Asus Z170-WS Socket 1151 HDMI Display Port 8-channel Audio ATX Motherboard CPU: Intel Socket 1151 for 6th Generation Core i 7/ Core i 5/ Core i 3/ Pentium/ Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 * The Intel Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to www.asus.com for CPU support list Chipset
- Intel Z170 Memory 4 x DIMM, Max. 64GB, DDR4 3733 (O.C.)/3600 (O.C.)/3466 (O.C.)/3400 (O.C.)/3333 (O.C.)/3300 (O.C.)/3200 (O.C.)/3000 (O.C.)/2800 (O.C.)/2666 (O.C.)/2400 (O.C.)/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). Graphic Integrated Graphics Processor- Intel HD Graphics support Multi-VGA output support: HDMI/ Display Port ports
- Supports HDMI with max. resolution 4096 x 2160 @ 60 Hz / 4096 x 2160 @ 24 Hz*1
- Supports Display Port with max. resolution 4096 x 2304 @ 24 Hz / 4096 x 2304 @ 60 Hz *2 Maximum shared memory of 512 MB Supports Intel In Tru 3D, Quick Sync Video, Clear Video HD Technology, Insider™ Supports up to 2 displays simultaneously DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain up to 3 displays Multi-GPU Support Supports NVIDIA Quad-GPU SLI Technology Supports NVIDIA 4-Way SLI Technology Supports AMD Quad-GPU Cross Fire X Technology Supports AMD 4-Way Cross Fire X Technology Expansion Slots 4 x PCIe 3.0/2.0 x 16 (single at x 16, dual at x 16/x 16 mode, triple at x 16/x 8/x 8 mode or dual x 8/x 8/x 8/x 8 mode) 1 x PCIe 3.0 x 4 (max at x 4 mode) *3 Storage Intel Z170 chipset: 6 x SATA 6 Gb/s port (s), gray, 2 x M.2 x 4 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & PCIE mode)*4 1 x U.2 connector, *5 Support Raid 0, 1, 5, 10 Intel Rapid Storage Technology supports LAN Intel I219-LM, 1 x Gigabit LAN Controller (s) Intel I210-AT, 1 x Gigabit LAN Gigabit Intel LAN Connection- 802.3az Energy Efficient Ethernet (EEE) appliance ASUS Turbo LAN Utility Audio Realtek ALC1150 8-Channel High Definition Audio CODEC featuring Crystal Sound 3
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 112 d B SNR stereo playback output (Line-out at rear) & 104 d B SNR recording input (Line-in) Audio Feature :
- DTS Connect
- DTS Studio Sound
- Optical S/PDIF out port (s) at back panel
- BD Audio Layer Content Protection
- Audio Shielding: Ensures precision analog/digital separation & greatly reduced multi-lateral interference
- Audio amplifier: Provides the highest-quality sound for headphone & speakers
- Premium Japanese-made audio capacitors: Provide warm, natural & immersive sound with exceptional clarity & fidelity
- Top notch audio sensation delivers according to the audio configuration
- Absolute Pitch 192khz/24bit true BD lossless sound Separate layer for left & right track, ensuring both sound deliver equal quality USB (Universal Serial Bus) Ports Intel Z170 chipset: 5 x USB (Universal Serial Bus) 3.0/2.0 port (s) (1 vertical Type A Connector, 4 at mid-board) Intel Z170 chipset: 6 x USB (Universal Serial Bus) 2.0/1.1 port (s) (4 at back panel, black, 2 at mid-board) ASMedia USB (Universal Serial Bus) 3.0 Hub: 4 x USB (Universal Serial Bus) 3.0/2.0 port (s) (4 at back panel, blue) ASMedia USB (Universal Serial Bus) 3.1 controller: 1 x USB (Universal Serial Bus) 3.1/3.0/2.0 port (s) (1 at back panel, teal blue, Type-A) ASMedia USB (Universal Serial Bus) 3.1 controller: 1 x USB (Universal Serial Bus) 3.1/3.0/2.0 port (s) (1 at back panel, , Type-C, Reversible) Workstation Feature: 4 x PCIe x 16 slot (s) 12K hours Capacitors Pro Cool Power Connector Q-Code Logger Special Features OC Design
- ASUS PRO Clock Technology
- Full BCLK range for extreme overclocking performance 5-Way Optimization by Dual Intelligent Processors 5
- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 3, & Turbo App ASUS TPU :
- Auto Tuning
- GPU Boost
- TPU switch ASUS EPU :
- EPU
- EPU switch ASUS Digital Power Design :
- Industry leading Digital 8 + 4 + 2 Phase Power Design ASUS Exclusive Features :
- USB (Universal Serial Bus) BIOS Flashback
- Mem OK!
- Ai Charger
- Ai Charger+
- Anti-Surge
- Front Panel USB (Universal Serial Bus) 3.0 Support
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- USB (Universal Serial Bus) 3.1 Boost
- Turbo LAN
- Crystal Sound 3
- EZ XMP ASUS Exclusive Features Remote Entertainment
- Media Streamer ASUS Quiet Thermal Solution :
- Stylish Fanless Design Heat-pipe solution
- ASUS Fan Xpert 3 ASUS EZ DIY :
- Direct Key
- ASUS USB (Universal Serial Bus) BIOS Flashback
- ASUS UEFI BIOS EZ Mode
- Multi-language BIOS
- Push Notice ASUS Q-Design :
- ASUS Q-Shield
- ASUS Q-Code
- ASUS Q-LED (CPU, DRAM, VGA, HDD LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector Special Memory O.C. Design Overclocking Protection :
- ASUS C.P.R. (CPU Parameter Recall) Fan Xpert 3 Turbo APP Key Express Operating System Support Windows 10, 64bit Windows 8.1, 64bit Windows 7 Back I/O Ports 1 x Display Port 1 x HDMI 2 x LAN (RJ45) port (s) 1 x USB (Universal Serial Bus) 3.1 (teal blue) Type-A 1 x USB (Universal Serial Bus) 3.1 Type-C 4 x USB (Universal Serial Bus) 3.0 (blue) 4 x USB (Universal Serial Bus) 2.0 1 x Optical S/PDIF out 1 x USB (Universal Serial Bus) BIOS Flashback Button (s) 1 x Q-Code Logger button 1 x 8-channel Audio I/O Internal I/O Ports 1 x AAFP connector 2 x USB (Universal Serial Bus) 3.0 connector (s) support (s) additional 4 USB (Universal Serial Bus) 3.0 port (s) (19-pin) 1 x USB (Universal Serial Bus) 2.0 connector (s) support (s) additional 2 USB (Universal Serial Bus) 2.0 port (s) 2 x M.2 Socket 3 with M Key design, type 2242/2260/2280/22110 storage devices support (Supports both SATA & PCIE SSD) 6 x SATA 6 Gb/s connector (s) 1 x CPU Fan connector (s) (1 x 4 -pin, 4 -pin) 1 x CPU OPT Fan connector (s) (1 x 4 -pin, 4 -pin) 4 x Chassis Fan connector (s) (1 x 4 -pin, 4 -pin) 1 x S/PDIF out header (s) 1 x Thunderbolt header (s) 1 x 24-pin EATX 12 V Power connector 1 x 6-pin EATX 12 V_1 Power connector (s) 2 x 8-pin ATX Power connector 1 x EZ XMP switch 1 x System panel (s) (Q-Connector) 1 x 5-pin EXT_FAN (Extension Fan) connector 1 x DRCT header (s) 1 x Mem OK! button (s) 1 x TPU switch (es) 1 x EPU switch (es) 1 x Power-on button (s) 1 x Clear CMOS button (s) 1 x Water Pump header (4-pin) 1 x 14-1 pin TPM connector 1 x vertical type A USB (Universal Serial Bus) 3.0 connector 1 x U.2 connector BIOS: 128 Mb Flash ROM, UEFI AMI BIOS, Pn P, DMI3.0, Wf M2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, Crash Free BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 Print Screen & ASUS DRAM SPD (Serial Presence Detect) memory information Manageability
- Wf M 2.0, DMI 3.0, WOL by PME, PXE Support Disc Drivers ASUS Utilities EZ Update Anti-virus software (OEM version) Form Factor ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm ) Weight Color Box (5-in-1) Net Weight: 8.05kg Gross Weight: 11.8kg Bulk Pack (5-in-1) Net Weight: 6.2kg Gross Weight: 8.2kg

















































