Processor Intel Core™ i 3-2365M Dual Core 1.4 G Hz, Intel Sandy Bridge Architecture, 3MB Cache Memory 4GB DDR3 1600 M Hz Hard Drive 500GB SATA Optical Drive DVD Writer Software Operating System: Windows 7 Professional Edition 64-bit (with Windows 8 Professional 64bit License & Restore Provided) Display 15.6" ASUS Colour-Shine Display Resolution: 1366 x 768 Graphics Intel HD Graphics 4000 with 128MB Memory Audio Integrated Sound System Networking Wireless (802.11b/g/n Wireless) 10/100/1000 Gigabit Fast Ethernet Bluetooth V4.0 Power Supply 3-4 Hours (up to 4 hours with power management) Interfaces 1 x External VGA Port 1 x USB (Universal Serial Bus) 3.0, 1 x USB (Universal Serial Bus) 2.0 1 x HDMI Port Expansion SD Card Reader Warranty / Miscellaneous 1 Year Manufacturer Warranty Integrated Webcam with Microphone ...

Processor Intel Core™ i 5-3337U Dual Core 1.8 G Hz, Turbo boost up to 2.7 G Hz 3MB Cache Memory 4GB DDR3 1600 M Hz Hard Drive 500GB SATA Optical Drive DVD Writer Software Operating System: Windows 7 Professional Edition 64-bit (with Windows 8 Professional 64bit License & Restore Provided) Display 15.6" ASUS Colour-Shine Display Resolution: 1366 x 768 Graphics Intel HD Graphics 4000 with 128MB Memory Audio Integrated Sound System Networking Wireless (802.11b/g/n Wireless) 10/100/1000 Gigabit Fast Ethernet Bluetooth V4.0 Power Supply 3-4 Hours (up to 4 hours with power management) Interfaces 1 x External VGA Port 1 x USB (Universal Serial Bus) 3.0, 1 x USB (Universal Serial Bus) 2.0 1 x HDMI Port Expansion SD Card Reader Warranty / Miscellaneous 1 Year Manufacturer Warranty Integrated Webcam with Microphone ...

DDR3 Dual channel Memory Dual-VGA output (RGB&DVI) ASUS EPU ASUS Turbo Key ASUS Anti-Surge Protection Direct X 10 Support CPU Intel Socket 775 Core 2 Quad/ Core 2 Extreme/ Core 2 Duo/ Pentium dual-core/ Celeron dual-core / Celeron Processors Support Intel 45nm Multi-Core CPU Intel Hyper-Threading Technology ready Support Enhanced Intel Speed Step Technology (EIST) Chipset Intel G41 / ICH7 Front Side Bus 1333/1066/800 MHz Refer to www.asus.com for Intel CPU support list Memory 2 x DIMM, Max. 8 GB, DDR3 1333 (O.C.)/1066/800 Non-ECC, Un-buffered Memory Dual Channel memory architecture Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List) Expansion Slots 1 x PCIe x 16 1 x PCIe x 1 2 x PCI VGA Integrated Intel GMA X4500 graphics Supports DVI with HDCP compliant with max. resolution 1920x 1200 (@ 60 Hz) Supports RGB with max. resolution 2048 x 1536 (@75 Hz) Supports Microsoft Direct X 10 Storage Southbridge 1 x Ultra DMA 100/66/33 4 x SATA 3 Gb/s ports LAN PCIE Gb LAN Audio ALC887 8-Channel High-Definition Audio CODEC USB 8 USB (Universal Serial Bus) 2.0/1.1 ports (4 ports at mid-board, 4 ports at back panel) ASUS Unique Features ASUS Crash Free BIOS 3 ASUS AI NET2 ASUS Q-Fan ASUS EZ Flash 2 ASUS My Logo 2 ASUS Anti-Surge ASUS Turbo Key ASUS Express Gate ASUS EPU 4 Engine Back Panel I/O Ports 1 x VGA 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x LAN (RJ45) port 4 x USB (Universal Serial Bus) 2.0/1.1 3 x Audio jacks 1 x DVI-D Internal I/O Connectors 2 x USB (Universal Serial Bus) connectors support additional 4 USB (Universal Serial Bus) ports 1 x CPU Fan connector 1 x Chassis Fan connector 1 x Front panel audio connector 1 x S/PDIF Out connector 1 x 24-pin EATXPWR Power connector 1 x 4-pin ATX 12V Power connector 4 x Serial ATA connectors 1 x System Panel connector 1 x IDE connector 1 x Parallel port 1 x COM BIOS 8 Mb Flash ROM, AMI BIOS, Pn P, DMI 2.0, Wfm 2.0, ACPI 2.0a, SMBIOS 2.5 Manageability WOL, PXE, WOR by Ring, PME Wake Up Accessories Users manual 1 x I/O Shield 1 x Ultra DMA 133/100/66 cable 2 x SATA cable (s) Support Disc Drivers ASUS PC Probe II ASUS Update Form Factor u ATX Form Factor 9.6 inch x 8 inch (24.4 cm x 20.3 cm ) ...

