Supports 10th Generation Intel Core™ Processor Intel B460 single chip architecture Supports 4-DIMM DDR4- 2133/ 2400/ 2666/ 2800/ 2933 up to 128 GB Memory Supports PCIe M.2 (32 Gb/s) Supports Intel Optane Technology Supports HDMI 4K resolution Supports Gb E LAN A combination of exclusive hardware & software design including "ground-isolation circuit design", "an independent audio power", & "a built=on-board amplifier", with all these hardware features gives you the best audio quality & performance. As for software, we offer you a free bundle utility " Multi-Channel Calibration" which normally youll find in high level sound systems; this feature means that you can auto detect your location; with a user friendly interface, you can easily adjust the volume of every speakers to make a well balanced surround sound. & of course, the built-on-board amplifier always gives you a super powerful sound comparing to other motherboards. Hi-Fi Ground BIOSTAR Hi-Fi Ground (Golden Line ) is noise-blocking multi-layer PCB design to isolates analog audio signals from digital sources. Unique PCB layout is ideal for exceptional clarity & high fidelity sound. Hi-Fi AMP The built-in amplifier can drive major high-end headphones with over 100d B loads & offer wide b&-width, low noise, high slew rate & low distortion audio source from front panel I/O. Gaming enthusiasts can enjoy a fuller range of dynamic sound with crisper details & less distortion. DVI DVI is better than VGA for LCD displays since it is digital while VGA is analog. For LCD displays, the picture is digitized pixel per pixel. Through DVI, the panel gets data for each pixel, so the picture generated in the Graphics device matches the pixels on the panel itself. DX12 Direct X 12 introduces the next version of Direct 3D, the graphics API at the heart of Direct X. Direct 3D is one of the most critical pieces of a game or game engine, & weve redesigned it to be faster & more efficient than ever before. Direct 3D 12 enables richer scenes, more objects, & full utilization of modern GPU hardware. PCI-E Gen 3.0 PCI-E 3.0 is the next evolution of the ubiquitous & general-purpose PCI Express I/O standard. At 8GT/s bit rate, the interconnect performance bandwidth is doubled over PCI-E 2.0, while preserving compatibility with software & mechanical interfaces. Intel Optane Memory Ready Intel Optane memory can accelerate traditional storage devices to reduce boot times & improve the overall performance, like a br&-new system. This revolutionary memory technology transforms your old PC to a performance monster without expensive SSD. ...

A combination of exclusive hardware & software design including "ground-isolation circuit design", "an independent audio power", & "a built=on-board amplifier", with all these hardware features gives you the best audio quality & performance. As for software, we offer you a free bundle utility " Multi-Channel Calibration" which normally youll find in high level sound systems; this feature means that you can auto detect your location; with a user friendly interface, you can easily adjust the volume of every speakers to make a well balanced surround sound. & of course, the built-on-board amplifier always gives you a super powerful sound comparing to other motherboards. Hi-Fi Ground BIOSTAR Hi-Fi Ground (Golden Line ) is noise-blocking multi-layer PCB design to isolates analog audio signals from digital sources. Unique PCB layout is ideal for exceptional clarity & high fidelity sound. Hi-Fi Sound BIOSTAR Hi-Fi series motherboards have a sampling rate of 192k Hz/24-bit which delivers a high quality audio through an analog connection to your home theater system, multi-channel speakers & high-end headphone. You can enjoy real Blu-ray grade high-definition sound that you’ve never experienced before. Smart Ear Smart EAR is a windows-based audio utility which means that you can easily adjust system volume. With its user-friendly GUI, you can also increase or decrease impedance setting (Low/ High Gain) to optimize your headphone performance. You can easily enjoy high-quality & awesome sound. DX12 Direct X 12 introduces the next version of Direct 3D, the graphics API at the heart of Direct X. Direct 3D is one of the most critical pieces of a game or game engine, & weve redesigned it to be faster & more efficient than ever before. Direct 3D 12 enables richer scenes, more objects, & full utilization of modern GPU hardware. Display Port Display Port is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio. DVI DVI is better than VGA for LCD displays since it is digital while VGA is analog. For LCD displays, the picture is digitized pixel per pixel. Through DVI, the panel gets data for each pixel, so the picture generated in the Graphics device matches the pixels on the panel itself. ...