...

Features LGA1151 socket for 6th-gen Intel Core™ i 7 / Core i 5 / Core i 3, Pentium & Celeron Processors Dual DDR4 4000 (OC) support Supreme FX: Flawless audio that makes you part of the game Sonic Radar ll: Scan & detect your enemies to dominate Intel Gigabit Ethernet, LANGuard & Game First technologies: Top-speed protected networking 5-Way Optimization & Pro Clock technology: Easy & stable overclocking RAMCache: Speed up your game loads Gamers Guardian: Highly-durable components & smart DIY features 2x 2 Wi-Fi with MU-MIMO, USB (Universal Serial Bus) 3.1 Type-A & M.2: Ultra-speedy transfers for faster gaming Overview FLAWLESS AUDIO THAT MAKES YOU PART OF THE GAME! Be the best on the battlefield with Z170I Pro Gamings truly immersive Supreme FX audio & experience sound so alive with realism that it hands you the vital competitive edge needed to win. With near-lossless delivery & exclusive Sonic Radar II technology to pinpoint battlefield enemies before they spot you, Supreme FX sounds stupendous — & puts both your ears & frags in front of everyone else! Supreme FX Shielded audio, superior sound ASUS-exclusive Supreme FX technology delivers high-fidelity, near-lossless audio no matter how frantic your game becomes. The purity & stability of the remarkable 115d B signal-to-noise ratio (SNR) is assured, with a shielded design, electromagnetic-interference (EMI) cover & voltage-protected 5V power supply. Supreme FXs superior components, including the trusted Realtek ALC1150 codec, maximize acoustic performance & eliminate interference – so you hear only the very best from your gaming headset or speakers! Sonic Radar II Scan & detect to dominate! Sonic Radar II displays a stealthy overlay that shows what your opponents & teammates are up to on the battlefield, all managed via a simple control panel & customizable game list. See the direction & origin of key in-game sounds, & practice your enemy-pinpointing skill, plus Audio Enhancement technology clarifies every last sound — so you hear the distant sound of enemy footsteps & become the hunter, not the hunted! TOP-SPEED PROTECTED NETWORKING Only the quickest shot survive, so Z170I Pro Gaming banishes lag — letting you annihilate your foes as fast as your trigger finger! Our engineers pack in only the best networking technology, including tournament-level Intel Gigabit Ethernet & ASUS-exclusive LANGuard & Game First IV to keep your connection fast, so always fire first & watch your enemies fall. DDR4 overclocking strength in numbers Now you can drive DDR4 memory up to 4000 (OC) at one DIMM per channel — & that means the best-ever gaming performance from your Z170I Pro Gaming! Exceptional engineering has created optimized trace layouts, providing superb memory-overclocking capabilities on mini-ITX.

