The VE803 HDMI USB (Universal Serial Bus) Extender extends an HDMI signal up to 60 meters from the HDMI source using two Cat 5e cables. It is capable of sending 1080i signals up to 60 meters & 1080p signals up to 40 meters. The VE803 is equipped with USB (Universal Serial Bus) connectors which allow you to extend any USB (Universal Serial Bus) device between the units. The USB (Universal Serial Bus) feature also provides support for touch panel control, allowing you to control the local HDMI source device from the remote display, or control the remote display through the local unit. ...

The VE803 HDMI USB (Universal Serial Bus) Extender extends an HDMI signal up to 60 meters from the HDMI source using two Cat 5e cables. It is capable of sending 1080i signals up to 60 meters & 1080p signals up to 40 meters. The VE803 is equipped with USB (Universal Serial Bus) connectors which allow you to extend any USB (Universal Serial Bus) device between the units. The USB (Universal Serial Bus) feature also provides support for touch panel control, allowing you to control the local HDMI source device from the remote display, or control the remote display through the local unit. The VE803 is ideal for transportation centers, medical facilities, shopping malls or anywhere touch panel control or a kiosk is required. For flexibility & convenience, the VE803 local unit can be powered via the USB (Universal Serial Bus) cable when connected to an appropriate source device. The VE803 is HDCP compliant, providing an easy & ideal HDMI extender solution for any application.
- Uses two Cat 5e cables to connect the local & the remote units
- Extends 1080p by 40m; extend 1080i by 60m
- Superior video quality – HDTV resolutions of 480p, 720p, 1080i, 1080p (1920 x 1080), VGA, SVGA, XGA, SXGA, UXGA & WUXGA (1920 x 1200)
- Supports USB (Universal Serial Bus) touch panel
- 8 segment equalization adjustment switch optimizes display quality
- Support Dolby True HD & DTS HD Master Audio
- Built-in 8KV/15KV ESD protection
- Transparent USB (Universal Serial Bus) Support – supports all USB (Universal Serial Bus) 2.0 full speed device (up to 12 Mbps)
- Supports wide screen formats
- HDMI (3D, Deep Color); HDCP compatible – signaling rates up to 2.25 Gbits
- Powered local unit via USB (Universal Serial Bus) cable










...

The ATEN VE811 HDMI HDBase T Extender guarantees the optimum HDMI connection up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. The VE811 meets HDMI

Specification features including 3D, Deep Color, HD lossless audio formats & CEC pass-through. It supports Dolby Digital 5.1, DTS HD audio & video signals at resolutions up to 4K. In addition, the VE811 supports long reach mode, providing an effective means for extending HDMI signals up to 150m over a single Cat 5e/6 cable. Pushing the technology & design to the limit, the compact design makes the VE811 easy to mount in any location. Engineered for today’s digital trends, the VE811 is ideal for meeting rooms, or any setting that requires high quality HDMI video to be extended for great distances.

...

The VE812 HDMI over Single Cat 5 Extender enables an HDMI display to be located up to 100 meters away from the source device. It can conveniently be extended using only one Cat 5e cable, which is cost-effective. The VE812 not only supports HDMI (3D, Deep Color ) but also Ultra HD (4k x 2k) & is HDCP compatible. Furthermore remote EDID pass-through ensures optimum video quality for your HDMI display. The VE812 is perfect for the meeting room, home theater or any installation that needs long distance transmission & superior video quality. ...

The VE813A HDMI HDBase T Extender is an HDMI & USB (Universal Serial Bus) Extender that supports HDBase T & patented Extreme USB technology. The VE813A can extend HDMI & USB (Universal Serial Bus) 2.0 signal up to 100 meters from the HDMI source using a single Ethernet cable. The VE813A supports HDMI features such as 3D, Deep Color, 4K, CEC & HDCP. It is equipped with USB (Universal Serial Bus) connectors that provide touch panel control & file transfer functionality. The extender is also great for synchronizing files & folders between portable & desktop computers. The superior display capability makes VE813A ideal for medical imaging & digital signage. Implements HDBase T extension technology using only one Cat 5e / 6 / 6a cable to connect the transmitter & receiver Extreme USB
- supports transparent USB (Universal Serial Bus) 2.0 signals & true plug-&-play (no software or drivers required) USB (Universal Serial Bus) 2.0 Support* – connects devices such as keyboard, mouse, flash drive, printer, touch panel & other USB (Universal Serial Bus) devices which require moderate amounts of bandwidth Supports Dolby True HD & DTS HD Master Audio
...

The VS0202 Video Matrix Switch allows video & audio from 2 computers to be routed to 2 monitors, projectors & speakers. Ideal for presentations & applications where information from multiple computers is being delivered to multiple destinations. Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

The VS0204 Video Matrix Switch allows video & audio from 2 computers to be routed to 4 monitors, projectors & speakers. Ideal for presentations & applications where information from multiple computers is being delivered to multiple destinations. Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

The VS0404 Video Matrix Switch allows video & audio from 4 computers to be routed to 4 monitors, projectors & speakers. Ideal for presentations & applications where information from multiple computers is being delivered to multiple destinations. The VS0404 is also a signal booster. It means that you can extend the signal transfer distance up about 210 feet with excellent video quality. To provide more outputs, VS0404 can be cascaded with regular video splitters for various applications. VS0404 is ideal for presentations & applications where information from multiple computers is being delivered to multiple destinations. Please note: networking components such as switches, routers, UPS & wireless devices require that speeds & standards be consistent throughout the network to gain optimum performance. To avoid compatibility clashes or for advice, please contact us on solutions@ebuyer.com. ...

The VM0202H is a 2 X 2 HDMI Matrix Switch that meets HDMI

Specification features including 3D, Deep Color up to 12-

...

The VM5808H 8 x 8 HDMI Matrix Switch is a distinct HDMI solution that offers an easy & affordable way to route any of 8 HDMI video sources to any of 8 HDMI displays, with a quick view of all port connections via the front panel LCD. The VM5808H

Includes:: seamless switching that employs a FPGA matrix architecture that ensures continuous video streams, real-time control & stable signal transmissions. With a built in high-performance scaler, the VM5808H easily converts various input resolutions into various output display resolutions, giving viewers the best video & picture quality across all displays. The switch integrates video wall functionality with an easy to use web GUI that lets you create 16 connection profiles that can be customized into different video wall layouts. The VM5808H is an ideal solution for applications that require multiple HDMI displays with multiple HDMI sources to be conveniently setup in multiple locations, such as for stage presentations, competitions, control centers, & installations that require real-time reports. Connects any of 8 HDMI sources to any of 8 HDMI displays Seamless Switch™ – ATEN FPGA design unifies video formats to provide continuous video streams, real-time switching & stable signal transmissions* HDMI (3D, Deep color); HDCP 1.4 compatible Multiple Control Methods – system management via front-panel pushbuttons, IR, RS-232 & Ethernet (Telnet / Web GUI) connections

...
