSION Mini ITX Form Factor Dimension: 17cm x 17cm (W x L ) OS SUPPORT Support Windows XP / Vista / 7 / 8 FEATURES Windows 8 Ready Supports Smart Speed LAN Supports BIO-Remote 2 Supports Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Supports 6th Generation Intel Core™ Processor Intel B150 single chip architecture Support 2-DIMM DDR4-2133/ 1866 up to 32G maximum capacity BIOSTAR Hi-Fi Technology inside Support USB (Universal Serial Bus) 3.0 Support PCIe U.2 (32 Gb/s) Support PCIe M.2 (32 Gb/s)

Specification Chipset- Intel Z170 CPU SUPPORT- Intel Core™ i 7 LGA 1151 Processor, Intel Core™ i 5 LGA 1151 Processor, Intel Core™ i 3 LGA 1151 Processor, Intel Pentium LGA 1151 Processor, Intel Celeron LGA 1151 Processor, Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY- Support Dual Channel DDR4 3200 (OC)/ 2133/ 1866 MHz 2 x DDR4 DIMM Memory Slot, Max. Supports up to 32GB Memory EXPANSION SLOT- 1 x PCI-E x 16 3.0 Slot STORAGE- 4 x SATA3 Connector, 1 x U.2 32 Gb/s Connector, Support SATA RAID: 0, 1, 5, 10, 1 x M.2 Key M 32 Gb/s Connector, support M.2 type 2260/ 2280 SATA 6 Gb/s & PCI-E Storage (on the back of the motherboard) USB (Universal Serial Bus)
- 4 x USB (Universal Serial Bus) 3.0 Port, 1 x USB (Universal Serial Bus) 3.0 Header, 2 x USB (Universal Serial Bus) 2.0 Port, 1 x USB (Universal Serial Bus) 2.0 Header LAN- Intel I219V
- Gigabit Ethernet PHY INTEGRATED VIDEO- By CPU model, Supports DX12, Supports HDCP CODEC- Realtek ALC892 8-Channel Blu-ray Audio, Support Biostar Hi-Fi REAR I/O- 1 x PS/2 Keyboard/ Mouse, 4 x USB (Universal Serial Bus) 3.0 Port, 2 x USB (Universal Serial Bus) 2.0 Port, 1 x HDMI Connector, resolution up to 4096 x 2160 @24 Hz, compliant with HDMI 1.4a, 1 x DVI-D Connector, resolution up to 1920 x 1200 @60 Hz, 1 x RJ-45 Port, 5 x Audio Connector, 1 x S/PDIF Out Port INTERNAL I/O- 1 x USB (Universal Serial Bus) 3.0 Header, 1 x USB (Universal Serial Bus) 2.0 Header, 4 x SATA3 6 Gb/s Connector, 1 x U.2 32 Gb/s Connector, 1 x M.2 Key M 32 Gb/s Connector, support M.2 type 2260/ 2280 SATA 6 Gb/s & PCI-E Storage (on the back of the motherboard), 1 x Front Audio Header, 1 x Front Panel Header, 1 x CPU Fan Header, 1 x System Fan Header, 1 x 5050 LED Header H/W MONITORING- CPU / System Temperature Monitoring, CPU / System Fan Monitoring, Smart / Manual CPU / System Fan Control System Voltage Monitoring DIMENSION- Mini ITX Form Factor Dimension: 17cm x 17cm (W x L ) OS SUPPORT- Support Windows 7 / 8.1 (x 64) / 10 (x 64) BUNDLE SOFTWARE- Racing GT Utility, Bull Guard, BIO-Remote 2 ACCESSORIES- 4 x SATA Cable, 1 x I/O Shield, 1 x DVD Driver, 1 x User Manual



...

Supports 6th Generation Intel Core™ Processor Intel Z170 single chip architecture Support 2-DIMM DDR4-3200 (OC)/ 2133/ 1866 up to 32G maximum capacity BIOSTAR Hi-Fi Technology inside Support USB (Universal Serial Bus) 3.0 Support PCIe U.2 (32 Gb/s) Support PCIe M.2 (32 Gb/s)