Specification CPU Intel Socket 1151 for 6th Generation Core™ i 7/ Core™ i 5/ Core™ i 3/ Pentium/ Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 * The Intel Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to www.asus.com for CPU support list Chipset Intel Z170 Memory 2 x DIMM, Max. 32GB, DDR4 3400 (O.C.)/3333 (O.C.)/3200 (O.C.)/3100 (O.C.)/3000 (O.C.)/2933 (O.C.)/2800 (O.C.)/2666 (O.C.)/2600 (O.C.)/2400 (O.C.)/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). Graphic Integrated Graphics Processor- Intel HD Graphics support Multi-VGA output support: HDMI/ Display Port ports
- Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
- Supports Display Port with max. resolution 4096 x 2304 @ 60 Hz Maximum shared memory of 1024 MB Supports Intel In Tru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™ Expansion Slots 1 x PCIe 3.0/2.0 x 16 Storage Support Raid 0, 1, 5, 10 Intel Rapid Storage Technology supports 1 x SATA Express port, Compatible with 2 x SATA 6.0 Gb/s ports 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)*1 2 x SATA 6 Gb/s port (s) Supports Intel Smart Response Technology*2 LAN Intel I219V, 1 x Gigabit LAN Controller (s), Game First technology Anti-surge LANGuard Wireless Data Network Wi-Fi 802.11 a/b/g/n/ac Supports dual band frequency 2.4/5 GHz Support ASUS Wi-Fi Go! Utility Bluetooth Bluetooth V4.1 Audio Supreme FX 8-Channel High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 115 d B SNR stereo playback output Audio Feature :
- Supreme FX Shielding™ Technology
- Optical S/PDIF out port (s) at back panel
- Sonic Radar II USB (Universal Serial Bus) Ports ASMedia USB (Universal Serial Bus) 3.1 controller: 2 x USB (Universal Serial Bus) 3.1 Gen 2 port (s) (Type-A) Intel Z170 chipset: 6 x USB (Universal Serial Bus) 3.1 Gen 1 port (s) (4 at back panel, blue, 2 at mid-board) Intel Z170 chipset: 4 x USB (Universal Serial Bus) 2.0/1.1 port (s) (2 at back panel, black, 2 at mid-board) Special Features ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 :
- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 2+, & Turbo App Gamers Guardian:
- ESD Guards on LAN, Audio, KBMS & USB3.0/2.0 ports
- DRAM Overcurrent Protection
- Stainless Steel Back I/O
- Highly Durable Components
- DIGI+ VRM ASUS TPU :
- Auto Tuning
- Turbo V
- GPU Boost ASUS EPU :
- EPU ASUS Exclusive Features :
- AI Suite 3
- Ai Charger+
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- USB (Universal Serial Bus) 3.1 Boost
- Disk Unlocker ASUS Quiet Thermal Solution :
- Stylish Fanless Design Heat-sink solution
- ASUS Fan Xpert 2+ ASUS EZ DIY :
- ASUS Crash Free BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- Push Notice ASUS Q-Design :
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-DIMM
- ASUS Q-Connector Media Streamer RAMCache Operating System Support Windows 10, 64bit Windows 8.1, 64bit Windows 7, 32bit/64bit Back I/O Ports 1 x PS/2 keyboard/mouse combo port (s) 1 x Display Port 1 x HDMI 1 x LAN (RJ45) port (s) 2 x USB (Universal Serial Bus) 3.1 Gen 2 (red) Type-A 4 x USB (Universal Serial Bus) 3.1 Gen 1 2 x USB (Universal Serial Bus) 2.0 1 x Optical S/PDIF out 5 x Audio jack (s) 2 x Wi-Fi antenna port (s) Internal I/O 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (s) support (s) additional 2 USB (Universal Serial Bus) 3.1 Gen 1 port (s) (19-pin) 1 x USB (Universal Serial Bus) 2.0 connector (s) support (s) additional 2 USB (Universal Serial Bus) 2.0 port (s) 1 x SATA Express connector: gray, Compatible with 2 x SATA 6.0 Gb/s ports 1 x M.2 Socket 3 with M Key design, type 2242/2260/2280 storage devices support (Supports both SATA & PCIE SSD) 2 x SATA 6 Gb/s connector (s) 1 x CPU Fan connector (s) (1 x 4 -pin) 2 x Chassis Fan connector (s) (2 x 4 -pin) 1 x 24-pin EATX Power connector (s) 1 x 8-pin ATX 12V Power connector (s) 1 x Front panel audio connector (s) (AAFP) 1 x System panel (s) 1 x Clear CMOS jumper (s) 1 x 14-1 pin TPM connector Accessories Users manual ASUS Q-Shield M.2 2242 mounting kit 4 x SATA 6 Gb/s cable (s) 1 x M.2 Screw Package 1 x CPU installation tool 1 x Supporting DVD 1 x 12 in 1 Cable Label (s) BIOS 128 Mb Flash ROM, UEFI AMI BIOS, Pn P, DMI3.0, Wf M2.0, SM BIOS 3.0 ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, Crash Free BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 Print Screen, & ASUS DRAM SPD (Serial Presence Detect) memory information Manageability Wf M 2.0, DMI 3.0, WOL by PME, PXE Support Disc Drivers ASUS Utilities ASUS EZ Update Anti-virus software (OEM version) Form Factor Mini ITX Form Factor 6.7 inch x 6.7 inch (17 cm x 17 cm ) Note *1: For a 2242 storage device, use the bundled 2242 mounting kit. *2: These functions will work depending on the CPU installed.

































...

Asus Z170M-E D3 Socket 1151 VGA DVI-D HDMI 8-Channel HD Audio u ATX Motherboard Specifications CPU Intel Socket 1151 for 6th Generation Core i 7/ Core i 5/ Core i 3/ Pentium/ Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 * The Intel Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to www.asus.com for CPU support list Chipset: Intel Z170 Memory: 4 x DIMM, Max. 64GB, DDR3 3100 (O.C.)/2933 (O.C.)/2800 (O.C.)/2666 (O.C.)/2400 (O.C.)/2200 (O.C.)/2133 (O.C.)/2000 (O.C.)/1866 (O.C.)/1600/1333 MHz Non-ECC, Un-buffered Memory Supports Intel Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). Graphic: Integrated Graphics Processor- Intel HD Graphics support Multi-VGA output support: HDMI/DVI-D/RGB ports Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz Supports RGB with max. resolution 1920 x 1200 @ 60 Hz Maximum shared memory of 1024 MB Supports Intel In Tru 3D, Quick Sync Video, Clear Video HD Technology, Insider Supports up to 3 displays simultaneously Multi-GPU Support: Supports AMD Cross Fire X™ Technology Expansion Slots: 1 x PCIe 3.0/2.0 x 16 (x 16 mode, gray) 1 x PCIe 3.0/2.0 x 16 (max at x 4 mode, black) 1 x PCIe 3.0/2.0 x 1 1 x PCI Storage Intel Z170 chipset: 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode) 4 x SATA 6 Gb/s port (s), gray, Support Raid 0, 1, 5, 10 Supports Intel Smart Response Technology*1 LAN: Realtek RTL8111H, 1 x Gigabit LAN Controller (s) Audio Realtek ALC887-VD2 8-Channel High Definition Audio CODEC *2 Supports: Jack-detection, Front Panel Jack-retasking Audio Feature: Audio Shielding: Ensures precision analog/digital separation & greatly reduced multi-lateral interference Dedicated audio PCB layers: Separate layers for left & right channels to guard the quality of the sensitive audio signals Premium Japanese-made audio capacitors: Provide warm, natural & immersive sound with exceptional clarity & fidelity USB (Universal Serial Bus) Ports: Intel Z170 chipset: 8 x USB (Universal Serial Bus) 3.0/2.0 port (s) (4 at back panel, blue, 4 at mid-board) Intel Z170 chipset: 6 x USB (Universal Serial Bus) 2.0/1.1 port (s) (2 at back panel, black, 4 at mid-board) Special Features ASUS 5X Protection II: ASUS LANGuard
- 2.5X higher surge tolerance ASUS Overvoltage Protection
- World-class circuit-protecting power design ASUS DIGI+ VRM
- 7 Phase digital power design ASUS DRAM Overcurrent Protection
- Prevents damage from short circuits ASUS Stainless-Steel Back I/O
- 3X corrosion-resistance for greater durability ASUS EPU: EPU ASUS Exclusive Features: GPU Boost AI Suite 3 Ai Charger Anti-Surge Low EMI Solution USB (Universal Serial Bus) 3.0 Boost Disk Unlocker Mobo Connect PC Cleaner ASUS Quiet Thermal Solution: Stylish Fanless Design Heat-sink solution ASUS Fan Xpert 2+ ASUS EZ DIY: ASUS O.C. Tuner ASUS Crash Free BIOS 3 ASUS EZ Flash 3 ASUS UEFI BIOS EZ Mode Push Notice ASUS Q-Design: ASUS Q-Slot ASUS Q-DIMM Media Streamer Operating System Support: Windows 10, 64bit Windows 8.1, 64bit Windows 7, 32bit/64bit *3 Back I/O Ports 1 x PS/2 keyboard (violet) 1 x PS/2 mouse (green) 1 x DVI-D 1 x D-Sub 1 x HDMI 1 x LAN (RJ45) port (s) 4 x USB (Universal Serial Bus) 3.0 (blue) Type-A 2 x USB (Universal Serial Bus) 2.0 3 x Audio jack (s) Internal I/O 2 x USB (Universal Serial Bus) 3.0 connector (s) support (s) additional 4 USB (Universal Serial Bus) 3.0 port (s) (19-pin) 2 x USB (Universal Serial Bus) 2.0 connector (s) support (s) additional 4 USB (Universal Serial Bus) 2.0 port (s) 1 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices 1 x LPT header 1 x COM port (s) connector (s) 4 x SATA 6 Gb/s connector (s) 1 x CPU Fan connector (s) (1 x 4 -pin) 2 x Chassis Fan connector (s) (2 x 4 -pin) 1 x S/PDIF out header (s) 1 x 24-pin EATX Power connector (s) 1 x 8-pin ATX 12V Power connector (s) 1 x Front panel audio connector (s) (AAFP) 1 x System panel (s) 1 x Clear CMOS jumper (s) 1 x 14-1 pin TPM connector BIOS: 128 Mb Flash ROM, UEFI AMI BIOS, Pn P, DMI3.0, Wf M2.0, SM BIOS 3.0 ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, Crash Free BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 Print Screen, & ASUS DRAM SPD (Serial Presence Detect) memory information Manageability: Wf M 2.0, DMI 3.0, WOL by PME, PXE Support Disc: Drivers ASUS Utilities ASUS EZ Update Anti-virus software (OEM version) Form Factor: u ATX Form Factor 9.6 inch x 8.8 inch (24.4 cm x 22.4 cm )




