2-port KVM switch with USB (Universal Serial Bus) 2.0 support & 2.1 surround sound audio
- One console controls two computers &
...

4-port KVM switch with USB (Universal Serial Bus) 2.0 support & 2.1 surround sound audio
- One console controls four computers
...

CS1742 2 Port KVM Switch integrates functions of video signal dual output & USB (Universal Serial Bus) KVM switches. It allows a computer with dual-screen support to pair with two VGA/SVGA/ Multisync displays via a USB (Universal Serial Bus) keyboard & mouse. Furthermore, CS1742 provides 2 USB (Universal Serial Bus) ports, allowing each server to share any USB (Universal Serial Bus) peripheral device that is connected to this HUB. Allows one USB (Universal Serial Bus) keyboard, USB (Universal Serial Bus) mouse, speakers, microphone & two displays to control two dual display computers Superior video quality
- up to 2048 x 1536; DDC2B Computer selection via front panel pushbuttons & hotkeys OS Support: Windows 2000, Windows XP, Windows Vista, LINUX, Mac, Sun & Free BSD
...

CS1744 KVM Switch integrates functions of video signal dual output & USB (Universal Serial Bus) KVM switches. It allows a computer with dual-screen support to pair with two VGA/SVGA/ Multisync displays via a USB (Universal Serial Bus) keyboard & mouse. Furthermore, CS1744 provides 1 USB (Universal Serial Bus) port on each of the front & rear panels, allowing each server to share any USB (Universal Serial Bus) peripheral device that is connected to this HUB. Allows one USB (Universal Serial Bus) keyboard, USB (Universal Serial Bus) mouse, speakers, microphone & two displays to control two dual display computers Superior video quality
- up to 2048 x 1536; DDC2B Computer selection via front panel pushbuttons & hotkeys OS Support: Windows 2000, Windows XP, Windows Vista, LINUX, Mac, Sun & Free BSD
...

The Cubi Q™ CS1762A USB (Universal Serial Bus) 2.0 DVI KVMP™ Switch charts a revolutionary new direction in KVM (Keyboard, Video, Mouse) switch functionality by combining a 2 port KVM switch with a 2 port USB (Universal Serial Bus) 2.0 hub at the same time as it provides an interface for a digital monitor (DVI). In addition, the CS1762A comes with ATEN's new Video Dyna Sync™ technology, which optimizes display resolution, & power on detection, which means if one computer is powered off, the CS1762A will automatically switch to the next powered-on computer. As a KVM switch, it allows users to access two computers from a single USB (Universal Serial Bus) keyboard, USB (Universal Serial Bus) mouse, & monitor console. As a USB (Universal Serial Bus) 2.0 hub, it permits each computer to access any peripherals connected to the hub on a 'one computer at a time' basis. Superior video quality – 1920 x 1200 Computer selection via front panel pushbuttons, hotkeys, & mouse DVI digital & analog monitor support – fully compliant with the DVI specifications Multiplatform support – Windows, Linux, Mac, & Sun ...

The CS1768 8-port USB (Universal Serial Bus) DVI KVM Switch is a multi-purpose appliance that consolidates access & control of up to 8 computers from a single USB (Universal Serial Bus) keyboard, USB (Universal Serial Bus) mouse, & dual-monitor (DVI-I & VGA) console. It can be cascaded to three levels – allowing up to 73 CS1768s to control up to 512 computers – all from the original single console, making it ideal for industry-grade IT applications & management. In addition, the CS1768 features multi-display functionality, which enables the use of standard USB (Universal Serial Bus) cables to stack up to four switches for quad-displaying in multiple-monitor installations where each computer is fitted with multiple video cards. It means that you can contrast, analyse & monitor video output in convenient ways, substantially simplifying the working environment. Furthermore, the CS1768 comes with ATEN’s on-screen display (OSD) function, which can access any computer connected to the installation, it also offers OSD configuration back up/restore to save/ back up the OSD settings & restore them as needed. The CS1768 provides multimedia keyboard support & is audio enabled. Two microphones can provide audio input to each of the computers, & you can listen to the audio output of each computer on two sets of speakers (on a one-at-a-time basis). Superior video quality – 1920 x 1200 (Single Link DVI); 2048 x 1536 (VGA); DDC2B Supports a digital (DVI) or analog (VGA) video output; Cascadable to three levels – control up to 512 computers Broadcast mode – allows you to send commands from the console to all computers to perform operations simultaneously. Multi-Display feature – stack up to four CS1768 units & display video from up to four monitors (dual display / triple display / quad display) ...

