Appearance Aluminium: steel grey Processor Intel Atom Bay Trail-T, Z3740 processor 1.33 to 1.8 G Hz 2M Cache Memory 2GB DDR3 RAM Hard Drive 32GB SSD Optical Drive None Software Operating System: Windows 8.1 (32bit) Microsoft Office full version included SKYPE Maxx Audio ASUS Win flash ASUS Live Update e Manual ASUS Web Storage Sync Agent ASUS Smart Gesture ATK Package (ASUS On Screen Display) ASUS Product Registration program KBFilter driver ASUS Installation Wizard Display 10.1” LED backlit slim TFT Wide view LCD display HD 1366x 768 16:9 Display type: (Typical 250-nit), 17ms response time NTSC 50% Glare support touch panel Graphics Intel HD Graphics Gen 7 Audio Built-in speaker Built-in microphone Input Devices Touchscreen Chiclet Keyboard ASUS 253.6mm keyboard with 17.43mm key pitch Networking WLAN: 802.11bgn Bluetooth 4.0 (Single band) LAN: 10/100/1000 Mbps Power Supply 10W AC Adapter Output: 5V DC, 2A, 10W Input: 100~240V AC, 50/60 Hz universal 31 W Hrs, 8060m Ah, 1S2P, 2-cell Li-ion polymer Battery pack Up to 11 hours battery

Dimensions 0.89kg (Without Battery) 1.03kg (with 2 cell battery) Tablet: 0.52kg (with 2 cell Battery) Dock: 0.50kg (with 0 cell Battery) 26.3 (W) x 17.1 (D) x 2.36 ~ 2.36 (H) cm 26.3 (W) x 17.1 (D) x 1.05 ~ 1.05 (H) cm Interfaces 1 x USB (Universal Serial Bus) 3.0 1 x Micro USB2.0 1 x Headphone-out & Audio-in Combo Jack 1 x micro HDMI Expansion Card Reader Warranty / Miscellaneous 1 Year Manufacturer Warranty 1.2 Mega Pixel web camera (Fixed type)

...

Processor Intel Atom Bay Trail-T, Z3740 processor 1.33 to 1.8 G Hz 2M Cache Memory 2GB DDR3 RAM Hard Drive 32GB SSD with Unlimited ASUS Web Storage (1 year trial) Optical Drive None Software Operating System: Windows 8.1 32bit Display 10.1” LED backlit slim TFT Wide view LCD display HD 1366x 768 16:9 Display type: (Typical 250-nit), 17ms response time NTSC 50% Glare support touch panel Graphics Intel HD Graphics Gen 7 Audio Built-in speaker Built-in microphone Input Devices Touchscreen Chiclet Keyboard ASUS 253.6mm keyboard with 17.43mm key pitch Networking WLAN: 802.11bgn Bluetooth 4.0 (Single band) LAN: 10/100/1000 Mbps Power Supply 10W AC Adapter Output: 5V DC, 2A, 10W Input: 100~240V AC, 50/60 Hz universal 31 W Hrs, 8060m Ah, 1S2P, 2-cell Li-ion polymer Battery pack Up to 11 hours battery

Dimensions 0.89kg (Without Battery) 1.03kg (with 2 cell battery) Tablet: 0.52kg (with 2 cell Battery) Dock: 0.50kg (with 0 cell Battery) 26.3 (W) x 17.1 (D) x 2.36 ~ 2.36 (H) cm 26.3 (W) x 17.1 (D) x 1.05 ~ 1.05 (H) cm Interfaces 1 x USB (Universal Serial Bus) 3.0 1 x Micro USB2.0 1 x Headphone-out & Audio-in Combo Jack 1 x micro HDMI Expansion Card Reader Warranty / Miscellaneous 1 Year Manufacturer Warranty 1.2 Mega Pixel web camera (Fixed type)

...