...

Asus Z170M-PLUS Socket LGA1151 DVI-D HDMI 8 Channel Audio Micro-ATX Motherboard CPU LGA1151 socket for 6th Generation Intel Core i 7/ i 5/ i 3/ Pentium/ Celeron Processors Supports 14nm CPU Supports Intel Turbo Boost Technology 2.0* * The Intel Turbo Boost Technology 2.0 support depends on the CPU types. Chipset Intel Z170 Express Chipset Memory 4 x DIMM, max. 64GB, DDR4 3466 (O.C.)/3400 (O.C.)/3333 (O.C.)/3300 (O.C.)/3200 (O.C.)/3000 (O.C.)/2800 (O.C.)*/2666 (O.C.)*/2400 (O.C.)*/2133 MHz, non-ECC, un-buffered memory Dual channel memory architecture Supports Intel Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. Refer to Asus website for the Memory QVL (Qualified Vendors List) Expansion Slots 1 x PCI Express 3.0/2.0 x 16 slot (at x 16) 1 x PCI Express 3.0/2.0 x 16 slot (max. at x 4 mode, compatible with PCIe x 1 & x 4 devices) 2 x PCI Express 3.0/2.0 x 1 slots Multi-GPU Support Supports AMD Cross Fire X Technology VGA Integrated Graphics Processor Intel HD Graphics support Multi-VGA output support: HDMI/DVI-D/RGB port Supports HDMI with max. resolution 4096 x 2160@24 Hz / 2560 x 1600@60 Hz Supports DVI-D with max. resolution of 1920 x 1200 @60 Hz Supports RGB with max. resolution 1920 x 1200@60 Hz Supports Intel In Tru™ 3D/ Quick Sync Video/ Clear Video HD Technology/ Insider™ Supports up to 3 displays simultaneously Maximum shared memory of 512MB Storage Intel Z170 Express Chipset with RAID 0, 1, 5, 10 & Intel Rapid Storage Technology 14 support 1 x SATA Express port (compatible with 2 x SATA 6.0 Gb/s ports) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode) 6 x SATA 6.0 Gb/s ports (gray, 2 from SATA Express) Supports Intel Smart Response Technology* * These functions will work depending on the CPU installed. LAN Intel I219-V Gigabit LAN Dual interconnect between the integrated Media Access Controller (MAC) & physical layer (PHY) Audio Realtek ALC887 8-channel high definition audio CODEC Breathing Audio LED
- Ensures precision analog/digital separation & greatly reduced multi-lateral interference, with a gorgeous illuminated trace path Audio Shielding: Ensures precision analog/digital separation & greatly reduces multi-lateral interference Dedicated audio PCB layers: Separate layers for left & right channels to guard the quality of the sensitive audio signals Premium Japanese-made audio capacitors: Provide warm, natural & immersive sound with exceptional clarity & fidelity. Supports jack-detection & front panel jack-retasking USB (Universal Serial Bus) Intel Z170 Express Chipset- supports ASUS USB (Universal Serial Bus) 3.0 Boost 6 x USB (Universal Serial Bus) 3.0/2.0 ports (4 ports @mid-board; 2 ports @back panel, blue, Type A) 1 x USB (Universal Serial Bus) 5 Gb/s Type C port support 3A power output 6 x USB (Universal Serial Bus) 2.0/1.1 ports (4 ports @mid-board; 2 ports @back panel) Back Panel I/O Ports 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x HDMI port 1 x DVI-D port 1 x RGB port 1 x LAN (RJ45) ports 2 x USB (Universal Serial Bus) 3.0/2.0 ports (blue, Type A) 1 x USB (Universal Serial Bus) 5 Gb/s Type C port 2 x USB (Universal Serial Bus) 2.0/1.1 ports 3-Jack 8-Channel Audio I/O ports Internal I/O Connectors 2 x USB (Universal Serial Bus) 3.0/2.0 connectors support additional 4 USB (Universal Serial Bus) ports (19-pin) 2 x USB (Universal Serial Bus) 2.0/1/1 connectors support additional 4 USB (Universal Serial Bus) ports 1 x SATA Express connector (compatible with 2 x SATA 6.0 Gb/s ports) 6 x SATA 6.0 Gb/s connectors (gray) 1 x M.2 Socket 3 1 x 4-pin CPU Fan connector for both 3-pin (DC mode) & 4-pin (PWM mode) CPU coolers control* 2 x 4-pin Chassis Fan connectors for 3-pin (DC mode) & 4-pin (PWM mode) coolers control 1 x Front panel audio connector 1 x System panel connector 1 x S/PDIF out header 1 x 24-pin EATX Power connector 1 x 8-pin EATX 12V Power connector 1 x COM header 1 x LPT connector 1 x Clear CMOS jumper * The CPU Q-Fan control setting is set as default in Auto mode for detecting the type of CPU fan installed & switches to the control mode automatically. Operating System Support Windows 10 (64-bit) Windows 8.1 (64-bit) Windows 7 (64-bit/32-bit) Form Factor Micro-ATX Form Factor, 9.6”x 8.95” (24.4cm x 22.7cm)
...