FSB 1333/1066/800 M Hz Dual-channel DDR3 1333 (OC)/1066/800 ASUS Anti-Surge ASUS Turbo Key Direct X10 support Express Gate & EPU CPU Intel Socket 775 Core™2 Quad/ Core™2 Extreme/ Core™2 Duo/ Pentium dual-core/ Celeron dual-core / Celeron Processors Compatible with Intel 05B/05A/06 processors Support Intel 45nm Multi-Core CPU * Refer to www.asus.com for Intel CPU support list Chipset Intel G41 /ICH7 Front Side Bus 1333/1066/800 MHz Memory 2 x 240-pin DIMM, Max. 8 GB, DDR3 1333 (O.C.)/1066/800 Non-ECC, Un-buffered Memory Dual Channel memory architecture Expansion Slots 1 x PCIe x 16 1 x PCIe x 1 2 x PCI VGA Integrated Intel GMA X4500 graphics Maximum shared memory of 1G Supports RGB with max. resolution 2048 x 1536 (@75 Hz) Supports Microsoft Direct X 10 Storage Southbridge 1 x Ultra DMA 100/66/33 4 x SATA 3 Gb/s ports LAN PCIe Gb LAN Audio ALC887 8-Channel AUDIO CODEC Supports Jack-detect & Multi-Streaming teconologies Supports S/PDIF out interface USB 8 USB (Universal Serial Bus) 2.0/1.1 ports (4 ports at mid-board, 4 ports at back panel) ASUS Unique Features ASUS My Logo 2 ASUS EZ Flash 2 ASUS Crash Free BIOS 3 ASUS Q-Fan ASUS Anti-Surge ASUS EPU-L ASUS Express Gate Turbo Key AI NET2 Overclocking Features SFS (Stepless Frequency Selection)
- FSB tuning from 200 M Hz to 800 M Hz at 1 M Hz increment Overclocking Protection
- ASUS C.P.R. (CPU Parameter Recall) Back Panel I/O Ports 1 x D-Sub 1 x Parallel port 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x LAN (RJ45) port 4 x USB (Universal Serial Bus) 2.0/1.1 1 x COM port 3 x Audio jacks Internal I/O Connectors 2 x USB (Universal Serial Bus) connectors support additional 4 USB (Universal Serial Bus) 2.0 ports 1 x IDE connector 4 x SATA connectors 1 x CPU Fan connector 1 x Chassis Fan connector 1 x High Definition front panel audio connector 1 x S/PDIF Out connector 1 x System Panel 1 x Internal Speaker connector 24-pin EATX power connector 4-pin ATX 12V Power connector BIOS 8 Mb Flash ROM, AMI BIOS, Pn P, DMI2.0, Wf M2.0, ACPI2.0, SMBIOS 2.5 Accessories Users manual 1 x Ultra DMA 133/100/66 cable 2 x SATA cable (s) I/O Shield Support Disc Drivers ASUS PC Probe II Anti-virus software (OEM version) ASUS Update Form Factor u ATX Form Factor 9.6 inch x 7.9 inch (24.4 cm x 20.1 cm )

...