A combination of exclusive hardware & software design including "ground-isolation circuit design", "an independent audio power", & "a built=on-board amplifier", with all these hardware features gives you the best audio quality & performance. As for software, we offer you a free bundle utility " Multi-Channel Calibration" which normally youll find in high level sound systems; this feature means that you can auto detect your location; with a user friendly interface, you can easily adjust the volume of every speakers to make a well balanced surround sound. & of course, the built-on-board amplifier always gives you a super powerful sound comparing to other motherboards. Hi-Fi Ground BIOSTAR Hi-Fi Ground (Golden Line ) is noise-blocking multi-layer PCB design to isolates analog audio signals from digital sources. Unique PCB layout is ideal for exceptional clarity & high fidelity sound. Hi-Fi Sound BIOSTAR Hi-Fi series motherboards have a sampling rate of 192k Hz/24-bit which delivers a high quality audio through an analog connection to your home theater system, multi-channel speakers & high-end headphone. You can enjoy real Blu-ray grade high-definition sound that you’ve never experienced before. Smart Ear Smart EAR is a windows-based audio utility which means that you can easily adjust system volume. With its user-friendly GUI, you can also increase or decrease impedance setting (Low/ High Gain) to optimize your headphone performance. You can easily enjoy high-quality & awesome sound. DX12 Direct X 12 introduces the next version of Direct 3D, the graphics API at the heart of Direct X. Direct 3D is one of the most critical pieces of a game or game engine, & weve redesigned it to be faster & more efficient than ever before. Direct 3D 12 enables richer scenes, more objects, & full utilization of modern GPU hardware. Display Port Display Port is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio. DVI DVI is better than VGA for LCD displays since it is digital while VGA is analog. For LCD displays, the picture is digitized pixel per pixel. Through DVI, the panel gets data for each pixel, so the picture generated in the Graphics device matches the pixels on the panel itself. PCI-E 4.0 PCI-E 4.0 is the next evolution of the ubiquitous & general-purpose PCI Express I/O standard. At 16GT/s bit rate, the interconnect performance bandwidth is doubled over PCI-E 3.0, while preserving compatibility with software & mechanical interfaces. Moistureproof PCB The popularity of PC usage & working environment is getting deteriorating & moist (rural, coastal, etc.). The PCB will be oxidizing easily by damp or absorbed moisture, & ionic migration or CAF (Conductive Anodic Filament) will be generated. Moisture-proof PCB meets high density & high reliability requirements for moisture proof. ...

Supports AMD 3rd Ryzen TM (Matisse/ Renoir) processors AMD B550 single chip architecture Supports 2-DIMM DDR4-4933+ (OC)/4800 (OC)/4600 (OC)/4400 (OC)/4000 (OC)/3800 (OC)/3600 (OC)/3200 (OC) /2933/2667/2400/2133/1866 Supports USB (Universal Serial Bus) 3.2 Gen 1 Supports PCIe M.2 4.0 (64 Gb/s) Supports HDMI 4K resolution AMD B550 chipset AMD B550 is the high-end chipset for overclockers & tweakers who need robust platforms. This chip provides the ultimate low-level control to its users & delivers ultimate graphics card bandwidth. It also supports PCI-E Gen 4 bandwidth Hi-Fi Ground BIOSTAR Hi-Fi Ground (Golden Line ) is noise-blocking multi-layer PCB design to isolates analog audio signals from digital sources. Unique PCB layout is ideal for exceptional clarity & high fidelity sound. HDMI 4K2K The new 4K2K resolution enables high-definition image display with four times the resolution of full HD, 4K2K display is faithfully express bright, highly detailed content that fills the entire screen with lifelike images. Connectivity with PCs via a single HDMI cable for displaying 4K2K data DX12 Direct X 12 introduces the next version of Direct 3D, the graphics API at the heart of Direct X. Direct 3D is one of the most critical pieces of a game or game engine, & weve redesigned it to be faster & more efficient than ever before. Direct 3D 12 enables richer scenes, more objects, & full utilization of modern GPU hardware. ...

Chipset Intel B75 CPU SUPPORT Intel Core i 7 LGA 1155 Processor Intel Core i 5 LGA 1155 Processor Intel Core i 3 LGA 1155 Processor Intel Pentium LGA 1155 Processor Maximum CPU TDP (Thermal Design Power): 95 Watt MEMORY Support Dual Channel DDR3 1600/1333/1066 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory EXPANSION SLOT 1 x PCI-E x 16 3.0 Slot (supported by Core i 5 -3xxx / Core i 7 3xxx CPU) 1 x PCI-E x 1 2.0 Slot 2 x PCI Slots STORAGE 1 x SATA3 6 Gb/s Connector 5 x SATA2 3 Gb/s Connector USB (Universal Serial Bus) 2 x USB (Universal Serial Bus) 3.0 Port 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header Intel USB3.0 only support Win 7 or later version Gb E Realtek RTL8111F
- 10/100/1000 Controller INTEGRATED VIDEO By CPU model Supports DX11 Supports HDCP CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 2 x USB (Universal Serial Bus) 3.0 Port 2 x USB (Universal Serial Bus) 2.0 Port 1 x HDMI Connector 1 x DVI Connector 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 1 x USB (Universal Serial Bus) 3.0 Header 2 x USB (Universal Serial Bus) 2.0 Header 1 x SATA3 6 Gb/s Connector 5 x SATA2 3 Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header 1 x CIR Header DIMENSION Micro ATX Form Factor Dimension: 24.4cm x 22cm (W x L ) OS SUPPORT Support Windows XP / Vista / 7 FEATURES Supports BIO-Remote 2 Supports BIO-Remote Windows 7 Compatible Supports 100% Solid capacitor Supports Charger Booster Supports BIOS Online Update
...