Processor Intel Atom Bay Trail-T, Z3740 processor 1.33 to 1.8 G Hz 2M Cache Memory 2GB DDR3 RAM Hard Drive 64GB SSD Optical Drive None Software Operating System: Windows 8 Pro Display 10.1” LED backlit slim TFT Wide view LCD display HD 1366x 768 16:9 Display type: (Typical 250-nit), 17ms response time NTSC 50% Glare support touch panel Graphics Intel HD Graphics Gen 7 Audio Built-in speaker Built-in microphone Input Devices Touchscreen Chiclet Keyboard ASUS 253.6mm keyboard with 17.43mm key pitch Networking WLAN: 802.11bgn Bluetooth 4.0 (Single band) LAN: 10/100/1000 Mbps Power Supply 10W AC Adapter Output: 5V DC, 2A, 10W Input: 100~240V AC, 50/60 Hz universal 31 W Hrs, 8060m Ah, 1S2P, 2-cell Li-ion polymer Battery pack Up to 11 hours battery

Dimensions 0.89kg (Without Battery) 1.03kg (with 2 cell battery) Tablet: 0.52kg (with 2 cell Battery) Dock: 0.50kg (with 0 cell Battery) 26.3 (W) x 17.1 (D) x 2.36 ~ 2.36 (H) cm 26.3 (W) x 17.1 (D) x 1.05 ~ 1.05 (H) cm Interfaces 1 x USB (Universal Serial Bus) 3.0 1 x Micro USB2.0 1 x Headphone-out & Audio-in Combo Jack 1 x micro HDMI Expansion Card Reader Warranty / Miscellaneous 1 Year Manufacturer Warranty 1.2 Mega Pixel web camera (Fixed type)

...

Processor Intel Atom Bay Trail-T, Z3740 processor 1.33 to 1.8 G Hz 2M Cache Memory 2GB DDR3 RAM Hard Drive 64GB SSD Optical Drive None Software Operating System: Windows 8 Pro (32bit) Display 10.1” LED backlit slim TFT Wide view LCD display HD 1366x 768 16:9 Display type: (Typical 250-nit), 17ms response time NTSC 50% Glare support touch panel Graphics Intel HD Graphics Gen 7 Audio Built-in speaker Built-in microphone Input Devices Touchscreen Chiclet Keyboard ASUS 253.6mm keyboard with 17.43mm key pitch Networking WLAN: 802.11bgn Bluetooth 4.0 (Single band) LAN: 10/100/1000 Mbps Power Supply 10W AC Adapter Output: 5V DC, 2A, 10W Input: 100~240V AC, 50/60 Hz universal 31 W Hrs, 8060m Ah, 1S2P, 2-cell Li-ion polymer Battery pack Up to 11 hours battery

Dimensions 0.89kg (Without Battery) 1.03kg (with 2 cell battery) Tablet: 0.52kg (with 2 cell Battery) Dock: 0.50kg (with 0 cell Battery) 26.3 (W) x 17.1 (D) x 2.36 ~ 2.36 (H) cm 26.3 (W) x 17.1 (D) x 1.05 ~ 1.05 (H) cm Interfaces 1 x USB (Universal Serial Bus) 3.0 1 x Micro USB2.0 1 x Headphone-out & Audio-in Combo Jack 1 x micro HDMI Expansion Card Reader Warranty / Miscellaneous 1 Year Manufacturer Warranty 1.2 Mega Pixel web camera (Fixed type)

...

Processor Intel Atom Bay Trail-T, Z3775 processor 1.46 to 2.39 G Hz 2M Cache Memory 2GB DDR3 RAM Hard Drive 32GB SSD Optical Drive None Software Operating System: Windows 8.1 Display 10.1" LED backlit slim TFT Wide view LCD display HD 1366x 768 16:9 Graphics Intel HD Graphics Audio Built-in speaker Built-in microphone Input Devices Touchscreen Chiclet Keyboard ASUS 253.6mm keyboard with 17.43mm key pitch Networking WLAN: 802.11bgn Bluetooth 4.0 (Single band) LAN: 10/100/1000 Mbps Power Supply 10W AC Adapter Output: 5V DC, 2A, 10W Input: 100~240V AC, 50/60 Hz universal 31 W Hrs, 8060m Ah, 1S2P, 2-cell Li-ion polymer Battery pack Up to 11 hours battery

Dimensions 0.89kg (Without Battery) 1.03kg (with 2 cell battery) Tablet: 0.52kg (with 2 cell Battery) Dock: 0.50kg (with 0 cell Battery) 26.3 (W) x 17.1 (D) x 2.36 ~ 2.36 (H) cm 26.3 (W) x 17.1 (D) x 1.05 ~ 1.05 (H) cm Interfaces 1 x USB (Universal Serial Bus) 3.0 1 x Micro USB2.0 1 x Headphone-out & Audio-in Combo Jack 1 x micro HDMI Expansion Card Reader Warranty / Miscellaneous 1 Year Manufacturer Warranty 1.2 Mega Pixel web camera (Fixed type)

...