Specifications CPU Intel Socket 775 Core™2 Quad/ Core™2 Extreme/ Core™2 Duo/ Pentium dual-core/ Celeron dual-core / Celeron Processors Compatible with Intel 05B/05A/06 processors Support Intel 45nm Multi-Core CPU * Refer to www.asus.com for Intel CPU support list Chipset Intel G41 /ICH7 Front Side Bus 1333/1066/800 MHz Memory 2 x 240-pin DIMM, Max. 8 GB, DDR2 1066 (O.C.)/800/667 Non-ECC, Un-buffered Memory Dual Channel memory architecture ** Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List) *** When installing total memory of 4GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended. Expansion Slots 1 x PCIe x 16 1 x PCIe x 1 2 x PCI Support PCIe 1.1 Architecture VGA Integrated Intel Graphics Media Accelerator (Intel GMA X4500)
- Supports Microsoft Direct X 10, Open GL 2.1
- Supports RGB with max. resolution 2048 x 1536@75 Hz Storage Southbridge 1 x Ultra DMA 100 4 x SATA 3 Gb/s ports LAN PCIe Gb LAN Audio High Definition Audio 6 -Channel CODEC Supports Jack-detect & Multi-Streaming teconologies Supports S/PDIF out interface USB (Universal Serial Bus) 8 USB (Universal Serial Bus) 2.0 ports (4 ports at mid-board, 4 ports at back panel) Overclocking Features SFS (Stepless Frequency Selection)
- FSB tuning from 200 M Hz to 800 M Hz at 1 M Hz increment Overclocking Protection
- ASUS C.P.R. (CPU Parameter Recall) Special Features ASUS My Logo 2 ASUS EZ Flash 2 ASUS Crash Free BIOS 3 ASUS Q-Fan Turbo Key AI NET2 Back Panel I/O Ports 1 x D-Sub 1 x Parallel 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x LAN (RJ45) port 4 x USB (Universal Serial Bus) 2.0/1.1 1 x COM port 6 -Channel Audio I/O Internal I/O Connectors 2 x USB (Universal Serial Bus) connectors support additional 4 USB (Universal Serial Bus) 2.0 ports 1 x IDE connector 4 x SATA connectors 1 x High Definition front panel audio connector 1 x S/PDIF Out connector System Panel 1 x Internal Speaker connector 1 x CD audio-in connector 24-pin EATX power connector 4-pin ATX 12V Power connector BIOS 8 Mb Flash ROM AMI BIOS, Pn P, DMI2.0, Wf M2.0, ACPI2.0, SMBIOS 2.5 Form Factor u ATX Form Factor 9.6 inch x 7.6 inch (24.4cm x 19.3cm)



...

Intel Core™ i 7 Processor Extreme Edition / Core™ i 7 Processor / Xeon 3500 Series Processor Intel X58 / ICH10R True 16+2 Power Phase Design ASUS EPU 6-Engine & Turbo V ATI Cross Fire X & NVIDIA SLI Support 2 onboard SAS ports PCI-X Architecture G.P. Diagnosis Card Bundled ASUS Express Gate 100% High-quality Japan-made Conductive Polymer Capacitors! CPU Intel Socket 1366 Core™ i 7 Processor Extreme Edition/ Core™ i 7 Processor/ LGA1366 socket for Intel Xeon processor 3500 Series LGA1366 socket for Intel Xeon processor E5502/E5504/E5506 Supports Intel Dynamic Speed Technology * Refer to www.asus.com for Intel CPU support list Chipset Intel X58 / ICH10R System Bus Up to 6400 MT/s ; Intel Quick Path Interconnect Memory 6 x DIMM, Max. 24 GB, DDR3 2000 (O.C.)