AMD FX-9830P Processor Supports AMD Radeon™ R7 Graphics Supports 2 DIMM of DDR4 2400/2133/1866 up to 32GB maximum capacity Supports M.2 M Key (16 Gb/s) Connector Supports USB (Universal Serial Bus) 3.2 Gen 1 Support HDMI 4K resolution AMD FX-9830P Quad-Core APU The FX-9830P packs a powerful Bristol Ridge architecture-based quad-core processor with an integrated AMD Radeon R7 Graphics for superb processing performance, power efficiency & game-ready graphics. HDMI 4K2K The new 4K2K resolution enables high-definition image display with four times the resolution of full HD, 4K2K display is faithfully express bright, highly detailed content that fills the entire screen with lifelike images. Connectivity with PCs via a single HDMI cable for displaying 4K2K data. DX12 Direct X 12 introduces the next version of Direct 3D, the graphics API at the heart of Direct X. Direct 3D is one of the most critical pieces of a game or game engine, & weve redesigned it to be faster & more efficient than ever before. Direct 3D 12 enables richer scenes, more objects, & full utilization of modern GPU hardware. PCI-e M.2 16 Gb/s PCIe M.2 16 Gb/s is the latest storage interface, it delivers the highest bandwidth & lower latency. Its 1.6 times faster compared with PCIe M.2 10 Gb/s. Dual DDR4 The primary advantages of DDR4 over DDR3, include higher module density, lower voltage requirements, coupled with higher data transfer rate. USB (Universal Serial Bus) 3.2 Gen 1 Type-A USB (Universal Serial Bus) 3.2 Gen 1 delivers a compelling performance boosts & can be used to connect multiple devices without worrying about compatibility. It is capable of data transfer speeds up to 5 Gbps & backwards compatible with all existing USB (Universal Serial Bus) products. ...

Socket LGA 775 Supports Intel Core 2 Quad/ Core 2 Duo/ Pentium Dual-Core/ Celeron Dual-Core/ Celeron 400 Series Processor Supports FSB 800/1066/1333 M Hz Chipset Intel G41 / ICH7 CPU SUPPORT Intel Core™2 Quad Processor Intel Core™2 Duo Processor Intel Pentium Dual-Core Processor Intel Celeron Dual-Core Processor Intel Celeron Processor 400 Sequence Maximum CPU TDP (Thermal Design Power): 95 Watt FSB Support FSB 800/1066/1333 M Hz MEMORY Support Dual Channel DDR2 667/800/1066 (OC) MHz 2 x DDR2 DIMM Memory Slot Max. Supports up to 8GB Memory EXPANSION SLOT 2 x PCI Slots 1 x PCI-E x 16 Slot STORAGE 4 x SATA2 3 Gb/s Connector 1 x IDE Connector USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8102EL
- 10/100 Controller INTEGRATED VIDEO Integrated Intel Graphics Media Accelerator X4500. (Intel X4500) Pixel Shader 4.0, Direct X 10 Supports RGB with max. resolution 2048 x 1536@75 Hz Max. shared memory 1759MB * * The Max shared memory size will be available only when 4GB memory or more installed on Motherboard under the 64-bit OS. CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 2.0 Port 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA2 3 Gb/s Connector 1 x IDE Connector 1 x Floppy Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header DIMENSION Micro ATX Form Factor Dimension: 23.5cm X 17.9cm (W x L) OS SUPPORT Support Windows XP / Vista / 7
...