Technical Specifications Processor Intel Quad-Core Atom Bay Trail-T, Z3775 1.46 G Hz Up to 2.39 GHz 2 MB cache Memory 2GB On board memory Hard Drive 32GB e MMC 500GB 5400RPM 2.5” HDD Optical Drive None Software Operating System: Windows 8.1 (32bit) Microsoft Office 2013 Trial 30 days Display 11.6” HD Ultra Slim Touch Screen LED-backlit Resolution 1366 x 768 Audio Built-in array microphone Built-in speaker Sonic Master Input Devices Illuminated Chiclet Keyboard ASUS 268mm keyboard with 18.4mm key pitch Networking Integrated 802.11 a/b/g/n Built-in Bluetooth V4.0 LAN 10/100 Mbps Power Supply 33W adapter output: 19V 1.75A input: 100-240V AC, 50/60 Hz universal 38 W Hrs, 2S1P, 2-cell Li-ion Polymer Battery Pack

Dimensions Width 305mm Depth 200mm Height 26mm Weight 1.65kg Interfaces 1 x USB (Universal Serial Bus) 3.0 1 x USB (Universal Serial Bus) 2.0 1 x Micro USB (Universal Serial Bus) 2.0 1 x HDMI 1 x Line-in Jack 1 x Headphone-out Jack 1 x Headphone-out & Audio-in Combo Jack Warranty/ Misc HD web camera + 5 Mega Pixel rear camera with Auto Focus

...

Appearance Vertical hairline with metal Processor Intel Core™ i 5-4200U 1.6 G Hz 3M Cache, Up to 2.30 GHz Mobile Intel HM86 Express Chipset Memory 4GB DDR3 RAM Hard Drive SATA3 256G M.2 SSD Optical Drive None Software Operating System: Windows 8 (64bit) Display 13.3” LED-backlit slim TFT LCD display, Resolution: FHD 1920x 1080 16:9 Aspect Ratio Display type (typical: 350 nits) 25ms response time NTSC:72% Glare Support touch panel Graphics Intel HD Graphics 4400 Audio Built-in speaker Built-in microphone Sonic Master Input Devices HD web camera Seamless Chiclet Keyboard ASUS 302mm keyboard with 19mm full size key pitch Touchpad Networking WLAN: 802.11bgn Bluetooth 4.0 (Single band) LAN: 10/100/1000 Mbps Power Supply 45W AC Adapter Output: 19V DC, 2.37A, 45W Input: 100~240V AC 50/60 Hz universal

Dimensions 34.2 (W) x 21.8 (D) x 2.40 ~ 2.40 (H) cm Tablet: 0.90kg (with 4 cell Battery) Dock: 0.80kg (with % cell Battery)" Interfaces SD only Card Reader 1 x USB (Universal Serial Bus) 3.0 1 x Headphone-out jack 1 x micro HDMI Warranty 1 Year Manufacturer Warranty

...

One TAICHI, Two Screens – Endless Flexibility ASUS TAICHI™ is an incredible fusion of notebook & tablet for unparalleled mobile flexibility. Lid open, TAICHI is a powerful notebook with a crystal-clear Full HD screen, Intel Core™ processor & backlit keyboard. Lid closed, TAICHI is a lightweight tablet with a slim, tapered profile & a multi-touch Full HD screen for intuitive fingertip control with Windows 8. 1. Notebook mode Lift the lid with one smooth motion & TAICHI becomes a fully featured notebook. The Full HD 11.6” or 13.3” screen features IPS technology for a vibrant image with wide viewing angles. The backlit keyboard with ambient light control & large multi-touch touchpad make light of productivity tasks, too. 2. Tablet mode Close the lid & TAICHI instantly be becomes a tablet with an 11.6” or 13.3” Full HD display. 10-point capacitive multi-touch gives complete fingertip control & the supplied stylus works just like a pen on paper for accurate handwritten notes & sketches, plus IPS technology keeps the image bright & clear. Built-in motion sensors also make TAICHI™ the ideal for mobile gaming, while dual-band Wi-Fi & Bluetooth 4.0 connect to the latest wireless devices. 3. Mirror mode TAICHI is more than just a mere table or notebook — mirror mode offers a unique way to share information. Mirror mode shows the same image on both back-to-back screens, so it’s perfect for showing a presentation without the need for a bulky projector or clumsy external monitor, or sharing a movie without worrying about where everyone will sit. IPS technology gives a wide 178° viewing angle, which means everyone gets the best view, too. 4. Dual-Screen mode In Dual Screen mode, TAICHI is no longer one computer — it’s two. Each back-to-back screen can be used separately with different apps: one with the keyboard & multi-touch touchpad; the other with the multi-touch screen & stylus. Dual-Screen mode is also ideal for presentations & the supplied Screen Share app lets the presenter see the script on one screen while the audience views slides on the other. Processor Intel Core i 7-3517U 1.9 G Hz Turbo Boost up to 3 G Hz 2 Cores 4MB Cache Memory 4GB RAM Hard Drive 256GB Solid State Drive Optical Drive None Software Operating System: Windows 8 64bit Display 11.6" Duo FHD IPS Touch, Finger Touch & stylus (Pen) on Screen A Graphics Intel HD Graphics Audio Integrated Speakers Input Devices Keyboard & Touchpad Touchscreen Networking WLAN: 802.11ABGN + WIDI Bluetooth 4.0 Warranty / Miscellaneous 1 Year MAnufacturer Warranty 5M Webcam & HD dual Webcam ...