*/1866 (O.C.)*/1800 (O.C.)*/1600 (O.C.)/1333/1066 ECC, Non-ECC, Un-buffered Memory Triple channel memory architecture Support Intel Extreme Memory Profile (XMP) * Hyper DIMM (DDR3 1800 M Hz or above) support is subject to the physical characteristics of individual CPUs. ** Refer to www.asus.com. Or user manual for the Memory QVL (Qualified Vendor Lists.) *** ECC memory support requires Intel Nehalem-WS 1S W3500 series or Nehalem-EP E5502/E5504/E5506 processors Expansion Slots 2 x PCIe 2.0 x 16 (at x 16 / x 16 mode) 1 x PCIe x 1 1 x PCI 2.2 2 x PCI-X Multi-GPU Support Supports NVIDIA 2-Way Geforce SLI or Quad-GPU SLI™ Technology* Supports ATI Cross Fire X™ Technology * SLI support may need driver update. Visit www.asus.com for more details. Storage Intel ICH10R controller 6 x SATA 3 Gb/s ports Intel Matrix Storage Support RAID 0, 1, 5, 10 Marvell 88SE6320 SAS controller 2 x SAS ports supporting SAS RAID 0, 1 Marvell 88SE6121 SATA controller 2 x External SATA 150/300 (SATA On-the-G0), supporting SATA RAID 0, 1 LAN 2 x Realtek 8111C PCIe Dual Gigabit LAN controllers
- Support teaming function Audio ADI 2000B, 8 -Channel High Definition Audio CODEC Multi-Streaming Jack-Sensing Front Panel Jack-Retasking Coaxial / Optical S/PDIF out ports at back I/O ASUS Noise-Filer IEEE 1394 LSI Agere FW3227 controller supports 2 x 1394a ports USB 12 USB (Universal Serial Bus) 2.0 ports ASUS Workstation Special Features G.P. Diagnosis Card bundled ASUS SASsaby Cards support ASUS WS Diag. LED ASUS WS Heartbeat SAS Onboard Special Features EPU
- 6 Engine True 16+2 Phase Power Design Turbo V Fan Xpert Express Gate AI Nap Q-Shield Q-Connector Fanless Design: Heat-pipe solution Fanless Design: Stack Cool 2 My Logo 2 Crash Free BIOS 3 EZ Flash 2 C.P.R. (CPU Parameter Recall) SFS (Stepless Frequency Selection) O.C. Profile Back Panel I/O Ports PS/2 KB/MS combo port 2 x RJ45 S/PDIF Out (Coaxial + Optical) 6 x USB (Universal Serial Bus) 2.0/1.1 ports 2 x e SATA 1 x IEEE1394a 1 x 8-channel Audio I/O Internal I/O Connectors 24-pin EATX Power connector 8-pin ATX +12V Power connector Chassis intrusion CPU fan with PWM control Chassis fan 1 with Q-fan control Chassis fan 2 with Q-fan control Chassis fan 3 w/o Q-fan control PWR fan CD audio in 3 x USB (Universal Serial Bus) connectors support additional 6 USB (Universal Serial Bus) ports 20-pin Panel connector 1 x IEEE 1394a port TPM header S/PDIF Out header Front panel connector BIOS 16 Mb Flash ROM AMI BIOS, Green, Pn P, DMI v 2.0, Wfm 2.0, ACPI v 2.0a, SMBIOS v 2.4BIOS flash utility under DOS Manageability WOL/WOR by PME, WOR by Ring, AI NET2, Chassis Intrusion Support Disc AI Suite ASUS Update ASUS PC Probe II Anti-Virus Software (OEM version) Adobe Acrobat Reader ver 8.0 Microsoft Direct X ver 9.0C Image-Editing Suite Form Factor ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.5 cm )

...