Socket LGA 775 Supports Intel Core 2 Quad/ Core 2 Duo/ Pentium Dual-Core/ Celeron Dual-Core/ Celeron 400 Series Processor Supports FSB 533/800/1066/1333 M Hz Supports BIO-Remote 2 Technology Supports Charger Booster Technology Specifications Chipset Intel G41 / ICH7 CPU SUPPORT Intel Core™2 Quad Processor Intel Core™2 Duo Processor Intel Pentium Dual-Core Processor Intel Celeron Dual-Core Processor Intel Celeron Processor 400 Sequence Maximum CPU TDP (Thermal Design Power): 95 Watt FSB Support FSB 533/800/1066/1333 M Hz MEMORY Support Dual Channel DDR2 667/800/1066 (OC) MHz 2 x DDR2 DIMM Memory Slot Max. Supports up to 8GB Memory EXPANSION SLOT 1 x PCI-E x 16 Slot 2 x PCI Slot STORAGE 4 x SATA2 Connector 1 x IDE Connector USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8102EL
- 10/100 Controller INTEGRATED VIDEO Intel Graphics Media Accelerator X4500. Support RGB with max. resolution 2048 x 1536@75 Hz Max. shared memory 1759MB (DVMT) * Supports DX10 * The Max shared memory size will be available only when 4GB memory or more installed on Motherboard under the 64-bit OS. CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 2.0 Port 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA2 3 Gb/s Connector 1 x IDE Connector 1 x Floppy Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU FAN Header 1 x System FAN Header 1 x Serial Header DIMENSION Micro ATX Form Factor Dimension: 23.5cm X 17.9cm (W x L ) OS SUPPORT Support Windows XP / Vista / 7 / 8 FEATURES Windows 8 Ready Supports Solid capacitor Supports BIOS-Flasher
...

Chipset Intel G41 / ICH7 CPU SUPPORT Intel Core„¢2 Quad Processor Intel Core„¢2 Duo Processor Intel Pentium Dual-Core Processor Intel Celeron Dual-Core Processor Intel Celeron Processor 400 Sequence Maximum CPU TDP (Thermal Design Power): 95 Watt FSB Support FSB 533/800/1066/1333 M Hz MEMORY Support Dual Channel DDR3 800/1066/1333 (OC) MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 8GB Memory Note: FSB800 CPU only support DDR3-800 EXPANSION SLOT 1 x PCI-E x 16 Slot 2 x PCI Slots STORAGE 4 x SATA2 Connector 1 x IDE Connector USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Realtek RTL8105T
- 10/100 Controller INTEGRATED VIDEO Intel Graphics Media Accelerator X4500. Supports RGB with max. resolution 2048 x 1536@75 Hz Max. shared memory 1759MB * Supports DX10 CODEC Realtek ALC662 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 2.0 Port 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector INTERNAL I/O 1 x Printer Header 2 x USB (Universal Serial Bus) 2.0 Header 4 x SATA2 3 Gb/s Connector
...

Socket LGA 775 Supported Intel Core 2 Quad/ Core 2 Duo/ Pentium Dual-Core/ Celeron Dual-Core/ Celeron D/ Celeron 400 Series Processor Supported FSB 800/1066/1333 M Hz Supported 2 DIMM of DDR3 1333/1066/800 M Hz Chipset Intel G41 / ICH7 CPU Support Intel Core 2 Quad Processor Intel Core 2 Duo Processor Intel Pentium Dual-Core Processor Intel Celeron Dual-Core Processor Intel Celeron D Processor Intel Celeron Processor 400 Sequence Maximum CPU TDP (Thermal Design Power): 95 Watt FSB Support FSB 1333/1066/800/533 M Hz Memory Support Dual Channel DDR3 1333 (OC)/1066/800 MHz 2 x DDR3 DIMM Memory Slot Max. Supports up to 8GB Memory Note: FSB800 CPU only support DDR3-800 Expansion slots 1 x PCI Slots 1 x PCI-E x 1 Slot 1 x PCI-E x 16 Slot Storage 2 x SATA2 3 Gb/s Connector 1 x IDE Connector USB (Universal Serial Bus) 4 x USB (Universal Serial Bus) 2.0 Port 2 x USB (Universal Serial Bus) 2.0 Header LAN Atheros AR8158
- 10/100 Controller Integrated Video Integrated Intel Graphics Media Accelerator X4500. (Intel X4500) Pixel Shader 4.0, Direct X 10 Supports RGB with max. resolution 2048 x 1536@75 Hz Max. shared memory 1759MB * * The Max shared memory size will be available only when 4GB memory or more installed on Motherboard under the 64-bit OS. Audio VIA VT1708B 6-Channel HD Audio REAR I/O 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB (Universal Serial Bus) 2.0 Port 1 x VGA Port 1 x RJ-45 Port 3 x Audio Connector Internal I/O 1 x Printer Header 2 x USB (Universal Serial Bus) 2.0 Header 2 x SATA2 3 Gb/s Connector 1 x IDE Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU FAN Header 1 x System FAN Header

Dimensions Micro ATX Form Factor Dimension: 22.5cm x 17cm (W x L ) OS Support Support Windows 2000 / XP / Vista / 7


...