Features LGA1151 socket for 8th Gen Intel Core™ desktop processors. Leading personalisation: ASUS-exclusive Aura Sync RGB lighting, including headers for both standard & addressable RGB strips. Onboard M.2 Heatsink: Cools your M.2 drive, delivering consistent storage performance & enhanced reliability. Gaming Audio: Supreme FX & Sonic Studio III – High fidelity audio that draws you deeper into the action. All the connectivity you need: Intel Gigabit Ethernet, LANGuard, 2x 2 802.11ac Wi-Fi, Dual M.2, USB (Universal Serial Bus) 3.1 Gen 2 Type-A & Type-C™ connectors. 5-Way Optimisation: Automated system-wide tuning, providing overclocking & cooling profiles that are tailor made for your rig. Gaming durability: ROG Armour, pre-mounted I/O shield & premium components throughout. Overview Drawing from a heritage that spans more than a decade, the latest incarnation of the Maximus series augments Intels Z370 chipset with all the enhancements that enthusiasts crave. Each model sports a unique blend of features to cater to a distinct audience, yet the core ROG DNA ripples through the entire lineup. From overclocking & cooling options to satiate die-hard fanatics, to clean, refined aesthetics that are tastefully accented by RGB lighting, Maximus X-series motherboards bring the octane to your build. AURA SYNC ASUS Aura offers full RGB lighting control with a variety of functional presets for the built-in RGB LEDs as well as strips connected to the onboard RGB headers. & it can all be synced with an ever-growing portfolio of Aura-capable ASUS hardware. RGB LIGHTING PERFECTED Maximus X Code features a pair of onboard 5050 RGB headers & a pair of addressable headers that can be connected to compatible lighting strips, fans, coolers, & PC cases, creating a new world of illumination possibilities. SONIC STUDIO III Sonic Studio supports HRTF-based (head-related transfer function*) virtual surround for VR headsets, casting an immersive aural landscape that draws you deeper into the action. The intuitive Sonic Studio interface also offers a range of EQ options, allowing you to tailor acoustics to suit personal preferences or the characteristics of your headset.

Specification CPU Intel Socket 1151 for 8th Generation Core™ Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 * The Intel Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to www.asus.com for CPU support list Chipset Intel Z370 Memory 4 x DIMM, Max. 64GB, DDR4 4133 (O.C.)/4000 (O.C.)/3866 (O.C.)/3733 (O.C.)/3600 (O.C.)/3466 (O.C.)/3400 (O.C.)/3333 (O.C.)/3300 (O.C.)/3200 (O.C.)/3000 (O.C.)/2800 (O.C.)/2666 (O.C.)/2400 (O.C.)/2133 MHz Non-ECC, Un-buffered Memory * Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). Graphic Integrated Graphics Processor Multi-VGA output support: HDMI/ Display Port 1.2 ports
- Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
- Supports Display Port with max. resolution 4096 x 2304 @ 60 Hz Maximum shared memory of 1024 MB Multi-GPU Support Supports NVIDIA 2-Way SLI™ Technology Supports AMD 3-Way Cross Fire X™ Technology Expansion Slots 2 x PCIe 3.0/2.0 x 16 (x 16, x 8/x 8, or x 8/x 4+x 4) 1 x PCIe 3.0/2.0 x 16 (x 4 mode, black) *1 3 x PCIe 3.0/2.0 x 1 Storage Intel Z370 Chipset: 1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & PCIE mode)*2 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*3 6 x SATA 6 Gb/s port (s) Support Raid 0, 1, 5, 10 Supports Intel Smart Response Technology*4 Intel Rapid Storage Technology supports Intel Optane™ Memory Ready LAN Intel I219V Anti-surge LANGuard ROG Game First IV Wireless Data Network Wi-Fi 802.11 a/b/g/n/ac Supports dual band frequency 2.4/5 GHz Supports MU-MIMO Bluetooth Bluetooth V4.2 Audio ROG Supreme FX 8-Channel High Definition Audio CODEC S1220
- Impedance sense for front & rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 d B SNR stereo playback output & 113 d B SNR recording input
- Supreme FX Shielding Technology
- ESS ES9023P
- Supports up to 32-Bit/192k Hz playback *5 Audio Feature :
- Gold-plated jacks
- Optical S/PDIF out port (s) at back panel
- Sonic Radar III
- Sonic Studio III USB (Universal Serial Bus) Ports ASMedia USB (Universal Serial Bus) 3.1 Gen 2 controller: 1 x USB (Universal Serial Bus) 3.1 Gen 2 front panel connector port (s) ASMedia USB (Universal Serial Bus) 3.1 Gen 2 controller: 2 x USB (Universal Serial Bus) 3.1 Gen 2 port (s) (2 at back panel, black+red, Type-A + USB (Universal Serial Bus) Type-CTM) Intel Z370 Chipset: 6 x USB (Universal Serial Bus) 3.1 Gen 1 port (s) (4 at back panel, blue, 2 at mid-board) Intel Z370 Chipset: 6 x USB (Universal Serial Bus) 2.0 port (s) (4 at back panel, black, 2 at mid-board) Overclocking Features Clear CMOS button ROG Armor ROG RAMCache II ROG CPU-Z ROG Clone Drive Pre-mounted I/O Shield Mem OK! Button Slow Mode Overwolf Re Try Button Safe Boot Button Start Button Reset Button LN2 Mode Game First IV Extreme Engine Digi+ :
- Micro Fine Alloy Chokes
- Nex FET™ Power Block MOSFET
- 10K Black Metallic Capacitors Key Bot II
- X.M.P.
- Clr CMOS
- Power On UEFI BIOS features :
- O.C. Profile
- Tweakers Paradise
- ROG SSD Secure Erase
- Graphic Card Information Preview ROG RAMDisk Extreme Tweaker USB (Universal Serial Bus) BIOS Flashback Special Features ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 :
- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Expert 4, & Turbo App Gamers Guardian:
- Safe Slot Live Dash OLED 1.3 ” AURA :
- Aura Lighting Control
- Aura RGB Strip Headers
- Aura Lighting Effects Synchronization with compatible ASUS ROG devices
- Aura Addressable Strip Header (s) ASUS Exclusive Features :
- Mem OK!
- AI Suite 3 ASUS EZ DIY :
- ASUS Crash Free BIOS 3
- ASUS EZ Flash 3
- ASUS USB (Universal Serial Bus) BIOS Flashback ASUS Q-Design :
- ASUS Q-Code
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector Overclocking Protection :
- ASUS C.P.R. (CPU Parameter Recall) Back I/O Ports 1 x Display Port 1 x HDMI 1 x LAN (RJ45) port (s) 1 x USB (Universal Serial Bus) 3.1 Gen 2 (red) Type-A 1 x USB (Universal Serial Bus) 3.1 Gen 2 (black)USB Type-CTM 4 x USB (Universal Serial Bus) 3.1 Gen 1 (blue) 4 x USB (Universal Serial Bus) 2.0 1 x Optical S/PDIF out 5 x Audio jack (s) 1 x Clear CMOS button (s) 1 x USB (Universal Serial Bus) BIOS Flashback Button (s) 1 x ASUS 2x 2 Wi-Fi 802.11 a/b/g/n/ac & Bluetooth v 4.2 module Internal I/O 2 x Aura Addressable Strip Header (s) 2 x Aura RGB Strip Headers 1 x USB (Universal Serial Bus) 3.1 Gen 1 connector (s) support (s) additional 2 USB (Universal Serial Bus) 3.1 Gen 1 port (s) 1 x USB (Universal Serial Bus) 2.0 connector (s) support (s) additional 2 USB (Universal Serial Bus) 2.0 port (s) 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode) 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) 6 x SATA 6 Gb/s connector (s) 1 x CPU Fan connector (s) (1 x 4 -pin) 1 x CPU OPT Fan connector (s) (1 x 4 -pin) 3 x Chassis Fan connector (s) (3 x 4 -pin) 1 x H_AMP fan connector 1 x W_PUMP+ connector (1 x 4 -pin) 1 x AIO_PUMP connector (1 x 4 -pin) 1 x 24-pin EATX Power connector (s) 1 x 8-pin ATX 12V Power connector (s) 1 x Front panel audio connector (s) (AAFP) 1 x System panel (s) (Q-Connector) 1 x Mem OK! button (s) 1 x Slow Mode switch (es) 1 x Reset button (s) 1 x LN2 Mode jumper (s) 1 x Safe Boot button 1 x Re Try button 1 x EXT_ Fan header 1 x W_IN header 1 x W_OUT header 1 x W_FLOW header 1 x Thermal sensor connector 1 x Start button 1 x USB (Universal Serial Bus) 3.1 Gen 2 front panel connector Accessories Users manual 1 x ROG logo plate sticker 4 x SATA 6 Gb/s cable (s) 1 x M.2 Screw Package 1 x CPU installation tool 1 x Supporting DVD 1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant) 1 x SLI HB BRIDGE (2-WAY-M) 1 x ROG big sticker 1 x Q-Connector 1 x M.2 bracket 1 x Extension Cable for RGB strips (80 cm) 1 x Extension cable for Addressable LED 1 x ROG coaster (s) 1 x USB (Universal Serial Bus) 3.1 Gen 1 Header to USB (Universal Serial Bus) 2.0 adapter cable BIOS 1 x 128 Mb Flash ROM, UEFI AMI BIOS, Pn P, DMI3.0, Wf M2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, Crash Free BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 Print Screen, F3 Shortcut functions & ASUS DRAM SPD (Serial Presence Detect) memory information. Operating System Windows 10 64-bit Form Factor ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm ) Note *1 The PCIe x 4_3 slot shares bandwidth with PCIex 1_3. The PCIe x 4_3 is default set at x 2 mode. *2 When the M.2_1 Socket 3 is operating in SATA mode, SATA port 1 will be disabled. *3 When the M.2_2 Socket 3 is operating in PCIe 3.0 x 4 mode, SATA ports 5 & 6 will be disabled. *4 This function will work depending on the CPU installed. *5 Due to limitations in HDA bandwidth, 32-bit/192k Hz is not supported for 8-Channel audio * CPUs for Call of Duty: Black Ops 4 Deluxe Edition 9900K 9700K 8086K 8700K 9600K 8600K CPUs for Call of Duty: Black Ops 4 Standard Edition 8600 8500 8400








