CPU Intel Socket 1366 Core i 7 Processor Extreme Edition/ Core i 7 Processor Supports Intel Dynamic Speed Technology (Refer to www.asus.com for Intel CPU support list) Chipset Intel X58 + ICH10R Nvidia n Force 200 System Bus Up to 6400 MT/s ; Intel Quick Path Interconnect Memory 6 x DIMM, Max. 24 GB, DDR3 2000 (O.C.)*/1866 (O.C.)*/1800 (O.C.)*/1600 (O.C.)/1333/1066 ECC, Non-ECC, Un-buffered Memory Triple channel memory architecture Support Intel Extreme Memory Profile (XMP) * Hyper DIMM (DDR3 1800 M Hz or above) support is subject to the physical characteristics of individual CPUs. ** Refer to www.asus.com. Or user manual for the Memory QVL (Qualified Vendor Lists.) *** ECC memory support requires Intel Nehalem-WS 1S W3500 series or Nehalem-EP E5502/E5504/E5506 processors Expansion Slots 2 x PCIe 2.0 x 16 slots (at x 16 or x 8 mode) 1 x PCIe 2.0 x 16 slots (at x 16 mode) 2 x PCIe 2.0 x 16 slots (at x 8 mode) 1 x PCIe 2.0 x 16 slot (at x 4 mode) * True @ x 16 3-Way SLI™ in slots 1, 3 & 5 when slots 2 & 4 are not occupied Multi-GPU Support Supports NVIDIA 2-Way & 3-Way SLITM techonology Supports ATI Cross Fire XTM technology, up to Quad Cross Fire XTM Storage Intel ICH10R controller 6 x SATA 3 Gb/s ports Intel Matrix Storage supporting SATA RAID 0, 1, 10, & 5 Marvell 88SE6320 SAS controller 2 x SAS ports supporting SAS RAID 0, 1, 10* Marvell 88SE6121 SATA controller 2 x External SATA 150/300 (SATA On-the-G0), supporting SATA RAID 0, 1, 10, & 5** * A SAS expander (excluded in package) is required while using RAID 10 on SAS ports. ** A port-multiplier (excluded in package) is required while using RAID 5 or 10 on e SATA ports. *** Due to the Windows XP/ Vista limitation, the RAID array with the total capacity over 2TB cannot be set as a boot disk. A RAID array over 2TB can only be set as a data disk only. For more information, please refer to http://support.microsoft.com/kb/946557/en-us LAN 2 x Realtek 8111C Dual Gb LAN Support Teaming Technology Audio ADI 2000B, 8 -Channel High Definition Audio CODEC Multi-Streaming Jack-Sensing Front Panel Jack-Retasking Coaxial / Optical S/PDIF out ports at back I/O ASUS Noise-Filer USB 12 USB (Universal Serial Bus) 2.0 ports ASUS Workstation Special Features 6 PCIe Gen 2.0 x 16 slots G.P. Dignosis Card bunddle ASUS SASsaby Cards support ASUS WS Diag. LED ASUS WS Heartbeat SAS Onboard Special Features EPU
- 6 Engine True 16+2 Phase Power Design Turbo V Fan Xpert Express Gate AI Nap Q-Shield Q-Connector Fanless Design: Heat-pipe solution Fanless Design: Stack Cool 2 My Logo 2 Crash Free BIOS 3 EZ Flash 2 C.P.R. (CPU Parameter Recall) SFS (Stepless Frequency Selection) O.C. Profile Back Panel I/O Ports 1 x PS/2 Keyboard 1 x PS/2 Mouse 2 x External SATA 1 x S/PDIF Out (Coaxial + Optical) 2 x LAN (RJ45) port 6 x USB (Universal Serial Bus) 2.0/1.1 8 -Channel Audio I/O Internal I/O Connectors 24-pin EATX Power connector 8-pin ATX +12V Power connector Chassis intrusion CPU fan with PWM control Chassis fan 1 with Q-fan control Chassis fan 2 with Q-fan control Chassis fan 3 with Q-fan control PWR fan CD audio in 3 x USB (Universal Serial Bus) connectors support additional 6 USB (Universal Serial Bus) ports 20-pin Panel connector TPM header Front panel connector S/PDIF Out header BIOS 16 Mb Flash ROM AMI BIOS, Green, Pn P, DMI v 2.0, Wfm 2.0, ACPI v 2.0a, SMBIOS v 2.4
...