Processor Intel Core i 7-3517U 1.9 G Hz Turbo Boost up to 3 G Hz 2 Cores 4MB Cache Memory 4GB RAM Hard Drive 256GB Solid State Drive Optical Drive None Software Operating System: Windows 8 64bit Display 11.6" Duo FHD IPS Touch, Finger Touch & stylus (Pen) on Screen A Graphics Intel HD Graphics Audio Integrated Speakers Inout Devices Keyboard & Touchpad Touchscreen Networking WLAN: 802.11ABGN + WIDI Bluetooth 4.0 Warranty / Miscellaneous 1 Year MAnufacturer Warranty 5M Webcam & HD dual Webcam ...

The slimmest & lightest 1920x 1200 resolution Full HD Android Tablet Feeling unsatisfied with the quality of an average screen? An upgrade to a FHD screen is what you need. The 1920x 1200 resolution is more exquisite & offers more details for a Full HD visual experience. The Super IPS+ offers 600nits of ultra bright backlight so it can be read easily, even under sunlight, at angles up to 178° wide. Screen toughness is also not a problem. As the 1st tablet with the latest generation Corning Gorilla Glass 2, the Infinity offers enhanced screen impact resistance so it’ll look great even after extended usage. Get immersed in entertainment on the Transformer Pad Infinity! The Fastest NVIDIA Tegra 3 CPU Ever Powered by the fastest NVIDIA Tegra 3 4-Plus-1™ chip around, the world’s 1st quad-core mobile CPU blazes at 1.6 G Hz, providing the Transformer Pad Infinity the power to browse the web & play 1080p HD video at lightning fast speeds. The snappier response time & better multi-tasking performance make the Transformer Pad Infinity a true mobile entertainment powerhouse. Processor NVIDIA Tegra 3 Quad-core CPU Memory 1GB RAM Hard Drive 64GB EMMC 8G life time ASUS Webstorage space Software Operating System: Android 4.0 ASUS launcher My Library My Net My Cloud @ Vibe Music asus webstorage File manager ASUS sync Super Note App Locker App Backup Tegra Zone Display 10.1" LED Backlight WUXGA (1920x 1200) Screen Super IPS+ 10 finger multi-touch support Audio High Quality Speaker High Quality Mic Input Devices Touchscreen Networking WLAN 802.11 b/g/n@2.4 G Hz Bluetooth V3.0+EDR Power Supply 9.5 hours; 25 Wh Li-polymer Battery 14 hours pad with dock; 25 Wh (pad) + 19.5 Wh (dock) Li-polymer Battery

Dimensions Width 263 mm Depth 180.8 mm Height 8.5 mm Weight 598 g Dock only: Width 263 mm Depth 180.8 mm Height 8~10.4mm Weight: 537g Pad with dock: Width 263 mm Depth 180.8 mm Height 16.5~18.9mm Weight: 1135g Interfaces Pad: 1 x 2-in-1 Audio Jack (Headphone / Mic-in) 1 x micro HDMI 1 x Micro SD Card Reader Mobile Dock: 1 x USB2.0 port 1 x SD Card Reader Sensor G-Sensor, Light Sensor, Gyroscope, E-compass, GPS Warranty / Miscellaneous 1 Year Manufacturer warranty 2 MP Front Camera 8 MP Rear Camera Auto focus (rear) with Flash BSI Sensor 5-element lens

...