...

Features LGA1151 socket: Ready for 9th/8th Generation Intel Core™ desktop processors. Synchronised RGB lighting technology: Works with a vast portfolio of Aura Sync-capable PC gear &

Includes:: support for addressable light strips & Phillip Hue Perfected cooling: Dedicated water-cooling zones, M.2 heatsink & flexible fan controls. ROG DIMM.2: Vertically-installed dual-M.2 expansion card with heatsink for maximum cooling & performance. 5-Way Optimisation: Automated system-wide tuning, providing AI overclocking & cooling profiles tailor-made for your rig. Gaming connectivity: Intel Gigabit Ethernet, onboard 5 Gbps Ethernet, four M.2, USB (Universal Serial Bus) 3.1 Gen 2, CNVi 2x 2 802.11ac Intel integrated Wi-Fi with MU-MIMO support for lightning-fast data transfers Gaming audio: High-fidelity sonics that draw you deeper into the action, with Supreme FX & Sonic Studio III. Gaming durability: ASUS Safe Slot, patented pre-mounted I/O shield & premium components for maximum durability. Overview Maximus XI Extreme unleashes the power of the latest Intel Z390 platform for the best gaming experiences. With optimised overclocking, high-speed memory support & comprehensive water & fan cooling controls, Maximus XI Extreme delivers ultimate performance combined with efficient, reliable operation. A blacked-out aesthetic & Aura Sync RGB lighting provide striking, customisable styling for a gaming system with the looks to match its formidable power. THRILLING PERFORMANCE Weve rethought & refined every aspect of Maximus XI Extreme to provide the foundation for extreme gaming systems that deliver the highest performance with efficient cooling. Featuring premium components, multiple fan headers, four M.2 slots, high speed memory support & onboard 5G Ethernet, Maximus Extreme is ready to take your gaming experience to new heights. CONTROL YOUR RIG Maximus XI Extreme is packed with intuitive & flexible tools that let you customize every aspect of your system to deliver the performance & features you want. Take advantage of 5-Way Optimization for intelligent, automatic overclocking or enjoy full manual control via comprehensive BIOS settings. Together with customizable audio profiles & tools to optimize storage & networking performance, Maximus XI Extreme gives you the ability to create an expertly tuned machine with minimal effort. PERSONALIZED FOR YOU In addition to extraordinary performance, Maximus XI Extreme provides extensive styling & customization options to let you build a system that truly stands apart. With a Live Dash OLED panel for displaying system stats & custom graphics & AURA RGB lighting that synchronizes with a vast ecosystem of compatible products, Maximus XI Extreme is primed for endless personalization.