Intel Core™ i 7 Processor & Xeon processor supported Nvidia n Force 200 X2 CUDA Parallel computing supported 7 PCI-E Gen 2 x 16 IO onboard NVIDIA Geforce 2 & 3 way SLI Support CPU Intel Socket 1366 Core™ i 7 Processor Extreme Edition/ Core™ i 7 Processor LGA1366 socket for Intel Xeon processor 3500 Series LGA1366 socket for Intel Xeon processor E5502/E5504/E5506 Supports Intel Dynamic Speed Technology * Refer to www.asus.com for Intel CPU support list Chipset Intel X58 + ICH10R Nvidia NF200*2 System Bus Up to 6400 MT/s ; Intel Quick Path Interconnect Memory 6 x DIMM, Max. 24 GB, DDR3 2000 (O.C.)/1866 (O.C.)/1800 (O.C.)/1600 (O.C.)/1333/1066 ECC, Non-ECC, Un-buffered Memory Triple channel memory architecture * Support Intel Extreme Memory Profile (XMP) ** Due to Intel spec definition, DIMMs of DDR3-1800 or above are supported by specific CPU models only. *** Please load X.M.P or D.O.C.P setting in BIOS for hyper DIMM (DDR3 1800 M Hz or above) support." **** Refer to www.asus.com or this user manual for the Memory QVL (Qualified Vendors Lists) Expansion Slots 3 x PCIe 2.0 x 16 (@ x 16 or x 8) 3 x PCIe 2.0 x 16 (@ x 8) 1 x PCIe 2.0 x 16 (@ x 16) Multi-GPU Support Supports NVIDIA 3-Way Geforce SLI™ techonology Storage Intel ICH10R controller 6 x SATA 3 Gb/s ports Intel Matrix Storage Support RAID 0, 1, 5, 10 Ext Marvell 88SE6121 SATA controller 2 x e SATA 150/300 (RAID 0, 1)* Ext Marvell 88SE6320 SAS controller 2 x SAS (RAID 0, 1)* LAN 2 x Realtek 8111C Dual Gb LAN (Support teaming function) Audio ADI 2000B 8 -Channel High Definition Audio CODEC ASUS Noise Filter Multi-Streaming Jack-Sensing Front Panel Jack-Retasking Coaxial / Optical S/PDIF out ports at back I/O IEEE 1394 VIA VT6315N controller supports 1 x 1394a ports USB 12 USB (Universal Serial Bus) 2.0 ports ASUS Unique Features EPU
- 6 Engine True 16+2 Phase Power Design Turbo V Fan Xpert Express Gate AI Nap Q-Shield Q-Connector Fanless Design: Heat-pipe solution Fanless Design: Stack Cool 2 My Logo 2 Crash Free BIOS 3 EZ Flash 2 C.P.R. (CPU Parameter Recall) SFS (Stepless Frequency Selection) O.C. Profile ASUS Workstation Special Features 7 PCIe x 16 slots G.P. Diagnosis Card bundled ASUS SASsaby Cards support ASUS WS Diag. LED ASUS WS Heartbeat SAS Onboard Back Panel I/O Ports 2 x External SATA 1 x S/PDIF Out (Coaxial + Optical) 2 x LAN (RJ45) port 6 x USB (Universal Serial Bus) 2.0/1.1 8 -Channel Audio I/O PS/2 KB/MS port Internal I/O Connectors 24-pin EATX Power connector 8-pin ATX +12V Power connector Chassis intrusion CPU fan with PWM control Chassis fan 1 with Q-fan control Chassis fan 2 with Q-fan control Chassis fan 3 with Q-fan control PWR fan CD audio in 3 x USB (Universal Serial Bus) connectors support additional 6 USB (Universal Serial Bus) ports 20-pin Panel connector 1 x IEEE 1394a port TPM header S/PDIF Out header Front panel connector BIOS 16 Mb Flash ROM AMI BIOS, Green, Pn P, DMI v 2.0, Wfm 2.0, ACPI v 2.0a, SMBIOS v 2.4, BIOS flash utility under DOS Manageability WOL/WOR by PME, WOR by Ring, Chasis Intrusion, AI NET2 Support Disc ASUS PC Probe II ASUS AI Suite Anti-virus software (OEM version) ASUS Update Adobe Acrobat Reader ver 8.0 Microsoft Direct X ver 9.0C Image-Editing Suite Form Factor CEB Form Factor 12 inch x 10.5 inch (30.5 cm x 26.9 cm )
...