Specification Chipset- Intel Z170 CPU SUPPORT- Intel Core™ i 7 LGA 1151 Processor, Intel Core™ i 5 LGA 1151 Processor, Intel Core™ i 3 LGA 1151 Processor, Intel Pentium LGA 1151 Processor, Intel Celeron LGA 1151 Processor, Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY- Support Dual Channel DDR4 3200 (OC)/ 2133/ 1866 MHz 2 x DDR4 DIMM Memory Slot, Max. Supports up to 32GB Memory EXPANSION SLOT- 1 x PCI-E x 16 3.0 Slot, 1 x PCI-E M.2 Key E Slot for M.2 type 2230 Wi-Fi card STORAGE- 4 x SATA3 Connector, 1 x U.2 32 Gb/s Connector, Support SATA RAID: 0, 1, 5, 10, 1 x M.2 Key M 32 Gb/s Connector, support M.2 type 2260/ 2280 SATA 6 Gb/s & PCI-E Storage (on the back of the motherboard) USB (Universal Serial Bus)
- 4 x USB (Universal Serial Bus) 3.0 Port, 1 x USB (Universal Serial Bus) 3.0 Header, 2 x USB (Universal Serial Bus) 2.0 Port, 1 x USB (Universal Serial Bus) 2.0 Header LAN- Intel I219V
- Gigabit Ethernet PHY INTEGRATED VIDEO- By CPU model, Supports DX12, Supports HDCP CODEC- Realtek ALC892 8-Channel Blu-ray Audio, Support Biostar Hi-Fi REAR I/O- 1 x PS/2 Keyboard/ Mouse, 4 x USB (Universal Serial Bus) 3.0 Port, 2 x USB (Universal Serial Bus) 2.0 Port, 1 x HDMI Connector, resolution up to 4096 x 2160 @24 Hz, compliant with HDMI 1.4a, 1 x DVI-D Connector, resolution up to 1920 x 1200 @60 Hz, 1 x RJ-45 Port, 5 x Audio Connector, 1 x S/PDIF Out Port INTERNAL I/O- 1 x USB (Universal Serial Bus) 3.0 Header, 1 x USB (Universal Serial Bus) 2.0 Header, 4 x SATA3 6 Gb/s Connector, 1 x U.2 32 Gb/s Connector, 1 x M.2 Key M 32 Gb/s Connector, support M.2 type 2260/ 2280 SATA 6 Gb/s & PCI-E Storage (on the back of the motherboard), 1 x Front Audio Header, 1 x Front Panel Header, 1 x CPU Fan Header, 1 x System Fan Header, 1 x 5050 LED Header H/W MONITORING- CPU / System Temperature Monitoring, CPU / System Fan Monitoring, Smart / Manual CPU / System Fan Control System Voltage Monitoring DIMENSION- Mini ITX Form Factor Dimension: 17cm x 17cm (W x L ) OS SUPPORT- Support Windows 7 / 8.1 (x 64) / 10 (x 64) BUNDLE SOFTWARE- Racing GT Utility, Bull Guard, BIO-Remote 2 ACCESSORIES- 4 x SATA Cable, 1 x I/O Shield, 1 x DVD Driver, 1 x User Manual



...

CPU Intel Celeron J1800 (2.41 GHz) Dual-Core Processor MEMORY Support Dual Channel DDR3/DDR3L 1333 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 16GB Memory INTEGRATED VIDEO Intel HD Graphics Supports DX11 Supports HDCP STORAGE 2 x SATA2 Connector LAN Realtek RTL8111G
- 10/100/1000 Mb/s Controller CODEC Realtek ALC662 6-Channel HD Audio USB 1 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header EXPANSION SLOT 1 x PCI-E 2.0 x 16 Slot (x 1 speed) 2 x PCI-E 2.0 x 1 Slot REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 1 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x LAN port 3 x Audio Jacks INTERNAL I/O 1 x Printer Header 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 2 x System Fan Connector 1 x Serial Port Header H/W MONITORING CPU / System Temperature Monitoring System Fan Monitoring System Voltage Monitoring DIMENSION Micro ATX Form Factor Dimension: 22.6cm x 18.8cm (W x L ) OS SUPPORT Support Windows 7 / 8 / 8.1 / 10 (x 64) BUNDLE SOFTWARE Bull Guard BIO-Remote 2 Smart Speed LAN Intel Smart Connect Technology ACCESSORIES 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide FEATURES Supports Solid capacitor Supports BIOS-Flasher Supports Charger Booster
...

Biostar J1900NH2 Ver. 6.0 Intel Celeron VGA HDMI 6-Channel HD Audio Mini ITX Motherboard Chipset NA CPU Intel Celeron J1900 (2.0 GHz) Quad-Core Processor MEMORY Support Dual Channel DDR3L 1333 MHz 2 x DDR3 SO-DIMM Memory Slot Max. Supports up to 16GB Memory The DIMM must be installed to DIMMA1 slot first. EXPANSION SLOT 1 x PCI-E x 1 Slot STORAGE 2 x SATA2 Connector USB (Universal Serial Bus) 1 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111G
- 10/100/1000 Controller INTEGRATED VIDEO Intel HD Graphics Supports DX11 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 1 x USB (Universal Serial Bus) 3.0 Port 4 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 2.0 Header 2 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 2 x System FAN Header 1 x Serial Header H/W Monitoring CPU / System Temperature Monitoring System Fan Monitoring System Voltage Monitoring DIMENSION Mini ITX Form Factor Dimension: 17cm x 17cm (W x L ) OS SUPPORT Support Windows 7 / 8 / 8.1 Bundle Software BIO-Remote 2 Smart Speed LAN FEATURES Supports Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...

Biostar J3160MD Ver. 6.x VGA DVI 6-Channel HD Audio Micro ATX Motherboard Specifications: CPU Intel Celeron J3160 Quad-core 2.24G MEMORY Support Dual Channel DDR3L 1600/1066 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 8GB Memory for DDR3L-1600 OR 16GB Memory for DDR3L-1066 » The DIMM must be installed to DIMMA1 slot first. EXPANSION SLOT 1 x PCI-E x 16 2.0 Slot (x 1) 2 x PCI Slot STORAGE 2 x SATA3 Connector USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8111H
- 10/100/1000 Controller INTEGRATED VIDEO Intel HD Graphics Supports DX11.1 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA3 6 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 2 x System Fan Header 1 x Serial Header H/W MONITORING CPU / System Temperature Monitoring System Fan Monitoring System Voltage Monitoring DIMENSION Micro ATX Form Factor Dimension: 22.6cm x 18.8cm (W x L ) OS SUPPORT Support Windows 7 (x 64) / 8.1 (x 64) / 10 BUNDLE SOFTWARE Bull Guard BIO-Remote 2 Smart Speed LAN FEATURES Supports 100% Solid capacitor Supports BIOS-Flasher Supports Charger Booster Supports BIOS Online Update
...