...

Features LGA1151 socket: Ready for 9th/8th Generation Intel Core™ desktop processors Crosschill EK III & Water Cooling Zone: Keep your system cool when the action heats up ROG Eco-System: ASUS-exclusive Aura Sync RGB lighting, including headers for both standard & addressable RGB strips Gaming connectivity: Aquantia 5G LAN & Intel Gigabit Ethernet onboard, dual M.2, USB (Universal Serial Bus) 3.1 Gen 2, Intel 2x 2 802.11ac Wi-Fi with MU-MIMO support, LANGuard & Game First 5-way Optimization: Automated system-wide tuning, providing AI Overclocking & cooling profiles tailor-made for your rig Gaming Audio: Supreme FX & Sonic Studio III – High fidelity audio that draws you deeper into the action Gaming durability: ROG RGB Armor, ROG patented pre-mounted I/O shield, ASUS Safe Slot, & premium components for maximum durability Overview THE FORMULA ROG Maximus XI Formula exhibits the sleek, refined & functional design that has become iconic in the Maximus motherboard series. With its distinctive integrated Cross Chill EK III cooling block, intelligent overclocking software & a stunning polished-mirror finish, the latest-generation Formula is all set to make your showcase rig shine. THRILLING PERFORMANCE Building on over a decade of ROG engineering & refinement, Formula is the motherboard that lets you push the boundaries while keeping the thermals in check & under careful control. CONTROL YOUR RIG Fast, intuitive control is vital for effective command of your rig, so weve loaded ROG Maximus XI Formula with simple, flexible tools that let you tweak almost every system aspect. Enjoy intelligent automated tuning with 5-Way Optimization technology, or dive deep into the revered ROG UEFI BIOS to take full manual control. Formula also makes short work of fine-tuning everything from sonics to storage, so its easy to get every part of your system up to speed. PERSONALIZED FOR YOU With Aura Sync to unleash synchronized illumination effects that extend from motherboard to a vast ecosystem of compatible components, & the Live Dash OLED panel to display system stats & custom visuals, ROG Maximus XI Formula is primed for endless personalization. ...

Features LGA1151 socket for 9th/8th -gen Intel Core™ desktop processors Synchronized RGB lighting technology works with a vast portfolio of Aura Sync-capable PC gear &

Includes:: support for addressable light strips & Philips Hue Perfected cooling with dedicatedwater cooling zones, M.2 heatsink & various fan controls Gaming connectivity: Intel Gigabit Ethernet, LANGaurd, dual M.2, USB (Universal Serial Bus) 3.1 Gen 2, & 802.11AC Wi-Fi 5-way Optimization: Automated system-wide tuning, providing AI Overclocking & cooling profiles tailor-made for your rig Gaming Audio: Supreme FX & Sonic Studio III – High fidelity audio that draws you deeper into the action Gaming durability: ASUS Safe Slot & premium components for maximum durability Overview THE HERO ROG Maximus XI Hero is the perfect introduction to the Republic of Gamers. Its a Z390 gaming motherboard that packs substantial power, smart cooling & faster memory support under a stealthy skin. Loaded with renowned ROG features, from one-click overclocking & cooling to attention-grabbing Aura Sync illumination, Maximus XI Hero is ready to perform & crafted for customization. THRILLING PERFORMANCE With a dedicated onboard clock generator, support for the latest high-performance memory, & cooling options to keep thermals under tight control, Hero provides a potent foundation for your next gaming build. CONTROL YOUR RIG Fast, intuitive control is vital for effective command of your rig, so weve loaded ROG Maximus XI Hero with simple, flexible tools that let you tweak almost every system aspect. Enjoy intelligent automated tuning with 5-Way Optimization technology, or dive deep into the revered ROG UEFI BIOS to take full manual control. Hero also makes short work of fine-tuning everything from audio to storage, so its easy to get every part of your system up to speed. PERSONALIZED FOR YOU With Aura Sync to unleash synchronized effects that extend from motherboard to a vast ecosystem of compatible components, ROG Maximus XI Hero is primed for endless personalization.

...

CPU Socket 1151 for 9th / 8th Gen Intel Core™, Pentium Gold & Celeron processors Supports 14nm CPU Supports Intel Turbo Boost Technology 2.0* * Intel Turbo Boost Technology 2.0 support depends on the CPU types Chipset Intel Z390 Chipset Memory " 4 x DIMM, Max. 64GB DDR4 4400 (OC)*/4266 (OC)*/4133 (OC)*/4000 (OC)*/3866 (OC)*/3733 (OC)*/3600 (OC)*/3466 (OC)*/3400 (OC)*/3333 (OC)*/3300 (OC)*/3200 (OC)*/3000 (OC)*/2800 (OC)*/2666/2400/2133 MHz, Non-ECC, Un-buffered memory " Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) * Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please refer to Memory QVL (Qualified Vendors List) for details. Expansion Slots Socket 1151 for 9th / 8th Gen Intel Core™, Pentium Gold & Celeron processors 2 x PCIe 3.0 x 16 slots (@x 16 or x 8/x 8, x 8/x 4+x 4)* Intel Z390 Chipset 1 x PCIe 3.0 x 16 slot (max. at x 4 mode)* 3 x PCIe 3.0 x 1 slots * The PCIe x 16_3 slot shares bandwidth with SATA6G_5 & SATA6G_6. The PCIe x 16_3 runs x 2 mode by default. Graphic Integrated Graphics Processor
- Intel UHD Graphics support Multi-VGA output support: HDMI/ Display Port -Supports Display Port 1.2 with max. resolution 4096 x 2304 @ 60 Hz - Supports HDMI 1.4b with max. resolution 4096 x 2160@30 Hz Multi-GPU Support Supports NVIDIA 2-Way/ Quad-GPU SLI™ Technology Supports AMD 3-Way/ Quad-GPU Cross Fire X™ Technology Storage Intel Z390 Chipset with RAID 0, 1, 5, 10, & Intel Rapid Storage Technology support
- 1 x M.2_1 Socket 3 with M Key, type 2242/2260/2280 (supports PCIE 3.0 x 4 & SATA modes)*
- 1 x M.2_2 Socket 3 with M Key, type 2242/2260/2280/22110 (supports PCIE 3.0 x 4 mode)
- 6 x SATA 6 Gb/s ports - Intel Optane Memory Ready * When the M.2_1 Socket 3 is operating in SATA mode, SATA6G_2 port will be disabled. LAN Intel I219-V Gigabit LAN- Dual interconnect between the integrated Media Access Controller (MAC) & physical layer (PHY) Anti-surge LANGuard ROG Game First V Technology Audio ROG Supreme FX S1220 8-Channel High Definition Audio CODEC
- ESS ES9023P High Definition DAC
- High quality 120 d B SNR stereo playback output & 113 d B SNR recording input
- Impedance sense for front & rear headphone outputs
- Jack-detection, Multi-streaming, & Front Panel Jack-retasking
- Supreme FX Shielding Technology
- Supports up to 32-Bit/192k Hz playback* - Optical S/PDIF out port at back panel Audio