Intel LGA1156 Platform / Intel P55 Express Chipset True USB (Universal Serial Bus) 3.0 or SATA 6 Gb/s Support ASUS Hybrid Technology Turbo V EVO T. Probe Technology for Active Cooling ASUS 16 Hybrid Phase Design CPU Intel Socket 1156 Core i 7 Processor/ Core i 5 Processor/ Core i 3 Processor Supports Intel Turbo Boost Technology Chipset Intel P55 Express Chipset Refer to www.asus.com for full list of compatible processors Memory 4 x DIMM, Max. 16 GB, DDR3 2200 (O.C.)*/1600/1333/1066 Non-ECC, Un-buffered Memory Dual Channel memory architecture Supports Intel Extreme Memory Profile (XMP) Refer to www.asus.com or this user manual for the Memory QVL (Qualified Vendors Lists). Expansion Slots 1 x PCIe 2.0 x 16 (single at x 16) 1 x PCI Express 2.0 x 16 slots (@x 4 mode, 2.5GT/s, black slot) 3 x PCI Express 2.0 x 1 (2.5GT/s, gray slots) 2 x PCI Multi-GPU Support Supports ATI Quad-GPU Cross Fire X Technology Storage Intel P55 Express Chipset built-in 6 x SATA 3.0 Gb/s ports Intel Matrix Storage Technology Support RAID 0, 1, 5, 10 JMicron JMB363 PATA & SATA controller 1 x Ultra DMA 133/100/66 for up to 2 PATA devices 1 x External SATA 3 Gb/s port 1 x SATA 3 Gb/s port (black) Marvell SATA 6 Gb/s controller: 2 x SATA 6.0 Gb/s ports (gray) LAN Realtek 8112L Gigabit LAN controller featuring AI NET2 Audio VIA VT1828S 8-Channel High Definition Audio CODEC Absolute Pitch BD192/24 DTS Surround Sensation Ultra PC BD audio layer Content Protection Supports Jack-Detection, Multi-streaming, Front Panel Jack-Retasking Optical S/PDIF out ports at back I/O IEEE 1394 VIA 6308P controller supports 2 x 1394a port (s) (one at mid-board; one at back panel) USB NEC USB (Universal Serial Bus) 3.0 controller: 2 x USB (Universal Serial Bus) 3.0 ports (blue; at back panel) Intel P55 Express Chipset: 12 x USB (Universal Serial Bus) 2.0/1.1 ports (6 ports at mid-board, 6 ports at back panel) ASUS Unique Features ASUS IO Level UP for Ultra Performance True USB (Universal Serial Bus) 3.0 or True SATA 6 Gb/s Support ASUS Xtreme Design: ASUS Hybrid Processor Turbo V EVO Auto Tuning, Turbo V & Turbo Key 16 Hybrid Phase T. Probe Technology for Active Cooling 12+2 Phase Power Design 16 Hybrid Phase = 12+2 Phase x T. Probe ASUS Hybrid OS
- Express Gate ASUS Xtreme Design ASUS Exclusive Features Mem OK! ASUS EPU ASUS Quiet Thermal Solution ASUS Fanless Design: Stylish Heat-sink solution ASUS Fanless Design: Stack Cool 3 ASUS Fan Xpert ASUS Crystal Sound ASUS Noise Filter ASUS EZ DIY ASUS Q-Shield ASUS Q-Connector ASUS O.C. Profile ASUS Crash Free BIOS 3 ASUS EZ Flash 2 ASUS My Logo 2 Multi-language BIOS ASUS Q-Design ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) ASUS Q-Slot ASUS Q-DIMM Overclocking Features Precision Tweaker 2 v Core: Adjustable CPU voltage at 0.00625V increment v IMC: 97-step IMC voltage control v DRAM Bus: 104-step DRAM voltage control v PCH: 36-step chipset voltage control v CPU_PLL: 56-step reference voltage control SFS (Stepless Frequency Selection) PCI Express frequency tuning from 100 M Hz up to 200 M Hz at 1 M Hz increment Internal Base Clock tuning from 80 M Hz up to 500 M Hz at 1 M Hz increment Overclocking Protection ASUS C.P.R. (CPU Parameter Recall) Back Panel I/O Ports 1 x PS/2 mouse port (Green) 1 x PS/2 Keyboard (violet) 6 x USB (Universal Serial Bus) 2.0/1.1 1 