One USB (Universal Serial Bus) console controls eight Dual Link DVI or VGA computers & two additional USB (Universal Serial Bus) 2.0 devices
- Supports both digital (DVI) & analog (VGA) video – mixed operation possible
- Cascadable to three levels – control up to 512 computers
- Multi-view feature – stack up to four CS1788 units & display video from up to four monitors (dual view / triple view / quad view)
- 2-port USB (Universal Serial Bus) 2.0 hub built in
- Fully compliant with the USB (Universal Serial Bus) 2.0

Specification
- Computer selection via front panel pushbuttons, hotkeys, & multilingual on-screen display (OSD)
- OSD Backup/ Restore feature – enables the administrator to back up the switch’s configuration & user profile information
- Two-level (Administrator/ User) password authorization for enhanced security protection
- Multilingual OSD supports English, German, Japanese, Traditional Chinese, Simplified Chinese, Spanish, Russian, & French
- Audio enabled – full bass response provides a rich experience for 2.1 channel surround sound Systems
- Console audio ports on front panel for easy access
- Multiplatform support – Windows, Linux, Mac, Sun
- Supports widescreen resolutions
- Superior video quality – 2560 x 1600 (Dual Link DVI); 2048 x 1536 (VGA); DDC2B
- Independent switching of KVM & USB (Universal Serial Bus) focus
- DVI digital & analog monitor support – fully compliant with the DVI specifications
- HDCP compatible
- Video Dyna Sync™ – exclusive ATEN technology eliminates boot-up display problems & optimizes resolution when switching between ports
- Console mouse port emulation/bypass feature supports most mouse drivers & multifunction mice
- Complete keyboard emulation for error-free booting
- Mac/ Sun keyboard support & emulation*
- Multilingual keyboard mapping – supports English (US), English (UK), French, German, Japanese, Korean, Traditional Chinese, & Spanish
- Auto Scan Mode for monitoring all computers
- Broadcast mode – means that you can send commands from the console to all computers to perform operations simultaneously
- Firmware upgradable


























...

The CS17916 16-port USB (Universal Serial Bus) HDMI KVM Switch is a multi-purpose appliance that consolidates access & control of up to 16 HDMI computers from a single USB (Universal Serial Bus) keyboard, USB (Universal Serial Bus) mouse, & monitor console. The CS17916 can be cascaded up to two levels – to control up to 256 computers – all from a single console. In addition the CS17916 features multi-display functionality, which enables the use of standard USB (Universal Serial Bus) cables to stack up to eight switches in a multi-display installation where each computer is fitted with multiple video cards. It means that you can contrast, analyse & monitor video output in convenient ways, substantially simplifying the working environment. Furthermore, the CS17916 comes with ATEN’s on-screen display (OSD) function, which can access any computer connected to the installation, it also offers OSD configuration backup/restore to save/back up the OSD settings & restore them as needed. The CS17916 provides multimedia keyboard support & is audio enabled. You can listen to the audio output of each computer on two sets of speakers (on a one at- a-time basis).
- One USB (Universal Serial Bus) console controls up to sixteen HDMI interface computers & two additional USB (Universal Serial Bus) 2.0 devices
- HDMI compatible
- Cascadable to two levels–control up to 256 computers
- Multi-Display feature – stack up to eight CS17916 units & display video from up to eight monitors (dual display/triple display/quad display/multi-display)
- 2-port USB (Universal Serial Bus) 2.0 hub built in
- Computer selection via front panel pushbuttons, hotkeys, & multilingual on-screen display (OSD)
- Independent switching of KVM & USB (Universal Serial Bus) focus
- OSD Backup/ Restore feature–enables the administrator to back up the switch’s configuration & user profile information
- Firmware upgradable
- Video Dyna Sync™ – exclusive ATEN technology eliminates boot-up display problems & optimizes resolution when switching between ports
- Superior video quality–supports up to 1080p / 1920 x 1200@60 Hz
- Supports widescreen resolutions
- Audio enabled–full bass response provides a rich experience for 2.1 channel surround sound systems
- Console audio ports on front panel for easy access
- Auto Scan Mode for monitoring all computers
- HDCP compatible
- Multiplatform support– Windows, Linux, Mac, Sun
- Console mouse port emulation/bypass feature supports most mouse drivers & multifunction mice
- Complete keyboard emulation for error-free booting
- Mac/ Sun keyboard support & emulation*1.2.
- Multilingual OSD supports English, German, Japanese, Traditional Chinese, Simplified Chinese, Spanish, Russian, & French
- Multilingual keyboard mapping – supports English (US), English (UK), German (GER.), German (SWISS), French, Hungarian, Italian, Japanese, Korean, Russian, Spanish, Swedish, Traditional Chinese, & Simplified Chinese





















...

With its unique design & innovative features, the Cubi Q™ CS1792 USB (Universal Serial Bus) 2.0 HDMI KVMP™ Switch provides both style & functionality for today's multimedia SOHO environment. Combining a 2-port switch with a 2-port USB (Universal Serial Bus) 2.0 hub, the CS1792 provides seamless HDMI signal switching between 2 PCs or other HDMI-enabled devices, such as gaming consoles, & allows users to share USB (Universal Serial Bus) peripherals from a single console. The CS1792 provides enhanced independent switching via front panel pushbuttons & keyboard hotkeys, & features Video Dyna Sync™ technology to ensure that HDMI display resolution is always optimized. With integrated digital audio, the CS1792 also allows users to experience high-definition sound, such as Dolby True HD & DTS HD Master Audio. Ideal for multimedia applications in the office, the Cubi Q™ CS1792 offers the ultimate in space-saving, streamlined KVM technology for the desktop. Superior video quality
- supports 480i, 480p, 720p, 1080i, & 1080p (HDTV)/1920 x 1200 (DVI) PC selection via pushbutton & hotkeys Video Dyna Sync™
- stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution Multiplatform support
- Windows, Linux, and Mac


...

- 4-port HDMI USB (Universal Serial Bus) 2.0 KVMP™ Switch
- One USB (Universal Serial Bus) console controls four HDMI-interface
...