Features:
- Sonic Studio III + Sonic Studio Link
- Sonic Radar III * Due to limitations in HDA bandwidth, 32-Bit/192k Hz is not supported for 8-Channel audio. USB Intel Z390 Chipset
- 4 x USB (Universal Serial Bus) 3.1 Gen 1 ports (2 ports at back panel [blue], 2 ports at mid-board)
- 6 x USB (Universal Serial Bus) 2.0 ports (2 ports at back panel [black], 4 ports at mid-board)
- 4 x USB (Universal Serial Bus) 3.1 Gen 2 ports (3 Type-A [red] & 1 Type-C [black] at back panel)
- 1 x USB (Universal Serial Bus) 3.1 Gen 2 front panel connector ROG Exclusive Features Extreme Engine Digi+ - Micro Fine Alloy Choke - Opti MOS Power Stage - 10K Black Metallic Capacitors Start Button Retry Button Extreme Tweaker ROG Exclusive Software
- Mem Tweakit&12288;
- RAMCache III&12288;
- RAMDisk&12288;
- CPU-Z&12288;
- Game First V
- Sonic Studio III + Sonic Studio Link
- Sonic Radar III AURA
- Aura Lighting Control
- Aura RGB Strip Headers
- Aura Addressable Strip Headers
- Aura Lighting Effects Synchronization with compatible ASUS ROG devices Special Features ASUS Dual Intelligent Processors 5
- 5-Way Optimization tuning key perfectly consolidates TPU Insight, EPU Guidance, DIGI+ VRM, Fan Xpert 4, & Turbo App ASUS Exclusive Features
- Mem OK! II
- Opti Mem II
- Pre- mounted I/O shield - AI Suite 3 - USB (Universal Serial Bus) BIOS Flashback - ASUS Crash Free BIOS 3 - ASUS EZ Flash 3 - ASUS C.P.R. (CPU Parameter Recall)
- Ai Charger
- BUPDATER
- Armoury Crate - ASUS NODE: hardware control interface
- BIOS Flashback Button
- Clear CMOS Button
- Reset Button ASUS Q-Design - Q-Code - Q-Connector - Q-LED (CPU[red], DRAM[yellow], VGA[white], Boot Device LED[green]) - Q-DIMM Back I/O 1 x Clear CMOS Button 1 x BIOS Flashback Button 1 x HDMI 1.4b 1 x Display Port 1.2 2 x USB (Universal Serial Bus) 2.0 ports [black] 2 x USB (Universal Serial Bus) 3.1 Gen 1 ports [blue] 1 x Anti-surge LAN (RJ45) port 4 x USB (Universal Serial Bus) 3.1 Gen 2 ports (3 x Type-A [red] & 1 x Type-C) 1 x Optical S/PDIF out 1 x PS/2 keyboard/mouse combo port 5 x Gold-plated audio jacks Internal I/O Ports 2 x AURA Addressable RGB headers 2 x AURA RGB strip headers 1 x USB (Universal Serial Bus) 3.1 Gen 1 header supports additional 2 USB (Universal Serial Bus) 3.1 Gen 1 ports 2 x USB (Universal Serial Bus) 2.0 headers support additional 4 USB (Universal Serial Bus) 2.0 ports 1 x USB (Universal Serial Bus) 3.1 Gen 2 front panel connector 1 x M.2_1 Socket 3 with M Key, type 2242/2260/2280 (supports PCIE 3.0 x 4 & SATA modes) 1 x M.2_2 Socket 3 with M Key, type 2242/2260/2280/22110 (supports PCIE 3.0 x 4 mode) 1 x TPM connector 6 x SATA 6 Gb/s ports 1 x 4-Pin CPU_FAN connector 1 x 4-Pin CPU_OPT fan connector 3 x 4-Pin Chasis fan connectors 1 x 4-Pin AIO_PUMP connector 1 x 4-Pin H_AMP fan connector 1 x 4-Pin W_PUMP+ connector 1 x 5-pin EXT_FAN connector 1 x 2-pin W_IN connector 1 x 2-pin W_OUT connector 1 x 3-pin W_FLOW connector 1 x T_ SENSOR connector 1 x 24-pin EATX power connector 1 x 8-pin EATX 12V power connector 1 x 4-pin EATX 12V power connector 1 x Front panel audio connector (AAFP) 1 x Mem OK!_II switch 1 x Reset button 1 x Retry button 1 x System panel connector 1 x Start button 1 x NODE connector Accessories 1 x User guide 1 x ROG motherboard support DVD 2 x 2-in-1 SATA 6 Gb/s cables 1 x Extension Cable for RGB strips 1 x Extension Cable for RGB Addressable strips 1 x SLI™ HB bridge (2-way-M) 1 x Q-Connector 1 x ROG Coaster 1 x M.2 screws package 1 x ROG Thank you card 1 x ROG sticker BIOS 1 x 128 Mb Flash ROM, UEFI AMI BIOS, Pn P, DMI3.0, SM BIOS 3.1, ACPI 6.1 Manageability WOL, PXE Software Win RAR Overwolf Kaspersky Anti-Virus DAEMON Tools Software Operating System Support Windows 10 64-bit Form Factor ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm) * CPUs for Call of Duty: Black Ops 4 Deluxe Edition 9900K 9700K 8086K 8700K 9600K 8600K CPUs for Call of Duty: Black Ops 4 Standard Edition 8600 8500 8400






































...

PERFORMANCE PUSHED TO THE APEX ROG Maximus XII Apex is the premiere overclocking platform for extreme OC enthusiasts looking to unlock the full potential of the latest generation Intel Core processors. Its optimized layout, enhanced power delivery & control, & striking design with a myriad of customization options will appeal to over clockers, gamers, & PC builders alike. AI Overclocking Tuning is now faster & smarter than ever before. AI Overclocking profiles the CPU & cooling to predict the optimal configuration for each system. OVERCLOCKING Push the performance envelope with hardware-level overclocking controls, intelligent power solution & enhanced memory support. Overclocker’s Toolkit An Overclocker’s Tookit with hardware-level controls will aid your overclocking experience. They’re quick & easy time-savers designed to help you break more records. LN2 Mode Jumper to enable special options & functions for liquid-nitrogen (LN2) over-clocking. Retry Button One press instantly initiates a hard reset. ...