x S/PDIF Out (Optical) 1 x IEEE 1394a 1 x External SATA 3 Gb/s 1 x LAN (RJ45) port 2 x USB (Universal Serial Bus) 3.0/2.0 ports (blue) 8 -Channel Audio I/O Internal I/O Connectors 3 x USB (Universal Serial Bus) connectors support additional 6 USB (Universal Serial Bus) ports 1 x IDE connector 1 x IEEE 1394a connector 1 x CPU Fan connector 1 x Power Fan connector 1 x COM port connector 2 x SATA 6.0 Gb/s connectors (gray) 7 x SATA 3.0 Gb/s connectors (blue from P55, black from JMB363) 2 x Chassis Fan connector (1x 4-pin, 1x 3-pin) Front panel audio connector 1 x S/PDIF Out Header CD audio in 24-pin ATX Power connector 1 x 8-pin ATX 12V Power connector System Panel (Q-Connector) 1 x Mem OK! button 1 x IO Level UP button BIOS 16 Mb Flash ROM, AMI BIOS, Pn P, DMI2.0, Wf M2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS Crash Free BIOS 3 Manageability Wf M 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE Accessories Users manual 1 x Ultra DMA 133/100/66 cable 2 in 1 Q-connector 2 x Serial ATA 6.0 Gb/s cables 2 x Serial ATA 3.0 Gb/s cables ASUS Q-Shield Support Disc Drivers ASUS Update ASUS Utilities Form Factor ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm )
...

P8B-E/4L is the latest ASUS UP serverboard designed as Bromolow platform flagship model, featuring an Intel C204 PCH chipset, leading SATA 6G storage technology, quad Intel server class Gb E, ASMB5-i KVM module (optional) for out-of-band remote management, & wide-range OS support, making it an ideal foundation for versatile & feature-rich UP solution. Processor / System Bus 1 x Socket LGA1155 Intel Xeon processor E3-1200 product family Intel Xeon processor E3-1200 v 2 product family Intel Core™ i 3-2100 Processor Family Intel Pentium™ G800/G600 Processor Family Intel Celeron™ G500/G400 Processor Family * Refer to asus for CPU Support list Core Logic Intel C204 Chipset Memory Total Slots: 4 (2-channel) Capacity: Maximum up to 32GB UDIMM Memory Type: DDR3 1600/1333/1066 UDIMM with ECC*1 Memory Size: 8GB, 4GB, 2GB, 1GB UDIMM Expansion Slots Total Slot: 6 Slot Location 1: PCI 32bit/33 M Hz Slot Location 2: PCI 32bit/33 M Hz Slot Location 3: PCI-E x 8 (Gen 2 X4 Link) Slot Location 4: PCI-E x 16 (Gen 3 X8 Link) *2 Slot Location 5: PCI 32bit/33 M Hz Slot Location 6: PCI-E x 16 (Gen 3 X16 Link), Auto switch to x 8 link if slot 4 is occupied *2 Additional Slot 1: PIKE Slot for Stroage expansion Follow SSI Location Form Factor ATX (12"x 9.6") ASUS Features FAN speed control Rack Ready (Rack & Pedestal dual use) Storage SATA Controller: Intel C204 2 x SATA3 6 Gb/s ports 4 x SATA2 3 Gb/s ports Intel Rapid Storage Technology (RST) (For Windows Only) (Support Software RAID 0, 1, 5, 10 ) LSI Mega RAID (For Linux/ Windows) (Support Software RAID 0, 1, 10 ) Networking 4 x Intel 82574L + 1 x Mgmt LAN Graphic Aspeed AST2050 with 16MB VRAM On Board I/O 1 x TPM header 1 x PSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector) 1 x Management Connector, Onboard socket for management card 1 x Internal A Type USB (Universal Serial Bus) Port 2 x USB (Universal Serial Bus) pin header, Up to 4 Devices 5 x Fan Header, 4pin (3pin/4pin fan dual support) 1 x SMBus 1 x Chassis Intruder 2 x Serial Port Header Back I/O Ports 2 x External USB (Universal Serial Bus) Port 1 x VGA Port 4 x RJ-45 1 x PS/2 KB/ Mouse ...
